Kaption Audio SRX Series User manual

SRX 6.5in Co-axial
570-SRX652
SRX 6.5in Reference Component System
570-SRXC652
Owner’s Manual

- 1 -
SRX Series
Introduction:
Congratulations on your new purchase of Kaption Audio loudspeakers. These
loudspeakers are engineered to reproduce music that is so detailed, you will
hear music in a whole new dimension. State of the art technology, rigorous
testing, superior materials, innovative design and painstaking quality control;
all of these factors make for a truly superior product.
For the best performance we recommend you have an authorized Kaption
Audio dealer install your product.
KAPTION AUDIO LOUDSPEAKERS COME WITH A ONE-YEAR PARTS AND
LABOUR LIMITED WARRANTY.
570-SRX652 Design Features:
• 80 Watts RMS / 160 Watts Peak Power (per pair)
• Precision 12dB crossover
• Butyl Rubber Surround with polypropylene Cone
• High Fidelity Sound
Parts list
• 2 - 6.5” Co-axial speakers
• Integral 12 dB crossover
• Mounting clips
• 2 - Grills
CAUTION
ExTENdEd ExpOsUrE TO sOUNd prEssUrE lEvEls OvEr 100dB mAy
rEsUlT IN TEmpOrAry Or pErmANENT hEArINg lOss. ExErCIsE CAUTION TO
prEvENT dAmAgE TO hEArINg.
KApTION AUdIO ACCEpTs NO lIABIlITy fOr ANy dAmAgEd Or pErmANENT
hEArINg lOss.

- 2 -
SRX Series
570-SRXC652 Design Features:
• 160 Watts RMS / 320 Watts Peak Power (per pair)
• External 12dB crossover
• Butyl Rubber Surround with Reinforced Paper Cone
• High Fidelity Sound
Parts list
• 2 - 6.5” Woofer
• 2 - 12dB External crossover
• 2 - SRX ¾” Soft Dome Tweeters
• 2 - Flush tweeter mounting cup
• 2 - Surface mount angled tweeter mounting cups
• Mounting clips
• 2 - Grills
Limited Warranty Information:
Kaption Audio loudspeakers have a one-year limited warranty. This warranty
covers the original purchaser of a Kaption Audio speaker, purchased from an
authorized Kaption Audio dealer.
In order to receive service, proof of purchase is required stating the customers
name, dealer name, product purchased and date of purchase.
Products found to be defective during the warranty period will be repaired or
replaced with a product deemed to be equivalent at Kaption Audio’s discretion.
What is not covered
1. Any product not purchased from an authorized Kaption Audio dealer.
2. Any expense related to the removal, re-installation or shipment of any
Kaption Audio products.
3. Any Kaption Audio product that has been defaced or altered.
4. Subsequent damage to other components.
5. Damage caused by accident, abuse, improper operation, water and theft.
6. Burnt voice coils due to amplifier clipping or distortion.
7. Repeated returns with the same damaged may be considered abuse.
How to obtain service
To obtain service on a Kaption Audio product, Please return product
along with original receipt to an authorized Kaption Audio dealer or call
1-866-KAPTION (527-8466)

- 3 -
SRX Series
Specifications
Model 570-SRX652 570-SRXC652
Speaker size 6.5” 6.5”
Sensitivity (1w/1m) 87 dB 87 dB
Power Handling (RMS / Peak) Total per pair 80 / 160 160 / 320
Impedance 4 ohm 4 ohm
Mounting Diameter 5.60” 5.60” (Woofer)
Mounting Depth 2.33” 2.33” (Woofer)
Driver Diameter 3.35” 3.70”
Tweeter Diameter 0.75” 1”
Tweeter protrusion 0.45” N/A
Thiele-Small Parameters
Model 570-SRX652 570-SRXC652
Fs (Hz) 73.5 76.5
Qts 0.70 0.58
Qms 3.4 3.71
Qes 0.88 0.69
Res (ohms) 3.55 3.55
Vas (liters) 11.0 13.11
Mms (g) 11.34 8.87
Cms (uM/N) 413 476
BL (T*M) 4.60 4.73
Impedance 4 ohm 4 ohm
Specifications subject to change without notice

- 4 -
SRX Series
Diagram
164
6.45
157
6.18
5
.20
8
.31
12
.45
59
2.33
85
3.35
164
6.45
157
6.18
5
.20
8
.32
94
3.70
62
2.45
70
2.75
120
4.70
38
1.50
67
2.64
15
.61
39
1.52
48
1.88
18
.71
42
1.65
19
.76
22
.86
43
1.68
19
.75
21
.83
24
.94
7°
17°
570-SRXC652
570-SRX652

- 5 -
SRX Series
TWEETER
WOOFER
AMP/SOURCE UNIT
Standard wiring configuration
for each speaker
TWEETER
IN+ IN- TW+ TW- WF+ WF-
AMP/SOURCE UNIT
570-SRXC652
570-SRX652

- 6 -
SRX Series
Warranty registration card
Name: ________________________________________________
Street: ________________________________________________
City: ________________________________________________
Province / State: ________________________________________________
Country: ________________________________________________
Postal / Zip code: ________________________________________________
Phone: ________________________________________________
Email: ________________________________________________
Model Number: ________________________________________________
Serial Number: ________________________________________________
Authorized
Kaption Audio dealer: ________________________________________________
Purchase Date: ________________________________________________
Kaption Audio
40 Emblem Court, Toronto, ON, Canada, M1S 1B1
www.kaptionaudio.com 1-866-KAPTION (527-8466)
Limited Warranty Information:
KAPTION AUDIO PRODUCTS COME WITH A ONE-YEAR PARTS AND LABOUR LIMITED
WARRANTY.
This warranty covers the original purchaser of a Kaption Audio product, purchased from an
authorized Kaption Audio dealer. In order to receive service, proof of purchase is required
stating the customers name, dealer name, product purchased and date of purchase.
Products found to be defective during the warranty period will be repaired or replaced with a
product deemed to be equivalent at Kaption Audio’s discretion.

SRX 6.5in Speakers
570-SRX652
570-SRXC652

Kaption Audio
40 Emblem Court,
Toronto, ON
Canada, M1S 1B1
www.KAPTIONAUDIO.com
866-Kaption (527-8466)
Design in Canada; Made in China
R0 (04/18)
