NXP Semiconductors MIMXRT1160-EVK User manual

QUICK START GUIDE
MIMXRT1160-EVK
MIMXRT1160-EVK
Evaluation kit for the i.MX RT1160 MCU
600 MHz Arm®Cortex®-M7 and 240 MHz Cortex-M4 cores

2
Figure 1: MIMXRT1160-EVK
Board Front Callouts
ArduinoArduino®®& MC Interface& MC Interface
M.2 SocketM.2 Socket
SD Card SocketSD Card Socket
USB OTG2USB OTG2
USB OTG 1(SDP)USB OTG 1(SDP)
MIMXRT1166MIMXRT1166
Arduino & MC InterfaceArduino & MC Interface
Audio JackAudio Jack
JTAGJTAG JTAG +JTAG +
TraceTrace
10/100M10/100M
ENETENET Camera ModuleCamera Module
ConnectorConnector
BootBoot
SwitchSwitch 10/100/1000M10/100/1000M
ENETENET
Debug USB PortDebug USB Port
SDRAMSDRAM
ResetReset
Power on ResetPower on Reset
5 V DC IN Switch5 V DC IN Switch
Power JumperPower Jumper
5 V DC IN5 V DC IN
CPU Wakeup
Button
CPU ON/OFF
Button Mic
MIC Array
Extension
Octal
Flash
GET TO KNOW THE MIMXRT1160-EVK

3
QUICK START GUIDE MIMXRT1160-EVK
QSPI FlashQSPI Flash
GET TO KNOW THE MIMXRT1160-EVK CONTINUED
Figure 2: MIMXRT1160-EVK
Board Back Callouts
MIPI LCD ConnectorMIPI LCD Connector

www.nxp.com/MIMXRT1160-EVK/startnow
NXP and the NXP logo are trademarks of NXP B.V. All other product or service names are the property of their
respective owners. Arm and Cortex are trademarks or registered trademarks of Arm Limited (or its subsidiaries)
in the US and/or elsewhere. The related technology may be protected by any or all of patents, copyrights,
designs and trade secrets. All rights reserved. © 2021 NXP B.V.
Document Number: IMXRT1160EVKQSG REV 0
Agile Number: 926-47813 Rev A
SUPPORT
Visit www.nxp.com/support for a list of
phone numbers within your region.
WARRANTY
Visit www.nxp.com/warranty for complete
warranty information.
GET STARTED
Download installation
software and documentation
at www.nxp.com/
MIMXRT1160-EVK/startnow.
GETTING STARTED
1. Plug the power adapter wire into the
MIMXRT1160-EVK board 5 V DC IN header
(J43) and switch on 5 V DC IN (SW5).
2. The MIMXRT1160-EVK board comes
preprogrammed with a demo that will initiate
the LED on the board to flash periodically when
plugged in.
3. Explore more out-of-box demos and
download software and tools at
www.nxp.com/MIMXRT1160-EVK/startnow.
Figure 3: MIMXRT1160-EVK
Power Adapter Cable
to 5 V DC IN Header
