Kaiser Baas X2 User manual

1
x2
Complete User Guide
X2 Action Camera

Join the social movement and follow us on
Disclaimers & Warnings
Product Diagram
Setup your X2
Capture Videos & Photos
Menu Settings
Eect Settings
General Settings
WIFI Guide
Battery Guide
Maintenance
FAQ
Specications
Support
04
05
08
10
10
15
10
19
20
21
21
23
25
Contents
DISCOVER: ADVENTURE
Share your footage with us on social media
#KBdiscover
To view the entire Kaiser Baas
product range visit:
www.kaiserbaas.com

3 4
Disclaimers & Warnings
• DO NOT use the camera in water without
the waterproof case.
• Always check the waterproof case seal is
clean and free of debris prior to use in water.
• Always check the charge port cap on the
waterproof case is tightened fully prior to
use in water.
• IMPORTANT! - The waterproof case
charge port and USB cable are only splash/
water resistant. DO NOT submerge them
underwater. Failure to observe may result
in damage to the camera.
• Always ensure the USB connection is
covered during wet conditions.
• DO NOT attempt to open the camera or
modify it in any way. If the camera has
been opened the warranty will be void.
Maintenance and repairs should only be
performed by Kaiser Baas.
• DO NOT handle or charge the camera
without its waterproof case using wet hands.
Failure to observe this may result in damage
to camera and persons.
• ONLY recharge the camera battery using
the supplied USB cable.
• If using a wall charger, ensure that it is a
certied product for your region. AC Input:
100-240VAC 50/60Hz. DC Output: 5V 1A.
Only use a USB wall charger with suitable
approval and certication. Do not charge in
conditions outside of the 10°C - 45°C range.
If you do not know the voltage and current
of your charger, use the included cable to
charge from your computer.
• The camera should not be used in heat
exceeding 55°C (131°F).
• DO NOT drop, crush, pierce, bend, deform,
microwave, incinerate or shoot the camera.
Before operating
please ensure
you have read
and understood
the safety
precautions

5 6
LCD Screen
MicroSD Card Slot
Micro HDMI Slot
Micro USB Port
G
L
K
H
MI
J
Product Diagram (Back)
Recording LED
Battery Slot
Battery Door
Product Diagram (Front)
Power/Menu Button
REC/OK
WiFi
Charging Indicator LED
Operation Indicator LED
Lens
A
A
B
B
D
C
C
F
E
F
ED
G
M
L
K
H
I
J

7 8
Set up your X2 Camera
Welcome to your new KB Action Camera.
Before you get shooting, please review
the User Guide carefully to ensure you
get the maximum performance out of
your camera.
Battery Charging
We recommend that you fully charge
your camera before use.
A full charge is approximately 2.5 hours
using a 5V 0.5/1A Charger.
The charging indicator LED light on the
top of the camera will be RED when
charging and will be OFF when charged.
For further important information about
the battery, see the Battery Guide.
Product Diagram (Case)
Case Latch
Power/Menu Button
REC/OK
Wi-Fi
Waterproof Case Lens
A
B
D
C
E
MicroSD Card Compatibility
Your camera requires a MicroSD Card
(not included).
Kaiser Baas recommends the use of a
brand name Class 10 or higher MicroSD
Card. Any content recording higher than
1080P@60FPS will require a Class UHS-1
or higher card.
There is only one correct way to insert
the MicroSD card. Do not force the card
into the slot as it may damage the camera
and card.
The maximum card size is 32gb.
You can nd the list of recommended
MicroSD cards for this camera at:
www.kaiserbaas.com/support
B
C
D
E
A

9 10
Format Card
Before you start recording for the rst
time, we recommend you format the
MicroSD card.
The format option is found in the General
Settings Menu.
For information on how to navigate the
menu please see the Navigation Guide.
Firmware Update
Please check the kaiserbaas.com/
support page for the latest rmware on
your camera. The current rmware can
be found in the general settings page.
Power On/O
To power ON your camera
1. Insert the battery into the camera.
2. Hold the power/menu button for 3
seconds until you see the Kaiser
Baas logo appear.
Navigation
Navigate the menus and camera modes
using the 3 buttons on your camera. To
toggle between Video, Photo, Playback
and Settings, click the power button
consecutively until your desired mode
appears.
To conrm the selection, click the Record/
Mode button. The menu can also be
accessed by holding the Record/Mode.
To go back, hold the Record/Mode button
for 2 seconds.
The Power/Menu button will scroll through
the menu items on the screen.
Capture Videos & Photos Menu Settings
Modes
The X2 features 2 key modes; Video
Mode and Photo Mode.
Both modes have dierent settings for
you to choose.
The following guides will help you
understand the modes and each setting.
Video Mode
The camera default mode is Video Mode.
Click the Record button to start recording.
When recording, the blue video LED
on the top of the camera ashes
continuously.
Photo Mode
When you are in Video Mode, click Power/
Mode Menu twice to toggle to Photo
Mode. Click the Record/Menu button
to take a photo.
Video Setup
To access the Video Settings menu, press
and hold the Record button for 2 seconds,
and short press again to conrm or click
with the Power Button consecutively until
you reach the Settings Mode. Use the
Power/Menu button to scroll through.
MODE
Set the mode in which to record.
Manual
This is the standard video recording
mode. The camera will record
continuously until the record button
is pressed.
Looping (loop recording)
This allows you to record continuously
using footage intervals of 3/5/10 minutes.
The camera will delete the oldest loop
recording le and replace with the latest
recording when the Micro SD is full.
Note: Formatting the card will
permanently erase all data on the
card. Be sure to backup any content
prior to formatting.

11 12
Auto Stop
This allows you to stop the video
recording automatically after your desired
time of 1 Min/5 Min/10 Min/30 Min.
Time lapse
Time-lapse is a creative technique that
records footage at a very low frame
rate. Playing it back at a higher frame
rate shows a rapid change over time.
This technique is most eective when
recording scenes or objects which have
a slow state of change, e.g. a sunset or
a ower blossoming.
Interval-T-Lapse
Time lapse can be set to the following
intervals 1/3/5/10/30/60 seconds.
The following chart is useful for
determining the amount of time required
that results in 1minute of footage.
Resolution
Your action camera can be set to support
an array of resolutions and frame rates.
Normally, the higher the resolution, the
greater the detail and clarity of footage.
Higher frames-per-second (FPS) capture
more motion and appear smoother on
playback.
FOV
Field of view is how much of the
observable scene the camera can capture.
There are 3 dierent FOV settings.
Time Lapse Specications
Interval Recording Time
130 mins
31 hour
52.5 hours
10 5 hours
30 15 hours
60 30 hours
Tip: The camera may be plugged into a
power bank/power source to extend the
battery life and allow you to shoot for
extended periods of time. This is very
useful for recording long time lapses.
Super Wide
In this view, the image captures more
height and length. SuperView is best if
you need a very wide eld of view like if
you’re skydiving or gliding.
Wide
Wide FOV is great for getting smooth and
immersive shots. This mode is perfect for
getting those high intensity, adrenaline
pumping, action shots and the sheye
eect enhances the overall image. With
this view, there is a lot more distortion
around the edges. This FOV isn’t best
for everyday use.
Medium
In medium mode, the camera will only
capture what is in the very middle of
the sensor.
Resolution FPS Aspect Ratio
1080P
(1920x1080) 60/30 16:9
720P
(1280x720) 120/60/30 16:9

13 14
Video Quality
This setting features 3 options. S.Fine
(Super Fine), Fine and Normal. This setting
changes the Video Bitrate and quality of
the video. The higher the setting (Super
Fine) the larger the video size.
Scene Mode
Scene Modes are pre-programmed
settings suitable for capturing a variety
of dierent environments. Scenes
available: Manual, Water, Riding,
Winter, Diving, Night.
Photo Setup
To enter the Photo Settings Menu, press
and hold the Record/Menu button for
2 seconds, and click the Power/ Menu
button to scroll to the photo setting menu.
Press Record to conrm.
Mode
The Available capture modes are:
Manual, Timelapse Photo, Burst &
Self Timer.
Manual
This mode captures a photo each time
you click the Record button.
Timelapse Photo
Timelapse Photo mode allows you to
shoot a continuous sequence of photos.
This mode is activated by clicking the
Record button and will continue to shoot
automatically until you stop it by pressing
the Record button again.
When in this mode you can shoot with
the following intervals 1/3/5/10/30/60
seconds.
Burst
Burst mode allows you to shoot several
photos per second. In this mode you
can shoot with the following intervals 3
photos/ 5 photos per second each time
you press the record key once.
Self Timer
When this mode is enabled, you can set
a delay interval that starts when you click
the Record button and then takes a single
photo when the delay ends.
FOV
Field of view is how much of the
observable scene the camera can capture.
There are 3 dierent FOV settings:
Super Wide
In this view, the image captures more
height and length. SuperView is best ifyou
need a very wide eld of view like if you’re
skydiving or gliding.
Wide
Wide FOV is great for getting smooth and
immersive shots. This mode is perfect for
getting those high intensity, action shots
and the sheye eect enhances the overall
image. With this view, there is distortion
around the edges.
Medium
In medium mode, the camera will only
capture what is in the middle area of
the sensor.
Scene Modes
You can set dierent scene modes:
Manual, Outdoor, Indoor, Portrait,
Landscape, Night.
Each one has its own interesting
characteristics. You should experiment
with each to acquaint yourself with the
possibilities.

15 16
Eect Settings
To enter the Eect Settings Menu, press
and hold the Record button for 2 seconds.
Now click the Power button to scroll
through the Eects settings and press
the Record button again to conrm your
chosen setting.
Zoom
Digital Zoom has following magnications
x1, x2, x3, x4.
Filter
You can add a color lter eect to your
footage/photo.
Availble lters include: Black & White,
Sepia, Vivid, Natural, Negative, Warm,
Cool, Red, Green, Blue.
AE Meter
You have control over how the camera
meters (interprets) the light in a scene.
You can choose to measure the light by
Center, Average or Spot. The Default
Mode is Center.
EV
You can control the exposure value – that
is, the amount of light the camera records.
Interval range is: -2.0/-1.0/+0.0/+1.0/+2.0
White Balance
Manually control the White Balance
setting.
Interval range is: Auto, 3000K, 5500K,
6500K.
ISO
You can control the ISO (sensitivity) level
that the camera captures footage at.
The default option is Auto.
Interval options:
Auto/100/200/400/800/1600.
Upside Down
When checked, this setting will allow you
to invert the footage captured - Useful
for when the camera is positioned upside
down.
Time Stamp
This setting will embed the Time on the
corner of your photos and videos.
The default value is OFF.
Note: The higher the ISO number the
more noise/grain will appear in your
footage.
Photo Settings
MP Resolution Aspect Ratio
8M 3264x2448 4:3
5M 2592x1944 4:3
3M 2048x1536 4:3
2M 1600x1200 4:3
Picture Quality
With this setting you select the quality of
the images.
S.Fine is the highest quality and therefore
the largest le size. As you move down
the options your le sizes will be smaller
and the quality will be lower.

17 18
To enter the General Settings Menu, press
and hold the Record button for 2 seconds.
Now click the Power button to scroll
through the General Settings menu and
Press the Record Button again to conrm
your selection.
Control
This allows you to change the volume
of the Mic.
Beep
This turns the beep sound on or o.
LED Indicator
Select this if you would like to disable
the LED lights.
WiFi
Switch ON/OFF the camera WiFi.
General Settings
Wi-Fi info
This shows you the Wi-Fi SSID and Wi-Fi
password.
Quick Rec
When enabled, this mode will
automatically begin recording the moment
the camera is turned on (no need to press
the Record button).
Auto LCD O
This setting lets you conserve power while
shooting. It will switch o the LCD screen
after 30 sec/1 min/5 min.
Auto Power O
This will power o the camera after a
period of inactivity.
Available intervals are: 5/10/30 Minutes.
Time Setup
Set the Date and Time.
Use the Power button to go through each
eld and use the Record button to make
the setting. Select ‘Done’ once you set the
Date & Time.
Language
This is to select your desired language
Format Card
This option will format the MicroSD card.
We recommend you do this prior to using
any MicroSD that has been used in other
devices.
Factory Reset
This resets all settings to the factory
defaults.
Software Info
This displays the current Firmware
Version.
