HIK VISION DS-2CC11D3S-IR User manual

1
‘
Camera
User Manual
HD-SDI Camera
UD.6L0201D1078A01

HD-SDI Camera·User Manual
2
2
Thank you for purchasing our product. If there are any questions, or requests,
please do not hesitate to contact the dealer.
This manual applies to DS-2CC11D3S-IR, DS-2CC51D3S-VPIR.
This manual may contain several technical incorrect places or printing errors, and
the content is subject to change without notice. The updates will be added to the
new version of this manual. We will readily improve or update the products or
procedures described in the manual.
DISCLAIMER STATEMENT
“Underwriters Laboratories Inc. (“UL”) has not tested the performance or
reliability of the security or signaling aspects of this product. UL has only tested
for fire, shock or casualty hazards as outlined in UL’s Standard(s) for Safety,
UL60950-1. UL Certification does not cover the performance or reliability of the
security or signaling aspects of this product. UL MAKES NO REPRESENTATIONS,
WARRANTIES OR CERTIFICATIONS WHATSOEVER REGARDING THE
PERFORMANCE OR RELIABILITY OF ANY SECURITY OR SIGNALING RELATED
FUNCTIONS OF THIS PRODUCT.
0100001030609

HD-SDI Camera·User Manual
3
3
Regulatory Information
FCC Information
FCC compliance: This equipment has been tested and found to comply with the
limits for a digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference when
the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instruction manual, may cause harmful interference
to radio communications. Operation of this equipment in a residential area is
likely to cause harmful interference in which case the user will be required to
correct the interference at his own expense.
FCC Conditions
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that
may cause undesired operation.
EU Conformity Statement
This product and - if applicable - the supplied accessories too
are marked with "CE" and comply therefore with the
applicable harmonized European standards listed under the
Low Voltage Directive 2006/95/EC, the EMC Directive 2004/108/EC, the RoHS
Directive 2011/65/EU.
2012/19/EU (WEEE directive): Products marked with this
symbol cannot be disposed of as unsorted municipal waste in
the European Union. For proper recycling, return this product
to your local supplier upon the purchase of equivalent new

HD-SDI Camera·User Manual
4
4
equipment, or dispose of it at designated collection points. For more information
see: www.recyclethis.info.
2006/66/EC (battery directive): This product contains a
battery that cannot be disposed of as unsorted municipal
waste in the European Union. See the product
documentation for specific battery information. The battery
is marked with this symbol, which may include lettering to
indicate cadmium (Cd), lead (Pb), or mercury (Hg). For proper recycling, return
the battery to your supplier or to a designated collection point. For more
information see: www.recyclethis.info.
Safety Instruction
These instructions are intended to ensure that user can use the product correctly
to avoid danger or property loss.
The precaution measure is divided into “Warnings” and “Cautions”
Warnings: Serious injury or death may occur if any of the warnings are
neglected.
Cautions: Injury or equipment damage may occur if any of the cautions are
neglected.
Warnings Follow these
safeguards to prevent serious
injury or death.
Cautions Follow these precautions
to prevent potential injury or
material damage.

HD-SDI Camera·User Manual
5
5
Warnings
In the use of the product, you must be in strict compliance with the electrical
safety regulations of the nation and region.
Please refer to technical specifications for detailed information.
Input voltage should meet both the SELV (Safety Extra Low Voltage) and the
Limited Power Source with AC 24V or DC 12V according to the IEC60950-1
standard. Please refer to technical specifications for detailed information.
Do not connect several devices to one power adapter as adapter overload may
cause over-heating or a fire hazard.
Please make sure that the plug is firmly connected to the power socket.
When the product is mounted on wall or ceiling, the device shall be firmly
fixed.
If smoke, odor or noise rise from the device, turn off the power at once and
unplug the power cable, and then please contact the service center.
If the product does not work properly, please contact your dealer or the
nearest service center. Never attempt to disassemble the camera yourself.
(We shall not assume any responsibility for problems caused by unauthorized
repair or maintenance.)
Cautions
Make sure the power supply voltage is correct before using the camera.
Do not drop the camera or subject it to physical shock.

HD-SDI Camera·User Manual
6
6
Do not touch senor modules with fingers. If cleaning is necessary, use clean
cloth with a bit of ethanol and wipe it gently. If the camera will not be used for
an extended period, please replace the lens cap to protect the sensor from
dirt.
Do not aim the camera at the sun or extra bright places. Blooming or smearing
may occur otherwise (which is not a malfunction), and affect the endurance of
sensor at the same time.
The sensor may be burned out by a laser beam, so when any laser equipment
is in using, make sure that the surface of sensor will not be exposed to the
laser beam.
Do not place the camera in extremely hot, cold (the operating temperature
shall be-10℃~+60℃), dusty or damp locations, and do not expose it to high
electromagnetic radiation.
To avoid heat accumulation, good ventilation is required for operating
environment.
Keep the camera away from liquid while in use.
While in delivery, the camera shall be packed in its original packing, or packing
of the same texture.
Improper use or replacement of the battery may result in hazard of explosion.
Replace with the same or equivalent type only. Dispose of used batteries
according to the instructions provided by the battery manufacturer.

HD-SDI Camera·User Manual
7
7
Table of Contents
1 Introduction......................................................................................................9
1.1 Product Features ..............................................................................9
1.2 Overview........................................................................................10
2 Installation......................................................................................................12
2.1 Installation of HD-SDI Bullet Camera...............................................12
2.2 Installation of HD-SDI Dome Camera ..............................................14
3 Menu Description ...........................................................................................18
3.1 LENS ...............................................................................................18
3.2 EXPOSURE ......................................................................................19
3.2.1 Shutter ................................................................................19
3.2.2 AGC .....................................................................................20
3.2.3 SENS-UP...............................................................................20
3.2.4 Brightness............................................................................20
3.2.5 ACCE(Adaptive Contrast & Color Enhancement) ..................20
3.2.6 Defog...................................................................................21
3.2.7 Backlight..............................................................................21
3.2.8 White Balance (WB).............................................................24
3.3 Day & Night ....................................................................................25
3.4 NR ..................................................................................................26
3.5 SPECIAL ..........................................................................................27
3.5.1 Camera Title ........................................................................28
3.5.2 D-effect................................................................................29
3.5.3 Motion ................................................................................30
3.5.4 Privacy .................................................................................32
3.5.5 Language .............................................................................33
3.5.6 Defect..................................................................................34
3.5.7 RS485 ..................................................................................35

HD-SDI Camera·User Manual
8
8
3.5.8 Version ................................................................................35
3.6 ADJUST...........................................................................................36
3.6.1 Sharpness ............................................................................36
3.6.2 Monitor ...............................................................................37
3.6.3 OSD .....................................................................................39
3.6.4 LSC.......................................................................................39
3.6.5 NTSC/PAL.............................................................................39
3.7 RESET .............................................................................................40
3.8 EXIT ................................................................................................40

HD-SDI Camera·User Manual
9
9
1Introduction
1.1 Product Features
This series of camera adopts high-sensitive sensor and advanced circuit board
design technology. It features high resolution, low distortion, and low noise
features, etc., which make it extremely suitable for surveillance system and
image process system.
The main features of HD-SDI cameras are as follows:
2 Megapixel high-performance CMOS sensor
Clear and detailed image of up to 1080P resolution
Low illumination: 0.01Lux @ (F1.2,AGC ON), 0 Lux with IR
IR cut filter auto switch
Auto white balance, auto gain control, and backlight compensation for
different surveillance environment
Support Digital Wide Dynamic Range (D-WDR) for backlighting surveillance
OSD menu, parameters are configurable
Advanced 3-axis design
Ingress protection level reaches IP66

HD-SDI Camera·User Manual
10
10
1.2 Overview
Overview of HD-SDI Bullet CameraFigure 1-1
Table 1-1 Description
No.
Description
No.
Description
1
Mounting Base
6
OK Button
2
Adjustable Nut
7
SDI Cable
3
Sun Shield
8
Power Cable
4
Lens
9
Auxiliary Video Output
5
IR LED
10
RS485 Cable
1
2
3
4
5
69
10
8
7
OK

HD-SDI Camera·User Manual
11
11
Overview of HD-SDI Dome CameraFigure 1-2
Table 1-2 Description
No.
Description
No.
Description
1
Mounting Base
6
OK Button
2
Black Liner
7
SDI Cable
3
Lower Dome
8
Power Cable
4
IR LED
9
Auxiliary Video Output
5
Lens
10
RS485 Cable
1
2
3
4
5
6
7
8
9
10
OK

HD-SDI Camera·User Manual
12
12
2Installation
Before you start:
Please make sure that the device in the package is in good condition and all
the assembly parts are included.
Make sure that all the related equipment is power-off during the installation.
Check the specification of the products for the installation environment.
Check whether the power supply is matched with your AC outlet to avoid
damage.
If the product does not function properly, please contact your dealer or the
nearest service center. Do not disassemble the camera for repair or
maintenance by yourself.
Please make sure the wall is strong enough to withstand three times the
weight of the camera.
2.1 Installation of HD-SDI Bullet Camera
Steps:
1. Drill the screw holes in the wall according to the drill template.

HD-SDI Camera·User Manual
13
13
Drill TemplateFigure 2-1
2. Route the corresponding cables.
3. Fix the camera to the wall with the supplied P A4 screws.
Secure the Camera to the WallFigure 2-2
φ68
55
φ
φ4
Cutting line
Screw Hole
Template

HD-SDI Camera·User Manual
14
14
4. Connect the video output cable to the monitor. Connect the power cable to
the power supply.
5. Adjust the Lens.
1). Loosen the adjustable nut.
2). Adjust the camera from pan direction which is 0~360°adjustable.
3). Adjust the camera from tilt direction which is 0~90°adjustable.
4). Rotate 0~360°to adjust the lens to the surveillance angle.
5). Tighten the adjustable nut to complete the installation.
3-axis AdjustmentFigure 2-3
2.2 Installation of HD-SDI Dome Camera
Steps:
1. Drill the screw holes on the ceiling according to the drill template.
Adjustable
Nut
T Direction
R Direction
PDirection

HD-SDI Camera·User Manual
15
15
Drill TemplateFigure 2-4
2. Loosen the set screws with a hex key (supplied) to remove the lower dome.
Remove the Lower DomeFigure 2-5
Hole
Hole Hole
Ceiling Mounting

HD-SDI Camera·User Manual
16
16
3. Fix the mounting base on the ceiling with screws.
Fix the Mounting BaseFigure 2-6
Note: If required, you can route cables through the side opening on the side
of the mounting base.
Side OpeningFigure 2-7
4. Loosen the tilt lock screws, adjust the tilting position in a range of 65
degrees, and tighten the tilt lock screws.
Side Opening

HD-SDI Camera·User Manual
17
17
5. Rotate the black liner to adjust the panning position in a range of 180
degrees until you get the desired surveillance angle.
Angle AdjustmentFigure 2-8
Note: As the lens has already been factory adjusted to the best imaging effect,
you just need to adjust the panning position and tilting position to get the
desired surveillance angle.
6. Reinstall the lower dome and tighten the screws.
Lower Dome ReinstallationFigure 2-9
Tilt Lock Screw
Black Liner
PAN
TILT

HD-SDI Camera·User Manual
18
18
3Menu Description
Main Menu OverviewFigure 3-1
Notes:
The OK button on the cable is used to control the menu.
Press the OK button up/down to select the menu item.
Press the OK button left/right to adjust the value.
OK button is also used to confirm a selection.
3.1 LENS
The camera is equipped with a fixed lens, which is not configurable.

HD-SDI Camera·User Manual
19
19
3.2 EXPOSURE
EXPOSURE
SHUTTER AUTO
AGC OFF
SENS-UP ---
BRIGHTNESS ---|------ 40
ACCE OFF
DEFOG OFF
BACKLIGHT OFF
RETURN RET
ExposureFigure 3-2
Exposure describes the brightness-related parameters. You can adjust the image
brightness by the SHUTTER, AGC, SENS-UP, BRIGHTNESS, ACCE, BACKLIGHT, etc.
in different light conditions.
3.2.1 Shutter
Shutter denotes the speed of the shutter.
AUTO,1/25, 1/50, FLK, 1/250, 1/500, 1/1k, 1/2k, 1/5k, 1/10k, 1/50k, x2, x4, x6, x8,
x10, x15, x20, x30, and x60 are selectable.
Note:
If you select shutter as AUTO or 1/25, the SENS-UP is adjustable (OFF/AUTO), and
the SENS-UP is disabled if any other shutter speed is selected.

HD-SDI Camera·User Manual
20
20
3.2.2 AGC
It’s a form of amplification where the camera will automatically boost the image
received in much lower light conditions than standard in order to optimize the
clarity of image in poor light scene. OFF, LOW, MIDDLE, and HIGH are selectable
for the AGC value.
Note:
The noise will be amplified if the AGC is on.
3.2.3 SENS-UP
SENS-UP increases the exposure on a signal frame, which makes a camera more
sensitive to light so it can produce images even in low lux conditions. You can set
the SENS-UP to OFF or AUTO according to different light conditions.
OFF: SENS-UP function is disabled.
AUTO: The SENS-UP function will atomically adjust itself to x2, x4, x6, x8, x10,
x15, x20, x30, and x60 according to the different light conditions.
3.2.4 Brightness
Brightness refers to the brightness of the image. You can set the brightness value
from 1 to 100 to darken or brighten the image. The higher the value is, the
brighter the image is.
3.2.5 ACCE(Adaptive Contrast & Color Enhancement)
It performs an image enhancement processing to enhance the visibility of an
image by expressing the contrast ratio of the image and improving the edge
information of the image effectively.
You can set the ACCE to OFF, LOW, MIDDLE, and HIGH.
