3. Removepanelsandsetpanelsasideonacoveredsurface.
4. Checkthatgroundingclipisattachedtothelowerpanel.
5.
Lower
panel
clip
Slide nut and ferrule onto tubing.
Copper tubing only: Slide nut, then ferrule, about 1" (2.5 cm)
onto copper tubing.
NOTE: To avoid vibration during operation, route the water
supply line so that it does not touch the dishwasher base, frame
or motor.
6. Add 90 ° elbow fitting to the water supply line.
Connect the 3/8" compression fitting to the water supply line
prior to installing the unit into the cabinet opening. Attach such
that the 3/4" connection is facing upward.
Copper tubing only: Put the tubing into the 90 ° elbow fitting as
far as it will go (the copper tubing bends and kinks easily).
Slide the nut and ferrule forward and start the nut onto the
elbow threads. Flexible braided connection: Secure nut to
elbow using 5/8" open ended wrench or adjustable wrench.
NOTE: Do not use Teflon_tape with compression fittings.
Remove terminal box cover.
- If you are direct wiring: Install a UL Listed/CSA Approved
clamp connector to the terminal box. If using conduit, use a
UL Listed/CSA Approved strain relief.
- If you are installing a power supply cord kit, do so now,
following kit instructions. The power supply cord kit must be
UL Listed and marked for use with dishwashers (that is, Power
Supply Cord Kit Part Number 4317824).
8°
.Terminal
I....................................................................................-_ box cover
_'_/ @' _ Cable clamp
connector
Dishwasher wires
Measure height of cabinet opening
from underside of countertop to
floor where dishwasher will be
installed (you need the lowest
point). Check chart for that height
opening. Put wheels in the required
position.
9°
Minimum Wheel Number of
turns on
cutout height position front leg
34" (86.4cm) 1 10
341/4"(87 cm) 2 5
341/2" (87.6 cm) 3 O
Turn both front leveler legs to the same
height.
If the minimum cutout height is less than 34"
(86.4 cm), the rear wheels can be removed
for additional clearance. This will allow the
dishwasher to fit into a 337/8'' (86 cm) high
cutout, but the dishwasher will be more
difficult to move into position. If the wheels Front leg
are removed, cover the floor when moving the dishwasher.
If you have built-upfloors
1.
2.
3°
Measure height of opening
from underside of countertop
to built-up floor. If the height
is at least 333/4" (85.7 cm),
the dishwasher will fit into the
opening without modification
to the countertop or flooring.
Put wheels in position 1 and
turn the front leveler legs up
all the way.
Add shims as needed in the
area shown to bring
dishwasher up to proper height.
/Countertop
33%"
(85.7 cra)
rain,
/ up
NOTE: Shims must be securely attached to the floor to keep
them from moving when the dishwasher is operating.
t®Teflon is a registered trademark of E.I. Du Pont de Nemours and Company.
10
