Leeds 7140-72 User manual

HD 720p Home Wifi
Camera
Instruction Manual
7140-72
1 x HD 720p Home Wifi Camera
1 x USB to Micro-USB power source
1 x Instruction Manual
1 x AC Adapter
1 x Mounting Screw
1 x Reset Pin
Photo size: 1MB, 1.3MB, 2MB
Video resolution: 720P 1280 x 720 @ 30fps
in MP4 (H.264)
Exposure: Auto
APP: Yoosee
Support USB2.0/3.0
Removable magnetic base
Support turning in 360 degree
Support two-way audio, built-in Mic and
Speaker
Image Sensor: SC1145 1/4” CMOS
Lens: 90 degree 3.6mm fixed focus lens
With 10 infrared night LED lights
LED distance: up to 30 meters
Photo resolution: 2592 x 1994 in JPEG max
Using the provided Micro-USB and UL listed
AC wall adapter, plug the camera into the wall.
Download the app (instructions listed under
Mobile Phone Software Operation).
Insert an SD card (optional).
iOS user can download and install Yoosee in
Apple iTunes store.
Android users can download the app from the
Google Play Store.
To download the software to a computer,
use http://yoosee.co/. Android version and
iOS version can be scanned by the QR code
located on the website listed above.
Once the app is downloaded you are ready to
connect the Camera to the app.
Follow the instructions provided in the app to
register the device.
Once the device is registered, you can connect
the device to the app. In the app, click “Add
new Device.”
Select that your connection is either: Wifi or
Wired. If “Wifi” then enter you’ll be prompted
to input the network password. When the wifi
connection is confirmed, the camera should
begin to make a “ting” sound. If a tone does
not sound, please push in the reset button
Download the app to a computer
Input http://yoosee.co/ in the PC explorer,
click the icon to download directly.
Log account in computer
Remote Login: use the ID (email/phone
number/Yoosee account ID) that was
registered through the mobile app to login
directly, no need to register again.
Adding the HD WiFi camera to a computer
In the left side of the “CMS” software
interface, click the “+” button, and input the
devices name and ID and password.
Device monitor in PC.
Open CMS software, right click device
name>start monitor, and follow the provided
instructions.
The video setting in PC.
Video: this device can store videos on the
computer’s hard drive, right click on the
monitor screen, select “start video” (note:
under certain circumstances the video can not
be stored on the computer’s hard disk).
Playback: this device can playback the video
from computer. Open the CMS software, click
on the replay button, choose “playback.” The
playback files will be listed according to the
date, then play it directly.
(Note: the videos on the computer hard drive
only can be played through the computer,
but does not support playing through the
mobile app)
WARNING–When using this product, basic
precautions should always be followed,
including the following:
Read all the instructions before using the
product.
Do not expose the device to moisture.
Use of a power supply not recommended or
sold by device manufacturer may result in a
risk of fire or injury.
Do not use the device if damaged or modified.
Damaged or modified batteries may exhibit
unpredictable behavior resulting in fire or
risk of injury.
Do not disassemble the device. Take it to a
qualified service person when service or repair
is required. Incorrect reassembly may result in
a risk of fire or injury.
Do not expose a device to fire or excessive
temperature. Exposure to fire or temperatures
above 212ºF may cause explosion.
Unplug the device when not in use.
Reset will erase all user settings, including
WIFI information, access password, alarm
information, and arming zones information.
The steps: Find the reset hole at the bottom of
the device, and then use needle, or small like-
object, to insert and press it more than three
seconds after which a tone will sound letting
you know you have correctly reset the camera.
Andriod
iOS
1.
2.
3.
1.
2.
3.
4.
5.
6
7.
8.
9.
10.
11.
12.
1.
-
2.
-
3.
-
4.
5.
-
-
*
•
1.
2.
3.
4.
5.
6.
7.
8.
•
1.
1.
2.
3.
4.
5.
6.
7.
8.
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Monitor Mic
LDR
Infrared Night Vision
CCTV MP lens
Bearing
Bracket
Intercom Horn
Reset Button
What’s included:
Tech Specifications
Beginning instructions:
Connecting to a Mobile Device:
Computer software operations:
SAFETY PRECAUTIONS:
Restore to factory default settings:
QR Codes
MADE IN CHINA
13
4
6
5
78
2
until the tone sounds.
When the app is connected through wifi to
the camera, input the password located on
the back of the camera. It is advised to change
your password after the initial pairing.
When the above is complete, in the app,
select the camera listed under the “Device
List” of the app.
From the “Camera Settings” you can turn on
the motion detection and set alarms.
To control the Camera, you must work from
within the app. This is where you can take
photos/videos, share photos/videos, and
delete files.
Video: this device supports 32GB TF card
(max). When recording a video, insert the
memory card first, and then open the Yoosee
app: Select, Device > (devices name) >
Settings > Video Settings, user can choose
record video manually, alarm video, or
timing video.
Playback: this device supports mobile phone
playback. Open the Yoosee append select
Device > (device name) > Playback. Playback
files will be listed according to the date, then
you can play it directly.
Operator must use discretion and respect
others privacy and local taboos while
operating this camera.
Privacy laws vary by jurisdiction. The
owner of this camera is solely responsible
for knowing, and following applicable local
ordinances.
The unique device password should be
changed during device set-up. Failure to
change the password can allow others to
access your camera, images, and audio
without your knowledge.
Audio recordings without consent of one, or
all parties, is often illegal.
There are federal and state laws prohibiting
surreptitious recording and monitoring of
audio conversations.
In many cases video recordings are legal with
or without consent.
Be aware that there are laws in some areas
dealing with expectations of privacy. These
include areas such as bathrooms, locker
rooms, changing/dressing rooms, adult
bedrooms, and other areas where a person
should expect a high level of personal privacy.
•
•
•
•
•
•
•
Important Notice:
Privacy
Security
Audio Recording
Video Recording
