K&F SP User manual

Self Powered K&F Subwoofers ‘SP’
Benutzer Handbuch
Wichtige Informationen,
vor Inbetriebnahme lesen!
KLING &FREITAG GmbH
Junkersstrasse 14
D-30179 Hannover
TEL [phone]
FAX [phone]
www.kling-freitag.de
User’s Manual
Important Information,
Please Read Before Use!
KLING &FREITAG GmbH
Junkersstrasse 14
D-30179 Hannover
PHONE [phone]
FAX [phone]
www.kling-freitag.de
Version 7.0
Released: 09.09.2014

User’s Manual K&F Self Powered Subwoofer Systems ‘SP’
KLING & FREITAG GMBH ©2003 - 2014 Version 7.0, 09.09.2014 Page 2 of 48

User’s Manual K&F Self Powered Subwoofer Systems ‘SP’
KLING & FREITAG GMBH ©2003 - 2014 Version 7.0, 09.09.2014 Page 3 of 48
Thank you for your decision to buy a Kling & Freitag product. To guarantee a trouble-
free operating of the equipment and to allow the KLING & FREITAG --- 'SP' speaker
system to achieve its full potential please read the operating instructions carefully
before use.
With the purchase of a K&F subwoofer system with integrated power amplifier tech-
nology, you have acquired a speaker system with the highest possible quality and
performance capabilities.
As the owner of this system, you now have a versatile and highly professional tool
which, when operated properly, is a true pleasure to use.
Symbols in User's Manual
Warning
This symbol indicates the possibility of life-threatening danger and a
health risk for persons. Not following these instructions may result in
serious health problems including potentially fatal injuries.
Caution
This symbol indicates a possibly dangerous situation. Not following
these instructions may cause minor injuries or cause property damage.
Important
This symbol gives instructions for the proper use of the described prod-
ucts. Not following these instructions may cause malfunctions or proper-
ty damage.
Information about this User's Manual
User's Manual K&F Self Powered Subwoofer Systems, Version 7.0 09.09.2014
© by André Figula, Kling & Freitag GmbH, July 2003-2014; all rights reserved.
All specifications in this manual are based on information available at the time of pub-
lishing for the features and safety guidelines of the described products.
Technical specifications, measurements, weights and properties are not guaranteed.
The manufacturer reserves the right to make product alterations within legal provisions
as well as changes to improve product quality.
All persons who use the speaker system must have this guide and all further
information for safe operations available to them during assembly, disassem-
bly, and use.
We appreciate any input with suggestions and improvements for this manual. Please
send this to us at the following address:
[e-mail] or to:
KLING & FREITAG GMBH Junkersstr.14 D-30179 Hannover
Phone +49 (0) 511 - 96 99 70 Fax +49 (0) 511 - 67 37 94

User’s Manual K&F Self Powered Subwoofer Systems ‘SP’
KLING & FREITAG GMBH ©2003 - 2014 Version 7.0, 09.09.2014 Page 4 of 48
Contents
Chapter Page
1. General Safety Instructions 6
2. Introduction SP Loudspeakers 8
3. Connectors, Controls und Displays 1
4. Power Cord 13
5. Safety Instructions for Suspending the Speakers 14
5.1 SW 215E - SP and Click & Fly Accessories 14
5.2 SP-Subwoofers with ‘Suspension Thread’ M12 (SWi-Versions) 15
5.3 Subwoofer SP with ‘allsafe JUNGFALK’ Flying Points 16
5.4 SW 215E ‘Suspension’: The ‘allsafe JUNGFALK’ Flying Track 17
6. Mounting Instructions for Speakers 18
6.1 Using the Mounting Accessory ‘Distance Rod’ 18
6.2 LINE 212 Systems on Top of SW 115E-SP 19
6.3 LINE 212 Systems on Top of SW 215E 19
7. Wiring 2
7.1 Avoiding Ground Loops 2
7.1.1 What is a Ground Loop? 2
7.1.2 Avoiding Ground Loops 2
7.2 Connecting the Power Connectors to the Connecting Terminal 21
8. Configurations and Connecting Diagrams 21
8.1 Operating the Systems without K&F System Controller 21
8.1.1 Subwoofer with Tops in Full-Range Mode 21
8.2 Operations with K&F System Controller 22
8.3 Maximum Configuration 22
9. Operating the Speakers 23
1 . Touching Up Damage to Paint / Changing the Front Foam 23
11. Block Diagram of the SP Subwoofer... 24
11.1 ... with one Amplifier Module 24
11.2 ... with two Amplifier-Modules (SW 215E - SP) 25
12. Technical Specifications 26
12.1 SW 112 - SP 26
12.2 SWi 112 - SP 27
12.3 SW 115E - SP 28
12.4 SWi 115E - SP 29
12.5 SW 118E - SP 3
12.6 SWi 118E - SP 31
12.7 SW 215E - SP 32

User’s Manual K&F Self Powered Subwoofer Systems ‘SP’
KLING & FREITAG GMBH ©2003 - 2014 Version 7.0, 09.09.2014 Page 5 of 48
Chapter Page
13. Frequency Diagrams 33
13.1 SW 112-SP / SWi 112-SP 33
13.2 SW 115E-SP / SWi 115E-SP 33
13.3 SW 118E-SP / SWi 118E-SP 33
13.4 SW 215E - SP 34
14. Dimensions 35
14.1 SW 112-SP 35
14.2 SW 112-SP ‘Suspension’ 36
14.3 SWi 112-SP 37
14.4 SW 115E-SP 38
14.5 SWi 115E-SP 39
14.6 SW 118E-SP 4
14.7 SWi 118E-SP 41
14.8 SW 215E - SP 42
15. Regulations for Disposal 43
15.1 Germany 43
15.2 EU, Norway, Iceland, and Liechtenstein 43
15.3 Other Countries 43
16. Declaration of Conformity and International Certificates 44
16.1 Declaration of Conformity 44
16.2 EMV Certificate Directive 89 / 336 / EWG 45
16.3 TÜV Certificate for the USA and Canada (UL 65 ) 47
17. Included Safety and Mounting Instructions for Loudspeakers and Accessories.

User’s Manual K&F Self Powered Subwoofer Systems ‘SP’
KLING & FREITAG GMBH ©2003 - 2014 Version 7.0, 09.09.2014 Page 6 of 48
1. General Safety Instructions
Warning: To avoid electric shock hazard, do not expose this
appliance to rain or moisture. The enclosures may only be
opened by qualified personnel!
Do not install devices in any of the following places:
−where the devices are permanently exposed to direct sunlight.
−near any heat sources and open fire. do not put candles etc. on top of the speaker.
−where the airflow for cooling is blocked. a minimum distance of 10 cm to the heat
sink on the rear of the speaker must be kept.
−where the devices are exposed to high moisture. Objects filled with liquids, such as
a vase, must not be placed on the speaker.
−where the devices are exposed to strong vibrations and dust.
Power Supply
Before connecting the AC power cable of the SP speaker, please check if the available
voltage is compatible with the operating voltage as indicated on the unit. If this is not
the case, then the unit needs to be adapted by the manufacturer or an authorized ser-
vice centre. If the unit is not compatible with the available voltage, it should never be
connected! This could irreparably ruin the SP speaker.
Make sure that the power outlet supplies a ground connector, which must be connect-
ed to the unit via the PE conductor of the power cord!
All equipment, which is connected together using signal cables and has a connection to
protect ground, must be connected to a common protective earth. If not, there is a risk
of an electric shock or the destruction of the connected equipment.
The power plug must always be used to disconnect from the power supply. Further-
more, the power plug must be easily accessible for use at all times.
Protection of Electrical Cables
Power cords should be laid in such a way that they are protected against footstep dam-
ages, tensile strain and against being trapped.
Transportation
When transporting the equipment, make sure that it is protected from vibrations.
Cleaning
The equipment should only be cleaned with a damp cloth when it is not plugged in.
Pauses in Use
The power cord should be disconnected from the power source during longer pauses in
use.
Intrusion of Objects or Liquids
No objects or liquids should intrude or leak into the equipment.
Warning
Risk of electric shock!
Do not open the units!
CAUTION

User’s Manual K&F Self Powered Subwoofer Systems ‘SP’
KLING & FREITAG GMBH ©2003 - 2014 Version 7.0, 09.09.2014 Page 7 of 48
Maintenance and Technical Service
The user should not perform any maintenance work on the equipment other than that
which is described in this manual. Repairs should be executed by a qualified service
technician only.
In the following cases, the unit should be serviced by an authorized technician only if:
−the power cord or the mains connectors have been damaged.
−objects or liquids have gotten into it.
−it was exposed to rain.
−it doesn't appear to be functioning properly.
−it has fallen down or the enclosure is damaged.
Mounting the speakers
If the weight of the speaker exceeds 25 kg then it is necessary for two people to carry it.
To prevent injury, this equipment must be securely placed on the floor or secured to the
wall according to the assembly instructions. Speakers, which are stacked, must be se-
cured with securing straps. Please note that speakers can move as a result of vibrations.
To prevent them from falling from their mounted position, they must be secured
properly.
Speakers may only be suspended by qualified personnel.
Never use signal cables or power cords for suspending, aligning or securing the systems.
When laying the connecting cables, make sure that nobody can trip.
The speakers must be hung by using at least two of the designated flying points. The
same applies when lifting and aligning the speakers.
Never hang more than two speakers under one another without using the designated
Kling & Freitag mounting devices.
Ensure that all installation connections comply with the applicable safety guidelines and
that the size and strength are sufficient. Further instructions are in our user's manual for
assembly equipment and in the general safety instructions for speakers and assembly
equipment.
For mobile and fixed installations, use only assembly equipment from KLING & FREITAG.
Make sure to observe the included Safety and Mounting Instructions for Loudspeakers
and Accessories.
Unwanted interference
RF interference on the power cord or on the line signal cables may lead to unwanted
sound interference.
Damage caused by the speakers' magnetic fields
Speakers are permanently surrounded by a magnetic field, even when they are not op-
erating Therefore, during transport and placement of the speakers, it is important to
ensure that there is always approx. 1 m between the speakers and magnetic data media
and computer/video monitors.
The following signals may damage the speakers
−permanent high-pitched signals with high frequency and continuous noise from
feedback
−permanently distorted signals with high power.
−noises, which occur when the SP speaker is connected while equipment is being
connected, disconnected or switched on.
Preventing hearing damage
To prevent the risk of hearing damage, avoid being too close to operating speakers
even if the volume level seems to be low enough. In general, volume levels over 90 dB
can cause hearing damage.
Warning
Important
Caution

User’s Manual K&F Self Powered Subwoofer Systems ‘SP’
KLING & FREITAG GMBH ©2003 - 2014 Version 7.0, 09.09.2014 Page 8 of 48
2. Introduction SP Loudspeakers
'SP' denotes the Self Powered product line in the K&F range of loudspeakers. Based
on selected K&F speaker systems, the ‘SP’ models are equipped with state-of-the-art
integrated driver circuits and Class D power amplifier technology. The extremely
lightweight system electronics replace ponderous racks, power amplifiers, controllers,
and speaker cables.
Aside from the integrated power amplifier and input modules with controller func-
tions, the full-range systems possess a passive crossover so that the advantageous
features provided by the K&F passive technology (all-pass filter, protection circuits)
remain usable. The frequency separation for the subwoofers is controlled by an active
110 Hz low pass filter.
Integrated phase optimisation allows for all systems in the ‘SP Series’ to be combina-
ble with one another. With this, the ‘SP’ speakers, when the filter section is switched
off, have a completely comparable sound to the corresponding versions without inte-
grated power amplifier technology. Operations using a K&F System Controller CD 44,
CD 44 (discontinued) und C2 (discontinued) are also possible, which is appropriate for
many applications.
Operating the ‘SP Series’ is incredibly easy: The full range systems transmit the com-
plete frequency spectrum. If necessary, the ‘SP’ subwoofers in parallel operations can
provide an additional bass boost.
The Input Module
−Line signal input
−Limiter section (feed-forward RMS-limiter and peak limiter in feed-back design).
−High pass filter, 45 Hz tops, and 32 Hz subwoofers
−Low pass filter 110 Hz (subwoofer systems only)
−System specific, switchable frequency equalisation (‘FILTERS ON/ OFF’) controllable
by a covered switch on the connecting terminal
−Phase correction
−Level adjustment (countersunk level control on the connecting terminal)
The Amplifier Module
−1 x, or 2 x 1 kW Class D state-of-the-art power amplifier
−Minimal dimensions (speaker dimensions of the models without the ‘SP’ module are
retained)
−Low weight (weight increase of 2.5 / 4 kg as compared to systems without the ‘SP’
module; and with the Line 212 - SP, the weight even stays identical)
−High efficiency enables convection cooling, because of which bothersome fans are
unnecessary
−High fidelity (even in high frequency range) and a large power band width resulting
from impedance optimisation

User’s Manual K&F Self Powered Subwoofer Systems ‘SP’
KLING & FREITAG GMBH ©2003 - 2014 Version 7.0, 09.09.2014 Page 9 of 48
Modes of Operation
−Operations without external controller:
with activated filters (FILTERS ‘ON’), all K&F models in the ‘SP Series’ are combin-
able with one another by simply linking the signal from one speaker to the next.
−With optional K&F System Controller*:
via a K&F System Controller CD 44, CD 24 (discontinued) or C2 (discontinued,
with system plug-in card) or an Audio DSP*:
−if used with BSS Soundweb, FDS 366, 336, 334, and XTA DP 226, 224, K&F sys-
tem parameters are available upon request
* The operation of the K&F 'SP' models with a K&F System Controller or Audio DSP is
recommended for uses in which special filter pre-sets are advisable, i.e. in combina-
tion with passive systems of the 'CA Series', in cluster operations (top low cut), when
bass and high boost are necessary, adjustment to the room acoustics (EQ), etc.
The following K&F 'SP' speakers are available:
Full-range systems: CA 1001 - SP,
CA 1201 - SP,
CA1215-6 - SP, CA 1215-9 - SP
CA 1515-6 - SP, CA 1515-9 - SP
LINE 212-6 - SP, LINE 212-9 --- SP
Subwoofers: SW 112 - SP, SWi 112 - SP,
SW 115E - SP, SWi 115E - SP,
SW 118E - SP, SWi 118E - SP,
SW 215E - SP, SW 215E - SP ‘Suspension’

User’s Manual K&F Self Powered Subwoofer Systems ‘SP’
KLING & FREITAG GMBH ©2003 - 2014 Version 7.0, 09.09.2014 Page 10 of 48
3. Connectors, Controls und Displays
2
8
6
5
7
3
4
1
1) LINE IN and LINE OUT (+6 dB)
Electronically balanced input and output connectors. Use the XLR female connector
(marked 'IN') as input. The parallel-wired XLR male connector (OUT) is for connec-
tions to further 'SP' loudspeakers.
2) GROUND LIFT
When the ‘Ground Lift’ switch is set to LIFT, pin 1 of the LINE IN connector (ground)
is not connected to the chassis ground of the integrated amplifier module. The
ground connection between LINE IN (XLR male) and LINE OUT (XLR female) is main-
tained. The use of the 'Ground Lift' switch is sometimes necessary in dealing with
hum problems (see chapter 7.1 )
Never tape over the protective earth on the plug --- danger to life!
3) PROTECTIVE COVER
The protective cover prevents unwanted adjustment of the gain control and filter
ON / OFF switch. The cover has a snap-in lock. In order to reach the controls be-
neath, turn the cover sharply down in the direction of the arrow.
Warning

User’s Manual K&F Self Powered Subwoofer Systems ‘SP’
KLING & FREITAG GMBH ©2003 - 2014 Version 7.0, 09.09.2014 Page 11 of 48
4) GAIN CONTROL (± 6 dB)
a) The gain control can be used to adjust the input level of the amplifier module
by ± 6dB. It serves to balance the volume levels of the various systems. In or-
der to avoid overloading the input circuit or the mixer’s output circuit, it
should normally be set in the case of K&F full-range systems at 0 dB (centre
notch setting).
b) When operating with a K&F System Controller, set the input level of the am-
plifier module on the controller. The gain control on the SP speaker should be
set at 0 dB (centre notch setting). One exception to this rule is a cluster ar-
rangement, in which the inner speakers should be set at a lower level than
the outer ones. In this case the level of the gain control on the inner SP
speakers can be adjusted downwards accordingly.
When operating with additional bass systems it is very important that the respec-
tive volume levels between the top speakers and the bass systems are correctly
balanced. To this end the sound engineer should check the volume levels during
the set-up and adjust them accordingly. When setting up a system without a K&F
System Controller this adjustment should be carried out using the gain control of
the SP subwoofer (use gain control of the top speaker if not sufficient); in the
case of a system with K&F System Controller set this gain on the controller.
Please note that the position of a bass speaker is crucial for its actual sound level. A
bass speaker, which is on the floor, can be a few decibels louder than a flown bass
system because of the floor reflections. Because of this, a sound engineer must al-
ways fine-tune the system using the corresponding level controls.
5) FILTERS ON / OFF (High Pass / Low Pass / Equalizer)
This switch turns the filter in the SP module on ('ON'), or off ('OFF').
a) The switch should always be in the 'ON' position when the speakers are being
driven without K&F System Controller.
b) The switch should always be in the ‘OFF’ position when the speakers are being
driven with K&F System Controller.
The filters consist of:
−high-pass: protects the speakers against mechanical stress due to frequen-
cies outside the speaker's frequency range (protection against subsonic
frequencies)
−low-pass (subwoofers with SP-module only): Only frequencies below 110
Hz can pass the low pass filter. In this way, the bass speaker only repro-
duces the intended frequencies.
−EQ: filter for basic equalization, optimizing the frequency response of the
speaker systems.
Furthermore the SP filter module has a phase alignment, which prevents loss of
certain frequencies due to phase shift between mid-high and bass systems.
Thus the combination of all available K&F mid-high SP systems with all K&F
bass SP systems is possible, and 100% phase compatibility with all K&F speak-
ers operating in conjunction with a K&F System Controller in the '2-way active'
mode is guaranteed.

User’s Manual K&F Self Powered Subwoofer Systems ‘SP’
KLING & FREITAG GMBH ©2003 - 2014 Version 7.0, 09.09.2014 Page 12 of 48
6) LED POWER ON (GREEN) and LIMIT / PROTECT (RED)
The LED is dual-purpose:
a) When the LED is green, the speaker is connected to the supply voltage and
ready for operation
b) The LED will turn red if…
…the input signal is so high that the internal limiters reduce its level.
The limiters consist of a peak limiter, which limits the peaks of the signal,
and an RMS / thermal limiter, which continuously regulates excessive levels.
During normal operation the red light may occasionally illuminate briefly. It
does indicate that the level peaks are limited by the limiter circuit. The peak
performance of the speaker has then been reached.
Should the red light come on more frequently or remain illuminated, the
output level of the mixer should be reduced. When speakers with and
without SP module are in operation simultaneously, the gain control on the
SP speaker can be turned down, provided the level is sufficient for the oth-
er power amplifiers. The limiter protects the speaker from damage due to
excessive levels.
c) The LED stays permanently red, if…
…the protection circuitry of the integrated power amplifier cuts in and as a
result no further signal reaches the speaker (Protect Mode).
The protection circuitry switches off the integrated power amplifier,…
−…if the temperature of the amplifier module is too high. As soon as
the temperature falls below the critical value, the amplifier module is
switched on again automatically. Excessive temperatures can be
caused for example by inadequate ventilation of the heat sink. Make
sure that the air vents are not covered or positioned directly against a
wall.
−…if the output impedance is too low or in the case of a short circuit,
caused for example by a defective chassis or a faulty component on
the crossover.
−…if the amplifier has an internal fault. The SP amplifier module checks
that all is functioning correctly during operation. As soon as a fault be-
comes apparent the module switches into protect mode. If only one
module of the SW 215E has a fault, the input signal is attenuated by
70 dB, to prevent damage to the other module.
Measures to be taken when LED is red:
Fault Measure Function
LED remains red or flickers
continually during opera-
tion
Reduce output level on mixer until LED
goes out or flickers only occasionally.
Limiter
No or too low output sig-
nal, LED shows red in spite
of reduced mixer level.
Allow to cool. The amplifier module
switches itself on after a few minutes.
Provide sufficient ventilation.
Temperature
protection
No or too low output sig-
nal, LED stays red after
cooling down.
Have loudspeaker checked by
authorized repair technician.
Other
protection
SW 215E:
Output signal is
too low
Have loudspeaker checked by
authorized repair technician.
Other
protection

User’s Manual K&F Self Powered Subwoofer Systems ‘SP’
KLING & FREITAG GMBH ©2003 - 2014 Version 7.0, 09.09.2014 Page 13 of 48
7) AC MAINS 'IN'
Connect this PowerCon socket using the mains cable supplied to a max. 16 A fused
mains socket, paying particular attention to the stated mains voltage! Connection
to an incorrect mains voltage can result in irreparable damage!
8) AC MAINS 'OUT'
Socket for connection to further equipment such as further speakers with SP mod-
ule. Use only connection cables, which conform to your national safety reg-
ulations.
Maximum power consumption: 230 V: 10 A / 2300 W
110 V: 10 A / 1150 W
4. Power Cord
In Germany, a pre-constructed ready for use power cord is included in the delivery.
For deliveries to foreign countries, a pre-constructed power cord incl. PowerCon plug is
included. Because of the different standards abroad, the power plug is not included.
This must be subsequently assembled only by qualified electrical specialists.
Important
Warning
Warning
brown = BN = L
green / yellow = GNYE =
blue = BU = N

User’s Manual K&F Self Powered Subwoofer Systems ‘SP’
KLING & FREITAG GMBH ©2003 - 2014 Version 7.0, 09.09.2014 Page 14 of 48
5. Safety Instructions for Suspending the Speakers
The speakers may only be mounted by trained specialised personnel with
proof of their qualifications as an approved ‘rigger’.
Please follow the accompanying instructions for speakers and assembly
equipment.
Speaker systems, whether single or connected to one another, must always be secured to
a second separate point, even if two rigging points are used for suspending the speaker
system!
A maximum load of 73 kg may be hung below one SW 215E --- SP subwoofer.
This means a maximum additional load of 36.5 kg on each flying point.
This means a maximum additional load of 36.5 kg on each flying point.This means a maximum additional load of 36.5 kg on each flying point.
This means a maximum additional load of 36.5 kg on each flying point.
A maximum load of 50 kg may be suspended from the two flying points of all other sub-
woofers. This means a maximum additional load of 25 kg on each flying point.
This means a maximum additional load of 25 kg on each flying point.This means a maximum additional load of 25 kg on each flying point.
This means a maximum additional load of 25 kg on each flying point.
Ensure that all connections are secured to prevent their detaching on their own and that
only admissible statically tested and sufficiently sized connecting devices, ropes and chains
are used.
5.1 SW 215E - SP and Click & Fly Accessories
The Click & Fly rigging system is a certified and type tested rigging system for safe and
comfortable rigging of SW 215E or Line 212 systems.
Click & Fly Systems with the classification of ‘CLICK & FLY RIGGING SYSTEM’
may not be used with the SW 215E Systems without the supplementary
measures described below.
This is necessary due to safety measures for the subwoofer system, which have become
additionally necessary. Only when these new supplementary measures are observed can
it be guaranteed that you will have a safe and accordingly certified product for your
further use.
CLI CK & FLY LI NE 21 2 / S W 21 5E
Made in
Germany
Manufacturing Year:
SW-Load:
&
135,0k g
2004
XXXXXXXXXXX
3,3k g
Ser.-No.:
Weight:
Supplementary measures which allow for an ‘old’ Click & Fly System to be used for
mounting SW 215E systems:
−Affix a new name plate, available from Kling & Freitag, recognisable by the classi-
fication ‘CLICK & FLY LINE 212 / SW 215E’
−Affix the following additional sticker, received from Kling &
Freitag, to the top side of the main bar:
−Receipt of a written version of this manual for each Click & Fly rigging system.
−User’s manual made available for the users.
−Disposal of the old user’s manual.
Kling & Freitag GmbH has made all resources necessary for supplementation including a
detailed manual available free of charge to all buyers of the ‘old’ ‘CLICK & FLY RIGGING
SYSTEM’. If you did not receive these resources, please contact your retailer!
Warning
At this position, ‘LINE 212 / SW 215E’ must be
visible. If ‘RIGGING SYSTEM’ is present at this
position, then the Click & Fly rigging systems is
only approved for use with the Line 212 sys-
tems.
DO NOT CONNECT
SPEAKERS WITH
CLICK & FLY
MAINBARS

User’s Manual K&F Self Powered Subwoofer Systems ‘SP’
KLING & FREITAG GMBH ©2003 - 2014 Version 7.0, 09.09.2014 Page 15 of 48
5.2 SP-Subwoofers with ‘Suspension Thread’ M12 (SWi-Versions)
If you want to use the SP subwoofers equipped with ‘suspension threads’ M12, please
read the following instructions.
Appropriate fastening mechanisms with an external screw thread of M12 and a mini-
mum length of 35 mm! may be screwed on to the M 12 thread inserts. The internal
screw threads in the speaker enclosure are fastened during production with counter-
sunk head screws M12.
The two internal screw threads of the inner enclosure edge are on an L-bracket. This L-
bracket has the function of connecting the adjoining plates of the enclosure. It provides
sufficient tensile strength for flown operations. To guarantee that the enclosure plates
are correctly connected by the L-brackets, only one screw of the enclosure edge may be
loosened at a time. If both screws of an enclosure edge become loose, then, for safety
reasons, the L-bracket will collapse into the enclosure.
If the L
If the LIf the L
If the L-
--
-bracket has fallen into the enclosure the loudspeaker must on no account
bracket has fallen into the enclosure the loudspeaker must on no accountbracket has fallen into the enclosure the loudspeaker must on no account
bracket has fallen into the enclosure the loudspeaker must on no account
be used again until it has been repaired by an authorized repair service.
be used again until it has been repaired by an authorized repair service.be used again until it has been repaired by an authorized repair service.
be used again until it has been repaired by an authorized repair service.
When mounting the speakers, use only fastening mechanisms with threads that extend
at least 35 mm into the speaker enclosure. Take into account the permissible load ca-
pacity of the fastening mechanisms while considering the safety factors. Mount the
speakers using at least two independently operating points. Secure all screws to prevent
loosening.
Warning
Always use flat
washers M12 with
the customary outer
diameter of 37 mm.
Loosen only one of
these two screws at a
time!
35 mm minimum

User’s Manual K&F Self Powered Subwoofer Systems ‘SP’
KLING & FREITAG GMBH ©2003 - 2014 Version 7.0, 09.09.2014 Page 16 of 48
5.3 Subwoofer SP with ‘allsafe JUNGFALK’ Flying Points
Single Stud Fitting
Used as fastener to the ‘allsafe
JUNGFALK’ flying point.
‘allsafe JUNGFALK’ Flying Point
Receptacle for special fasteners.
1.) 2.)
Take the single stud fitting in one
hand...
... and push the locking device up
against the spring tension.
3.) 4.)
Put the flat head of the holding
bolt into the guiding of the flying
point.
Release the locking device when
the single stud fitting is located in
the middle of the flying point.
Make sure that the locking device
clicks into place.
5.)
Check that the single stud fitting is
securely fastened and cannot be
pulled out.
Warning

User’s Manual K&F Self Powered Subwoofer Systems ‘SP’
KLING & FREITAG GMBH ©2003 - 2014 Version 7.0, 09.09.2014 Page 17 of 48
5.4 SW 215E ‘Suspension’: The ‘allsafe JUNGFALK’ Flying Track
The subwoofer SW 215E with rigging option may only be suspended by using the dou-
ble stud fittings available from Kling & Freitag. The ‘allsafe JUNGFALK’ flying tracks are
used to suspend the SW 215E system.
We recommend using the certified Click & Fly Line 212 / SW 215E rigging system for
suspending the SW 212E.
The ‘allsafe JUNGFALK’ Flying Track can only support weights up to 73 kg!
Please follow the accompanying safety and assembly instructions carefully!
Double Stud Fitting
Used as fastener to the ‘allsafe
JUNGFALK’ flying point and the
‘allsafe JUNGFALK’ flying track.
‘allsafe JUNGFALK’ Flying Track
Receptacle for the double stud fit-
ting.
1.) 2.)
Align the double stud fitting as
shown above and push it into the
track,…
... slide the pushed double stud fitting
to the middle of the speaker until it
clicks into place. Make sure that it is
secured tightly.
Warning

User’s Manual K&F Self Powered Subwoofer Systems ‘SP’
KLING & FREITAG GMBH ©2003 - 2014 Version 7.0, 09.09.2014 Page 18 of 48
6. Mounting Instructions for Speakers
Mount the speakers securely. To avoid injury or damage, always be sure to mount the
speakers securely so that they do not fall. Speakers, which are stacked, must be secured
with securing straps. When laying the connecting cables, make sure that nobody can
trip.
The stability of stacked systems (also valid for the use of stands and distance rods!) is
contingent upon the following stability requirement. These conditions must, therefore,
be guaranteed by the user:
Stacked systems may not fall over even if they are inclined by 10° in each dire
Stacked systems may not fall over even if they are inclined by 10° in each direStacked systems may not fall over even if they are inclined by 10° in each dire
Stacked systems may not fall over even if they are inclined by 10° in each direction.
ction.ction.
ction.
If this requirement is not fulfilled, then it is necessary to take steps to achieve
If this requirement is not fulfilled, then it is necessary to take steps to achieveIf this requirement is not fulfilled, then it is necessary to take steps to achieve
If this requirement is not fulfilled, then it is necessary to take steps to achieve
compliance. Possible measures include strapping it to an appropriate base stru
compliance. Possible measures include strapping it to an appropriate base strucompliance. Possible measures include strapping it to an appropriate base stru
compliance. Possible measures include strapping it to an appropriate base struc-
c-c-
c-
ture or fastening it using safety straps.
ture or fastening it using safety straps.ture or fastening it using safety straps.
ture or fastening it using safety straps.
6.1 Using the Mounting Accessory ‘Distance Rod’
The SP subwoofer is equipped with a threaded flange (M20) on the top of the enclosure
for mounting the optionally available distance rod (not on the SWi versions).
All K&F top speakers with a mounting flange or stand adapter may be mounted on the
distance rod. Only use authentic Kling & Freitag distance rods and stand adapters. We
can only guarantee safe operations when these parts are used.
When a top speaker is mounted on the subwoofer using a distance rod, the stability of
the speakers is reduced. Please follow the stability requirements in chapter 6!
When re-positioning after set-up, remove the upper speaker mounted on the distance
rod first.
Special note for the model SW 112
A top speaker with a maximum weight of 28 kg (i.e. CA 1201) may be mounted on this
speaker using a distance rod. Speakers, which are heavier than 28 kg, may not be
mounted on the distance rod flange and must be mounted on an additional speaker
stand.
Warning
Caution
Distance Rod 337
with stand adapter and
adjustable speaker mount
Distance Rod 337
(adjustable)
Distance Rod 334

User’s Manual K&F Self Powered Subwoofer Systems ‘SP’
KLING & FREITAG GMBH ©2003 - 2014 Version 7.0, 09.09.2014 Page 19 of 48
6.2 LINE 212 Systems on Top of SW 115E-SP
In addition to the stacking foot
grooves for stacking the same
enclosures, the subwoofer SW
115E -SP also has stacking foot
grooves for the Line 212 system.
One Line 212 System can be
quickly and safely placed on the
subwoofer.
6.3 LINE 212 Systems on Top of SW 215E
In addition to the stacking foot grooves for stacking the
same enclosures, the subwoofer SW 215E also has
stacking foot grooves for the Line 212 system.
One Line 212 system can be quickly and safely posi-
tioned on top of a vertically placed SW 215E.
Two Line 212 systems can be precisely arrayed on top of
a horizontally placed SW 215E - SP.
Other combinations of Line 212 Systems are not recommended as they can cause unwanted interferences.
Horn not rotated on
standing Line 212 system
Horn rotated on
standing Line 212 system
Line 212-6 - SP
with
Line 212-6 - SP
8,5°
38,5°
30°
Line 212-6 - SP
with
Line 212-9 - SP
15,0°
45°
Stapelmulden
für 'LINE 212' und SW 115E
Stapelmulden
für 'LINE 212'
Stapelmulden
für SW 115E

User’s Manual K&F Self Powered Subwoofer Systems ‘SP’
KLING & FREITAG GMBH ©2003 - 2014 Version 7.0, 09.09.2014 Page 20 of 48
7. Wiring
Before connecting your SP system, be sure to switch off all connected appliances and
turn down all level controls.
−We recommend the use of high-quality cables provided by KLING & FREITAG.
−For connections to the line level inputs, please use 2-pin shielded microphone cable
with high-quality connectors.
−Avoid ground loops (see chapter 7.1 )
−Make sure that the pin assignment of the line level connectors is correct (2 + / 3 - / 1 ┴).
7.1 Avoiding Ground Loops
7.1.1 What is a Ground Loop?
Every component of a P.A. or Hi-Fi System has its own internal 0V reference (ground). This
point is often connected to the protective earth connector (PE / Ground). If two or more
units are connected to one another with a line level audio cable, there may be a ground
connection through the ground of the power supply cable (yellow-green) as well as
through the shielding of the audio cable. The voltage difference between these two
ground points causes audible interference to come from the speaker.
7.1.2 Avoiding Ground Loops
If there is a loud humming or buzzing after the 'SP' System has been connected, then
set the "Ground Lift" switches on the rear of the 'SP' speakers to the 'Lift' position
(chapter: 3 / section 2).
If the noise is still audible, check if
1. the noise is caused by a ground loop before the speakers (e.g. mixing console,
effects or equalizers).
2. the system or parts of the system are connected to an "unclean" power supply
- meaning one which is also running large motors or lighting systems. An "un-
clean" supply voltage, electrostatic and electromagnetic fields can cause inter-
ference.
Please observe the following basic rules:
−Never !!! try to avoid a ground loop by disconnecting or taping the ground
contact at the connector! Extremely dangerous!
−If possible, only use high-quality audio appliances with balanced signal outputs and
with power cables with PE connectors.
−Use high-quality cables with good shielding.
−The point of ground for all connected components should merge at one central
point. The power connections should lead out in a radial manner from one point
and not be linked from one unit to the next.
−When installing appliances that create strong electrostatic or electromagnetic fields
(large transformers, switch-mode power supplies), maintain some distance from
other audio appliances. In extreme cases, the only solution is to create a completely
independent 'audio ground'; in other cases, it is sufficient to connect a filter in front
of the audio equipment.
Warning
