Kennell LTC2-A1202 User manual

Lecturer Tracking Camera
User Manual V1.0

SAFETY NOTICE-IMPORTANT!!!
The following important notes must be followed carefully to run the camera and respective
accessories in total safety. The camera and relative accessories are called video system in this
section.
Before installing the camera, please read this manual carefully. Please follow installation
instructions indicated in this manual during installation. Please keep this manual for future use.
The installation should be performed by qualified service personnel or system installers in
accordance with all local rules.
Before powering on the camera, please check the power voltage carefully. Make sure that you
are using the correct power source.
Please put the power cable, video cable and control cable in safe place.
Do not operate the camera beyond the specified temperature and humidity. Working
temperature range of the camera is between 0℃and +40℃. The ambient humidity range is
less than 95﹪.
During transporting, avoid violent shake or force to the camera.
To prevent electric shock, do not remove screws or housing of the camera. There are no
self-serviceable parts inside. Refer to qualified service personnel for servicing.
Video cable and RS485/RS232 cable should be kept far away from other cables. Shielded and
independent wiring is necessary for video and control cables.
Never aim the lens of the camera at the sun or other extremely bright objects. Otherwise, it may
cause damage.
When cleaning the camera, please use soft cloth. If the camera is very dirty, wipe it off gently
with a soft cloth moistened with a weak solution of water and a neutral kitchen detergent. Wring
all liquid from the cloth before wiping the camera, then wipe off all remaining dirt with a soft, dry
cloth. Use lens cleaning paper to clean the lens.

Do not move the camera head manually. In doing so would result in malfunction of the
camera. Do not hold the camera head when carrying the video camera.
Make sure the camera is not directly exposed to rain and water.
Make sure the camera is far away from area where radiation, X-rays, strong electric waves, or
magnetism is generated.

Attention
If you need to extend the power cable, please extend the power cable
from the part 1 on below picture (220V/110V), do not extend from part
2 on below picture (DC12V), otherwise it will cause unexpected
damage to the device.

CONTENTS
ABOUT THE PRODUCT-------------------------------------------------------- 1
QUICK GUIDE ------------------------------------------------------------------------------ 1
FEATURES--------------------------------------------------------------------- 2
CHARACTERISTICS &FUNCTIONS ----------------------------------------------------------- 2
LIST OF PARTS &ACCESSORIES ------------------------------------------------------------ 3
MAIN PARTS &INTERFACES ---------------------------------------------------------------- 4
REMOTE CONTROLLER --------------------------------------------------------------------- 5
INSTALLATION INSTRUCTIONS----------------------------------------------- 7
DESKTOP MOUNT INSTALLATION ------------------------------------------------------------ 7
WALL MOUNT INSTALLATION ---------------------------------------------------------------- 7
SOFTWARE CONNECTION ---------------------------------------------------- 8
PARAMETERS ---------------------------------------------------------------------------- 11
SETTING PROCESS------------------------------------------------------------------------ 11
BLS-------------------------------------------------------------------------------------- 14
MENU SETTINGS ------------------------------------------------------------ 16
MENU CONFIGURATION-------------------------------------------------------------------- 16
MENU EXPLANATION ---------------------------------------------------------------------- 20
VIDEO ----------------------------------------------------------------------------------- 21
EXPOSURE ------------------------------------------------------------------------------- 21
WHITE BALANCE-------------------------------------------------------------------------- 22
PAN/TILT/ZOOM--------------------------------------------------------------------------- 23
SYSTEM---------------------------------------------------------------------------------- 23
STATUS ---------------------------------------------------------------------------------- 24

RESTORE DEFAULTS ---------------------------------------------------------------------- 24
ANNEX 1 TECHNICAL SPECIFICATIONS------------------------------------ 25
ANNEX 2 SIZE AND DIMENSION -------------------------------------------- 27
TROUBLESHOOTING-------------------------------------------------------- 28

1
ABOUT THE PRODUCT
Quick Guide
LTC can be accessed and controlled via the
following ways:
Client software RoomTracker: tracking setting,
camera search and control, network setting
etc;
RTSP: view of main stream and sub video
stream;
RTMP: view of main stream video stream;
Internet Explorer: view of main stream video
stream, camera control, network setting;
Onvif: version 2.1 supported.
RoomTracker Software
1.Make sure PC and LTC in the same LAN;
2.Setup and open RoomTracker to find and
display ETC devices online in cam list;
3.In CONFIGURE menu, set camera IP and
port;
4.Click CONFIGURE to set tracking
parameters.
Rtsp
1.Make sure PC and LTC in the same LAN;
2.Open VLC software and input the following
URL for each stream;
3.Main stream: rtsp://IP:port/main.h264;
4.Sub stream: rtsp://IP:port/sub.h264;
5.The IP and port number can be checked with
RoomTracker software.
Rtmp
1.Make sure PC and LTC in the same LAN;
2.Setup rtmp server, such as FMS;
3.Enable rtmp from Setting>Network in
RoomTracker. Set rtmp stream ID such as
EST0, and input rtmp server IP (default port
is1935);
4.Open VLC and input the following:
rtmp://IP/live/TEST0.
Internet Explorer
1.Make sure PC and LTC in the same LAN;
2.Open Internet Explorer and Enter Internet
Options for Security Setting;
Mainly setting over the following two
options:

2
Meanwhile make sure the following setting
options are checked;
3. Input IP address+ port number 88 (default
is 88) in the IE address bar:
http://IP:88, such as:
http://192.168.18.229:88;
4.Install plugin;
5.Name: admin Password: NULL.
FEATURES
The lecturer tracking camera adopts the most
advanced face and motion detection
technology, it can lock and track moving target;
it can realize smooth tracking performance
automatically; it can precisely lock the moving
target in the center of the image.
With its stability, easy-to-use and excellent
performance, it is widely used in electronic
classroom, distance learning, technical
training and video conferencing room, etc.
Characteristics & Functions
Featured Advantages
Advanced face and motion detection
technology;
Integrated Full HD full view camera and Full
HD tracking camera;
The camera can track lecturer all around the
classroom, even if lecturer walks into students
area;
The camera can adjust automatically as per
the height of lecturer;
Excellent locking and anti-interference: the
camera keeps tracking on the object even the
object is still for a long period. Other moving
objects and video from projectors do not
interfere the tracking performance;

3
Precisely and stably track a specific target,
free from any light & moving interference;
Smart AE: keeps the same exposure with
considerable lighting variability;
Intelligent Tracking
Smooth tracking performance, free from
interference of other moving objects, also
even if the target turns around, stands still for
a long time or his / her other small gestures
will not affect the tracking effect;
Auto zoom performance during tracking.;
Suits all kinds of classroom with different size,
shape and type;
IP (Network)
H.264 video compression;
Support dual stream to output tracking
image;
Simple Configuration
1 priority zone, and 8 blocking zones can be
easily set through control software installed on
PC;
User-friendly interface, simple parameter
settings, parameters can be set via network.
List Of Parts & Accessories
When you open the box, check all accessories
according to the packing list.
Camera (1)
Power Adapter (1)
Remote Controller (1)
Cable Package (1)
USB Cable (1)
Software Disc (1)

4
Main Parts & Interfaces
Camera
Front View
1 Camera Module
2 Remote Controller Indicator
3 Power Indicator
4 Communication Indicator
5 Full-view camera
Rear View
6 Audio
7 TF Card Slot
8 RJ45 (Network)
9 DVI Video Output
10 3G-SDI
11 RS-232 / RS-485
12 USB
13 Power（DC12V）
Bottom View
14 Mounting Hole
1/4”inch screw thread for fixing camera.
15 Locating Hole
To define installation direction of camera.

5
Remote Controller
1 HOME
Press HOME button, camera moves to
initial position where both pan and tilt angle
is zero.
2 Camera Selection Button
Used to switch among 4 cameras, press 1-4
number buttons to control cameras with 1-4
addresses respectively. For example, press
button 1 to control the camera with address
1.
3 Focus
Press “AUTO” button to switch to Auto
Focus, press “MANU” button to switch to
Manual Focus mode.
“ ”button to Focus Near
“ ”button to Focus Far
“ ”button to Auto Focus once every time
it is pressed, then switch back to Manual
Focus mode.
4 Iris
Press“ ”button to reset iris value to
default. “ ”button to Iris Open
“ ”button to Iris Close.
5 Menu
Press MENU button to enter / exit menu.
6 Data
Press DATA button to set on / off the
display of pan tilt angel, zoom times and
other prompt message.
7 Number Keys
Used to input numbers, for example, preset
number.

6
8 Cancel
To cancel numbers input
9 Power
After the camera has been connected to
power source, in none-menu status, press
this button to turn on / off the camera.
10 Reserved buttons（F1, F2, F3, F4）
These buttons are reserved for future use.
11 Pattern
Used to activate Pattern Scan 1 and Pattern
Scan 2.
12 BLC
Used to open / close back light
compensation.
13 Zoom
Used to adjust zooming times.
“ ”button to zoom in
“ ”button to zoom out.
14 Back
Press“ ”button to go back to previous
menu.
15 OK
In None-menu status: press this button to
switch among pan / tilt control speeds.
In Menu status: get into relative menu
option after it has been selected.
16 Direction / Menu Operation
In None-menu status, press these four
buttons to pan left/right and tilt up/down.
In Menu status: or button to select
among menu options, or to change
option / value.
17 Preset Setting
“ ” button to call a preset.
Input number key(s), and then press this
button to call a preset.
“ ”button to set a preset.
Move the camera to a specific position,
adjust focus value and etc, and then press
this button to set a preset.
“ ”button to clear a preset.
Input number key(s), and then press this
button to clear a preset.
18 Enter
After inputting numbers, press this button to
confirm.

7
INSTALLATION
INSTRUCTIONS
The camera has 2 installation types: desktop,
wall (optional) installations.
Note
Before installing, make sure there
is enough space to install the
camera and its parts.
Make sure the installed place is
strong and safe enough to hold the
camera and relative parts, it is
suggested that the installed place
can withstand 4 times the weight of
the camera and its relative parts.
Desktop Mount Installation
1. Put the camera on a flat surface. In case
the camera has to be placed on an
inclined surface, make sure the cline
angle is less than 15 degrees to ensure
proper pan /tilt operation.
Note
Take effective measures to avoid
camera from dropping.
Do not grab the camera head
when carrying.
Do not rotate the camera head
with hand. It may cause
malfunction to the camera.
Wall Mount Installation
1. According to diameter and position of the
4 installation holes (As shown below) on
the bracket, drill 4 holes on the wall and fix
the bracket onto the wall by using 4
screws which should be prepared by you.
2. Before fixing the camera, set the DIP
switches of the camera correctly.
3. Use inch screws to fix the camera on the
bracket, fix the limit screw according to
actual requirement, and make sure the

8
camera is tightly fixed onto the bracket
before your hands leave the camera.
BLS Requirements
BLS device shall be installed up-left or
up-right of the blackboard, with a distance of
15~20cm from the blackboard. The viewangle
of the camera built in BLS is 90°. Please
capture the camera view and adjust the
installation position till the camera view is fully
covered to the whole blackboard and the
bottom boundaries of blue rectangle and the
blackboard in parallel, shown as follows:
SOFTWARE
CONNECTION
Setup RoomTracker from the disc in the
packing, and enter the main interface as
following.
The software will auto search all devices from
the same network and list all those found in
the camera list. Press the Search button and
the software will search again.
In CONFIGURE menu, select a camera in
the list to change camera parameters.
Network: Set camera IP and port. App port is
for SDK. Stream media is for rtsp and rtp
access to the camera (such as access to main
stream via VLC). Network type is to identify
camera IP type and address.
System: set camera name, time, RTSP (main
channel and sub channel), update PWD, and
reboot camera;

9
At the main interface, double click a device
from the camera list and the preview interface
will display the video of the device’s main
channel. Please use other stream media
players such as VLC to view the sub channel;
The control interface is under the camera
list, as follows:
Menu Button:
Click MENU and the camera menu will display
in the preview interface to set camera video
parameters; Click MENU again and the men
will disappear;
White Balance
White balance mode, two options: Auto WB,
one push WB.
Auto WB: The camera can automatically
adjust white balance (WB) according to the
alteration of background lightness to give a
true color image. Auto WB can be used for
general use.
One push WB: When the color of the video is
obviously incorrect, you can enable one push
trigger WB for color correction.
Operation of One push WB :
1. Have a person hold a A4 white paper,
make sure the paper is pointing directly to the
tracking camera.
2. Adjust the camera’s Pan / Tilt / Zoom until
the paper is able to cover the whole image
without finger or other objects.
3. Choose one push WB option, after waiting
for ten seconds when the image has been
adjusted, move away the paper.

10
Tracking Control
Start Tracking: Start the camera’s tracking
function;
Stop Tracking: stop camera’s tracking
function;
Tracking Setting
Click SETTING and a setting interface will be
displayed at the right side of the view interface
to set the tracking parameters of the selected
device; Click Save to save the parameter.
Click INQUIRE to verify if the set parameters
are saved.
For LTC device, the view interface will
display the videos of tracking camera (left)
and full-view camera (right). After setting,
the view will display the video of tracking
camera.

11
PARAMETERS
SETTING
Setting Process
Preset 0: It is a position that can be
configured to have the camera move to once
tracked object gets lost, recommended to set
at a full view image of the lecturing area. See
basic parameter settings for details.
Preset 1: Preset 1 is the position where
tracking starts, preferred to be set at Podium;
to configure it, move the camera’s
Pan/Tilt/Zoom to put the lecturer in the
appropriate size and position in the image,
then set it as preset 1. In some other cases,
the preset 1 is also useful: after camera
finishes calibration, it will sit at preset 1; once
tracking object gets lost, the camera can be
configured to move to preset 1; when the
camera starts auto zooming, its zooming
times is also based on preset 1’s zooming
times.
Preset 2: the position of BLS to determine the
P/T/Z level of the LTC .
Tracking Setting

12
Basic
The factory default setting of LTC is 1
(address), 9600bps, VISCA protocol,
1080P25 for tracking camera and full-view
camera.
Position Calibration: adjust the lecturer’s
position in the video when he/she is not in the
center.
Warning
The position has been adjusted to
the best value before leaving the
factory, do not change it until it is
necessary.
Adjust Head Height
User can adjust the head height in the view.
Debug
Enable and disable the rectangles of head
tracking of tracking camera and motion
detection of full-view camera.
Zone Set
Recommended to set the platform or podium as
priority zone, the camera will detect object from
this zone to start tracking accordingly. Set other
interference sources (like projector, digital
whiteboard, TV screen and etc) near the
platform or podium as blocking zones so the
camera will not track these sources. The
blocking zones must be inside the priority zone,
otherwise, there will be problem in blocking.
The camera’s tracking range can cover the
whole classroom, so the platform zone is
defined as a priority tracking zone.
Usually set the top edge of the blackboard as
the top boundary of the platform zone (at least
higher than the lecturer's head), and the bottom
boundary is higher than the students' head.
Blocking zones: There are 8 blocking zones
shown in green rectangle, they can be
configured independently. The moving
objects inside the blocking zones of the
full-view camera will not be detected and
tracked while the tracking camera still tracks
the lecturer head.
