SERVICE MANUAL
COPYRIGHT © 2003 VICTOR COMPANY OF JAPAN, LIMITED No.22070
2003/7
HOME CINEMA CONTROL CENTER
2207020037RX-ES1SL
TABLE OF CONTENTS
1 PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
2 SPECIFIC SERVICE INSTRUCTIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5
3 DISASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6
4 ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-12
5 TROUBLE SHOOTING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-13
Area suffix
B ------------------------------- U.K.
E ----------- Continental Europe
EN ------------ Northern Europe

1-2 (No.22070)
SPECIFICATION
Designs & specifications are subject to change without notice
Amplifier Output Power At Stereo operation Front ch 100 W per channel, min. RMS, both channels
driven into 8
Ω at 1kHz with no more than 10%
total harmonic distortion. (IEC268-3)
At Surround
operation Front ch 100 W per channel, min. RMS, driven into 8
Ω at
1 kHz with no more than 0.8% total harmonic dis-
tortion.
Center ch 100 W, min. RMS, driven into 8
Ω at 1 kHz, with
no more than 0.8% total harmonic distortion.
Surround ch 100 W per channel, min. RMS, driven into 8
Ω at
1 kHz, with no more than 0.8% total harmonic
distortion.
Audio AudioInputSensitivity/
Impedance (1 kHz) DVD IN, DVD MULTI IN, STB IN, VCR IN, TV IN 260 mV/47 k
Ω
Audio Input
(DIGITAL IN)* Coaxial DIGITAL 1 (DVD) 0.5 V(p-p)/75
Ω
Optical DIGITAL 2/3 (STB/TV) -21 dBm to -15 dBm (660 nm ±30 nm)
* Corresponding to Linear PCM, Dolby Digital, and DTS Digital Surround (with sampling frequency -32 kHz, 44.1 kHz, 48 kHz).
Audio Output Level VCR OUT, TV OUT 250 mV
Signal-to-Noise Ratio (‘66 IHF/DIN)
DVD MULTI IN 87 dB/62 dB
Frequency Response (8
Ω )
DVD IN, STB IN, VCR IN, TV IN
Tone Control
Bass (100 Hz) ±10 dB ±2 dB
Treble (10kHz) ±10 dB ±2 dB
Bass boost +4 dB ±1 dB at 100 Hz
Video VideoInputSensitivity/
Impedance (1 kHz) Composite video DVD IN, STB IN, VCR IN 1 V(p-p)/75
Ω
S-video DVD IN, STB IN, VCR IN (Y: luminance) 1 V(p-p)/75 Ω
(C: chrominance) 0.286 V(p-p)/75 Ω
RGB DVD IN, STB IN, VCR IN 0.7 V(p-p)/75 Ω
Video Output Level/
Impedance (1 kHz) Composite video VCR OUT, TV OUT 1 V(p-p)/75
Ω
S-video VCR OUT, TV OUT (Y: luminance) 1 V(p-p)/75 Ω
(C: chrominance, burst) 0.286 V(p-p)/75 Ω
RGB TV OUT 0.7 V(p-p)/75 Ω
Signal-to-Noise Ratio (S/N) 45 dB
Synchronize Negative
FM tuner (IHF) Tuning Range 87.5 MHz to 108.0 MHz
Usable Sensitivity Monaural 17.0 dBf (1.95
µ V/75 Ω )
50 dB Quieting Sensi-
tivity Monaural 21.3 dBf (3.2
µ V/75 Ω )
Stereo 41.3 dBf (31.5
µ V/75 Ω )
Stereo Separation at REC OUT 35 dB at 1 kHz
AM (MW) tuner Tuning Range MW 522 kHz to 1629 kHz
General Power Requirements AC 230~, 50 Hz
Power Consumption 105 W (at operation) 2 W (in standby mode)
Dimensions (W
× H × D) 435 mm × 69.5 mm × 330.5 mm
Mass 6.6 kg

(No.22070)1-3
SECTION 1
PRECAUTIONS
1.1 Safety Precautions
(1) This design of this product contains special hardware and
many circuits and components specially for safety purpos-
es. For continued protection, no changes should be made
to the original design unless authorized in writing by the
manufacturer. Replacement parts must be identical to
those used in the original circuits. Services should be per-
formed by qualified personnel only.
(2) Alterations of the design or circuitry of the product should
not be made. Any design alterations of the product should
not be made. Any design alterations or additions will void
the manufacturers warranty and will further relieve the
manufacture of responsibility for personal injury or property
damage resulting therefrom.
(3) Many electrical and mechanical parts in the products have
special safety-related characteristics. These characteris-
tics are often not evident from visual inspection nor can the
protection afforded by them necessarily be obtained by us-
ing replacement components rated for higher voltage, watt-
age, etc. Replacement parts which have these special
safety characteristics are identified in the Parts List of Ser-
vice Manual. Electrical components having such features
are identified by shading on the schematics and by ( ) on
the Parts List in the Service Manual. The use of a substitute
replacement which does not have the same safety charac-
teristics as the recommended replacement parts shown in
the Parts List of Service Manual may create shock, fire, or
other hazards.
(4) The leads in the products are routed and dressed with ties,
clamps, tubings, barriers and the like to be separated from
live parts, high temperature parts, moving parts and/or
sharp edges for the prevention of electric shock and fire
hazard. When service is required, the original lead routing
and dress should be observed, and it should be confirmed
that they have been returned to normal, after reassem-
bling.
(5) Leakage shock hazard testing
After reassembling the product, always perform an isola-
tion check on the exposed metal parts of the product (an-
tenna terminals, knobs, metal cabinet, screw heads,
headphone jack, control shafts, etc.) to be sure the product
is safe to operate without danger of electrical shock.Do not
use a line isolation transformer during this check.
• Plug the AC line cord directly into the AC outlet. Using a
"Leakage Current Tester", measure the leakage current
from each exposed metal parts of the cabinet, particular-
ly any exposed metal part having a return path to the
chassis, to a known good earth ground. Any leakage cur-
rent must not exceed 0.5mA AC (r.m.s.).
• Alternate check method
Plug the AC line cord directly into the AC outlet. Use an
AC voltmeter having, 1,000Ωper volt or more sensitivity
in the following manner. Connect a 1,500Ω10W resistor
paralleled by a 0.15µF AC-type capacitor between an ex-
posed metal part and a known good earth ground.
Measure the AC voltage across the resistor with the AC
voltmeter.
Move the resistor connection to each exposed metal
part, particularly any exposed metal part having a return
path to the chassis, and measure the AC voltage across
the resistor. Now, reverse the plug in the AC outlet and
repeat each measurement. Voltage measured any must
not exceed 0.75 V AC (r.m.s.). This corresponds to 0.5µ
mA AC (r.m.s.).
1.2 Warning
(1) This equipment has been designed and manufactured to
meet international safety standards.
(2) It is the legal responsibility of the repairer to ensure that
these safety standards are maintained.
(3) Repairs must be made in accordance with the relevant
safety standards.
(4) It is essential that safety critical components are replaced
by approved parts.
(5) If mains voltage selector is provided, check setting for local
voltage.
1.3 Caution
Burrs formed during molding may be left over on some parts
of the chassis.
Therefore, pay attention to such burrs in the case of pre-
forming repair of this system.
1.4 Critical parts for safety
In regard with component parts appearing on the silk-screen
printed side (parts side) of the PWB diagrams, the parts that are
printed over with black such as the resistor ( ), diode ( )
and ICP ( ) or identified by the " " mark nearby are critical
for safety. When replacing them, be sure to use the parts of the
same type and rating as specified by the manufacturer.
(This regulation dose not Except the J and C version)
Good earth ground
Place this
probe on
each exposed
metal part.
AC VOLTMETER
(Having 1000
ohms/volts,
or more sensitivity)
1500 10W
0.15 F AC TYPE

1-4 (No.22070)
1.5 Safety Precautions (U.K only)
(1) This design of this product contains special hardware and many circuits and components specially for safety purposes. For con-
tinued protection, no changes should be made to the original design unless authorized in writing by the manufacturer. Replace-
ment parts must be identical to those used in the original circuits.
(2) Any unauthorised design alterations or additions will void the manufacturer's guarantee; furthermore the manufacturer cannot
accept responsibility for personal injury or property damage resulting therefrom.
(3) Essential safety critical components are identified by ( ) on the Parts List and by shading on the schematics, and must never
be replaced by parts other than those listed in the manual. Please note however that many electrical and mechanical parts in
the product have special safety related characteristics. These characteristics are often not evident from visual inspection. Parts
other than specified by the manufacturer may not have the same safety characteristics as the recommended replacement parts
shown in the Parts List of the Service Manual and may create shock, fire, or other hazards.
(4) The leads in the products are routed and dressed with ties, clamps, tubings, barriers and the like to be separated from live parts,
high temperature parts, moving parts and/or sharp edges for the prevention of electric shock and fire hazard. When service is
required, the original lead routing and dress should be observed, and it should be confirmed that they have been returned to
normal, after re-assembling.
1.5.1 Warning
(1) Service should be performed by qualified personnel only.
(2) This equipment has been designed and manufactured to meet international safety standards.
(3) It is the legal responsibility of the repairer to ensure that these safety standards are maintained.
(4) Repairs must be made in accordance with the relevant safety standards.
(5) It is essential that safety critical components are replaced by approved parts.
(6) If mains voltage selector is provided, check setting for local voltage.
Burrs formed during molding may be left over on some parts of the chassis. Therefore,
pay attention to such burrs in the case of preforming repair of this system.

(No.22070)1-5
SECTION 2
SPECIFIC SERVICE INSTRUCTIONS
This service manual does not describe SPECIFIC SERVICE INSTRUCTIONS.

1-6 (No.22070)
SECTION 3
DISASSEMBLY
3.1 Main body section
3.1.1 Removing the top cover
(See Figs.1 and 2)
(1) From the back side of the main body, remove the three
screws Aattaching the top cover.(See Fig.1)
(2) From the both sides of the main body, remove the four
screws Battaching the top cover.
(3) Remove the top cover by moving up the back part of the top
cover and release the six joints ausing a longer driver from
the inside. (See Fig.2.)
Note:
•Do not damage any part and board inside the main body when
releasing the joints a using a longer driver.
3.1.2 Removing the front panel assembly
(See Figs.2 to 4.)
• Prior to perform the following procedures, remove the top cov-
er.
(1) From the top side of the main body, cut the tie bands and
disconnect the wire from the connector CN451 on the main
board. (See Fig.2.)
(2) From the bottom side of the main body, remove the four
screws Cattaching the front panel assembly. (See Fig.3.)
(3) From the both sides of the main body, release the joints b
and remove the front panel assembly in the direction of the
arrow. (See Fig.4.)
(4) From the top side of the main body, remove the screw Dat-
taching the earth wire on the DC power board. (See Fig.2.)
References:
• After attaching the front panel assembly, bundling the wires
using the new tie bands.
• When attaching the screw D, attach the earth wire with it.
Fig.3
Fig.1
Fig.2
Fig.4
C
Front panel assembly
A
Bx2 Bx2
Top cover
CN451
Main board
Front panel assembly
Joints a
Tie bands
Earth wire
D
DC power
board
Front panel assembly
Joint b

(No.22070)1-7
3.1.3 Removing the tuner
(See Figs.5 and 6.)
• Prior to perform the following procedures, remove the top cov-
er.
(1) From the top side of the main body, disconnect the card
wire from the connector CN1 on the tuner. (See Fig.5.)
(2) From the back side of the main body, remove the two
screws Eattaching the tuner to the rear panel. (See Fig.6.)
Fig.5
Fig.6
3.1.4 Removing the rear panel
(See Fig.7)
• Prior to perform the following procedures, remove the top cov-
er.
(1) From the back side of the main body, remove strain relief
from the rear panel in the direction of the arrow.
(2) Remove the twenty screws Fattaching the rear panel.
Fig.7
3.1.5 Removing the digital input board
(See Fig.8)
• Prior to perform the following procedures, remove the top cov-
er, tuner and rear panel.
Reference:
• Remove the tuner as required.
(1) From the top side of the main body, remove the connector
CN521 on the digital input board in an upward direction.
(2) From the reverse side of the digital input board, disconnect
the card wire from the connector CN522 on the digital input
board.
Fig.8
Card wire
Tuner CN1
ERear panel
F
F
Rear panel
Strain relief
Digital input board
CN522
CN521

1-8 (No.22070)
3.1.6 Removing the digital output board
(See Fig.9)
• Prior to perform the following procedures, remove the top cov-
er, tuner, rear panel and digital input board.
Reference:
• Remove the tuner as required.
(1) Disconnect the card wires from the connectors CN513 and
CN514 on the digital output board.
(2) Remove the screw Gattaching the digital output board.
Fig.9
3.1.7 Removing the AC power supply board
(See Fig.10)
• Prior to perform the following procedures, remove the top cov-
er and tuner.
(1) From the top side of the main body, disconnect the power
cord from the connector CN203 on the AC power supply
board and remove it from the rear panel.
(2) Cut the tie bands and disconnect the wire from the connec-
tor CN218 on the DC power board.
(3) Remove the three screws Hattaching the AC power supply
board.
(4) Disconnect the wire from the connector CN202 on the AC
power supply board and remove the wire holders from the
reverse side of the AC power supply board.
Reference:
• When attaching the three screws H, attach the wire holder
with it.
Fig.10
Card wires
Digital output board CN513
CN514
G
CN202
CN203
DC power board
Power cord
CN218
AC power supply board
Wire holder
Rear panel
Tie bands
H
H
Wire
holder
Wire
holder

(No.22070)1-9
3.1.8 2.1.8 Removing the power transformer
(See Fig.11)
• Prior to perform the following procedures, remove the top cov-
er and front panel assembly.
(1) From the top side of main body, disconnect the wire from
the connector CN202 on the AC power supply board.
(2) Remove the strain relief holding the power cord and re-
move the three screws H attaching the AC power supply
board.
(3) Lift the AC power supply board and remove the wire hold-
ers from the reverse side of the AC power board.
(4) Cut the tie band.
(5) Disconnect the wire from the connector CN201 on the DC
power board.
(6) Disconnect the wire from the connector CN702 on the rec-
tifier board.
(7) Remove the four screws Jattaching the power transform-
er.
Reference:
• After attaching the front panel assembly, bundling the wires
using the new tie bands.
Fig.11
3.1.9 Removing the fan
(See Figs.12 and 13)
• Prior to perform the following procedures, remove the top cov-
er.
(1) From the top side of the main body, cut the tie bands and
disconnect the wire from the connector CN207 on the DC
power board. (See Fig.12.)
(2) Remove the screw Kand screw K’ attaching the fan as-
sembly, then remove the fan assembly. (See Fig.12.)
(3) Remove the two screws Lattaching the fan to the fan
bracket. (See Fig.13.)
Reference:
• After attaching the screw K’, attach the wire holder with it.
Fig.12
Fig.13
CN202
DC power board
Power cord
Wire holder
Rectifier board
AC Power supply board
Strain relief
CN201 CN702
Power transformer
Tie band
H
JJ
Fan assembly
DC power board CN207
Tie bands
K
K'
Wire holder
L
Fan bracket Fan

1-10 (No.22070)
3.1.10 Removing the DC power board
(See Fig.14)
• Prior to perform the following procedures, remove the top cov-
er, front panel assembly, rear panel and digital input board.
(1) From the top side of the main body, disconnect the wires
from the connectors (CN201, CN206, CN207, CN211,
CN218, CN510, CN520, CN711) on the DC power board.
(2) Disconnect the parallel wire from the connector CN712 on
the amp. board.
(3) Remove the two screws Mattaching the DC power board.
Fig.14
3.1.11 Removing the main board
(See Fig.15)
• Prior to perform the following procedures, remove the top cov-
er, front panel assembly, rear panel, digital input board, digital
output board, AC power supply board and DC power board.
(1) From the top side of the main body, disconnect the wires
from the connector CN525 on the main board.
(2) Disconnect the wires from the connectors CN516 and
CN519 on the amp board.
(3) Remove the two screws Nattaching the main board.
Reference:
• When attaching the two screws N, attach the wire holder
with it.
3.1.12 Removing the amp. board
(See Fig.15)
• Prior to perform the following procedures, remove the top cov-
er, front panel assembly, rear panel, digital input board, digital
output board, AC power supply board and DC power board.
(1) From the top side of the main body, disconnect the wires
from the connectors CN516 and CN519 on the amp. board.
(2) Disconnect the wire from the connector CN525 on the main
board.
(3) Disconnect the wire from the connector CN703 on the rec-
tifier board.
(4) Remove the four screws Pattaching the amp. board. Fig.15
CN520
CN510
CN210 CN711
CN712
CN211
CN207
CN206
Amp. board
CN218
M
M
DC power board
P
P
N
P
Main board
CN516
CN519
CN703
CN525
Wire holder
Amp. board
Rectifier board
P

(No.22070)1-11
3.1.13 Removing the rectifier board
(See Fig.16)
• Prior to perform the following procedures, remove the top cov-
er and front panel assembly.
(1) From the top side of the main body, disconnect the wires
from the connectors CN702 and CN703 on the rectifier
board.
(2) Disconnect the parallel wire from the connector CN711 on
the DC power board.
(3) Remove the two screws Qattaching the rectifier board.
3.1.14 Removing the headphone jack board
(See Fig.16)
• Prior to perform the following procedures, remove the top cov-
er and the front panel.
(1) From the top side of the main body, cut the tie bands.
(2) Disconnect the wire from the connector CN206 on the DC
power board.
(3) Remove the screw Rattaching the headphone jack board.
Reference:
• After attaching the front panel assembly, bundling the wires
using the new tie bands.
Fig.16
3.1.15 Removing the FL board
(See Fig.17)
• Prior to perform the following procedures, remove the top cov-
er and front panel assembly.
(1) From the inside of the front panel assembly, remove the six
screws Sattaching the FL board.
(2) Disconnect the wire from the connector CN403 on the FL
board.
(3) Disconnect the connector CN401 on the FL board in an up-
ward direction.
3.1.16 2.1.16 Removing the volume board
(See Fig.17)
• Prior to perform the following procedures, remove the top cov-
er and front panel assembly.
(1) From the inside of the front panel assembly, remove three
screws Tattaching the volume board.
(2) Disconnect the wire from the connector CN403 on the FL
board.
Fig.17
3.1.17 Removing the SW board
(See Fig.18)
• Prior to perform the following procedure, remove the top cover,
front panel assembly and FL board.
(1) From the inside of the front panel assembly, remove the
seven screws Uattaching the SW board.
Fig.18
CN206
DC power board
Headphone jack board Recfifier board
CN703
CN702
CN711
Tie band
R
Q Q
TS
Front panel assembly
FL board
Volume board
CN403
CN401
U
Front panel assembly
SW board

1-12 (No.22070)
SECTION 4
ADJUSTMENT
This service manual does not describe ADJUSTMENT.

(No.22070)1-13
SECTION 5
TROUBLE SHOOTING
This service manual does not describe TROUBLE SHOOTING.

(No.22070)
AV & MULTIMEDIA COMPANY AUDIO/VIDEO SYSTEMS CATEGORY 10-1,1chome,Ohwatari-machi,Maebashi-city,371-8543,Japan
VICTOR COMPANY OF JAPAN, LIMITED
WPC
Printed in Japan
