Kalerm KLM1604 User manual
Fully Automatic Coffee Machine
OPERATION MANUAL
Instructions of coffee machine parts
Bean container cover
Water tank lid
Water tank
Coffee grounds container
Drip tray
Drip tray grid
Powder container cover
Grinding wheel
Bean container
Milk frother
Milk and cream spout
Coffee spout
Power cord
1
2
3
4
5
6
7
8
9
10
11
12
13
1
2
3
4
5
6
7
8
9
10
12
11
13
Coffee machine operation interface instructions
Power switch
Cappuccino button
Coffee Latte button
Coffee button
Screen
Setting
Coffee strength button
Double cup
1
2
3
4
5
6
7
8
01
Safety Instructions
Precautions
Please see specification label on the bottom of coffee machine or specification
parameters indicated in instruction manual(P19).
Please do not contact with heat parts of coffee machine to avoid scalding.
To avoid operator’s injury caused by burn, electric shock or other unexpect-
ed reasons, please do not contact the power cord, plug, and main body
with water.
Unplug from outlet when stop using and before cleaning. Allow to cool
before disassembling and cleaning the coffee machine.
Use of parts that are not explicitly recommended would result in a fire of
coffee machine, electric shock, or injury to persons.
Please do not use the machine outdoor.
Please do not hang up the power cord to the edges of the table, for it might
be abased to an electric leakage, and cause injury to operators.
Please place the machine in a fixed and stable workbench, and keep far
away from high temperature (e.g. gas stoves, electric cookers, induction
cookers, etc).
Power off the machine, until the cleaning program finished and no
indication on screen, and then unplug the power.
When using Espresso, Americano and Hot water, liquid in high temperature
will flow from coffee spout and hot water spout. Please do not touch it to
avoid scalding.
This appliance can be used by children aged from
8 years and above if they have been given
supervision or instruction concerning use of the
appliance in a safe way and if they understand the
hazards involved. Cleaning and user maintenance
shall not be made by children unless they are
older than 8 and supervised. Keep the appliance
and its cord out of reach of children aged less than
8 years. Children shall not play with the appliance.
Appliances can be used by persons with reduced
physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given
supervision or instruction concerning use of the
appliance in a safe way and understand the
hazards involved.
If the supply cord is damaged, it must be replaced
by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
02
Warnings
Prohibitions
Never disassemble and repair the machine without authorization. If there is
any errors, please sent it to authorized service center for repairing.
Except cleaning and daily maintenance for coffee machine, if it failures,
please send it to authorized after-sale service center for repairing, or contact
with customer service for after-sale services.
Never immerse the machine into water, and do not put the machine near
the water tap or water tank.
Never disassemble coffee machine without authorization, for any maintenance,
please return it to Service Centre or contact after-sales service center.
Never use an unmatched voltage to the electric specification of the
machine; otherwise, the machine would be burnt.
Only purified water in room temperature is allowed to be filled into the water
tank. Never put warm water, hot water, milk or other liquid into it.
Never carry or move the coffee machine while working. For moving or
carrying the coffee machine, please switch it off and unplug the power
cord first.
The machine may release heat. Therefore, when placing the machine in the
workbench, at least 3cm must be left against its surface, sides and wall side;
at least 15cm must be left against its top. Prohibit placing the machine into
a narrow space. As for dimension of the machine, please look up the
Technical Data of User Manual (Page 21).
Safety Instructions
Never use non-family usage detergent to wipe the machine, otherwise it
may cause corrosion of coffee machine, and result in a risk of electric shock.
Never use wet rag to wipe coffee machine, may result in a risk of electric
shock.
Never use hard edged tool or rough rag to clean the stain on the machine,
it will damage the machine. To wipe the coffee machine with a rag
provided is recommended.
Never put instant coffee powder or cocoa powder and other mixture into
the bean container or powder container. It would cause coffee machine
damaged.
Never fill specially treated coffee bean (e.g. cocoa, sugar coated) into the
bean container, it would cause coffee machine damaged.
Only roasted coffee bean is allowed to put into the bean container. Rice,
soybean, chocolate bean, nut, sugar, spice etc are prohibited. Otherwise it
would cause coffee machine damaged.
Never wash bean container or powder container with water, it will damage
the machine.
Never use coffee machine in the environment temperature below 0 °C.
Water inside the machine will freeze and cause the coffee machine
damaged.
Never expose the machine in rainy, snowy, frosty environment. It would
cause coffee machine damaged.
If the coffee machine is damaged because of the situation that has
been warned above, it is not covered in the warranty!
03
Proper operation
Safety Tips
To guarantee the coffee taste, make sure that temperature of the water filled
into the water tank is at 25ąor so.
Coffee machine can only be used for preparing coffee and hot water. Do not
use it for any other intended use. We will not in charge of any responsibility for
the consequences of improper use. Please carefully read all the contents of
this manual, so that you can know the coffee machine sufficiently.
Please keep this manual properly for looking up at any time.
Please notice the following tips to avoid personal injury from electric shock.
Do not operate the coffee machine if the appliance or the power cord is
damaged.
When encountering breakdowns of the machine (if any burning smell or
smoke), unplug the power cord immediately and contact with service
center.
If the power cord coffee machine is damaged, please contact with service
center.
Place the coffee machine and the power cord far away from heat sources.
Please don't contact power cord with sharp tools.
Do not repair the coffee machine without authorization or operate it in the
way that was not mentioned in this manual, to avoid personal injury.
Place the coffee machine out of the reach of children.
When Coffee machine is unused for long periods, unplug the power cord
and put it away, so that not to trip up people or damage to the power cord.
Please don't use unoriginal parts, otherwise, it may cause the machine
damaged.
Instructions for use
Coffee machine model
Symbol description
Reading this manual will help you familiar with the coffee machine, and use it
properly.
“Instruction for first-time use " introduces the operation process of coffee
machine step-by-step, for first-time use.
“Encounter problem" will provide information when encountering problems.
This Manual is only applicable to the coffee machine of QUARZA series and
the model KLM1604.
Non-compliance with the operation, may cause electric shock,
and threat to life.
Non-compliance with the operation may cause Coffee machine
damaged, or personal injury.
Non-compliance with the operation, may cause scalded or burn
injury.
This symbol, if prompted, please carefully read it.
This symbol, if prompted, represents recycle.
04
05
03
03
05
05
05
06
06
17
18
19
19
05
01
03
03
10
10
10
11
11
11
11
11
11
11
11
10
12
12
13
15
15
16
12
16
16
08
09
09
07
07
08
Catalogue
Safety Instructions
Proper usage
Instructions for use
Coffee machine model
Symbol description
Instructions for first time use
Power connection
Fill water tank
Fill beans
Grinding wheel
Power on
Power off
Making beverages
Making coffee
Single time setting of coffee parameters
Making coffee with coffee powder
Making double cups of coffee
How to use milk frother
Program setting
Maintenance setting
Beverage setting
Setting beverage parameters and scopes
Temperature setting
Prebrew setting
water filter
Automatic power off
Reset
Information
Language
Exit
Cleaning and maintenance
Rinsing the coffee machine
Cleaning brewing unit
Descaling the coffee machine
Rinse milk unit
Cleaning coffee grounds container and drip tray
Cleaning water tank
Cleaning bean container
Cleaning coffee machine
Transport and recycle
Display information
Failures handling
Technical data
05
Instructions for first-time use
This chapter will help you to know the basic operations and settings for your
first time use
Power conection
Place the coffee machine on a stable workbench that is not
close to water.
Keep the coffee machine far away from high temperature
heat source.
Be sure to use power supply that is in accord with regulation.
Put the power cable at a suitable place to avoid people
tripping over.
Fill water tank
Only purified water at room temperature is allowed to fill in
the water tank, never fill any other liquid (e.g. warm water,
hot water, milk). It will damage coffee machine. In order to
ensure the taste of coffee, it is recommended to use water at
25ąor so. Low temperature water will not make a good
taste.
To ensure healthy and the taste of coffee, please change
the water in the tank every day.
The amount of water in the water tank cannot exceed the
height of the MAX mark.
Fill beans
Never put the coffee beans that have been specially
treated (e.g. sugar, cocoa) into the bean container.
Only roasted coffee beans can be put into the bean container,
never put others like rice, soybeans, chocolate beans, nuts,
sugar, and spices.
Never put hard objects into the bean container, otherwise it
will damage the grinder.
The bean container cover playing a role as seal. It keeps the
aroma of coffee bean maximally. Please do not lose the
cover.
Don't fill the liquid in the bean container.
Finest
Fine
Medium
Rough
Roughest
Grinding wheel
Please adjust the fineness of coffee bean powder according
to the coffee beans.
Please adjust the grinding wheel when the grinder is running,
or the grinder will be damaged.
If your coffee beans are in dark color, it is recommended to
set to rough mode.
If your coffee beans are in light color, it is recommended to
set to the fine mode.
During making coffee, if the coffee outflows very slow or
completely does not outflow, please set it to the rough
mode.
If the coffee outflows very quickly and the color of crema on
the top is very light, please set it to the fine mode.
The adjustment of grinding wheel will be effective only after
making two or more cups of coffee.
Welcome
06
Power on
As the machine has been tested at factory, there may be a
little coffee powder left over. We promise the machine is
brand new.
The coffee machine will start self-testing and cleaning at the
first-time use, this helps the coffee machine to achieve the
best working condition, and this process cannot be skiped.
Every time powering on the coffee machine, it will automatically
complete heating and cleaning for one time, and the
process cannot be stopped. The coffee machine can only
be used after finished the above cycle process.
During the cleaning process, some hot water may flow out of
the coffee spout into the drip tray. Please avoid contacting
the spilling hot water.
Please ensure the power is connected before pressing
power button.
First-time use
Power off
Every time when powering off the coffee machine, it will
automatically complete cleaning process for one time, and
the process cannot be stopped. This operation is to clean up
the coffee pipelines and remove the coffee grounds.
During the cleaning process, some hot water will flow out of
the coffee spout into the drip tray. Avoid touching spilt hot
water, so as not to be burned.
When you press power button, the machine will be
power off after auto cleaning.
VOLUME 30ML
VOLUME 50ML
COFFEE
STRENGTH
READY
07
Making beverages
This chapter instructs you making various kinds of coffee, hot water,
hot milk and milk foam by this coffee machine. Please read the following
instructions carefully to help you make high-quality beverages.
The temperature of the hot water is high, please do not touch it to
avoid being scalded.
Before we make all kinds of coffee, please ensure “READY” is indicated
on the display.
Never use dark roasted coffee beans.
The coffee beans should be put at dry place and avoid sunlight.
Only purified water at normal temperature can be used. To make
the coffee taste better, it is recommended to use water around
25ą.
To ensure the quality of coffee, please change the water in water
tank every day.
Please warm the coffee cup before making coffee for better
taste.
Please adjust the height of the coffee spout according to the
height of the cup in order to avoid coffee splashing.
Adjustable height of coffee spout: 80-115mm.
Making coffee
When the screen shows “READY”, press
espresso button for espresso function.
The grinder will begin to grind. At this time,
you can adjust the amount of coffee beans
by pressing the left and right button.
Default amount of coffee beans for
espresso:
During making coffee, you can adjust the
volume of coffee by pressing the left and
right button.
After grinding , the amount of coffee beans
can not be adjusted by pressing the left
and right button.
During making coffee, you can cancel
making coffee by pressing coffee button.
When the screen shows as the left picture, it
means the coffee is ready, please enjoy it.
You can make any kinds of coffee by touch icons, when the screen shows
“READY”
Take coffee for example to explain how to make coffee.
The volume of coffee is suggested between 50 to 100ml.
Please warm the coffee cup before making coffee. When making coffee,
press coffee button twice to cancel.
COFFEE
VOLUME 50ML
COFFEE
ENJOY!
08
Single time setting of coffee parameters
When the screen shows “READY”, press the
coffee strength button to set three levels:
the setting is only for
making next cup of coffee, and it will not be
saved.
Detail instructions
5 items as bellow can be set at single time.
You can set the fineness of coffee and the volume of beverage before or
during making the beverage at single time, the setting will not be saved.
Set the amount of coffee beans when the screen shows “READY”
Set the amout of coffee beans during grinding process
Set the the volume of coffee when making coffee
Cream making time can be set when making cappuccino
Cream making time can be set when making coffee latte
Steam making time can be set
When making “Cappuccino”, press left and
right button to adjust the making time of
cream. Press right button to increase, left
button to reduce.
When making “Coffee Latte”, press left and
right button to adjust the making time of
cream. Press right button to increase, left
button to reduce.
When making “Steam”, press left and right
button to adjust the making time of steam.
Press right button to increase, left button to
reduce.
When making “Coffee”, press left and right
button to adjust the amout of coffee beans,
press right button to increase, left button to
reduce.
When grinding coffee beans, press left or right
button to adjust coffee strength. The default
setting is normal ,press left button to
choose mild , and press right button to
choose strong .
Making beverages
STRENGTH
STRENGTH
VOLUME 30ML
COFFEE 40ML
Making coffee with coffee powder
You can choose this function if you want to make coffee with
coffee powder.
Prohibit filling other mixtures such as instant coffee powder
or cocoa powder in the powder container. Otherwise it will
damage the machine.
Do not fill the coffee powder into the coffee bean container,
otherwise, it will damage the machine.
Do not rinse the powder container with water, or it will result
in operator’s injury by electric shock.
Please use proper grounded coffee powder for espresso.
Only 7-14g coffee powder can be added. Machine will be
damaged with more powder.
The process of using coffee powder to make coffee only skips
the process of grinding coffee beans, other operations are
the same as making espresso, Americano, and coffee. This
chapter illustrates with espresso.
VOLUME 30ML
CREAM 60S
VOLUME 30ML
CREAM 60S
VOLUME 30ML
STEAM 40S
09
Making beverages
READY
When the screen shows ”READY”, press
setting button to enter into setting.
READY
When the screen shows ”READY”, Press
double cup button to enter into process.
Choose coffee beverage, there is espresso
and coffee for choosing.
The grinding amounts shows. The default
setting is (strong)
press left and right button to choose the
fuction you need.
When the screen shows “USE POWDER”,
press setting button to enter into coffee
powder making coffee fuction.
Add coffee powder, choose your need
coffee icon enter into coffee making. There
is espresso, americano, coffee for choose.
CLEAN
USE POWDER
FILL POWDER
SELECT BEVERAGE
Making double cups of coffee
You can make double cups of coffee with this machine.
Double cups of coffee includes double espresso and double coffee.
The process of making double cups of coffee is the same as process of
making espresso and normal coffee, the only difference is need to choose
beverage for making double cups of coffee.
SELECT BEVERAGE
STRENGTH
READY
When the screen shows ”READY”, rotate the
milk frother knob,select milk foam or hot
milk, then press “Steam” button to make
beverage.
If the temperature is not ready to make
steam, boiler starts to work. Press “Steam”
button can stop heating process.
Press “Steam” button to make beverage
During making process, you can adjust the
volume of steam by pressing the left and
right button. You can cancel the process
by pressing “Steam” button.
When screen shows”Ready”, you can
return to make coffee.
How to use milk frother
You can use milk frother to make milk foam and hot milk.
The hot steam may spray from milk frother spout, take care of burns.
READY
VOLUME 30ML
STEAM 40S
HEATING
STEAM READY
Steam Hot water
10
Program setting
This chapter will give instructions on program setting.
Ensure the coffee machine shows “READY”, press the setting
button, than press left and right button to select “MENU”,
than you can set the menu.
Maintenance setting
Please read the detailed instructions about rinsing the brewing unit and
decalcifying on P12 and P13.
Beverage setting
This chapter will instruct you how to set beverages. The setting parameters
include coffee taste strength, amount of coffee, amount of hot water and
steam time.
The parameters accomplished by beverage setting will be the default
values for each beverage.
1. Cappuccino setting
2. Coffee Latte setting
3. Coffee setting
4. Steam setting
Setting up beverage parameters and range
Drinks
Coffee volume: 25 - 240ML
Coffee volume: 25 - 240ML
Steam time: 3 - 120S
Cream time: 3 - 120S
Coffee volume: 25 - 240ML
Cream time: 3 - 120S
Strength Volume
The parameters as strength and volume can be set for the beverages
bellow.
Please read the following table for the detail setting parameters and
adjustment range
The strength, volume and cream making time of Cappuccino can be set
The strength, volume and cream making time of Coffee Latte can be set
The strength and volume of Coffee can be set
Steam making time can be set
Temperature setting
You can set the temperature of coffee baverage.
Enter program setting menu, choose “TEMPERATURE”, press left or right
button to choose your coffee temperature. Press setting button to confirm,
setting is completed. There is high temperature and normal temperature for
choosing.
Prewbrew setting
Prebrew can be set when making coffee.
Enter into setting, choose “PRE-BREW”, press left or right button to choose if
need prebrew precooking, press setting button to confirm, setting is
completed.
coffee
coffee latte
cappuccino
steam
Mild:
Normal:
Strong:
SETTING
11
Automatic switch-off
The machine’s default switch off time is 2 hours, which means
the machine will automatically switch off after power on 2
hour.
The setting range of automatic switch-off is from 5 minutes to
4 hours.
After entering the program setting, choose “AUTO-OFF”, press
left and right button to adjust auto off time, then press the
setting button, setting is completed.
Reset
This function will reset all the menu setting and default beverage
parameters to the factory settings (except the language
options). In addition, the information options will not be reset.
After entering the program setting, choose “RESET” option
and press the left and right button choose ”RESET”, then press
setting button to confirm, the setting is completed.
Information
In this program you can view verson information, numbers of
produced each drinks and maintainance times.
1. Total numbers on produced drinks
2. Numbers of produced cappuccino
3. Numbers of produced coffee latte
4. Numbers of produced coffee
5. Numbers of produced steam
6. Numbers of produced coffee by coffee powder
7. Numbers of rinsing operations
8. Numbers of decalcifying operations
9. Numbers of rinsing brewing unit operations
10. Numbers of rinsing milk unit
11. Numbers of installing and replacing the water filter
At the first-time use, there is already a number of produced
beverages because each coffee machine has been tested
before leaving factory.
Language
You can set your requested language on the coffee machine.
After entering the program setting "CHOOSE LANGUAGE", then press the
left and right button to choose the language, and press the setting button
to confirm, setting is completed.
EXIT
After entering the program setting, choose “EXIT”. Then press the setting
button to exit. After completing setting, the machine will return to
“READY” .
Program setting
12
Cleaning and maintenance
This chapter will instruct you how to clean and maintain the
coffee machine.
Paying attention to daily maintenance of coffee machine,
not only ensure the taste of each cup of coffee, but also
extend the life of the coffee machine.
Rinsing the coffee machine
This chapter will introduce you how to clean and maintain
the coffee machine.
Before making coffee, press the cleaning button. It will
pre-heat the brewing unit and inner pipeline, to improve
the taste of the coffee next time.
Cleaning function must be processed in “READY” status.
When the coffee machine is in “READY”
status, press the setting button to enter into
the setting.
When the screen shows “CLEAN”, press
setting button to enter into cleaning
fuction, then start to clean the brewing unit
and coffee spout.
The process of cleaning coffee machine
cannot be interrupted.
It will automatically return to “READY” status
after cleaning.
Cleaning the brewing unit
After a long-term use, there will be some coffee powder left on the
brewing unit. Remove the powder by cleaning brewing unit.
After a period of time use, if the brew unit needs to be cleaned, the
screen will remind you “NEED BREW CLEAN”, this is only for reminding, other
functions can still be performed.
The process of cleaning brewing unit takes about 10 minutes.
After a period of time use, if the brew unit
need to be cleaned, the screen will reming
you “NEED BREW CLEAN”, press setting
button to enter into brew unit clean
process.
Press left and right button to choose
“MENU”, then press setting butoon to enter
into program setting menu.
Press left and right button to choose
“MAINTENANCE”, then press setting butoon
to enter into maintenance setting.
Press left and right button to choose “BREW
CLEAN”, press setting button into the page.
Press left and right button to choose “BREW
CLEAN CONFIRM”, press setting button to
start cleaning brewing unit.
READY
CLEAN
READY
READY
CLEANING
NEED BREW CLEAN
MENU
MAINTENANCE
BREW CLEAN
BREW CLEAN
CONFIRM
13
The drip tray should be cleaned before
cleaning brew unit. Because waste water
will be dripped to the tray.
Install the drip tray.
After istalling the drip tray, screen shows
“PRESS SETTING” to start.
The brew unit is cleaning.
Open the coffee powder container lid and
add the cleaning tablet, close the coffee
powder container lid and press the
cleaning button to clean the brew unit.
Brew unit is cleaning.
Empty the drip tray.
Instal the drip tray.
After cleaning finished, the machine enters
into “READY” status.
Cleaning and maintenance
Descaling the coffee machine
The daily usage will cause calcareous deposited in coffee
machine. The depositing rate vary with the local water
hardness.
Decalcifier contains acidic substances that would stimulate
your eyes and skin, so you must strictly comply with the
security warnings noted by manufacturer on the packaging.
If you have contacted it with your eyes or skin by accident,
please wash it with clean water immediately.
Only the original decalcifier can be used, use of other
decalcifier may cause damage to your coffee machine.
Dissolve the decalcifier in clean water, and then lead the
mixed liquid into the water tank. Fully dissolve the decalcifier
can descale the coffee machine more thoroughly.
The whole descaling process takes about 30 minutes.
The termination during the descaling process will damage
the coffee machine. So once you start the descaling process,
please do not terminate it midway.
After a centain time use, the screen will
display “NEED DESCALE” and “READY”
alternately. Now, press setting button to
enter the descaling program.
Press left and right button to choose
“MENU”, then press setting butoon to enter
into program setting menu.
Press left and right button to choose
“MAINTENANCE”, then press setting butoon
to enter into maintenance page.
READY
NEED DESCALE
MENU
MAINTENANCE
EMPTY TRAY
INSTALL TRAY
PRESS SETTING
CLEANING
CLEANING
ADD TABLET
PRESS SETTING
EMPTY TRAY
INSTALL TRAY
READY
14
Press left and right button to choose
“DESCALE”.
Press setting button to confirm.
It will take around 30 minutes. Press setting
to start descaling.
Prearation for descaling and cleaning. First
of all, emply the drip tray, because it would
drain some waste water into drip tray.
Install tray.
Take a bag of decalcifier and sufficiently
dissolves it in clean water then lead this
mixed liquid to the water tank, and reinstall
the water tank to coffee machine.
To start descaling and cleaning for the first
time, put a container, of which the capacity
is more than 1L, under the coffee spout.
Empty tray.
Install tray.
Empty tray.
Install tray.
After the first stage of descaling and
cleaning, take the water tank out and
clean it. Add purified water again, and
reinstall it to the coffee machine.
Press setting button to enter the second
stage of descaling and cleaning.
To clean the residual decalcifierin in pipes .
Put a container, of which the capacity is
more than 1L, under the coffee spout.
When the screen shows “READY”, it indicates
the descaling is completed; Now, you can
continue to make coffee.
DESCALE
DESCALE
CONFIRM
30 MINS
PRESS SETTING
EMPTY TRAY
INSTALL TRAY
SOLVENT IN TANK
PRESS SETTING
DECALCIFYING
INSTALL TRAY
CLEAN WATER TANK
FILL WATER TANK
EMPTY TRAY
2
3
5
1
4
PRESS SETTING
DECALCIFYING
READY
INSTALL TRAY
EMPTY TRAY
15
Cleaning and maintenance
Cleaning the coffee grounds container and the drip tray
Do not use chemical solvents and erosive cleaner or alcohol
to clean the coffee grounds container and drip tray.
The drip tray and coffee grounds container cannot be cleaned
in dishwasher.
Do not use metal objects to clean dirt or coffee precipitate to
avoid scraping the drip tray and coffee grounds container.
When prompted to clean the coffee grounds, coffee grounds
must be cleaned up, or it will cause the machine damaged.
Rinse milk unit
After a long time use, residual materials may be left in the milk
unit and need to be cleaned.
When it cumulates to 15 cups, it will
automatically indicate “EMPTY GROUNDS”.
1
EMPTY GROUNDS
Rinse milk unit
Please use steam function to clean the inside milk unit before
disussembling the milk unit.
Take care of burns when using steam function, because hot
steam may spray from steam nozzle.
1. Remove the milk unit carefully
2. Clean every part by water
3. Re-assemble the milk unit and install it to the coffee machine
When the screen shows “READY”, press
setting button to enter into setting.
Select “MAINTENANCE” by pressing the left
and right button, then press the button to
enter it.
Select “RINSE MILKUNIT” by pressing the left
and right button, then press the button to
enter it.
Select “CONFIRM” by pressing the left and
right button, then press the button to enter
clean process.
Remove the milk pipe from the milk box/
container and insert to the hole of the drip
tray grid according to the display on
screen. Press setting button.
Milk unit is under cleaning process.
After cleaning process, the machine enters
into “READY” status.
Select “MENU” by pressing the left and right
button, then press the button to enter it.
READY
MENU
MAINTENANCE
RINSE MILKUNIT
READY
REMOVE MILK PIPE
PRESS SETTING
CLEANING
RINSE MILKUNIT
CONFIRM
16
Cleaning and maintenance
Cleaning the water tank
Suggested that, each time adding water, clean the tank
thoroughly with running water first.
Cleaning water tank regularly (about 1 time per month, or
every time when changing the water filter), it would be better
to use wet rag and some mild cleaning fluid.
Because the water tank is made from food-grade and environmental
materials, it might be friable to crack. Please gently pick it up
and put it down, and never let it fall down. If the water tank
damaged, please contact with customer sevice center.
Please remove coffee grounds of the drip
tray and coffee grounds container.
Reinstall the water drip tray to the machine,
it returns to “READY” status.
Reinstall the water drip tray to the machine,
it returns to “READY” status.
If the drip tray is full, the machine will
automatically prompt "EMPTY TRAY". Take
out the water drip tray and pour the waste
water.
Every time when cleaning coffee grounds and waste water in
the drip tray, please clean the drip tray and coffee grounds
container.
After cleaning drip tray, please wipe dry the 2 pieces of
sheetmetals at the end of the drip tray, and then reinstall the
drip tray to the coffee machine.
2
3
INSTALL TRAY
READY
READY
EMPTY TRAY
Cleaning the bean container
Please do not use water to wash the beans container, it would
cause the grinder damaged.
Please use a dry rag or a paper towel to clean the residuary
grease in the bean container.
Because the bean container cover is made from food-grade
and environmental materials, it might be friable to crack.
Please gently pick it up and put it down, and never let it fall
down. If the bean container lid damaged, please contact
with customer sevice center.
Cleaning the coffee machine
Before cleaning the interior of the coffee machine, power it
off, and pull out plug. Never immerse the coffee machine in
water. There will be a risk of electric shock.
Regularly check the coffee machine whether there is excessive
coffee powder precipitate inside the machine. You can use a
brush to remove the coffee precipitate.
Use a dry and soft rag to wipe the touch panel of the machine.
As the touch panel is made of glass, please do not hit it to
avoid the risk of electric shock once the glass broken.
Use a dry and soft rag to wipe the surface of the machine,
and never use hard objects to clean coffee leftover on the
surface, otherwise it would cause the surface damaged.
17
Display information
This chapter will instruct you the information shows on the
screen and the solutions.
Causes Solutions
If the water drip tray is full, any
function of making beverage will
be out of service.
Take the drip tray out, empty the
waste water in the drip tray and
reinstall it to the machine.
If the coffee grounds container is
full, any function of making
beverage will be out of service.
Take the coffee grounds container
out, empty the coffee grounds
container and reinstall it.
If water in the water tank is used
up, any function of making
beverage will be out of service.
Fill the water tank with water.
If coffee beans in the bean
container are used up, function of
making coffee will be out of
service.
Add beans into bean container,
and press any button to release.
There is not enough coffee powder
in the powder container.
Next time when making coffee
with coffee powder, please put a
full spoon of powder.
The drip tray is not installed
correctly; any function is out of
service.
Install the drip tray correctly.
The water in the pipe inside the
machine is not enough; any
function is out of service.
Press any button to release to run
the water self-check system.
Temperature of the machine is too
high, the machine cannot be used.
Power off the main power, and use
it 1 hour later.
Temperature of the machine is too
low, the machine cannot be used.
Increase environmental temperature
to above 10ą.
1. Line clossing; 2. Using dark
roasted coffee beans or over fine
coffee powder; 3. The filter of the
brewer is clogged.
1. Press any button to release to
run the self-check system; 2. Adjust
grinder wheel to rougher; 3. Start
brewer cleaning procedure (refer
to P12).
Internal parts stucked. Press any button to run the self-test
system.
EMPTY TRAY
INSTALL TRAY
FILL BEANS
LACK OF POWDER
PRESSURE HIGH
BREW UNIT STUCK
TEMPERATURE HIGH
TEMPERATURE LOW
FILL WATER TANK
EMPTY GROUNDS
UNIT EMPTY
This manual suits for next models
2
Table of contents
Other Kalerm Coffee Maker manuals
