Use and Care Guide
®
LiquidPropaneGasGrill withinfraredCooking System
Sears ModelNo. 4t5.t6650900
This Grill isfor Outdoor Use Only : i i ¸¸¸¸¸!:L : !_i_i!i!ii,¸¸
•Read and follow all Safety, Assembly,
and Use and Care instructions in this
Guide before assemblingand cooking
with this grill.
•Failure to follow all instructions in this
Use and Care Guide may lead to fire or
explosion, which could result in property
damage, personal injuryor death.
• Safety
• Parts
• Use and Care
• Assembly
Assembly Questions?
Call t-800-241-7548
Tools needed for assembly:
Adjustable wrench (not provided)
Screwdriver (not provided)
7/16" Combinationwrench (not provided)
SAVETHESEINSTRUCTIONS!
Sears, Roebuck and Co., Hoffman Estates, IL 60179
©2008Sears,RoebuckandCo., AllRightsReserved Printedin China
U.S.A.
464222209,80019045,11-18-08

ifyou smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. Open lid.
4. if odor continues, keep away from the appliance
and immediately call your gas supplier or your
fire department.
1. Do not store or use gasoline or other
flammable liquids or vapors in the vicinity of
this or any other appliance.
2. An LP Tank not connected for use shall not
be stored in the vicinity of this or any other
appliance.
Call Grill Service Center For Help And Parts
If you havequestions or need assistance during assembly,
please call 1-800-241-7548. You wilt be speaking to a
representative ofthe grill manufacturerand not a Sears
employee. Toorder new parts call Sears at 1-800-4-MY-HOME®.
Product Record
IMPORTANT:Fillouttheproductrecordinformationbelow.
Model Number
Serial Number
Date Purchased
Seeratinglabelongrillforserialnumber.
To InstalledAssembler: Leave these instructionswith
consumer.
To Consumer: Keep this manual for future reference.
CAUT,o. YK
CALIFORNIA PROPOSiTiON 65
1. Combustion by-products produced when using
this product contain chemicals known to the State of
California to cause cancer, birth defects, and other
reproductive harm.
2. This product contains chemicals, including lead
and lead compounds, known to the State of
California to cause cancer, birth defects or other
reproductive harm.
Wash your hands after handling this product.
installation Safety Precautions
•Use grill, as purchased, only with LP (propane) gas and the
regulator/valve assembly supplied.
• Grill installation must conform with local codes, or in the
absence of local codes, with either the National Fuel Gas
Code,ANSI Z223.1/NFPA 54, Natural Gas and Propane
Installation Code, CSAB149.1, or Propane Storage and
Handling Code, B149.2, or the Standardfor Recreational
Vehicles,ANSI A 119.2/NFPA1192,and CSAZ240 RV Series,
Recreational VehicleCode, as applicable.
• All electrical accessories (such as rotisserie) must be
electrically grounded in accordance with local codes, or
National Electrical Code,ANSI / NFPA 70or Canadian
Electrical Code, CSA C22.1. Keep any electrical cords and/or
fuel supply hoses away from any hot surfaces.
• Grill is not for use in or on recreational vehicles and/or boats.
• This grill issafety certified for use in the United States and/or
Canada only. Donot modify for use in any other location.
Modification wilt result in a safety hazard.
Safety Symbols
The symbols and boxes shown below explain what each heading
means. Read and follow all of the messages found throughout
the manual.
DANGER: Indicates an imminently hazardous situation
which, if notavoided, will result in death or serious injury,
,Some parts may contain sharp edges,
especially as noted in these instructions.
Wear protective gloves if necessary.
CAUTION
For residential use only. Do not use for commercial
cooking.
2" 464222209
WARNING: Be alert to the possibility of serious bodily injury
if the instructions are not followed. Be sureto read and
carefully follow all of the messages.
CAUTION
CAUTION: Indicates a potentially hazardous situation which,
if notavoided, may result in minoror moderate injury,

ForYourSafety.................................2
GrillServiceCenter...........................2
ProductRecordInformation..............2
SafetySymbols.................................2
InstallationSafetyPrecautions..........2
KenmoreEliteGrillWarranty............3
UseandCare...................................4-13
PartsList..........................................14
PartsDiagram..................................15
Assembly.......................................16-27
Troubleshooting.............................28-30
RepairProtection Agreements
Congratulations on making a smart purchase. Your new
Kenmore® product is designed and manufactured for years of
dependable operation. Butlike all products, it may require repair
from time to time. That's when having a Repair Protection
Agreement can save you money and aggravation.
Here's what the Repair Protection Agreement* includes:
[] Expert service byour 10,000professional repair specialists
[] Unlimited service and no chargefor parts and labor on all
covered repairs
[] Product replacement up to $1500 if your covered product
can't be fixed
[] Discount of 10% from regular price of service and related
installed parts not covered by the agreement; also, 10% off
regular priceof preventive maintenance check
[] Fast help by phone - we call it Rapid Resolution -
phone support from a Sears representative. Think of us
as a "talkingowner's manual."
Once you purchase the Repair ProtectionAgreement, a
simple phonecall is all that it takes for you to schedule service.
You can call anytime day or night, or schedule a service
appointment online.
The Repair ProtectionAgreement is a risk-free purchase. If
you cancel for any reasonduring the product warranty period,
we will provide a full refund. Or, a prorated refund anytime after
the product warranty period expires. Purchase your Repair
ProtectionAgreement today!
Some limitations and exclusions apply. For prices and
additional information inthe U.S.A. call 1-800-827-6655.
*Coverage in Canada varies on some items. For full details
call Sears Canada at 1-800-361-6665.
Sears Installation Service
For Sears professional installation of home appliances, garage
door openers, water heaters,and other major home items, in the
U.S.A. or Canada call 1-800-4-MY-HOME®.
KENMORE GRILL WARRANTY
One Year Full Warranty on Kenmore Grill
If this grill fails due to a defect in material or workmanship
within one yearfrom the date of purchase, call 1-800-4-MY-
HOME®to arrange for free repair (or replacement if repair
proves impossible).
Ten-Year Limited Warranty on Burners
For ten years from the date of purchase, any burner that
rusts throughwill be replaced free of charge.After the first
year from the date of purchase, you payfor labor if you wish
to have it installed.
All warranty coverage excludes ignitor batteries and grill part
paint loss, discoloration or rusting, which are either
expendable parts that can wear out from normal usewithin
the warranty period, or are conditions that can be the result
of normal use, accident or improper maintenance.
All warranty coverage is void if this grill is ever used for
commercial or rental purposes.
All warranty coverage applies only if this grill is used in the
United States.
This warranty gives you specific legal rights, and you may
also haveother rights which vary from state to state.
Sears, Roebuck and Co., Hoffman Estates, IL 60179
Dual FueFMand SureFireTM are registered trademarks of
the W. C. Bradley Company and used,with permission,
by Sears Holding Corporation. All rights reserved.
464222209.3

•NEVERstore aspare LP cylinder under or near the
appliance or in an enclosed area.
• Never fill a cylinder beyond 80%full.
• If the information in two points above is not
followed exactly, afire causing death or serious
injury may occur.
• An over filled or improperlystored cylinder isa
hazard due to possible gas release from the safety
relief valve. This could cause an intense fire with
risk of property damage, serious injury or death.
• If you see, smell or hear gas escaping, immediately
get away from the LP cylindedappliance and call
your fire department.
LP Tank Removal, Transport And Storage
• Turn OFF all control knobs and LP tank valve. Turn coupling
nut counterclockwise by hand only - do not use tools to
disconnect. Lift LP tank wire upward off of LP tank collar, then
lift LP tank up and off of support bracket. Installsafety cap onto
LP tank valve.Always use cap and strap supplied with valve.
Failure to use safety cap as directed may result in serious
personal injury and/or property damage.
LP Tank Valve,
SafetyCap
RetainerStrap
• A disconnected LP tank in storage or being transported must
have a safety cap installed (as shown). Do notstore an LPtank
in enclosed spaces such as a carport, garage, porch, covered
patio or other building. Never leavean LP tank inside a vehicle
which may become overheated bythe sun.
• Do notstore an LPtank in an area where children play.
4" 464222209
LP Tank
• The LP Tank used with your grill must meet the following
requirements:
• Use LP Tanksonly with these required measurements: 12"
(30.5cm) (diameter) x 18" (45.7 cm) (tall) with 20 lb. (9 kg.)
capacity maximum.
• LPTanks must be constructed and marked in accordancewith
specifications for LP Tanksof the U.S. Department of
Transportation (DOT) or for Canada, CAN/CSA-B339, tanks,
spheres and tubes for transportation of dangerous goods.
Transport Canada (TC). See LP Tank collarfor marking.
• LP Tank valve must have:
• Type 1 outlet compatiblewith
regulatoror grill.
• Safety reliefvalve.
• ULlisted Overfill Protection
Device (OPD). This OPD safety OPDHandWheel
feature is identified by a unique triangular hand wheel. Use
only LP Tanks equipped with this type of valve.
• LPTank must be arranged for vapor withdrawal and include
collar to protect LPTank valve.Always keep LP Tanks in
upright position during use, transit or storage.
i[iii}iiiii!
il
LP Tank in upright position for vapor withdrawal
LP (Liquefied Petroleum Gas)
• LPgas is nontoxic, odorless and colorless when produced. For
Your Safety, LPgas has been given an odor (similar to rotten
cabbage) so that it can be smelled.
• LPgas is highly flammable and may ignite unexpectedly when
mixedwith air.
LP Tank Filling
•Use only licensed and experienced dealers.
•LPdealer must purge new tank before filling.
• Dealershould NEVER fill LP Tank more than 80% of LPTank
volume. Volume of propane in tank will vary by temperature.
• A frosty regulator indicates gas overfill. Immediately close LP
Tankvalve and call local LP gas dealer for assistance.
• Donot releaseliquid propane (LP) gas into the atmosphere.
This is a hazardous practice.
• Toremove gas from LPTank, contact an LP dealer or call a
local fire department for assistance. Check the telephone
directory under "Gas Companies" for nearest certified LP
dealers.

LP Tank Exchange
• Many retailers that sell grills offer you the option of replacing
your empty LP tank through an exchange service. Use only
those reputable exchange companiesthat inspect, precision fill,
test and certify their tanks. Exchange your tank only for an
OPB safety feature-equipped tank as described in the "LP
Tank" section of this manual.
• Always keep new and exchanged LP tanks in upright position
during use, transit or storage.
• Leak test new and exchanged LP tanks BEFORE
connecting to grill.
Connecting Regulator To The LP Tank
1. LP tank must be properly secured onto grill. (Refer to
assembly section.)
2. Turnall control knobs to the OFF position.
3. Turn LP tank OFF by turning OPD hand wheel clockwise to a
full stop.
4. Remove the protective capfrom LP tank valve.Always use
cap and strap supplied with valve.
LP Tank Leak Test
For your safety
•Leak test mustbe repeated each time LP tank isexchanged or
refilled.
* Do not smoke during leak test.
•Do not use an open flame to check for gas leaks.
•Grill must be leak tested outdoors in a well-ventilated area,
away from ignition sources such as gas fired or electrical
appliances. Duringleak test, keep grill away from open flames
or sparks.
• Use a clean paintbrush and a 50/50 mild soap and water
solution. Brush soapy solution onto areas indicated byarrows
in figure below. Leaks are indicated bygrowing bubbles.
If "growing" bubbles appear do not use or move the LP tank.
Contact an LP gas supplier or your fire department!
ADo not use household cleaning agents. Damage to gas
train components can result.
OPDHandWheel
_J Type 1outlet with
threadon outside
Safety Relief Valve
•
Strapand Cal_
Do not use a POL transport plug
(plastic part with external threads)!
It will defeat the safety feature of
the valve.
5. Hold regulator and insert nipple into LP
tank valve. Hand-tightenthe coupling
nut, holding regulator in a straight line
with LP tank valve so as not to cross-
thread the connection.
Nipplehas to be centered
into the LP tankvalve.
464222209• 5
