Kenwood KDC-1010U User manual

Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
B5A-0872-00 (MN/M2N/HN)© 2015 JVC KENWOOD Corporation
KDC-1010U
KDC-200UV
KDC-100UW
KDC-100UR
CD-RECEIVER
INSTRUCTION MANUAL
KDC-100UG
KDC-100UB
KDC-100UA
KDC-181UWM
KDC-161URM
KDC-151UBM
JS_KWD_KDC_1010U_MN_C00_4.indd 1JS_KWD_KDC_1010U_MN_C00_4.indd 1 14/7/2015 4:11:54 PM14/7/2015 4:11:54 PM

Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
2
CONTENTS BEFORE USE
IMPORTANT
• To ensure proper use, please read through this manual before using this product. It is especially important
that you read and observe Warning and Caution in this manual.
• Please keep the manual in a safe and accessible place for future reference.
Warning
Do not operate any function that takes your attention away from safe driving.
Caution
Volume setting:
• Adjust the volume so that you can hear sounds outside the car to prevent accidents.
• Lower the volume before playing digital sources to avoid damaging the speakers by the sudden increase of
the output level.
General:
• Avoid using the external device if it might hinder safe driving.
•
Make sure all important data has been backed up. We shall bear no responsibility for any loss of recorded data.
• Never put or leave any metallic objects (such as coins or metal tools) inside the unit, to prevent a short
circuit.
• If a disc error occurs due to condensation on the laser lens, eject the disc and wait for the moisture to
evaporate.
• Depending on the types of cars, the antenna will automatically extend when you turn on the unit with
the antenna control wire connected ( 
19, 20 ). Turn off the unit or change the source to STANDBY when
parking at a low ceiling area.
Remote control (RC-406):
• Do not leave the remote control in hot places such as on the dashboard.
• The Lithium battery is in danger of explosion if replaced incorrectly. Replace it only with the same or
equivalent type.
• The battery pack or batteries shall not be exposed to excessive heat such as sunshine, fire or the like.
• Keep the battery out of reach of children and in its original packaging when not in used. Dispose of used
batteries promptly. If swallowed, contact a physician immediately.
How to read this manual
• Operations are explained mainly using buttons on the faceplate of .
• English indications are used for the purpose of explanation. You can select the display language from the
[
FUNCTION ] menu. (  5 )
• [
XX ] indicates the selected items.
• ( 
XX ) indicates references are available on the stated page.
BEFORE USE 2
BASICS 3
GETTING STARTED 4
1 Select the display language
and cancel the demonstration
2 Set the clock and date
3 Set the initial settings
RADIO 6
AUX 7
CD / USB / iPod / ANDROID 8
Pandora®
(for ) 10
AUDIO SETTINGS 11
DISPLAY SETTINGS 12
TROUBLESHOOTING 13
REFERENCES 15
Maintenance
More information
INSTALLATION /
CONNECTION 17
SPECIFICATIONS 21
JS_KWD_KDC_1010U_MN_EN_4.indd 2JS_KWD_KDC_1010U_MN_EN_4.indd 2 14/7/2015 4:11:30 PM14/7/2015 4:11:30 PM

Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
3
BASICS
To On the faceplate On the remote control
Turn on the power Press .
• Press and hold to turn off the power.
Press and hold SRC to turn off the power.
( Pressing SRC does not turn on the power. )
Adjust the volume Turn the volume knob. Press or .
Press ATT during playback to attenuate the sound.
• Press again to cancel.
Select a source Press repeatedly. Press SRC repeatedly.
Change the display information Press DISP repeatedly. ( 
16 ) ( Not available )
Faceplate
How to resetAttach Detach
Remote control (RC-406)
(Sold separately for / /
)
: Flashes when the unit
enters searching status.
ENGLISH
Display window
Pull out the
insulation sheet
when using for the
first time.
Your preset adjustments
will be erased except
stored radio stations.
How to replace the battery
Remote sensor (Do not expose
to bright sunlight.)
Volume knob
Detach button
Loading slot
*
Not used
JS_KWD_KDC_1010U_MN_EN_5.indd 3JS_KWD_KDC_1010U_MN_EN_5.indd 3 24/7/2015 4:47:03 PM24/7/2015 4:47:03 PM

4
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
GETTING STARTED
Select the display language and cancel the demonstration
When you turn on the power (or after you reset the unit), the display shows:
“SEL LANGUAGE” “PRESS” “VOLUME KNOB”
1 Turn the volume knob to select the desired display language, [ ENG ]
(English) or [
TUR ] (Turkish), then press the knob.
/ / : Selectable display language:
[
EN ] (English)/ [ RU ] (Russian)/ [ TU ] (Turkish)/ [ SP ] (Spanish)
[
ENG ]/ [ EN ] is selected for the initial setup.
Then, the display shows: “CANCEL DEMO” “PRESS” “VOLUME KNOB”.
2 Press the volume knob.
[
YES ] is selected for the initial setup.
3 Press the volume knob again.
“DEMO OFF” appears.
Set the clock and date
1 Press the volume knob to enter [
FUNCTION ].
2 Turn the volume knob to select [ CLOCK ], then press the knob.
To adjust the clock
3 Turn the volume knob to select [ CLOCK ADJUST ], then press the knob.
4 Turn the volume knob to make the settings, then press the knob.
Hour Minute
5 Turn the volume knob to select [ CLOCK FORMAT ], then press the knob.
6 Turn the volume knob to select [ 12H ] or [ 24H ], then press the knob.
1
2
To set the date
7 Turn the volume knob to select [ DATE FORMAT ], then press the
knob.
8 Turn the volume knob to select [ DD/MM/YY ] or [ MM/DD/YY ], then
press the knob.
9 Turn the volume knob to select [ DATE SET ], then press the knob.
10 Turn the volume knob to make the settings, then press the
knob.
Day Month Year or Month Day Year
11 Press and hold to exit.
To return to the previous setting item, press .
Set the initial settings
1 Press repeatedly to enter STANDBY.
2 Press the volume knob to enter [ FUNCTION ].
• Pressing AUD enters [ AUDIO CONTROL ] directly.
3 Turn the volume knob to select an item (see the following
table), then press the knob.
4 Repeat step 3until the desired item is selected or activated.
5 Press and hold to exit.
To return to the previous setting item, press .
Default:
XX
AUDIO CONTROL
SWITCH
PREOUT
REAR / SUB-W or REAR / SUBWOOFER : Selects whether rear
speakers or a subwoofer are connected to the line out terminals on
the rear (through an external amplifier).
SP SELECT OFF / 5/4 / 6 × 9/6 / OEM : Selects according to the speaker size
(5inches or 4inches, 6×9inches or 6inches) or OEM speakers for
optimum performance.
3
JS_KWD_KDC_1010U_MN_EN_5.indd 4JS_KWD_KDC_1010U_MN_EN_5.indd 4 24/7/2015 4:47:04 PM24/7/2015 4:47:04 PM

ENGLISH 5
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
DISPLAY
EASY MENU
(For )
ON :Both display and button illumination change to white color when
entering [
FUNCTION ].; OFF :Both display and button illumination
remain as [
COLOR  SELECT ] color. (  13 )
TUNER SETTING
PRESET TYPE NORMAL
:Memorizes one station for each preset button in each band
(
6, RADIO ).; MIX :Memorizes one station for each preset button,
regardless of the selected band.
SYSTEM
KEY BEEP ON
:Activates the keypress tone.; OFF :Deactivates.
TDF ALARM
(Except for / / )
ON : Activates the alarm if you forget to detach the faceplate when ACC
is set to OFF.;
OFF : Deactivates.
SOURCE SELECT
PANDORA SRC
(For )
ON :Enables PANDORA in source selection.; OFF :Disables. (  10 )
BUILT-IN AUX ON :Enables AUX in source selection.; OFF :Disables. (  7 )
P-OFF WAIT
(For / / )
Applicable only when the demonstration mode is turned off.
Sets the duration when the unit will automatically turn off (while in
standby mode) to save the battery.
20M : 20minutes; 40M : 40minutes; 60M : 60minutes;
WAIT TIME – – – or OFF – – – :Cancels
CD READ 1 :Automatically distinguishes between audio file disc and music
CD.;
2 :Forces to play as a music CD. No sound can be heard if an
audio file disc is played.
F/W UPDATE
UPDATE SYSTEM
F/W UP xx.xx YES
:Starts upgrading the firmware.; NO :Cancels (upgrading is not
activated).
For details on how to update the firmware, see:
www.kenwood.com/cs/ce/
CLOCK
CLOCK DISPLAY ON
:The clock time is shown on the display even when the unit is
turned off.;
OFF :Cancels.
ENGLISH
Select the display language for [ FUNCTION ] menu and music
information if applicable.
By default, [
ENGLISH ] is selected.
*
Selectable only for / /
.
РУССКИЙ *
TURKCE
ESPANOL
*
GETTING STARTED
JS_KWD_KDC_1010U_MN_EN_5.indd 5JS_KWD_KDC_1010U_MN_EN_5.indd 5 28/7/2015 2:05:49 PM28/7/2015 2:05:49 PM

6
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
Direct Access Tuning (using RC-406)
1 Press DIRECT to enter Direct Access Tuning.
2 Press the number buttons to enter a frequency.
3 Press to search for a station.
• To cancel, press or DIRECT.
• If no operation is done for 10seconds after step2, Direct Access Tuning is
automatically canceled.
Other settings
1 Press the volume knob to enter [
FUNCTION ].
2 Turn the volume knob to select an item (see the following table), then
press the knob.
3 Repeat step 2until the desired item is selected or activated.
4 Press and hold to exit.
To return to the previous setting item, press .
Default:
XX
TUNER SETTING
LOCAL SEEK
*1
ON : Searches only stations with good reception. ; OFF : Cancels.
•
Settings made are applicable only to the selected source/station. Once you change
the source/station, you need to make the settings again.
AUTO
MEMORY
YES :Automatically starts memorizing 6 stations with good reception.; NO :Cancels.
•
Selectable only if [ NORMAL ] is selected for [ PRESET TYPE ]. (  5 )
MONO SET ON :Improves the FM reception, but the stereo effect may be lost.; OFF :Cancels.
NEWS SET ON : The unit will temporarily switch to News Programme if available. ; OFF : Cancels.
REGIONAL
*2
ON : Switches to another station only in the specific region using the “AF” control.;
OFF :Cancels.
AF SET
*2
ON : Automatically searches for another station broadcasting the same program
in the same Radio Data System network with better reception when the current
reception is poor.;
OFF :Cancels.
RADIO
Supported band:
/ / / /
/ / :
FM1/ FM2/ FM3/ AM/ SW1/ SW2
/ / :
FM1/ FM2/ FM3/ MW/ LW
Search for a station
1 Press repeatedly to select TUNER.
2 Press repeatedly (or press / on
RC-406) to select the band.
3 Press S/T(or press S/ on RC-406) to search
for a station.
• To change the searching method for S/T: Press
repeatedly.
AUTO1 : Automatically search for a station.
AUTO2 : Search for a preset station.
MANUAL : Manually search for a station.
• To store a station: Press and hold one of the number buttons
(1to6).
• To select a stored station: Press one of the number buttons
(1to6) (or press one of the number buttons (1to6) on RC-406).
JS_KWD_KDC_1010U_MN_EN_4.indd 6JS_KWD_KDC_1010U_MN_EN_4.indd 6 14/7/2015 4:11:31 PM14/7/2015 4:11:31 PM

ENGLISH 7
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
RADIO
TI ON :Allows the unit to temporarily switch to Traffic Information if available (“TI”
lights up).;
OFF :Cancels.
PTY SEARCH 1 Press the volume knob to enter PTY language selection.
2 Turn the volume knob to select the PTY language ( ENGLISH / FRENCH /
GERMAN ), then press the knob.
3 Turn the volume knob to select the available Program Type (see the following).
4 Press S/ T to start searching.
CLOCK
TIME SYNC ON
:Synchronizes the unit’s time to the Radio Data System station time.;
OFF :Cancels.
*1
/ / / / /
/ : AM/ SW1/ SW2 stations only.
/
/ : FM stations only.
*2
/ / / / /
/ : Default: [ OFF ]
/
/ : Default: [ ON ]
Available Program Type
SPEECH : NEWS , AFFAIRS , INFO (information), SPORT , EDUCATE , DRAMA , CULTURE ,
SCIENCE , VARIED , WEATHER , FINANCE , CHILDREN , SOCIAL , RELIGION , PHONE IN ,
TRAVEL , LEISURE , DOCUMENT
MUSIC
: POP M (music), ROCK M (music), EASY M (music), LIGHT M (music), CLASSICS ,
OTHER M (music), JAZZ , COUNTRY , NATION M (music), OLDIES , FOLK M (music)
The unit will search for the Program Type categorized under [
SPEECH ] or
[
MUSIC ] if selected.
• [ MONO SET ]/ [ NEWS SET ]/ [ REGIONAL ]/ [ AF SET ]/ [ TI ]/ [ PTY SEARCH ] is selectable only
when the band is FM1/ FM2/ FM3.
• If the volume is adjusted during reception of traffic information, alarm or news
bulletin, the adjusted volume is memorized automatically. It will be applied the
next time traffic information, alarm or news bulletin is turned on.
AUX
Preparation:
Select [
ON ] for [ BUILT-IN AUX ]. (  5 )
Start listening
1 Connect a portable audio player (commercially available).
2 Press repeatedly to select AUX.
3 Turn on the portable audio player and start playback.
Set the AUX name
While listening to a portable audio player connected to the unit...
1 Press the volume knob to enter [ FUNCTION ].
2 Turn the volume knob to select [ SYSTEM ], then press the
knob.
3 Turn the volume knob to select [ AUX NAME SET ], then press the
knob.
4 Turn the volume knob to select an item, then press the
knob.
AUX (default)/ DVD / PORTABLE / GAME / VIDEO / TV
5 Press and hold to exit.
To return to the previous setting item, press .
Auxiliary input jack
Portable audio player
3.5mm stereo mini plug with “L” shaped
connector (commercially available)
JS_KWD_KDC_1010U_MN_EN_4.indd 7JS_KWD_KDC_1010U_MN_EN_4.indd 7 14/7/2015 4:11:32 PM14/7/2015 4:11:32 PM

8
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
CD / USB / iPod / ANDROID
Start playback
The source changes automatically and
playback starts.
To On the faceplate On the remote control
Playback / pause Press . Press .
Reverse / Fast-forward*4Press and hold S/T. Press and hold S/ .
Select a track/file Press S/T. Press S/ .
Select a folder*5Press J/K.Press / .
Repeat play*6Press repeatedly.
TRACK REPEAT / ALL REPEAT : Audio CD
FILE REPEAT / FOLDER REPEAT / ALL REPEAT : MP3/WMA/WAV/FLAC file
FILE REPEAT / FOLDER REPEAT / REPEAT OFF : iPod or ANDROID
Random play*6Press repeatedly.
DISC RANDOM / RANDOM OFF : Audio CD
FOLDER RANDOM / RANDOM OFF : MP3/WMA/WAV/FLAC file, iPod or
ANDROID
Press and hold to select
ALL RANDOM .*7
*1
KCA-iP102 : 30-pin type, KCA-iP103 : Lightning type
*2
Do not leave the cable inside the car when not using.
*3
When connecting an Android device, “Press [VIEW] to install KENWOOD MUSIC PLAY APP” is shown. Follow the instructions
to install the application. You can also install the latest version of KENWOOD MUSIC PLAY application on your Android device
before connecting. ( 
15)
*4
For ANDROID: Applicable only when [ BROWSE MODE ] is selected. (  9)
*5
For CD: Only for MP3/WMA files. This does not work for iPod/ ANDROID.
*6
For iPod/ ANDROID: Applicable only when [ MODE OFF ]/ [ BROWSE MODE ] is selected. (  9)
*7
For CD: Only for MP3/WMA files.
Label side M Eject disc
USB input terminal
CA-U1EX (max.: 500mA)
(optional accessory)
Micro USB 2.0 cable
*2
(commercially available)
KCA-iP102 / KCA-iP103
(optional accessory)
*1
or accessory cable of the
iPod/iPhone
*2
USB
iPod/iPhone
(for )
ANDROID*3
JS_KWD_KDC_1010U_MN_EN_4.indd 8JS_KWD_KDC_1010U_MN_EN_4.indd 8 14/7/2015 4:11:32 PM14/7/2015 4:11:32 PM

ENGLISH 9
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
CD / USB / iPod / ANDROID
Select control mode
While in iPod source, press 5repeatedly.
MODE ON : Control iPod using the iPod itself. However, you can still
play/pause, file skip, fast-forward or reverse from this
unit.
MODE OFF : Control iPod from this unit.
While in ANDROID source, press 5repeatedly.
BROWSE MODE : Control Android device from this unit via KENWOOD
MUSIC PLAY application installed in the Android
device.
HAND MODE : Control Android device using the Android device
itself via other media player applications installed
in the Android device. However, you can still play/
pause and file skip from this unit.
Select music drive
Press 5repeatedly.
Stored songs in the following drive will be played back.
• Selected internal or external memory of a smartphone (Mass
Storage Class).
• Selected drive of a multiple drives device.
Select a file from a folder/list
1 Press .
2 Turn the volume knob to select a folder/list, then press the knob.
3 Turn the volume knob to select a file, then press the knob.
Quick Search
If you have many files in the iPod, you can search through them quickly
according to the first character of the file name.
Turn the volume knob quickly to enter character search.
Turn the volume knob to select the character.
To search for a character other than A to Z and 0to9, enter only “
*”.
Press S/Tto move to the entry position.
• You can enter up to 3characters.
Press the volume knob to start searching.
• To return to the root folder/ first file/ top menu, press 5.
• To return to the previous setting item, press .
• To cancel, press and hold .
• For iPod, applicable only when [
MODE OFF ] is selected.
• For ANDROID, applicable only when [
BROWSE MODE ] is selected.
Direct Music Search (using RC-406)
1 Press DIRECT.
2 Press the number buttons to enter a track/file number.
3 Press to search for music.
• To cancel, press or DIRECT.
• Not available if Random Play is selected.
• Not applicable for iPod and ANDROID.
JS_KWD_KDC_1010U_MN_EN_4.indd 9JS_KWD_KDC_1010U_MN_EN_4.indd 9 14/7/2015 4:11:32 PM14/7/2015 4:11:32 PM

10
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
CD / USB / iPod / ANDROID
Listen to TuneIn Radio/ TuneIn Radio Pro/
Aupeo
(for )
While listening to TuneIn Radio, TuneIn Radio Pro or
Aupeo, connect the iPod/iPhone to the USB input
terminal of the unit.
• The unit will output the sound from these
applications.
Other settings
1 Press the volume knob to enter [
FUNCTION ].
2 Turn the volume knob to select an item (see
the following table), then press the knob.
3 Repeat step 2until the desired item is selected
or activated.
4 Press and hold to exit.
To return to the previous setting item, press .
Default:
XX
USB
MUSIC DRIVE DRIVE CHANGE
:The next drive ([ DRIVE 1 ]
to [
DRIVE 5 ]) is selected automatically and
playback starts.
Repeat steps
1 to 3 to select the following
drives.
SKIP SEARCH 0.5% / 1% / 5% / 10% : While listening to
iPod or ANDROID, selects the skip search ratio
over the total files.
Pandora® (for )
Preparation:
Install the latest version of the Pandora application on your device (iPhone/ iPod touch), then
create an account and log in to Pandora.
• Select [
ON ] for [ PANDORA SRC ]. (  5 )
Start listening
1 Open the Pandora application on your device.
2 Connect your device to the USB input terminal.
The source changes to PANDORA and broadcast starts.
To On the faceplate On the remote control
Playback / pause Press . Press .
Skip a track Press T.Press .
Thumbs up or thumbs down*3Press J/K.Press / .
*1
KCA-iP102 : 30-pin type, KCA-iP103 : Lightning type
*2
Do not leave the cable inside the car when not using.
*3
If thumbs down is selected, the current track is skipped.
Create and save a new station
1 Press .
2 Turn the volume knob to select [ NEW STATION ], then press the knob.
3 Turn the volume knob to select [ FROM TRACK ] or [ FROM ARTIST ], then press the knob.
A new station is created based on the current song or artist.
4 Press and hold one of the number buttons (1to5) to store.
To select a stored station, press one of the number buttons (1to5).
USB input terminal
KCA-iP102 / KCA-iP103 (optional accessory)
*1
or
accessory cable of the iPod/iPhone
*2
JS_KWD_KDC_1010U_MN_EN_5.indd 10JS_KWD_KDC_1010U_MN_EN_5.indd 10 24/7/2015 4:38:58 PM24/7/2015 4:38:58 PM

ENGLISH 11
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
Pandora® (for )
Search for a registered station
1 Press .
2 Turn the volume knob to select an item, then press the knob.
[
BY DATE ]:According to the registered date
[
A-Z ]:Alphabetical order
3 Turn the volume knob to select the desired station, then press
the knob.
To cancel, press and hold .
(or using RC-406)
Press J/ Kto search for a station, then press .
Bookmark current song information
Press and hold the volume knob.
“BOOKMARKED” appears and the information is stored to your
device. The bookmark is available on your Pandora account but not
on this unit.
Delete a station
While listening to PANDORA...
1 Press the volume knob to enter [ FUNCTION ].
2 Turn the volume knob to select [ SYSTEM ], then press the knob.
3 Turn the volume knob to select [ STATION DEL ], then press the
knob.
4 Turn the volume knob to select [ A-Z ] or [ BY DATE ], then press
the knob.
5 Turn the volume knob to select the desired station to delete,
then press the knob.
6 Turn the volume knob to select [ YES ], then press the knob.
7 Press and hold to exit.
To return to the previous setting item, press .
AUDIO SETTINGS
While listening to any source...
1 Press AUD to enter [ AUDIO CONTROL ] directly.
2 Turn the volume knob to select an item (see the following table), then
press the knob.
3 Repeat step 2until the desired item is selected or activated.
4 Press and hold to exit.
(or using RC-406)
1 Press AUD to enter [ AUDIO CONTROL ].
2 Press J/ Kto select an item, then press .
To return to the previous setting item, press .
Default: XX
SUB-W LEVEL –15 to +15 ( 0 ) Adjusts the subwoofer output level.
BASS LEVEL –8 to +8 ( +2 )
Adjusts the level to memorize for each source. (Before making
an adjustment, select the source you want to adjust.)
MID LEVEL –8 to +8 ( +1 )
TRE LEVEL –8 to +8 ( +1 )
EQ PRO (This setting is stored to [ USER ].)
BASS ADJUST BASS CTR FRQ 60 / 80 / 100 / 200 or 60HZ / 80HZ / 100HZ / 200HZ : Selects
the center frequency.
BASS LEVEL –8 to +8 ( +2 ):Adjusts the level.
BASS Q FACTOR 1.00 / 1.25 / 1.50 / 2.00 :Adjusts the quality factor.
BASS EXTEND ON :Turns on the extended bass.; OFF :Cancels.
MID ADJUST MID CTR FRQ 0.5KHZ / 1.0KHZ / 1.5KHZ / 2.5KHZ :Selects the center
frequency.
MID LEVEL –8 to +8 ( +1 ):Adjusts the level.
MID Q FACTOR 0.75 / 1.00 / 1.25 :Adjusts the quality factor.
JS_KWD_KDC_1010U_MN_EN_6.indd 11JS_KWD_KDC_1010U_MN_EN_6.indd 11 31/7/2015 9:28:37 AM31/7/2015 9:28:37 AM

12
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
TRE ADJUST TRE CTR FRQ 10.0KHZ / 12.5KHZ / 15.0KHZ / 17.5KHZ :Selects the center
frequency.
TRE LEVEL –8 to +8 ( +1 ):Adjusts the level.
PRESET EQ DRIVE EQ / TOP40 / POWERFUL / ROCK / POPS / EASY / JAZZ / NATURAL / USER :Selects
a preset equalizer suitable to the music genre. (Select [
USER ] to use the settings made
in [
EQ PRO ].)
[
DRIVE EQ ] is a preset equalizer that reduces noise outside the car or running noise of
the tyres.
BASS BOOST LV1 / LV2 / LV3 or LEVEL1 / LEVEL2 / LEVEL3 :Selects your preferred bass boost level.;
OFF :Cancels.
LOUDNESS LV1 / LV2 or LEVEL1 / LEVEL2 :Selects your preferred low and high frequencies boost to
produce a well-balanced sound at a low volume level.;
OFF :Cancels.
SUBWOOFER SET ON :Turns on the subwoofer output.; OFF :Cancels.
LPF SUBWOOFER THROUGH :All signals are sent to the subwoofer.; 85HZ / 120HZ / 160HZ :Audio
signals with frequencies lower than 85Hz/ 120Hz/ 160Hz are sent to the subwoofer.
SUB-W PHASE REVERSE (180°)/ NORMAL (0°):Selects the phase of the subwoofer output to be in line
with the speaker output for optimum performance. (Selectable only if a setting other
than [
THROUGH ] is selected for [ LPF SUBWOOFER ].)
FADER R15 to F15 ( 0 ):Adjusts the rear and front speaker output balance.
BALANCE L15 to R15 ( 0 ):Adjusts the left and right speaker output balance.
VOLUME OFFSET For AUX: –8 to +8 ( 0 ) ; For other sources: –8 to 0 :Preset the initial volume level of
each source. (Before adjustment, select the source you want to adjust.)
SOUND RECNSTR
(Sound
reconstruction)
ON :Creates realistic sound by compensating the high-frequency components and
restoring the rise-time of the waveform that are lost in audio data compression.;
OFF :Cancels.
• [ SUB-W LEVEL ]/ [ SUBWOOFER SET ]/ [ LPF SUBWOOFER ]/ [ SUB-W PHASE ] is selectable only if
[
SWITCH PREOUT ] is set to [ SUB-W ] or [ SUBWOOFER ]. (  4 )
• [
SUB-W LEVEL ]/ [ LPF SUBWOOFER ]/ [ SUB-W PHASE ] is selectable only if [ SUBWOOFER SET ] is
set to [
ON ].
AUDIO SETTINGS DISPLAY SETTINGS
Set the dimmer
Press and hold DISP (DIMMER) to turn on or off the
dimmer.
• If you have set [
DIMMER TIME ], it will be canceled once you
press and hold this button.
Other settings
1 Press the volume knob to enter [
FUNCTION ].
2 Turn the volume knob to select [ DISPLAY ], then press the
knob.
3 Turn the volume knob to select an item (  13 ), then
press the knob.
4 Repeat step 3until the desired item is selected/
activated or follow the instructions stated on the
selected item.
5 Press and hold to exit.
To return to the previous setting item, press .
(For )
JS_KWD_KDC_1010U_MN_EN_6.indd 12JS_KWD_KDC_1010U_MN_EN_6.indd 12 31/7/2015 9:28:38 AM31/7/2015 9:28:38 AM

ENGLISH 13
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
DISPLAY SETTINGS
Default: XX
COLOR SELECT
(For )
Select color for
ALL ZONE , ZONE 1 and ZONE 2 separately.
1 Select a zone. (  12 )
2
Select a color for the selected zone.
VARIABLE SCAN / CUSTOM R/G/B / preset colors*
To make your own color, select [ CUSTOM R/G/B ]. The color you have
made will be stored in [
CUSTOM R/G/B ].
1 Press the volume knob to enter the detailed color adjustment.
2 Press S / T to select the color ( R / G / B ) to adjust.
3 Turn the volume knob to adjust the level (0— 9), then press the knob.
DIMMER
Dim the display illumination (and button illumination for ).
ON :Dimmer is turned on.; OFF :Cancels.
DIMMER TIME :Set the dimmer on and off time.
1 Turn the volume knob to adjust the [ ON ] time, then press the knob.
2 Turn the volume knob to adjust the [ OFF ] time, then press the knob.
(Default: [
ON ]: 6:00 PM or 18:00 ; [ OFF ]: 6:00 AM or 6:00 )
BRIGHTNESS 0 — 31 : Select your preferred brightness level for display illumination.
(For )
1 Select a zone. (  12 )
2
0 — 31 : Select your preferred brightness level for display and button
illumination.
TEXT SCROLL AUTO / ONCE :Select whether to scroll the display information
automatically, or scroll only once.;
OFF :Cancels.
*
Preset colors: RED1 / RED2 / RED3 / PURPLE1 / PURPLE2 / PURPLE3 / PURPLE4 / BLUE1 /
BLUE2
/ BLUE3 / SKYBLUE1 / SKYBLUE2 / LIGHTBLUE / AQUA1 / AQUA2 / GREEN1 /
GREEN2
/ GREEN3 / YELLOWGREEN1 / YELLOWGREEN2 / YELLOW / ORANGE1 / ORANGE2 /
ORANGERED
TROUBLESHOOTING
Symptom Remedy
General
Sound cannot be heard.
•
Adjust the volume to the optimum level.
•
Check the cords and connections.
“MISWIRING CHECK WIRING
THEN PWR ON” appears.
Turn the power off, then check to be sure the terminals
of the speaker wires are insulated properly. Turn the
power on again.
“PROTECTING SEND SERVICE”
appears.
Send the unit to the nearest service center.
•
Sound cannot be heard.
•
The unit does not turn on.
•
Information shown on the
display is incorrect.
Clean the connectors. ( 
15 )
The unit does not work at all. Reset the unit. ( 
3 )
R
adio
•
Radio reception is poor.
•
Static noise while listening
to the radio.
Connect the antenna firmly.
CD / USB / iPod
Disc cannot be ejected. Press and hold
M to forcibly eject the disc. Be careful
not to drop the disc when it is ejected. If this does not
solve the problem, reset the unit. ( 
3 )
Noise is generated. Skip to another track or change the disc.
Tracks do not play back as
you intended them to play.
Playback order is determined when files are recorded.
“READING” keeps flashing. Do not use too many hierarchical levels or folders.
Elapsed playing time is not
correct.
This is caused by how the tracks are recorded.
Correct characters are not
displayed (e.g. album name).
This unit can only display uppercase letters, numbers,
and a limited number of symbols. ( 
5 )
JS_KWD_KDC_1010U_MN_EN_5.indd 13JS_KWD_KDC_1010U_MN_EN_5.indd 13 24/7/2015 4:38:59 PM24/7/2015 4:38:59 PM

14
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
Symptom Remedy
CD / USB / iPod
“NA FILE” Make sure the disc contains supported audio files. (  15 )
“NO DISC” Insert a playable disc into the loading slot.
“TOC ERROR” Make sure the disc is clean and inserted properly.
“PLEASE EJECT” Reset the unit. If this does not solve the problem, consult
your nearest service center.
“READ ERROR” Copy the files and folders onto the USB device again. If this
does not solve the problem, reset the USB device or use
another USB device.
“NO DEVICE” Connect a USB device, and change the source to USB again.
“COPY PRO” A copy-protected file is played.
“NA DEVICE”
Connect a supported USB device, and check the connections.
“NO MUSIC” Connect a USB device that contains playable audio files.
“iPod ERROR”
•
Reconnect the iPod.
•
Reset the iPod.
ANDROID
•
Sound cannot
be heard during
playback.
•
Sound output only
from the Android
device.
•
Reconnect the Android device.
•
If in [ HAND MODE ], launch any media player application
on the Android device and start playback.
•
If in [ HAND MODE ], relaunch the current media player
application or use another media player application.
•
Restart the Android device.
•
If this does not solve the problem, the connected Android
device is unable to route the audio signal to unit. ( 
16 )
Cannot playback at
[
BROWSE MODE ].
•
Make sure KENWOOD MUSIC PLAY APP is installed on the
Android device. ( 
8 )
•
Reconnect the Android device and select the appropriate
control mode.
•
If this does not solve the problem, the connected Android
device does not support [
BROWSE MODE ]. (  16 )
TROUBLESHOOTING
Symptom Remedy
ANDROID
“NO DEVICE” or
“READING” keeps
flashing.
•
Switch off the developer options on the Android device.
•
Reconnect the Android device.
•
If this does not solve the problem, the connected
Android device does not support [
BROWSE MODE ].
(
16 )
Playback is intermittent
or sound skips.
Turn off the power saving mode on the Android device.
“ANDROID ERROR” /
“NADEVICE”
•
Reconnect the Android device.
•
Restart the Android device.
Pandora
“ADDERROR” New station creation is unsuccessful.
“CHECKDEVICE” Check the Pandora application on your device.
“NOSKIPS” The skip limit has been reached.
“NOSTATIONS” No stations are found.
“STATIONLIMIT”
The number of registered stations has reached its limit.
Retry after deleting unnecessary stations from your device.
“CONNECT ERROR” Communication is unstable.
“RATING ERROR” Registration of thumbs up/thumbs down has failed due to
insufficient network connectivity.
“THUMBS N/A” Registration of thumbs up/thumbs down is not allowed.
“LICENSE ERROR” You try to access from a country which Pandora is not
deliverable.
Muting upon the reception of a phone call
Connect the MUTE wire to your telephone using a commercial telephone accessory.
(
19, 20 )
When a call comes in, “CALL” appears. (The audio system pauses.)
•
To continue listening to the audio system during a call, press . “CALL” disappears
and the audio system resumes.
When the call ends, “CALL” disappears. (The audio system resumes.)
JS_KWD_KDC_1010U_MN_EN_4.indd 14JS_KWD_KDC_1010U_MN_EN_4.indd 14 14/7/2015 4:11:33 PM14/7/2015 4:11:33 PM

ENGLISH 15
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
REFERENCES
Maintenance
Cleaning the unit
Wipe off dirt on the faceplate with a dry silicone or soft cloth.
Cleaning the connector
Detach the faceplate and clean the connector gently
with a cotton swab, being careful not to damage
the connector.
Handling discs
•
Do not touch the recording surface of the disc.
•
Do not stick tape etc. on the disc, or use a disc with tape stuck on it.
•
Do not use any accessories for the disc.
•
Clean from the center of the disc and move outward.
•
Clean the disc with a dry silicone or soft cloth. Do not use any solvents.
•
When removing discs from this unit, pull them out horizontally.
•
Remove burrs from the center hole and disc edge before inserting a disc.
More information
Visit also the following website <www.kenwood.com/cs/ce/> for:
–
Latest firmware updates and latest compatible item list
–
Android™ application KENWOOD MUSIC PLAY
–
Any other latest information
General
•
This unit can only play the following CDs:
•
Detailed information and notes about the playable audio files are stated in an online manual
on the following website: www.kenwood.com/cs/ce/audiofile/
Connector (on the reverse
side of the faceplate)
Playable files
•
Playable audio file: MP3 (.mp3), WMA (.wma)
•
Playable disc media: CD-R/CD-RW/CD-ROM
•
Playable disc file format: ISO 9660 Level 1/2, Joliet, Long file name.
•
Playable USB device file system: FAT12, FAT16, FAT32
Even when audio files comply with the standards listed above, playback may be impossible
depending on the types or conditions of media or device.
Unplayable discs
•
Discs that are not round.
•
Discs with coloring on the recording surface or discs that are dirty.
•
Recordable/ReWritable discs that have not been finalized.
•
8cm CD. Attempting to insert using an adapter may cause malfunction.
About USB devices
•
This unit can play MP3/WMA/WAV/FLAC files stored on a USB mass storage class device.
•
You cannot connect a USB device via a USB hub.
•
Connecting a cable whose total length is longer than 5m may result in abnormal playback.
•
This unit cannot recognize a USB device whose rating is other than 5V and exceeds 1A.
About iPod/iPhone
Made for
-
iPod touch (2nd, 3rd, 4th, and 5th generation)
-
iPod classic
-
iPod nano (3rd, 4th, 5th, 6th, and 7th generation)
-
iPhone 3G, 3GS, 4, 4S, 5, 5S, 5C, 6, 6 Plus
•
You cannot operate iPod if “KENWOOD” or “ ” is displayed on iPod.
JS_KWD_KDC_1010U_MN_EN_5.indd 15JS_KWD_KDC_1010U_MN_EN_5.indd 15 28/7/2015 2:06:21 PM28/7/2015 2:06:21 PM

16
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
REFERENCES
Change the display information
Each time you press DISP , the display information changes.
•
If the information is unavailable or not recorded, “NO TEXT”, “NO INFO”, or other information (eg. station name, playing time) appears.
Source name
/ / /
/ / /
/ /
STANDBY Source name (Date/Clock) Source name Clock (back to the beginning)
TUNER Frequency (Date/Clock) Frequency Clock (back to the beginning)
(For FM Radio Data System stations only)
Station name (Date/Clock) Radio text (Date/Clock)
Radio text+ (R.TEXT+) Title (Artist) Title (Date/Clock)
Frequency (Date/Clock) (back to the beginning)
(For FM Radio Data System stations only)
Station name Radio text Radio text+
Title/Artist Frequency Clock
(back to the beginning)
CD or USB (For CD-DA)
Track title (Artist) Track title (Disc name) Track title
(Date/Clock) Playing time (Date/Clock)
(back to the beginning)
(For CD-DA)
Disc name/Artist Track title/Artist Playing time
Clock (back to the beginning)
(For MP3/WMA/WAV/FLAC files)
Track title (Artist) Track title (Album title) Track title
(Date/Clock) File name (Folder name) File name
(Date/Clock) Playing time (Date/Clock)
(back to the beginning)
(For MP3/WMA/WAV/FLAC files)
Track title/Artist Album title/artist Folder name
File name Playing time Clock
(back to the beginning)
IPOD or
ANDROID
Track title (Artist) Track title (Album name) Track title
(Date/Clock) Playing time (Date/Clock)
(back to the beginning)
Track title/Artist Album title/Artist Playing time
Clock (back to the beginning)
PANDORA Station name (Date/Clock) Shared / Radio station
(Date/Clock) Track title (Artist) Track title (Album title)
Track title (Date/Clock) Playing time (Date/Clock)
(back to the beginning)
—
AUX Source name (Date/Clock) Source name Clock (back to the beginning)
About Android device
•
This unit supports Android OS 4.1 and above.
•
Some Android devices (with OS 4.1 and above) may
not fully support Android Open Accessory (AOA) 2.0.
•
If the Android device supports both mass storage
class device and AOA 2.0, this unit always playback
via AOA 2.0 as priority.
About Pandora
•
Pandora is only available in certain countries.
Please visit <http://www.pandora.com/legal> for
more information.
•
Because Pandora is a third-party service, the
specifications are subject to change without
prior notice. Accordingly, compatibility may be
impaired, or some or all of the services may become
unavailable.
•
Some functions of Pandora cannot be operated from
this unit.
•
For issues using the application, please contact
Pandora at [email protected].
JS_KWD_KDC_1010U_MN_EN_5.indd 16JS_KWD_KDC_1010U_MN_EN_5.indd 16 24/7/2015 4:40:24 PM24/7/2015 4:40:24 PM

ENGLISH 17
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
INSTALLATION / CONNECTION
Warning
•
The unit can only be used with a 12V DC power supply, negative ground.
•
Disconnect the battery’s negative terminal before wiring and mounting.
•
Do not connect Battery wire (yellow) and Ignition wire (red) to the car chassis or Ground wire
(black) to prevent a short circuit.
•
Insulate unconnected wires with vinyl tape to prevent a short circuit.
•
Be sure to ground this unit to the car’s chassis again after installation.
Caution
•
For safety’s sake, leave wiring and mounting to professionals. Consult the car audio dealer.
•
Install this unit in the console of your vehicle. Do not touch the metal parts of this unit during
and shortly after use of the unit. Metal parts such as the heat sink and enclosure become hot.
•
Do not connect the [ wires of speakers to the car chassis or Ground wire (black), or connect
them in parallel.
• Mount the unit at an angle of less than 30º.
•
If your vehicle wiring harness does not have the ignition terminal, connect Ignition wire (red)
to the terminal on the vehicle’s fuse box which provides 12 V DC power supply and is turned
on and off by the ignition key.
•
Keep all cables away from heat dissipate metal parts.
•
After the unit is installed, check whether the brake lamps, blinkers, wipers, etc. on the car are
working properly.
•
If the fuse blows, first make sure the wires are not touching car’s chassis, then replace the old
fuse with one that has the same rating.
Basic procedure
1 Remove the key from the ignition switch, then disconnect the [
terminal of the car battery.
2 Connect the wires properly.
See Wiring connection. ( 
19, 20 )
3 Install the unit to your car.
See Installing the unit (in-dash mounting).
4 Connect the [terminal of the car battery.
5 Reset the unit. (  3 )
Part list for installation
(A) Faceplate (B) Trim plate
(C) Mounting sleeve
(E) Wiring harness
(D) Extraction key
/ // /
/ /
/ /
JS_KWD_KDC_1010U_MN_EN_4.indd 17JS_KWD_KDC_1010U_MN_EN_4.indd 17 14/7/2015 4:11:34 PM14/7/2015 4:11:34 PM

18
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
Do the required wiring.
(
19, 20 )
Dashboard of
your car
Bend the appropriate tabs to hold the
mounting sleeve firmly in place.
How to remove the unit
1 Detach the faceplate.
2 Fit the catch pin on the
extraction keys into the holes
on both sides of the trim plate,
then pull it out.
3 Insert the extraction keys
deeply into the slots on each
side, then follow the arrows as
shown on the right.
Installing the unit (in-dash mounting)
Hook on the top side
Orientate the trim plate as
illustrated before fitting.
INSTALLATION / CONNECTION
When installing without the mounting sleeve
1 Remove the mounting sleeve and trim plate from the unit.
2 Align the holes in the unit (on both sides) with the vehicle
mounting bracket and secure the unit with screws
(supplied).
The following screws are supplied for:
/ / / /
/ / :
Round head screws (M5 × 8mm) × 4 To secure the mounting
bracket
Flat head screws (M5 × 8mm) × 4
Sems screws (M4 × 8mm) × 1 To secure the ground
wire (black)
/ / :
Round head screws (Ø5 × 8mm) × 4 To secure the mounting
bracket
Flat head screws (Ø5 × 8mm) × 4
Sems screws (M4 × 8mm) × 1 To secure the ground
wire (black)
Use only the specified screws. Using wrong screws might damage the unit.
– – – – – or – – – – –
JS_KWD_KDC_1010U_MN_EN_4.indd 18JS_KWD_KDC_1010U_MN_EN_4.indd 18 14/7/2015 4:11:34 PM14/7/2015 4:11:34 PM

ENGLISH 19
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
INSTALLATION / CONNECTION
Wiring connection (for / / / / / / )
Fuse (10A)
Front/ Rear/ subwoofer output
Antenna terminal
Car fuse box
Car fuse box
Battery
Ignition switch
Blue/White
(Power control wire/
Antenna control wire)
Light blue/yellow
(Steering remote control wire)
Red (Ignition wire)
Yellow (Battery wire)
Black (Ground wire)
To the metallic body or chassis of the car
To the power control terminal when using the optional
power amplifier or to the antenna control terminal in
the vehicle
Brown
(Mute control wire)
White
Gray
Green
Purple
White/Black
Gray/Black
Green/Black
Purple/Black
To the terminal that is grounded when the telephone
rings or during conversation
(  14 )
(To connect the Kenwood navigation system, refer your
navigation manual.)
To front speaker (left)
To rear speaker (left)
To front speaker (right)
To rear speaker (right)
If no connections are made, do not let the wire come out from the tab.
To the steering wheel remote control adapter
When connecting to an external amplifier, connect its ground
wire to the car’s chassis to avoid damaging the unit.
IMPORTANT : We recommend installing the unit with a commercially available custom wiring harness specific for your car
and leave this job to professionals for your safety. Consult your car audio dealer.
JS_KWD_KDC_1010U_MN_EN_4.indd 19JS_KWD_KDC_1010U_MN_EN_4.indd 19 14/7/2015 4:11:35 PM14/7/2015 4:11:35 PM

20
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
REMOTE CONT
STEERING WHEEL
REMOTE INPUT
P. CONT
ANT CONT
MUTE
If your car does not have an ISO terminal :
We recommend installing the unit with a commercially
available custom wiring harness specific for your car and
leave this job to professionals for your safety. Consult your
car audio dealer.
INSTALLATION / CONNECTION
Wiring connection (for / / )
Fuse (10A)Front/ Rear/ subwoofer output
Antenna terminal
Blue/White
(Power control wire/
Antenna control wire)
Light blue/yellow
(Steering remote control
wire)
To the power control terminal
when using the optional power
amplifier or to the antenna control
terminal in the vehicle
Brown
(Mute control wire)
To the terminal that is grounded
when the telephone rings or during
conversation
(  14 )
(To connect the Kenwood
navigation system, refer your
navigation manual.)
If no connections are made, do not let the wire come out from the tab.
To the steering wheel remote
control adapter
Yellow (A4)
Red (Ignition wire)
Red (A7)
Yellow (Battery wire)
Pin Color and function
A4 Yellow : Battery
A5 Blue/White : Power control
A7 Red : Ignition (ACC)
A8 Black : Earth (ground) connection
B1 Purple
]
: Rear speaker (right)
B2 Purple/black
[
B3 Gray
]
: Front speaker (right)
B4 Gray/black
[
B5 White
]
: Front speaker (left)
B6 White/black
[
B7 Green
]
: Rear speaker (left)
B8 Green/black
[
ISO connectors
Connecting the ISO connectors on some VW/Audi or
Opel (Vauxhall) automobiles
You may need to modify the wiring of the supplied
wiring harness as illustrated below.
UnitVehicle
A7 (Red)
Ignition wire
(Red)
A4 (Yellow)
Default wiring
Battery wire
(Yellow)
When connecting to an external amplifier, connect its
ground wire to the car’s chassis to avoid damaging the unit.
JS_KWD_KDC_1010U_MN_EN_4.indd 20JS_KWD_KDC_1010U_MN_EN_4.indd 20 14/7/2015 4:11:35 PM14/7/2015 4:11:35 PM
