ENGLISH - 1 -
For your safety
This equipment has been designed and
manufactured to meet international safety stan-
dards but, like any electrical equipment, care
must be taken if you are to obtain the best
results and safety is to be assured. So, please
read the points below for your own safety. They
are of a general nature, intended to help you
with all your electronic consumer products and
some points may not apply to the goods you
have just purchased.
Some DOs and DONTs for you
Air Circulation
eave at least 10cm clearance around the tele-
vision to allow adequate ventilation. This will
prevent the TV from overheating and conse-
quential possible damage to the TV. Dusty
places should also be avoided.
Heat Damage
Damage may occur if you leave the TV in di-
rect sunlight or near a heater. Avoid places
subject to extremely high temperatures or hu-
midity, or locations where the temperature is
likely to fall below 5ºC (41ºF).
DO ensure that the TV is not standing on the
mains lead. DO NOT cut off the mains plug
from this equipment, this incorporates a spe-
cial Radio Interference Filter, the removal of
which will impair its performance.
Hot / Moderate Climate Conditions
This device is suitable for working in hot and
moderate climate conditions.
IF IN DOUBT PLEASE CONSULT A
COMPETENT ELECTRICIAN.
Contents
For your safety 1
Important Information 4
Remote Control Buttons 5
Control Panel Buttons and Terminals 6
How to remove the stand 8
Installing TV on the wall 9
Preparation 10
Before Switching on your TV 10
Switching the TV ON/OFF 11
Initial Settings 12
Operating the TV 13
Menu System 14
Other Features 20
PC Mode 23
Teletext 25
Peripheral Equipment Connections 26
Antenna Connections 28
Peripheral Equipment Connections 28
PC Input Typical Display Modes 29
Tips 30
Specifications 31

ENGLISH - 2 -
DO
DO read the operating instructions before you
attempt to use the equipment.
DO ensure that all electrical connections (in-
cluding the mains plug, extension leads and
inter-connections between pieces of equip-
ment) are properly made and in accordance
with the manufacturers instructions.
Switch off and withdraw the mains plug be-
fore making or changing connections.
DO consult your dealer if you are ever in doubt
about the installation, operation or safety of
your equipment.
DO be careful with glass panels or doors on
equipment.
DO NOT
DONT remove any fixed cover as this may
expose dangerous voltages.
DONT obstruct the ventilation openings of the
equipment with items such as newspapers,
table-cloths, curtains etc. Overheating will
cause damage and shorten the life of the
equipment.
DONT allow electrical equipment to be ex-
posed to dripping or splashing or objects filled
with liquids, such as vases, to be placed on
the equipment.
DONT place hot objects or naked flame
sources, such as lighted candles or night-
lights on, or close to the equipment. High tem-
peratures can melt plastic and lead to fires.
DONT use makeshift stands and NEVER fix
legs with wood screws. To ensure complete
safety, always fit the manufacturers approved
stand or legs with the fixings provided accord-
ing to the instructions.
DONT listen to headphones at high volume,
as such use can permanently damage your
hearing.
DONT leave equipment switched on when it
is unattended, unless it is specifically stated
that it is designed for unattended operation or
has a standby mode. Switch the equipment
off and make sure your family know how to do
this. Special arrangements may need to be
made for infirm or handicapped people.
DONT continue to operate the equipment if
you are in any doubt about it working normally,
or it is damaged in any way  switch off, with-
draw the mains plug and consult your dealer.
DONT put the empty batteries into garbage
instead of recycle bin to reduce harmfull ef-
fects to the environment.
ABOVE ALL  NEVER let anyone, especially
children, push anything into holes, slots or
any other openings in the case  this could
result in a fatal electric shock
NEVER guess or take chances with electrical
equipment of any kind  it is better to be safe
than sorry.
To fully disconnect the TV, switch off the
mains socket and remove the Power plug
** Cold cathode fluoresant lamp in LCD PANEL
contains a small amount of mercury, please
follow local ordinates or regulations for dis-
posal.
The LCD panel is very high technology prod-
uct with about a million thin film transistors,
giving you fine picture details Occasionally,
a few non-active pixels may appear on the
screen as a fixed point of blue, green or red
Please note that this does not affect the per-
formance of your product 
Please note that certain light guns used with
games consoles may not work on this prod-
uct
Warning:
This is a Class A product In a domestic envi-
ronment this product may cause radio inter-
ference in which case the user may be re-
quired to take adequate measures

ENGLISH - 3 -
WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO
NOT EXPOSE THIS APP IANCE TO RAIN OR MOISTURE.
WARNING
Do not allow children to hang from the TV, place their
elbows on the TV or lean against the TV. Doing so may
cause the TV to fall over and lead to injuries.
CAUTION:
 To avoid electric shock or damage to the unit, first firmly
connect the small end of the power cord to the rear of the
TV and then plug the larger end of power cord into an AC
outlet.
CAUTION:
 The TV screen may be damaged if the TV is carried as
shown in the diagram.
The TV should always be carried by two people.

ENGLISH - 4 -
Important Information
Please take note
EXCLUSION CLAUSE
JVC shall under no circumstances be liable for loss and/or damage to the product caused
by:
 fire;
 earthquake;
 accidental damage;
 intentional misuse of the product;
 use of the product in improper conditions;
 loss and/or damage caused to the product whilst in the possession of a third party;
 any damage or loss caused as a result of the owner s failure and/or neglect to follow the
instructions set out in the owners manual;
 any loss or damage caused directly as a result of misuse or malfunction of the product
when used simultaneously with associated equipment;
Furthermore, under no circumstances shall JVC be liable for any consequential loss and/
or damage including but not limited to the following, loss of profit, interruption of business,
the loss of recorded data whether caused during normal operation or misuse of the
product.
WARNING! NE ER LEA E A
STATIONARY IMAGE ON THE
SCREEN
If stationary images generated by TE ETEXT,
CHANNE IDENTIFICATION OGOS, COM-
PUTER DISP AYS, VIDEO GAMES, ON
SCREEN MENUS, etc. are left on the TV
screen for any length of time, they could be-
come permanently ingrained.
If you use your television to display completely
still images, or moving pictures which have a
permanent still image superimposed e.g.
broadcast network logos, it is always advis-
able to reduce BOTH the brightness and con-
trast settings.
Care and disposal
Cleaning the screen and cabinet
Turn off the power, clean the screen and cabi-
net with a soft, dry cloth. We recommend that
you do not use any proprietary polishes or
solvents on the screen or cabinet as this may
cause damage.
Disposal
When the set reaches the end of its useful
life please dispose of it in accordance with
ocal Government Regulations or at a recy-
cling centre.

ENGLISH - 5 -
Remote Control Buttons
3
=220
3,&785(
0(18
%$&.
7230(18
3&
79
9
&
5
'
9
'
7
9
$9























2.
/ I = (Stand By) button
TV / VCR / DVD Switch
Number buttons
AV button
(EXT-1, EXT-2, EXT-2S, EXT-3,
EXT-4, EXT-4S, PC)
BLUE / PICTURE Mode button
YELLOW / Sleep Timer button
MENU button
= Cursor Up button
OK button
= Cursor Right button
BACK button
= Volume + / - buttons
Teletext / VCR /DVD Control buttons
PC Control Buttons
P buttons
= Cursor Down button
= Teletext Button
= Cursor eft button
= Stereo / Bilingual button
GREEN / Hyper Sound On/Off button
RED / ZOOM Mode button
= Information Button / T-V ink in
Programme Menu
= Mute button

ENGLISH - 6 -
Control Panel Buttons and Terminals
With certain combinations of connectors and leads the back cover
may not be easily fitted. If the cover is left off, this in no way infringes
safety requirements.
32:(5
/$03
,1)5$5('
5(&(,9(5
63($.(5 63($.(5
67$1'%<
352*5$00(
83'2:1
92/80(
83'2:1
0(18
79$92.
+($'3+21(

ENGLISH - 7 -
3&$8',2,1
$17(11$
(;7
$
%
&
'
(
(;7
)
*
+
,
3&,1387
(;7
(;7
$8',2287
7(50,1$/
<
3E
3U
&RPSRQ QW$XGLR,Q5
&RPSRQ QW$XGLR,Q/
69LG R,Q
9LG R,Q
$XGLR5
$XGLR/
$XGLR5
$XGLR/
6XEZRRI U2XW
32:(5&25',1387
-
212))6:,7&+
99
$&a+]
32:(5

ENGLISH - 8 -
How to remove the stand
 oosen the 5 screws that attach the stand to the TV.
 Gently pull the stand downwards to remove it.

ENGLISH - 9 -
Installing TV on the wall
WARNING
 When you install the TV on the wall, only use a JVC wall mounting unit (optional) which is
designed for this TV
 Make sure that the TV is installed on the wall by a skilled installer
ocate the TV away from direct sunlight and strong lights, soft, indirect lighting is recommended
for comfortable viewing. Place on a sturdy platform, the mounting surface should be flat and
steady, it should then be secured to the wall with a sturdy tie using the hook on the back of the
TV, this will prevent it from falling over. Use curtains or blinds to prevent direct sunlight falling on
the screen.
A floor and table top stand are available for this television, or and angled bracket which enables
the TV to be wall-mounted.
The CD display panels are manufactured using an extremely high level of precision technol-
ogy, however sometimes some parts of the screen may be missing picture elements or have
luminous spots. This is not a sign of a malfunction.
Make sure the TV is located in a position where it cannot be pushed or hit by objects, as
pressure will break or damage the screen.
