KR200S

SYMBOLS
1. SAFETY INSTRUCTIONS
!
This symbol, wherever it appears, alerts you to
important operating and maintenance istructions in
the accompanying literature. Read the manual!
Dangerous voltages: risck of electric shock.
For information about the disposal of Waste Electrical
and Electronic Equipment (WEEE), please refer to the
website at
www.scanning.datalogic.com
This symbol alerts the user to the presence of
re c o mm e n da t i on s a b ou t pr o d uc t ' s us e a n d
maintenance.
CAUTION !
!
• To reduce the risk of electric shock, disconnect the amplifier from the AC mains before installing audio cable.
Reconnect the power cord only after making all signal connections.
• Connect the amplifier to a two-pole, three wire grounding mains receptacle. The receptacle must be connected to
a fuse or circuit breaker. Connection to any other type of receptacle poses a shock hazard and may violate local
electrical codes.
• Do not install the amplifier in wet or humid locations without using weather protection.
• Do not allow water or any foreign object to get inside the amplifier. Do not put objects containing liquid on, or near,
the unit.
• To reduce the risk of overheating the amplifier, avoid exposing it to direct sunlight. Do not install the unit near heat
emitting appliances, such as a room heater or stove.
• No naked flame sources such like lighted candles should be placed on the device.
• The amplifier should be placed so that its location does not interfere with its proper ventilation. For example, the
appliance should not be situated on a bed, carpet, or similar surface that may create an obstacle for the ventilation
openings.
ENGLISH
USER'S MANUAL pag. 02

2. INTRODUCTION
The KR200S is a high performance ultra-slim powered two way system designed for small to medium wavefront
systems, in both mobile and installed applications.
The KR200S includes two KR200 satellites and 2 KL18ma powered subwoofers.
KL18ma features a 1600 watt 18" drive unit with neodymium magnet structure and suspension engineered for
maximum linear excursion. Its ultra-light reflex cabinet is fitted with two pocket handles and one 35mm pole
mounting point for easy installation with every satellite speaker on it.
The KR200S features a line array of 32x2" high efficiency neodymium magnet drivers enclosed in an ultra-strong
chassis, to ensure high resistance and durability in the hardest working conditions.
The KR200S thanks to true line array technologies and powerful DSP system, achieve outstanding power and
coherence throughout the intended coverage allowing a wide dynamic range and a faithful reproduction of sound.
All the components are
The
designed by K-array R&D department and custom made under K-array control quality
system.
3. VOLTAGE REQUIREMENTS
KA 10 operates safely and without audio discontinuity if the AC voltage stays within either of two operating
windows: 95-125 (voltage selector on 115 V) or 195-250 V (voltage selector on 230 V), at 50 or 60 Hz.
115-230
Connecting a 115V system on a 230V AC Power causes heavy
damages to the device and serious risk for users .
CAUTION
!
The device is default set to be connected to 230 V AC Power. To use the device on a 115 V AC Power you need,
before connecting it, to move the voltage selector's cover, just loosening the two screws, and to choose the correct
use voltage by the red switch. Be sure that both voltage set on the selector and AC Power have the same value .
Always close the voltage selector's cover before connecting the device to AC Power. Change the label that points
out the correct voltage in use.
ENGLISH
pag. 03
USER'S MANUAL

PRESET
keep pressed
for preset lock
INPUT
PARALLEL
OUT
INPUT
(balanced)
GROUND
LIFT
ON LIMIT
LINK
LINK
(parallel)
POWER
ON
ATTENTION!:
READ MANUAL FOR
CORRECT
PRESET SELECTION
1+ POSITIVE OUT
1- NEGATIVE OUT
2+ N.C.
2- N.C.
REMOTE
DSP
POWER
OUTPUT
ANALOG
POWER SUPPLY
INPUT
PAD
dB
0
0.5 34
5
6
9
12
18
35
0
0
RS485
ADDRESS
MADE IN ITALY
WARNINGS:
To ensure correct operation,
allow at least
20 cm clearance from
back surface and correct
ventilation. To reduce risk of
electric shockdo not remove
cover. No operatoror serviceable
parts inside. Refer servicing to
qualified personnel. To reduce the
risk of fire or electric shock do
not expose this appliance to
rain or moisture.
CAUTION
RISK OF ELECTRICAL SHOCK
DO NOT OPEN!
DO NOT EXPOSE
TO RAIN OR MOISTURE!
ATTENTION
RISQUE DE CHOC ELECTRIQUE
NE PAS ENLEVER!
is a product of
viale Roma 7/i, 50037 S.Piero a Sieve
Firenze ITALY Tel + 39 055 8487222
HP Sound Equipment srl
ID12
PRESET
I
0
PUSH
Balanced XLR
In \ Out parallel
RS485 connection
for remote control
(don't connect to
LAN port!)
Ground lift switch
Input pad level
Preset change button
Keep it pressed 10sec.
to store preset as default
I D n u m b e r f o r
remote control
S p e a k o n p o w e r
output.
To use with KR200
satellite or with
K L 1 8 p a s s i v e
subwoofer
PowerCon Input
PowerCon parallel Output
(max 14 A)
Preset loaded
ENGLISH
pag. 04
4. AMPLIFIER PANEL
USER'S MANUAL

9 Kg
20 Kg
200 cm
100 cm
46.5 cm
46.5 cm
58.5 cm
7 cm
KR200
KL18ma
Open and lock the KR200 satellite
before installing on the KL18ma.
Warning
Pay attention when closing the
KR200 satellite, do it slowly and
watch your hands!
ENGLISH
pag. 05
5. PHYSICAL
USER'S MANUAL

To get higher SPL and horizontal directivity, is
possible to combine two KR200 columns using the
machanical parts fitted on each speaker.
Assembly Manual
System 1 System
2 x KR200
SX DX
2 x KL18ma
2 x KR200
2 x KL18ma
Unscrew the four screws that
fix the high steel bracket (by
a 2.5mm allen key), then
remove it.
Combine two KR200 by the
t o p u s i n g o n e o f t h e
disassembled brackets.
Disassemble the junction of the lower support.
Combine the two
KR200 by the bottom
u s i n g t h e o t h e r
disassembled steel
bracket. Fix it only by
the more external
h o l e s . T h e f o u r
ce n t r a l poi n t s of
attachment (A) must
be left free.
Assemble the junction
sopport with the middle of
the bracket, by the four
free central points of
attachment. Use other
four screws in the four
holes on the bottom of the
speaker.
M3x10
M3x10
A
M3x10
ENGLISH
pag. 06
6. SYSTEM'S EXTENSION
USER'S MANUAL

Acoustics
Power handling
Max power
Impedance
Operating frequency range
Frequency range
SPL 1W/1mt
Maximum SPL
Cross over
Type
Frequency
Transducers
Low frequency
High frequency
Audio Input
Connectors
Wiring
Audio powered Output
Connector
Wiring
Remote control Input
Connectors
Power Input
Connectors
Amplifiers
Type
Subwoofer power
Satellite power output
Protections
AC power
Operating range
Max continuos and burst current
Physical
Measures
Weight
800(sub) + 500(sat) w1
1200(sub) + 1200(sat) w
8 (sub) + 8 (sat)
30Hz - 19 KHz +/- 3dB (preset relating)
35Hz - 19 KHz +/- 3dB (preset relating)
97 dB(sub) 101 dB(sat)
127dB continuos - 133 dB peak
DSP controlled preset relating
150 Hz minimum (preset relating)
1 x 18" Neodymium speakers with 3" voice coil
32 x 2" Neodymium speakers with 0,75" voice coil
male + female parallel 3 poles balanced XLR
= ground / = hot / = cold
Female Speakon (14A max)
= CH1+ / = CH1- / = N.C. / = N.C.
1 x female 8 poles RJ45
2 x PowerCon IN/OUT (max out 14 A)
1 modules class D - DSP controlled
1000 Watt
1000 Watt
Dynamic limiter, over current, over temp, short circuits
Standard 210 - 240 Vac 50Hz (standard)
Standard 6A(>10 sec) - 12A (<1 sec)
46.5 x 46.5 x 58.5 cm (KL18ma) 5.5 x 7 x 200 cm (KR200)
20 Kg (KL18ma) 9 Kg (KR200)
2
3
4
5
6
7
8
8
W W
Pin1 Pin2 Pin3
Pin1+ Pin1- Pin2+ Pin2-
Optional 100 - 120 Vac 60Hz (optional)
Optional 10A(>10 sec) - 20A (<1sec)
Notes for data
1. Power handling is measured following AES standard conditions: transducers driven continuously for two hours with a band-limited noise signal having 6 dB of crest factor.
2. Max power is the maximum RMS applicable power for a musical signal, the referement signal is the one proposed by EIAJ standard.
3. Recommended maximum operating frequency range. Response depends on loading conditions and room acoustics.
4. Free field measured with 1/3 octave frequency resolution at 2 mt.
5. Measured@4 mt then scaled@1 mt.
6. Measured with audio source @1 mt.
7. This is the frequency in which the transducers produce the same sound pressure level (measured@2 mt).
8. Amplifier wattage rating is based on the maximum unclipped burst sine wave RMS voltage that the amplifier will produce into the nominal load impedance .
