Quick Start Guide
65" LED Smart 4K HDR TV
LT-65C880(C)
Thank you for purchasing your new JVC TV.
Your new TV incorporates the latest technology to enhance your viewing
experience. We would suggest that you allow about 15 mins for initial setup.
Please follow this guide for a successful rst time installation.
The latest eco-friendly power-saving technology will switch o the TV if
it is left on and idle for 4 hours. Please refer to“Auto Standby” under the
“Time Settings”section of the instruction manual for more detail.
Remove all packaging from the unit. Retain the packaging. If you dispose of it please do so according to any local regulations.
TV
Right Foot
Left Foot
Remote Control/
AAA Batteries x2
Feet Screws x 6
Instruction Manual
Quick Start Guide Please inspect your TV for damage after unpacking. If
you do notice any damage please consult your dealer.
1. Slide open the battery compartment on the back of the remote control.
2. Insert two AAA size batteries. Make sure to match the (+) and ( - ) ends of the
batteries with the (+) and ( - ) ends indicated in the battery compartment.
3. Slide the battery compartment cover back into place. Make sure it clicks into place.
Fitting the Feet to the TV
1. Ensure the TV is switched o and not connected to the mains power supply.
2. Keep the protective bag on the TV to protect it.
3. Make sure you have some help, this requires 2 people. Lay the TV down on a at surface ideally on the edge of a table so the base of the TV slightly
overhangs the edge of the table, with the back side facing up. Please make sure a soft cushioned material (such as a dry bath towel or thick piece of foam) is
placed beneath the screen. Be very careful not to knock the edges of the TV, the screen is very fragile.
4. The feet are marked up as Left and Right. They can only be attached with the right foot on the right side of the TV as you look from the back and the left on the
left side. Attach each foot with 3 of the supplied screws.
Right FootLeft Foot
Table
Cushioned
material
Protective
Bag
The LCD display is very fragile, and must be protected at all times when installing and removing the base stand. Be sure that no hard or sharp object, or
anything that could scratch or damage the LCD display, comes into contact with it. DO NOT exert pressure on the front of the TV at any time because the
screen could crack.
• Do not connect the TV to the mains supply until you have completed all the connections.
• Always disconnect the TV from the mains socket when not in use for a long period of time.
• The button on the remote control is only used for switching the TV into standby, it does not disconnect the TV from the mains power.
To completely disconnect the mains power, please remove the mains plug from the mains socket.
1. Connect one end of the RF coaxial cable to the aerial socket on the wall and the other end of the cable to the ANT socket on the back of your TV.
2. Plug the TV into a mains socket and switch on at the mains.
3. In standby mode, press the button on the remote control to turn the TV on. The LED indicator will ash for a few seconds then the TV will switch on.
RF coaxial cable
(not included)
Router
(not included)
LANVGA ANT.HDMI 1Optic.OUT
Optional
If you want to connect to the internet via a wired connection
then connect your ethernet cable to the LAN socket.
Setup in
15mins
3
2
What’s in the Box?
Operating Your Remote Control
Installing the Base Stand
1
4Connecting the Aerial and Turning on the TV
JVC 65' LED Smart 4K HDR TV LT-65C880(C) Quick Start.indd 1-3 07/11/2018 10:57

6 75
The rst time you turn the TV on, it will go straight into the First Time Installation menu. Most of the
settings are pre-set so you can just press OK. Please ensure the aerial is plugged in.
1. Press the buttons to highlight your LANGUAGE then press OK.
Getting Started
2. Press the buttons to highlight your COUNTRY then press OK.
Before you are able to connect to the internet and use the smart features of your TV, you MUST make sure that some Privacy Settings are activated. This is part of
the Initial Setup process or if you skip it, you can select them later by either pressing the SMART button where you'll be directed to the Privacy Settings menu or
you can select the Privacy settings directly from Settings menu.
To use Smart functions the minimum settings that you will need to activate are Portal and Applications and Internet connection . For Red Button services you
must activate HbbTV.
By activating these settings you are allowing the TV Manufacturer to store data to help improve the performance and user experience of your TV.
Each setting has a description, if you press the P / button when the setting is highlighted you will be able to scroll up and down the text to read the
description. To access all the features of your Smart TV you must be connected to the internet. If you do not wish to set up your network connection you can skip
this section by pressing , however we recommend you set up your network connection now.
To enjoy Freeview Play and Smart functionality your TV must have enabled ‘Portal and Applications’
and ‘Internet Connection’ in the Privacy Setting and then connect to the internet.
Press OK to Accept Terms of Use
Reminder of setting not selected
To Accept ALL (recommended)
1. To accept all the setting press the OK button.
2. The 'Terms of Use' screen will appear. Press OK to
accept the terms.
3. All of the boxed will now be ticked and NEXT will
be highlighted, press OK.
Select Individual Settings
If you don’t want to accept all the setting you can
choose to activate settings individually.
1. First make sure Accept All is deactivated.
2. Press the button to highlight your desired
setting then press OK to activate it.
3. Press the button to highlight NEXT then press
OK, a list will appear highlighting the settings that
you haven't accepted. Select YES to continue.
Choosing to Activate No Settings
1. If you don't wish to accept any of the settings press the button to highlight NEXT then press OK.
You will be informed that you haven't enabled HbbTV and Portal and Applications. Select YES and
press OK.
2. You're TV will now skip section 6 'Connecting to the Internet' and start to tuning.
You will NOT have any smart functionality once your TV has tuned in.
Connecting to the Internet - Wired, Wireless or using the WPS button
WIRED Connection
•If you have connected your ethernet cable to the LAN socket on the back of your TV, press the
button to highlight NEXT then press OK.
WIRELESS Connection
You can connect using a wireless connection via your router.
Make sure your TV
is as close to your
router as possible,
within 5m and ideally
in the same room as
the TV
1. Press the buttons to select WIRELESS DEVICE then press the button to highlight NEXT then
press OK.
WPS Connection
Rather than having to enter your Wireless password, you can select the WPS option. This will allow you to connect to your router without a password once the WPS
button is pressed on your router.
Tuning in Your TV
Choose Region (UK only)
During tuning, your TV may have received signals from more than one transmitter. If this has occurred the Choose Region screen will be displayed. This will enable
you to select the correct regional transmission for the local news service that you require.
1. Press the button to highlight Primary region, then press the buttons to select your Primary
Region e.g. England.
2. Press the button to highlight Secondary region, then press the buttons to select your
Secondary Region e.g. London.
3. Press the button to highlight Tertiary region, then press the buttons to select your Tertiary
Region e.g. Greater London.
4. Press the button to highlight Save then press OK.
1. To make sure you activate Freeview Play select YES and press OK.
5. The Channel list will appear, press the EXIT button to remove this. Your TV is now fully tuned in and
ready to use.
3. Your TV will now start automatic channel scan. It will tune in all available TV channels.
1. Select WIRELESS DEVICE.
2. Press the button to highlight 'Press WPS on your wifi router' then press OK. Now press the WPS
button on your router and your TV will connect to your router, without the use of a password.
2. Press the buttons to select your wireless
network then press OK.
3. You now need to enter your password, a keyboard
will appear. Press the buttons to select a
letter/number/symbol and press OK to enter each
one. Once you have typed your password highlight
OK and press OK.
Need More Help?
If you need more help setting up your TV then please call:
UK: 0344 561 1234
Ireland: 1890 818 575
Lines are open 24/7
Best connection
speed
Maximum distance
5m
Wireless Router Wireless Router
3. Select Home Mode by pressing the OK button.
4. Press the buttons to highlight your desired
picture mode. Its set to Natural as this is the most
energy efficient mode. Then press OK.
Press OK to Accept All 4. The network will now show Connected and NEXT will be highlighted press the OK button to continue.
If you View TV Through a Set Top Box
If you have attached a Set top box such as Sky/Virgin or BT via a HDMI cable then un-tick Digital
Aerial and select NEXT. This will mean your TV will not try to tune any channels in. To view your set
top box press the HOME button, scroll to SOURCE and select the HDMI socket you have attached
your set top box to.
2. To tune in your TV using the aerial connection press OK.
(QSG-LT-65C880(C)181107V2)
