Jumbuck JF118 User manual

Retain manual for future reference
BAR FRIDGE
118 & 228 LITRE
03561 03/17
Important: Retain these instructions for future use.
• Compressor refrigerator
• Adjustable shelves
• Interior light
• Adjustable thermostat for temperature control
• Magnetic door seal
• Height adjustable feet
• Powder coated black finish
• Size: 503mm W x 520mm D x 900mm H
118L Bar Fridge
Double Glazed Glass Door

2
Product Description
Inspect contents of the box to ensure all parts are
included and undamaged.
1. Double glazed glass door.
2. Adjustable thermostat control inside fridge.
3. Adjustable shelves.
4. Light is located at the top front of fridge cabinet.
5. Light switch.
6. Door lock.
4 2
3
1
65

3
SAFE OPERATION
Beware of Children and Pets
Children should not be allowed to touch or operate
refrigerators or touch extension cords, if used. All
refrigerators should be kept out of reach of children,
preferably stored or locked in a secure room when
not in use.
Do Not Abuse the Power Cord
Never yank or pull on the power cord to disconnect
it from the mains supply socket. Never carry or move
your refrigerator by it’s power cord. Keep the power
cord away from heat, oil, solvents and sharp edges.
Check the power cord regularly for any damage and if
the power cord becomes damaged have it replaced by
an authorised service facility.
Extension Cords and Reels
This refrigerator is NOT designed to run off an
extension cord. If you require an additional power
point please have one installed by a qualified
electrician.
The use of extension cords may cause power voltage
loss which will result in damage to the compressor
this will NOT be covered under warranty.
Installation & Operation
Electrical Installation
The electrical system of this refrigerator must be
connected with an automatic 30mA circuit breaker
and/or residual current device (RCD). If uncertain
have a qualified electrician check your electrical
system before installation and/or use.
Safety
Before attempting to operate this refrigerator, the
following basic safety precautions should be taken
to reduce the risk of fire, electric shock and personal
injury. It is important to read the instruction manual
and to understand it’s applications, limitations and
potential hazards associated with this refrigerator.
This refrigerator is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision
or instruction concerning the use of the appliance
by a person responsible for their safety. This
refrigerator is not designed for use within 1m or
above a water source. It is important that you read,
understand and follow these instructions very
carefully. They are designed for the safety of yourself
and others ensuring a long and trouble free service
life from your refrigerator. This electric refrigerator
complies with Australian and International
standards and safety requirements. Repairs should
only be carried out by qualified persons using
original spare parts. Failure to do so may result in
considerable danger to the operator.
NOTE: If using the refrigerator outside in an alfresco area ensure that it is directly connected to
an outdoors power point.
Ensure this fridge is not left in the weather or in direct sunlight.
The electrical system of this refrigerator must be connected with an automatic 30mA circuit breaker
and/or residual current device (RCD). If uncertain have a qualified electrician check your electrical
system before installation and/or use.
All electrical connections are to be made in a dry area.
Outdoor power points must be weatherproof and installed by a qualified electrician.
Sitro Group Australia Pty Ltd is not responsible for incorrectly located refrigerators.
FOR YOUR SAFETY

4
Specific Safety Instructions
WARNING
• NEVER use with the power cord coiled, bundled
up or tied up. Always extend fully before use.
• NEVER use the refrigerator if any part of it
is damaged.
• Ensure that the refrigerator is disconnected
from the mains supply when installing,
cleaning or removing/installing.
• Always turn the refrigerator OFF at the unit
switch and the power point switch when not
in use for extended periods of time.
• Always ensure that the power cord is fully
extended.
• Always ensure that the refrigerator is kept
clean and free from dust.
• Never use refrigerator with cracked/broken
glass - replace glass before use.
• Only use this refrigerator on flat and level
ground.
• Before you throw away your old refrigerator,
take off the door, leave the shelves in place, so
that children may not easily climb inside.
• Never allow children to operate, play with or
crawl inside the appliance.
• This refrigerator is not designed for perishable
foods. It is a drinks refrigerator.
• Adults and children should never sit or stand
on the fridge as injury may occur.
Do not use the refrigerator in areas where there
is a risk of explosion or fire from flammable
gases. Ensure that the area is kept clear
of combustible materials. Do not use the
refrigerator in damp areas, without suitable
ventilation. This refrigerator is not designed for
use within 1m or above a water source. Do not
place within one metre (1m) of any water source.
Fire risk exists if this refrigerator is covered by or
positioned close to curtains or other combustible
materials.
• This refrigerator is intended for domestic/
household use only.
• DO NOT use this refrigerator in either the
bathroom or ensuite.
• DO NOT use a 3rd party timer, or
programmable system with this refrigerator.
• DO NOT clean the refrigerator while the
refrigerator is on or plugged into the mains
power supply.
• DO NOT attempt to modify the refrigerator,
power cord, power plug or the supplied
accessories in any way.
• DO NOT expose the refrigerator to rain, water,
or use in damp wet conditions.
• DO NOT expose the refrigerator to direct
sunlight.
• If left in direct sunlight the fridge may not
operate as designed.

5
WARNING
• When you dispose of your old refrigerators
and freezers, remove any doors. Children can
suffocate if they get trapped inside.
• This appliance contains insulation formed with
flammable blowing gases. Avoid safety hazards
by carefully disposing of this appliance.
• The appliance must be plugged into its own
dedicated 220-240V, 50Hz AC electrical outlet.
• Ensure that the electric outlet is properly
earthed to ground. Consult a qualified
electrician if you are unsure.
• Do not use an extension cord or adaptor plug.
• Unplug the appliance before cleaning.
• Never unplug the appliance by pulling on the
power cord. Always grip the plug firmly, and
pull straight out of the receptacle to prevent
damaging the
power cord.
• Chose a location that is not too cold - the
temperature should be above 10°C.
• Chose a location that is not affected by direct
sunlight.
Protection from Moisture
Avoiding placing the refrigerator in a place where
heavy moisture is present so as to minimise
possibility of rusting of metal parts. The refrigerator
should be kept out of water or direct sprayed water,
failure to do this could cause poor performance and/
or an electrical short could occur.
Protection from Heat
The refrigerator should be protected from excessive
heat sources and out of direct sunlight.
Moving
When fixed or moved, the refrigerator cannot be
set horizontally or reclined to more than 45° or
positioned upside down.
Never move while refrigerator is plugged in and
operating.
Once you have moved the refrigerator, leave
standing in a level position for 4 - 6 hours so that
the gas can settle.
• Put the appliance in a dry place, avoiding areas
of high moisture or humidity.
• Don’t put the appliance in direct sunlight.
• Don’t put the appliance near stoves, fires or
heaters.
• The appliance shall not be exposed to rain.
• Keep ventilation openings, in the appliance
enclosure or in the built-in structure, clear of
obstruction. Do not use mechanical devices
or other means to accelerate the defrosting
process.
Do not use electrical appliance inside the food
storage compartments of the appliance.
• If power cord is damaged, it must be replaced
by the manufacturer or its service agent or a
similarly qualified person in order to avoid a
hazard.
• The electrical system of this refrigerator must
be connected with an automatic 30mA circuit
breaker and/or residual current device (RCD).
If uncertain have a qualified electrician check
your electrical system before installation and/
or use.
Positioning
Ensure the sides and top have at least 50mm
clearance and the rear at least 100mm clearance to
ensure adequate ventilation.
Never cover the bottom front grill as this is required
for ventilation.
After installation the appliance should be left for
4 - 6 hours before it is switched on in order to allow
the refrigerant to settle.
Disposal of Old Appliances
The majority of components are recyclable, however
there are also dangerous chemicals inside. To
dispose of old fridges remove the doors and contact
your local council for recycling options.
Electrical Installation
The electrical system of this refrigerator must be
connected with an automatic 30mA circuit breaker
and/or residual current device (RCD). If uncertain
have a qualified electrician check your electrical
system before installation and/or use

6
CAUTION
• Never lick icy drinks when they first come
out of the fridge. This can freeze burn your
lips and mouth.
• If the supply cord is damaged, it must be
replaced by professional electrician. The cord
must be replaced with a cord of the same
specification.
• Before you throw away your old refrigerator,
take off the door, leave the shelves in place,
so that children may not easily climb inside.
• Never allow children to operate, play with or
crawl inside the appliance.
• This refrigerator is not designed for
perishable foods. It is a drinks refrigerator.
MAINTENANCE
• The refrigerator should be cleaned and maintained
once a month with a soft clean cloth.
• When performing maintenance, make absolutely
sure that the power plug is first disconnected
from the power outlet.
• Wipe the inner and outer surface of the
refrigerator and its accessories with soft clean wet
cloth. If they are too dirty, scrub them with neutral
detergent, and then clean them with water and
dry them with a clean cloth.
• Never use hot water, petrol, alcohol, kerosene,
abrasive powder, alkaline detergent, acid, oven
cleaners, etc. These could damage the lacquer
finish and plastics.
• If the plastic parts in refrigerator become
contaminated by oil (animal or vegetable), they
could become brittle and possibly cracked.
Electrical Data
IMPORTANT
This product is fitted with a sealed electrical
connection plug that is compatible with the
fridge, the mains supply for Australia and meets
the requirements of international standards. This
fridge must be connected to a supply voltage that is
equal to that stated on the rating label. If the mains
connection plug or power cord becomes damaged it
must be replaced with a complete assembly that is
identical to the original, and this must be replaced
by an authorised service centre. Always follow
the Australian requirements for connection to the
mains supply. If in doubt always consult a qualified
electrician.
Note: Before using your fridge, unpack and correctly
position. Once in position leave to stand for around
4-6 hours before turning on for the first time.

7
INTERNAL LIGHT
To turn light on use switch, located on bottom kick
panel I for on and Ofor off. It is recommended
that the switch be turned on only when required.
Using Your Refrigerator
TEMPERATURE CONTROL
• The first time you turn the unit on, set the
temperature control to position “Max”.
• The settings of the temperature control are “Min,
Mid, Max”. After 6 hours you can adjust the
temperature control setting to suit the types of
drinks being cooled.
• To turn the refrigerator off, turn the temperature
control to “Min”.
Note
• Turning the temperature control to “Min” position
stops the cooling cycle, but does not shut off the
power to the refrigerator.
• If the unit is unplugged, turned off or power is
lost you must wait 3 to 5 minutes before
restarting the unit. If you attempt to restart
without waiting the refrigerator will not start and
may damage the compressor.

8
Trouble Shooting
1. When the refrigerator does not work:
Check if there is a power failure.
Check if the power plug is plugged into the
power outlet.
Check that the R.C.D. has not been tripped.
If ambient temperature is above 40°C the Thermal
Safety Cut may have operated. Check if unit has
restarted once ambient temperature is below
30°C.
2.When the refrigerator is cooling excessively:
The temperature control dial may be set too
high. If you place drinks containing a lot of water
directly under the cool air outlets they may freeze.
This does not indicate a malfunction.
3.When the refrigerator is not cooling
sufficiently:
The drinks may be packed too tightly together
which will block the flow of cool air. You may
have put something hot or a lot of drinks into
the refrigerator. The door may not have closed
properly. There may be insufficient clearance
between the refrigerator and the other surfaces,
both sides, back and above. The temperature
control dial may not be set low enough. Daily
ambient temperature may be excessively high.
Check there is no direct sun on front of fridge.
4.When condensation forms on the outside of
the refrigerator:
Condensation may form on the outside when
the humidity is high. This is the same result as
the condensation formed when chilled water
is poured into a glass. It does not indicate a
malfunction. Wipe dry with a cloth.
5.When you hear a sound like water flowing:
A sound like water flowing is the refrigerant
flowing. It does not indicate a malfunction.
6.When the cabinets side panel heats up:
The side panel of the cabinet will heat up when
the door is opened and closed frequently, when
starting the unit and when the unit operates in
summer with high ambient outside temperature.
Do not touch the side panel, it is a result of heat
from inside the cabinet. It does not indicate a
malfunction.

9
Model JF118
Doors 1
Capacity 118L
Rated Voltage 220 ~ 240V AC
Rated Frequency 50Hz
Rated Current 1.7A
Rated Input Power at 240V AC 408W
Energy Consumption 0.87 kw.h/24h
Light 3W 12VDC
Lamp Type LED
Noise Level (db@3m) 51 db
Refrigerant R134a
Refrigerant Charge Volume 150gm
Foam Blowing Agent Cyclopentane
Net Weight 33.3kg
Technical Specifications
Specifications are subject to change without prior
notice. If the technical specifications are different
from the plate on the back of the refrigerator,
please refer to the plate.

10
P R O D U C T W A R R A N T Y
Thank you for purchasing one of our quality Jumbuck products. Your Jumbuck fridge
is covered against defects for a period of 12 months for parts and labour, repair or
replacement. This warranty excludes surface rust and damage caused by abuse or neglect.
This warranty in Australia is given by
Sitro Group Australia Pty Ltd, Tel: [phone]
Fax: [phone]. Email: [email protected]om.au
The warranty in New Zealand is given by Bunnings
NZ Ltd, PO Box 14436, Panmure, Auckland, 1741.
Tel: [phone] Fax: [phone].
Email [email protected].nz
Any claim under this warranty must be made within
12 months of the date of purchase of the product.
Proof of purchase must be presented.
Goods presented for repair may be replaced by
refurbished goods of the same type rather than
being repaired. Refurbished parts may be used to
repair the goods.
For Australian Customers
To make a claim under the warranty please contact
the store where the fridge was purchased or Sitro
Group directly.
This warranty is provided in addition to other rights
and remedies you may have under law: our goods
come with guarantees which cannot be excluded
under the Australian Consumer Law. You are
entitled to replacement or refund for a major failure
and to have the goods repaired or replaced if the
goods fail to be of acceptable quality and the failure
does not amount to a major failure.
For New Zealand Customers
To make a claim under the warranty please contact
the store where the fridge was purchased.
Goods presented for repair may be replaced by
refurbished goods of the same type rather than
being repaired. Refurbished parts may be used to
repair the goods.
NZ WARRANTY CONDITIONS
Any claim under this warranty must be made within
12 months of the date of purchase of the product.
To make a claim under the warranty, take the
product (with proof of purchase) to any Bunnings
store (see www.bunnings.co.nz for store locations)
Bunnings NZ Ltd bears reasonable, direct, expenses
of claiming under the warranty. You may submit
details and proof to our store for consideration.
The warranty covers manufacturer defects in
materials, workmanship and finish under normal
use.
This warranty is provided in addition to other rights
and remedies you may have under law: our goods
come with guarantees which cannot be excluded
under the Consumer Guarantees Act 1993 (NZ). You
are entitled to replacement or refund for a major
failure and to compensation for other reasonably
foreseeable loss or damage. You are also entitled to
have the goods repaired or replaced if the goods fail
to be of acceptable quality and the failure does not
amount to a major failure.
The warranty excludes damage resulting from
product misuse or product neglect. The warranty
covers domestic use only and does not apply to
commercial applications.
Please thoroughly read conditions of warranty

11
CONDITIONS OF WARRANTY
• The appliance must be operated and maintained
in accordance with the instructions supplied in
the operating manual.
• Any repair does not extend the warranty period.
• Any parts other than original Jumbuck parts will
void this warranty.
WHAT IS NOT COVERED IN THE WARRANTY
• Removal or re-installation costs. This warranty
does not cover costs for transit, nor in home
service.
• Liability will only be accepted for loss or damage
during transit if at the time the product was being
transported by Bunnings or a Bunnings approved
contractor.
• Lack of maintenance, abuse, neglect, misuse,
accidental or improper installation of this
appliance
• Scratches, dents, corrosion or discolouration
caused by heat, abrasive or chemical cleaners
• Corrosion or damage caused by exposure to the
elements
• Rusting
• Cleaning and wear and tear; service calls of this
nature are chargeable
• Commercial use of the product
• Unauthorized repairs or modifications during the
warranty period
• Glass breakage due to misuse
RECORD THE FOLLOWING INFORMATION
Attach a copy of the purchase receipt here:
Date of Purchase ______________________
Purchased from _______________________
Location _____________________________
Model Name and Number _______________
Serial number ________________________
Receipt number _______________________
Note: The serial number is located either on the
outside of the packing carton or outside or inside
the appliance
FOR TECHNICAL ASSISTANCE
For Australian Customers
If you experience any technical issues with your
Jumbuck product, in the first instance review the
instruction manual or call the warranty service
agent below.
For New Zealand Customers
If you experience any technical issues with your
Jumbuck product, in the first instance review the
instruction manual or call your local Bunnings
warehouse.
WARRANTY CLAIMS
For Australian Customers
Please contact Sitro Group Australia Pty Ltd,
Tel: [phone] Fax: [phone]
Email: [e-mail]
For New Zealand Customers
Please contact the store where the product was
purchased.

Jumbuck®is a registered trademark of Bunnings Pty Ltd.
For any queries or assistance call
Customer Service
Australia Only
1300 174 876
Hours of operation: Mon to Fri 8.30am - 5.30pm EST
Do not return to place of purchase.
Keep your purchase receipt, this will be required to
make any claims under the 12 month warranty.
