KaiCong ZT01 User manual

KaiCong—Nothing important than safety!!

ZT01 Auto Tracking IR High Speed Dome Camera User Manual
!
KaiCong Electronic Technology Co,.LTD
!
ZT01 Automatic Tracking Ball Manual two-dimensional code
!
December/19/2013 V1.0
!
1

KaiCong—Nothing important than safety!!
!
Packing:
!
PTZ
1
Wall Bracket(include fixed Screws)
1
Holder
1
DC12V/5A power supply
1
Screws
4
PM8*25 socket head screws
4
User’s manual
1
Warranty Card
1
Conformity of quality
1
2

KaiCong—Nothing important than safety!!
Contents
!
1 Instruction————————————————————————————————4
1.1 Safety Instructions————————————————————————————4
2. Warnings ————————————————————————————————4
3. Features ————————————————————————————————5
2.1 Product Features ————————————————————————————5
2.2 Specifications —————————————————————————————6
4 Installation Preparations ——————————————————————————7
4.1 Tool List ————————————————————————————————7
4.2 Installation Preparation ——————————————————————————7
4.3 DIP Switch Setup ————————————————————————————8
5 Setup of the OSD Menu———————————————————————————9
5.1 Display Boot-UP Info———————————————————————————11
5.2 Enter the OSD Menu ———————————————————————————13
5.3 SYSTEM ———————————————————————————————15
5.4 LENS ————————————————————————————————17
5.5 CAMERA ———————————————————————————————17
5.6 PAN/TILT ———————————————————————————————18
5.7 AUTO RUNNING ————————————————————————————19
5.8 PRIVACY MASK (Need support by camera) —————————————————20
5.9 ALARM ————————————————————————————————23
5.10 LANGUAGE——————————————————————————————26
5.11ZOOM SET —————————————————————————————29
APPENDIX I: DIP SWITCH SETTING —————————————————————31
APPENDIX II Shortcuts Key Chart ———————————————————————33
APPENDIX III Trouble Shooting ———————————————————————36
!
3

KaiCong—Nothing important than safety!!
!
1 、Instruction
These series of products can be widely used in intelligent building, bank security, urban roads, airport terminals and bus stations, and
also are able to satisfy various demands from any square and activities occasion.
1.1 Safety Instructions
◆Make sure to read the use’s manual before using the product.
◆Always confirm to national and local safety codes during installation.
◆Only qualified and experienced person can carry on this installation and maintenance.
◆Use reliable tools, otherwise may lead to dangerous incidents.
◆Make sure that the environmental conditions meet the installation requirements for this product.
◆Please check the space and toughness of the site before installing. It should be able to bear 4 times the weight of the dome and
its accessories.
◆Please keep all the original dome package materials for future repacking and transporting.
1.2 Warnings
◆Do not install this speed dome in hazardous places where combustible or explosive materials are stored or used.
◆Do not place the machine on shaking desk.
◆Make sure no uncertain object or fluid substances get inside the unit.
◆This speed dome runs on DC 12V, do not connect it to higher or lower voltage.
◆Please check RS 485 cable.
◆Do not turn power on before finishing installation.
◆Do not disassemble any part of the items.
◆Use soft towel to clean the down cover when necessary, do not use caustic detergent.
◆To protect CCD, avoid facing the camera directly to the strong light.
◆To prevent damage, do not drop the unit or subject to strong shock or vibration."
4

KaiCong—Nothing important than safety!!
2、Features
2.1 Product Pictures
1) A (Superpower LED) 2)B (Anti-Darkening module)
!
2.2 Product Features
◆Alarm(Optional)
◆Adaptive PELCO-P/D protocol
◆IR start illumination menu can be adjusted
◆Auto running memory against power outage
◆RTC function, call any functions at any time
◆8 privacy masks (need the support of the camera)
◆Support 128 preset positions, and support lens preset
◆English OSD menu, user friendly and easily operation
◆Compass function,proportional zoom and auto flip function
◆Built in double devices for lightning proof and surge proof
◆Adopt advanced stepper motor less heat, runs steady, no shaking
◆Efficient heating device, ensure to work in -20°low temperature(Optional)
◆Support multi-protocols: SONY、LG、CNB、HITACHI、SAMSUNG etc. Special protocols can be ODM
◆Support 4 groups cruise scan(27 presets/group),4 group patterns, one scan, and 360°continuous scan and 360°intermittent scan
◆IR lights automatically adjust the light intensity according to the zoom speed to reduce the dark angle and flashlight effect.
◆The upper dome adopts 7 " aluminum alloy structure, better magnetic shield and heat radiation.
◆The underpart dome adopts full metal class points bin type design, fast heat dissipation and anti-mist, noninterference light
source images and long life span IR light
◆Variable housing, 2 kinds of housing can be chosen:
A: A (Superpower LED): 1pc superpower LED IR light+ 6 pcs LED Array IR lights. Superpower LED IR light equipped with big or
small lens(the big lens’ min. Angle is 5°) to secondary condense the light, this model can fully gather IR lights into small angle and
emit to far distance, and the effect is excellent and night vision distance is up to 150 meters.
B: B (Anti-Darkening module)：1pc IR Zoom module +4 pcs LED Array IR lights, light vision effect evenly and distance up to 120
meters."
5

KaiCong—Nothing important than safety!!
2.3 Specifications
!
Power Supply
Output：DC12V±5%，5A
Input：AC100～240V 50/60Hz
Max. Power
IR off：15W
IR on：31W
Sync system
Internal Sync
Language
English
Pan Speed
0.08°～240°/S
Tilt Speed
0.08°～240°/S
Pan Range
0°～360°(Continuous)
Tilt Range
0°～90°（180° auto flip）
Preset
128
Preset Accuracy
<±0.1°
Tour
4, 27 presets/tour
Pattern
4
Zone
1
Protocol
RS485
Communication
PELCO-D/P auto detected
Baud Rate
2400bps、4800bps、9600bps、19200bps
Address
1-255
RTC
Set any functions at any time
IR Light switch
A (Superpower LED)：Default::1~5 times, open the near-distance lights; 6~9
times, open the near-distance and middle-distance lights; after 10 times, turn off the
near-distance lights, open the middle-distance and far-distance lights.
B (Zoom Module)：in 10 times, open IR module+ near distance lights; after 10
times, open IR module+far-distance lights, turn off the near-distance lights.
Work Temperature
Indoor：0℃～+50℃；
Outdoor ：-20℃～+50℃(with heater)
Work Humidity
<90%
6

KaiCong—Nothing important than safety!!
4 Installation Preparations
4.1 Tool List
(The tools in the list will be used or not)
(1) Screws (2) Monkey wrench
(3) Philips screwdriver (4) Straight Screwdriver
(5) Wire stripper (6) Ladder
(7) Electric drill (8) Socket head wrench
(9) Hammer (10) Electric iron
(11) BNC mail connector
!
4.2 Installation Preparation
(1) Check the space and toughness of the site Make sure that the environmental conditions meet the installation requirements for this
product.
(2) Please check the space and toughness of the site before installing. It should be able to bear 4 times the weight of the PTZ and its
accessories.
4.3 DIP Switch Setup
(1)Default: Pelco P/D auto detected, baud rate: 2400bpx, address: 1. Detach the upper housing and bottom cover, you can see DIP
switch below
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!!
!
(2)Baud Rate Setup
Decoder Switch: 9~10 (1=ON, 0=OFF)
!
Notice: Please restart the camera after setting switch.
(3) When the DIP Switch 9th and 10th are ON, the PTZ can automatically detected the baud rate 2400, 4800,9600,19200."
Switch 9-10 setting
Baud Rate
Max transmission distance(M)
9
10
0
0
2400BPS
1800
1
0
4800BPS
1200
0
1
9600BPS
800
1
1
Auto detected 2400、4800、9600、19200BPS
600-1800
7
DIP Switch Position
Reset Position

KaiCong—Nothing important than safety!!
5.1 Setup of the OSD Menu
5.1.1 Protocol
(1) Braud Rate
The baud rate is determined based on the ball machine DIP switch. When the baud rate DIP switch DIP nobody any
baud rate of automatic identification
Data bits: 8
Parity: without
Stop bits: 1
(2) Protocol
PECOL-D, pecol-p, SAMSUNG, B01, HIKVISION, DAHUA.
!
5.1.2 PTZ Control
Left, Right, Auto flip.
5.1.3 Camera control
TELE WIDE NEAR FAR OPEN CLOSE, NEAR FAR
5.1.4 Presets
Set, call, delete
5.2 Running setup
5.2..1 Presets
Support 220 persets, Call or set up preset point No. 66- No.99 (special preset point of system) to open the menu.
!
!
2. The operation process of presets:
(1) Set up preset points
Shake the keyboard joystick or other control software to make PTZ reach a region. Enter the point ID on the
keyboard or other control software and press “install” or “SET” button. Set the current preset point, and the PTZ
will save the zoom of the camera to a specific point ID.
(2) Call preset points
Enter the point ID on the keyboard or other control software and press “transfer” or “CALL” button. And the PTZ
will jump to the position which the presets had set before. If the point ID is not set before, the OSD will show "not
set"
(3) Delete preset points
Enter the point ID on the keyboard or other control software and press “delete”, then the change of preset points
will be deleted.
5.2.2 Cruise function of preset points
The product supports 9 cruise functions of presets points and each cruise trajectory can edit 16 preset points.
It will make the corresponding presets jump one by one according to priority. 16 preset points should be set by
cruise function one by one. If the preset point number is not set, it will jump directly to the next set preset point.
Concerning the cruise function configuration, please see the cruising scan settings of the menu.
5.2.3 Function of sweep scan
The product supports 16 sweep scan. It finishes the action of scanning by PTZ between two points.
You should pre-set the start point, end point and the DIA. The zoom of camera will change according to the
camera of the start point and the one of the end point will never change. Please see the menu of sweep scan
function configuration behind.
!
5.2.4 Function of rotate scan (360°)
The product support 8 rotate scan, which scan by 360°. You need pre-set the start point, end point and the DIA
(Clockwise or counterclockwise). See the menu about the details.
!
5.2.5 Function of pattern scan
The product supports 4 pattern scan. Every pattern scan can record 450 mandates for 10 minutes. It includes 2
phases. The first one is record, which will record all mandates of control that the product receives. The second one
is playback, which will execute the mandates circulating. See the menu about the details.
!
5.2.6 Timing functions
The product supports 4 timing functions. It can specify the machine reaches a certain point and perform the
appointed action in time. You need to set start time, end time and time mode (Appointing one appointed day to
start the function). When the system clock reaches the start time, it will perform the appointed action. And when it
reaches the end time, it will finish the action. Concerning timing function configuration, see the menu behind.
!
8

KaiCong—Nothing important than safety!!
Note:
When the system clock reaches the end time, the system will judge whether the current implementation of the action initiated by a
timer first. If not, the action will not be canceled.
!
5.2.7 Power up action
After the system reboot, it will perform the appointed action. It includes: (1) Transferring preset points. (2) Performing sweep scan.
(3) Performing rotate scan. (4) Performing pattern scan. (5) Performing preset point cruise (6) Performing motion detection. (7)
Performing Motion tracking
!
5.2.8 Park action & park time
Definition of park action: without control of the machine. The product doesn’t perform any continuous action.
Park action: when the product comes to the park time in the circumstances of park, it will perform the appointed action. It includes:
(1) Transferring preset points. (2) Performing sweep scan. (3) Performing rotate scan. (4) Performing pattern scan. (5) Performing
preset point cruise (6) Performing motion detection. (7) Performing Motion tracking
!
5.2.9 Depth of field proportion deceleration (it require the camera read the zoom)
The product supports the function of depth of field proportion deceleration. It will read the zoom automatically and determine the
maximum speed of the product according to the zoom. The zoom of camera becomes bigger; the maximum speed by manual control
becomes lower.
!
5.2.10 Auto flip
In the process of operating the joystick to trace and monitor, if the user move the lens to the bottom (vertical) then continues pressing
the joystick, the lens will automatically flip 180º horizontally, then the user can still control it to move upwards till 90°, which
enables the user to directly observe the situation on the back side, thus fore-and-aft 180° consecutive monitoring can be realized.
!
5.2.11 Motion detection
The product supports 8 zones for motion detection. Every zone supports 4 regions. The sensitivity, the size of the target and the
position of region can be set.
!
5.2.12 Motion tracking
The product supports Motion tracking. It will trace the locomotive object and change the zoom of the lens to an opportune magnitude
when there is a locomotive object. The sensitivity, trigger tracking object size, and trigger tracking object speed can be adjusted to
different situation.
!
5.3 Menu Setup
5.3.1 Open the menu
Call or set up preset point No.95 (a special preset point of system) to open the menu.
5.3.2 Basic patterns of menu
Menu includes 4 basic forms:
(1) “[******]”
This kind of menu item shows that the menu involves submenu.
(2) “<******>”
This kind of menu item shows that the number in”< >”can be changed by “up” and “down”, “left” and “right”.
(3)“******>”
This kind of menu item shows that press <IRIS OPEN> to enter configuration.
(4)“****** ：******”
This kind of menu item includes 2 parts, before “:”is the item of configuration, after”:” is the value of configuration. Pressing
<IRIS OPEN>and it will changed into“****** ：<******>”.Concerning <******>”, please see (ⅱ).
5.3.3 Basic operation of menu
Basic operation of menu: up and down, left and right, <IRIS OPEN>, <IRIS CLOSE>
Up and down, left and right: about ergodic menu item or modify the value of the item.
<IRIS OPEN>: to enter submenu, begin to modify the value of the menu item, confirm and save the value.
<IRIS CLOSE>: to return to the previous menu or cancel the modification of the value.
!
!
9

KaiCong—Nothing important than safety!!
5.4.1 System Info.
In this menu the user can find system information. Including:
Camera number, camera address, Baud Rate, protocol, camera temperature, Software version, Camera name.
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
5.4.2 Display Setup
In this menu， User can set any names in the Monitor. Including: Camera title, Date Display, Presets Display, Angle Zoom, Alarm,
Regional Prompt, Temperature Display.
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
1) Description of all the Configurations
Continuance: After set the “Display Setup” in this function, , it will be always show
Open: After set the “Display Setup” in this function, , it will be always show
Close: It will not display this screen
〈N seconds〉when open this, N seconds later, it will auto clear all the display, N: 1~60 seconds
〈N minutes〉when open this, N seconds later, it will auto clear all the display, N: 1~60 minutes.
(2) Set Date Display
Move to present menu to “Display Setup”, chose OPEN (IRIS OPEN+) into the Submenu. Move to the menu which you will change
it, choose OPEN to get in the present menu. Press to open the Modify button to enter the value of the current menu item, move the
joystick up and down to select the value of the menu item, press the OPEN(IRIS+) to confirm the disease exit. Press the Close button
to cancel the setting operation."
10
Main Menu
System Info.
Display Setup
Control Settings
Camera Setup
Run Setup
Others
Language
System restart
Restore factory settings
Exit
System Info.
Camera No.”XXXX
Camera add.:003
Baud Rate: 2004,N,8,1
Protocol: PECOL-D
Camera temperature: 27
Version: V1.0.0
Camera Title: XXXX
Back
Exit
Main Menu
System Info.
Display Setup
Control Settings
Camera Setup
Run Setup
Others
Language
System restart
Restore factory settings
Exit
Display Setup.
Camera Title: 〈3 seconds〉
Date Display: 〈Open〉
Presets Display: 〈3 seconds〉
Angle Zoom Display: 〈3 seconds〉
Alarm Display: 〈3 seconds〉
Regional Prompt: 〈close〉
Camera Title
Location Display Setup
Back
Exit

KaiCong—Nothing important than safety!!
(3) Camera Title Setup
Enter 【Camera Title】Submenu→Move to【Camera Title】→Move the joystick left and right to select the character set→Move to
“ Input Type” Select the current type of characters→Select OPEN( IRIS OPEN+) Enter the character→Select it (The character which
will be twinkling) →Press OPEN( IRIS OPEN+) Select it.
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
After finish all the choice, move to “ Confirm input” Press “ OPEN (IRIS OPEN+) Save it and back to Return to the previous menu,
or move to Cancel, Click OPEN (IRIS OPEN+) exit
!
!
!
!
!
!
!
(4) Regional Prompt Setup!
11
Display Setup.
Camera Title: 〈3 seconds〉
Date Display: 〈Open〉
Presets Display: 〈3 seconds〉
Angle Zoom Display: 〈3 seconds〉
Alarm Display: 〈3 seconds〉
Regional Prompt: 〈Close〉
Camera Title
Location Display Setup
Back
Exit
Camera Title Setup
Camera Title: _ _ _ _ _ _ _
Input Type: (Number)
/ (Capitals)
/ (Spell)
/ (Letter)
A B C D E F G H I J K L M N O P Q R
S T U V W X Y Z.
〈_ _ _ _ _ _ _〉
〈_ _ _ _ _ _ _ _ _ _ _ _ _ _〉
Confirm input
Cancel
!
!
!
Regional Prompt
Display Location Type: 〈Date〉
/〈Camera title & Add.〉
/ 〈Presets Title〉
/ 〈Alarm Location〉
/ 〈Angle Zoom Display〉
/ 〈Regional Prompt〉
Setup
Back
Exit
Display Setup.
Camera Title: 〈3 seconds〉
Date Display: 〈Open〉
Presets Display: 〈3 seconds〉
Angle Zoom Display: 〈3 seconds〉
Alarm Display: 〈3 seconds〉
Regional Prompt: 〈Close〉
Camera Title
Location Display Setup
Back
Exit
Display all items can be displayed
Configuration items can be moved
!
!
Confirm: (OPEN)
Cancel: (CLOSE)

KaiCong—Nothing important than safety!!
!
5.4..3 Control Setting
[NORMAL SETUP]: this submenu includes some basic controlling attribute. See the description of the submenu.
[ALARM SETUP]: this submenu includes setup of alarm attribute. See the description of the submenu.
[IR SETUP]: this submenu includes setup of IR attribute.
[TIMER SETUP]: this submenu includes setup of time attribute. See the description of the submenu.
[WIPERS SETUP] this submenu includes setup of controlling attribute of wipers. Just domes with wipers support this setup. Others
show“[ ------ ]”
[ADVANCE SETUP]: this submenu includes setup of advance attribute. See the description of the submenu.
!
【Normal Setup】setup includes following submenu items:
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
Press<IRIS OPEN>to enter normal setup. Move to menu item, press<IRIS OPEN>to modify the value of the corresponding menu
item—> move the joystick up and down, left and right to modify the value —> press<IRIS OPEN> to confirm and save, and
press<IRIS CLOSE> to cancel the setting.
Auto flip: Moving to the vertical bottom by the lens is automatic flip by 180º horizontally,
Proportion speed: Confirm the hand controlling speed according to the zoom of camera.
Image freeze: Before preset calling, first send message to freeze frame. Then unfreeze the frame after it reaches the preset point.
Soft addr switch: Turn on the switch, the function of soft address is open. The value is the value of the menu “SOFT ADDR”. When
you cancel this function, the dome’s address is the address that the DIP switch has set.
Soft addr: The No. of soft address.
Power on action: The action that the dome executive once power on.
Park time: Move the joystick left and right to select<N second>、<N minute>, and move the joystick up and down to select the value
of “N”.
!
Park action: Move the joystick left and right to select the type of park action, and move the joystick up and down to select the value
of this type."
12
Main Menu
【System Info.】
【Display Setup】
【Control Setup】
【Camera Setup】
【Run Setup】
【Other setup】
Language Setup: 〈Chinese〉
〈System Restart〉
Restore factory settings
Exit
!
Control Setup
【Normal Setup.】
【Alarm Setup】
【IR Setup】
【Timing Setup】
【Wiper Control】
【Advance Setup】
Language Setup: 〈Chinese〉
Back
Exit
!
Control Setup
【Normal Setup】
【Alarm Setup】
【IR Setup】
【Timer Setup】
【Wiper Setup】
【Advance setup】
Language Setup: 〈Chinese〉
〈System Restart〉
Restore factory settings
Exit
Normal Setup
Auto Flip: OPEN/CLOSE
Proportion speed: OPEN/CLOSE
Image Freeze: OPEN/CLOSE
Soft Add. Switch: OPEN/CLOSE
Soft Add. No.: 〈n〉
Power on action: None
Park time: 1~60seconds
1~60 minutes
Park Action: NONE
Return
Exit
Control Setup
【Normal Setup】
【Alarm Setup】
【IR Setup 】
【Wiper Setup】
【Advance Setup】
【Other setup】
Return
Exit

KaiCong—Nothing important than safety!!
(3) IR Setup
Press<IRIS OPEN>to enter alarm setup. Move to menu item, press<IRIS OPEN>to modify the value of the corresponding menu item
—> move the joystick up and down, left and right to modify the value —> press<IRIS OPEN> to confirm and save, and press<IRIS
CLOSE> to cancel the setting.
ALARM ID: When you modify the alarm number, all items of this menu will refresh the configuration value of all items according to
the configuration of the alarm number.
ALARM MODE: <START SCHEDULE>---when there is an alarm, it will executive the appointed action by “ALARM ACTION”.
<CLOSE SCHEDULE>---never executive any action even if there is an alarm. <AUTO>---when there is an alarm, judge the currant
time, if it is during the configuration values of “START TIME” and “CLOSE TIME”, it will executive alarm action.
ALARM OUTPUT: Switch of alarm output.
KEEP TIME: The time keep an alarm. Move the joystick left and right to select<N second>、<N minute>, and move the joystick up
and down to select the value of “N”.
START TIME: When the alarm mode is <AUTO>, it appoints when the alarm is ON.
END TIME: When the alarm mode is <AUTO>, it appoints when the alarm is OFF.
[ALARM TITLE]: Concerning the submenu’s setting way of the alarm title, please see the setting way of dome title. All alarm title
can be set independently.
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
Press<IRIS OPEN>to enter IR setup. Move to menu item, press<IRIS OPEN>to modify the value of the corresponding menu item—
> move the joystick up and down, left and right to modify the value —> press<IRIS OPEN> to confirm and save, and press<IRIS
CLOSE> to cancel the setting.
IR MODE: Define the mode of IR brightness. Auto- IR brightness read the environmental condition at regular time, according to the
value that “SCAN TIME” has set. If it reaches the level that “THRESHOLD” has set, the dome will open or close the IR brightness
automatically.
Hand-actuated - the IR brightness will keep ON. Hand-shutdown - the IR brightness will keep OFF. Camera – when the IR of camera
changed automatically, the IR will change into the corresponding mode. Time – turn on the IR brightness automatically during
“OPEN TIME” and “CLOSE TIME”.
BRIGHTNESS: Appoint the brightness level of IR brightness. If it is<AUTO>, the brightness will adjust to the currant zoom of the
camera.
OPEN TIME: When it is <TIME>, the value of the menu is defined as open time of the IR brightness,
CLOSE TIME: When it is <TIME>, the value of the menu is defined as close time of the IR brightness,
COMPENSATION: Level of compensation.
SCAN TIME: Define the scan time of lightness sensitivity. Move the joystick left and right to select<N second>、<N minute>, and
move the joystick up and down to select the value of “N”.
THRESHOLD: The threshold level of IR brightness turning on.
"
13
Alarm Setup
Alarm ID: 1~7
Alarm Mode: 〈Close
Schedule;〈Start
Schedule〉;〈Auto〉
Linkage Function: 〈No
action〉
Alarm Output: 〈Open〉
〈Close〉
Alarm Time: 〈Close〉/
〈1~60 seconds〉/〈1~60
minutes〉
Start Time: 00:00
End Time: 00:00
Alarm Title:
Return
Back
Control Setup
【Normal Setup】
【Alarm Setup】
【IR Setup 】
【Wiper Setup】
【Advance Setup】
【Other setup】
Return
Exit
IR Setup
I R M o d e : 〈Auto〉/
〈Hand-actuated〉/
〈Hand-shutdown〉/
〈Time〉〈Camera〉
Brightness: Auto:010
Open Time: 00:00
Close Time: 00:00
Compensation: Moderate
S c a n T i m e : < 1 ~ 6 0
seconds> <1~60minutes>
Threshold: <n>
Return
Back

KaiCong—Nothing important than safety!!
(3)Timer Setup
Press<IRIS OPEN>to enter IR setup. Move to menu item, press<IRIS OPEN>to modify the value of the corresponding menu item—
> move the joystick up and down, left and right to modify the value —> press<IRIS OPEN> to confirm and save, and press<IRIS
CLOSE> to cancel the setting.
IR MODE: Define the mode of IR brightness. Auto- IR brightness read the environmental condition at regular time, according to the
value that “SCAN TIME” has set. If it reaches the level that “THRESHOLD” has set, the dome will open or close the IR brightness
automatically.
Hand-actuated - the IR brightness will keep ON. Hand-shutdown - the IR brightness will keep OFF. Camera – when the IR of camera
changed automatically, the IR will change into the corresponding mode. Time – turn on the IR brightness automatically during
“OPEN TIME” and “CLOSE TIME”.
BRIGHTNESS: Appoint the brightness level of IR brightness. If it is<AUTO>, the brightness will adjust to the currant zoom of the
camera.
OPEN TIME: When it is <TIME>, the value of the menu is defined as open time of the IR brightness,
CLOSE TIME: When it is <TIME>, the value of the menu is defined as close time of the IR brightness,
COMPENSATION: Level of compensation.
SCAN TIME: Define the scan time of lightness sensitivity. Move the joystick left and right to select<N second>、<N minute>, and
move the joystick up and down to select the value of “N”.
THRESHOLD: The threshold level of IR brightness turning on.
!
!
!
!
!
!
!
!
!
!
!
!
!
!
(5) Advance Setup
!
Press<IRIS OPEN>to enter advance control. Move to menu item, press<IRIS OPEN>to modify the value of the corresponding menu
item—> move the joystick up and down, left and right to modify the value —> press<IRIS OPEN> to confirm and save, and
press<IRIS CLOSE> to cancel the setting.
PAN SPEED LIMIT: Set the highest speed of PAN
TILT SPEED LIMIT: Set the highest speed of TILT
PAN CTRL REV: When this function is ON, move the joystick right, the dome will move to the left side.
TILT CTRL REV: When this function is ON, move the joystick down, the dome will move up.
PAN LEFIT LIMIT: The position that can not step over by manual.
PAN RIGHT LIMIT: The position that can not step over by manual.
HORIZONTAL ZERO SETTING: It set the “NORTH” of the dome."
14
Control Setup
【Normal Setup】
【Alarm Setup】
【IR Setup 】
【Wiper Setup】
【Advance Setup】
【Other setup】
Return
Exit
Timer Setup
Normal Setup
Timer ID: <….>
Timer Action: <Close>/<…..>
Start Time: 00:00
End Time: 00:00
Timer Cycle
Return
Back
!
Timer Period Setup
Monday:<Open>/<Close>
Tuesday: <Open>/<Close>
Wednesday: <Open>/<Close>
Thursday: <Open>/<Close>
Friday: <Open>/<Close>
Saturday: <Open>/<Close>
Sunday: <Open>/<Close>
Return
Back
!
Return
Exit
Control Setup
【Normal Setup】
【Alarm Setup】
【IR Setup 】
【Wiper Setup】
【Advance Setup】
【Other setup】
Return
Exit
Advance Setup
Pan Speed Limit : <….> (64L)
Tilt Speed Limit: <….> (64L)
Pan Control Direction: <Open>/ <Close>
Tilt Control Direction: <Open>/ <Close>
Pan Left Limit
Pan Right Limit
Horizontal Zero
Return
Back

KaiCong—Nothing important than safety!!
5.4.4 Camera Setup
Camera Setup includes the following submenu items:
Note: When the camera supports OSD, it will enter the menu auto.
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
5.4.5 Running Setup
Preset Point: Setting preset points
Region Setup： Setting dome’s region instruction
Cruise Setup: Setting cruise scanning of preset points.
Line Scan: Setting scan between two points.
Circle scan: Setting scan by 360°
Motion Tracking: Setting tracing attribute of motion object.
Motion Detection: Setting detaching attribute of motion object.
"
15
Main Menu
【System Info.】
【Display Setup】
【Control Setup】
【Camera Setup】
【Run Setup】
【Other setup】
Language Setup: 〈Chinese〉
〈System Restart〉
Restore factory settings
Exit
Main Menu
Camera OSD: <Close>
Auto Focus: <Open>
Digital Zoom: <Close>
BLC: <Close>
Mirror Vertical: Close
Image Rotate: Close
Zoom Speed: <High>
ICR: <Auto>
Advance Setup
Return
Back
Main Menu
【System Info.】
【Display Setup】
【Control Setup】
【Camera Setup】
【Run Setup】
【Other setup】
Language Setup: 〈Chinese〉
〈System Restart〉
Restore factory settings
Exit
Running Setup
Preset Point
Region Setup
Cruise Setup
Pattern Scan
Sweep Scan
Circle Scan
Motion Detection
Motion Tracking
Return
Exit

KaiCong—Nothing important than safety!!
“[ Preste Setup]
Press<IRIS OPEN>to enter preset point setup. Move to menu item, press<IRIS OPEN>to modify the value of the corresponding
menu item—> move the joystick up and down, left and right to modify the value —> press<IRIS OPEN> to confirm and save, and
press<IRIS CLOSE> to cancel the setting.
POINT ID: Point ID.
[POINT TITLE]: The title of the submenu which you can edit preset point. The point title just supports point No.1~48. Others can not
be set. Concerning the setting way, please see the progress of dome’s title setting.
SET>: setting preset points.
CALL>:calling preset points.
DELETE>: delete the preset point’s information that the current point has saved
DELETE ALL>:delete all preset points saved by the dome.
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
“[Region Setup]”: Setting dome’s region instruction, setting dome’s title in one region. The lens is “right” side according to
clockwise when it is format. When it is inversion, anticlockwise is the “right” side.
Press<IRIS OPEN>to enter region setup. Move to menu item, press<IRIS OPEN>to modify the value of the corresponding menu
item—> move the joystick up and down, left and right to modify the value —> press<IRIS OPEN> to confirm and save, and
press<IRIS CLOSE> to cancel the setting.
REGION ID: 8 regions can be set.
[REGION TITLE]：The title of the submenu which you can region title. Concerning the setting way, please see the progress of
dome’s title setting.
SET LEFT>：setting the left boundary of the region.
SET RIGHT>：setting the right boundary of the region.
DELETE>：delete the region title."
16
Running Setup
Preset Point
Region Setup
Cruise Setup
Pattern Scan
Sweep Scan
Circle Scan
Motion Detection
Motion Tracking
Return
Exit
Region Setup
Region ID: <…> (8 Regions)
[Region Title]
Set Right
Set Left
Delete
Return
Exit
Running Setup
Preset Point
Region Setup
Cruise Setup
Pattern Scan
Sweep Scan
Circle Scan
Motion Detection
Motion Tracking
Return
Exit
Running Setup
Preset Point
Region Setup
Cruise Setup
Pattern Scan
Sweep Scan
Circle Scan
Motion Detection
Motion Tracking
Return
Exit
Region Setup
Region ID: <…> (8 Regions)
[Region Title]
Set Right
Set Left
Delete
Return
Exit
Running Setup
Preset Point
Region Setup
Cruise Setup
Pattern Scan
Sweep Scan
Circle Scan
Motion Detection
Motion Tracking
Return
Exit

KaiCong—Nothing important than safety!!
“ [Cruise Setup]” : Setting cruise scan of preset point
Press<IRIS OPEN>to enter cruise setup. Move to menu item, press<IRIS OPEN>to modify the value of the corresponding menu
item—> move the joystick up and down, left and right to modify the value —> press<IRIS OPEN> to confirm and save, and
press<IRIS CLOSE> to cancel the setting.
CRUISE ID: support 9 cruise of preset point.
[POSITION EDIT]: edit the preset point’s position of this cruise ID.
START>: start cruise scan. It will exit the menu automatically when it starts.
SET DEFAULT>: restore the cruise configuration of default preset point, state time and speed. Default state time is 5 seconds and
speed is 64-level.
Press<IRIS OPEN>to enter position edit. Move to menu item, press<IRIS OPEN>to modify the value of the corresponding menu
item—> move the joystick left and right to select “POS.”, “STATE TIME” and “SPEED”; move the joystick up and down to select
the value.—> press<IRIS OPEN> to confirm and save, and press<IRIS OPEN> to cancel the setting.
POS.: the number of cruise preset point.
STATE TIME: the time state after the dome jump to this preset point.
SPEED: the speed of jumping to one preset point.
!
!
!
!
!
!
!
!
!
!
!
!
!
!
“ [ Line Scan ] ”: Set scan between two point.
!
!
!
!
!
!
!
!
!
!
!
!
17
Cruise Setup
Cruise ID: <…>
[Position Edit]
Start
Set Default
Return
Exit
Cruise Setup
Index Pos. Dwell Time Speed
1. 001 <1~255>secs 64L
2. 002 <1~255>secs 64L
3. 003 <1~255>secs 64L
4. 004 <1~255>secs 64L
Pre. Page
Next Page
Return
Exit
Running Setup
Preset Point
Region Setup
Cruise Setup
Pattern Scan
Sweep Scan
Circle Scan
Motion Detection
Motion Tracking
Return
Exit
Pattern Scan
Scan ID: <…> (4 Pattern)
Record
Start
Set Default
Return
Exit
Pattern Scan
Scan ID: <…> (4 Pattern)
Record
Start
Set Default
Return
Exit
Free Space
[ | | | | | | | | | | | | | | | | | | | ] 100%
OK>----------<Open>
Cancel>------<Close>

KaiCong—Nothing important than safety!!
!
Press<IRIS OPEN>to enter cruise setup. Move to menu item, press<IRIS OPEN>to modify the value of the corresponding
menu item—> move the joystick up and down, left and right to modify the value —> press<IRIS OPEN> to confirm and
save, and press<IRIS CLOSE> to cancel the setting.
Press<IRIS OPEN>to enter rotate scan. Move to menu item, press<IRIS OPEN>to modify the value of the corresponding
menu item—> move the joystick up and down, left and right to modify the value —> press<IRIS OPEN> to confirm and
save, and press<IRIS CLOSE> to cancel the setting.
SCAN ID: support 8 rotate scan.
SCAN SPEED: setting scan speed level of 360°, 64 levels in total.
SCAN DIR: direction of scan. Clockwise or anticlockwise.
SET START POS>: setting the start position of rotate scan. Press “OPEN” to enter the start position, and move the joystick
to make the lens move to the start position, then press<IRIS OPEN>to save the position.
START>:start the rotate scan. It will exit the menu automatically when it starts.
DELETE>: delete the scan
!
!
!
!
!
!
!
!
!
!
!
!
!
!
[MOTION TRACKING ]: setting tracing attribute of motion object.
!
!
!
18
Running Setup
Preset Point
Region Setup
Cruise Setup
Pattern Scan
Sweep Scan
Circle Scan
Motion Detection
Motion Tracking
Return
Exit
Line Scan
Line ID : <…> (16 lines)
Speed: <…> (1-64L)
Dweell Time: <1-60mins>/
<1-60secs>
ScanDIR: <Clockwise>/
<Counterclockwise>
Set Start Pos.>
Set End Pos.>
Start
Delete
Return
Exit


  
  
  
  
  
  
   
   
 
 


  
   
  
 
 
 
 
 


  
  
  
  
  
  
   
   
 
 


  
   
  
 
 
 
 
 

KaiCong—Nothing important than safety!!
Press<IRIS OPEN>to enter Motion tracking. Move to menu item, press<IRIS OPEN>to modify the value of the corresponding menu
item—> move the joystick up and down, left and right to modify the value —> press<IRIS OPEN> to confirm and save, and
press<IRIS CLOSE> to cancel the setting.
TRACE ENABLE: whether open Motion tracking.
SENSITIVITY: setting the sensitivity of triggering Motion tracking.
OBJECT SIZE: setting the motion object’s size of triggering Motion tracking.
OBJECT SPEED: setting the speed of motion object.
BACK TIME: time of backing to the default scene when losing the motion target.
ZOOM TRACE: setting zoom of lens.
SET REGION>: setting the backing scene that back when it loses the object.
DELETE REGION>: delete the backing scene.
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
Press<IRIS OPEN>to enter motion detection. Move to menu item, press<IRIS OPEN>to modify the value of the corresponding
menu item—> move the joystick up and down, left and right to modify the value —> press<IRIS OPEN> to confirm and save, and
press<IRIS CLOSE> to cancel the setting.
ZONE NUM: support 8 zones. After starting motion detection, system will skip 8 zones by turns.
STATUS TIME: the status time of the zone.
[DETE ACH REGION]: setting the detach region of the zone. Every zone has 4 regions.
SET ZONE>: setting the zone
DELETE ZONE>: delete the zone.
START>: start the motion detection. It will exit the menu automatically when it starts.
Press<IRIS OPEN>to enter the submenu item of motion detection. Move to menu item, press<IRIS OPEN>to modify the value of
the corresponding menu item—> move the joystick up and down, left and right to modify the value —> press<IRIS OPEN> to
confirm and save, and press<IRIS CLOSE> to cancel the setting.
REGION NUM: a zone supports 4 regions.
REGION ENBALE: enable defined zone. 4 regions is in a condition of enable under acquiescence.
TRACE: whether start “trace” when it finds a motion object in the region.
SENSITIVITY: sensitivity of detach.
OBJECT SIZE: setting the motion object’s size of triggering motion detection
SET REGION>: start “set region”, you can set the appointed region’s position in the screen. After entering, move the joystick up and
down, left and right to set the start position of the region. Press “OPEN” to set the size of the region, then press ”OPEN” to finish
setting, and press ”CLOSE” to cancel the setting.
!
[PRIVACY SETUP]: setting private setup region.( needs support of the camera. It just supports SONY, NEWLG
camera privacy setup so far
"
19


  
  
  
  
  
  
   
   
 
 
 

  
  
  
  
   
  
 
 
 
 


  
  
  
  
  
  
   
   
 
 
 

  
  
  
  
   
  
 
 
 
 


  
  
  
  
  
  
   
   
 
 
 
                        
  
   
  
    
 
 
 
 
 
   

  
  
  
  
  
 
 
 


  
  
  
  
  
  
   
   
 
 
 
                        
  
   
  
    
 
 
 
 
 
   

  
  
  
  
  
 
 
 


  
  
  
  
  
  
   
   
 
 
 
                        
  
   
  
    
 
 
 
 
 
   

  
  
  
  
  
 
 
 

KaiCong—Nothing important than safety!!
Press<IRIS OPEN>to enter private setup. Move to menu item, press<IRIS OPEN>to modify the value of the corresponding
menu item—> move the joystick left and right to modify the value —>move the joystick to select the value—> press<IRIS
OPEN> to confirm and save, and press<IRIS CLOSE> to cancel the setting.
!
MASK ID: 24 masks(different cameras, different masks)
!
MASK ENABLE: open or close the mask of corresponding mask ID.
CAMERA MASK SETUP>: Press<IRIS OPEN>to enter camera mask setup. Move the joystick to make one region of the
lens move—>press<IRIS OPEN>to enter the configuration of region’s size(at this time, there will be a black region in the
middle of the screen —> move the joystick up and down, left and right to configure the size of the black region —>
press<IRIS OPEN> to confirm.
!
DELETE>: delete the mask region.
CLEAN>: delete all 24 mask region.
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
[PASSWORD SETUP]: the password to enter the menu
Press <IRIS OPEN> to enter date setup. Move to menu item, press<IRIS OPEN>to modify the value of the corresponding menu item
—> move the joystick up and down, left and right to modify the value —> press<IRIS OPEN> to confirm and save, and press<IRIS
CLOSE> to cancel the setting.
DATE: date of dome’s system.
TIME: current time of dome’s system."
20


 
 
 
 
 


  
  
 
 
 
 
 


 
 
 
 
 


  
  
 
 
 
 
 


  
  
  
 
 


  
 
   
 
 


  
  
  
 
 


  
 
   
 
 
