KANYON K110 User manual

ASSEMBLY REQUIREMENTS
K110
FOLDING ADIRONDACK CHAIR
1 STEP
ARMS
K111
FOLDING ADIRONDACK CHAIR W/PULLOUT
OTTOMAN
1 STEP
ARMS
K120
ADIRONDACK ROCKING CHAIR
3 STEPS
ARMS & ROCKING LEGS
K140
2' ADIRONDACK GLIDER
5 STEPS
BACK TO SEAT, ARMS, TOP TO BASE
K141
2' SWIVEL ADIRONDACK GLIDER
6 STEPS
BACK TO SEAT, ARMS, TOP TO BASE
K150
4' ADIRONDACK GLIDER
ASSEMBLED
K160
5' ADIRONDACK GLIDER
ASSEMBLED
K171
GLIDING OTTOMAN
ASSEMBLED
Dining Tables and Chairs
K210
DINING HEIGHT CHAIR
4 STEPS
BACK TO SEAT, ARMS
K211
DINING HEIGHT SWIVEL CHAIR
1 STEP
TOP TO BASE
K220
DINING HEIGHT 42" SQUARE TABLE
ASSEMBLED
K221
DINING HEIGHT 6' RECTANGLE TABLE
ASSEMBLED
K222
DINING HEIGHT 6' OVAL TABLE
ASSEMBLED
K310
COUNTER HEIGHT CHAIR
5 STEPS
BACK TO SEAT, ARMS, FOOTREST
K311
COUNTER HEIGHT SWIVEL CHAIR
1 STEP
TOP TO BASE
K320
BAR HEIGHT CHAIR
5 STEPS
BACK TO SEAT, ARMS, FOOTREST
K321
BAR HEIGHT SWIVEL CHAIR
1 STEP
TOP TO BASE
K324
BAR HEIGHT SADDLE STOOL
ASSEMBLED

ASSEMBLY REQUIREMENTS
K330
COUNTER HEIGHT 42" SQUARE TABLE
ASSEMBLED
K331
COUNTER HEIGHT 6' RECTANGLE TABLE
ASSEMBLED
K332
COUNTER HEIGHT 6' OVAL TABLE
ASSEMBLED
K340
BAR HEIGHT 42" SQUARE TABLE
ASSEMBLED
K341
BAR HEIGHT 6' RECTANGLE TABLE
ASSEMBLED
K342
BAR HEIGHT 6' OVAL TABLE
ASSEMBLED
K343
BAR HEIGHT 72"X28" HARVEST TABLE
ASSEMBLED
Other Causual Seating Options
K410
CHAISE LOUNGE WITHOUT ARMS
4 STEPS
SEAT BACK TO BASE, WHEELS
K420
CHAISE LOUNGE WITH ARMS
5 STEPS
SEAT BACK TO BASE, ARMS, WHEELS
K511
COUNTER HEIGHT TETE-A-TETE
6 STEPS
ARMS, BASE, BACK AND SEAT, TRAY
K512
BAR HEIGHT TETE-A-TETE
6 STEPS
ARMS, BASE, BACK AND SEAT, TRAY
K610
4' ADIRONDACK SWING
5 STEPS
BACK TO SEAT, ARMS, CHAIN
K620
5' ADIRONDACK SWING
5 STEPS
BACK TO SEAT, ARMS, CHAIN
Accessory Items
K710
BASIC FOLDING END TABLE
ASSEMBLED
K720
DELUXE FOLDING END TABLE W/SHELF
ASSEMBLED
K750
UNIVERSAL CUPHOLDER
ASSEMBLED

Step 1 (Open legs and attach arms)
Lay the chair at and open the front legs. Align the hole on the front side of the arm with the
front leg. Insert a short bolt into the washer, arm and front leg. Slide on another washer and
tighten a nut onto the bolt.
Lift the back and align with the arm. Insert a long bolt into the washer, arm and front leg.
Slide on another washer and tighten nut onto bolt.
(Repeat process for opposite side)
POLY ADIRONDACK FOLDING CHAIR
EASY ASSEMBLY INSTRUCTIONS
1

Step 2 (Fold and open chair)
Step 3 Tighten bolts
Fold the chair closed and reopen while applying upward pressure on the back of the chair.
FOLDING CHAIR CONT.
2
Step 4 ENJOY!
Customer Service: Call 1-866-872-3437. Ask for Darren.

1
FOLDING ADIRONDACK CHAIR W/ PULL OUT OTTOMAN
Step 1 (Attach the arms to seat)
Unfold the back by standing it up. Align the arm holes with the holes in the back and use a
bolt and washer to connect. Repeat on other side. Then place the half circle of the arm on the
outside of the legs and align the holes. Connect with a bolt and washer and tighten. Repeat on
the other side.
EASY ASSEMBLY INSTRUCTIONS

2
FOLDING ADIRONDACK CHAIR W/ PULL OUT OTTOMAN CONT.
EASY ASSEMBLY INSTRUCTIONS
Step 3 ENJOY!
Customer Service: Call 1-866-872-3437. Ask for Darren.
Extend the ottoman by pulling it forward from the chair until it’s in the fully extended position,
making sure the legs are in a stable position to support it.
Step 2 (Extend)

Step 1 (Open legs and attach arms)
Lay the chair at and open the front legs. Align the hole on the front side of the arm with the front leg.
Insert a short bolt into the washer, arm and front leg. Slide on another washer and tighten a nut onto
the bolt.
Step 2 (Attach back of arms)
Lift the back up and insert a long bolt into the washer, back of the arm and back. Slide on anoth-
er washer and tighten a nut onto the bolt.
(With the legs out and seat back already up, repeat steps 1 & 2 for opposite side)
POLY ADIRONDACK ROCKING CHAIR
EASY ASSEMBLY INSTRUCTIONS
1

ROCKING CHAIR CONT.
Step 3 (Attach runners)
Place the front of the runner on the inside of the front leg. Insert a long bolt into the washer,
front leg and runner. Slide on another washer and tighten a nut onto the bolt.
Place the back of the runner on the outside of the back legs. Insert a long bolt into the washer,
front leg and runner. Slide on another washer and tighten nut onto bolt.
(Repeat this process for the opposite side)
2

Step 4 ENJOY!
Customer Service: Call 1-866-872-3437. Ask for Darren.
3
ROCKING CHAIR CONT.

POLY ADIRONDACK GLIDER
EASY ASSEMBLY INSTRUCTIONS
Step 1 (Attach arms to seat)
Set the seat on its side then set the arms on the side of the side ensuring the bolt holes align.
Insert a short bolt into the washer, top hole of the front arm brace and seat. Slide on another
washer and tighten nut onto bolt. Using another of the same bolt, repeat this process for the
lower hole.
For both holes on the back arm brace, insert a long bolt into the washer and set in the holes of
the back brace and seat. You may use a hammer to pound the bolts down until ush.
(Repeat this process for the opposite side)
1

Step 2 (Attach back to chair)
Step 4 (Attach chair to base)
Step 3 Tighten all bolts in the chair
Align the holes midway up the back with the holes on the back of the arms. For both sides, insert
a medium bolt into the washer, arms and back then slide on another washer to each and tighten
nuts onto the bolts.
Align the holes on the bottom of the back with the holes that set the bolts in during step 1. You
may use a hammer to pound the bolts all the way through then for each bolt, slide on another
washer and tighten nut onto bolts.
*The front hangers on the base are 1” shorter than the back
With the front facing forward, slide the base under the chair.
Insert one of the short thicker bolts into the washer and front of chair. Lift the side of the chair
and push the bolt through the front hanger. Slide on another washer and tighten nut onto bolt.
(Repeat this process for the back hanger.)
Repeat the hanger bolting process for the opposite side then tighten all bolts.
GLIDER CONT.
2

Step 5 (Attach gliding braces)
Horizontally align the front sliding brace with the screws in the bottom arm brace. Ensure the
sliding brace is ush with the bottom arm brace and drive screws in.
(Repeat this process for the opposite side)
Vertically align the back gliding brace with the screws in the bottom arm brace and drive screws
in. Ensure the sliding brace is ush with the bottom arm brace and drive screws in.
(Repeat this process for the opposite side)
GLIDER CONT.
3
Step 6 ENJOY!
Customer Service: Call 1-866-872-3437. Ask for Darren.

1
SWIVEL GLIDER
Step 1 (Attach front side arms to seat)
Slide a washer onto a short bolt and insert into the top hole of the arm base.
Align with the top hole towards the front of the seat and push the bolt through.
Slide on another washer and tighten a nut onto the bolt. (Only nger tight) Once completed
tighten everything up. Insert another short bolt into the washer and slide through lowest hole on
the arm base, and seat. Slide on another washer and tighten a nut onto the bolt.
EASY ASSEMBLY INSTRUCTIONS

2
Step 2 (Set bolts in front of arms)
Place the medium bolt and washer in the front of the arms, but don’t push it all the way through.
This will be where the arm and back connect. When the back is added, then the bolts will be
pushed through and tightened.
SWIVEL GLIDER CONT.
Step 3 (Attach back side of arms to seat)
Place a long bolt and washer on the outside of the arm and push it through the seat, but don’t
push it all the way through. This will be where the back side of the arm, seat and back connect.
When the back is added, then the bolts will be pushed through and tightened.

3
SWIVEL GLIDER CONT.
Step 4 (Attach the back)
Once the back is in place and aligned with the upper arm holes, the bolts that have already been
placed can be pushed through and tightened.
Align the bottom of the back with the arm and seat holes and push the bolts through and
tighten.
(Repeat process for opposite side.)
Slide the chair onto the base. The hangers are the same length, so it doesn’t matter which are in
front or back.
Step 5 (Attach chair to base)

4
SWIVEL GLIDER CONT.
Step 6 (Tighten all bolts)
Line up the holes in the base with the holes in the brackets and use a bolt and a washer
to connect and tighten.
(Repeat process for opposite side.)
Step 7 ENJOY!
Customer Service: Call 1-866-872-3437. Ask for Darren.

Step 1 (Attach arms and legs to base)
Align the right legs to the right side of the base and insert a short bolt through the washer, leg,
and base for the front and back. Slide on another washer and tighten a nut onto the bolt.
(Repeat process for left side)
Step 2 (Attach seat)
Align the holes on the front of the seat to the holes just under the armrests. Insert a short bolt through
the washer, arm, and seat. Slide on another washer and tighten a nut onto the bolt.
(Repeat process for opposite side)
POLY ADIRONDACK COUNTER CHAIR
EASY ASSEMBLY INSTRUCTIONS
1

COUNTER CHAIR CONT.
Step 5 Tighten bolts
Step 4 (Connect back to seat)
For right and left sides, insert a long bolt through the washer and partially through the legs.
Lift the seat up and push the back forward. Align the holes and push the bolts through. Slide on
another washer and tighten a nut onto the bolt.
Step 3 (Attach back)
For right and left sides, insert a medium bolt through the washer and partially through the arms.
Align the top holes of the seat back with the holes towards the back of the arms. Push the bolt
through the arms and back. Slide on another washer and tighten a nut onto the bolts.
2
Step 6 ENJOY!
Customer Service: Call 1-866-872-3437. Ask for Darren.

1
DINING, COUNTER, BAR HEIGHT SWIVEL CHAIR
Step 1 (Attach chair to base)
Place the chair upside down. Angle the plate so you can see the holes in the corners and place
the base on the chair. Place and tighten the bolts on the four corners.
EASY ASSEMBLY INSTRUCTIONS

2
DINING, COUNTER, BAR HEIGHT SWIVEL CHAIR
EASY ASSEMBLY INSTRUCTIONS
Step 2 ENJOY!
Customer Service: Call 1-866-872-3437. Ask for Darren.
