MONITOR WITH DVD RECEIVER
DDX8019/8029
DDX8029Y/8039
SERVICE MANUAL © 2007-5 PRINTED IN JAPAN
B53-0529-00 (N)521
ATT
FNC V. S E L SRC
RC-DV330
DC cord
(E30-6678-05)
DC cord
(E30-6677-05)
Screw set
(N99-1776-05)
Lever
(D10-4674-04) x2
Antena adaptor
(T90-0552-05)
Remote controller assy
(A70-2082-15)
Mounting hardware assy
(J22-0498-13)
Escutcheon
(B07-3172-12)
Size AAA battery
Not supplied
Cord with plug
(E30-6693-05)
Escutcheon
(B07-3173-11)
Panel assy
(A64-4223-01): DDX8019
(A64-4224-01): DDX8029/8029Y
(A64-4225-01): DDX8039(M type)
(A64-4226-01): DDX8039(R,X type)
DDX8029/8029Y DDX8019/8039
Illustrations is DDX8019
Adhesive double-
coated tape
(H30-0595-04)
(1m)
PRK: (2m)
REV: (6m)
PRK: (2m)
REV: (6m)

2
DDX8019/8029/8029Y/8039
●The IC106 in the DIGITAL I/O UNIT (X88-2020-15) is not a replaceable component.
In case of defective of this IC, replace the entire unit (X88-2020-15).
●The IC5, IC21, and IC60 in the DVD unit (X37-1120-03) are not replaceable components.
In case of defective of any of these ICs, replace the DVD mechanism assembly. (The IC5 has a device key, which shall be
made consistent with the S/No. of the mechanism assembly after replacement. Thus you cannot replace only the board.)
●MICROCOMPUTER’S TERMINAL DESCRIPTION, TEST MODE, ADJUSTMENT are the same as KVT-719DVD.
Please refer to the service manual (KVT-719DVD: B53-0507-00).
In assembling the Traverse UD arm, Drive cam assembly,
Drive gear 5 and Drive gear 4C, align register marks on
these components.
GEAR POSITION IN A DVD MECHANISM
Drive gear 5
Drive cam assembly
Do not forcibly press gears to engage their teeth
but freely let the gears fall under their own weight
and engage their teeth.
Traverse UD arm
Drive gear 4C
Inscriptions
(register marks)
on gears
Align 6 marks
as shown in the
figure

3
DDX8019/8029/8029Y/8039
BLOCK DIAGRAM
(X14-985)
(X34-487)
(X88-202)
(X35-473)
(X29-443)
NAVI
(ONLY DNX)
ZACTION
MECHA
(X89-298)
BU3.3V
IC1
PON 3.3V
Q22
SW14V
J1
DC CN
DC/DC
IC101
D5V
MECHA
8V or 5V V5V
TC3.3V
DC/DC
IC102
USB5V
SW3.3V
P5V
Q43
LED9V
DVDA8V
Q31
AREF
A8V
Q35
iPod
CN401
SPDIF
J501
IC400 IC401
AUDIO SEL
IC408 (SUB)
IC407 (MAIN)
to DVD MECHA
CN502CN503
to X34
SYS-COM
IC201
IC402
PARALLEL
SERIAL
Q304,306-308
RGB SW
IC403
IC404
RGB SW
CN501
GAMMA IC
IC301
to X88
CN501
VIDEO IN SW
IC405
DVD MUTE
IC406
OUT
VIDEO
IC303
to X35
DVD MECHA
DC CN
J1
RELAY SW
J2
BU5V
Q51
SW5V
Q53
A8V
Q71
9V (MID)
IC904
1/2VCC (MID)
IC910,911
POWER IC
IC301
CN501
LEVEL SHIFT
IC106
DET MUTE E2PROM
AUDIO
u-COM
IC101
SERIAL
PARALLEL
IC105
5V AMP
(MID)
IC901
(MID)
5V AMP
IC902
(MID)
5V AMP
IC903
MUTE MUTE MUTE MUTE
SEL
AUDIO
IC203 (SUB)
IC202 (MAIN)
OUTPUT SECTION
E-VOL
INPUT
SECTION
REAR
PRE OUT
SUB AV OUTFRONT
CN351
LX
J401
A251
F/E
E2PROM
RDS IC
IC251
CN327
IC332
A5V
IC105
1.8V
USB2
5V (MID)5V
USB1
OSD IC
IC309
CPLD
IC322 IC104
MEDIA PROCESSOR
IC106
VIDEO ENC
IC302
to X14
X100 IC301
2ch DAC
IC305
LPF
IC211 IC202,203 IC200
32,768kHz
X202
IC201,205
NOR FLASH
128Mbit 256Mbit
SDRAM
X'TAL
14.7456MHz
IC101 (MID)
IC100
IC207
AUTHENTICATION
iPod
PROTECT
OVER CURRENT
USB CN
CN101
USB2
5V (MID)
5V
USB1
W251
IC201
BUFF
DELAY
REG
REG
BUFF
ISO ISO
MOTOR
DRIVER
IC501
to X29
CN504
MID
Q501,505
CN600
D600
CN601
-12V 18.5V
DC/DC
12.5V
IC100
TOUCH PANEL
to TOUCH PANEL
BACK LIGHT
to BACK LIGHT
CN1 CN500 CN301
to LCD PANEL
LCD PANEL
INVERTER
CIRCUIT
to X14
CN300
CONTROLLER
TIMING
IC302
to X89
CN600
REMO
SW
SILED
IC801
VIDEO SWVSYNC SW
IC805
RGB SW
VIDEO SW
IC803
VIDEO SW
IC806
ISO
CN703
IC704
AV IN1
TV-TUNER I/FNAVI I/F
CN702
IC804
BACK CAM
AV IN
AV OUT
ISO
IC701
J701
CN502
IC703
ISO
AV IN2
CN803WH804
CN801
DNX
CN505
to X14
to X29
to X34to X14
AV IN2 : DDX809 ONLY
BU DET
ACC DET
PON
A8VV5V
USB
iPod
DVD
AMUTE
DVD SCL
DVD SDA
DVD RESET
DISC DET
MAIN
SUB
BU DET
SW1/2/3/4 AUTO
iPod COMP
A8V
SEL DATA
SEL CLK
V IN SW1/2/3
V OUT SW
VCOM IN VR/VG/VB
SW3.3V
XDATA
YDATA
OPEN/CLOSE
REMO
SRC
KEY3
RESET
X0/X1/Y0
PWM
MIRROR
HSY ADJ
ENABLE
INV PWM
INV SW
NT PAL
VCOM R/G/B POLS
V5V
V5V
OSD BLK
GAN COMP
V5V
DVD R/G/B
DVD COMP
M CLK
M DATA
SYS ON
M REQ
S DATA
S REQ
RESET
X 29 VOUT
RESET
GRA SYNC
GRA R/G/B
RGB SW1/2
GAN VSW
DVD R/G/B
GAN SYNC SW
OSD MODE
FILD DET
CIR BU DET
CIRMREQ
CIR STBY
CIR CON
CIR SREQ
CIR RST
CIR INI
CIR RX
CIR TX
SW3.3V
NCLP
BLK HSY
HSY
VSY
STH
DOT CLK
CPV
BL14V
TC3.3V
PON3.3V
V5V
LED9V
TP3.3V
P5V
V5V
D5V
A8V
AREF
LINE MUTE
EXT CON
ANT CON
P CON
W REMO
ILLUMI
REVERSE
PARKING
PWIC STBY
BU DET
PON OFFSET DET
RELAY SW1/2 RELAY DET1/2
I2C SCL/SDA MUTE 0/1/2/A/B/C PWIC DC DET
BU DET
BU5V SW5V
BEEP
MUTE
SYS ON
M DATA
M CLK
M REQ
BU5V
BU
S DATA
S REQ
MUTE (SYS BU-DET)
RESET
REMO
A IN SEL 1/2/3/4
V IN SEL 1/2/3/4
V OUT SEL 1/2/3
SEL DATA SEL CLK
SW5V
TV RESET
SW5V
W REMO MIX REMO
V SYNC DET
AUTO SW 1/2
TV SC CON TV JUDGE TV CLK TV MC REQ TV SC REQ TV MC DATA TV SC DATA NAVI TX NAVI RX RGB MUTE RGB SW
RDS CLK TUN SMET TUN SCL TUN SDA TUN IFC AM +B RDS QAUAL RDS DATA RDS AFS RDS NOISE
LX RST LX CON LX MUTE LX CLK LX REQ M LX REQ S LX DATA M LX DATA S
BU5V BU5V BU5V BU5V
X14 AUDIO
TV
AVI N2
LX
MAIN
SUB
TUNER
NAVI
AVOUT
A8V
BU3.3V
SW3.3V
V5V
USB5V
A8V
SW5V
USB5V V5V SW3.3V BU3.3V A8V
A8V
SW3.3V
OSD R/G/B OSD BCK/FILD DET OSD MODE HSY/VSY
STH DOT CLK
GRA SYNCVSYNC
HSYNC
GRA R/G/B
SP CLK EP R/G/B
CPV
OSD DATA
OSD CE
OSD CLK
CS6
CS0
CIR BU DET
CIR CON
CIR SREQ
CIR MREQ
CIR STBY
CIR RST
CIR INI
CIR MDATA
CIR SDATA
SDO0
LRCLK
SCLK
MCLK
USB L/R
CP READY
SCL SDA
ENB (MID) ENA FLGB (MID) FLGA
ADDRESS DATA
USBm0 USBp0
USB5V
USBm1 USBp1
SPDIF
OSD R/G/B
MUTE
BU5V
A8V
BU
A8V
CIR RST
MECHA8V or 5V
V5V
TILT M+
SENSOR OUT
SENSOR GND
TILT M-
SENSOR 3.3V
V5V
PON3.3V
BU
V5V
X 29 COMP
X 29 R/G/B
HPOSI1/2/3/4
MODE1/2/3
GAN R/G/B
LED ON
D5V
D5V
D5V
V5V
BL14V
TC3.3V 18.5V V5V -12V
+12.5V
PWM
ENABLE
INV PWM
XDATA
YDATA
Y0
X0
X1
R/G/B VCOM
OE1/2/3
STH1/2
UPSD
STV1/2
HDIR
CPV2
CPH1
CX
POLS
NCLP
DOT CLK
VSY/CPV
BLK/HSY
STH
NT/PAL MIRROR MODE1/2/3 HPOSI1/2/3/4
TC3.3V
PON3.3V TP3.3V
SI REMO OPEN/CLOSE RESET SRC KEY3(VSEL/FUNC/VOL-/VOL+/ATT)
LED9V
PON3.3V
TP3.3V
LED9V
TP3.3V
PON3.3V
LED9V
REMO
SI
OPEN/CLOSE
RESET
SRC
ATT
VOL-/VOL+
VSEL/FUNC
RGB OUT
X14 VIDEO
VIN
BACK CAM AVI N2
V IN SEL 1/2/3/4
V OUT SEL 1/2/3
AVI N2 BACK CAM
V5V
TV
NAVI
BACK CAM
X14 VIDEO
V5V
RGB SW RGB MUTE
TV JUDGE
TV SC REQ
TV MC DATA
TV SC DATA
TV MC REQ
TV SC CON
TV RST
TV CLK
NAVI TX
NAVI RX
MIX REMO
NAVI RGB
TV
V5V
TV RGB
A8V
V5V
NAVI
A8V
BU
PARKING/REVERSE
NAVI ONLY
A8V
AVI N1
AVI N1 AVI N1
AVIN1
AVIN2
TV
NAVI
REVERSE
PARKING
NAVI
AUTO SW1/2
V SYNC DET
V5V
A8V
BU
V5V
PON3.3V
SENSOR 3.3V
SENSOR GND
TILT M+
TILT M-
SENSOR OUT
BU3.3V
ACC DET SD DET1
TMOTOR M
TMOTOR P

4
DDX8019/8029/8029Y/8039
BLOCK DIAGRAM
(X37-112)
MOTOR
SPINDLE
LIM-SW
HALL IC
M
LO/EJ
DC MOTOR 2PHASE
STEPPING
KDP2C
OPTICAL
PICKUP
(28P)
CONNECTOR
P5V
P5V ACTUATER
MOTOR &
DRIVER
(30P)
CONNECTOR
A5V A5V
IC39
IOPDET
A3.3V
Q27
Q12,13
Q10,11
D3.3V
IC1
SDRAM
IC54
D3.3V
D3.3V
A3.3V V3.3V
PLL3.3V D1.2V
D3.3V
Q25
ROM D-FF
IC10
IC5 IC42
D3.3V D3.3V
FLASH
D3.3V
LOGIC
IC55
CONNECTOR(35P)
BUFFER
IC53
IC57
AUDIO
DAC
IC15
VIDEO AMP
IC12
3.3V to 1.2V
IC49
D3.3V
D1.2V
IC50,51
L.P.F
A8V
5V REG
IC60
A8V
A5V
A5V
ADATA0-2
BCK/LRCK
PD
Y/G,Pb/B,Pr/R
VIDEO
SPDIF
AMUTE
SDA,SCL
AREFL
Lch
MASTER/SLAVE
RESET
CONNECTOR
(10P)
(50P)
CONNECTOR
Rch
AREFR
DISC DET
IFSELIF-SEL
SW LOST
SW LOEND
D5V
A5V
P5V
A8V
D7
D3.3V
V3.3V
PLL3.3V
A3.3V
IC9
E2PROM
D3.3V
D1.2V
IC21
SW REG
F/E+B/E+MCU
DVN
DISC
Q14,15
D5V
VIDEO AMP
HALL BIAS U.V.W COIL HALL SENSOR
PDIC VCC
DVD LD/CD LD
HFM
VREFH
THERMISTER
PDIC I/V OUT
IMON/VR DVD/VR CD
FO+-,TR+-
3
3
H1H,H1L,HB
A1,A2,A3
FO6,RO6
FO4,RO4
FO5,RO5
FO3,RO3
FO2,RO2
VREF,EC VHALF
STBY BMS FG
SPIN,IN2-6,MUTE
4
LPC01/LPC02
DRV0
VREFH
LPC1/LPC2
A,B,C,D,E,F,FE1,FE2,RF
TEMP(AD1)
2
9
VHALF
DQM3,P9
DRV1,DRV2,DRV3,DRV4
PWM0,PWM1,P10
FG,P5
MDQ0-15
NWE,NCAS,NRAS,NCSM,MCK0
BA0-1,MA0-11,DQM0-1
IOP
(AD0)
7
2
21
16
2
27MHz
IF-SEL
E
DQ0-15
W,G A0-20
CLR
D1-8
Q1,Q2
CLK
Q3-8
23
8
EXADT11
EXADT DQM2 NEXCE 0-15
A19
NEXWE
EXADR16-19 EXADT0-15 NEXOE P15 NEXWE P6,P14 P0,P3 DD0-15,DA0-1,CS1FX,CS3FX INTREQ,IORDY,DASP,PDIAG DMARQ,DIOW,DIORDMACK RESET MASTER
16 4
2
3
4
2
R+
L-
R-
L+
DACCK
ADOUT3
P1,P2
IECOUT
DAC4OUT
DAC0-3OUT
SRCK,LRCK
ADOUT0-2
2
2
3
PON
3
2
6
30
ATAPI I/F
P7,P8
NRST
POR
SW2
SW1
2
4
SW EIEND
P12(CE)
CLAMP/BIAS,
POWER SAVE

5
DDX8019/8029/8029Y/8039
●VIDEO CONTROL UNIT (X14-985x-xx)
Ref. No. Application / Function Operation / Condition / Compatibility
IC1 3.3V regulator BU_3.3V
IC2 3.3V regulator TC3.3V
IC10 OP AMP AREF power supply (4V)
IC101 DC-DC control IC DC-DC control (Mechanism 8V, V5V)
IC102 DC-DC control IC DC-DC control (SW3.3V, D5V)
IC201 MPU System µ-com
IC202 Reset IC Reset IC
IC203 EEPROM Save settings
IC204 EEPROM ROM correction
IC205 AND Inverter PWM buffer
IC301 Chroma gamma Chroma gamma
IC302 NOT HSY reverse buffer
IC303 Monostable multivibrator HSYNC delay
IC304 NOT HSYNC delay
IC400 VIDEO ISO AMP iPod video signal
IC401 AUDIO ISO AMP iPod audio signal
IC402 Serial/parallel conversion Extension of µ-com port
IC403 Video switch X34 RGB or Graphic RGB
IC404 Video switch IC403 RGB or DVD RGB
IC405 Video switch iPod or DVD or Graphic or X34 Composite signal
IC406 Video switch For AVOUT (To X34)
IC407 Audio selector MAIN
IC408 Audio selector SUB
IC501,502 Motor driver Panel drive
Q1 SW ACC_DET detection circuit
Q2~10 SW BU_DET detection circuit
Q13 Short protection BU power supply regulator (8.5V)
Q14 8.5V regulator BU power supply regulator (8.5V)
Q15~17 8.5V regulator control BU power supply regulator (8.5V)
Q19~21 SW P-ON 14V control
Q22 SW FET P-ON 14V ON/OFF
Q23,24 Emitter follower Analogue power supply reference circuit
Q25,26 SW T_P3.3V switch
Q31~34 8V regulator control DVD A8V regulator
Q35 8V regulator A8V regulator
Q36~38 8V regulator control A8V regulator
Q43 9V regulator LED9V regulator
Q44~46 9V regulator control LED9V regulator
Q101 SW DC-DC output voltage switching
Q103,106
Q108,111
SW DC-DC protection control
Q104 SW DC-DC SW FET (5V or 7.5V)
Q105 SW DC-DC SW FET (5V)
Q109 SW DC-DC SW FET (3.3V)
COMPONENTS DESCRIPTION

6
DDX8019/8029/8029Y/8039
Ref. No. Application / Function Operation / Condition / Compatibility
Q110 SW DC-DC SW FET (5V)
Q201 SW µ-com reset SW
Q203 SW KEY RESET
Q204,205 SW SI
Q206,207 SW LED SW
Q301 Buffer Composite signal
Q304 Buffer VCOM
Q305 MUTE IC301 SYNC OUT MUTE
Q306 Buffer RGB Signal_R
Q307 Buffer RGB Signal_G
Q308 Buffer RGB Signal_B
Q309 Buffer HSY SYNC
Q401 Buffer Graphic SYNC
Q504 Buffer SPDIF signal
Q506 MUTE DVD MUTE (Lch)
Q507 MUTE DVD MUTE (Rch)
Q508 Buffer Remote control signal
Q509 SW DVD MUTE control
Q600,601 SW DISC loading LED control
●CONTROL CIRCUIT UNIT (X29-443x-xx)
Ref. No. Application / Function Operation / Condition / Compatibility
IC701 ISO AMP For TV sound
IC702 Logic IC (AND) Buffer for NAVI_REMO
IC703 ISO AMP For AVIN2 sound
IC704 ISO AMP For AVIN1 sound
IC801 Video SW Selection of SW for VIN, TV COMP, AVIN1, AVIN2, BCAME, NAVI COMP
IC803 Video SW Selection of SW for AVOUT, TV, AVIN1, DVDIN
IC804 75Ωdriver (6dB amplifier) Selection of SW for AVOUT IC803 output and AVIN2
IC805 SW for sync separation Selection of BCAME, AVIN1, AVIN2
IC806 Video SW Selection of TV R, G, B, NAVI R, G, B
Q801 Transistor Current amplification and buffer for VIN
Q802~808 Transistor Sync separation circuit of BCAME, AVIN1, AVIN2
Q809 Transistor Current amplification and buffer for ROUT
Q810 Transistor Current amplification and buffer for GOUT
Q811 Transistor Current amplification and buffer for BOUT
Q813 Transistor For ROUT MUTE
Q814 Transistor For GOUT MUTE
Q815 Transistor For BOUT MUTE
●ELECTRIC UNIT (X34-487x-xx)
Ref. No. Application / Function Operation / Condition / Compatibility
IC71 3 terminal regulator Audio8V and Tuner8V generation
IC101 Pin100 µ-com Primarily, audio board control
IC102 Voltage detector µ-com reset voltage (4.2V) monitoring
COMPONENTS DESCRIPTION

7
DDX8019/8029/8029Y/8039
Ref. No. Application / Function Operation / Condition / Compatibility
IC104 Logic IC (inverter) Synthesis of remote control signal from X14 and Wired_remote control signal
IC105 Serial/Parallel IC Control output of AudioSW IC
IC106 Logic IC Conversion of communication level (3.3 → 5) between X14 system µ-com
IC201 Electronic volume IC Audio volume control and audio signal selection
IC202 Logic IC (multiplexer) Audio signal selection (Main)
IC203 Logic IC (multiplexer) Audio signal selection (Sub)
IC251 RDS decoder IC For RDS signal processing and demodulation
IC301 Power IC Power amplifier for speaker output
IC901 OPAMP PREOUT amplifier (Front)
IC902 OPAMP PREOUT amplifier (Rear)
IC903 OPAMP PREOUT amplifier (Sub woofer)
IC904 Power supply converter ±9V power supply generation of PREOUT amplifier
IC910 OPAMP SVR and Ref3.3V generation for Power IC
IC911 OPAMP Midpoint potential generation (4.0V) for Power IC
Q1 Transistor Reverse detection circuit
Q2 Transistor Parking detection circuit
Q3 Transistor ILLUMI detection circuit
Q4,6 Transistor Bu detection circuit
Q7~10 Transistor P_CON output circuit
Q11,12 Transistor ANT_CON output circuit
Q13 Transistor EXT_CONT output circuit
Q51 Transistor Bu5V generation
Q52 Transistor Bu5V circuit
Q53,54 Transistor SW5V circuit
Q70~72 Transistor Audio8V and Tuner8V generation
Q81~86 Transistor Relay SW1 output, and over current detection circuit
Q91~96 Transistor Relay SW2 output, and over current detection circuit
Q101 Transistor µ-com reset circuit
Q102,103 Transistor TV reset circuit
Q104,105 Transistor DET MUTE circuit (Trigger Reset)
Q107 Transistor DET MUTE circuit (Trigger X14MUTE)
Q108 Transistor DET MUTE circuit (Trigger Bu-DET)
Q251,252 Transistor On when AM (Tuner8V)
Q351 Transistor Pre-OutMute Mute transistor (FL)
Q352 Transistor Pre-OutMute circuit (Front, Rear)
Q353 Transistor Pre-OutMute Mute transistor (FR)
Q354 Transistor Pre-OutMute Mute transistor (RL)
Q355 Transistor Pre-OutMute Mute transistor (RR)
Q356 Transistor Pre-OutMute Mute transistor (SUB L)
Q357 Transistor Pre-OutMute circuit (SUB)
Q358 Transistor Pre-OutMute Mute transistor (SUB R)
Q359 Transistor Pre-OutMute Mute transistor (AV-OUT L)
Q360 Transistor Pre-OutMute circuit (AV-OUT)
Q361 Transistor Pre-OutMute Mute transistor (AV-OUT R)
COMPONENTS DESCRIPTION

8
DDX8019/8029/8029Y/8039
Ref. No. Application / Function Operation / Condition / Compatibility
Q901,
Q903~910
Transistor Power supply for Pre-Out amplifier Circuit to generate ±9V
Q911,
Q921~924
Transistor Circuit to generate the midpoint potential for Power IC
●VIDEO UNIT (X35-4730-10)
Ref. No. Application / Function Operation / Condition / Compatibility
IC1 Inverter control IC Control and drive of the inverter circuit for the back light
IC100 DC/DC converter IC +12.5V power supply for VCOM amplifier, and -12.0V/+18.5V power supply for LCD
IC102 Mono-multi Delay 5V power supply for DC/DC IC
IC103 NOT Reverse
IC300 AND Buffer to delay V.SYNC
IC302 Timing controller IC Control of LCD module
IC303 PLL LPF LPF for PLL control (VT voltage control)
Q1 5V constant voltage 5V power supply for inverter control IC
Q2,3 Inverter driver Drive the inverter circuit
Q4 Dimmer SW Turn on or off in response to the PWM control signal to dimmer the back light
Q5
Inverter frequency switching switch SW to switch the free run frequency for inverter control IC
Q302 Buffer For PLL clock
Q303 VCO For PLL oscillation
Q500 Touch panel X1 SW X1 SW: Turn on in response to detection of the panel touch or X axis input and apply voltage
Q501 Touch panel X0 SW X0 SW: Turn on in response to X axis input and apply voltage
Q502 Touch panel Y1 SW Y1 SW: Turn on in response to Y axis input and apply voltage
Q503 Touch panel Y0 SW Y0 SW: Turn on in response to Y axis input and apply voltage
Q504 Touch panel Y0/Y1 SW Y0/Y1 SW: Turn on in response to Y axis input and off in response to X axis input
●DIGITAL I/O UNIT (X88-2020-15)
Ref. No. Application / Function Operation / Condition / Compatibility
IC100 Fixed Current Limit
Power Distribution Switch Large current distribution switch for USB1
IC101 Fixed Current Limit
Power Distribution Switch Large current distribution switch for USB2
IC104 Exclusive OR Gate EP_SYNC (composite sync) output
IC105 Low Dropout Voltage
Linear Regulator SW3.3V →1.8V (for EP9307IRZ)
IC106 System-On-Chip Processor Media Processor
IC108 Inverter E_HSYNC Buffer
IC200 Triple Inverter Sub Clock Buffer
IC201 Octal Bus Transceiver Flash Memory data line switching (DA0~7)
IC202,203 SDRAM 256Mbit SDRAM for work memory
IC205 Octal Bus Transceiver Flash Memory data line switching (DA8~15)
IC207 iPod Authentication Coprocessor iPod Authentication
IC211 NOR Flash Memory 128Mbit Flash Memory for program data and graphic data
IC301 Stereo DAC Audio signal digital/analog converter
IC302 Color TV signal encoder Graphic signal digital/analog converter
IC305 Dual OP-Amp.(LPF) Stereo DAC Output LPF
COMPONENTS DESCRIPTION

9
DDX8019/8029/8029Y/8039
Ref. No. Application / Function Operation / Condition / Compatibility
IC309 On-Screen Display Controller On-Screen Display analog signal output
IC316 Triple Inverter Dot Clock (14.4MHz) Buffer
IC322 CPLD 2/3 frequency dividing and PAL thinning control (compression processing circuit)
IC332 Low Dropout Voltage Regulator A8V →A5V (for Stereo DAC and LPF)
IC336 Triple Schmitt Inverter VSY, HSY Buffer
IC337 Triple Schmitt Inverter CPV, STH Buffer
Q302 General Purpose Transistor OSD ROUT Current Amplifier
Q303 General Purpose Transistor OSD GOUT Current Amplifier
Q304 General Purpose Transistor OSD BOUT Current Amplifier
●DVD UNIT (X37-1120-03)
Ref. No. Application / Function Operation / Condition / Compatibility
IC1 One chip LSI for DVD player RF signal processing / Servo processing / Decoding processing / AV decoding processing
IC5 FLASH ROM To retain F/W for one chip LSI (Nonvolatile memory)
IC9 EEP ROM To retain data for one chip LSI (Nonvolatile memory)
IC10 Driver IC Fo coil / Tr coil / SP motor / SLD motor / LO-EJ motor drive
IC12 1ch video AMP +6dB amplifier with internal composite video output filter
IC15 Audio DAC DA converter for 2ch analogue audio output
IC21 2-output switching REG 5V →3.3V/1.2V
IC39 OP-AMP for Iop measurement For Iop measurement
IC42 Logic IC for port extension For port extension
IC49 Low voltage logic For S/PDIF signal amplitude conversion (3.3V →1.2V)
IC50 OP-AMP for audio LPF LPF for 2ch analogue audio output (Rch)
IC51 OP-AMP for audio LPF LPF for 3ch analogue audio output (Lch)
IC54 SDRAM To retain data for one chip LSI (Nonvolatile memory)
IC55,56 Logic IC for port extension For port extension
IC57 3ch video amplifier With built-in filter +6dB amplifier for component/RGB video output
IC60 Power supply for 5.0V 8V →5V (Exclusively for audio DAC)
Q1 Transistor with internal resistor LO_MUTE control
Q2 Transistor with internal resistor For FG signal
Q3 Transistor with internal resistor For BMS
Q4 Transistor with internal resistor DRMUTE control
Q10 Front end transistor for APC Control of CD laser diode emission
Q11 Front end transistor for APC Control of DVD laser diode emission
Q12 Rear end transistor for APC Control of CD laser diode emission
Q13 Rear end transistor for APC Control of DVD laser diode emission
Q14 MOS-FET ON/OFF control of CD laser diode
Q15 MOS-FET ON/OFF control of DVD laser diode
Q20 MOS-FET for level shifter Level shifter for I2C clock
Q21 MOS-FET for level shifter Level shifter for I2C data
Q24 MOS-FET For Iop measurement
Q25 Transistor with internal resistor IFSEL control
Q27 Transistor with internal resistor HFM ON/OFF control
Q28 Transistor for APC For CD laser diode protection (Current limiter)
Q29 Transistor for APC For DVD laser diode protection (Current limiter)
COMPONENTS DESCRIPTION

10
DDX8019/8029/8029Y/8039
ABCDE
1
2
3
4
5
6
7
IC801
IC701
IC803
IC804 IC805
IC806
IC703
IC704
IC702
CONTROL CIRCUIT UNIT
X29-443x-xx (J76-0392-12)
1
1
2
8
81
16
119
1
220
2
1
20
19
1
1
1
1
1
C808
C709
C724
C725
C707
C711
C720
C717
C727
C726
C820
C721
C719
C716
C718
C809
C818
C824
C840
C704
C705
C706
C713
C830
C841 C842 C843
C722
C723
L702
R829
R836
R838
R840
R812
R813
R827
R837 R839 R841
R848 R849 R850
R826
R842
R843
R844
R811
R851
R852
R782
R790
R791
R814
C854
C855
C836
C814
C801
C816
C838
C813
C822
C817
C823
C821
C802
C834
R741
R742
R743
R744
R761
R762
R763
R788
R789
R765
R767
R710
R768 R770
R747
R709
R748
R708
R745
R707
R746
R711
R712
R705
R706
R769
R766
R857
R722
R720
R758
R755
R721
R723
R757
R756
R858
R833
R859
R835
R779
R834
R724
R825
R828
R725
R726
R727
R845
R846
R847 7
814
9
18
5
1
4
54
1
6
43
20
191
5
3
5
4
2
49
50
5
610
5
610
5
10
6
214
13
BEBEBE
BEBEBE
BE
BE
J701
WH804
Q807
Q813
Q814
Q815
Q808
Q809
Q810
Q811
CN703
CN803
P801
P701
D705
D706
D719
D720
D721
D722
D707
CN702
D708
D709
D710
CN801
D723
D736
D737
D734
D735
D740
D742
D741
PC BOARD (COMPONENT SIDE VIEW)
Refer to the schematic diagram for the values of resistors and capacitors.
X29-443x-xx
Ref. No Address
IC701
IC702
IC703
IC704
IC801
IC803
IC804
IC805
IC806
Q807
Q808
Q809
Q810
Q811
Q813
Q814
Q815
2C
3C
3B
2B
3E
3D
3D
3D
4E
4E
4D
4D
4E
4E
4D
4E
4E

11
DDX8019/8029/8029Y/8039
JIHGF
1
2
3
4
5
6
7
CONTROL CIRCUIT UNIT
X29-443x-xx (J76-0392-12)
R803
C819
C812
C714
C715
C708
C825
C828
C829
R805
R822
R801
R802
R853
R806
R831
R832 R821
L801
R815
R819
R817
R824
L703
R759
R760
R818
R734
C712
C710
C837
C806
C831
C835
C803
C827
C804
C728
C815
C805
C833
C832
C839
R701
R702
R703
R704
R808
R820
R823
R830
R733
C701
C702
C703
R738
C811
R740
R773
R774
R715
R772
R713
R736
R737
R718
R717
R719
R716
R735
R739
R854
R855
R714
R764
R777
R775
R776
R751
R750
R787
R786
R785
R784
R781
R778
R780
R783
R816
R856
R728
R771
BE
BE
BEBE
BEBE
Q801
Q802
Q803
Q805
Q804
Q806
D717
D718
D701
D702
D703
D704
D711
D715
D724
D729
D728
D730
D731
D733
D732
D714
D713
D738
D716
D739
D712
TP815
TP822
TP832
TP816
PC BOARD (FOIL SIDE VIEW)
Refer to the schematic diagram for the values of resistors and capacitors.
X29-443x-xx
Ref. No Address
Q801
Q802
Q803
Q804
Q805
Q806
3F
3G
3G
3G
3G
4G

12
DDX8019/8029/8029Y/8039
KLMNO
1
2
3
4
5
6
7
PC BOARD (COMPONENT SIDE VIEW)
C1
12
11
22
1
C51
L1
1
1
1
111
212
50
41
I
G
4
5
1
125
224
1
O
8
8
C54
C201
C305
C306
C311
C312
C317
C318
C8
C205
C206
C202
C211
C210
C209
C920
C930
C929
C921
C925
C105
C53
C351
C352
C108
C10
C114
C320
C366
C358
C370
C216
C7
C11
C12
C13
C82
C116
L71
R1
R129
R130
R167
R193
R207
R88
R206
R14
R7
R15
R28
R6
R89
R126
R9
R39
R124
R125
R75 R76
R13
R22
R204
R81
TH301
C9
C4
C5
C6
C207
C228
C224
C223
C227
R19
F51
C71
C316
C72
R72
R24
R304
C363
R201
R958
C933
R4
R11
R205
R16
R21
R23
R30
R25
R26
R36
R73
R84
R302
C355
R306
R215
R214
R213
R959
R12
R37
R40
R8
R82
R3
R10
R385
R209
R216
R217
R218
R219
R208
R127
R87
R303
R301
R372
R378
R386
R356
R362
R83
R212
R955
X101
R948
R952
R950
R944
C939
R951
R355
R361
C928
C937
R935
R941
R937
R936
L901
C924
C926
C922
C923
C932
C931
R371
R377
R943
C934
R954
R934
C935
C630
C936
R902
R907
R
9
R
R924
R918
R904
R908 R919
R921
R957
C908
C915
C918
C905
C912
C902
C914
C907 C904 C917
R909
R905
R920
R922
R914
R903
R956
R926
R910
R915
R906
R917
R901
R923
R307
R308
R310
R309
R311
R928
R942
R947
R953
C349
C350
C333
C334
C341
C34
BE
BE EB
8
5
1
44
1
5
8
85
14 41
58
4
5
43
2
64 17
16
48 33
49 32
BE
BE
B
CC
BEE
BEBE
E
BE BEBE
BE
BE
BE
BE
BE
CC
EBE
BE
BE
EB
EB
EB
BE
BE
BE
BE BE
BE
D1
Q71
Q51
J1
Q83
Q93
Q903
Q901
CN351
CN502
Q2
Q8
Q84
D6
D8
D9
D203
D202
D201
D7
D301 Q7
Q9
Q4
Q6
Q82
Q86
Q85
D2
D4
D3
D5
D11
D13
Q924
D10
D12
D14
D15
D113
Q1
Q3
Q10
Q81
D351
D352
D353
D354 D355
D356
D357
D358
J2
Q101
Q102
P2
D112
Q904
Q909
Q910
Q908
P1
D903
Q923
IC301
IC201
IC102
IC71
IC910 IC911
IC901
IC902
IC903
IC904
ELECTRIC UNIT
X34-487x-xx (J76-0414-12)
TP201
TP203
T
TP202
TP900

13
DDX8019/8029/8029Y/8039
TSRQP
1
2
3
4
5
6
7
Refer to the schematic diagram for the
values of resistors and capacitors.
X34-487x-xx
Ref. No Address Ref. No Address
IC71
IC101
IC102
IC104
IC105
IC106
IC201
IC202
IC203
IC251
IC301
IC901
IC902
IC903
IC904
IC910
IC911
Q1
Q2
Q3
Q4
Q6
Q7
Q8
Q9
Q10
Q13
Q51
6L
5Q
4O
4Q
4P
4Q
5O
6P
6P
5R
4L
3N
2P
3O
4N
5M
5N
2N
2N
3M
3L
4L
4M
4N
4M
5M
4P
6M
Q71
Q81
Q82
Q83
Q84
Q85
Q86
Q93
Q101
Q102
Q103
Q104
Q105
Q107
Q108
Q251
Q252
Q354
Q355
Q901
Q903
Q904
Q908
Q909
Q910
Q923
Q924
5M
2N
3N
2N
3N
2N
2N
3M
4O
5O
5P
4Q
4Q
4Q
4Q
3Q
3Q
3P
3P
3M
3M
3M
3N
3N
3N
6M
6N
14
58
912
13
1
1
8
16
120
24
1
1
3
1
4
5
1
8
1
X251
C233
C268
C269
C211
C210
2
09
C101
C226
C225
C402
C401
C403
C502
C104
C105
C107
C109 C110
C108
C113
C114
C359
C367
C370
C234 C235
C270
C115
L101
L253
L255
L251
R129
R130
R167
R193
R158
R160
R161
R131
R367
R366
R34
R
126
R190
R103
R113
R119
R121
R125
R140
R151
R152
R181
R189
R123
R187
R188
R180
R102
R501
C106
R251
R365 R368
R118
C360 C361
R141
R163
R134
R252
R253
R132
C362
R405
R260
R261
R406
R379
R385
R107
R139
R192
R168
R111
R109
R112
R169
R145
R117
R170
R173
R171
R137
R115
R116
R138
R144
R146
R136
R191
R110
R135
R114
R127
R128
R35
R165
R255
R164
R380
R364 R370
R386
R108
R178
X101
C501
C117
R197
R363
R369
R911
R916
R924
R912 R913
R254
C911
C909
R910
R915
R923
7
814
8
16 9 1
54
4
3
2
25
100
26
51 75
50 76
9
8
116
98
1
9
16
BEBE
BE
BE
BE
BE
BE
BEBE
BE
BE
J401
A251
W251
Q13
Q252
D
203
D361
D202
D201
Q103
Q104
Q108
P252
Q251
Q105
Q107
D357
D403
Q102
CN501
Q354
Q355
D101
D252
P251
IC101
IC104
IC105
IC202
IC203
IC102
IC106
IC251
IC902
TP101
TP111
TP104
TP102
TP103
TP105
TP112
TP106
TP113
TP107
TP109
TP108
TP110

14
DDX8019/8029/8029Y/8039
UVWXY
1
2
3
4
5
6
7
PC BOARD (FOIL SIDE VIEW)
D405
D406
D407
D362
D363
D359
D365
D205
D364
D360
D204
Q907
Q352
Q357
Q360
Q905
D401
D402
D404
D251
Q351
Q353
Q356
Q358
Q359
Q361
D253
D902
ELECTRIC UNIT
X34-487x-xx (J76-0414-12)
C353
C354
C261
C263 C260C262
C266
R148
R149
R200
R153
R155
R157
R383
R375
R358
R382
R359
R374
R184
R104
R105
R106
R120
R122
R150
R182
R183
R38
R186
R179
R185
C213
C212
R357 R360 R373 R376
R381 R384
C103
C112
C356 C357C364 C365
C368 C369
R222
R210
R211
C264 C265
R404
R408
C267
R409
R411
R407
R402
R401
R403
R410
R175
R174
R166
R172
R142
R177
R143
R147
R162
R176
R257
R29
R256
R195
R194
C903
C910
C916
C906
C913
C919
C927
R932
R929
R931
R930
BE
BE
BE BE
BE
BE BE
BE
B
BEBE BE
TP256
TP271
TP254
TP261
TP352
TP506
TP251
TP255
TP260
TP262
TP266
TP268
TP272
TP513
TP264
TP351
TP358
TP541
TP356
TP536
TP353
TP522
TP114
TP411
TP252
TP535
TP508
TP542
TP514
TP523
TP538
TP404
TP521
TP405
TP533
TP507
TP556
TP524
TP539
TP540
TP525
TP267
T
P
TP406
TP544
TP504
TP505
TP553
TP530
TP502
TP549
TP409
TP263
TP537
TP543
TP532
TP546
TP503
TP401
TP545
TP555
TP529
TP410
TP501
TP550
TP269
TP257
TP253
TP354
TP554
TP547
TP407
TP511
TP359
TP557
TP512
TP551
TP403
TP408
TP558
TP531
TP509
TP265
TP516
TP270
TP552
TP510
TP402
TP548
TP357
TP528
TP515
TP115
TP259
TP355
TP258
TP901
TP903
TP11

15
DDX8019/8029/8029Y/8039
ADACABAAZ
1
2
3
4
5
6
7
Refer to the schematic diagram for the
values of resistors and capacitors.
X34-487x-xx
Ref. No Address
Q11
Q12
Q52
Q53
Q54
Q70
Q72
Q91
Q92
Q94
Q95
Q96
Q351
Q352
Q353
Q356
Q357
Q358
Q359
Q360
Q361
Q905
Q906
Q907
Q911
Q921
Q922
4Z
4Z
6AA
6AA
6AA
5AA
5AA
3AA
3Z
3AA
3Z
3Z
3Y
4Y
3Y
3X
4X
3X
3X
4X
3X
4Z
4Z
4Y
5Z
5Z
5Z
Q94
Q53
9
07
Q52
Q12
Q92
Q96
Q95
Q72
Q905
D82
D92
D91
D81
D52
Q54
Q70
Q91
Q11
Q921
Q922
Q906
D53
D18D21
D901
D111
Q911
C2
C92
R33
R98
R99
R78
R79
R91
C73
R51
R71
R52
C315
R55
C81
C91
R945
R77
R80
R32
R31
R94
R27
R961
R92
R56 R53
R54
R97
R29
R305
R93
R86
R85
R95
R96
C938
C326
C74
R927
C940
C927
R933
R932
R929
R931
R930
R962
R960
R963
R946
C309
C313
C327
C303
C329
C307
C347
C348
C328
C330
C331
C332
C335 C336
C337
C338
C339
C340
C343
C344
C345
C346
BE
BE
BE
BE
BE
BE
BE
BE
BEBE
BE
BE
BE
BE
BE
BE
BE
BE
TP53
TP20
TP51
TP71
TP52
TP527
TP21
TP304
TP526
TP4
TP308
TP23
TP301
TP541
TP306
TP8
TP536
TP520
TP535
TP7
TP24
5
TP22
TP523
TP519
TP14
TP5
TP12
TP3
TP525
TP534
TP6
TP303
TP2
TP17
TP537
TP543
TP532
TP517
TP18
TP81
TP518
TP91
TP305
TP9
TP10
TP19
TP531
TP302
TP307
TP16
TP15 TP13
TP11
TP1
TP902
TP901
TP904

16
DDX8019/8029/8029Y/8039
AE AF AG AH AI
1
2
3
4
5
6
7
IC1
IC406
IC202
IC301
IC405 IC403 IC404
IC205
IC204
VIDEO CONTROL UNIT
X14-985x-xx A/2 (J76-0388-22)
C1
L1
16
1
1
13
1
36
G
1
1
24
1
8
1
1
1
O
1
25
5
4
C2
R6
R11
R22
R25
C6
C7
C503
L201
C20
R138
R450
R451
C201
C212
R228
R235 R239
R248
R249
R250
R254
R255
R257
R259
C522
C324
L302
R34
R444
R421 C407
C414
C421
C427 C433
L403
R431
C326
C328
L303
C303
L301
R301
R305
R308
R318
C140
C141
R136
R137
C339
C346
L305
C502
L404
C43
5
L3
C17
C122
C132
C163
C173
L101
L103
L107
C171
C172
R165
R166
R167
C181
C182
R175
R176
C9
C215
C506
R129
C130
C131
R127
R163
C347
C359
C501
R388
C211
C504
R326
C189
C190
C195
C196
C3
C5
C8
R8 R9
R10
R13
R16
R17
R19
R24
R27
R36
R38
C193
C194
C200
C204
C205
C199
C191
R229
R231
R245
R246
R247
R252
R253
R256
R258
R389
C123
C124
C128
C129
C133
C134
C136
C137
C164
C165
C169
C170
C174
C175
C179
C180
R81
R82
C213
C310
C313
C314
C316
C318
C319
C321
C322
C426
R83
R307
R311
R312
R313
R317
R324
R426
R428
R430
R437
R440
R443
R459
R180
R179
C301
C304
C305
C306 C307
C308 C309
C311
C312
C320
C325
C302
C323
R554
R553
C408
C409
C410
C411
C412
C413
C415
C416
C417
C418
C419
C420
C422
C423
C424
C425
C429
C430
C192
C197
C198
L102
L104
L108
R7
R12
R14
R15
R26
R28
R29
R35
R37
R77
R126 R134
C216
R164
R173
R205
R206 R207
R215
R217 R220
R221
R234
R236
R238
R240
R241 R242
R302
R303
R304
R306
R309
R310
R316
R319
R320
R321
R322
R325
R327
R328
R329
R555
C187
R422
R423
R424
R425
R427
R429
R432
R433
R434
R435 R436
R438
R439
R
4
R445
R446
R447
R448
R449
R452
R457
R458
R501
R504
R505
R506
R507
R508
R509
R510
X301X302
C188
C214
C168
C185
C219
C186
C178
C24
C525
C217
C218
R178
C534
C535
R263
L105
R39
R550
C166C167C176C177
L106
R539
R540
C260
2
I
3
45
3
46
7
814 8
916 9
18
37 48
1
12
60
2
43
2
BE
D SSGG
DDD D
SSGG
DDD
D SSGG
DDD
D SSGG
DDD
CB EB
E C
BE
BE
BE BE
BE
E
BE
BEBE
B
BE
BE
BE
BEBE
BE
BE
BE
BE
BE
BE
BE
BE
DDDD
BE
BE
BE BE
SGSS
Q2
Q4
Q14
CN1
CN501
Q3
Q5
Q7 Q9
Q17
Q
D4
Q203
Q205
Q20
Q21
Q22
Q104
Q105
Q109
Q309
Q204
Q6
Q8
Q10
Q13
Q15
Q16
Q19
Q25
Q201
Q305
Q401
P103
P101
P104
P102
Q501
Q502
Q505
CN600
Q110
PC BOARD (COMPONENT SIDE VIEW)

17
DDX8019/8029/8029Y/8039
ANAMALAKAJ
1
2
3
4
5
6
7
Refer to the schematic diagram for the values of resistors and capacitors.
I
C404
IC401
IC400
IC10
X14 B/2
L1
1
13
24
1
1
1
1
R40
R538
R42
C414
R431
R1
R2
L404
C435
L3
C403
C401
C21
C404
L401
C508
C14
C507
R535
C405
R96
R412 R405
R400
C516
R84
R86
C452 R537
R518
R519
R413
R443 R45
C34
R46
L501
C417
C419
C420
R41
R401
R402
R403
C465
C400
C402
R410 R411
R433
R434
R441
R442
R18
R522
R525
R526
R527
R534
C511
R536
L502
C526
C538
C537
R521
R520
R463
R464
C464
C463
C53
9
8
5
3
54
56
10
45
8
68
250
49
BE
BE
BE
J1
Q24
CN301
D402
D503
J501
Q23
Q504
CN401
D401
D407
D502
D408
P105
P106
D600
CN502
D400
X14-985x-xx
Ref. No Address Ref. No Address
IC1
IC10
IC202
IC204
IC205
IC301
IC400
IC401
IC403
IC404
IC405
IC406
Q2
Q3
Q4
Q5
Q6
Q7
Q8
Q9
Q10
Q13
Q14
2AH
5AJ
4AG
4AG
3AG
5AH
3AJ
4AJ
4AI
4AI
4AH
3AH
2AF
2AF
2AF
3AF
3AF
2AF
3AF
2AF
2AF
3AG
2AG
Q15
Q16
Q17
Q19
Q20
Q21
Q22
Q23
Q24
Q25
Q104
Q105
Q109
Q110
Q201
Q203
Q204
Q205
Q305
Q309
Q401
Q504
2AG
2AG
2AG
2AH
3AH
2AH
2AH
3AJ
3AJ
3AH
3AF
4AF
5AF
5AF
4AG
4AH
4AH
4AH
5AI
5AG
3AH
3AJ

18
DDX8019/8029/8029Y/8039
AO AP AQ AR AS
1
2
3
4
5
6
7
VIDEO CONTROL UNIT
X14-985x-xx A/2 (J76-0388-22)
X14 B/2
R43
R541
C202
C203
C209
C327
R344
R3
C523
C330
C335
R335
R337
R347
R349
R351
R353
R354
R355
C16
C19
R69
C515
R551
CP403
R71
C514
C406
L402
C12
C13
R58
C431
C432
C505
C509
C528
C22
R415
C10
C11
R53
R63
C510
CP401
CP402
R420
C331
C333
R331
R542
R544
R51
R52
R54
R56
R57
R59
R65
R67
R68
R70
C4
R4
C206
R201
R262
X201
C317
C512
C513
R500
C329
C343
C344
C345
R334
R336 R338
R346
R348
R350
R352
R357
R359
R361
C332
C334
C27
R44
R50
R55
R66
R73
R74
R76
C340
C28
C341
C342
R202
R20
3
R
2
R330
R332
R339
R342
R345
R356
R358
R360
R370
R371
R372
R373
R374
R375
R376
R377
R378
R379
R380
R381
R382
R383
R384
R385
R404
R414
R453
R454
R455
R456
R261
R543
R552
X202
R600
R394
C364 C524
C529
C362
C527
C518
C520
C26
C363
C530
C361
C519
C521
C536
R79
R72
R75
R461
C29
R462
R523 R524
C436
C437
R503
R529 R528
R95
C45
18
16 9 16 9
18
13
45
12
119
220
916
81
1
14
75
1
76
100
5
43
1
1
3
5
4
58
14
5
43
1
291
230
7
1
BEBE
BE
EB
EB
BE
BE
BE
B
BEBE
BE
E
BE
BE
BE
BE
BE
BE
BE
CBE CBE
BEC BEC
ECB CEB
E
CBE
CB
BE
BE
CN504
CN505
Q26
Q304
Q33
Q37
Q306
Q307
Q308
Q43
Q46
Q207
Q31
Q35
Q38
Q34
Q45
D404
Q32
Q36
Q44
Q206
D2
Q1
Q508
D312
D313
D314
D315
D316
D317
D318 D319 D320
D322
D323
D324
CN503
D3
D301
D403
Q301
CN601
Q509
D5
Q506 Q507
D506
IC201
IC302
IC502
IC501
IC402
IC407
IC408
IC303
IC304
IC2
PC BOARD (FOIL SIDE VIEW)

19
DDX8019/8029/8029Y/8039
AXAWAVAUAT
1
2
3
4
5
6
7
Refer to the schematic diagram for the values of resistors and capacitors.
R170
R5
R260
C208
0
9
C117
C118
R171
C523
C183
R104
R133
C112
R116
R124
R120
R158
C153
R154
R162
C158
C159
C143
R143
C119
C120
C160
C161
C531
C210
R209
R210
R211
R212
R213
R226
R227
C206
C207
R230
R262
C101
C104
C105
C107
C108
C110
C114
C115
C142
C145
C146
C148
C149
C151
C155
C156
R102 R103
R106
R108
R112
R115
R118
R145
R146
R150
R153
R156
4
3
4
4
4
5
5
7
5
9
6
1
C102
C106
C109
C111
C116 C121
C147
C150
C152
C157 C162
C184
R105 R107
R111
R114
R117
R121
R122
R123
R130
R131
R132
R144
R149
R152
R155
R159
R160
R161
R168
R169
R202
R203
R204
R208
R214
R216
R218
R219
R222
R223
R224
R225
R232
R233
R237
R251
5
6
5
8
0
C532
R511
R512
R513
R514
R515
R261
X202
C524
2
9
17
14 8
51
25
26
50
14
85
1
14 15
28
1
14 15
28
BE
BE
BE
BE
BE
BE
BE
Q600
D101
D103
Q101
Q103
Q106
Q108
Q111
Q601
D102
D104
IC201
IC101
IC501
IC102
IC203
X14-985x-xx
Ref. No Address Ref. No Address
IC2
IC101
IC102
IC201
IC203
IC302
IC303
IC304
IC402
IC407
IC408
IC501
IC502
Q1
Q26
Q31
Q32
Q33
Q34
Q35
Q36
Q37
Q38
6AQ
4AU
5AU
4AS
4AT
5AR
5AR
5AR
3AR
4AQ
4AQ
3AT
4AP
3AQ
3AS
5AQ
5AQ
5AQ
5AQ
3AQ
3AQ
4AQ
3AQ
Q43
Q44
Q45
Q46
Q101
Q103
Q106
Q108
Q111
Q206
Q207
Q301
Q304
Q306
Q307
Q308
Q506
Q507
Q508
Q509
Q600
Q601
5AQ
5AR
5AQ
5AR
3AT
3AU
4AU
4AU
5AU
5AQ
5AR
4AS
5AS
5AS
5AS
5AS
5AP
5AQ
4AP
6AP
5AT
5AT

20
DDX8019/8029/8029Y/8039
AY AZ BA BB BC
1
2
3
4
5
6
7Refer to the schematic diagram for the values of resistors and capacitors.
J100
J101
P301 P302
P303 P304
CN327
CN101
D104
D105
D109
D102 D103
D300
D106
D107
D108
IC305
IC105
IC100
IC303
IC309
IC106
IC302
IC300
IC101
IC301
IC200
IC207
IC322
DIGITAL I/O UNIT X88-2020-15 (J76-0394-42)
1
4
1
1
1
5
1
1
15
48
1
11
3
1
37
40
1
1
4
1
13
10
5
R502
R503
R505
R496
R498
R500
C113
C138
C139
C200
C202
C300
C106
CP204
R157
R158
L302
CP205
C342
CP206
R293
C112
R294
R295
R6
R8
R177
CP128
CP129 CP130
CP131 CP147
CP148
CP149
CP150
CP151
CP152
CP153
CP154
R178
CP207
C100
R179
C101
L203
L204
L205
L212
L306
L307
L310
R105
R107
R108 R109
R1
R116
R118
R124
R126
R220
R221
R267
R268
R269
R270
R271
L300
L301
L304
C143
R159
C330
L305
C352
C354
C355
C356
C357
C360 C361
C375
C376
R465
L101
C126
C133
L102
C130
C134
C118
R112
C311
C322
C336
R37
R36
C227
R212
C228
R213
C362 C363
C303
C304
C305
C306
C308
C313
C319 C320
C325
R318
R443
R444
R445
C331
C332
R320
C201
C314
C316
R301
R300
R35
R33
C153
C317
R34
C302
CP104
C142
C230 C231
R13
C264
C301
C307
C107 C389
C392
C394
C395
R180
C140
R181
R182
R292
R115
U1 A1
U17 A17
R121
R123
R162
R129
R137
R219
R248
R249
R250
R258 R259 R260
R265 R266
R304
R305
R308 R310
R321
R322
R185
R186
C315
R440
C309
C310
C312
C318
C328
C329
R467
C367
C368
R344
R345
R458
C337
C338
C340
C341
C349
C351
R187
CP105
R188
R189
R190
R191R192
R160
R161
R163
R166
CP155
CP156
CP157
CP158
CP159
R165
R164
R167
R170
R172
R171
R175
R203
R329 R328
R202
R200
L303
R104
R134
R139
R150
R153
R174
R173
R176
R255
R3
R9
R273
R10
R315 R317
R324
R325
R326
R327
R459
R332
R333
R343
R5
R373
R14
R463 R464
R473
R478
R485 R486
R487
R494
X100
X202
C148
R284
R285 R286
R287
C154
R462
C478
L200
R523
R291
R15
R16
R142
R141
R529
C275 R297
C800
C801
C802
C803
C804
C805
C807
C808
C809
C810
C811
C812 C813
C814
R601 R600
R602
R603
C601
C602
R703
R705
81
31
20
10 21
30
6
36 25
12
24
48
37
4
6
3
1
5
48
24
13
12
2536
20
1110
81
4
60
12
36 25
37
48
24
13
3
5
4
80 61
21 40
20 41
60
TP302
TP200
TP300
PC BOARD (COMPONENT SIDE VIEW)
X88-2020-15
Ref. No Address
IC100
IC101
IC105
IC106
IC200
IC207
IC301
IC302
IC305
IC309
IC322
5AZ
5AZ
5AZ
4AZ
2AZ
2AZ
6AZ
5AZ
6AZ
5BB
5BA
