Kenstar KK23SSL2 User manual

Please read this instruction manual carefully before operating your machine. Retain it for future reference.
Record model name & serial number of the machine. Please quote this information when you require service.
OWNER'S MANUAL
USER GUIDE PRINTING IN BLACK COLOUR
A5 size - 296mm (w) x 210mm (h)
MICROWAVE : KK23SSL2
DISPLAY
Power
Time Cook
Popcorn
Sweets
Time Defrost
Clock
Snacks
Beverages
Weight Defrost
Child Dish
Meal
Kitchen Timer

1
CONTENTS
PRECAUTION
SPECIFICATIONS
IMPORTANT SAFETY INSTRUCTIONS
GROUNDING INSTALLATION / CLEANING
MATERIALS TO BE USED & AVOIDED
SETTING UP YOUR OVEN
INSTALLATION
OPERATING INSTRUCTIONS
2
2
2,3
4
5
6
7
8-19
* Design and specification are subjected to change without prior notice.
PAGE NO.
TROUBLE SHOOTING 20
WARRANTY
BRANCH OFFICES
(AUTOCOOK RECIPES FROM PAGE NO:- 12 - 17)

2
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY
SPECIFICATIONS
Model
Rated Voltage
Rated Input Power(Microwave)
Rated Output Power(Microwave)
Oven Capacity
Turntable Diameter
External Dimensions(LxWxH)
Net Weight
KK23SSL2
230V~ 50Hz
1250 W
800 W
23 L
ø 270 mm
485 X 410 X287 mm
Approx 13.2 kg
(a) Do not attempt to operate this oven with the door open since this can result
in harmful exposure to microwave energy. It is important not to break or
tamper with the safety interlocks.
(b) Do not place any object between the oven front face and the door or allow
soil or cleaner residue to accumulate on sealing surfaces.
(c) WARNING: If the door or door seals are damaged, the oven must not be
operated until it has been repaired by a competent person.
ADDENDUM
If the apparatus is not maintained in a good state of cleanliness, its surface
could be degraded and affect the life span of the apparatus and lead to a
dangerous situation.
IMPORTANT SAFETY INSTRUCTIONS
1. Warning: Liquids and other foods must not be heated in sealed containers
since they are liable to explode.
2. Warning: It is hazardous for anyone other than a competent person to remove
a cover which gives protection against exposure to microwave energy.
3. Warning: Only allow children to use the oven without supervision when
adequate instructions have been given so that the child is able to use the oven
in a safe way and understand the hazards of improper use.
4. Warning: When the appliance is operated in the combination mode,
children should only use the oven under adult supervision due to the
temperatures generated. (only for grill series)
WARNING To reduce the risk of fire, electric shock, injury to persons or exposure to
excessive microwave oven energy when using your appliance, follow basic
precautions, including the following:

3
IMPORTANT SAFETY INSTRUCTIONS
5. Only use utensils suitable for use in microwave ovens.
6. The oven should be cleaned regularly and any food deposits should be
removed.
7. Read and follow the specific: "PRECAUTIONS TO AVOID POSSIBLE
EXPOSURE TO EXCESSIVE MICROWAVE ENERGY".
8. When heating food in plastic or paper containers, keep an eye on the oven
due to the possibility of ignition.
9. If smoke is observed, switch of f or unplug the appliance and keep the door
closed in order to stifle any flames.
10. Do not overcook food.
11. Do not use the oven cavity for storage purposes. Do not store items, such
as bread, cookies, etc. inside the oven.
12. Remove wire twist-ties and metal handles from paper or plastic
containers/bags before placing them in the oven.
13. Install or locate this oven only in accordance with the installation
instructions provided.
14. Eggs in the shell and whole hard-boiled eggs should not be heated in
microwave ovens since they may explode, even after microwave heating
has ended.
15. Use this appliance only for its intended uses as described in manual.
Do not use corrosive chemicals or vapors in this appliance.
This oven is especially designed to heat. It is not designed for industrial or
laboratory use.
16. If the supply cord is damaged, it must be replaced by the manufacture,
its service agent or similarly qualified persons in order to avoid a hazard.
17. Do not store or use this appliance outdoors.
18. Do not use this oven near water, in a wet basement or near a swimming
pool.
19. The temperature of accessible surfaces may be high when the appliance is
operating. Keep cord away from heated surface, and do not cover any
events on the oven.
20. Do not let cord hang over edge of table or counter.
21. Failure to maintain the oven in a clean condition could lead to deterioration
of the surface that could adversely affect the life of the appliance and
possibly result in a hazardous situation.
22. The contents of feeding bottles and baby food jars shall be stirred or
shaken and the temperature checked before consumption, in order to
avoid burns.
23. Microwave heating of beverages can result in delayed eruptive boiling,
therefore take care when handling the container.
24. The appliance is not intended for use by persons (including children) with
reduced physical , sensory or mental capabilities, or lack of experience
and knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
25. Children should be supervised to ensure that they do not play with the
appliance.
26. The microwave oven shall not be placed in a cabinet.

4
TO REDUCE THE RISK OF INJURY TO PERSONS GROUNDING INSTALLATION
DANGER: Electric Shock Hazard Touching some of the internal components can
cause serious personal injury or death. Do not disassemble this appliance.
WARNING: Electric Shock Hazard Improper use of the grounding can result in
electric shock. Do not plug into an outlet until appliance is properly installed and
grounded.
CAUTION: Personal Injury Hazard
It is hazardous for anyone other than a competent person to carry out any service
or repair operation that involves the removal of a cover which gives protection
against exposure to microwave energy.
UTENSILS: See the instructions on "Materials you can use in microwave oven or
to be avoided in microwave oven." There may be certain non-metalic utensils that
are not safe to use for microwaveing. If in doubt, you can test the utensil in
question following the procedure below.
Utensil Test:
1. Fill a microwave-safe container with 1 cup of cold water (250ml) along with
the utensil in question.
2. Cook on maximum power for 1 minute.
3. Carefully feel the utensil. If the empty utensil is warm, do not use it for
microwave cooking.
4. Do not exceed 1 minute cooking time.
CLEANING
Be sure to disconnect the oven from the power supply.
1. Clean the inside of the oven after using with a slightly damp cloth.
2. Clean the accessories in the usual way in soapy water.
3. The door frame and seal and neighboring parts must be
cleaned carefully with a damp cloth when they are dirty.
This appliance must be grounded. In the event of an electrical short circuit, grounding
reduces the risk of electric shock by providing an escape wire for the electric current.
This appliance is equipped with a cord having a grounding wire with a grounding plug.
The plug must be plugged into an outlet that is properly installed and grounded.
Consult a qualified electrician or serviceman if the grounding instructions are not
completely understood or if doubt exists as to whether the appliance is properly
grounded. If it is necessary to use an extension cord, use only a 3-wire extension
cord.
1. A short power-supply cord is provided to reduce the risks resulting from
becoming entangled in or tripping over a longer cord.
2. If a long cord set or extension cord is used:
1) The marked electrical rating of the cord set or extension cord should be
at least as great as the electrical rating of the appliance.
2) The extension cord must be a grounding type 3-wire cord.
3) The long cord should be arranged so that it will not drape over the counter
top or tabletop where it can be pulled on by children or tripped over
unintentionally.
Three-round-pin plug

5
MATERIALS YOU CAN USE IN MICROWAVE OVEN
Use as a cover to prevent splattering and retain moisture. Do not allow plastic wrap
to touch food.
Wax paper
Microwave-safe only (meat and candy thermometers).
Thermometers
Plastic wrap Microwave-safe only. Use to cover food during cooking to retain moisture.
Do not allow plastic wrap to touch food.
Plastic Microwave-safe only. Follow the manufacturer’s instructions. Should be labeled
"Microwave Safe". Some plastic containers soften, as the food inside gets hot.
"Boiling bags" and tightly closed plastic bags should be slit, pierced or vented as
directed by package.
Parchment
paper
Use as a cover to prevent splattering or a wrap for steaming.
Paper towels Use to cover food for reheating and absorbing fat. Use with supervision for a
short-term cooking only.
Paper plates
and cups
Use for short–term cooking/warming only. Do not leave oven unattended while
cooking.
Oven cooking
bags
Follow manufacturer’s instructions. Do not close with metal tie. Make slits to
allow steam to escape.
Glassware Heat-resistant oven glassware only. Make sure there is no metallic trim. Do not
use cracked or chipped dishes.
Glass jars Always remove lid. Use only to heat food until just warm. Most glass jars are not
heat resistant and may break.
Aluminum foil
Shielding only. Small smooth pieces can be used to cover thin parts of meat or
poultry to prevent overcooking. Arcing can occur if foil is too close to oven
walls. The foil should be at least 2.5cm away from oven walls.
Remarks
Utensils
Browning dish Follow manufacturer’s instructions. The bottom of browning dish must be at
least 5mm above the turntable. Incorrect usage may cause the turntable to break.
Dinnerware Microwave-safe only. Follow manufacturer's instructions. Do not use cracked
or chipped dishes.
MATERIALS TO BE AVOIDED IN MICROWAVE OVEN
Remarks
Utensils
Aluminum tray
Food carton with
metal handle
Metal or metal
trimmed utensils
Metal twist ties
Paper bags
Plastic foam
Wood
May cause arcing. Transfer food into microwave-safe dish.
May cause arcing. Transfer food into microwave-safe dish.
Metal shields the food from microwave energy. Metal trim may
cause arcing.
May cause arcing and could cause a fire in the oven.
May cause a fire in the oven.
Plastic foam may melt or contaminate the liquid inside when exposed
to high temperature.
Wood will dry out when used in the microwave oven and may split
or crack.

6
SETTING UP YOUR OVEN
A) Control panel
B) Turntable shaft
C) Turntable ring assembly
D) Glass tray
E) Observation window
F) Door assembly
G) Safety interlock system
Names of Oven Parts and Accessories
Remove the oven and all materials from the carton and oven cavity.
Your oven comes with the following accessories:
Glass tray : 1
Turntable ring assembly : 1
Instruction Manual : 1
Turntable Installation
Shut off oven power if the door is opened during operation.
Hub (underside)
Glass tray
Turntable shaft
Turntable ring assembly
a. Never place the glass tray upside
down. The glass tray should never
be restricted.
b. Both glass tray and turntable ring
assembly must always be used
during cooking.
c. All food and containers of food are
always placed on the glass tray for
cooking.
d. If glass tray or turntable ring
assembly cracks or breaks, contact
your nearest authorized service
center.
Countertop Installation
Remove all packing material and accessories. Examine the oven for any
damage such as dents or broken door. Do not install if oven is damaged.
Cabinet: Remove any protective film found on the microwave oven cabinet
surface.
Do not remove the light brown Mica cover that is attached to the oven
cavity to protect the magnetron.
DISPLAY

7
INSTALLATION
1. Select a level surface that provide enough open space for the intake
and or outlet vents.
A minimum clearance of 7.5cm is required between the oven and any
adjacent walls. One side must be open.
(1) Leave a minimum clearance of 30cm above the oven.
(2) Do not remove the legs from the bottom of the oven.
(3) Blocking the intake and/or outlet openings can damage the oven.
(4) Place the oven as far away from radios and TV as possible. Operation
of microwave oven may cause interference to your radio or TV
reception.
2. Plug your oven into a standard household outlet. Be sure the voltage and
the frequency is the same as the voltage and the frequency on the rating
label.
WARNING: Do not install oven over a range cook top or other heat-
producing appliance. If installed near or over a heat source, the
oven could be damaged and the warranty would be void.

1. Power Level
11 power levels are available.
Level
Power
Display
10
100%
PL10
9
90%
PL9
8
80%
PL8
7
70%
PL7
6
60%
PL6
5
50%
PL5
4
40%
PL4
3
30%
PL3
2
20%
PL2
1
10%
PL1
0
0%
PL0
2 Clock Setting
1) Press " CLOCK "once, "00:00" will display.
2) Press the number keys and enter the current time. For example,
time is 12:10 now, please press "1,2,1,0" in turn.
3) Press " CLOCK " to finish clock setting. ":" will flash and the clock will
be lighted.
4) If the numbers input are not within the range of 1:00--12:59, the setting
will be invalid until valid numbers are input.
Note: 1) In the process of clock setting, if the " STOP/CANCEL " button is
pressed or if there is no operation within 1 minute, the oven will go
back to the former setting automatically.
2) If the clock need to be reset, please repeat step 1 to step 3.
.
3 Kitchen Timer
1) Press "KITCHEN TIMER " , LED will display 00:00, the first hour figure
flash.
2) Press the number keys and enter the timer time.
(the maximum cooking time is 99 minutes and 99 seconds)
3) Press " START/+30SEC. " to confirm setting.
4) When the timer time arrives, the buzzer will ring 5 times.
If the clock be set (12-hour system), LED will display the current time.
Note: 1) The kitchen time is differ from 12-hour system, Kitchen Timer is a timer.
2) During kitchen timer, any program cannot be set.
.
4 Microwave cook
1) Press "TIME COOK" once, LED will display "00:00".
2) Press number keys to input the cooking time; the maximum cooking time
is 99 minutes and 99 seconds.
3) Press " POWER " once, LED will display "PL10". The default power is
100% power. Now you can press number keys to adjust the power level.
4) Press " START/+30SEC." to start cooking.
.
8
OPERATING INSTRUCTIONS

6. Weight Defrost Function
1) Press " W.T./TIME DEFROST "once, LED will display "dEF1".
2) Press numerical buttons to input weight to be defrosted. Input the weight
ranged between 100~2000 g.
3) If the weight input is not within 100~2000, the input will be invalid.
A "beep" will be sound and the unit will not work until valid numbers are
input .
4) Press " START/+30SEC. " to start defrosting and the cooking time
remained will be displayed.
9
Example: to cook the food with 50% microwave power for 15 minutes.
a. Press "TIME COOK" once."00:00" displays.
b. Press "1","5","0","0" in order.
c. Press "POWER" once, then press "5" to select 50% microwave power.
d. Press "START/+30SEC." to start cooking.
Note: 1) In the process of cooking, if the " STOP/CANCEL" button is pressed or
if there is no operation within 1 minute, the oven will go back to the
former setting automatically.
2) If "PL0" selected, the oben will work with fan for no power. You can use
this level to remove the odour of the oven.
3) During microwave cooking, "POWER" can be pressed to change the
power you need. After pressing "POWER",the current power flash for 3
seconds, now you can press number button to change the power. The
oven will work with the selected power for the rest time.
5. Speedy Cooking
1) In waiting state, instant cooking at 100% power level can be started by
select a cooking time from 1 to 6 minutes by pressing number pads1 to 6.
Press " START/+30SEC." to increase the cooking time; the maximum
cooking time is 99 minutes and 99 seconds.
2) In waiting state, instant cooking at 100% power level with 30 seconds'
cooking time can be started by pressing " START/+30SEC ". Each press
on the same button will increase cooking time by 30 seconds. the
maximum cooking time is 99 minutes and 99 seconds.
Note: during microwave cooking and time defrost, time can be added by
pressing "START/30SEC." button.
OPERATING INSTRUCTIONS

10
7. Time Defrost Function
1) Press " TIME DEFROST " , LED will display "dEF2".
2) Press number pads to input defrosting time. The effective time range is
00:01~99:99
3) The default microwave power is power level 3. If you want to change the
power level, press " POWER " once, and the LED will display "PL 3", then
press the number pad of the power level you wanted.
4) Press " START/+30SEC. " to start defrosting. The remained cooking time
will be displayed.
8. POPCORN
a) Press " POPCORN " repeatedly until the number you wish appears in the
display, "50","100" grams will display in order.
For example, press "POPCORN" once , "50" appears.
b) Press " START/+30 SEC. " to cook, buzzer will sound five times and then
turn back to waiting state.
Important Information About Microwave Popcorn Feature
1. When selecting 100 grams of popcorn, it is suggested
that you fold down a triangle on each corner of the bag
before cooking. Refer to the picture at right.
2. If/When the popcorn bag expands and no longer
rotates properly, please press STOP/CANCEL
button once and open the oven door and adjust the bag
position to ensure even cooking.
OPERATING INSTRUCTIONS

STOP
Cancel
START
+30 SEC.
Memory
Power
Time Cook
Popcorn
Sweets
Time Defrost
Clock
Snacks
Beverages
Weight Defrost
Child Dish
Meal
Kitchen Timer
9. AUTO-MENU
You only need to select the food type and weight, it will help you to automatically
adjust the power and time.
Example: Auto cooking 0.4 kg “Milk Cake(A5)”
a) Press "Sweets” button.
b) Select the desired recipe by pressing the button until "A5" is displayed
then Press Start to confirm.
c) Press “Sweets” button to select the desired weight of recipe and Press
Start to initiate.
11
HOW TO AUTOCOOK A RECIPE? Recipes Page
SWEETS
BEVERAGES
CHILD DISHES
SNACKS
MEAL
A1 Suji Halwa
A2 Gajjar Halwa
A3 Coconut Barfi
A4 Saviya Kheer
A5 Milk Cake
A6 Sweet Rice
b1 Sweet Corn Soup
b2 Tea
b3 Coffee
c1 Noodles
c2 Fruit/Apple jam
c3 Corn Chat
c4 Macroni
Sn1 Idle
Sn2 Poha
Sn3 Dhokla
L1 Bhindi masala
L2 Dal
L3 Chicken Masala
L4 Shahi Paneer
12-13
13-14
14-15
15
16-17
OPERATING INSTRUCTIONS
Step:-1 Press food type to select recipe.
Step:-2 Press Start button to confirm.
Step:-4 Press Start button to Initiate cooking.
Step:-3 Press food type again to select weight.

12
SWEETS AUTOCOOK RECIPES
Recipe
Code Ingredients Weight Process
0.2kg
100gm
2 tbsp
½ cup 3/4 cup
2 cup
1 cup
3 cup 4 cup
As per your taste.
150gm 200gm
4 tbsp 6 tbsp
0.3kg 0.4kg Utensil: MWS Glass Bowl
A1
A2
SUJI
HALWA
GAJJAR
KA
HALWA
Suji
Ghee
Sugar
Water
Elaichi Powder &
Dry Fruit
1. In MWS glass bowl take suji
& ghee select menu & press Start
2. When beep. Stir and again
press start.
3. When beep add water, sugar,
dry fruits & Elacichi powder mix
well & press start.
0.5kg
300gm
2 tbsp
5 tbsp
4 tbsp
4 tbsp
As per your taste.
Grated Gajar
Ghee
Milk Powder
Khoya
Sugar
Milk
Elaichi Powder
& Dry Fruit
1. In MWS glass bowl take gajar and
ghee, mix it well then select Menu
and Press Start.
2. When beep add milk powder, milk,
khoya and sugar ,mix it well and
Press Start .
3. Again when beep add elachi
powder dry fruit mix it well and Press
Start..
Utensil: MWS Glass Bowl
A3
A4
COCONUT
BURFI
Utensil: MWS Glass Bowl
½ cup
0.2kg
40gm
40gm
120gm
½ tbsp
1 pinch
Fresh Coconut
Khoya
Sugar
Elaichi Powder
Edible Yellow
Colour
1. In MWS Bowl, mix all the
ingredients. Select Menu & Press
Start.
2. When Beep mix well &Press
Start.
3. When beep mix it well and
keep it cool.
0.2 kg
As per your taste.
Utensil: MWS Glass Bowl
SAVIYA
KHEER
1. In MWS glass bowl add
Saviya and Ghee. Select Menu
and Weight and Press Start.
2. When beep add milk and
press start.
3. When beep add badam,Pista,
Kesar, Elaichi powder,sugar. Mix
well and Press start.
Saviya
Hot Milk
Sugar
Ghee
Badam,Pista,
Kesari, Elaichi
Powder
100gm
100 ml

13
SWEETS AUTOCOOK RECIPES
Recipe
Code Ingredients Weight Process
Utensil: MWS Glass Bowl
0.3kg
200gm
100gm
2 tbsp
1 tsp
1 tsp
4 tbsp
2tsp
2tsp
300gm
200gm
0.5kg
A5 MILK
CAKE
Grated Paneer
Milkmaid
Milk Powder
Cornflourr
Elaichi Powder
1. In MWS glass bowl take
grated paneer, milkmaid and milk
powder and mix them well.Select
menu and weight. Press Start.
2. When beep add cornflour,
elaichi powder, mix it again and
Press Start. Garnish with dry
fruit. When all set cut into pieces.
0.2 kg
200 gm
3/4 cup
As per your taste.
Utensil: MWS Glass Bowl
A6 SWEET
RICE
Soaked Rice
Sugar
Lemon Juice
Dry Fruits & Elaichi
Powder
Edible Yellow colour
Ghee
1. In MWS bowl take ghee &
soaked Rice select Menu & Press
start.
2. When beep add water, cover it
& press start.
3. When beep add sugar, dry
fruits, colour, Elachi Powder,
mix well & press start.
1½ tsp
BEVERAGES
0.2kg 0.4kg 0.6kg Utensil: MWS Glass Bowl
b1
SWEET
CORN
SOUP
Ready to eat corn
soup powder
Water
50 gm
150 ml
75 gm
325 ml
100 gm
500 ml
1. In MWS bowl add corn soup
and water, mix ingredients well.
Select menu and Press Start.
2. When beep mix well and again
Press Start.
3. When Beep serve hot and
garnish with hara dhaniya.
2 cups Utensil: MWS Glass Bowl
b2 TEA
Tea Leaves
Milk
Sugar
Tea Masala
Ginger
Elaichi
1. In MWS bowl add all
ingredients. Select menu and
Press Start..
As per your taste.

14
BEVERAGES AUTOCOOK RECIPES
Recipe
Code Ingredients Weight Process
2 cups Utensil: MWS Glass Bowl
b3 COFFEE
Coffee Powder
Milk
Sugar
1. In MWS bowl add all
ingredients. Select menu and
Press Start..
As per your taste.
CHILD DISH AUTOCOOK RECIPES
Recipe
Code Ingredients Weight Process
0.3 Kg Utensil: MWS Glass Bowl
c1
1. In MWS bowl take noodles,
water,Select Menu and Press start.
2. When Beep add maggi masala
and mix well and Press start.
Serve hot.
NOODLES
Noodles(maggi)
Water 3 cup
150gm
Utensil: MWS Glass Bowl
c2
FRUIT
APPLE
JAM
Apples
Sugar
Lemon Juice
1 cup
1 tbsp
0.5kg
300gm 1. Peel the apple and cut into
Pieces. In MWS bowl take apple
pieces with 2 tbsp water. Select
Menu & Press start.
2. When beep grind it in a blender
take it in MWS bowl. Add sugar
and lemon juice. Press start.
0.3 Kg
300gm
100ml
Utensil: MWS Glass Bowl
c3 CORN
CHAT
Sweet Corn
Water
Salt, Sugar,Butter
Chat masala
Pepper powder
1. In MWS glass Bowl take sweet
corn with water select Menu and
Press Start.
2. When beep drain water and add
salt, sugar, butter, chat masala and
pepper powder mix well and serve
hot.
As required

SNACKS
AUTOCOOK RECIPES
AUTOCOOK RECIPES
Utensil: MWS Glass Bowl
Sn2 POHA
Poha
Oil
Onion Chopped
Green Chilli
Rai, Jeera Hing,
Haldi, Curry Leaves
Grated Coconut &
Hara Dhaniya
1. In MWS Bowl put oil rai,
jeera, green chilli, curry leaves.
Select Menu and Weight and
Press Start.
2.When beep add chopped onion,
haldi powder, hing. Press Start.
3. When beep add washed phoa,
salt and sugar to taste. Mix well
and press start. Garnish coconut
and hara dhaniya. Serve hot.
1 tbsp 2 tbsp 3 tbsp
½ cup
2 Nos 3 Nos 4 Nos
1 cup 1 cup
For Tempering.
For Tempering.
0.2kg
0.1kg
0.3kg
0.2kg
0.4kg
0.3kg
CHILD DISH
Recipe
Code Ingredients Weight Process
8 Nos
2 cups
1 cup
Utensil: MWS Idli Stand
Sn1 IDLI
Instant Idli Mix
Curd
Ginger garlic chilli
paste and salt
Water
1. Mix all the ingredients and
make a batter, pour this batter to
greased Idli stand. Select menu
& Press start. Serve hot with
Chutney & Sambhar.
As per your taste.
As required.
Utensil: MWS Glass Bowl
c4
300gm150gm
700ml350ml
4 tbsp2 tbsp
4 tbsp2 tbsp
5 tbsp2 tbsp
5 nos3 nos
6 tbsp3 tbsp
4 tbsp2 tbsp
MACRONI
Macaroni
Hot Water
Butter
SpringOnion(chopped)
Garlic (chopped)
Mushrooms(chopped)
Tomato Sauce
Chilli Sauce
Salt, Sugar, Pepper &
Oregano
1. In MWS bowl take Macaroni
with hot water. Select Menu &
Weight and Press Start.
2. Drain water from it. In MWS
bowl add all the ingredients with
boiled Macroni, mix well &
Press Start.
As per your taste.
0.4kg0.2kg
0.2 Kg
200gm
Utensil: MWS Glass Bowl
Sn3 DHOKLA
1. Grease the MWS flat dish, with
little oil. Mix besan curd, sugar,
salt, water, ginger- green chilli
paste, yellow colour,fruit salt
together.
2. Pour the mixture in greased dish
select Menu and Press Start. Cut it
into pieces, garnish with grated
coconut and hara dhania and serve
with sauce or chutney.
Besan
Warm Water
Curd
Green chilli-ginger
paste
Fruit Salt
1½ tsp
1½ tsp
75 ml
3 tbsp
Salt & Sugar As per your taste
And Idli Stand
15

AUTOCOOK RECIPES
MEAL
Recipe
Code Ingredients Weight Process
Utensil: MWS Glass Bowl
L1
0.3kg 0.4kg 0.5kg
BHINDI
MASALA
As per your taste
As required
Bhindi(cut into
pieces)
Onion(Chopped)
Tomato(Chopped)
Ginger Garlic Paste
Dhania Powder
Jeera Powder
Haldi
Red Chilli Powder
Garam Masala
Salt
Oil
1.In MWS bowl take oil. Add
chopped onion and ginger garlic
paste. Select Menu and Weight
and Press start.
2.When beep add Powder Masala.
Chopped tomato and bhindi and
Press Start.
3.When beep add salt mix well and
Press Start.
4. Serve hot with roti/parantha.
2 tbsp 2 ½ tbsp
1½ tbsp
2 Nos
2 Nos
2 Nos 3 Nos
2 Nos 2 Nos
300 gm 400 gm 500 gm
L2 DAL
0.2kg
200gm
300gm
2 tbsp
1 tbsp
2-3nos
5-6nos
Utensil: MWS Glass Bowl
1. In MWS bowl take dal. Add
water, haldi and hing and cover
it. Select Menu and Press Start.
2. When Beep take another bowl
and add oil, jeera, chopped hari
mirch, curry leaves an Press
Start.
3. When Beep add cooked dal,
salt, dhaniya, jeera powder, hara
dhaniya, kasuri meethi, lemon
juice and press Start.
4. Garnish with tomato.
Soaked Arhar Dal
(Soaked for 1 hr)
Water
Oil
Jeera
Hari Mirch
Curry Leaves
Salt, Dhaniya Jeera
Powder, haldi,
Hing, Kasuri
meethi, lemon
juice, hara dhaniya
As per your taste.
L3 CHICKEN
MASALA
Chicken(cut into
pieces)
Onion(Chopped)
Tomato(Chopped)
Ginger Garlic Paste
Haldi
Red Chilli Powder
Garam Masala
Salt
Oil
As per your taste
As required
3 Nos
3 Nos
0.5kg
400 gm
Utensil: MWS Glass Bowl
1. In MWS glass bowl take oil,
Add Chopped onion & ginger
garlic paste. Select Menu & Press
Start.
2. Add all the Masalas, Tomato &
Cream. Press start.
3. When beep add Chicken Pieces.
Add salt & mix well. Add some
water. Cover it & press start.
16
