Kenmore C970 Series User manual

TM
Kenmore®
Electric Slide-in Range
Cuisinière encastrable électrique
Use & Care Guide
Manuel d’utilisation et d’entretien
English / Français
P/N 318205824A (1012)
Sears Canada Inc., Toronto,
Ontario, Canada M5B 2C3
www.sears.ca

2
Serial Plate Location
You will nd the model and serial
number printed on the serial
plate. The serial plate is located
along the interior side trim and
visible when the oven door is
opened.
Remember to record the serial
number for future reference.
Product Record
In this space below, record the date of purchase, model and
serial number of your product. You will nd the model and
serial number printed on the serial plate.
Model No. ______________________________________
Serial No._______________________________________
Date of purchase ________________________________
Save these instructions and your sales receipt for future reference.
C970-
Please carefully read and save these instructions
This Use & Care Manual contains general operating instructions for your appliance and feature information for several models.
Your product may not have all the described features. The graphics shown are representative. The graphics on your appliance
may not look exactly like those shown. The instructions are not meant to cover every possible condition and situation that may
occur. Common sense and caution must be practiced when installing, operating and maintaining any appliance.
Printed in Canada
Table of Contents
Kenmore Appliance Warranty...........................................2
Maintenance Agreements.................................................2
Product Record .................................................................3
Serial Plate Location .........................................................3
IMPORTANT SAFETY INSTRUCTIONS ......................... 4-5
Slide-in Range Features....................................................6
Setting Surface Controls................................................ 7-9
Surface Cooking ..........................................................9-10
Before Setting Oven Controls...................................... 10-11
Setting the Oven Controls ........................................... 11-17
Self-Cleaning..............................................................18-19
Adjusting the oven temperature...................................... 19
Care & Cleaning....................................................... 20-23
• Cleaning Various Parts of Your Range ............................ 20
• Ceramic Glass Cooktop Cleaning and
Maintenance.................................................................. 21-22
• Care and Cleaning of Stainless Steel.............................. 22
• Removing and Replacing the Lift-O Oven Door ........ 22
• Remove the “Hidden Bake” Cover....................................23
• Changing Oven Light .........................................................23
• Storage Drawer ...................................................................23
Before you call ..........................................................23-25
Kenmore Warranty
When installed, operated and maintained according to all instructions supplied with the product, if this appliance fails due to a defect
in material and workmanship within one year from the date of purchase, call 1-800-4-MY-HOME® to arrange for free repair.
This warranty applies for only 90 days from the date of purchase if this appliance is ever used for other than private family purposes.
This warranty covers only defects in material and workmanship. Sears will NOT pay for:
1. Cracks in a ceramic glass cooktop that are not a result of thermal shock.
2. Stains and scratches on a ceramic glass cooktop resulting from accident or improper operation or maintenance.
3. Expendable items that can wear out from normal use, including but not limited to lters, belts, light bulbs, and bags.
4. A service technician to instruct the user in correct product installation, operation or maintenance.
5. A service technician to clean or maintain this product.
6. Damage to or failure of this product if it is not installed, operated or maintained according to the all instructions
supplied with the product.
7. Damage to or failure of this product resulting from accident, abuse, misuse or use for other than its intended purpose.
8. Damage to or failure of this product caused by the use of detergents, cleaners, chemicals or utensils other than those
recommended in all instructions supplied with the product.
9. Damage to or failure of parts or systems resulting from unauthorized modications made to this product.
Disclaimer of implied warranties; limitation of remedies
Customer’s sole and exclusive remedy under this limited warranty shall be product repair as provided herein. Implied
warranties, including warranties of merchantability or tness for a particular purpose, are limited to one year or the shortest
period allowed by law. Sears shall not be liable for incidental or consequential damages. Some states and provinces do not
allow the exclusion or limitation of incidental or consequential damages, or limitation on the duration of implied warranties
of merchantability or tness, so these exclusions or limitations may not apply to you.
This warranty applies only while this appliance is used in the United States or Canada.
This warranty gives you specic legal rights, and you may also have other rights which vary from state to state.
Sears Brands Management Corporation, Homan Estates, IL 60179 - Sears Canada Inc., Toronto, Ontario, Canada M5B 2B8

3
• All ranges can tip.
• Injury to persons could result.
• Install anti-tip device packed
with range.
• See Installation instructions.
To reduce the risk of tipping
of the range, the range must
be secured by properly
• Remove all tape and packaging wrap before
using the appliance. Destroy the carton and
plastic bags after unpacking the appliance.
Never allow children to play with packaging
material.
•Proper Installation—Be sure your appliance is
properly installed and grounded by a qualied
technician in accordance with CSA C22.1 PART
1—latest edition and local code requirements.
Install only per installation instructions provided
in the literature package for this appliance.
Ask your dealer to recommend a qualied
technician and an authorized repair service.
Know how to disconnect the electrical power to
the range at the circuit breaker or fuse box in
case of an emergency.
• User Servicing—Do not repair or replace
any part of the appliance unless specically
recommended in the manuals. All other
servicing should be done only by a qualied
technician to reduce the risk of personal injury
and damage to the appliance.
•Never modify or alter the construction of a
range by removing levelling legs, panels, wire
covers, anti-tip brackets/screws, or any other
part of the product.
Stepping, leaning or sitting on the
door or drawer of this appliance can result in
serious injuries and may also cause damage to
the appliance. Do not allow children to climb or
play around the appliance. The weight of a child
on an open door may cause the appliance to
tip, resulting in serious burns or other injury. An
open drawer, when hot, may cause burns.
Do not use the oven or Warmer
Drawer (if equipped) for storage.
• Storage in or on Appliance—Flammable
materials should not be stored in an oven, near
surface units or in the drawer (if equipped).
This includes paper, plastic and cloth items, such
as cookbooks, plasticware and towels, as well
as ammable liquids. Do not store explosives,
such as aerosol cans, on or near the appliance.
Flammable materials may explode and result in
re or property damage.
Do not store items of interest to
children in the cabinets above the appliance.
Children climbing on the range to reach items
could be seriously injured.
• Do not leave children alone. Children should
not be left alone or unattended in the area
where an appliance is in use. They should
never be allowed to sit or stand on any part of
the appliance.
• DO NOT TOUCH SURFACE UNITS, AREAS
NEAR THESE UNITS, OVEN HEATING
ELEMENTS OR INTERIOR SURFACES OF THE
OVEN OR WARMER DRAWER (if equipped).
Both surface units and oven heating elements
may be hot even though they are dark in
color. Areas near surface units may become
hot enough to cause burns. During and after
use, do not touch, or let clothing or other
ammable materials touch these areas until
they have had sucient time to cool. Among
these areas are the cooktop, surfaces facing
the cooktop, the oven vent openings and
surfaces near these openings, oven door and
window.
IMPORTANT SAFETY INSTRUCTIONS
Read all instructions before using this appliance. Save these instructions for future reference.
This guide contains important safety symbols and instructions. Please pay special attention to these
symbols and follow all instructions given. Here is a brief explanation of these symbols.
This symbol will help you to situations that may cause serious bodily harm, death or
property damage.
This symbol will help you to situations that may cause bodily injury or property damage.
installed anti-tip bracket(s) provided with the
range. To check if the bracket (s) is installed
properly, remove the lower panel or storage
drawer and verify that the anti-tip bracket
(s) is engaged. Refer to the installation
instructions for proper anti-tip bracket(s).

4
• Wear Proper Apparel—Loose-tting or
hanging garments should never be worn while
using the appliance. Do not let clothing or
other ammable materials contact hot surfaces.
Never use your appliance for
warming or heating the room.
• Do Not Use Water or Flour on Grease
Fires—Smother the re with a pan lid, or use
baking soda, a dry chemical or foam-type
extinguisher.
• When heating fat or grease, watch it closely.
Fat or grease may catch re if allowed to
become too hot.
• Use Only Dry Potholders—Moist or damp
potholders on hot surfaces may result in
burns from steam. Do not let the potholders
touch hot heating surface units or interior oven
elements. Do not use a towel or other bulky
cloth instead of a potholder.
•Do Not Heat Unopened Food Containers—
Build up of pressure may cause the container
to burst and result in injury.
•Remove the oven door from any unused
appliance if it is to be stored or discarded.
• IMPORTANT—Do not attempt to operate the
oven during a power failure. If the power
fails, always turn the oven o. If the oven
is not turned o and the power resumes, the
oven may begin to operate again. Food left
unattended could catch re or spoil.
Electronic controllers can be
damaged by cold temperatures. When you use
your appliance for the rst time, or if it has
not been used for a long period of time, make
sure that it has been exposed to a temperature
above 0°C/32°F for at least 3 hours before
connecting it to the power supply.
IMPORTANT INSTRUCTIONS FOR USING
YOUR COOKTOP
• Know which knob controls each surface
heating unit.
• Use Proper Pan Size—This appliance is equipped
with one or more surface units of dierent sizes.
Select utensils having at bottoms large enough
to cover the surface unit. The use of undersized
utensils will expose a portion of the surface
heating unit to direct contact and may result in
ignition of clothing. Proper relationship of utensil
to the surface unit will also improve eciency.
•Utensil Handles Should Be Turned Inward and
Should Not Extend Over Adjacent Surface
Units—To reduce the risk of burns, ignition
of ammable materials, and spillage due
to unintentional contact with the utensil. The
handle of the utensil should be positioned so
that it is turned inward, and does not extend
over adjacent surface unit.
•Never Leave Surface Units Unattended—
Boilovers cause smoking and greasy spillovers
that may ignite, or a pan that has boiled dry
may melt.
• Protective liners— Do not use aluminum
foil to line oven bottom or any other part
of the appliance. Only use aluminum foil
as recommended for baking if used as a
cover placed on the food. Any other used of
protective liners or aluminum foil may result in
a risk of electric shock or re or a short circuit.
• Glazed Cooking Utensils—Only certain types
of glass, glass/ceramic, ceramic, earthenware,
or other glazed utensils are suitable for
rangetop service without breaking due to the
sudden change in temperature. Check the
manufacturer’s recommendations for rangetop
use.
• Do Not Use Decorative Surface Element
Covers. If an element is accidentally turned
on, the decorative cover will become hot and
possibly melt. Burns will occur if the hot covers
are touched. Damage may also be done to the
cooktop.
IMPORTANT SAFETY INSTRUCTIONS

5
IMPORTANT SAFETY INSTRUCTIONS
• Do Not Clean or Operate a Broken Cooktop
—If cooktop should break, cleaning solutions
and spillovers may penetrate the broken
cooktop and create a risk of electric shock.
Contact a qualied technician immediately.
• Clean Cooktop Glass with Caution—If a wet
sponge or cloth is used to wipe spills on a hot
cooking area, be careful to avoid a steam
burn. Some cleaners can produce harmful
fumes if applied to a hot surface.
• Avoid scratching the cooktop glass with sharp
objects.
IMPORTANT INSTRUCTIONS FOR USING
YOUR OVEN
• Use Care When Opening Door or Warmer
Drawer (if equipped)—Stand to the side of
the appliance when opening the door of a hot
oven. Let hot air or steam escape before you
remove or replace food in the oven/warmer
drawer.
• Keep Oven Vent Ducts Unobstructed. The oven
is vented at the front above the oven door.
Touching the surfaces in this area when the
oven is operating may cause severe burns. Also,
do not place plastic or heat-sensitive items on
or near the oven vent. These items could melt
or ignite.
• Placement of Oven/Warmer Drawer (if
equipped) Racks. Always place oven racks
in desired location while oven/drawer (if
equipped) is cool. Remove all utensils from the
rack before removing rack. If rack must be
moved while oven is hot, use extreme caution.
Use potholders and grasp the rack with both
hands to reposition. Do not let potholders
contact the hot oven element or interior of the
oven/warmer drawer (if equipped).
• Do not use your broiler pan without its insert.
Your broiler pan and grid allow dripping fat to
drain and be kept away from the high heat of
the broiler.
•Do not cover the broiler or warmer drawer (if
equipped) grid with aluminum foil. Exposed
fat and grease could ignite.
• Do not touch a hot light bulb with a damp
cloth. Doing so could cause the bulb to break.
Disconnect the appliance or turn o the
power to the appliance before removing and
replacing light bulb.
IMPORTANT INSTRUCTIONS FOR
CLEANING YOUR RANGE
• Clean the range regularly to keep all parts
free of grease that could catch re. Exhaust
fan ventilation hoods and grease lters
should be kept clean. Do not allow grease to
accumulate. Greasy deposits in the fan could
catch re. Refer to the hood manufacturer’s
instructions for cleaning.
• Cleaners/aerosols—Always follow the
manufacturer’s recommended directions for
use. Be aware that excess residue from cleaners
and aerosols may ignite causing damage and/
or injury.
SELF-CLEANING OVENS
• Clean in the self-cleaning cycle only the parts
of the oven listed in this owner’s guide. Before
self-cleaning the oven, remove all utensils stored
in the oven.
• Do not clean the oven door gasket. The door
gasket is essential for a good seal. Care should
be taken not to rub, damage or move the
gasket.
• Oven racks. Oven racks color will change if
left in the oven during a self-cleaning cycle.
• Do not use oven cleaners. No oven cleaner or
oven liner protective coating of any kind should
be used in or around any part of the oven.
• Remove oven racks. Oven racks color will
change if left in the oven during a self-cleaning
cycle.
The health of some birds is
extremely sensitive to the fumes given o
during the self-clean cycle of any range. Move
birds to another well ventilated room.
SAVE THESE INSTRUCTIONS

6
Slide-in Range Features
Note: The features of your wall oven will vary according to model.
Your Slide-in Range Features At a Glance
1. Left Front Control
2. Left Rear Control
3. Right rear Control
4. Right Front Control
5. Electronic Oven Control With Clock and Kitchen Timer
6. Oven Vent
7. Broil Element
8. Oven Light
9. Convection Fan Cover
10. Self-Clean Convection Oven
11. Adjustable Oven Racks
12. Oven Door Handle
13. Glass Oven Door
14. Storage Drawer
15. 6” Single Radiant Element
16. Warmer Zone Element
17. 6” Single Radiant Element
18. 6”/9” Dual Radiant Element
19. 9”/12” Dual Radiant Element
20. Hot Surface Indicator Lights
6
11
10
14
1 32 4
7
12
15
18
16 17
19
20
8
13
9
5

7
About the Ceramic Glass Cooktop
The ceramic cooktop has radiant surface elements
located below the surface of the glass. The design of the
ceramic cooktop outlines the area of the surface element
underneath. Make sure the diameter of the pan matches the
diameter of the element outline on the cooktop.
Heat is transferred up through the surface of the cooktop
to the cookware. Only at-bottom cookware should be
used. The type and size of cookware, the number of surface
elements in use and their settings, are all factors that will
aect the amount of heat that will spread to areas beyond
the surface elements. The areas surrounding the elements
may become hot enough to cause burns.
About the Radiant Surface Elements
The element temperature rises gradually and evenly. As the
temperature rises, the element will glow red. To maintain
the selected setting, the element will cycle on and o. The
heating element retains enough heat to provide a uniform
and consistent heat during the o cycle. For ecient
cooking, turn o the element several minutes before cooking
is complete. This will allow residual heat to complete the
cooking process.
Locations of the Radiant Surface Elements and
Controls
Your range is equipped with radiant surface elements with
dierent wattage ratings. The ability to heat food quicker
and in larger volumes increases as the element wattage
increases.
The radiant surface elements are located on the cooktop as
follows:
- Two 6"radiant elements at the right and left rear positions;
- One dual 6"or 9"radiant element at the left front
positions;
- One dual 9”or 12”radiant element at the right front
positions;
- One warmer zone element at the center rear position.
NOTE: Please read detailed instructions for ceramic
glass cooktop cleaning in the General Care & Cleaning
section and Before You Call checklist section of this Use
and Care Guide.
NOTE: Radiant elements have a limiter that allows the
element to cycle on and o, even at the HI setting. This
helps to prevent damage to the ceramic smooth top.
Cycling at the HI setting is normal and can occur if the
cookware is too small for the radiant element or if the
cookware bottom is not at (Refer to Selecting Surface
Cooking Cookware section).
NOTE: Due to the high intensity of heat generated by
the surface elements, the glass surface will turn green
when the element will be turned o. This phenomenon is
normal and the glass will come back to its original white
color after it has completely cooled down. (White glass
cooktops only).
Setting Surface Controls

8
Surface Cooking Settings
Use the chart below to determine the correct setting for the
kind of food you are preparing. The Simmer settings are
used to simmer and keep larger quantities of foods warm
such as stews and soups. The lower Simmer settings are ideal
for delicate foods and melting chocolate or butter.
Note: The size and type of cookware used will inuence the
setting needed for best cooking results.
Radiant surface elements may appear to
have cooled after they have been turned o. A hot surface
indicator light will come on and will continue to glow until
the glass cooktop has cooled down to a moderate level. The
glass surface may still be hot and burns may occur if the
glass surface is touched before the indicator light has turned
o.
Do not place plastic items such as salt and
pepper shakers, spoon holders or plastic wrappings on top
of the range when it is in use. These items could melt or
ignite. Potholders, towels or wooden spoons could catch re
if placed too close to the surface elements.
Figure 1
Figure 2
Operating Single Radiant Surface Elements
The cooktop has single radiant surface elements at location
as shown on gure 1.
Recommended Settings for Surface Elements
Setting Type of Cooking
HIGH (Hi) Start most foods, bring water to a boil,
pan broiling.
MEDIUM HIGH
(5-8)
Continue a rapid boil, fry, deep fat fry.
MEDIUM (5) Maintain a slow boil, thicken sauces and
gravies, steam vegetables.
MEDIUM LOW
(2 - 4)
Keep foods cooking, poach, stew.
LOW (Lo - 2) Keep warm, melt, simmer.
Setting Surface Controls
To Operate the Single Surface Elements:
1. Place correctly sized cookware on the radiant surface
element.
2. Push in and turn the surface control knob in either
direction to the desired setting (Figure 2).
3. When cooking has completed, turn the surface control
knob to OFF before removing the cookware. Note:
The Hot Surface Indicator light will come on when the
control knob will be turn on and will continue to glow
until the glass cooktop has cooled down to a moderate
level. The light may remain on even though the controls
are turned OFF.
Note: See table, for recommended control settings.
Important notes:
•Start most cooking operations on a higher setting and then
turn to a lower setting to nish cooking.
• For ecient cooking, turn the surface element OFF several
minutes before cooking is complete. This will allow residual
heat to complete the cooking process.
• A glowing red surface heating area extending beyond the
bottom edge of the cookware indicates the cookware is too
small for the surface heating area.
• Radiant elements have a limiter that allows the radiant
heating element to cycle ON and OFF, even at the Hi
setting. This helps prevent damage to the ceramic cooktop.
Cycling at the HI setting is normal and will occur more often
if the cookware is too small for the radiant element or if the
cookware is not at.

9
Setting Surface Controls
Operating the Dual Surface Radiant Element
Your model is equipped with Dual radiant surface element
in the right &left front positions (See Figure 1). Turn the knob
clockwise to turn on the DUAL surface element (See Figure
3) and counterclockwise to turn on the SINGLE surface
element (See Figure 2). You may switch from either setting at
any time during cooking.
Figure 1
Figure 2
Single Setting Figure 3
Dual Setting
Dual Radiant heating areas on ceramic smooth top
(shown in black)
Important notes:
•Start most cooking operations on a higher setting and then
turn to a lower setting to nish cooking.
• For ecient cooking, turn the surface element OFF several
minutes before cooking is complete. This will allow residual
heat to complete the cooking process.
• A glowing red surface heating area extending beyond the
bottom edge of the cookware indicates the cookware is too
small for the surface heating area.
• Radiant elements have a limiter that allows the radiant
heating element to cycle ON and OFF, even at the Hi
setting. This helps prevent damage to the ceramic cooktop.
Cycling at the HI setting is normal and will occur more often
if the cookware is too small for the radiant element or if the
cookware is not at.
Radiant surface elements may appear to
have cooled after they have been turned o. A hot surface
indicator light will come on and will continue to glow until
the glass cooktop has cooled down to a moderate level. The
glass surface may still be hot and burns may occur if the
glass surface is touched before the indicator light has turned
o.
Do not place plastic items such as salt and
pepper shakers, spoon holders or plastic wrappings on top
of the range when it is in use. These items could melt or
ignite. Potholders, towels or wooden spoons could catch re
if placed too close to the surface elements.
To Operate the Dual Surface Element:
1. Place correctly sized cookware on the dual surface
element.
2. Push in and turn the control knob counterclockwise (See
Figure 2) for smaller cookware or clockwise (See Figure
3) for larger cookware.
3. Turn the knob to adjust the setting if needed. Start most
cooking operations on a higher setting and then turn to
a lower setting to nish cooking. Each surface element
provides a constant amount of heat at each setting. A
glowing red surface heating area extending beyond the
bottom edge of the cookware indicates the cookware is
too small for the surface heating area.
4. When cooking has completed, turn the surface control
knob to OFF before removing the cookware. Note: The
Surface Indicator light will come on when the control
knob will be turn on and will continue to glow until the
glass cooktop has cooled down to a moderate level. The
light may remain on even though the controls are turned
OFF.
Note: See page 8, for recommended control settings.

10
Figure 1
Setting Surface Controls
Setting Warmer Zone
The purpose of the Warmer Zone is to keep hot cooked foods
at serving temperature. Use the Warmer Zone to keep cooked
foods hot such as: vegetables, gravies, casseroles, soups, stews,
breads, pastries and oven-safe dinner plates. Always start
with hot food. It is not recommended to heat cold food on
the Warmer Zone.
All food placed on the warmer zone should be covered with a
lid to maintain quality. For best results, when warming pastries
or breads, the cover should have an opening to allow moisture
to escape. Do not use plastic wrap or aluminum foil to cover
food. Plastic or aluminum may melt onto the surface.
Use only plates, utensils and cookware recommended for oven
and cooktop use on the Warmer Zone.
Warmer Zone Temperature Selection
Refer to the Warmer Zone table for recommended heating
levels (Figure 1). If a particular food is not listed, start with the
medium level, and adjust as needed. Most foods can be kept
at serving temperatures by using the medium level.
To Set the Warmer Zone Control:
NOTE: The controls and indicator light are located on the
control panel.
1. Touch the ON/OFF pad at the Warmer Zone control position.
The Warmer Zone indicator light will ash. Note: If no further
pads are touched within 25 seconds the request to power the
Warmer Zone ON will clear.
2. At the Warmer Zone controls position touch Hi once to turn
ON the power level for HI (see Figure 2) or Lo to turn ON
the power level for LO (see Figure 5). The Warmer Zone
Indicator light located at the right of the ON/OFF pad
will turn on steady and the Hot Surface indicator light will
turn ON when the Warmer Zone becomes hot.
3. Each touch Hi or Lo will increase or decrease the power
levels. The Warmer Zone has 5 power levels from Hi (see
Figure 2) through Med (see Figure 4) to Lo (see Figure 5).
The power level may be adjusted at any time while the
Warmer Zone is ON.
4. When it is time to serve the food, touch the ON/OFF pad
once to turn the Warmer Zone OFF. The Warmer Zone
indicator light will turn OFF (see Figure 3).
Note: The Hot Surface indicator light will remain ON if the
cooktop is still hot and will remain ON until the heating surface
area has cooled suciently.
The Warmer Zone will not glow red when it is
hot, but becomes hot enough to cause burns. Avoid placing
hands on or near the Warmer Zone until the Warmer Zone Hot
Surface indicator light is OFF. Always use potholders or oven
mitts when removing food from the warmer zone as cookware
and plates will be hot.
Figure 2
Figure 4
Figure 3
Figure 5
Radiant surface elements may appear to have
cooled after they have been turned o. The glass surface may
still be hot and burns may occur if the glass surface is touched
before it has cooled suciently.
Do notplace aluminumfoilor plastic items such
assaltandpeppershakers, spoonholdersorplasticwrappings
on top of the range when it is in use. These items could melt
or ignite. Potholders, towels or wooden spoons could catch re
if placed too close to the surface elements or burners.
Warmer Zone Recommended Food Setting Table
Food Item Heating Level
Hot beverages HI
Fried Foods HI
Vegetables MED
Soups (Cream) MED
Stews MED
Sauces MED
Meats MED
Gravies LO
Eggs LO
Diner Plates with Foods LO
Casseroles LO
Breads/Pastries LO

11
Cookware Material types
The cookware material determines how evenly and quickly heat
is transferred from the surface element to the pan bottom. The
most popular materials available are:
ALUMINUM - Excellent heat conductor. Some types of food
will cause it to darken (Anodized aluminum cookware resists
staining & pitting). If aluminum pans slide across the ceramic
glass cooktop, they may leave metal marks which will resemble
scratches. Remove these marks immediately.
COPPER - Excellent heat conductor but discolours easily. May
leave metal marks on ceramic glass (see Aluminum above).
STAINLESS STEEL - Slow heat conductor with uneven cooking
results. Is durable, easy to clean and resists staining.
CAST IRON - A poor heat conductor however will retain heat
very well. Cooks evenly once cooking temperature is reached.
Not recommended for use on ceramic cooktops.
PORCELAIN-ENAMEL on METAL - Heating characteristics will
vary depending on base material. Porcelain-enamel coating
must be smooth to avoid scratching ceramic cooktops.
GLASS - Slow heat conductor. Not recommended for ceramic
cooktop surfaces because it may scratch the glass.
Figure 2
CORRECT
• Flat bottom and straight
sides.
• Tight ttings lids.
• Weight of handle does
not tilt pan. Pan is well
balanced.
• Pan sizes match the
amount of food to be
prepared and the size of
the surface element.
• Made of a material that
conducts heat well.
• Easy to clean.
• Always match pot
diameter to element
surface diameter.
• Curved and warped
pan bottoms.
INCORRECT
Surface Cooking
Selecting Surface Cooking Cookware
Cookware should have at bottoms that make good contact
with the entire surface heating element. Check for atness
by rotating a ruler across the bottom of the cookware (See
Figure 1). Be sure to follow the recommendations for using
cookware as shown in Figure 2.
Note: The size and type of cookware used will inuence the
setting needed for best cooking results.
Figure 1
• Pan overhangs element
by more than one-half
inch.
• Pan is smaller then
element.
• Heavy handle tilts pan.

12
Before Setting Oven Controls
Removing and Replacing Oven Racks
To remove, pull the rack forward until it stops. Lift up front
of rack and slide out. To replace, t the rack onto the
guides on the oven walls. Tilt the front of the rack upward
and slide the rack back into place.
Oven Vent Location
The oven vent is located at right side of the front panel
and visible when the oven door is open. When the oven
is on, hot air is released through the vents. This venting is
necessary for proper air circulation in the oven and good
baking results.
Arranging Oven Racks
ALWAYS ARRANGE OVEN RACKS WHEN THE OVEN IS COOL (PRIOR TO OPERATING THE OVEN). Always use oven mitts
when the oven is hot.
This range has a fan that will turn “ON” and “OFF” by itself to keep the electronics cool. It may continue
to run after the range has been turned “OFF”, but may also stop immediately and then turn “ON” after a while.
RECOMMENDED RACK POSITIONS FOR
BROILING, BAKING & ROASTING
Food Rack position
Broiling meats, chicken or sh 3 or 4
Cookies, cakes, pies, biscuits &muns
1 rack 2 or 3
Multiple racks 2 & 4
Frozen pies, angel food cake, yeast, bread,
casseroles, small cuts of meat or poultry 1 or 2
Turkey, roast or ham 1
Note: Always use caution when removing food.
Air Circulation in the Oven
For best air circulation and baking results allow 2-4" (5-10 cm)
around the cookware for proper air circulation and be sure pans and
cookware do not touch each other, the oven door, sides or back of the
oven cavity. The hot air must circulate around the pans and cookware
in the oven for even heat to reach around the food. 1 Oven Rack
Multiple Oven Racks
4
3
2
1
Rack
positions

13
Setting Oven Controls
Control Pad Functions
READ THE INSTRUCTIONS CAREFULLY BEFORE USING THE OVEN. For satisfactory use of your oven, become familiar with
the various functions of the oven as described below.
Note: The time of day must rst be set in order to operate the oven.
1. Bake Conv. - Use to select the convection bake feature.
2. Roast Conv. - Use to select the convection roast feature.
3. Conv. Convert - Use to select the Convection Convert
feature
4. Preheat - Use to raise oven to cooking temperature.
5. Bake - Use to enter the normal bake feature.
6. Broil - Use to select variable broil function.
7. Slow Cook - Use to select the slow cook feature.
8. Warm - Use to select the Warm feature.
9. Clean - Use to select the Self-Clean feature.
10. Cook Time - Use to enter the length of the baking time.
11. Delay Start - Use with Bake, Conv Bake, Preheat, Slow
Cook, Cook Time and Clean to program a delayed
Timed bake or delay self-cleaning cycle start time.
1
4 10 11 12
16
13
17 18 19
20
14 15
7
2
5
8
3
6
9
12. Timer - Use to set or cancel the Kitchen Timer. The
kitchen Timer does no start or stop cooking.
13. Add 1 minute - Use to select add 1 minute feature.
14. Recipes - Use to select the recipes feature.
15. Oven Light - Use to turn the oven light ON and OFF.
16. Cooktop Surface Lockout - Use to set the cooktop
lockout feature.
17. Clock - Use to set the time of day.
18. Stop - Use to cancel any oven mode previously entered
except the time of day and minute timer. Press Stop to
stop cooking.
19. Start - Use to start all oven features (not used with Oven
Light).
20. 0 thru 9 number pads - Use to enter temperature and
times.

14
Setting the Clock
The pad is used to set the clock. The clock may be set
for 12 or 24 hour time of day operation. The clock has been
preset at the factory for the 12 hour operation. When the
range is rst plugged in, or when the power supply to the
range has been interrupted, the time in the display will ash.
To set the clock (example below for 1:30)
1. Press .
2. Press 1, 3 & 0 pads to set the time of day to 1:30. Press
Start.
Changing between 12 or 24 hour time of day display
1. Press and hold for 7 seconds. CONTINUE holding
the pad until “12Hr dAy” or “24Hr dAy” appears in the
display and the control beeps once.
2. Press Clean to switch between the 12 and 24 hour time
of day display. The display will show either “12Hr dAy”
or “24Hr dAy”.
3. Press Start to accept the change or press Stop to reject
the change.
4. Reset the correct time as described in To set the Clock
above. Please note that if the 24 hour time of day mode
was chosen, the clock will now display time from 0:00
through 23:59 hours.
Setting Continuous Bake or 12 Hour Energy
Saving
The Timer and Clean pads control the Continuous Bake or 12
Hour Energy Saving features. The oven control has a factory
preset built-in 12 Hour Energy Saving feature that will shut
o the oven if the oven control is left on for more than 11
hours and 59 minutes. The oven can be programmed to
override this feature for Continuous Baking.
To set the control for Continuous Bake or 12 Hour
Energy Saving features
1. Press and hold Timer for 7 seconds. After 7 seconds
“12Hr OFF” or “StAy On” will appear in the display and
the control will beep once.
2. Press Clean to switch between the 12 Hour Energy
Saving and continuous bake features. Note: “12Hr OFF”
in the display indicates the control is set for the 12
Hour Energy Saving mode and “StAy On” indicates the
control is set for the Continuous Bake feature.
3. Press Start to accept the change (Display will return to
time of day) or press Stop to reject the change.
Setting Kitchen Timer
The Timer pad controls the Kitchen Timer feature. The
Kitchen Timer serves as an extra timer in the kitchen that
will beep when the set time has run out. It does not start or
stop cooking. The Kitchen Timer feature can be used during
any of the other oven control functions
To set the Kitchen Timer (example for 5 minutes)
1. Press Timer.
2. Press the number pads to set the desired time in the display
(example 5). Press Start. The time will begin to count down
with “5:00”. Note: If Start is not pressed the timer will return
to the time of day after 25 seconds.
3. When the set time has run out, “End” and “TIMER” will
show in the display. The clock will sound with 3 beeps
every 5 seconds until TIMER is pressed.
To cancel the Kitchen Timer before the set time has run
out
Press Timer. The display will return to the time of day.
To Set Add 1 Minute Feature
The Add 1 Minute pad is used to set the Add 1 Minute
feature. When the Add 1 Minute pad is pressed, 1 minute is
added to the Kitchen Timer feature if this feature is already
active. If the Kitchen Timer feature is not active and the
Add 1 Minute pad is pressed, the Kitchen Timer feature will
become active and will begin counting down from 1 minute.
Setting Oven Controls

15
Consumer Dened Control
Note: The Consumer Dened Control features are adjustments
to the control that will not aect cooking results. These include
the Oven Lockout, Temperature Display and Silent Control
Operation features
Setting Oven Lockout Feature
The Stop pad controls the Oven Lockout feature. The Oven
Lockout feature automatically locks the oven door and prevents
the oven from being turned on. It does not disable the display
of the clock, the Kitchen Timer or the interior oven lights.
To activate the Oven Lockout feature
1. Press and hold Stop for 3 seconds.
2. After 3 seconds “door Loc” will appear, a beep will sound
and “DOOR LOCKED” will ash in the display. Once the
oven door is locked the “DOOR LOCKED” indicator will
stop ashing and remain on along with the “Loc”.
To reactivate normal oven operation:
1. Press and hold Stop for 3 seconds. A beep will sound. The
“DOOR LOCKED” will ash in the display until the oven
door has completely unlocked.
2. The wall oven is again fully operational.
To Set the Cooktop Surface Feature
The pad is used to activate the Cooktop Lockout feature
which will lock all surface elements from being accidentally
turned ON. This feature will only lock the cooktop.
To turn the Cooktop Lockout Feature ON:
1. BE SURE ALL surface element controls are set to the OFF
position.
2. Press and hold until one beep is heard. If a triple beep
sounds instead, check all surface elements and turn them
to the OFF position and repeat this step. The Cooktop
Locked icon will turn ON and the cooktop controls and
functions are locked out until the cooktop is unlocked.
To turn the Cooktop Lockout Feature OFF:
1. BE SURE ALL surface element controls are set to the OFF
position.
2. Press and hold until one beep is heard (after 3 seconds).
If a triple beep sounds instead, check all surface elements
and turn them to the OFF position and repeat this step.
The Cooktop Locked icon will turn OFF and the cooktop
may be used normally.
Important notes:
- Starting a Self-Clean cycle will also turn ON the Cooktop
Lockout feature. The cooktop will remain locked until the
Self-Clean cycle has completed and the oven door has
unlocked.
- If a power failure occurs after the Cooktop Lockout has been
activated, you must turn OFF the Cooktop Lockout feature
before being able to use the cooktop features again.
Setting Temperature Display
The Broil and Clean pads control the Fahrenheit or Celsius
temperature display modes. The oven control can be
programmed to display temperatures in Fahrenheit or
Celsius. The oven has been preset at the factory to display in
Fahrenheit.
To change display from Fahrenheit to Celsius or
Celsius to Fahrenheit
1. To tell if the display is set for Fahrenheit or Celsius press
Broil and hold for 7 seconds. If “F” appears, the display
is set to show temperatures in Fahrenheit. If “C” appears,
the display is set to show temperatures in Celsius.
2. Press Clean to switch between Fahrenheit or Celsius display
modes. The display will show either “F” or “C”.
3. Press Start to accept the change or press Stop to reject
the change.
Setting Silent Control Operation
The Delay Start and Clean pads control the Silent Control
operation feature. The Silent Control operation feature
allows the oven control to be operated without sounds or
beeps whenever necessary. If desired the control can be
programmed for silent operation and later returned to
operating with all the normal sounds and beeps.
To change control from normal sound operation to
silent control operation
1. To tell if your range is set for normal or silent operation
press and hold Delay Start. “ -- --” will appear and “DELAY”
will ash in the display. After 7 seconds “bEEp On” will
appear in the display.
2. Press Clean to switch between normal sound operation and
silent operation mode. The display will show either “bEEp
On” or “bEEp OFF”.
If “bEEp On” appears, the control will operate with normal
sounds and beeps. If “bEEp OFF” appears, the control is
in the silent operation mode.
3. Press Start to accept the change or press Stop to reject
the change.
Note: The control will always beep at the end of a kitchen
timer and will beep when a set temperature has been reached,
even if the control is set to silent operation.
Setting Oven Controls

16
Setting Preheat
The Preheat pad controls the Preheat feature. The Preheat
feature will bring the oven up to temperature and then
indicate when to place the food in the oven. Use this feature
when recipes call for preheating. Preheating is not necessary
when roasting or cooking casseroles. The oven can be
programmed to preheat at any temperature between 170°F
to 550°F.
The following temperature settings apply to the preheat
feature:
• Auto-suggest (default setting: 350°F / 177°C.
• Min. bake setting: 170°F / 77°C.
• Max. bake setting: 550°F / 288°C.
To set the Preheat
See example below to set a preheat to start immediately at
375°.
1. Arrange the interior oven racks.
2. Press Preheat.
3. Press 3, 7, 5.
4. Press Start.
To change Preheat temperature while oven is
preheating
See example below to change from 375° to 425°.
1. Press Preheat. “375”.
2. Press 4, 2, 5.
3. Press Start.
“PRE” and the actual oven temperature shown in the display
will alternate as the oven heats and reaches 375°F.
When the oven is nished preheating, the controls will beep
and the “PRE” light will turn o and oven temperature will
be displayed. If you missed hearing the beep, you can tell
that the oven has reached preheat temperature if you see
the oven temperature showing in the oven display. Once
the oven has preheated, PLACE FOOD IN THE OVEN. The
“BAKE” light will stay on.
Note
• To cancel the function, press Stop at any time when
setting the control or during the cooking process.
• During the preheating, the convection fan will be
activated to allow the oven to reach its target
temperature faster. The Bake, Broil and Convection
elements will also cycle for a better heat distribution.
Setting Bake
TheBAKEpad controls normal baking. If preheating is necessary,
refer to the Preheat Feature for instructions.
The following temperature settings apply to the bake
feature:
• Auto-suggest (default setting): 350°F / 177°C.
• Min. bake setting: 170°F / 77°C.
• Max. bake setting: 550°F / 288°C.
To set the Bake
See example below to set a bake to start immediately at
375°.
1. Arrange interior oven racks and place food in oven.
2. Press Bake.
3. Press 3, 7, 5.
4. Press START.
To change the Bake Temperature
See example below to change from 375° to 425°.
1. Press Bake.
2. Press 4, 2, 5.
3. Press Start.
Once START is pressed the oven will begin heating. The oven
display shows the temperature rising.
After the oven reaches set temperature a beep will indicate
the oven is ready. The oven will continue to maintain this
temperature until the cooking feature is canceled.
Note
• To cancel the function, press Stop at any time when
setting the control or during the cooking process.
• During the rst rise of temperature, the convection fan
will be activated to allow the oven to reach its target
temperature faster. The Bake, Broil and Convection
elements will also cycle for a better heat distribution.
Setting Oven Controls

17
Setting Cook Time
Adding a cook duration when baking is benecial when a
recipe requires a specic temperature and period of time to
cook. Following the recipe cook time helps insure the best
possible results.
Cook Time may be set with the following features:
• Preheat
• Bake
• Conv Bake
• Conv Roast
• Slow Cook
To set the Cook Time feature
See example below to set the oven for bake, starting
immediately at 375°F and then to automatically turn off after
30 minutes:
1. Be sure the clock is set for the correct time of day.
2. Arrange oven rack(s) and place the food in the oven.
3. Press Bake.
4. Press 3, 7, 5.
5. Press Start.
6. Press Cook Time.
7. Enter the desired baking time by pressing 3, 0.
8. Press Start.
Once START is pressed the oven will cook and after 30
minutes automatically shut-o.
When the timed bake nishes:
1. “End” and the time of day will show in display. The oven
will shut o automatically.
2. The control will beep 3 times. The control will continue
to beep 3 times every 30 seconds until Stop is pressed.
Note
• To cancel the function, press Stop at any time when
setting the control or during the cooking process.
• The maximum Cook Time setting is 11 hours and 49 minutes.
• After the Cook Time feature has been activated, the
display will go back to showing the hour of day. Press the
Cook Time keypad to display any remaining cook time.
• Dark or dull pans absorb more heat than shiny
bakeware resulting in dark or overbrowning of foods.
It may be necessary to reduce the oven temperature
or cook time to prevent overbrowning of some foods.
Dark pans are recommended for pies. Shiny pans are
recommended for cakes, cookies or muns.
Setting Delay Start (with Cook Time)
Adding a cook duration along with specic start time gives
the same benets as the cook time option in addition to
controlling exactly when the cooking process will begin and
end.
Delay Start may be set with the following features:
• Bake
• Conv Bake
• Conv Roast
• Slow Cook
• Clean
To set the Delay Start (with Cook Time) feature
See example below to set the oven with preheating for Bake
at 375°F (191°C) for 50 minutes and to automatically start at
5:30:
1. Be sure the clock is set for the correct time of day.
2. Arrange oven rack(s) and place the food in the oven.
3. Press Bake.
4. Press 3, 7, 5.
5. Press Start.
6. Press Cook Time.
7. Enter the desired baking time by pressing 5, 0.
8. Press Start.
9. Press Delay Start.
10. Enter 5, 3, 0.
11. Press Start.
Once START is pressed, the oven will calculate the start time
at which the oven will begin heating.
The oven will continue to maintain this temperature for the
selected time or until the cooking feature is canceled.
When the timed bake nishes:
1. “End” and the time of day will show in display. The oven
will shut o automatically.
2. The control will beep 3 times. The control will continue
to beep 3 times every 30 seconds until Stop is pressed.
Note
• When setting the Delay Start option be sure the correct
time of day is set.
• To cancel the function, press Stop at any time when
setting the control or during the cooking process.
• You may choose to use Delay Start with no Cook Time.
• Delay start may be set using a 24 hour clock. See setting
12 or 24 hour display modes for more information.
Use caution with the DELAY START (Delayed Timed Bake) features. Use the automatic timer when cooking cured or frozen
meats and most fruits and vegetables. Foods that can easily spoil such as milk, eggs, sh, meat or poultry, should be chilled
in the refrigerator rst. Even when chilled, they should not stand in the oven for more than 1 hour before cooking begins, and
should be removed promptly when cooking is completed. Eating spoiled food can result in sickness from food poisoning
Setting Oven Controls

18
Setting Convection Bake
Convection baking uses a fan to circulate the oven’s heat
evenly and continuously within the oven. This improved heat
distribution allows for even cooking and browning results.
Multiple racks cooking may slightly increase cook times for
some foods, but the overall result is time saved.
The Conv Bake feature should ONLY be used when your
recipe instructions have been written for use with convection
baking.
If your recipe instructions are for normal baking and
you wish to use convection bake, follow the Convection
Convert option instructions. The convection convert option
will automatically adjust the oven temperature so that
convection baking may provide the best possible result.
Conv Bake may be set with the following option:
• Conv Convert
• Cook Time and / or Delay Start
Benets of Convection Bake
• Multiple rack baking.
• No special pans or bakeware needed.
For best results
• Cookies and biscuits should be baked on pans with no
sides or very low sides to allow heated air to circulate
around the food. Food baked on pans with a dark nish
will cook faster.
• Preheating is not necessary when cooking casseroles with
Convection Bake.
• When using Convection Bake with a single rack, place
oven rack in position 2 or 3. If cooking on multiple racks,
place the oven racks in positions 2 and 4.
Air circulation during
Convection Bake
Figure 1
The following temperature settings apply to the conv bake
feature:
• Auto-suggest (default setting): 350°F / 177°C.
• Min. bake setting: 170°F / 77°C.
• Max. bake setting: 550°F / 288°C.
To set the Convection Bake
See example below to set conv bake to start immediately at
375°.
1. Arrange interior oven racks and place food in oven.
2. Press Conv Bake.If default temperature (350°F) is needed,
press Start.
3. Press 3, 7, 5.
4. Press Start.
The actual oven temperature will be displayed. “CONV BAKE”
will stop ashing and the fan icon will appear in the display.
Press Stop to stop Convection Bake or cancel Convection Bake
at any time.
Note
The convection fan will start AS SOON AS the oven is set for
Convection Bake. The display will show an icon of rotating
fan within a square. This rotating fan icon indicates when the
Convection Fan is operating. The Bake, Broil and Convection
elements will cycle for a better heat distribution.
4
3
2
1
Setting Oven Controls

19
Setting Convection Roast
This method of cooking enables you to obtain the best
results when roasting. Remember to use tested recipes
with times adjusted for convection roasting when using the
convection mode. This oven is equipped with multiple fan
speeds for even cooking when baking and better tasting
meats when roasting. It will use a faster fan speed for
roasting which will quickly strip the cold air away from the
meats replacing it with warm air (making a crisp outside -
type of searing) sealing in juices for better tasting meats.
Conv Bake may be set with the following option:
• Cook Time and / or Delay Start
The following temperature settings apply to the conv bake
feature:
• Auto-suggest (default setting): 350°F / 177°C.
• Min. bake setting: 170°F / 77°C.
• Max. bake setting: 550°F / 288°C.
Benets of Convection Bake
• Multiple rack baking.
• No special pans or bakeware needed.
For best results
• Preheating is not necessary for most meats and poultry.
• Be sure to carefully follow your recipe's temperature and
time recommendations.
• Do not cover foods when dry roasting - this will prevent
the meat from browning properly.
• Since Conv Roast cooks food faster, reduce the cook
time by 25% from the recommended cook time of
your recipe (check the food at this time). If necessary,
increase cook time until the desired doneness is
obtained.
To set the Convection Roast
See example below to set conv roast to start immediately at
375°.
1. Arrange oven racks.
2.Press Conv Roast.
3. Enter the desired roasting temperature using the number
pads 3, 7, 5.
4.Press Start.
To change the Convection Roast temperature
(example: changing from 375°F to 425°F)
1. Press Conv Roast.
2. Enter the desired roasting temperature using the number
pads 4, 2, 5.
3.Press Start.
After the oven has reached the desired temperature, the
control will beep and CONV ROAST light will stay on. Note:
The Bake, Broil and Convection elements will cycle for a
better heat distribution.
When convection roasting is complete press Stop.
Setting Convection Convert
The Conv Convert pad is used to automatically convert
a standard baking recipe for convection baking. When
set properly, this feature is designed to display the actual
converted (reduced) temperature in the display.
Convection Convert may ONLY be used with a Conv Bake,
Timed Conv Bake or a Delay Start (Delayed Timed Conv
Bake) setting. When used with a Timed Bake or a Delay
Start (Delayed Timed Bake) setting, the Convection Convert
will display a “CF” for check food when the bake time is
75% complete. At this time the oven control will sound 3
long beeps at regular intervals until baking had nished.
When the bake time has completely nished the control will
display “End” and will sound 3 long beeps every 30 seconds
until the Stop pad is pressed.
To change from a normal bake recipe to a convection
bake recipe (example: changing a 400°F normal
bake recipe to a convection bake recipe)
When the conv bake mode is on at 400°F, press Conv
Convert. “CONV BAKE” and the oven temperature
adjustment will appear briey in the display (for this
example it is 375°F). A beep will sound once the adjusted
oven temperature is reached. The display will show “375°”,
“CONV BAKE” and the fan icon.
NOTE: When using a Cook Time, the convection convert will
not operate if you have a timed bake under 20 minutes.
Setting Oven Controls

20
Setting Oven Controls
Setting Broil
When broiling, heat radiates downward from the oven broiler
for even coverage.
The following temperature settings apply to the broil feature:
• Auto-suggest (default setting): 550°F / 288°C.
• Min. bake setting: 400°F / 204°C.
• Max. bake setting: 550°F / 288°C.
To set the oven to broil
See example below to set broil to start immediately at 500°.
1. Place the broiler pan insert on the broiler pan. Then
place the food on the broiler pan insert. DO NOT use
the broiler pan without the insert. DO NOT cover the
broiler insert with foil. The exposed grease could ignite.
2. Arrange the interior oven rack and place the broiler pan
on the rack. Be sure to center the broiler pan directly
under the broiler element. Make sure the oven door is in
the broil stop position (See Figure 1).
3. Press Broil.
4. Press 5, 0, 0.
5. If a lower broil temperature is desired (minimum
broil temperature setting is 400°F), press the desired
temperature before continuing to step 6.
6. Press Start. The oven will begin to broil.
7. Broil on one side until food is browned; turn and cook
Broil Stop Position
Figure 1
Be aware that the suggested broil setting table are
recommendations only. Increase or decrease broiling times,
or move to a dierent rack position to suit for doneness. If
the food you are broiling is not listed in the table, follow the
instructions provided in your cookbook and watch the item
closely.
on the second side.
Season and serve.
Note: Always pull
the rack out to the
stop position before
turning or removing
food.
8. To cancel broiling
press Stop.
Electric range broiling table recommendations
Food Item
Rack
Position
Temp.
setting
Cook time
Doneness1st side 2nd side
Steak 1" thick 2nd 550°F 6:00 min. 4:00 min. Rare
2nd 550°F 7:00 min. 5:00 min. Medium
Pork chops ¾" thick 2nd 550°F 8:00 min. 6:00 min. Well
Chicken - Bone In 3rd 450°F 20:00 min. 10:00 min. Well
Chicken Boneless 2nd 450°F 8:00 min. 6:00 min. Well
Fish 2nd 500°F 13:00 min. N/A Well
Shrimp 3rd 550°F 5:00 min. N/A Well
Hamburger 1" thick 2nd 550°F 9:00 min. 7:00 min. Medium
3rd 550°F 10:00 min. 8:00 min. Well
For best results
• Use the recommended pans and oven rack positions for
the type of meat being prepared.
• For optimum browning results, allow the oven to preheat
5-6 minutes before placing the food in the oven.
• Do not use the broiler pan without the insert.
• Do not cover the broil pan/insert with aluminum foil; the
exposed grease could ignite.
• To prevent food from contacting the broil element and to
prevent grease splattering, do not use the roasting rack
when broiling.
Should an oven re occur, leave the oven door closed and
turn o the oven. If the re continues, throw baking soda on
the re or use a re extinguisher. DO NOT put water or our
on the re. Flour may be explosive and water can cause a
grease re to spread and cause personal injury.
Broiler Pan and Insert (Available with some models)
The broiler pan and the insert allows grease to drain and
be kept away from the high heat of the broiler. DO NOT
use the pan without the insert. DO NOT cover the insert
with foil; the exposed grease could ignite.
Broiler Clean-Up Tips (some models):
• To make cleaning easier, line the bottom of the broiler
pan with aluminum foil. DO NOT cover the broiler grid
with foil.
• To prevent grease from baking on, remove the broiler
pan from the oven as soon as cooking is completed.
4
3
2
1
Use hot pads because the
broiler pan is extremely hot.
Pour o grease. Soak the
pan in HOT, soapy water.
• Clean the broiler pan as soon
as possible after each use. If
necessary, use soap-lled steel
wool pads. Heavy scouring
may scratch the grid.
Insert
Broiler
pan
