KEBCO COMBICOM User manual

COMBICOM ACCESSORIES
INSTRUCTIONS FOR USE | INSTALLATION BLUETOOTH-ADAPTER
Translation of the original manual
Document 20260008 EN 01

3
PREFACE
Preface
The hardware and software described in this document are products of KEB. The infor-
mation contained in this document is valid at the time of publishing. KEB reserves the
right to update this document in response to misprints, mistakes or technical changes.
Signal words and symbols
Certain procedures within this document can cause safety hazards during the installati-
on or operation of the device. Refer to the safety warnings in this document when per-
forming these procedures. Safety signs are also located on the device where applicable.
A safety warning is marked by one of the following warning signs:
DANGER Dangerous situation, which will cause death or serious injury iif this safe-
ty warning is ignored.
WARNING Dangerous situation, which may cause death or serious injury if this
safety warning is ignored.
CAUTION Dangerous situation, which may cause minor injury if this safety warning
is ignored.
NOTICE Situation, which can cause damage to property if this safety warning is
ignored.
RESTRICTION
Used when the following statements depend on certain conditions or are only valid for
certain ranges of values.
Used for informational messages or recommended procedures.
More symbols
► Thisarrowstartsanactionstep.
• / - Enumerations are marked with dots or indents.
=> Cross reference to another chapter or another page.
Note to further documentation.
www.keb.de/service/downloads

4
PREFACE
Laws and guidelines
KEBAutomationKGconrmswiththeECdeclarationofconformityandtheCEmarkon
the device nameplate that it complies with the essential safety requirements.
The EC declaration of conformity can be downloaded on demand via our website.
Warranty and liability
The warranty and liability on design, material or workmanship for the acquired device is
given in the general sales conditions.
Hereyouwillndourgeneralsalesconditions.
www.keb.de/terms-and-conditions
Furtheragreementsorspecicationsrequireawrittenconrmation.
Support
Although multiple applications are referenced, not every case has been taking into ac-
count. If you require further information or if problems occur which are not referenced in
the documentation, you can request the necessary information via the local KEB agency.
The use of our units in the target products is outside of our control and therefore
lies exclusively in the area of responsibility of the customer.
Theinformationcontainedinthetechnicaldocumentation,aswellasanyuser-specic
advice in spoken and written and through tests, are made to best of our knowledge and
information about the intended use. However, they are regarded as being only informal
and changes are expressly reserved, in particular due to technical changes. This also
applies to any violation of industrial property rights of a third-party. Selection of our units
in view of their suitability for the intended use must be done generally by the user.
Tests can only be done within the intended end use of the product (application) by
the customer. They must be repeated, even if only parts of hardware, software or
the unit adjustment are modied.
Copyright
The customer may use the instructions for use as well as further documents or parts
from it for internal purposes. Copyrights are with KEB and remain valid in its entirety.
This KEB product or parts thereof may contain third-party software, including free and/
or open source software. If applicable, the license terms of this software are contained
in the instructions for use. The instructions for use are already available to you, can be
downloaded free of charge from the KEB website or can be requested from the respec-
tive KEB contact person.
Other wordmarks or/and logos are trademarks (™) or registered trademarks (®) of their
respective owners.

5
TABLE OF CONTENTS
Table of Contents
Preface ....................................................................................................................................................3
Signal words and symbols .............................................................................................................3
More symbols.................................................................................................................................3
Laws and guidelines.......................................................................................................................4
Warranty and liability......................................................................................................................4
Support ........................................................................................................................................4
Copyright........................................................................................................................................4
Table of Contents ................................................................................................................................... 5
List of Tables .......................................................................................................................................... 6
List of Figures.........................................................................................................................................6
1 Basic Safety Instructions.............................................. 7
1.1 Target group.....................................................................................................................................7
1.2 Intended use ....................................................................................................................................8
1.3 Disposal............................................................................................................................................8
2 Product Description ...................................................... 9
2.1 Intended use ....................................................................................................................................9
2.2 Factory setting.................................................................................................................................9
2.3 Nameplate ......................................................................................................................................10
3 Hardware .......................................................................11
3.1 Overview Bluetooth-Adapter ........................................................................................................ 11
3.2 Technical data................................................................................................................................ 11
3.3 Terminal assignment.....................................................................................................................12
3.4 Start-up...........................................................................................................................................12
3.5 Status LED .....................................................................................................................................13
4 Software........................................................................ 14
4.1 COMBIVIS mobile App .................................................................................................................. 14
4.1.1 Functions and features of the COMBIVIS mobile App .......................................................14
4.1.2 Applications of the COMBIVIS mobile App......................................................................... 15
4.1.3 Connection setup ...............................................................................................................15
4.1.4 Application examples of the COMBIVIS mobile App ..........................................................16
4.2 KEB Elevator App.......................................................................................................................... 21
5 Certication.................................................................. 22
5.1 CE-Marking.....................................................................................................................................22
5.2 Declaration of Conformity ............................................................................................................23
5.3 Grant of Equipment Authorization FCC.......................................................................................24
5.4 RED certication............................................................................................................................25
6 Revision History .......................................................... 26

6
LIST OF TABLES
List of Tables
List of Figures
Figure 1: Nameplate Bluetooth-Adapter..........................................................................................10
Figure 2: Overview Bluetooth-Adapter............................................................................................ 11
Figure 3: Contact details service.....................................................................................................16
Figure 4: Connection menu.............................................................................................................16
Figure 5: Dashboard: Data..............................................................................................................17
Figure 6: Dashboard: Error .............................................................................................................17
Figure 7: Dashboard: I/O.................................................................................................................17
Figure 8: Dashboard: Favourites.....................................................................................................17
Figure 9: Parameter menu ..............................................................................................................18
Figure 10: Parameter group..............................................................................................................18
Figure 11: Parameter selected..........................................................................................................18
Figure 12: Parameter "Edit mode“ ....................................................................................................18
Figure13: CreateBackupleparameterlist..................................................................................... 19
Figure 14: Create Backup 1/2 ...........................................................................................................19
Figure 15: Create Backup 2/2 ...........................................................................................................19
Figure 16: Download Backup............................................................................................................19
Figure17: SettingsO󰀪ineScope .....................................................................................................20
Figure18: O󰀪ineScopeRecording ..................................................................................................20
Figure19: CreatedFileO󰀪ineScope...............................................................................................20
Figure20: RecordedDataO󰀪ineScope ..........................................................................................20
Figure 21: Declaration of Conformity to the RED Directive............................................................... 23
Figure 22: Grant of Equipment Authorization FCC............................................................................24
Figure23: REDcertication ..............................................................................................................25
Table 1: Factory settings..................................................................................................................9
Table 2: Technical data.................................................................................................................. 11
Table 3: Terminal assignment........................................................................................................12
Table 4: Status LED.......................................................................................................................13

7
BASIC SAFETY INSTRUCTIONS
1 Basic Safety Instructions
The Bluetooth-Adapter has been developed and built in accordance with the state of the
art and recognised safety regulations. Nevertheless, the function of the machine may
cause danger to life and limb of the user or third parties or damage to the machine and
other property.
NOTICE Safety rules and hazards.
►The safety instructions listed in this manual apply in addition to the
basic safety instructions for the drive controller !
►These can be found in the corresponding instructions for use.
►All instructions for use are available in the download area of www.keb.de.
Read the safety instructions carefully before using the adapter. Observe all warnings
and instructions on the device and in the instructions for use.
• In case of malfunctions, disconnect the adapter from the power source.
• The adapter is supplied via the serial interface at which it is operated.
• Intheeventofadefect,have theadaptercheckedbyqualiedpersonnelbefore
putting it back into operation.
• Modicationstotheadapterwillvoidthemanufacturer'sresponsibility.
• Clean the adapter only with a dry cloth.
• If you move the adapter from a cold to a warm environment, moisture may condense
inside the adapter. In this case, wait about one hour before putting the adapter back
into operation.
1.1 Target group
Thismanualisintendedforusebyqualiedelectriciansonly.Qualiedelectriciansas
denedinthismanualmusthavethefollowingqualications:
• Knowledge and understanding of safety instructions.
• Skills for installation and assembly.
• Start-up and operation of the product.
• Understanding of the function in the used machine.
• Recognition of dangers and risks of electrical drive technology.
• Knowledge of DIN IEC 60364.
• Knowledge of EN 60664-1.
• Knowledge of national safety regulations (e.g. DGUV Regulation 3).

8
BASIC SAFETY INSTRUCTIONS
1.2 Intended use
The Bluetooth-Adapter is connected to the serial interface of a KEB drive controller and
serves to transmit data from this interface via a Bluetooth Low Energy connection to a
corresponding remote station. It is intended exclusively for this purpose and may only be
used for this purpose. This also includes observing all the information in these instruc-
tions for use, especially the safety instructions. Any other use is considered improper
and can lead to property damage or personal injury. It also means the immediate loss of
the warranty. The manufacturer accepts no liability for damage caused by improper use.
1.3 Disposal
The packaging of the adapter consists exclusively of recyclable materials. Please return
them to the "dual system" sorted accordingly. At the end of its service life, the adapter
must not be disposed of with normal household waste. It must be taken to a collection
point for the recycling of electrical and electronic equipment.
The "dustbin" symbol on the packaging indicates that the materials are recyclable ac-
cording to their labelling. By reusing, recycling or otherwise recovering old appliances,
you are making an important contribution to protecting our environment. Make sure that
electronic waste does not end up in household waste, but is disposed of properly.

9
PRODUCT DESCRIPTION
2 Product Description
The Bluetooth-Adapter is used to connect KEB drive controllers or operators with DIN
66019 interface via Bluetooth connection using the COMBIVIS mobile app or the KEB
Elevator app.
The Bluetooth-Adapter is not a standard Bluetooth-Adapter. It can be used exclusively
forthecommunicationwithKEBdeviceswiththeinterfacespeciedabove.Theadapter
must be plugged directly onto the interface.
2.1 Intended use
The KEB Bluetooth-Adapter is exclusively for operation with KEB drive controllers or
operators. The operation of other electrical consumers is prohibited and can lead to the
destruction of the devices.
The used semiconductors and components of KEB Automation KG are developed and
dimensioned for the use in industrial products. If the product is used in machines, which
work under exceptional conditions or if essential functions, life-supporting measures or
anextraordinarysafetystepmustbefullled,thenecessaryreliabilityandsecuritymust
be ensured by the machine builder.
Operatingourproductsoutsidethelimitsspeciedinthetechnicaldatawillresultinthe
loss of any claims for damages.
2.2 Factory setting
The adapter is delivered with the following settings (factory settings):
Settings Values
Connection interval 8 ms
Slave latency 0
Advertising interval 20 ms
Baud rate (bps) 38400
Data bit 8
Parity No
Stop bit 1
Hardwareowcontrol No
Command mode via "COMMAND:" Yes
Operating mode Peripheral
Device name KEB BLE XXXXXX (LAP BT address)
Transmission power -2 dmb
Table 1: Factory settings

10
PRODUCT DESCRIPTION
2.3 Nameplate
①
②
③
④
⑤
⑥
⑦
⑧
⑨
⑩ ⑪
KEB Automation KG
32683 Barntrup
Made in Germany
Bluetooth-Adapter
Mat.No: 0058060-0060
FCC-Id: 2A2AG-KEB0060
IC-Id:27804-KEB0060
Ser.No.: 207441234
Legend
1Manufactureridentication
2 Device series
3 Material number
4FCCidenticationnumber
5ICidenticationnumber
6 Pairing address
7 Barcode Interleaved 2/5 (serial number)
8 Serial number
9 Country of manufacture
10 CEcertication
11 Disposal note
Figure 1: Nameplate Bluetooth-Adapter

11
HARDWARE
3 Hardware
3.1 Overview Bluetooth-Adapter
Sub-D 9-pole
DIN 66019 (RS 485) /
HSP5 (TTL level)
Top view
Status LED
Figure 2: Overview Bluetooth-Adapter
3.2 Technical data
Application Description
Bluetooth
Frequency / max. transmission power:
Bluetooth 2402-2480 MHz – 8 dBm / 6.3 mW
Empfangsempndlichkeit-87dBm
Connections D-Sub-9 (male)
RS485 standard
Voltage supply Via serial interface
Dimensions 25 x 35 x 88 mm (H x B x L)
Driver software
FTDI (FT232R) serial USB driver at:
(https://www.ftdichip.com/Drivers/VCP.htm)
No Bluetooth driver software required
Max. data rate 115 kbps
Ambient conditions Operatingtemperature:-20˚C...75˚C
Storagetemperature:-30˚C...85˚C
Climatic category (EN60721-3-3) 3K3
Potential isolation Internal potential isolation
Weight in kg 0.3
Table 2: Technical data

12
HARDWARE
3.3 Terminal assignment
The adapter is supplied with power via the serial interface. Input voltage 5...12 V (16 V max).
Pin Designation
=> KEB
control
board
Properties Specication
1 FLASH-TERMINAL In Programming mode
(not for customers)
Reserved
(not wired)
2 TxD Out Transmission signal Not wired
3 RxD In Receive signal Not wired
4 RxD-A In Receive signal negative RS485 half and
full duplex
5 RxD-B In Receive signal positive
6
5V_DIAG_TERMI-
NAL
Power Voltage supply
@ F5 Lift opera-
tor / S6/F6 control
board: 5 V ±20 %
7 0V_TERMINAL Power
Reference potential
RS232 [RS485]
Reference potential
Voltage supply
Reference poten-
tial
8 TxD-A Out Transmission signal
negative RS485 half and
full duplex
9 TxD-B Out Transmission signal
positive
Table 3: Terminal assignment
3.4 Start-up
The Bluetooth-Adapter is visible to the user via the apps and can be paired with them.
After Bluetooth pairing has been carried out with the pairing code shown on the Blue-
tooth-Adapter, the Bluetooth-Adapter is ready for operation.
After successful connection to the KEB drive controller, the user can access the follow-
ing functions, among others:
• COMBIVIS mobile app supports the KEB drive controllers COMBIVERT S6 and
COMBIVERT F6
• KEB Elevator App supports the KEB drive controllers COMBIVERT F5 with Lift Op-
erator
• Dashboard for monitoring of current status values of the drive
• View of the parameter list and parameter values
• Creating and sending backups of the parameter list
• Contact to the KEB Service

13
HARDWARE
3.5 Status LED
State LED
Advertising mode (connectable) Permanently red
Connected (not released) Flashes blue every 300 ms
Connected (release just given) Flashes green every 300 ms (for 5 seconds)
Connected (released) Permanently green
Data transmission (RX/TX active) Flashes yellow every 300 ms
Table 4: Status LED

14
SOFTWARE
4 Software
4.1 COMBIVIS mobile App
Drive controllers perform complex tasks in machines and systems. The scope of func-
tions is constantly growing and requires user-friendly interfaces to be able to manage
them. In addition to the PC tool COMBIVIS 6, a simple and convenient operation of KEB
drive controllers COMBIVERT F6 und S6 can be carried out via the App COMBIVIS mo-
bile. The KEB app enables wireless communication via a smartphone or tablet.
This means that the status information of the drive can be read out easily via a us-
er-friendly interface in order to use it for process monitoring and error diagnosis. The
display and setting of parameters as well as the back-up and restoring of data is also
done via App. For quick support by the worldwide KEB service, the contact details of the
local contact person can be found via a menu item. COMBIVIS mobile is available free
of charge for iOS and Android.
Available on Google Play Store and Apple App Store.
COMBIVIS mobile app in the Google Play Store
https://play.google.com/store/apps/details?id=de.keb.
combivismobile&hl=en
COMBIVIS mobile App in the Apple App Store
https://apps.apple.com/app/combivis-mobile/id1399585561
4.1.1 Functions and features of the COMBIVIS mobile App
• The App supports the drive controllers of the COMBIVERT F6 and S6 series.
• Simple connection via WLAN and Bluetooth 1)
• Diagnosis: Clear dashboard for monitoring current status values of the drive, list of
occurred errors, status of the I/Os, operating history
• View of the parameter list and parameter values
• Writing of parameters
• Creating a parameter favorites list
• Creating and sending backups of the parameter list
• Downloading backups to the drive controller
• O󰀪inescopefunction
• Link to KEB homepage for easy search of product information, technical data, cat-
alogues
• Contact details for the worldwide KEB service (telephone and e-mail)
1) The Bluetooth-Adapter described in this manual is required for the Bluetooth connec-
tion.

15
SOFTWARE
4.1.2 Applications of the COMBIVIS mobile App
Ambient conditions:
• Industrial environment, production, machinery
• Lift applications / elevator shaft with own KEB Elevator App for COMBIVERT F5
drive controller
4.1.3 Connection setup
The adapter is displayed in the COMBIVIS mobile App if it is not connected to another
mobile device. To use the adapter in the App, a key is required, which can be found on
the housing. The connection setup is automated in the App and the user is prompted
to enter the key in the correct place if necessary. Internally, the procedure is as follows:
The connection setup from the Bluetooth-Adapter to the COMBIVIS mobile App works
via the "Just Works" method. This means that no key is required by the Bluetooth sys-
tem. There is no Bluetooth bonding. Encryption that goes beyond the normal mecha-
nisms of Bluetooth is not necessary.
AfterBluetoothpairingisperformed,theadapterexpectswritingofadenedwrite-only
GATT characteristic with a key value. The value can be found on the housing of the
adapter. The key is numeric and 6 characters long.
Until the correct key has been written, all other GATT Write Requests are answered with
an error and otherwise ignored. If the correct key is not written within 30 seconds, the
adapter terminates the Bluetooth connection.
After the correct key has been written, the adapter is ready for normal use. Further write
requests on the key characteristic are ignored. This shifts the entry of the key from the
operating system to the App.
The adapter does not store any coupling info, the KEB App stores the key for the adapter
(no BLE bonding). Data transmission is not encrypted at Bluetooth level.

16
SOFTWARE
4.1.4 Application examples of the COMBIVIS mobile App
Figure 3: Contact details service
Figure 4: Connection menu

17
SOFTWARE
Figure 5: Dashboard: Data Figure 6: Dashboard: Error
Figure 7: Dashboard: I/O Figure 8: Dashboard: Favourites

18
SOFTWARE
Figure 9: Parameter menu Figure 10: Parameter group
Figure 11: Parameter selected Figure 12: Parameter "Edit mode“

19
SOFTWARE
Figure 13: Create Backup le para-
meter list
Figure 14: Create Backup 1/2
Figure 15: Create Backup 2/2 Figure 16: Download Backup

20
SOFTWARE
Figure 17: Settings Oine Scope Figure 18: Oine Scope Recording
Figure 19: Created File Oine
Scope
Figure 20: Recorded Data Oine
Scope
