KBT X6 User manual

Robot Vacuum Cleaner X6
Please read this manual carefully before using the product and keep it safe.
Robot Vacuum Cleaner Instruction Manual

Product Introduction
Robot Front
Robot Back
Boundary Sensor
Dustbin Flip Cover
Universal Wheel
Side Brush
Suction port
Soft pack driving wheel
Power interface
Power switch
Dustbin Cover Plate
Front Buffer Bar
Start / Pause Button
Robot

Product Introduction
List of Parts
Dustbin HEPA Filter Primary Filter
Side Brushes USB charging cable
Product Parameters
Items
Product Model
Overall Dimensions
Net Weight
Rated Voltage
Rated Power
Battery Capacity
Charging Time
Cleaning Time
Dustbin Capacity
Parameters
X6
Height 79mm* diameter 306mm
2.1KG
7.4V
15W
2000mAh lithium battery
240-350min
60-80min
500ML

Start Cleaning
Pause
Installing side brush
Charging
Installation/Operation
Start Cleaning
Start by pressing the start/pause button of the
robot
1. Short press to start random cleaning mode;
2. Long press for 3 seconds to enter the key
cleaning mode.
Warm Tips:
Before starting the program, it is necessary to
ensure that the start/pause button of the robot
remains on, indicating that the robot is waken.
If the robot is not waken, please short press
the start/pause button to wake it.
Short press the start/pause button on the
robot while the robot is working, and the
robot pauses working.
Warm Tips:
After standby for 2 minutes, the robot enters
the sleep state, and the start/pause key
indicator goes out.
Place the machine against the wall on the
horizontal ground and connect the power supply.
Warm Tips:
1. Ensure that there is a gap over 1 meter on
both sides of the cleaning robot and a gap over 2
meters in front;
2. The power cord vertical to the ground may be
dragged by the robot;
3. The yellow light is on when the battery level of
the robot is low, and the yellow light breathes
when it is charging.
Take out the side brush from the box, align
it with the mounting hole of the side brush,
and press it directly.

Regular Maintenance
Clean Dust Box
1. Gently lift the finger position of dust box
cover;
2. The dust box cover will open, hold the
hand buckle position of the dust box by
hand, and gently force it apart upwards;
3. Open the box cover;
4. Take out the filter screen;
5. Turn over the dust box and pour out the
garbage.
Warm Tips:
Dust box can be washed with clear water.
Side Brush Cleaning
1. Turn over the machine directly upwards,
and pull up the side brush more forcefully;
2. Remove and clean the side brush;
3. Put the side brush back into the machine
after cleaning.
Warm Tips:
It is recommended to change the side
brush every 3-6 months to ensure the
cleaning effect.
Boundary Sensor
Wipe the sensor with a soft clean cloth to
ensure the sensitivity of the sensor.
Battery Maintenance
The host has a built-in high-performance
lithium ion rechargeable battery pack. In
order to maintain the battery performance,
please keep the host charged for daily use.
Warm Tips:
1.If you don’t use it for a long time, please
turn it off and store it, and charge it for _
times at least three months to avoid
battery damage due to over-discharge;
2. In case of battery leakage, remove the
battery and clean it up;
3. The capacity of deeply discharged or
long-term unused batteries may be
reduced, and it’s recommended to
be activated.
Universal Wheel Cleaning
1.Take out that universal wheel, and clean the
hair wound around the universal wheel;
2.Put the universal wheel back to its original
position,and press it down hard with your
fingers.
Warm Tips:
It is recommended to clean up every month.
Dustbin
Boundary Sensor
Universal wheel
1.The primary & HEPA filters may be cleaned
with the electric blower or brush.
2.After cleaning the dust on the primary &
HEPA filters, install the primary & HEPA filters
into the dust box again.
3.Put the dust box back into the equipment.
Clean the Primary & HEPA Filters
Primary filter
Tips:
If the dust box is not installed or it is not
installed in place, the garbage cannot enter the
dust box.
HEPA filter

Safety information
1.Please use this product according to the instructions in the manual. Any operation inconsistent with
this manual may cause damage to this product;
2.The product cannot be operated and used by children under 8 years old or mentally handicapped
people. If they want to use it, they need to use it under the supervision and guidance of their guardian.
Never let children ride on products or play with products as toys.
3.Before using the product, please clean the power cord and small articles on the ground to avoid the
blockage of the product during cleaning. Fold the side ears of the carpet under the carpet, and keep
the hanging curtains and tablecloths from touching the ground;
4.If there is a hanging environment such as stairs, please test whether the product can detect the edge
of the hanging area without falling. A fence should be set at the edge of the suspended area to prevent
the product from falling, and it should be ensured that the protective facilities will not cause personal
injury such as tripping;
5.This product is an indoor household product, please do not use it outdoors;
6.Only original rechargeable batteries specially designed by the manufacturer can be used, and
non-rechargeable batteries are strictly prohibited. Please refer to product parameters for battery
specification information;
7.Do not wash products directly with water;
8.Do not wipe the product with a rag with water;
9.Do not use products on the ground with accumulated water;
10.Do not use products in the environment with open flames or fragile articles;
11.Prohibited in the environment of extreme high temperature (higher than 40°c ) or extremely low
temperature (Use products below -5°C);
12.It is forbidden for hair, clothes, fingers and other parts of the human body to approach the opening
or moving parts of the product;
13.It is forbidden for products to absorb any flammable materials, such as gasoline, printer or copy
color mixer and toner, and it is forbidden to use products in cleaning areas with flammable materials;
14.It is forbidden for products to absorb any burning items, such as cigarettes, matches, ashes and
other items that may cause fire;
15.It is forbidden to place objects at the suction port. Please clean up the dust, cotton wool and hair at
the suction port in time to ensure smooth air circulation at the suction port;
16.It is forbidden to use the power cord to drag or lift products. It is forbidden to use the power cord as
a handle. It is forbidden to clamp the power cord in the opening or seam. It is forbidden to pull the
power cord at sharp corners or corners. It is forbidden for products to run on the power cord. At the
same time, the power cord should be far away from heat sources.
17.Before using the product, please confirm that the dustbin and filter materials have been installed in
place;
18.If the power cord is damaged, in order to avoid danger, it should be replaced by the manufacturer’s
maintenance department or a professional from the designated institution;
19.Check whether the charger and socket are properly linked, otherwise it may lead to fire;
20.Plug the charger power cord firmly; otherwise it may cause electric shock; short circuit; smoke or
fire.
21.Do not touch the electrical power cord when your hands are wet, otherwise it may cause electric
shock;
22.Do not charge the product with damaged power cord or socket. Do not use the product when it
cannot work normally due to falling, damage, outdoor use or water ingress. In order to avoid injury, the
product should be repaired by the manufacturer or its after-sales service;
23.If the product is not used for a long time, please power off the product;
24.Before cleaning and maintaining the product, be sure to pull the plug out of the power socket and
turn off the power switch of the product;
25.Please clean the hair wound on the universal wheel and side brush in time;
26.Please clean up the garbage in the dustbin in time to avoid the blockage of HEPA and affect the
dust collection effect;
27.Before discarding the product, turn off the power switch and take out the battery. Please follow local
laws and regulations to remove and discard the battery.
28.Even if the product is seriously damaged, it is forbidden to burn the product, because the battery of
the product may explode.

FAQ
Harmful Substances
No. Fault Conditions Solutions.
Unable to boot
The battery is not enough, please charge the cleaning robot before using
it; The ambient temperature can not be too low (less than 0°c ) or too
high (higher than 40°c ), please use it under ambient temperature of
0-40°C;
Unable to charge Please make sure that both ends of the power cord are plugged in.
Please confirm whether the charging indicator is on;
There is abnormal noise or the robot
is shaking during cleaning
The side brush or universal wheel is entangled with hair, please clean the
hair entangled with the side brush or universal wheel;
Abnormal dust suction effect The suction port is blocked or the dustbin is full, please check the suction
port and clean up the dustbin;
Robot keeps going backwards Boundary sensor is abnormal, please clean the surface of boundary
sensor.
Abnormal Restart after shutdown;
Part
Category
Harmful Substances
Lead (Pb )
and its
compounds
mercury (Hg
) and its
compounds
Cadmium
(Cb ) and its
compounds
Hexavalent
chromium
(CrVI ) and its
compounds
Polybromi-
nated
biphenyls
(PBB )
Polybrominat-
ed diphenyl
ethers (PBDE
)
Plastic Parts
Alloy Parts
(Alloy)
Robot Circuit
Module
Battery
Plug Power Cord
(Metal)
O：Means that the content of the harmful substance in all homogeneous materials of the parts is below the
limit requirements specified in the current effective version of GB /T 2657.
X : It means that the content of the harmful substance in at least one homogeneous material of the parts
exceeds the limit requirements specified in the current effective version of GB /T 2657, there is no mature
alternative in the industry at present, and meets the environmental protection requirements of EU RoHs
Directive.
The numbers in this logo indicate that the environmental protection service life of the
product under normal use is 10 years
Implementation standard
