Kamasa-TOOLS K 9836 User manual

K 9836
Cut-o tool
400 mm

2
This tool is designed for cutting metal, plastic and similar materials
in confined spaces. A 75 or 100 mm cutting disc shall be used.
SAFETY AND PRECAUTION
Read these safety instructions before starting to use the tool and follow the instructions
1 Always use impact resistant eye protection when operating a pneumatic tool.
2 Always be aware that hearing protection is recommended at sound levels above
85 dBA, 2003/10/EG.
3 Vibration, repetitive motions or uncomfortable positions may be harmful to your hands
or arms. Stop using any tool if discomfort, tingling feeling or pain occurs, seek medical
advice before resuming use.
4 Keep unqualified persons, children, etc. away from the tool.
5 Never use oxygen and combustible gas as an air supply for the tool which many be
ignited by sparks and cause fire or explosion.
6 This power tool is not intended for use in potentially explosive atmospheres and is not
insulated against coming into contact with electric power.
7 Never use gasoline or other flammable liquids to clean the tool.
8 Do not expose air tools to rain. Do not use air tools in damp or wet locations.
9 When not in use, keep tools in a dry place, either locked up or in a high place,
out of the reach of children.
10 Only qualified and trained operators should install, adjust or use power tools.
11 Do not modify this power tool. Modifications can reduce the eectiveness of safety
measures and increase the risks to the operator.

3
12 Ensure that the maximum operating speed of the abrasive is equal to or greater that the
rated speed of the spindle.
13 Check the protective guard on a regular basis. The protective guard must be securely
attached to the device and in good condition.
14 Never put the device down before the tool has come to a complete stop. Lay the device
down in a secure location.
15 Do not use the tool if it has been damaged.
16 Failure of a work piece, accessories or even of the power tool itself can generate high-
velocity projectiles.
17 Entanglement hazards can result in choking, scalping and/or lacerations if loose clothing,
bracelets, neckwear, hair or gloves are not kept away from the tool and accessories.
18 Always shut of air supply, drain hose of air pressure and disconnect tool from air supply
when not in use, before changing accessories or when making repairs.
19 Do not exceed the maximum air pressure, see Specifications in this manual
20 Never carry an air tool by the hose.
21 Preferably shut o the air supply before changing disc or at least ensure that the hands
are well clear of the operating trigger.

4
PRODUCT SPECIFICATIONS
Model No. K 9836
Revolutions 14000 rpm
Cutting disc 75 or 100 mm
Air connection ¼” NPT
Sound level 85,5 dBA
Vibration level 3,8 m/s2
Air consumption 113 l/m
Max operating pressure 6,3 bar
Length 400 mm
Weight 1,7 kg
MAJOR COMPONENTS
Spindle lock knob
Protedctive guard adjustment
Trottle lever switch lock
Abrasive disc
Trottle lever
Handle
Air inlet

5
OPERATION INSTRUCTIONS
1 Screw the hose connection on to the compressed air connection.
2 Fit the cutting disc, make sure it lays flat.
3 Position the support flange. It is fitted correctly when it cannot be turned on the spindle.
4 Attach the screw and tighten. Keep the spindle locking knob pressed in to prevent the
spindle from rotating.
MAINTENANCE
1 If the tool is used every day, disassemble and inspection is recommended every 6 months.
2 Keep the casing dry, clean and free from oil. Never use brake fluid, petrol or solvent for
cleaning.
3 Check screws for tight fitting.
4 Air tools require lubrication throughout the life of the tool. Since the compressed air
driving the motor contains water, the tool must be lubricated daily. We also recommend
water separator in the air supplying system.
5 Avoid storing the tool in a location subject to high humidity. If the tool is left as it is used,
the residual moisture inside the tool can cause rust. Before storage, lubricate tool and run
it for a few seconds.
6 If the tool is too seriously damaged to be used anymore, recycle raw material instead of
disposing as waste. The machine, accessories and packaging should be sorted for environ-
mental-friendly recycling. Check with your local authority or retailer for recycling advice.
7 Tools repair and maintenance should be carried out by an authorized service center.

6
PARTS K 9836

7
Spare part No Kit
KR 9836-1 Motor repair kit: Pos 6, 13, 16, 46, 49, 50, 51, 53
KR 9836-2 Gearing repair kit: Pos 22, 23, 58, 61, 62, 63
KR 9836-3 Air inlet kit: Pos 3, 64, 65
KR 9836-4 Disc fastener kit: Pos 26, 32, 34, 67
No Parts name Qt Spare part No
1 Motor housing 1
2 Spring pin 1
3 Air inlet 1 KR 9836-3
4 Trottle lever 1
5 Valve shaft 1
6 O-ring 1 KR 9836-1
7 Connecter 1
8 Spring pin 1
9 Valve spring 1
10 Plug 1
11 Ball bearing 1
12 Bushing 1
13 O-ring 1 KR 9836-1
14 Rear end plate 1
15 Rotor 1
16 Rotor blade 4 KR 9836-1
17 Screw 1
18 Cylinder 1
19 Front end plate 1
20 Connector nut 1
21 Lock nut 1
22 Bevel gear 1 KR 9836-2
23 Bevel gear 1 KR 9836-2
24 Lock bar 1
25 Bushing 1
26 Flange nut 1 KR 9836-4
27 Lock nut 1
28 Front housing 1
29 Connector pipe 1
30 Nut 1
31 Lock nut 1
32 Screw 1 KR 9836-4
33 Stop button 1
34 Disc cover 1 KR 9836-4
No Parts name Qt Spare part No
35 Button seat 1
36 Nut 1
37 Screw 1
38 Roller shaft 1
39 Spring 1
40 Washer 1
41 Washer 1
42 Oil felt 1
43 Spring pin 1
44 Nut 1
45 Decoration ring 1
46 Ball bearing 1 KR 9836-1
47 Spring pin 1
48 Spring 1
49 Ball bearing 1 KR 9836-1
50 O-ring 1 KR 9836-1
51 O-ring 1 KR 9836-1
52 Grip 1
53 O-ring 1 KR 9836-1
54 Clamp nut 1
55 Wave washers 1
56 Retaining ring 1
57 Safety bar 1
58 Retaining ring 1 KR 9836-2
59 Pin 1
60 O-ring 1
61 Ball bearing 2 KR 9836-2
62 Ball bearing 1 KR 9836-2
63 Ball bearing 1 KR 9836-2
64 Diuser 1 KR 9836-3
65 Muer 1 KR 9836-3
66 Hex key wrench 1
67 Flange 1 KR 9836-4
68 Screw 1
PARTS LIST K 9836

www.kamasatools.com
K 9836
Kamasa Tools is a registered trademark of KG Knutsson AB, 191 81 Sollentuna, Sweden
CE declaration for this product is available as a file on www.kamasatools.com
