Kelvinator MT630K5HPM series User manual

INSTRUCTION MANUAL
Microwave Oven
SAVE THESE INSTRUCTIONS CAREFULLY
Read these instructions carefully before using your
microwave oven, and keep it carefully.
If you follow the instructions, your oven will provide you with
many years of good service.
MODEL: * MT630K5HPM
MADE IN CHINA

Model:
Rated Voltage:
Rated Input Power(Microwave):
Rated Output Power(Microwave):
Rated Input Power(Grill):
Oven Capacity:
Turntable Diameter:
External Dimensions:
Net Weight:
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE
TO EXCESSIVE MICROWAVE ENERGY
(a) Do not attempt to operate this oven with the door open since this can
result in harmful exposure to microwave energy. It is important not to
break or tamper with the safety interlocks.
(b) Do not place any object between the oven front face and the door or allow
soil or cleaner residue to accumulate on sealing surfaces.
(c) WARNING: If the door or door seals are damaged, the oven must not
be operated until it has been repaired by a competent person.
Specifications
30L
315 mm
520
Rated Input Power(Convection):
1450W
900W
1100W
2500W
If the apparatus is not maintained in a good state of cleanliness, its surface could
be degraded and affect the lifespan of the apparatus and lead to a dangerous
situation.
ADDENDUM
210 335 mm
Approx.19.3 kg
2
*
MT630K5HPM
220V~60Hz

IMPORTANT SAFETY INSTRUCTIONS
WARNING To reduce the risk of fire, electric shock, injury to persons
or exposure to excessive microwave oven energy when
using your appliance, follow basic precautions, including
the following:
1. Warning: Liquids and other foods must
not be heated in sealed containers since
they are liable to explode.
2. Warning: It is hazardous for anyone other
than a competent person to carry out any
service or repair operation that involves
the removal of a cover which gives
protection against exposure to microwave
energy.
3. Warning: Only allow children to use the
oven without supervision when adequate
instructions have been given so that the
child is able to use the oven in a safe way
and understand the hazards of improper
use.
4. Warning: When the appliance is operated
in the combination mode, children should
only use the oven under adult supervision
due to the temperatures generated.
(only for grill series)
5. Only use utensils suitable for use in
microwave ovens.
6. The oven should be cleaned regularly and
any food deposits should be removed.
7. Read and follow the specific:"PRECAU-
TIONS TOAVOID POSSIBLE EXPOSURE
TO EXCESSIVE MICROWAVE ENERGY".
8. When heating food in plastic or paper
containers, keep an eye on the oven due
to the possibility of ignition.
9. If smoke is observed, switch off or unplug
the appliance and keep the door closed
in order to stifle any flames.
10. Do not overcook food.
11. Do not use the oven cavity for storage
purposes. Do not store items,
such as bread, cookies, etc. inside the
oven.
12. Remove wire twist-ties and metal handles
from paper or plastic containers/bags
before placing them in the oven.
13. Install or locate this oven only in
accordance with the installation
instructions provided.
14. Eggs in the shell and whole hard-boiled
eggs should not be heated in microwave
ovens since they may explode, even
after microwave heating has ended.
15. Use this appliance only for its intended
uses as described in manual. Do not
use corrosive chemicals or vapors
in this appliance. This oven is especially
designed to heat. It is not designed for
industrial or laboratory use.
16. If the supply cord is damaged, it must
be replaced by the manufacturer, its
service agent or similarly qualified
persons in order to avoid a hazard.
17. Do not store or use this appliance
outdoors.
18. Do not use this oven near water, in a
wet basement or near a swimming
pool.
19. The temperature of accessible surfaces
may be high when the appliance is
operating. The surfaces are liable to get
hot during use. Keep cord away from
heated surface, and do not cover any
events on the oven.
20. Do not let cord hang over edge of table
or counter.
21. Failure to maintain the oven in a clean
condition could lead to deterioration
of the surface that could adversely
affect the life of the appliance and
possibly result in a hazardous situation.
22. The contents of feeding bottles and
baby food jars shall be stirred or shaken
and the temperature checked before
consumption, in order to avoid burns.
3

35.The rear surface of appliance shall be placed against a wall.
23. Microwave heating of beverages can result in delayed eruptive boiling, therefore
care must be taken when handling the container.
24.The appliance is not intended for use by persons (including children) with reduced
physical , sensory or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction concerning use of the appliance
by a person responsible for their safety.
25.Children should be supervised to ensure that they do not play with the appliance.
26.The microwave oven shall not be placed in a cabinet unless it has been tested in a
cabinet.
27.The appliances are not intended to be operated by means of an external timer or
separate remote-control system.
28. WARNING: Ensure that the appliance is switched off before replacing the lamp to avoid
the possibility of electric shock.
29. Accessible parts may become hot during use. Young children should be kept away.
30.Steam cleaner is not to be used.
31. Surface of a storage drawer can get hot.
32. Do not use harsh abrasive cleaners or sharp metal scrapers to clean the oven door
glass since they can scratch the surface, which may result in shattering of the glass.
33. During use the appliance becomes hot. Care should be taken to avoid touching heating
elements inside the oven.
34. Only use the temperature probe recommended for this oven.(for ovens provided with a
facility to use a temperature-sensing probe.)
4

DANGER
Electric Shock Hazard
Touching some of the internal
components can cause serious
personal injury or death. Do not
disassemble this appliance.
WARNING
Electric Shock Hazard
Improper use of the grounding
can result in electric shock. Do
not plug into an outlet until
appliance is properly installed
and grounded.
To Reduce the Risk of Injury to Persons
Grounding Installation
CLEANING
Be sure to unplug the
appliance from the power supply.
1. Clean the inside of the oven after using
with a slightly damp cloth.
2. Clean the accessories in the usual way
in soapy water.
3. The door frame and seal and
neighbouring parts must be cleaned
carefully with a damp cloth when they
are dirty.
1. A short power-supply cord is provided to
reduce the risks resulting from becoming
entangled in or tripping over a longer cord.
2. If a long cord set or extension cord is used:
1)The marked electrical rating of the cord set
or extension cord should be at least as great
as the electrical rating of the appliance.
2)The extension cord must be a grounding-
type 3-wire cord.
3)The long cord should be arranged so that it
will not drape over the counter top or tabletop
where it can be pulled on by children or tripped
over unintentionally.
This appliance must be grounded. In the event of
an electrical short circuit, grounding reduces the
risk of electric shock by providing an escape wire
for the electric current. This appliance is equipped
with a cord having a grounding wire with a
grounding plug. The plug must be plugged into an
outlet that is properly installed and grounded.
Consult a qualified electrician or serviceman if the
grounding instructions are not completely
understood or if doubt exists as to whether the
appliance is properly grounded. If it is necessary
to use an extension cord , use only a 3-wire
extension cord.
5

CAUTION
Personal Injury Hazard
It is hazardous for anyone
other than a compentent person
to carry out any service or repair
operation that involves the removal
of a cover which gives protection
against exposure to microwave
energy.
Utensil Test:
1. Fill a microwave-safe container with 1 cup of cold
water (250ml) along with the utensil in question.
2. Cook on maximum power for 1 minute.
3. Carefully feel the utensil. If the empty utensil is
warm, do not use it for microwave cooking.
4. Do not exceed 1 minute cooking time.
Materials you can use in microwave oven
Utensils Remarks
Aluminum foil Shielding only. Small smooth pieces can be used to cover thin parts of
meat or poultry to prevent overcooking. Arcing can occur if foil is too
close to oven walls. The foil should be at least 1 inch (2.5cm) away from
oven walls.
Follow manufacturer’s instructions. The bottom of browning dish must be
at least 3/16 inch (5mm) above the turntable. Incorrect usage may cause
the turntable to break.
Microwave-safe only. Follow manufacturer's instructions. Do not use
cracked or chipped dishes.
Always remove lid. Use only to heat food until just warm. Most glass jars
are not heat resistant and may break.
Heat-resistant oven glassware only. Make sure there is no metallic trim.
Do not use cracked or chipped dishes.
Follow manufacturer’s instructions. Do not close with metal tie. Make
slits to allow steam to escape.
Use for short–term cooking/warming only. Do not leave oven unattended
while cooking.
Use to cover food for reheating and absorbing fat. Use with supervision
for a short-term cooking only.
Use as a cover to prevent splattering or a wrap for steaming.
Microwave-safe only. Follow the manufacturer’s instructions. Should be
labeled "Microwave Safe". Some plastic containers soften, as the food
inside gets hot. "Boiling bags" and tightly closed plastic bags should be
slit, pierced or vented as directed by package.
Microwave-safe only. Use to cover food during cooking to retain
moisture. Do not allow plastic wrap to touch food.
Thermometers Microwave-safe only (meat and candy thermometers).
Wax paper Use as a cover to prevent splattering and retain moisture.
Browning dish
Glass jars
Glassware
UTENSILS See the instructions on "Materials you can use in
microwave oven or to be avoided in microwave oven."
There may be certain non-metallic utensils that are not
safe to use for microwaving. If in doubt, you can test the
utensil in question following the procedure below.
Oven cooking
bags
Paper plates
and cups
Paper towels
Parchment
paper
Plastic
Plastic wrap
Dinnerware
6

A) Control panel
B) Turntable shaft
C) Turntable ring assembly
D) Glass tray
E) Observation window
F) Door assembly
G) Safety interlock system
Materials to be avoided in microwave oven
Utensils Remarks
Aluminum tray
Food carton with
metal handle
Metal or metal-
trimmed utensils
Metal twist ties
Paper bags
Plastic foam
Wood
F
G
A
C B
ED
SETTING UP YOUR OVEN
Names of Oven Parts and Accessories
Remove the oven and all materials from the carton and oven cavity.
Your oven comes with the following accessories:
Glass tray 1
Turntable ring assembly 1
Instruction Manual 1
Metal shields the food from microwave energy. Metal trim may
cause arcing.
May cause a fire in the oven.
Plastic foam may melt or contaminate the liquid inside when exposed
to high temperature.
Wood will dry out when used in the microwave oven and may split
or crack.
May cause arcing. Transfer food into microwave-safe dish.
May cause arcing. Transfer food into microwave-safe dish.
May cause arcing and could cause a fire in the oven.
Grill Rack( Only for Grill series )
7

Remove all packing material and accessories.
Examine the oven for any damage such as
dents or broken door. Do not install if oven is
damaged.
Countertop Installation Cabinet: Remove any protective film found
on the microwave oven cabinet surface.
Do not remove the light brown Mica cover
that is attached to the oven cavity to
protect the magnetron.
Installation
1. Select a level surface that provide
enough open space for the intake
and/or outlet vents.
A minimum clearance of 3.0 inches
(7.5cm) is required between the oven and
any adjacent walls. One side must be open.
(1) Leave a minimum clearance of 12
inches (30cm) above the oven.
(2) Do not remove the legs from the
bottom of the oven.
(3) Blocking the intake and/or outlet openings
can damage the oven.
(4) Place the oven as far away from
radios and TV as possible.
Operation of microwave oven may
cause interference to your radio or TV
reception.
2. Plug your oven into a standard household
outlet. Be sure the voltage and the
frequency is the same as the voltage
and the frequency on the rating label.
WARNING: Do not install oven over a
range cooktop or other heat-producing
appliance. If installed near or over a heat
source, the oven could be damaged and
the warranty would be void.
Hub (underside)
Glass tray
Turntable ring assembly
3.0 inch(7.5cm)
12 inch(30cm)
OPEN
a. Never place the glass tray upside down. The glass
tray should never be restricted.
b. Both glass tray and turntable ring assembly must
always be used during cooking.
c. All food and containers of food are always placed
on the glass tray for cooking.
d. If glass tray or turntable ring assembly cracks or
breaks, contact your nearest authorized service
center.
Turntable Installation
Turntable shaft
The accessible surface
may be hot during
operation.
GTQ ^QM^ _a^RMOQ [R M\\XUMZOQ _TMXX NQ
\XMOQP MSMUZ_` M cMXX~
8

2. Microwave Cooking
Press " Power Level "several times to select the power you want. Turn " "
to adjust the cooking time. Press " Start/Go " to start cooking.
Example: If you want to use 80% microwave power to cook for 20 minutes, you can
operate the oven as the following steps.
1) Press " Power Level " once, the oven will display "P100".
This microwave oven applies modern electronic control to adjust cooking parameters
to meet your needs better for cooking.
When the microwave oven is electrified,the oven will display "0:00", buzzer will ring once.
2) Turn " " to adjust the hour figures, the input time should be within
0--23(24-hour) or 1--12(12-hour).
3) Press " Clock ", the minute figures will flash.
5) Press " Clock " to finish clock setting. ":" will flash.
Note: 1) If the clock is not set, it would not function when powered.
2) During the process of clock setting, if you press " Stop/Clear ", the oven
will go back to the previous status automatically.
2) Press " Power Level " once again to choose 80% power, the oven will
display "P80".
3) Turn " " to adjust the cooking time until the oven display"20:00"
(The maximum setting time is 95 minutes.)
4) Press " Start/Go " to start cooking, ":" will light.
1) Press " Clock " to choose 12-hour or 24-hour system.
OPERATION INSTRUCTION
NOTE: the step quantities for the adjustment time of the coding switch are as follow:
0---1 minute : 5 seconds
1---5 minutes : 10 seconds
5---10 minutes : 30 seconds
10---30 minutes : 1 minute
30---95 minutes : 5 minutes
4) Turn " " to adjust the minute figures, the input time should be within 0--59.
Presses
Instructions Microwave
Power
Display
1
2
3
4
5
100%
80%
50%
30%
10%
P100
P80
P50
P30
P10
1.Clock Setting
9

3. Convection Cooking(Warm-up)
5. Grill Cooking
4. Convection Cooking(No Warm-up)
1) Press the " Cooking Function " key once to select convection function, and
the oven will display "140"( ).
Turn " " to select convection temperature from "140" to "230" ( ).
4) Press the " Start/Go " key to start cooking.
3) Turn " " to adjust the cooking time. (The maximum setting time is 95 minutes.)
1) Press the " Cooking Function " key once to select convection function, and
the oven will display "140"( ).
Turn " " to select convection temperature from "140" to "230" ( ).
1) Press the " Cooking Function " key once, and the oven will display "140"( ).
Turn " " to select grill function till the oven display "G-1".
3) Press the " Start/Go " key to start warming up. When the preheated
temperature arrives, five minutes later,the buzzer will ring twice to remind you to
put the food into the oven, and then close the door.
4) Turn " " to adjust the cooking time. (The maximum setting time is 95 minutes.)
5) Press the " Start/Go" key to start cooking.
2) Press the " Start/Go " key to confirm.
2) Press the " Start/Go " key to confirm.
2) Press the " Start/Go " key to confirm.
3) Turn " " to adjust the cooking time. (The maximum setting time is 95 minutes.)
4) Press the "Start/ Go " key to start cooking.
The convection cooking can let you to cook the food as a traditional oven. Microwave is not
used. It is recommended that you should preheat the oven to the appropriate temperature
before placing the food in the oven.
Note: a. Cooking time cannot be input until the preheating temperature arrives.
If the temperature arrives, door must be opened to input the cooking time.
b. If the time not input in 5 minutes, the oven will stop preheating. The buzzer
sound five times and turn back to waiting states.
Note:If half the grill time passes, the oven sounds twice to tell you to turn the food over.
You can just leave continue working. But in order to have a better effect of grilling
food, you should turn the food over, close the door, and then press"Start/Go" to
continue cooking. If no operation, the oven will work automatically and sound once.
10

6. Combination Cooking
7. Auto Menu
8. Multi-Stage Cooking
Three stages of cooking can be maximumly set together.If one of the stages is defrosting, it
should be put in the first stage. The buzzer will ring once after each stage and the next stage
will begin.
Note:Auto menu cannot be set as one of the stages of multi-stage cooking
1) Press the " Cooking Function " key once, and the oven will display "140"( ).
Turn " " to select combination function till the oven display "C-1","C-2","C-3" or "C-4".
(2) Cake menu is under convection cooking with 160 -warm-up function,
and you should preheat first following the auto menu operation, when the oven
reaches the temperature, it will stop working and sound to remind opening
the door to put cake in, then press "Start/Go" to start cooking.
1) Turn " " right till the oven display "A1".
Example: If you want to use "Auto Menu" to cook fish of 250g.
2) Press " Start/Go"key to confirm.
4) Turn " " to select the weight of fish till "250" display.
5) Press "Start/Go" key to start cooking.
Example: If you want to cook the food with 100% microwave power for 10 minutes+ 80%
microwave power for 15 minutes. Do it as following:
1) Press "Power Level " once to choose 100% microwave power;
2) Turn " " to adjust the cooking time of 10 minutes;
3) Press "Power Level" twice to choose 80% microwave power;
4) Turn " " to adjust the cooking time of 15 minutes;
5) Press "Start/Go " to start cooking.
Order Microwave
Power Grill
Power
Display
1
2
3
4
Convection
Power
Note: (1) Consult the appendix of the automatic menu procedure.
C-1
C-2
C-3
C-4
3) Turn " " to adjust the cooking time. (The maximum setting time is 95 minutes.)
4) Press the " Start/Go " key to start cooking.
2) Press the " Start/Go " key to confirm.
11

9. Auto Reheat
10. Defrost by Weight
11. Defrost by Time
1) Press "Auto Reheat "key once, the oven will display "h-1".
(press"Auto Reheat " several times to select the varidty of reheating function)
2) Turn " " to select the weight as the chart below.
3) Press " Start/Go" key to start cooking.
1) Press "Defrost " pad once, the oven will display "d-1".
3) Press "Start/Go" key to start defrosting and the surplus cooking time will be
displayed.
2) Turn " " to select the weight of food within the range of 100 to 2000 g
3) Press " Start/Go" key to start defrosting and the surplus cooking time will be
displayed.
1) Press " Defrost " key twice, "d-2" will be displayed.
2) Turn " " to select the defrosting time.The maximum setting time is 95 minutes.
Display
150
250
350
450
600
250
350
450
1
2
3
1
2
3
Function
h-1
(Auto Reheat)
h-2
(Dinner Plate)
h-3
(Beverage/Coffee)
h-4
(Roll/Muffin)
Weight
150g
250g
350g
450g
600g
250g
350g
450g
240g
480g
720g
70g
140g
210g
12

12. Speedy Cooking
13. Pre-set Function
1) Set the clock first. (Consult the instruction of clock setting.)
2) Input the cooking program. Three stagescan be set at most. Defrosting sholuld not
be set here.Please do not press "Start/Go" at the last step.
15. Lock-out Function for Children
Lock: In waiting state, press "Stop/Clear" for 3 seconds, there will be a long "beep"
denoting entering the children-lock state and the locked indicator will light.
Lock quitting: In locked state, press "Stop/Clear" for 3 seconds, there will be a long "beep"
denoting that the lock is released, and the locked indicator will disappear.
16. Cooking End Reminding Function
When cooking ends, there will be 5 "beep" which is reminding the completion of cooking.
17. Display Specification
(1) In waiting state, the oven will display clock and " :" will flash.
(2) In function setting state, the oven will display the related setting.
(3) In the operation and suspending state, the oven will display the residual cooking time.
14. Inquiring Function
(1) During cooking state, press "Power Level" or " Cooking Function" key, the current
power will be displayed for 2-3 seconds. After that, the oven will turn back to the former
state;
(2) In pre-set state, press " Clock " to inquire the time for delay start cooking. The
pre-set time will flash for 2-3 seconds, then the oven will turn back to the clock display.
(3) In cooking state, press "Clock" to inquire the current time.
When the oven is in the waiting states, Press " Start/Go " key to start
cooking food with full microwave power for 30 seconds. The cooking time will add
30 seconds by every press of " Start/Go" key,and the maximum setting
time is 95 minutes.
Note: Be invalidation under the situation of Defrost, Auto menu and Multi-stage cooking.
3) Press " Clock " to display the current time, and hour figures will flash.
5) Press " Clock ", the minute figures will flash.
6) Turn " " to adjust the minute figures, the input time should
be within 0--59.
7) Press " Start/Go " to finish setting, and ":" will stop flashing.
buzzer will ring twice when the time arrives, then cooking will start automatically.
4) Turn " " to adjust the hour figures, the input time should be within
0--23(24-hour) or 1--12(12-hour).
13

appendix of the automatic menu procedure
Cook
Display Cook
Display Cook
Display Cook
Menu Weight Display
A1
A2
A3
A4
A5
A6
A7
A8
A9
A10
Fish
Soup
Meat
Bread
Pizza
Cake
Pasta
Roast
Chicken
Vegetable
Potato
Display
A1
Fish
A2
Soup
A3
Meat
A4
Bread
A5
Pizza
A6 Cake
A7
Pasta
A8
Roast Chicken
A9
Vegetable
A10
Potato
150
250
350
450
650
200
400
600
150
300
450
600
50
100
150
200
300
400
475
50
100
150
500
750
1000
1200
150
350
500
1
2
3
150 g
250 g
350 g
450 g
650 g
200 ml
400 ml
600 ml
150 g
300 g
450 g
600 g
50 g
100 g
150 g
200 g
300 g
400 g
475 g
50(with water 450 g)
100(with water 800 g)
150(with water 1200 g)
500 g
750 g
1000 g
1200 g
150 g
350 g
500 g
1(about 230 g)
2(about 460 g)
3(about 690 g)
14

Trouble shooting
According to Waste of Electrical and Electronic Equipment
(WEEE) directive, WEEE should be separately collected and
treated. If at any time in future you need to dispose of this
product please do NOT dispose of this product with household
waste. Please send this product to WEEE collecting points
where available.
It is forbidden to run the unit without any food inside.
It is very dangerous.
15
