MCB1750 Evaluation Board
The Keil CB1750 Evaluation Board introduces
the new NXP LPC1750 family of AR Cortex- 3
processor-based devices, allowing you to create
and test working programs for this advanced
architecture. The CB1750 has a wide range of
interfaces making it a great starting point for
your next Cortex- 3 project.
MCB1750 Features

100 Hz LPC1758 AR Cortex™- 3
processor-based CU in 80-pin LQFP
 On-Chip emory: 512KB Flash & 64KB RA
 Color QVGA TFT LCD

10/100 Ethernet Port
 USB 2.0 Full Speed - USB, USB-OTG, & USB Host
 2 CAN Interfaces
 2 Serial Ports

SD/ C Card Interface
 5-position Joystick and push-button
 Analog Voltage Control for ADC Input

Amplifier and Speaker

52 GPIO pins
 Debug Interface Connectors
 (0.1 inch connector)

(0.05 inch connector)

(0.05 inch connector)
System Requirements
 PC with one available USB port

Windows 2000, XP and Vista

One CD-RO drive
 for high-performance Debug/Download
(optional)
ome Products Events Support
CB1758
Go
Quick Links

Get A Quote
20 pin JTAG
10 pin Cortex debug
20 pin Cortex debug + ET Trace
ULINK family USB-JTAG Adapter
Page
1
of
2
Keil MCB1750 Evaluation Board Overview
6/8/2010
http://www.keil.com/mcb1700/mcb1750.asp

Starter Kit
The CB1750 is also available as a starter kit which includes the
USB-JTAG adapter.
Part numbers are:
 MCB1750: CB1750 Only
 MCB1750UME: CB1750 and
Evaluation Software
The CB1750 Evaluation Board and Starter Kit include the
. These tools help you get started writing programs and
testing the microcontroller and its capabilities. Sample applications that run
on the CB1750 are included.
