Kensington VCM43A14V User manual

RENAELCMUUCAV
INSTRUCTION MANUAL
MODEL VCM43A14V

If the supply cord is damaged,
it must be replaced by the
manufacturer or its service
agent or a similarly qualified
person in order to avoid a
hazard.
This appliance is not intended
for use by persons (including
children) with reduced physical,
sensory or mental capabilities,
or lack of experience and
knowledge, unless they have
been given supervision or
instruction concerning use of
the appliance by a person
responsible for their safety.
Children should be supervised
to ensure that they do not play
with the appliance.
The plug must be removed from
the power socket before
cleaning, maintenance or
replacement.
The hose should be checked
regularly and must not be used
if damaged.
The appliance is for household
use only.
Never leave the appliance
unattended when it is switched
on.
Read the manual carefully and
keep it secure for future use.
Before the first operation, make
sure all parts are correctly
installed.
Make sure the power supply is
220-240V~ 50/60Hz.
Do not suck up liquids or
flammable material.
Do not suck up burning material
or ash.
Do not use the appliance
without the filters in place.
Please empty the dust bin
immediately when it is full (dirt
reached MAX line).
Do not store or use the
appliance close to high
temperature sources (heaters).
If abnormal noise, smell, smoke
or any other failure or breakage
is found during the operation,
immediately turn off the switch
and unplug it. Contact an
authorised service centre, Do
not attempt repair by yourself.
For indoor use only, do not
expose to water.
Important Safety Instructions
1
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•

Product and accessory overview
Turbo brush
4. Floor Head
(Adjustable length)
10
10. Dust Collection Container

3
•
•
How to Use
Attaching the tools
To connect the hose, insert the
hose end connector into the hose
socket at the front of the vacuum
cleaner until it clicks.
To remove the hose, press the
button on the hose connector and
pull out the hose.
Connect the adjustable extension
tube to the curved end of the
hose. The shorter end of the tube
is connected to the hose.
Connect the other end of the
extension tube to the floor head.
Make sure the tool is attached
securely before use. You can
choose Hard Floor or Carpet
cleaning by pushing the selector
on the floor tool (bristles
extended for hard floor).
Operation
Extend the power cable until you
see the yellow mark. Make sure
the red mark is not visible.
When cleaning is finished, turn off
the power, unplug and push the
cable retract button until the
cable has fully retracted.
Tube length can
be adjusted by
pushing the unlock
button and sliding
the inner tube up
or down, release
button to lock in
position.
Note: Accessory holder can
be slid onto the extension
tube and then used to
support accessories.

•
Care and Maintenance
Emptying the dust collection
container
Hold the handle of the dust
collection container and push
the release button, Lift the
container away from the
machine.
Hold the collection container
above the rubbish bin, push the
release button to the open the
bottom of the container, and
empty the contents. Close the
collection container bottom lid
after emptying.
4
•Turbo Brush
The turbo brush can be used on both
carpet and hard floor surfaces.
It provides a deeper clean for
carpeted floors (also good for
efficiently collecting pet hair).
To switch ON or OFF, press the
power button as shown below.
Use the slider to adjust the suction
power for different cleaning
purposes.

5
Cleaning the filters
The filters should be periodically
checked and cleaned if
necessary. Frequency of cleaning
will vary with amount of use and
volume of dust collected.
WARNING: The performance of
the vacuum will be severely
compromised if the filters are not
regularly cleaned.
The filters must be correctly fitted
before using the vacuum cleaner
again.
Filters should be hand washed in
warm water only and allowed to
air dry. Do not wash the filters in a
washing machine or dry them in a
dryer.
Do not use the filters while they are
wet. This will reduce the suction
power and damage the motor.
1. Press the outlet lock to open the
outlet cover, take out the outlet
filter.
2. Press the button of front cover to
open the dust bin, Take the HEPA
filter out from the dust bin,
Wash the cyclone assembly.
WARNING:
Only use water without detergent
when you wash the filters, the
cyclone assembly, the inlet cover
and the dust collection container.
Dry them throughly before use.
3. Replace the cyclone assembly
and the filter in the dust container.
When you place the filter on the
cyclone assembly, rotate the filter
until it locks in position.
Make sure the parts are in correct
positions.
Carefully place the dust collection
container on the vacuum cleaner
main body. Gently push the dust
container until it clicks and locks in
position.
If the dust collection container
does not click and lock, make sure
it is aligned correctly.
•

6
