KEECOON KC-MH-J008 User manual
KC-MH-J008
Cool Mist
Ultrasonic Humidifier
User's Guide
Thanks for your purchase.
We provide a one-year warranty.
If any quality issues,
replacement or refund is available.
Please feel free to contact us via E-mail:
Precautions
Thank you for purchasing our humidifier KC-MH-J008.
Please read this manual carefully before using
and keep it for future reference.
All pictures shown are for illustration purposes only.
Actual products may vary due to product enhancement.
Safety Guide
Components
Placement
Installation
Water filling& Use of Essential Oil
Control Panel& Remote Control
Maintenance
FAQ
Product Specification
Warranty
1-2
3
4
5-6
7
8-9
10-11
12-13
14
15
0101
Safety Guide
0101
01010101
Do not disassemble or modify the machine.
Do not subject the machine to strong impacts.
Turn off the machine before moving it.
Do not connect the machine to a socket that exceeds the rated voltage or use an
extension cable, as this may cause fire or electric shock.
If the plug or wire becomes abnormally hot, stop using the machine immediately.
Do not unplug the power plug with wet hands, as this may cause electric shock or injury.
Do not use acidic detergents in the main body, as they may produce toxic gas.
Children should use the machine under adult supervision.
When the machine is not in use for more than 24 hours, please pour out the water from
the water tank and main body to prevent mold or impurities from harming your health.
Before the first use, leave the machine at room temperature for 30 minutes to avoid
damage to the water tank due to sudden temperature changes.
Do not put essential oil into the main body or water tank, as this may cause water
leakage, deformation or failure.
Do not block the outlet or add water to the mist outlet, as this may cause water leakage,
deformation or failure.
Do not block the outlet or add water to the mist outlet, as this may cause water leakage,
deformation or failure.
Keep a safe distance when the humidifier is spraying mist, especially if you have a
sensitive respiratory tract.
02
Safety Guide
02
02
Use the machine at normal room temperature, which ranges from 5°C to 40°C.
When the room temperature drops below 0°C, please pour out the water in the water
tank and sink to avoid freezing and damaging the machine.
Note: The above safety guide is for your reference only. Please read the user manual
carefully before using the machine. If you have any questions, please contact customer
service.
Remote Control Misting Nozzle
Extended Tube
Components
03
Cover
Main Body
Water Pipe
Pump Connector
Tank Handle
LED
Display
Fan Outlet
Main Body
Water Outlet Stopper
Water Inlet
Float
2 Atomizers
Mist Outlet
Water
Tank
Essential
Oil Tray
Water Pump
Cleaning Sponge
Power Cord
Place the humidifier in a horizontal position that is more than 20 cm away from walls,
furniture, household appliances, and other objects.
Do not use the humidifier in the following situations to avoid water leakage, signal
jamming, damage or injury:
In direct sunlight.
On an unstable platform.
In high temperatures, humidity, or dust.
Near the air conditioner, heater, or stove.
Under tables, or on the carpets, bedding,
etc.
Near the radio and other objects that emit
radio waves.
Near mobile phones, computers, and other
precision instruments.
Placement
04
3.Remove the protective bag from the water
pump before using the machine.
4.Properly place the main body on top of
the water tank.
1.Take the main body out of the packaging
and remove the remote control and other
accessories from the water tank.
2.Before using the remote, please purchase
and install batteries. For the safety of
long-distance transportation, the remote
control is not equipped with batteries.
Installation
05
Note:
If the water pump fails to pump water, please try disassembling it along with the water pipe
and then reinstalling them.
To remove the pump, turn the connector counterclockwise, and to reinstall it, turn the
connector clockwise.
5.Install the misting nozzle and extended tube as you like.
Installation
06
Water Filling& Use of Essential Oil
07
Open the cover and add water from
the top.
Add water from the water tank.
Add water below 40°C to the water tank.
Do not exceed the max water line.
Do not let the water into the mist outlet to avoid
machine failure.
Do not add mineral water, plasma water, or tap
water that has been left for a long time. If mold
or impurities breed, it may cause health
problems.
When the water level is low, the machine will
prompt for water shortage and shut down
automatically. Refill the water and turn it back on.
Place a tissue or sponge underneath before
adding essential oil.
Do not put essential oil directly into the water
tank or sink, as it may cause water leakage,
deformation or failure.
To use essential oils, click on the tray on the
back of the machine, and it will pop out.
Control Panel& Remote Control
08
The control panel and remote control allow you to operate the humidifier with ease.
Here is a breakdown of the various functions:
Relative Humidity(RH)
Percentage Indicator
Mist Level Button
Mist Level Indicator
Temperature Indicator
Power Indicator
Power Button
Timer Indicator Water Shortage Indicator
Child Lock Indicator
Child Lock Button
Timer Button /
Sleep Mode Button
Humidity Set Indicator
Interval Mist Function
Button
Interval Mist
Function Indicator
Humidity Setting
Button
RH
%
Power Child Lock
Humidity
Interval Mist Max-Min
Timer/Sleep
℃
℉
09
The operation of remote control is the same as the control panel.(except childlock).
Please install batteries before using remote.
The display will dim automatically if no operation.
Control Panel& Remote Control
This button turns on the humidifier when pressed. The display will light
up, and the humidifier will start working.
This button allows you to set the humidity level between 40-90% in
increments of 5%. The humidifier will automatically stop spraying mist
when the surrounding humidity reaches the set value.Long press the
button can change the display between ℃ and ℉
This button lets you set the timer for the humidifier to shut down
automatically after 1-12 hours. Each touch increases the timer by
1 hour.
This button adjusts the mist volume in three levels: low, medium, high.
By default, the product starts working at the maximum mist output.
Press this button to activate the intermittent mist function.
It has 3 patterns: P1: Spray 30s then stop 30s.
P2: Spray 60s then stop 60s.
P3: Spray 90s then stop 90s.
Long press the button to enter sleep mode, and the display will shut off,
and humidifier keep working.
Long press the button on the panel or press the button on the remote to
activate the childlock function and do the same action to turn it off.
Timer
Max-Min
Interval Mist
Humidity
Sleep
Child Lock
Power
External
Water Sink& tank
Maintenance
Clean the external surface of the humidifier 1-2 times a week using
a clean cloth to remove dust and dirt.
If the dirt is stubborn, soak the cloth in a neutral detergent before
wiping.
Make sure the main body is completely dry before use.
Clean the water sink and tank 1-2 times a week as water can
cause minerals and organic matter to accumulate, affecting the
function of the humidifier.
Use a soft cloth or brush to clean the internal surfaces of the sink
and tank.
For stubborn dirt, soak the cloth in white vinegar or baking soda
before wiping.
10
Maintenance
Water Pump
If you notice sediment in the water pipe, you can clean it using a slim brush or contact our
customer service to request a replacement. Follow these steps to clean or replace the
water pipe:
1. Unplug the water pipe from the humidifier.
2. Clean the water pipe using a slim brush, or replace it if necessary.
3. Reinstall the water pipe by plugging it back into the humidifier.
4. If the water pipe is too long, you can cut it to a suitable length before reinstalling it.
Note:
Always disconnect the power plug before performing any maintenance on the humidifier.
Do not directly flush the whole machine with water as this can cause short circuit and failure.
Use mild detergent and make sure to remove any residue to avoid harm to health.
If the humidifier will not be used for more than 24 hours, pour out the water from the tank
and sink to avoid mold or impurities that may be harmful to health.
11
① ② ③ ④
Q：Why doesn't the display light up after turning on the power?
A：It's possible that water has entered the circuit board. Air-dry the main body for one
day. If it still can't be turned on, please contact customer service via email.
Q：Why is the mist output low?
Q：Why is there abnormal noise?
A：There may be too little water in the tank or the humidifier may not be on a stable
surface. Please fill the water and place the humidifier on a flat and stable surface.
Q：Why is the humidity value not consistent with the room humidity?
A：Ensure the humidity sensor is not blocked or wet. A difference of 5-10 degrees
is within the normal range. If it's not within this range, please contact customer
service via email.
Q：Why is the red light flashing?
FAQ
A：When the ambient humidity exceeds the set value, the machine will
automatically stop spraying mist. However, if the atomizer is damaged, please
contact customer service via email.
A：Open the sink and check whether the water can be pumped up.
If not, disassemble the water pump and water pipe and install them again
(see page 6). If neither of these is the issue, please contact customer service
to get replacement pump via email.
12
FAQ
Q：Why is there white powder around the humidifier?
A：Tap water contains minerals that can adhere to objects. Clean the water tank
regularly and keep precision instruments away from the humidifier to avoid
damage.
Q：Why is there scale in the water sink or tank?
A：Tap water contains minerals that can adhere to objects. Clean the water sink
and tank regularly.
Q：Why is the floor wet or there is water around the humidifier?
A：The humidity may be too high or the humidifier may be placed in a non-ventilated
place, causing the mist to not fully evaporate.
Q：Why is the fire on the stove turning red?
Q：Why is there interference with the TV remote control signal?
A：Keep the humidifier 1m away from the TV or other objects that emit radio waves.
A：The composition of tap water can react with the flame, so keep the humidifier
away from the stove.
13
Product Name Ultrasonic Humidifier
Model Number KC-MH-J008
Operation Mode Low Medium High
Max Mist Output 600ml/h
Rated Power 56W
Noise ≤35dB
Coverage Area 1000 sq.ft
Size 39*8.58*8.58 inches
(including extended tube)
G.W. 3.2Kg
Safety Functions
1-12 hours Timer
Waterless auto shut-off
Automatic shutdown when falling
Product Specifications
14
Warranty Period
Our company provides a one-year warranty starting from the date of purchase.
Warranty Requirements
In order to receive warranty service, please follow these steps:
Provide the warranty card and the order number.
Please note that we cannot provide warranty service if you are unable to provide the
above information.
Thank you for choosing our product, and we hope you enjoy using it. If you have any
questions or concerns, please don't hesitate to contact us.
Describe the problems you are experiencing in detail and provide pictures or videos
if possible.
Non-Warranty Policy
The following conditions are not covered by the warranty:
Damage that occurs after the warranty period has expired.
Damage caused by natural disasters or other force majeure events.
Any damage caused by use that does not follow the requirements outlined in the
User Manual.
Failure or damage caused by the forced use of the product.
The user disassembles or repairs the product without authorization.
Warranty
If you need to return the product, please make sure that it is intact and that
the packaging boxes and accessories are complete.
15
Table of contents
Other KEECOON Humidifier manuals
