Ken A Vision Vision 4 VFCD40 User manual

Applied VisionTM 4 Software
Instruction Manual
VFCD40

2

3
Thank you for your purchase.
This guide provides basic information about installing and using Applied
VisionTM 4 Software. You can also find this guide on the Ken-A-Vision® web
site www.ken-a-vision.com/resources.
Introduction to Applied VisionTM Software
Applied Vision 4 (AV4) is a software program designed to enhance the use of
Ken-A-Vision digital imaging products.
Applied Vision enables users to connect their USB-based Ken-A-Vision
products to their computer, allowing capturing, viewing, and manipulation of
both video and still images. Applied Vision 4 is optimized for utilization in a
classroom setting while remaining widely applicable for any environment in
which digital imaging is required.
Here are a few of the features built into Applied Vision:
• Cross-platform support for Windows, Mac, and Linux
• Full screen viewing
• Video recording
• Still image capture
• Multiple camera support
• Advanced image editing and analysis
• Time lapse recording
• Video rotation
• Digitalzoom
• Numerous science applications including calibrated measurement

4
Installation
Minimum Requirements
o Windows XP SP2 or higher, Windows Vista
o 512MB RAM
o USB 2.0
Installation Instructions
Insert the software disc into your disc drive, and the installer will launch via
AutoPlay. If your camera requires drivers, it will choose to install these by
default as well. Follow the prompts, and at the end if you are prompted to
reboot, do so. When finished, plug in your camera; depending on the model,
it may automatically install the driver in a matter of seconds, or a "Found New
Hardware" wizard may appear. If the latter, click through the default selections
to automatically install the device drivers for your camera.
Automatic Updates
Applied Vision 4 has an automatic update feature that will query Ken-A-Vision
for newer versions of the software. You can adjust the settings or operate this
update checker manually with options in the Help menu.
Applied Vision 3 Software
Temporarily we are including, for your convenience, our previous software
Applied Vision 3 (AV3) for those who prefer its simpler functions and interface.
The installer file can be accessed by browsing the "AV3" folder on the CD and
running AV3Install.exe stored in that directory.
Mac Software
If your camera is a model that is compatible with Mac OSX, we have included
a "Mac Software" directory on your software disc from which you can install
Ken-A-Vision Capture 1.3.2, our current imaging software for OSX. Check
our website (http://www.ken-a-vision.com) frequently for the upcoming release
of Applied Vision 4 for Mac OSX which will bring the advanced features of
Applied Vision to the Mac platform.

5
Interface Description
Applied Vision 4 creates a unique window for each active video device and
each captured image or movie.
There are three styles of windows:
Camera Window - Live streaming video from the USB camera device.
Image Window - A still image captured from the video stream or loaded
from a saved file.
Video Window - A movie captured from the camera or loaded from a saved
file.
When Applied Vision launches, the primary window opens, and then camera
windows are opened for any available imaging devices.

6
Main Applied Vision Window
The main Applied Vision window is the parent window for the application. If
you close this window, it will close all Applied Vision windows and the
application.
At the top of the window is a menu bar:
• File
o Properties - Set various program properties such as the localized
language of choice
o Exit - Exit the Applied Vision application
• Cameras
o A dynamically populated list of all available imaging devices on
your system
o Refresh Device List
• Snapshots
o A list of all captured snapshot images, which can be clicked on to
save to disk
• Advanced
o Advanced Image Functions - Launch a separate window for the
Advanced Image Functions
o Image Comparison - Open the Image Comparison window
which allows the user to layer one image over another
•Help
o Help Topics - the help file for Applied Vision 4
o Update Options - sets options related to Applied Vision 4's ability
to check for new software updates
o Check for Updates - checks the Internet for updates to Applied
Vision 4 and, with the user's permission, installs updates
o About - Applied Vision 4 information
Below the title bar are two buttons:
•Open Image - Open a still image previously saved on the computer
•Open Video - Open a video file previously saved on the computer

7
Camera Window
The Camera Window displays the real-time live video stream being transmitted
by the connected video device. It may be resized, moved, maximized,
minimized, or closed.
At the bottom of the window is a tabbed toolbar. It has four tabs:
• Camera Options (default)
•Rotate
•ColorBalance
•Zoom
Camera: Video Options Toolbar
This toolbar is the default toolbar setting of a Camera window. The following
commonly used features are included:
• Fullscreen - Stretch the video stream to fill the entire screen. To exit this
mode, click the "X" button in the upper right corner of the screen.
• Take Snapshot - Capture a still image frame from the video stream,
and open the captured image up in a new Image window.
• Record - Select a location and filename to record to, and start
capturing video to a saved movie file. Click the button again to stop the
recording process.
• Time-Lapse Record - Enter a time value in seconds and then select a
location to save the files. Applied Vision 4 will take a snapshot once
every number of seconds specified by the user.
• Document Orientation - Flip and mirrors the current video. Useful
when documents are placed under the camera and appear "upside
down".
• Camera Resolution - Change the display resolution of the camera.
High resolutions have superior image quality but lower frame rates.
Lower resolutions have superior frame rates but lower image quality.

8
Camera: Rotate Toolbar
This toolbar offers several options for rotating and manipulating the video
stream:
• Rotate Counterclockwise - Left
• Rotate Clockwise - Right
• FlipHorizontal
• Flip Vertical
Camera: Color Balance Toolbar
This toolbar allows adjustment of the following settings affecting the video
stream:
• Brightness
• Contrast
• Saturation
To reset these to their original values, click Reset Defaults.
Camera: Zoom Toolbar
This toolbar allows digital zooming on the video stream. There are three
modes:
•Original Size - Display video without scaling.
•Fit to Window - Scale the image to fit in the window size; this is the
default.
•Custom Zoom - Allow for a manual configuration of digital zooming.
When Custom Zoom is enabled, the slider bar at right can be utilized to
change the zoom factor. Note, that as digital zoom increases, the image will
progressively pixelate. To return to normal settings, click Fit to Window.

9
Image Window
The image window displays a still image captured from a video device or
opened from a file. It may be resized, moved, maximized, minimized, or
closed. At the bottom of the window is a tabbed toolbar. It has six tabs:
• General (default)
• Measure
• Zoom
• Rotate
• Drawing
•Comparison
Image: General Toolbar
This toolbar is the default toolbar setting of an Image window. The following
commonly used features are included:
• Open Image - Open a saved image file in a new Image window.
• Save Image - Save the image to its current filename and location (if
unsaved, Save Image As).
• Save Image As - Save the image with a specified filename and
location.

10
Image: Measure Toolbar
This toolbar provides the following tools for measurement and analysis:
•Measurement Type
o Linear Measurement - Measure a straight line.
o Angular Measurement - Measure an angle.
•Calibration - Create a new scale measurement standard.
•Select/Remove Scale
o Select Saved Scales - Choose a saved scale with which to measure.
o Remove Saved Scales - Remove a previously saved scale.
•Perform Measurement - Show the results of the current measurement
relative to the selected scale.
•Copy All Measurements to Clipboard - Add contents of the Mea-
surement window to the clipboard for pasting into other programs.
Calibration
To calibrate a new scale, follow these instructions:
1. First ensure Measurement Type is set to Linear Measurement.
2. Click Calibration
a. If an existing line is on the image, Applied Vision 4 will prompt you
to either use the existing line or draw a new one for the purpose of
identifying a known distance that can be used to calibrate a
measurement scale. Multiple measurement scales are useful
when measuring objects viewed through a microscope under
different objectives.
3. Type a full name for the scale under Name.
4. The Distance in Pixels should be preset according to the line drawn in
step 2.
5. Type the amount of actual units measured by the line in Known
Distance.
6. Enter an abbreviated unit name under Unit of Length.
7. Click OK.
Now the new scale will be selected by default and new measurements will be
computed using that scale.

11
Image: Zoom Toolbar
This toolbar allows manipulation of the image with the following tools:
•Zoom - Zoom in and out on the image. Left click on a point on the
image to zoom in, right click to zoom out.
•Reset Zoom - Reset the zoom function to the default, fitting the image to
the window.
•Display as Original Size - Resizes the window and displays the image
in its original size, without scaling (e.g. at a 1:1 pixel ratio).
Image: Rotate Toolbar
This toolbar allows manipulation of the image with the following tools:
•Rotate Counterclockwise - Rotate the image 90 degrees
counterclockwise.
•Rotate Clockwise - Rotate the image 90 degrees clockwise.
•Custom Rotation
o Flip Vertically - Flip the image vertically.
o Flip Horizontally - Flip the image horizontally.
o Custom Rotation - Rotate the image at a specified number of degrees.

12
Image: Drawing Toolbar
This toolbar offers markup, annotation, and drawing tools for editing images.
•Arrow - Click and drag on the image to draw a directional linear arrow.
•Text - Click anywhere within the image to create a text field. Click and
drag to move the location of the field. Text can be entered and a new line
can be inserted by typing Ctrl + Enter. Hitting the Enter key will draw the
entered text onto the image.
•Pencil - A single pixel (by default) drawing tool.
•Paintbrush - A 10 pixel (by default) drawing tool.
•Spray Can - A spraypaint-style drawing tool.
•Color Picker - Click to set color for the above tools.
•Settings
o Set Line Width
o Set Text Options
o Set Pencil Tool Options
o Set Paintbrush Tool Options
o Set Spray Can Tool Options
Image: Comparison Toolbar
This toolbar opens the Image Comparison window and loads the selected
image into either the top or bottom slot for variable opacity image blending
and comparison.

13
Video Window
The Video Window allows the user to playback recorded video and audio files
created using Applied Vision 4. This window has two tabs that contain control
buttons: Playback and Options.
The Playback tab has Stop and Play / Pause buttons. These buttons
control the basic playback of the recorded video file. There is also a slider
control that allows the user to move to a specific section of the video by
clicking or dragging the slider bar to a given location.
The Options tab has buttons that allow you to open another Video file, take
the current video being played to fullscreen mode or Take A Snapshot from
the movie that is currently being played back.
Advanced Image Functions
The Advanced Image Functions contain a large assortment of tools for
annotation and analysis. It can be launched from either the main Applied
Vision window. For detailed help on these functions, see the Help menu under
the Advanced Image Functions menu bar.

Image Comparison
Images can be loaded for comparison in two ways:
1. In the main Applied Vision 4 window, click on the Advanced menu
and select Image Comparison. Click on either the Open Top
Image or Open Bottom Image buttons to open existing images for
comparison.
2. Select an open Camera Window. Click the Take Snapshot button.
Click on the Comparison tab. Click on either Set Top Image for
Comparison to add this image to the Comparison window in the top
layer or Set Bottom Image for Comparison to add this image to
the Comparison window in the bottom layer.
Aligning the Image:
Once images have been opened in the Image Comparison window, they may
be aligned using the mouse. In the Align section of the Image Comparison
window, select either the Top Image or Bottom Image and then click and
drag with the mouse to move the image and thus changes its alignment
relative to the other image in the window. Click the Reset Alignment button
to align both images to the upper left hand corner of the window.
Setting the Opacity:
Move the slider bar under the Blend / Transparency Ratio section to
determine the opacity or transparency of the top and bottom images.
Saving Output:
Click Save Blended Image if you want to save the current comparison to
an image file.

15

5615 Raytown Road • Kansas City, MO 64133 U.S.A.
Tel.: [phone] • Fax: [phone]
email:[e-mail] • www.ken-a-vision.com
INS-AV4
Troubleshooting
For technical support please visit our website for troubleshooting guides,
downloads, and technical support request forms:
http://www.ken-a-vision.com/techsupport.asp
You can also call our offices toll-free 1-800-627-1953 for technical support.
Ken-A-Vision reserves the right to make design improvements and other changes in accordance with the
latest technology. There is no obligation to make changes in products already manufactured. Patents
Pending Copyright 2009 Ken-A-Vision Corporation
