Kenmore 22-92202/3/4/8/9 User manual

22-9220X.PDF
22-92202/3/4/8/9
Page 1 of 2
Kenmore 30-Inch Self-Clean Radiant Range
White 22-92202
Stainless 22-92203
Bisque 22-92204
Ultra SilverSteel™ 22-92208
Black 22-92209
• 5.3 cu. ft. self-clean oven
• Ceramic glass top easily wipes clean
• Hot surface indicator light
• Cooktop on indicator light
• Oven control lockout
• One dual 9" / 6" @ 2,500 / 1,200W radiant element
• One 9" @ 2,500W radiant element
• Two 6" @ 1,200W radiant elements
• Dual Radiant™ baking system
• Easy Set™ 305 electronic oven controls and auto oven shutoff
• Two racks
• Interior light (auto & manual)
• Glass door with x-large window (22-92203: stainless door,
22-92208: Ultra SilverSteel™ door)
• Sabbath mode
• Storage drawer
Effective 10/04/10
14010
Due to Sears policy of continuous improve ment on its products, Sears
reserves the right to change materials and specifications without notice.
Before installing, consult installation instructions packed with product
for current dimensional and installation data.
Model 22-92202 22-92203 22-92204 22-92208 22-92209
Overall White Stainless Bisque Ultra Silver Steel Black
Console White Brushed Aluminum Bisque Ultra Silver Steel Black
Knobs White Black Bisque Black Black
Door White Stainless Bisque Ultra Silver Steel Black
Drawer White Stainless Bisque Ultra Silver Steel Black
Handle White Stainless Bisque Black Black
Sides White Black Bisque Black Black
Surface Black Black Black Black Black
Flecks Grey Grey Bisque Grey Grey
SELECTION KENMORE
White 22-92202
Stainless 22-92203
Bisque 22-92204
Ultra SilverSteel™22-92208
Black 22-92209
OVEN FEATURES SELF-CLEAN
Oven Capacity (cu. ft.) 5.3
Variable Time Self-Cleaning Select Clean® 2–3–4 Hrs.
Electronic Oven Controls Easy Set™ 305
Control Lockout Oven
Delay Start Cook & Clean
Automatic Oven Shutoff •
Sabbath Mode* •
Variable Broiling System Hi / Lo
Total Adjustable Oven Racks 2
Oven Lights Interior, Auto / Manual
Removable Glass Door** •
Window X-Large
Main Oven Interior W x H x D (in.) 24 3/8 x 19 3/4 x 19 1/8
COOKTOP FEATURES
Element Type Radiant
9-in. / 6-in. Dual (Watts) 1 @ 2,500 / 1,200
9-in. (Watts) 1 @ 2,500
6-in. (Watts) 2 @ 1,200
Cooktop Surface Ceramic Glass
Cooktop On Indicator Lights •
Hot Surface Indicator Lights •
GENERAL FEATURES
Drawer Storage
Power Rating (kW) @ 240V / 208V 12.5 / 9.5
Bake / Broil @ 240V (Watts) 3,500 / 4,000
Bake / Broil @ 208V (Watts) 2,625 / 3,000
Breaker / Copper Wire Size (240V) 40 / 8
Shipping Weight (Approx. Lbs.) 175
WARRANTY
1-Year Limited Warranty –
Entire Appliance Parts & Labor
If used for other than private family purposes, warranty applies for only 90 days.
*Sabbath Mode overrides auto oven shutoff
**Stainless model has stainless door, Ultra SilverSteel™ model has Ultra SilverSteel™ door

22-9220X.PDF
22-92202/3/4/8/9
Page 2 of 2
Effective 10/04/10
14010
Due to Sears policy of continuous improve ment on its products, Sears
reserves the right to change materials and specifications without notice.
Before installing, consult installation instructions packed with product
for current dimensional and installation data.
44 3/4"
Door Open
C
Door Open 29 7/8"
36"
47 3/4"
max.
B
max.
30 1/8"A25 3/4"
28 13/32"
with
Handle
30"
30"D
13"
18"
Side
View
Min. to
cabinets on
either side
of range
36"
1"
Min. to wall on
either side of
range above
36" height.
30"
min.
0" clearance
below cooking
top and at
rear of range
Max. depth for
cabinets above
range top
25"
Wall
Edge
Centerline
of range
C
L
2 5/8" for models equipped
with warming drawer.
3 1/2" for models equipped
with storage drawer.
Rear
View
6"
11"
22"
44 3/4"
Door Open
C
Door Open 29 7/8"
36"
47 3/4"
max.
B
max.
30 1/8"A25 3/4"
28 13/32"
with
Handle
30"
30"30"
13"
18"
Side
View
Min. to
cabinets on
either side
of range
36"
1"
Min. to wall on
either side of
range above
36" height.
30"
min.
0" clearance
below cooking
top and at
rear of range
Max. depth for
cabinets above
range top
25"
Wall
Edge
Centerline
of range
C
L
2 5/8" for models equipped
with warming drawer.
3 1/2" for models equipped
with storage drawer.
Rear
View
6"
11"
22"
44 3/4"
Door Open
C
Door Open 29 7/8"
36"
47 3/4"
max.
B
max.
30 1/8"A25 3/4"
28 13/32"
with
Handle
30"
30"D
13"
18"
Side
View
Min. to
cabinets on
either side
of range
36"
1"
Min. to wall on
either side of
range above
36" height.
30"
min.
0" clearance
below cooking
top and at
rear of range
Max. depth for
cabinets above
range top
25"
Wall
Edge
Centerline
of range
C
L
2 5/8" for models equipped
with warming drawer.
3 1/2" for models equipped
with storage drawer.
Rear
View
6"
11"
22"
Dashed cubed area shows where the
electrical outlet must be installed for
flush to the wall installation.
All dimensions for electrical outlet
location are maximum.
Dimensions, Inches (+/– 1/8")
A B C
22-9220X 29 7/847 3/448 1/4
All ranges are equipped with an Anti-Tip
device. The installation of this device is an
important, required step in the installation
of the range.
22-49614,
22-49616 RANGE CORDS FOR
ELECTRIC RANGES
Order Wire Length
22-49614 3 4 ft.
22-49616 3 6 ft.
22-49624* 4 4 ft.
22-49626* 4 6 ft.
* Complies with 1/1/96 NEC code
revision for new construction and
remodeling
22-49624,
22-49626
