Before Use
With new technology readily available, JVCKENWOOD has developed an easy
to use dashboard camera for everyday use. The device allows its user to record files in1 / 3 / 5minute
lengths. These files are easy to download to your desktop or laptop.
In most instances, the video files are easily played on your mobile device.
While most cameras traditionally use the entire capacity of the SD card until it is
removed, the device automatically deletes the oldest file to create space for the new video.
Dashboard camera offers three modes:
1. Video Mode: Video mode will set to default when the device is active.
2. Photo Mode: The device setting takes still photographs.
3. Playback Mode: Users can view all previously recorded videos and photos taken.
FEATURES:
Automatic Start/Stop Technology:
Maintain full focus on the road! The vehicles ignition will let the device turn on while
connected to your vehicles 12 V outlet or cigarette lighter socket. When the vehicle is
turned off, the device will automatically shut down, preserving the device power for those
moments you are not connected to permanent power.
The device lets users adjust camera settings to get the perfect shot. For a great photo
every time, here are a few tips from the designers:
Reduce the amount of sky in the picture. By adjusting the device towards the road,
the automatic exposure compensation will be focused on the road and not the light from
the sky.
Position the device in the center of the dash. If you place the device behind the rearview
mirror, you will avoid all distractions from the road.
Remove any objects that will obstruct your shot such as the protective lens cover.
Clear vision will allow you to record everything in one shot.
1.
2.
3.
The screen images and operation examples in this document were created for explaining the
operating procedures.
There may be screen images that differ from the actual screens or examples of operations not
actually performed.
Please note that JVCKENWOOD shall not be responsible for any damages suffered by the
customer or a third party as a result of incorrectly using this product, a failure during use of
this product, or other trouble, or due to the use of this product, unless such liability is
acknowledged by law.
Recorded video, image, and audio content cannot be used for other than personal enjoyment
without the consent of the copyright holder as specified in the Copyright Act.
Please note that the recording of an event such as a show, performance, or exhibition may be
restricted even when doing so for personal enjoyment.
•
•
•
•
•
Dashboard Camera Function Guide
01
Disclaimer
Copyrights

02
For your own safety, do not operate the controls of the product while driving.
A window mount is needed when using the device in a car. Make sure that you place the device in
an appropriate place, so as not to obstruct the driver's view or deployment of airbags.
Make sure that no object is blocking the camera lens and no reflective material is placed near the
lens. Please keep the lens clean.
If the car's windscreen is tinted with a coating, this may impact the recording quality.
Connect the charger to a proper power source. The voltage requirements are found on the product
case and/or packaging.
Do not use the charger if the cord becomes damaged.
Do not attempt to service the unit. There are no serviceable parts inside. Replace the unit if it is
damaged or exposed to excess moisture.
Keep your device away from excessive moisture and extreme temperatures.
Avoid exposing your device to direct sunlight or strong ultraviolet light for extended periods of
time.
Do not place anything on top of your device or drop objects on your device.
Do not drop your device or subject it to severe shock.
Do not subject your device to sudden and severe temperature changes. This could cause moisture
condensation inside the unit, which could damage your device. In the event of moisture
condensation, allow the device to dry out completely before use.
The screen surface can easily be scratched. Avoid touching it with sharp objects. Nonadhesive
generic screen protectors designed specifically for use on portable devices with LCD panels may be
used to help protect the screen from minor scratches.
Never clean your device with the power on. Use a soft, lint-free cloth to wipe the screen and the
exterior of your device.
Do not use paper towels to clean the screen.
Never attempt to disassemble, repair or make any modifications to your device. Disassembly,
modification or any attempt at repair could cause damage to your device and even bodily injury or
property damage and will void any warranty.
Do not store or carry flammable liquids, gases or explosive materials in the same compartment as
your device, its parts or accessories.
To discourage theft, do not leave the device and accessories in plain view in an unattended vehicle.
Overheating may damage the device.
Precautions for Use
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Precautions and notices
Warning! Do not operate the device while driving. Using this product does not change the
requirement for a driver to take full responsibility for his or her behavior. This responsibility includes
observing all traffic rules and regulations in order to avoid accidents, personal injury or property
damage.
Caring for your device
Taking good care of your device will ensure trouble-free operation and reduce the risk of damage.

03
Install the device in a position where it will not block the front view of the driver (position where
hidden by the rear-view mirror).
Install the device so that it is within the wiping range of the wiper.
Install the device in a position where it will not interfere with the movement of the rear-view
mirror.
Take care not to install the device over the vehicle inspection sticker or other sticker.
Take care not to install the device where it will interfere with driving or airbag operation.
When installing the device in a vehicle equipped with a driving support system, check the
instruction manual of the vehicle and then select an installation position that will not interfere
with the driving support system.
If the device is installed incorrectly, event recording or parked recording may not work correctly.
Refer to “Installation and Connection” for the loosening of fixing knob, installation orientation,
installation angle, and other information and then install the device correctly.
Do not install the device near a digital terrestrial television antenna or an electrical component.
Doing so may reduce television receiver sensitivity or cause flickering and noise.
When selecting a position for the suction mount, make sure it’s on a glass surface that is smooth
and free of paint.
Before mounting, clean the area with a dry/clean cloth and add a small amount of moisture to the
windshield. This allows a stronger bond to form between the glass and the suction mount.
When fixing the device with the adhesive mount, use a commercially available cleaning cloth or
the like to wipe off all dirt and grease on the mounting surface. If the device is re-affixed or
mounted using, for example, general-purpose double-sided tape, the adhesion strength may
weaken and cause the device to fall.
After mounting the device, leave it for 24 hours before use to enable the mounting strength of
the adhesive mount to improve. Failing to do so may result in the adhesion of the adhesive mount
becoming weak and the device falling.
Fix the cord in place with tape or the like so that it does not interfere with driving.
Do not block the camera lens, get dirt on it, or place a reflective object near it.
When LED traffic lights are recorded, video in which they appear to be flickering or flashing may
be recorded. JVCKENWOOD assumes no responsibility with regard to the distinguishing or
recording of traffic lights.
If coating is used on the windshield of the vehicle, recording quality may be affected.
There is no guarantee that the device can record video in all conditions.
When the device is dirty, wipe it with a dry silicone cloth or other soft cloth. If the device is very
dirty, remove the dirt with a cloth with neutral cleaner on it then wipe off the cleaner. Wiping the
device with a hard cloth or using a volatile substance such as thinner or alcohol may cause
scratches, deformation, deterioration or other damage.
When the lens is dirty, gently wipe it with a soft cloth dampened with water. Rubbing the lens
strongly with a dry cloth may cause scratches.
Precautions for installation
Precautions for use
Cleaning the device
If you notice a problem with the device
If you notice a problem with the device, first refer to “Troubleshooting” (P. 42) and check whether
there is a way to resolve the problem.
If the device does not return to normal after the reset, turn off the power of the device and then
contact your dealer or nearest JVCKENWOOD service center.
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
