Kenwood KDC-715S User manual

KDC-715S
DISP
Escutcheon assy
(B07-2139-03)
Panel assy
KDC-715S : (A64-1872-02)
KDC-8015 : (A64-1871-02)
KDC-8016 : (A64-1874-02)
Dressing panel
(A21-4010-03)
DC cord
(E-30-4780-05)
Torsion coil spring
(G01-2924-04)
Screw set
(N99-1683-05)
Mounting hardware assy
(J21-9491-03)
Plastic cabinet assy
(A02-1489-03) Remote controller assy (A70-0883-05) Lever
(D10-4301-14)
Lever
(D10-4302-14)
Bracket
(J19-4876-04)
Bracket
(J19-4875-04)
Screw set
(N99-1652-05)
Stay
(J54-0606-04)
Escutcheon assy
(B07-2183-02)
Front grass
KDC-715S : (B10-3112-01)
KDC-8015 : (B10-3111-01)
KDC-8016 : (B10-3114-01)
Illustration is KDC-715S
© 2000-1 PRINTED IN JAPAN
B51-7570-00 (N)1789
CD RECEIVER
SERVICE MANUAL
KDC-715S/8015
KDC-8016
Extension cord Parts No.
CD mechanism (22P) W05-0618-00
The MECHANISM OPERATION DESCRIPTION is the same as model KDC-S3007 and KDC-5050RG.
Please refer to the service manual for model KDC-S3007 (B51-7029-00) or KDC-5050RG (B51-7099-00).
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

KDC-715S/8015/8016
2
BLOCK DIAGRAM
COM+B
FM+B
AM+B
E2PROM
DIMMER
2WAY MUTE
ACC DET.
SRM
PHOT
BU DET.
SRM
DRIVER
A8V
SERVO
DC/DC
SW14V
SW5V BU5V
P CON
ANT-CON
MUTE DRIVER
4.5V PRE
MUTE
E's
POWER IC
IC4
IC14
u-com
IC1
CD
CH
IC10
IC7-9
IC5
IC2
F/E
MECHA
DET.
E-VOL
PREOUT
SP-OUT
DIMMER
TEL-MUTE
ACC
ANT-CONT
P-CON
BACK UP
DECORDER
RDS
IC11
EX.AMP CONTROL
AVR
RESET IC
IC15
ANT. IN
AMP
IC12 NOISE
PREOUT OUTPUT VOLTAGE
CONTROL
EX.AMP
NAVI-MUTE
PANEL 5V
4.5VPRE
IC3
IC6
ILLUM
+B
LCD
LCD CONT. 1 G/R SW
KEY
MATRIX
LCD TYPE
LOCK SW
PANEL
REMO
RESET SW
PLL CLK
CH
MO SW
SERVO+B
LO/EJ
STOP
MUTE
DATA S
CLK
SW2
CS
SQR
DATA M
SW3
SW1
A8V
BU5V
RST
REQ C
CLK
CH-CON
DATA H
REQ H
CD
AM
FM
MUTE
RESET
SRM SW1
SRM DET
SRM SW2
RDCK
RDDA
QUAL
SDA
SCL
A8V
+B
-B
+B
-B
PLL DATA
PLL CE
S-METER
SW5V
SW5V
DATA C
BACK UP
750mV
4500mV
CHANGER
AM
4.5V PRE
2250mVFM
160mV
1200mV
1200mV
213mV (E TYPE)
400mV (K TYPE)
RDS OUT
FM+B
NOISE
4500mVCD K TYPEMODE 4500mV
4500mV
1069mV
1715mV
E TYPE 3600mV
600mV
1800mV
3600mV
K TYPE E TYPE
3600mV
1372mV
855mV
3600mV
1.8V PRE
SRM SUB-
SRM SUB+
DRIVER
MUTE
BU5V
PANEL 5V
DIMMER PWM CONTROL
ILLUM +B IS LCD ONLY
RST
L DATAL
L CLK
L CE
L DATAS
DIMMER
(X86)
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

KDC-715S/8015/8016
3
MICROCOMPUTER’S DESCRIPTION
System µ-com : UPD784217GC (X25-)
Terminal description
No. Pin name Function I/O Description Processing Operation
1 P120/RTP0 CHCON1 O Changer 1 control Active : Hi
2 P121/RTP1 CH_MUTE I Changer muting input MUTE Requested : Hi
3 P122/RTP2 REQH O Handshake request to changers Active : Lo
4 P123/RTP3 ILL_ON O Illumination output Active : Hi
5 P124/RTP4 NC O Open
6 P125/RTP5 CD_SW2 I 12cm DISC detection ON : Lo
7 P126/RTP6 CD_SW1 I Loading detection ON : Lo
8 P127/RTP7 NC O Open
9 Vdd Vdd - Positive power supply
10 X2 X2 - Main clock connection
11 X1 X1 - Main clock connection
12 Vss Vss - GND
13 XT2 XT2 - Sub clock connection
14 XT1 XT1 - Sub clock connection
15 RESET RESET I Reset input Active : Lo
16 P00/INTP0 CH_RST O Changer reset output Active : Lo
17 P01/INTP1 R_CLK I RDS clock input
18 P02/INTP2/NMI REQC I Handshake request from changer Active : Lo
19 P03/INTP3 N C I/O
20 P04/INTP4 N C I/O
21 P05/INTP5 N C I/O
22 P06/INTP6 SC_REQ I Handshake request from panel µ-com
23 AVdd AVdd - A/D analog power supply
24 AVref0 AVref - A/D reference voltage input
25 P10/ANI0 PHONE I PHONE detection terminal 1V or less : PHONE
2.5V or more : NAVI MUTE
26 P11/ANI1 SRM_SW1 I SRM position detection Open : Hi
27 P12/ANI2 NOISE I FM noise detection Analog input
28 P13/ANI3 SMETER I FM signal meter detection Analog input
29 P14/ANI4 IF_MODE I K2I IF selector Wide : Hi / Narrow : Lo
30 P15/ANI5 NC I GND
31 P16/ANI6 M_MUTE_R I Mute request from meshanism Mute requested : Lo
32 P17/ANI7 M_MUTE_L I Mute request from meshanism Mute requested : Lo
33 AVss AVss - A/D GND
34 P130/ANO0 EXT_AMP O EXT_AMP control
35 P131/ANO1 M_RST O Reset output to mechanism Reset : Lo
36 AVref1 - D/A reference voltage input
37 P70/RxD2/SI2 DATAC I Data line from changer
38 P71/TxD2/SO2 DATAH O Data line to changer
39 P72/ASCK2/SCK2 CH_CLK I/O Clock line from/to changer
40 P20/RxD1/SI1 L_DATAL/SC_DATA I Data line from LCD driver
41 P21/TxD1/SO1 L_DATAS/MC_DATA O Data line to LCD driver
42 P22/ASCK1/SCK1 L_CLK/MC_CLK I/O Clock line to LCD driver
43 P23/PCL M_STOP I/O Stop request to mechanism Stop Requested : Lo
44 P24/BUZ BEEP O Beep output Active : Hi
45 P25/SI0 PLL_CE O CE output to PLL
46 P26/SO0 PLL_DATA I/O Data in/out with PLL
47 P27/SCK0 PLL_CLK O Clock output to PLL
48 P80/A0 CD_SW3 I Switch detection ON : Hi
49 P81/A1 LO/EJ O Loading/Eject control Loading : Lo / Eject : Hi
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

KDC-715S/8015/8016
4
MICROCOMPUTER’S DESCRIPTION
No. Pin name Function I/O Description Processing Operation
50 P82/A2 MOSW O Motor output Loading : Hi / Eject : Lo
51 P83/A3 MECH_DET I Mechanism detection ON : Hi / OFF : Lo
52 P84/A4 PAN 5V O Panel detection OFF : Hi
53 P85/A5 L_CE/P_RST O CE to LCD driver / Panel µ-com reset
54 P86/A6 L_INH/MC_REQ O Reset to LCD driver
55 P87/A7 DIM_CON O DIM control
56 P40/AD0 QUAL I RDS receiving condition Good : Hi
57 P41/AD1 R_DATA I RDS data input
58 P42/AD2 SRM_SUB– O SRM sub motor output
59 P43/AD3 SRM_SUB+ O SRM sub motor output
60 P44/AD4 SRM_DET I SRM mechanism detection ON : Lo / OFF : Hi
61 P45/AD5 SRM_SW2 I SRM eject detection Å™ : Eject
62 P46/AD6 FM_SD I FM SD input Station detected : Hi
Not detected : Lo
63 P47/AD7 NC O Open
64 P50/A8 AFC O Noise detection time constant switching During reception : Hi
During search : Lo
65 P51/A9 Å\O
66 P52/A10 WIDE O K2I Wide output Active : Hi
67 P53/A11 NARROW I/O K2I Narrow output Active : Hi
68 P54/A12 AM+B O AM power supply Active : Hi
69 P55/A13 FM+B O FM power supply Active : Hi
70 P56/A14 NC O Open
71 P57A15 NC O Open
72 Vss - GND
73 P60/A16 TYPE0 I Destination type switch
74 P61/A17 TYPE1 I Destination type switch
75 P62/A18 TYPE2 I Destination type switch
76 P63/A19 ST_TYPE0 I IC2 Var. 3 destination type 0 Initial value : Lo
77 P64/RD ST_TYPE1 I IC2 Var. 3 destination type 1 Initial value : Lo
78 P65/WR NC O Open
79 P66/WAIT PRE MUTE R O Audio mute Active : Lo
80 P67/ASTB PRE MUTE L O Audio mute Active : Lo
81 Vdd - Positive power supply
82 P100/TI5/TO5 NC O Open
83 P101/TI6/TO6 SVR O Power IC reset Power ON : Lo
84 P102/TI7/TO7 NC O Open
85 P103/TI8/TO8 P_MUTE O Power IC muting Active : Lo
86 P30/TO0 ANT_CON O Antenna control Active : Hi
87 P31/TO1 IC2_SCK O IC2, IC5, EEPROM clock line
88 P32/TO2 DIMMER I Dimmer detection Active : Lo
89 P33/TI1 P_CON O Power control Active : Hi
90 P34/TI2 ACC_DET I ACC detection ACC OFF : Hi
91 P35/TI00 REMO I Remote control input
92 P36/TI01 P_ON O µ-com peripheral power supply Active : Hi
93 P37 BU_DET I Momentary power down detection Momentary power down : Hi
94 TEST Å\- Test GND
95 P90 IC2_SDA I/O IC2, IC5, EEPROM data line
96 P91 MUTE O Muting output Active : Hi
97 P92 SW5 O 5V power supply Active : Lo
98 P93 MS_CL O CD mechanism clock line
99 P94 MS_DA I/O CD mechanism data line
100 P95 Å\O
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

KDC-715S/8015/8016
5
TEST MODE
1. Entering the test mode
Reset the unit by pressing the FM key and the Preset 6
key at the same time.
When the test mode is entered, all indicators light up.
2. Releasing the test mode
Reset the unit by pressing the preset 6 key.
Note: The unit cannot be reset by simply turning ACC
off, turning power off, or turning power off for a
brief moment.
3. Voltage adjustment on the FM S-meter
(1) Enter the test mode.
(2) While pressing the Preset 1 key, keep on pressing
the Preset 6 key.
(3) When the adjustment is made, "ADJ OK" is dis-
played. When adjustment cannot be made, "ADJ
NG" is displayed.
4. Writing SD voltage for the AM
(1) Enter the test mode.
(2) While pressing the Preset 1 key, keep on pressing
the Preset 6 key, which results in writing SD.
5. Forced switching of K2I Auto/Manual
In tuner-mode, keeping on pressing TI key, and the Auto
and Manual modes can be switched. The initial condi-
tion is in manual modes, which is indicated by flashing
DUAL dots.
6. Forced narrow/wide switching of K2I
In turner-mode, when Preset 6 is pressed, forced nar-
row/wide mode switching is made. The initial condi-
tion is in wide mode and the NEWS dot flashes.
7. CD receiver test mode specification
By pressing the track-up key, the unit jumps to the fol-
lowing tracks:
No.9→No.15→No.10→No.11→No.12→No
13→ No.14→No. 9 (Goes back to the first position.)
When the track-down key is pressed, the unit jumps to
the previous track.
8. MD test mode specification
After loading MD, the unit plays No. 7. Then, the unit
jumps as follows each time it trackups.
No. 2→No. 13→No.23→No.30→
NO.34→No. 7 (Goes back to the first position.)
When the track-down key is pressed, the unit jumps to
the previous track.
9. Tape test mode
In the initial step, the blank skip is turned off.
10. Audio-related items
• The volume is -10dB (on display, it is 30).
• The loudness is off and CRSC is off regardless of func-
tions.
• Buss/treble and balance/fader are to be adjusted by
the up/down key to full-boost/fullcut and fullfront/
fullrear respectively.
• The high-pass filter is adjusted by the up-key to
throughput/100Hz/200Hz and, by the down-key, to
200Hz/100Hz/throughput.
• Other adjustments are the same as before.
11. Backup current measurement
When reset in ACC-off condition (backup is on), the mute
terminal goes off after 2 seconds instead of 15 seconds,
when the ACC is turned off in the test mode. (In this
case, the panel/CD/C/MD mechanisms are not activated.)
12. Registering security code after changing E2PROM at
the services (Only for type M. However, RDS models
are excluded)
(1) Put the unit into the test mode (Refer to 1. Above
for how to enter the test mode.)
(2) Press SRC key to put the unit into the tuner mode.
(3) Press Audio key for one second and put the unit into
the menu mode.
(4) Press FM/AM key and then select "SECURITY."
(5) Press track up/down key for full 2 seconds.
(6) Press Preset 1, Preset 2, Preset 3, and Preset 4 and
then input codes.
Example: Inputting "3510."
• Press 1 key 4 times.
• Press 2 key 6 times.
• Press 3 key 2 times.
• Press 4 key once.
(7) Press DISP key for 3 seconds and confirm that
"APPRODVED" is displayed.
(8) Release the test mode. (Refer to "2. Releasing the
test mode" above.)
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

KDC-715S/8015/8016
TEST MODE
13. Simplified method for clearing the security code
(Only for type K)
(1) When code is requested, continue pressing VOL UP
key for three seconds while pressing the DISP key.
(--- disappear.)
(2) Input "KCAR," using the remote controller (the same
as the 98 Model)
• Press Tenkey 5 twice and then press track-up key.
(Inputting "K")
• Press Tenkey 2 three times and then press track-
up key. (Inputting "C")
• Press Tenkey 2 once and then press track-up key.
(Inputting "A")
• Press Tenkey 7 twice and then press track-up key.
(Inputting "R")
(3) Then, the security is released and the unit goes into
the Tuner Mode.
14. Writing MASK KEY on line
(E2PROM in initial condition)
(1) While pressing the FM key and Preset 6 key, press
reset key to enter the test mode.
(2) Press AUDIO key for full one second to put the unit
into the menu mode.
(3) Select the "MASK KEY," using the FM key or AM key.
(4) Press on the track up/down key to display "TRANS-
MIT 1."
(5) Point the MASK KEY to the light receptor and press
it for 0.5 second or longer.
(6) When "TRANSMIT 2" is displayed, press MASK KEY
for 0.5 second or longer. When this is conducted,
the counter codes for the first time and the second
time will not be compared.
(7) When "APPROVED" is displayed, writing is com-
pleted. time the demonstration mode is set and the
test mode is released.
Note: After an elapse of 30-minute period, during
which no code is written, an error is effected
and the device will power off.
15. Releasing MASK KEY requests (When reset or backup
is off when MASK KEY is approved)
(1) When power is turned on, "TRANSMIT 1" is dis-
played and the unit goes into MASK KEY request
mode.
(2) Point the MASK KEY to the light receptor and press
it for more than 3 seconds (until the level display
indicates full)
(3) When "TRANSMIT 2" is displayed, press the MASK
KEY again for more than three seconds. At this point,
when "TRANSMIT 1" is displayed, repeat the pro-
cess in (2) above for the second time.
(4) When "APPROVED" is displayed, MASK KEY is ap-
proved and the unit turns power on.
16. Initializing MASK KEY (returning to the default condi-
tion from MASK KEY approved state)
(1) While pressing the FM key and Preset 6 key at the
same time, press RESET to enter the test mode.
(2) "TRANSMIT 1" is displayed and the unit goes into
MASK KEY request mode. The display at this point
will be "**" instead of "[ ]".
(3) Use MASK KEY release remote controller for more
than three seconds.
(4) When "TRANSMIT 2" is displayed, press the MASK
KEY for more than three seconds for the second
time.
(5) When "APPROVED" is displayed, the MASK KEY is
released and the demonstration mode is set. Then,
the test mode is released, returning the unit into de-
fault condition.
17. Clearing from the MASK KEY
(1) While pressing FM key and Preset 6 key at the same
time, press RESET to enter the test mode.
(2) Press the AUDIO key for full one second to put the
unit into the menu mode.
(3) Select MASK KEY, using track up/down key.
(4) Press on the FM key or AM key for full two seconds
and the unit will display "TRANSMIT 1."
(5) Point the MASK KEY release controller to the light
receptor and press it for 3 seconds or longer. (Until
the level display indicates full.)
(6) When "TRANSMIT 2" is displayed, press MASK KEY
for 3 seconds or longer for the second time. If
"TRANSMIT 1" is displayed, start again from (5)
above.
(7) When "APPROVED" is displayed, E2PROM is cleared.
The unit goes back to the condition described in Line
14: Writing MASK KEY on line (E2PROM in initial
condition)
18. Other
• Automatic panel closing does not occur in case a
TAPE, CD, or MD is inserted.
•
Panel is opened/closed when ATT key is turned On/Off.
( A remote controller is used when turning ATT on.)
• The DNPP/SBF key of the remote controller (RC-510)
is used for tuning the menu mode On/Off.
• The OPEN/CLOSE key of the remote controller (RC-
510) is used for tuning the audio mode On/Off.
• The feed on the menu will be feeds only for neces-
sary features.
• "CODE OFF" and other displays will not be issued
when the power is turned on.
• The dimmer of the FL model and contrast on the LCD
model can be adjusted only for 0/5/10 by the UP/
DOWN key.
6
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

ABCDE
1
2
3
4
5
6
7
PC BOARD (COMPONENT SIDE VIEW)
R219
R23
C85
C41
CP1
R117
R101
X1
C63
R121
R103 C77
R45
R125
C71
R104
C78
R122
R118 R126
C67
R102
R107
R108
C79
C80
R32
C68
C34
C72
C24
R36 C26
R34
R22
R77
R37 C28
R38 C25
R46
R73
R74
C21
R75
R80
CP2
CP3
R50
OGI
R54
C22
C43
C23
R72
R71
R31
C44
R81
R79
R83
C45
R82
L2
R47
C32
C31
R78
R76
R44
R18
R6
R3
R13
C17
R15
C15
C14
R16
R12
R10
R14
C7
C6
R11
C5
R1
C35
R2
R218
W8
1
FE
TE
IOP+
GND
ARF
Vref
F
E
RF
TE
TR
D.GND
TVD
Vc
F
MOTOR
Rch
A
CB
TRK-
LD
PD VR
FCS+
TRK+
FCS-
A.+B
/MUTEL
/MUTER
SLED-
EJECT
LOAD
SLED+
A.GND
/MRST
/MSTOP
SPDL-
S.GND
S.+B
SW3
LDON
Lch
SPDL+
LO/EJ
A.5V
D.OUT SW1
/CLK
SW2
ECS
BU.5V
DATA
/RST
D
1
1
IOP-
Vcc
EB
EB EB
BE
BE
22
16
45
8
D4
IC5
Q8
CN2
IC6
Q3
Q4
D2
CN1
Q2
Q5
D3
C4
W4
L1
R35
R5
BE
C29
C46
R52 R49
C33
C51
R9
R217
C20
C19
R20
R8
C1
C8
C12
C10
C9
C11
C3
C2
C18
R17
C16
C13
R216
R19
R202
C55
R21
/RFDET
OFT
BDO
TRCRS
VDET
SMCK
ST-O
FCLK
TOFS
TBAL
FBAL
DQSY
1
1
1
STLD
FLAG
CLVS
IPFLAG
14 15
28
18 19
36
25 26 50 51
75
76100
IC1
IC4
D1
S3
S2
Q1
IC2
S1
X32-47XX-XX (J74-0992-12)
DC 12456
address 5B 5C 2D 3D 4D
Q 123458
address 5A 5D 3D 4C 5D 5C
Refer to the schematic diagram for the values of resistors and capacitors.
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

FGHIJ
1
2
3
4
5
6
7
(FOIL SIDE VIEW)
/MUTEL
BE
R107
R117
BU.5V R219
E
C6 R13
R2
E
LDON
TE
IOP-
IOP+
ARF
GND
RFTR
FTE
R14
C7
A
R18 R16
C15
C14
C23
C17
R23
R15 R1
R22
DCB
1
Vref
C85
C24
R54
C26
R38
R32
R218
R36
R37
R34
C35
FE
B
W8
C28
C25
C22 X1
R46
R76
R73 R79
R71
R82
SLED-
22
LD
R12
C5
R11
R10
FCS+
16
VR PD
FCS-
Vcc
Vc
F
R6
R3
CP3
TRK-
TRK+
A.+B
S.+B
SW3
Rch
S.GND
1
LOAD
SLED+
EJECT
ECS
/MRST
/MSTOP
R47
C32 B
CP1
E
CP2
C31
C21
L2
D.OUT
SPDL+
A.GND
Lch
SPDL-
TVD
R74
R75
R44
R45
C34
R72 R83
C45C43
R80
R81
C44
BE
BE
R77
R126
R108
C78
C77
R102
DATA
R101
SW1 /CLK
SW2
R31
D.GND
/RST
C67
R103
R121
C71
5
R104
C68
C72
4
R118
R122
C79
R125
8
C80
1
LO/EJ
R50
OG I
/MUTER
A.5V
C63
MOTOR
R78
C41
Q3
CN1
D4
CN2
Q8
Q4
Q2
D2
Q5
IC6
D3
IC5
C51
FBAL
VDET OFT
/RFDET
BDO
C9
C11
C10 C8
C12
18
R202 TRCRS
C2
C13
C16
R17
19
R19
C20
R20
C19
IPFLAG
C29
25 R35
TOFS
26
TBAL
C33
C18
R21
100 1
51
FLAG
STLD
FCLK
50
SMCK
ST-O
7576
DQSY
W4
R5
BE
L1
R9
1
R8
C4
36
C1
R216
C3
R217
C55
C46
CLVS
R52 R49
14
1
15
28
IC1
IC2
Q1
D1
S3
(J74-0992-12)
X32-47XX-XX
S2
S1
IC4
IC 12456
address 5I 5H 2G 3G 4G
Q 123458
address 5J 5G 3G 4H 5G 5H
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

KLMNOPQRST
1
2
3
4
5
6
7
PC BOARD (COMPONENT SIDE VIEW)
Refer to the schematic diagram for the values of resistors and capacitors.
R35
R147
R106
R2
R37
C28
R39
R40
R38
R187
C116
R107
C166
C142
R162
C153
R155
R33
C23
R31
R30
R161 C151
W16
R156
C62
C144
C145
C115
C149
R167
R157
R168
R158
R164
R176
R175
R163
W13/C83
R169
R170
W12/C84
W15/C87
R177
R178
W14/C88
R221
C133
R225
C134
C137
C136 R223
R222
C138
R224
C162
C120
C118
C121
C59
C7
R8
R7
R9
R140
R34
R197
R184
R182
R183
R181
R122
R123
R131
R1
C4
R125
R126
C2
C146
R215
W18
C73
C74
C75
C76
C77
R135
R246
TH1
W3
R237
W2
R16
R139
R188
R234
R236
R130
R173
W4
W1
L5
R186
W17/C150
C54
R195
R194
R42
R43
R44
R45
R46
R47
R48
R193
R189
R24
R25
R82
R243
R23
R132
C30
C36
C35
R51
R50
R21
R61
R63 R62
R60
R64
R73
R72
R102
R74
C38
R166
C106
R93
R100
L11 R103
C32
R104
R18
R244
C13
R69
R68
C37
R89 R3
C31
R57
R56
C110
C148
R228
C140
C141
R229
R86
R77
C34
R78
R84
W20
R97
R203
L2
R205
C39
C63
C50
C56
C159
R207
R208
R206
R210
R209
R17
C157
C25
C26
C55
R144
R143
W26
R230
L10
C78
C79
C80
W5
R41
C160
R11
C68
R232
R145
C122
W27
C128 C127
W21
R65
C105
R105
R248
C123
C124 C126
C125
R22
EB
EB
BE
BE
E
B
BE
EB
EB
EB
BE
EB
BE
EB
EB
EB
EB
EB
EB
BE
EBEB EB
EB
EB
EB
BE
BE
W6
12
34
14 8
7
1
15
610
Q19
Q20
Q45
Q25
Q26 D13 Q24
Q22
Q18
D33
Q5
D32
Q2
Q6
Q10
Q38
IC10
Q32
D29
D57 D58
Q49
Q51
D34
D28
IC15
Q14
D55
Q30
Q3
D54 D53
D60
D59
Q12
D21
D41
D39
Q42
Q43 Q44
Q33
D37
D35
D42
D40
D38
D36
D43
Q55
D56
D16
IC13
Q41
Q52
D47
IC6
Q16
Q15
Q17
IC1
IC2
IC3
Q35
Q34
Q36 Q37
Q31
Q11
IC8
D51
IC16 D23
D24
IC7
IC12
IC11
D31
IC5
Q29
D22
Q50
Q48
IC14
Q28
D6
Q9
Q8
D27
D48
Q39Q40
IC9
Q53
Q54
D18
D50
X25-84XX-XX (J74-1000-12)
D8
D20
CN8
D12
Q23
Q1Q4
A1
D2
CN4
CN3
CN6
J1
D19
D1
IC4
WH1
CN7
D5
D3
Q56
Q7
D4
CN5
Q13 D7
CN1
CN2
Q21
D11
CP7
R76
R115
C20
C22
R28 R29
R27
R242
X2
W28/C12
R179
R137
C58
C67
L7
CP2
L6
C164
L4
L9
W10
R124
W11
W9 W8
R26
R220
R218
C139
R226
R217
R219
R90
C132
R231
R58
R113
R199
R116
R6
R192
C17
R108
C16
R138 R247
CP5
CP4
R129
R127
R128
C69
R15
C70
C71
R211
R212
C72
CP3
R200
R185
C57
R216
R235
R67
R118
X1
R52
R59
R53
R5
R71
R151
L1
R121
R70
R79
R80
CP6
R99
R110
R191
R190
R196
R66
R20
C165
C19
R101
R120
CP9
R180
R172
R171
R96
C131
R13
R227
C135
R149
R92
R14
R241
R83
R142
R94
R114
R141
W19/
R95
C51
R152
R32
R19 R204
R198
R112
VR1
R233
R159
R160
R201 R153
R202
R154
R148
R174
R119
R136
R133
R134
R4
R12
R165
R245
R111 L3
C163
12.0M
4.332M
FMSD
IFMODE
SMTR
32.768k
NOISE
TEST
RESET
C52
C53C43
C46
C42
FRONT
REAR
(3PRE)
(2P)N-F/REAR
1
1
1
11
44
1
1
1
1
C14
C91
C18
C6
C92 C1
C10
C95
C27
C29
R54
C21
C24
C130
X3
C3
C119C117
C8
C100
C102
L8
C161
C111
C113
C112
C60
C45
C44
C5
C64
C61
C90
C33
C66
C147
C15
C89
C97
C108
PH1
C107
C49
C48
C96 C98
C65
C99
C103
C81
C104
C85
C86
C82
C101
BE
EB
BE BE
E
B
B
E
EB
B
E
BE
EB EB
EBEBEBEBEBEB
BEBE
I
G
O
19
9
81
16
4
5
8
4
5
8
5
4
8
1
2
25
24
21
34
33
1123 22 12
1
14
2815
231
4
58
6118
14
85
25
26 50 51
75
76100
4
5
8
135
42
24
1
R117
22
21 1
21
212
13
21
8
169
85
4
E
BE
BE
BEBE
BEB
EB
910
IC Q address
15M
24O
33K
42O
64L
73M
83M
10 5N
13 5P
14 4N
15 4M
13K
23K
34M
43K
53M
63M
75P
85L
95L
10 5L
12 4M
13 4L
14 4L
15 4L
16 4L
17 4L
18 4L
19 4L
20 4L
21 3L
22 3N
23 3N
24 2N
25 2N
26 2N
28 3M
29 3M
30 5N
31 4N
33 3N
34 3N
35 3N
36 3N
37 3N
38 2O
41 6N
48 3P
49 3P
50 3P
51 3P
52 3L
53 3K
C15
R28
R26
C19
R9
OPEN
R6
R8
R5
R2
R1
R4
R3
R10 R24 R23
R29
R27
R15
R12
R11
R14R13
C11
C10
C9
C14
C13
C12
C8
C3
C2
C1
C6
C5
C4
R31
C16
R19
R20
R17
R18 R21
R25
R22
R16
C7
CP1
C17
R30
1
1
ILL+B
KI5
KS3
KS2
KS1
KI4
KS4
KI3
KS5
KI2
KI1
ILL G
RESET
LOCK SW
DIMMER
DGND
VDD
REMO
L DATAL
L DATAS
L CLK
L CE
EB
EB
EB
EB
EB
EB
EB EB
25
5175
76
100 26
50
75
76
100 25 26
50
51
1
214
15
IC1
CN1
Q3
Q8
Q2
Q1
Q5
Q4
Q7
Q6
D1 IC2
S23
S22
S2
S3
S4
S5
S6 S7
S8
S9 S10 S11
S12
S13
S21
S15
S16
S17
S14
S18 S19
S20
RESET
IC3
D6
D5
S1
D3
D2
D4
X13-972X-XX (J74-0984-12)
ED1
43
1
2
18 9 1819 64
65119
120
139
EJECT
SRC
FM
AM
CLKAUD
DISCAUTO653421ATT
IC Q address
15S
37S
16S
26S
33S
43S
56S
67S
77S
85S
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

UVWXYZAA AB AC AD
1
2
3
4
5
6
7
1211
(FOIL SIDE VIEW)
R161
R106
R173
R140
R131
R63
R61
R65
R68
C37 R46
R144
R41
R43
R44
R42
R45
BE
C166
R31
R33
C23
R143
R197
C34
R82
R102
R248
R84 C35
L11
C36
R93
W18
R107
R103
R104
R100
W20
R105
W21
C38
C157
R38
W26
R17
R246
R48
R47
R30
BE
BE
R22
BR25
R24
E
EB
EB
C160
R18
R23
L2
R21
R2
C7
R8
E
R9
R7
EB
C4
R1
B
R34
R37
W27
R155
EBEBB
R3
E
C105
R210
R209
R69
R74
R89
12
34
R78
R77
C13
BE
R64
R243
R73
R62
R60
R244
R205
R206
R207
R208
C106
R203
R177
R178
W15/C87
W14/C88
R170
W13/C83
R169
W12/C84
R50
C30
R51
R164
R168
R167
R157
R158
R156
R162
R175
R163
R176
R166
EB
C126 C124
C123 C127
C110
C128
C125
C26
R86
C25
R16
R56
R57
C31
R35
EB
C2
C162
R135
R132
R130
E
C50
B
R139
814
EB
R126
R122 R97
610
C121 C120
BE
C118
R11
C142
BE
15
C116
C115
C122
C153
C151
R40
W6
R125
71
C32
R72
W5
EB
BE
R123
C39
W3
W2
W4
C78
C77
W1
C74
C75
C76
C73
EB
C68
C79
C80
C62
C63 C59
L10
R39
C54
R229
BE
C133
R221
E
C141
R230
R228
C140
B
C138
R224
R222
C136
R225
C134
C148
R223
C137
C159
R193
R195
R194
C56
R236
R234
C55
R147
BE
BE
R187
C28
EEB
TH1
B
EB
R182
R181
R189
R183 R184
R186
R188
L5
C144
R145
R232
C145
C146
W16
R215
C149
R237
W17/C150
Q10
D16
D60
D21
Q55
Q14
Q19
Q18
Q20
Q2
Q52
IC15
Q5
Q12
Q3
Q6
Q22
D43
D32
Q26
Q32
D59
D56
Q41
D53 D58 D57
D55
D54
IC10
Q43
IC13
Q44
Q30
D47
Q45
Q33
Q42
D29 D28
Q49
Q51
D41
D13
Q25
D37
D39
Q24
Q38 D35
D34
D36
D38
D42
D40
D33
Q31
CN3
CN5
D5
D18
Q9
Q8
D8
IC1
X25-84XX-XX (J74-1000-12)
CN1
CN8
D11
Q21
D19
IC6
D50
Q56
Q54
D6
Q16
Q15
Q17
Q13
D7
Q4
IC3
Q53
D3
Q1
D12
Q11
IC9
Q39Q40
Q35
Q29
Q28
D2
Q36
IC7
Q34
IC8
Q37
Q23
D20
J1
D1
D31
CN7
D51
D22
CN6
D4
IC11
Q7
IC5
IC14
D48
IC16
D27
D24
D23
IC2
IC12
CN4
Q48 Q50
IC4
CN2
WH1
A1
C82
R165
R201
C104
R204
R202
E
75
51
12.0M
R27
R32
C20 C17
RESET
R79
C19
C163
C164
PH1
R13
C161
8
BE
C16
R101
R83
R12
R14
BE
C21
R29 R28
222
R118
32.768k
21
R137
R242
R96
R138
R80
X2
R95
X1
R116
1
R99
CP6
R92
R117
W19/
R108
CP5
CP4
25
26
50
R15
E
R245
1
14
C18
61
BEEB
C24
85
B
BE
E
B
E
C22
BE
W28/C12
R19
C14
C5
I
G
O
BEB
E
R6
R5 BE
C3
C8
C6
R59
TEST
R20
C33
R241
C15
R76
REAR
(3PRE)
L1
EB
R4
R70
R67
C51
100 1
R71
76
R66
1
R53
4
8
5
EB
B
EB B
8
R52
N-F/REAR
R58
BE
(2P)
EB
B
FRONT
E
W10
W8
W9
1
4
51
8
4
EBEB
R154
W11 5
BE
E
C91 C92 C90 C89
R211 R171
R212 C108C107
1
R179
R172
R180
R26
8
9
9
R54
1
16
C1
SMTR
FMSD
R127
R120
L3
R90
R112
113
R119
R136
R134
122
R198 R247
CP3
CP9
CP2
R199
R110
R133
R111
R174
R196
R128
1
R200 C45
4
C10 4.332M 9
X3
16
R113
8
C165
1
IFMODE
C117
C44
C119
1
53
42
L9
C147
C131
R218
R220
R149
C69
C70
C72
C52
R121
C81
58
R142
1
CP7
R141
4
R124
R115
C43
C103
15
R129
8
C46
C42
5
C53
14
C71
C61
R151
C85
C86
R153
R160
C67
R159
B
R191
1
C64
28
C60
R152
R190
C95
C58
C49
C48
C65
C66
NOISE
33
34
44
1
R114
R227
C139
C135
1
1
R231
R226
R94
C130
8
R216
R219
C132 5
R148
23
22
C112
12
C111
11
C113
C96 C97
231
C98
R185
E
C57
R233
BE
L6
R235
B
R192
L7
C29
1
C101C27
214
C100
C99
C102
15
21
L4
R217
24
VR1
1
2
L8
1
IC Q address
15Y
24W
3 3AA
42W
6 4AA
73Y
83Y
10 5X
13 5V
14 4X
15 4Z
1 3AA
2 3AA
34Z
4 3AA
53Z
63Y
75V
85Z
9 5AA
10 6Z
12 4Z
13 4Z
14 4AA
15 4Z
16 4Z
17 4Z
18 4Z
19 4Z
20 4Z
21 3Z
22 3Y
23 3X
24 2X
25 2X
26 2Y
28 3Z
29 3Z
30 5X
31 4Y
33 3X
34 3Y
35 4Y
36 3Y
37 3Y
38 2W
41 6X
48 3V
49 3V
50 3V
51 3V
52 3AA
53 3AA
OPEN
100
76
BE R25
C19
R19
R31
KI1
ILL G
B
C15
BE
C16
E
E
C4
C1
C6
C2
C3
R2 B
C5
BE
R3
R1
R4
R18
RESET
R26
R28
C7
C14
KI2
R9
KS5
KI3
R5
1
LOCK SW
26 25
R10
75
KS4
KI4
R21
KS1
51
50
C11
C8 C9
C10
R11
R12
DIMMER
R30
C17
100
C12 VDD
1
R13R14
R27
BE
DGND
R15
76
75
KS2
26 25
REMO
R23
R8
R29
R24
R6
50 51
EBEB
15 1
2
14
L DATAS
L DATAL
CP1
R16
R20
L CLK
L CE
R22
ILL+B KS3
R17
C13
KI5
Q2
Q6
Q7
Q5
S23
Q1
IC1
S22
D1
Q8
IC2
Q4
Q3
CN1
S12
S19
IC3 S14
S15
S20 RESET
D4
D2
D3
S6S1
S3
S7S9
S10
ED1
S13 S11S2
D5
S18
S21
S17
S5
S16
S4
S8
X13-972X-XX (J74-0984-12)
D6
EJECT
4
3
2
139
1
1
ATT
1
119 120
891819
2
345
65 64
SRC
FM
AM
AUTO 6DISC
AUD
CLK
IC Q address
1 5AC
3 7AC
1 6AC
2 6AC
3 3AC
4 3AC
5 6AC
6 7AC
7 7AC
8 5AC
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

KDC-715S/8015/
8016
ABCDEFGHIJ
1
2
3
4
5
6
7
CAUTION : For continued safety, replace safety critical components only with manufacturer's recommended parts (refer to parts list).
Indicates safety critical components. To reduce the risk of electric shock, leakage-current or resistance measurements shall be
carried out (exposed parts are acceptably insulated from the supply circuit) before the appliance is returned to the customer.
•DC voltages are as measured with a high impedance voltmeter. Values may vary slightly due to variations between individual
instruments or/and units.
!
0V
0V
0V
0V
5.0V
0V
5.0V
2.5V
3.0V
2.5V
2.5V
2.5V
2.5V
2.5V
2.5V
1.4V
1.5V
2.5V 2.5V 2.5V 2.5V 2.5V
1.8V
0V
5.0V 0V 0V
5V
0V
0V
4.8V
0V
5.0V
5.0V
5.0V
0V 5.0V
5.0V 5.0V 5.0V 0V 5.0V
5.0V
0V
5.0V
0V
5V
5.0V 5.0V
0V
0V
8.0V
3.2V
3.8V
3.8V
3.2V
0V
8.0V
0V
5.0V
4.0V
4.0V
4.0V
4.0V
2.5V
5.0V
4.0V 4.0V 2.5V
2.0V
2.0V 2.0V 4.0V 4.0V 2.5V
2.5V 2.5V
3.4V 3.5V 3.0V 3.6V 3.5V 3.4V
0V or 5.0V
0.8Vpp 5.0V
5.0V
0.1V
2.4V 2.4V 2.4V
5Vpp
TE
FE
2.5V
2.5V
8.0V
1.2Vp-p 0.8Vp-p
B LINE
CN1
CN2
D3
D4 Q8
D1
Q1
S2
S1
IC6
(2/2)
(1/2)
IC6
Q3
Q4
D2
Q5
Q2
S3
DOWN & LIMIT
SWITCH
M
M
LOADING & SLED
MOTOR
SPINDLE
MOTOR
MAIN
UNIT
CN1
to
PICKUP
OPTICAL
IC1 : AN8806SB
IC2 : MN662773KB3
IC4 : BA5917AFP
IC5 : TA78L05F
IC6 : NJM4565MD
Q1 : 2SB1188
Q2,5,8 : DTC124EUA
Q3,4 : 2SA1362(Y)
D1,2,4 : DAN202U
D3 : DA204K
GND LINE
SIGNAL LINE
RF
AMP
CD SIGNAL
PROCESSOR
BTL
DRIVER
ACTIVE
APC
PON SW
MOTOR SW
D.5V SW
A.8V SW
GAIN
CONTROL SW
FILTER
DPU1
(T25-0215-05)
(X92- )
DM2
(X92- )
DM1
(X92- )
DET.SWITCH
SWITCH
S1 : LOAD DET.
S2 : 12cm DISC
bult in u-COM.
5V AVR
50 49 48 47 46 45 44 43 42 41 40 39 38 37 36 35 34 33 32 31 30 29 28 27 26
25
24
23
22
21
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
76
77
78 79 80
81
82
83
84
85 86
87
88 89 90
91
92
93
94
95 96
97
98 99
100
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
STOUT
TRCRS
FLAG
IPFLAG
FCLK
CLDCK
EFM or CK384
DVSS2
AVSS2
AVDD2
TOFS
FOD
TRD
KICK
ECS
ECM
PC
TVD
TRV
VCOF2
VCOF
PLLF2
PLLF
IREF
DSLF
DRF
ARF
VREF
RFENV
NC
NC
NC
TE
NC
NC
FE
TBAL
FBAL
AVDD3
AVSS3
NC
NC
LDON
VDET
RFDET
OFT
BDO
73/74SEL TES ICRST CLVS TEST ASEL PON SEARCH VER/HOR SW3 AMUTE L AMUTE R CD-R RST MECHASEL MSTOP NC DATA CLK HOT AVREF OUT R AVDD1 OUT L AVSS1
CSEL
TEST1
TEST2
IOSEL
NRST
BCLK
LRCK
SRDATA
SUBC
SBCK
DQSY
DEMPH
TX
PSEL
MSEL
SSEL
DVDD1
X1
X2
DVSS
XSUB1
XSUB2
DVDD2
NC
NC
SMCK
STLD
PCK or DSLB
14 13 12 11 10 9 8 7 6 5 4 3 2 1
OP.OUT
GND
SLED+
SLED-
NC
SL.IN
GND
MUTE
NC NC
TR.IN
NC
TRK+
TRK-
15 16
17
18 19 20
21
22
23
24
25 26
27
28
OP.IN- OP.IN+ SPDL+ SPDL- NC SP.IN VCC VCC VREF FC.IN NC FCS- FCS+ GND
18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1
GND
NRFDET
OFTR
C.SBRT
BDO
C.SBDO
C.EA
C.ENV
ARF
C.AGC
RFIN
RFOUT
RF-
VCC
LDP
LDON
LD
PD
19 20
21
22
23
24
25 26
27
28 29 30
31
32
33
34
35 36
ENV VREF LD OFF VDET TEBPF CROSS TEOUT TE- FEOUT FE- FBAL TBAL PDER PDFR PDF PDE PDAC PDBD
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
D
B
C
A
GND
LD
PD
VR
VC
VCC
F
E
FCS+
TRK+
TRK-
FCS-
22
21
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
D.OUT
SW2
SW1
CLK
DATA
MECHA
NC
BU+5V
D.GND
MUTE R
MUTE L
MRST
MSTOP
A.+8V
Lch
A.GND
Rch
LO/EJ
MOTOR
S.7.5V
S.GND
SW3
1K
R31
16.93MHz
X1
CLVS
W4
W8
R52 100K
C46 0.047
C85
0.1
100K
R54
0.1
C35 0.1 C55
220K
R38
0.012
C25 0.1 C29
R37
470 C28
1
1
C26
150
R36
C24 0.022
R34 68K
R35 100K
R32
100K
R218 47K
4.7K
R219
C13 0.027
R220 10K
R202 1K
R15
820K
R217 1.5M R216 1.5M
C20 0.1
R21 220K R20 100K
C19 0.1
27K
R19
470P
C18
36K
C16
100P
R17
0.047
C15
4700P
C14
22K
R16
3.9K
R18
R1 33K
R2 33K
R22 33K
R23 33K
R5 91
82K
R6 33
34
34
33
R8
4.7
R9
10
IOP1 IOP2
10u6.3
+
C4
10uH
L1
6.8K
R11 33P C5 4.3K R12
3P
C6
6.8K
R10
36K
R13
0.1
C7
R14
820K
C8 1
RF
ARF
C9 100P
C10 4700P C11 6800P C12 2200P
82K
R3
FCS+
TRK-
TRK+
FCS-
47K
R73
0.012
C45
10K R82
1K
R83
0.1
C44
R71
10K
1K
R72
0.012
C43
24K
R78
56K
R77
2K
R80
33K
R81
2.4K
R79
R76 6.2K
33K
R75
10K
R74
27
26
1
2
CP1 100
4.7K
R49
76
85
4
12
3
C79
C80
330
R108
330
R107 20K
R121 R117
20K
68P
C77
20K
R125
R118
20K
R122
20K
68P
C78
R126
20K
R45 10K
C34 3.3 R47
10K
OUT
GND
IN
3.3
C51
10u16
C63
+
2200P
CP3 100
CP2 100
R102 3.3K R101 3.3K
R104 5.6K
C67 1
R103 5.6K
C68 1
26
1
2
L2
0.01
C32
0.01
C31
4
47
15
47
32
33
29
30
34
35 36
93
94
86
89
91
87
11
12
11
12
17
18
86
87
89
94
93
91
10
2
1
5
4
3
11
12
15
19
20
29
30
32
33
34
35 36
25
3
1
20
19
12
10
11
27
TVDECS
18
17
LOAD
SLED+
SLED-
EJECT
SPDL-
SPDL+
R44
5.1K
1K
R46
1K
R50
10u16
C21
+
0.1
C22
0.1
C33
1000P
C23
10u16
+
C3
IC5
Q3
FE
1
C2
C17
4700P
TE
1
C1
2.2
C41
C72
470P
2200P
470P
C71
FIN FIN
22K
22K
22K
22K
22K
22K
IC2
IC4
IC1
IC5
X32-4720-00 : (DXM-1340)
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

KLMNOPQRST
1
2
3
4
5
6
7
CAUTION : For continued safety, replace safety critical components only with manufacturer's recommended parts (refer to parts list).
Indicates safety critical components. To reduce the risk of electric shock, leakage-current or resistance measurements shall be
carried out (exposed parts are acceptably insulated from the supply circuit) before the appliance is returned to the customer.
•DC voltages are as measured with a high impedance voltmeter. Values may vary slightly due to variations between individual
instruments or/and units.
!
0V
7.4V
4.5V
7.4V
14.4V
7.4V
0V
7.4V
7.3V
7.2V 0V
7.2V 7.3V 0V
7.3V
14.4V
7.3V
7.3V
3.2V
0V
0V
0V
-9.4V
0V
9.8V 9.8V
0V
0V
-9.4V 0V
0V
0V
0V 5.0V 0V
0V
5.0V
0V
0V
0V
5.0V
0V
5V
0V
0V
4.9V
13.6V
1.26V
0V
0V
10.4V
0V
10.5V
0V
-10.0V
-9.8V
5.8V
10.4V
4.0V
4.0V
4.0V
4.0V
4.8V
5V
0V
5V
0V 0V
8.1V
4.0V
4.0V
4.0V
4.0V
4.0V
0V 0V
R54
R39
22K
+
R11
C10 100u10
INOUT
Q3
R4 2.2K
C2 0.01
R3 22K
C4 0.01
10u10
220u16
C6 100u6.3
+
C3
+
C5
22K
R1 100 R2
+
Q4,52,53 IC3
GND
4.3K
R7
220u10
C8
+
Q7
Q5,6
1.5K
100K
R20
Q12
C1 3300u16
+
Q1,2
220
R5
C13
0.022
47K
15K
R6
R8
1
C7
47K
R9
97
34
C14
+
1u50
88
54
C16 2.2
R22 100K
C15 4.7u16
R21 1K
+
C17 2.2
C19 2.2
VOUTCAP-
BOOST V+
75
100u16
R23
C18
+
C21 22u16
LV
3GND 6
+
OSC
2CAP+ 7
L2
22uH
18
560 1W
1K
R38
1/2W
C22 0.022
Q15-20
C20 2.2
4.7u16
C24
+
Q21,22
C160 2.2
C23 0.01
R33 91K
R28 56K
R27
7.5K
R24 2.7K
47
R30 47
R29 91K
R32 91K
R31
10K
R25
R37 4.7K
3.3u25
C27
R34 4.7K
22K
R35
R36
4
3
R12
1K
ILLMG
ILL+B
L DATAS
L DADAL
L CLK
RST
L CE
Q8-10
750
R132
R133
R134
R140 R135 R119
13 12 10 911 87
470
0.1
470
4.7K
470 470
DIM CON
LOCK SW
REMO
NC
DGND
VDD
R174
R136 R199
46 53 21
470
100K
1K
90
1M
42
53
41
40
R197
55
54
R131
4.7K
47K
R130
93
11
R52
5.6K
R58
18K
22K
R53
Q23-26
1/2W
89
86
C51
0.01
1
2
3
4
100K
R59
100K
0.068
C29
+
0.1u50
R40 1K
R51
12K
1000P
C30
+
C28
R50
12K
R57
0.01
C32
14 13 12
R56
C31
100K
0.01
3.3K
1/2W
79
80
36
5 6
7
8
71
A0VCC
2
A2
A1TEST
SCL
10 9 8
96
95
87
54
SDA GND
N-FR
C90
1u50
C100
+
R186 R185
180K
Q13,14
83
92
1u50
C102
R192
+
33K
RL
FL
44
85
2
9
Q34-37
24K
R188
R191 22K
R190 100
FR
RR
430
TH1
470
4.7K
R155 R156
4.7K
C81
+360
R153
13
RLA
FLA
RLB
FLB
C97
0.22u50
C95
0.22u50
+
4.7K
R181
4.7K
R183
100u10
C101
R189 1K
8
TAB PGND OUT2- ST-BY OUT2+ VCC OUT1-
1
2
3 5 6
7 4
IN1 IN2 OUT1+ SVR PGND
9
10
11
12
R170
22K
W13
R169
C98
0.22u50 0.22u50
750
R187
C96
RRA
+
4.7K
R182
4.7K
R184
1u50
C99
FRA
RRB
FRB
W9
R158R157
R167 10K R168 10K
4VSS 5
2
3
22K
6
OUT4+ IN4 IN3 ACGND OUT3+ PGND OUT3- VCC SGND
14
15 16
17
18 19 20
21
CD MUTE OUT4- PGND
22
23
24
25
81 VDD 7
82
R171
R172
10u16
+
C89
B.U. GND
RRA
FRA
RRB
FRB
RLB
FLA
FLB
RLA
580 R26
10K
R16
1K
Q11
10
REAR Lch-
FRONT Lch+
REAR Lch+
FRONT Lch-
87
9
FRONT Rch-
REAR Rch-
FRONT Rch+
REAR Rch+
ACC
PHONE
P-CON
EXT CONT
P-ANT
GND
ILLUM
3
4
2
32654
1311 12 14 15
1F1 10A
16
2
N-FL
N-FL
1
1000P
C26
33
ACIN RR
ACIN LR
ACOUT L
ACOUT R
ACIN RF
C91
C55 0.082
11
8
10 +
R161
4.7K
R162
4.7K
C86
C82
+ +
C85
360
R154
360
R160
360
R159
0.027
C148
10
C54
0.018
C58
Q30,31
87
95
4.7K
R145
120P
12
87
C56
0.47
C57
0.1
R147
4.7K
4.7uH
95
L10
1
3
2
5
7
8
6
9
10
11
4
R177
W15
W12
W14
22K
R178
R176 10K
W8 W10
R163R164
R175 10K W11
5
VSS
463
2
22K
82 82
R180
18
7
VDD
82
R179
10u16
+
+
C92
+
4
5
2
3
1
0.01
C59 C60
GND
QUAL MP IN LEVEL MP OUT SPANA L SPANA R SMUTE
18
14
12
13 15 16
17
MPX NC NC
19 20
21
22
NC
NC
NC
AM 24
23
SDA
SCL
25
NC
23
24
29
CDL OUT
NC
NC
NC
CDL
NC 27
VDD 26
OUT RR 28
CDR OUT
CDGND
CDR 31
30
OUT RF
OUT LR
32
NC
OUT LF
+
Rch Lch
Rch Lch Lch Rch
A GND
GND GND
C25
C125
1000P
0.047
FR
FL
N-FR
FR
FL
3 5
1
C126
C124
1000P
0.047
1000P
12345 6
+ + +
0.47u50
C113
0.47u50
C112
47u6.3
C111 4.7
10
R195 R193
10
R194
213
35
34
C61 2.2u50
C63 0.012
CREF
VREF
TAPE R
TAPE L
ACIN LF
44 43 42 41 40 39
NC
34 37 36 35 38
+
C49 10u16 C48 10u16 C53 10u16 C52 10u16
+ + + +
44
43
+
+
4
2
NO
NO
NO NO NO
YES
YES
NO
NO
YES NO
NO
NO
YES
IC5 IC7,8
70-14
70-22
70-15
70-13 YES
YES
NO
NO
NO
YES
D32
NO
YES
NO
NO NOYES NOYES
YES
YES
NO NOYES
NO
NO YES
YES
NO
NO
YES
R61R60 R62
NO
R63,167-170,
175-178
NO
NO
YES
62,64,69-80
C48,49,52,53,
10u16
10u16
22u16
22u16
C81,82,
85,86
MODEL
NAME UNIT No.
KDC-8015
KDC-X715
KDC-8016
KDC-715S
MODEL
NAME
NAME
MODEL
YESYES
NO
YESYES
YES NONO
W1- W8-
156
NO
NO
NO
YES
Q11
YES
YES
YES
NO
13
2
R86
Q38
R26,86,
90,112,113
R82,
110,111
KDC-715S
KDC-8016
KDC-X715
KDC-8015
KDC-715S
KDC-8016
KDC-X715
KDC-8015
10u16 10u16
100u10
C66 2.2u50
C65 2.2u50
C50
C123
PNK/BLK BLU
BU 116
YEL
EXT.
CONT
ILLMI ORG/WHT 3
2
14
15
413
BLK GND
ANT CONT
P. CON
BLU/WHT
RED ACC
REAR L
REAR R 611
512
VIOL
GRN/BLK
VIOL/BLK 710
89
GRN FRONT L
GRY FRONT R
WHT/BLK
GRY/BLK
WHT
BU 116 GND
611
314
CONT
ILLMI ORG/WHT 215
YEL
REAR R
EXT.
TEL MUTE PNK/BLK 413
BRN
512
VIOL
P. CON/ANT CON
RED
BLK
ACC
BLU/WHT
GRY FRONT R
REAR L GRN/BLK
VIOL/BLK 710
89
GRN FRONT L
WHT/BLK
GRY/BLK
WHT
R157,158,
YES
YES
YES
163,164
NO
MUT
MUT
4
2
22K22K
47K
47K
22K
22K
22K
22K
22K
22K
47K
47K
10K
10K
22K
22K
22K
22K
10K
10K
22K
22K
22K 22K
47K
10K
47K
2.2K
22K
22K
IC3
IC6
IC10
IC14
IC4
IC7 IC8 IC2
(X25-847X-XX)
(E30-4779-05)
KDC-8015/715S/X715
DC CORD
DC CORD
KDC-8016
(E30-4781-05)
CURRENT
D3
AMPLIFICATION
8V
Q52
SW5V
A8V
A.V.R
Q6
SERVO +B
SW14V
D4
Q4
D2
D1
B.U.5V Q2
Q1 Q3
DETECT SW
SMALL LAMP
Q53
Q7
Q5
Q12
C
D7
4V PRE DC/DC
CONVERTER
Q14
Q13
VOLTAGE
LEGULATOR
Q16 Q22 P-ANT SW
Q18
Q15 Q17
D8
Q20
Q19
D43
Q21
D11
D12 Q23
CN6
D5
ILL +B D57D55 D56 D58 D60D59 D53D54
Q9 Q8
Q10
PAN 5V
Q41
SW
DETECT
ACC
DETECT
SW
Q26
P-CON SW B.U.
Q28
CIRCUIT
Q29
MUTE
LOGIC
Q24
D13
Q25
D19
D20
MUTE
AUDIO
ROM
E
Q38
CONVERTER A.V.R
4V PRE DC/DC
COMPULSION
DISCHARGE
SVR VOLTAGE
PRE MUTE
D34D27
D35
D37
D39
D41
POWER AMP
D36 D38 D40
D42
Q35 Q34
4V PRE
OP AMP
Q11
EXT.AMP
CON.SW
J1
CN2
D47
Q30 Q31 D48
MUTE
Q33
E-VOL
Q37Q36
4V PRE
OP AMP E-VOL
D28D29
CN1
CN4
CG
(X25-847X-XX)
D32
D23
D24
RCA
CORD
N-FADER FRONT
SP OUT/DC IN PRE OUT
CH-IN
P
2SB1565 DTA114EK DTA123JK
DTA124EK DTB123YK
DTC114EK DTC114TK
DTC114YK DTC124EK
DTC144EK 2SA1362
2SC2412K
2SD2114K
2SB1277
2SB1443 2SD1760 DTC124EUA KRC-104S
2SB1188
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

KDC-715S/8015/
8016
UVWXYZAA AB AC AD
0V
4.9V
4.9V
5V
0V
5V
0V
7.8V
0V
0V 0V
0V
0V
0V
5V
5V
0V
2.4V
2.4V
4.9V
0V
4.9V0V 0V 4.9V
4.0V
4.0V
4.0V
4.0V
4.0V
4.0V
4.0V
4.0V
0V
4.0V
0V
4.0V
0V
0V
4.0V
4.0V
4.0V
0V
8.1V
5V
0V
5V
0V
5V
0V
0V
5V
5.0V
5V
0V0V
5V
0V
5V
0V
5.0V
0V
5V
5.0V
0V-4.4V
0V or 5.0V
0V 0V
5V
0V
5V
0V
0V
5V
5.0V
5V
0V
0V
5V
0V
5V
5V
0V
0V
5V
0V
5V
0V
5V
0V
5V
2.6V/5.0V
0V or 5.0V
0V
0V
5V
5V
0V 5V 0V
5V
0V (FL) 5.0V(LCD)
5V
0V
0V
5V
0V
5V
4.9V
0V
0V
0V
5V
4.9V
0V
5V
0V
0V
5V
0V
0V
0V
5.0V
5V
0V
5V
0V
0V
5V
0V
4.9V
0V
5V
0V
4.9V
5V
0V
0V
5V
0V
5V
0V
0V
5V
5V
0V
4.0V
(LCD)
B LINE
B LINE
29
96
R74 22K
R139 2.2K
SW2
D OUT
22 21
R137 2.2K R138 2.2K
R89 100K
MOSW
MUTE L
MS CLK
MECH
MUTE R
SW1
MS DA
NC
BU 5V
D GND
M STOP
AUDIO +B
M RST
GND
Rch
Lch
LO/EJ
SERVO SERVO
SW3
4
R143 100K R144 100K
1220 19 18 17 15 14 13 16 11 10 97 65 8
44
43
1
321
2
3
4
1
C37
6
2.2K
R118
50
47u6.3
32
98
7
51
99
31
43
35
49
L1 4.7uH
+
0.01
C34
C33
48
3
1
2
R76 47 R78 47
R77 100K
R79 2.2K R80 2.2K
6 7
12.0MHz
32.768kHz
16 18
C36
24P
C35
X1
X2
27P
R82 100K R83 100K
9
100
CHCON CH MUTE REQH ILL ON CD SW2 CD SW1
1
2
3
4
5 6
7
8
SW597
99 99
100
R241
98 98
100
R242
MS DA
MS CLK
R95 4.7K 97
R96 4.7K MUTE
SC REQ(KEY REQ) AVDD XT1 VSS XT2 VDD RESET CH RST R CLK REQC
10
12
13
14
X2 X1
11
15 16
17
18 19 20
22
23
1K
R84
1K 21
R13
AVREF0 PHONE(E)
470
0.01
25
C163
24
R90
100K
R14
26
SRM SW1 R92 1K
R114 160K
27
NOISE(E) W20
C38 4700P
28
SMETER R94 22K
IF MODE W21
28
14
13
12
11
10
CR1
DGND
C62
0.01
24
23 AUX1 INRSDA
28 VCC 1
AUX1 INL
26 SCL
27
3
MUTE 2
AUX2
HP FR1
6
23
+
1u50
C64
AGND
25
CR2 4
CREF
24
CL1 5
0.27
7
22
C69 HP FL1
0.27
CL2
21 HP FL2
0.27
8
AUX2
0.27
C73
C74 19 HP FR2
20
C70 HP
9
18 HP RL1
0.27
C71
HP
0.27
C75
0.27
C76
16
C72
17 HP RR1
0.27 HP RL2 HP
OUT
HP RR2
15 HP
5.6K
R73
95
95
R244 1K
96
SDA IC2
93 94
R70 1K
R71 4.7K
92
2.2M
R68
92
93 BU DET
TEST
P ON
5.6K
R72
87
34
35 DIMMER88
90
R67 4.7K
R69 2.2K
90
91
89 89
ACC DET
REMO
P CON
R243 1K
R66 2.2K
87
88 SCK IC2
100K
R101
EX.AMP CON
31
30
MUTE R
33
32
AVSS
MUTE L
CP6 1K
31
32
AVREF1 35
M RST 34 R99 1K
36
35
SC DATA(L DATAL)
100K
L11
DATAH 37
DATAC R100 1K
39
CH CLK 38
47
R102 47 38
37
39
R116 1K
40
R103 R104
79
C78 0.1
C80 0.1
C79 0.1
C77 0.1 83
85 86
86
84
83
85 P MUTE
ANT CON
SVR
81
82
80
79
80
VDD
RPRE MUTE
LPRE MUTE
FL
10
FR
11
RL
RR
77
78
R142 100K
76
R141 100K
ST TYPE1
ST TYPE0
TYPE2
TYPE1
TYPE0
FM+B
AM+B
VSS
46
MC CLK(L CLK)
MC DATA(L DATAS)
43
34
41 R117 1K
42
M STOP
41
43
42
44
BEEP CP5 1K
45
PLL DATA
PLL CE R105 2.2K
44
46
45
PANEL 5V
P RST(LOCK SW)
MC REQ(L CE)
SRM SUB-
NARROW
WIDE
FM SD
SRM SW2
SRM DET
SRM SUB+
AFC
R DATA
QUAL
DIM CON
49LO/EJ
CD SW3 47
PLL CLK R107 2.2K
R106 2.2K
48 R108 2.2K 48
47
CP4 1K
MECH DET
50
MOSW 49 50
W4
W2
W3
W1
9
W5 8
W6
CP7 1K
R63 100K
R65 100K
72 75 74 73 71 70 69 68
R61 100K
R62 100K
69 68
R60 100K
CP8 1K CP2 1K
67 66 65 64 63 62 61 60 59 58
R111
100K 100K
R110
57 56 55 54 53 52
58
62
64
61
60
59
R113
2.2K
R112
2.2K 56
57
100K
R196
R248 100K
51
R247 1K
51
CP3 470
54
53
55
GND EXTRES
+
C117
C118
10u10
0.01
7
8FILOUT FSEL
ARI TM 10
9
SRM SUB- SRM DET
GND
SRM SW2 SRM SUB+
C116 0.22 C115 0.22
S-GND
P-GND
OSCO
C119
C122
270P
L3
4.7uH 5
6
3
10u10 4
+MPX OSCI
OSEL VCC 12
11
VREF C120
X3
13 10P
1
2
56
57
16
QUAL
RDDA
RDCK
T57 C121
15
14 10P
R200
2.2K
17
4
61
101
3
4
5
58
59 IN1
IN2 NC OUT2
2VCC NC
NC OUT1 8
7
6
9
5
2
60
31
100u10
C147
0.01
C146
P-ON 5V
C144 0.01
24 D GND
46
L4
4.7uH 47
45 PLL DATA
22 PLL CLK
23
20
PLL CE
21
FSD OUT28
12
10 R232 2.7K /IF MODE OUT
+
4.7uH
L5
18
HI UP ADJ
19 IF GND
COMMON +B
17
15 FM DET OUT
AM DET OUT
16
W16
W17
62
VCO GND
13 FM SD
14
12
10 REQUEST
11 K2IVTH
IF SELECT
8
9RDS OUT
1
4.7uH
Q50,51 L6
68Q48,49
1K R233
22K
R234 4.7uH
69 R235
22K
R236
1K
4
0.01
C151
AM LO/DX
FM LO/DX
7
5FM VCC
AM VCC
6
0.01
C153
L9
3AM ANT
2RF GND
FM ANT
L7
D33
2
1
L8
52mH
RROUT
RLOUT
REF
FROUT
FLOUT
OUTL
OUTR
4.332MHz
24315
24
315
3
L DATAL
REMO
LOCK SW
DIM CON
L CLK
L DATAS
ILL+B
ILLMG 13
11
12
L CE
RST 9
10
7
8
5
6
4
DGND
VDD
NC 2
1
5
3
2
4
6
7
8
9
10
11
12
13
14
15
1
S.GND
S.GND
UNIT
0-11
0-11
No.
KDC-8016
KDC-8015
MODEL NAME
KDC-X715 0-10
0-11KDC-715S
10
17 40
REMO
LOCK SW
DIM CON
L DATAL
L DATAS
L CLK
ILLMG
ILL+B
DGND
VDD
NC
RST
L CE
C162
0.01
W28
GND
+B
DET
4
1
2
R44 47
R46 2.2K
R45 47
R48 4.7K R47 4.7K
18
3
39
38
37
16
REQ C REQ H CH CON CH MUTE
2134
R42 2.2K
R43 47
R41 4.7K DATA C
DATA H CH RST
7
CLK
56 8
22K
22K
22K
22K
IC15
IC5
IC1
IC11
IC13
KDC-X715/8015/715S/8016 (1/2)
(x13-978X-XX)
A
CN5
D21
RST IC
PH1
NONFAD SW
HPF & LPF u-COM
CN7
GRDS
DECODER
Q50
AM+B
Q49
Q48
FM+B
Q51
WH1
IC1 :
IC2 : TDA7400
IC3 : M5237ML
IC4 : TDA7386
IC5 : TDA7401
IC6 :
IC7,8 :
IC10 : TC74HC02AF
IC11 : TDA7479D
IC13 : LB1930M
IC14 : BR24C01AF or
IC15 : S-80830ANNP
Q1,4 : 2CB1565F(E,F)
Q2,14,16,18,20,28,29,
34-37 : 2SD601A or
Q3,15,17,19,24,41 : 2SB709A or
Q5,8,25,30,31,53 : KRA103S or
Q6,9,33,49,51 : UN2212 or
Q7 : 2SD2396F40
Q10 : 2SD1760
Q11 : DTA123JK
Q12,52 : KRC104S or
Q13 : 2SB1443
Q21,23 : 2SB1277(Q,R)
Q22,26 : DTC114EK
Q38 : KRC107S or
Q48,50 : 2SB1188(Q,R)
D1 : RM10ZLF
D2,11,12 : AMOIZ
D3,8,19 : MA4056(N)-M
D4 : MA4082(N)-L
D5 : MA4110-L
D7 : MA4110(N)-M
D13,27,47,48 : KDS181 or
D16,18,60 : MA3062WA
D20 : MA4062(N)-M
D21,34 : KDS184 or
D53-59 : KDS226 or
M24C01-WMN6T
2SC2412K
2SA1037K
DTC124EK
DTA124EK
DTC144EK
DTC114YK
DAP202K
DAN202K
DA204K
D23,24 : RD6.8M(B2)
D28,29 : RD6.8MW
D32 : MA3056-M
D33 : SA-C2012-101TB
D35-43 : 1SR154-400
(X25-847X-XX)
SIGNAL LINE
A1
MASK
MECHA
(E30-4802)
CH CORD
2/2
X13-
CN1
(X13-978X-XX)
UPD784217GC105
NJM4565M-TE2
ICL7660SIBA
to CD MECHA. (X32- )
ANT.
D18 D16
CN3
TUNER
J1
MOTOR
DRIVER
NJM4565M-TE2
NJM4565MD DAN202K
DAN202U TA78L05F DAP202K DA202U RD6.8M TC74HC02AF BR24C01AF M5237ML AN8806SB LB1930M
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

AE AF AG AH AI AJ AK AL AM AN
1
2
3
4
5
6
7
CAUTION : For continued safety, replace safety critical components only with manufacturer's recommended parts (refer to parts list).
Indicates safety critical components. To reduce the risk of electric shock, leakage-current or resistance measurements shall be
carried out (exposed parts are acceptably insulated from the supply circuit) before the appliance is returned to the customer.
• DC voltages are as measured with a high impedance voltmeter. Values may vary slightly due to variations between individual
instruments or/and units.
!
KDC-715S/8015/
8016
B LINE
0V
5V
5.0V
5.0V
8.5V
6.8V
5.1V
3.4V
1.7V
OV
OV
OV
5.0V
0V
5.0V
25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1
100
99
98
97
96
95
94
93
92
91
90
89
88
87
86
85
84
83
82
81
80
79
78
77
76
51
52
53
54
55 56
57
58 59 60
61
62
63
64
65 66
67
68 69 70
71
72
73
74
75
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
S25
S24
S23
S22
S21
S20 S19 S18
S17
S16 S15
S14
S13
S12
S11
S10
S9 S8
S7
S6 S5
S4
S3
S2
S1
DI
CL
CE
DO
INH
OSC
TEST
VSS
VLCD4
VLCD3
VLCD2
VLCD1
VLCD0
VLCD
VDD
KEY
GREEN
RED
REMO
KI5
KI4
KI3
KI2
KI1
KS6
S51 S52 S53 S54 S55 S56 S57 S58 S59 S60 COM10 COM9 COM8 COM7 COM6 COM5 COM4 COM3 COM2 COM1 KS1 KS2 KS3 KS4 KS5
S26
S27
S28
S29
S30
S31
S32
S33
S34
S35
S36
S37
S38
S39
S40
S41
S42
S43
S44
S45
S46
S47
S48
S49
S50
1
2
4 3
7 8 6
5
16 15 13
14
11
12
10
9
22
23
21
20
19 18
17
24
25
26
27
28
29
30
32
33
31
34
38
40
41
39
36
37
35
45
47
48
46
43
44
42
50
49
51
52
54
53 56 55 58
57 60
59
63 65
64
66 68
67
70
69
KS2
KS1
KS3
KS4
KS5
C4
0.1
C2
0.1
R1
43K
C1
680P
C5
0.1
0.1
C6
C3
0.1
83
KI4
KI2
KI1
KI3
KI5
84
R5
2.2K
2.2K
R2
2.2K
R3R4
2.2K
750
R27
4
3
GND2 GND1
OUT
VCC 1
2
100
R9
C7 2.2
1K
R29
1K
R6
69 1IC1 COM2
IC1 SEG12 57 12
IC1 COM368 2
56
IC1 SEG13 13
IC1 COM467 3
55
IC1 SEG14 14
IC1 COM566 4
54
IC1 SEG15 15
IC1 COM665 5
53
IC1 SEG16 16
IC1 COM764 6
52
IC1 SEG17 17
IC1 COM863 7
51
IC1 SEG18 18
IC1 COM170 8
50
IC1 SEG19 19
IC1 SEG3131 9
49
IC1 SEG20 20
IC1 SEG3232 10
48
IC1 SEG21 21
IC1 SEG3333 11
47
IC1 SEG22 22
IC1 SEG3434 12
46
IC1 SEG23 23
IC1 SEG3535 13
45
IC1 SEG24 24
IC1 SEG3636 14
44
IC1 SEG25 25
IC1 SEG3737 15
43
IC1 SEG26 26
IC1 SEG3838 16
42
IC1 SEG27 27
IC1 SEG3939 17
41
IC1 SEG28 28
IC1 SEG4040 18
40
IC1 SEG29 29
IC1 SEG5151 19
39
IC1 SEG30 30
IC1 SEG5252 20
38
IC1 SEG41 41
IC1 SEG5353 21
37
IC1 SEG42 42
IC1 SEG5454 22
36
IC1 SEG43 43
IC1 SEG5555 23
35
IC1 SEG44 44
IC1 SEG5656 24
34
IC1 SEG45 45
IC1 SEG5757 25
33
IC1 SEG46 46
IC1 SEG5858 26
32
IC1 SEG47 47
IC1 SEG5959 27
31
IC1 SEG48 48
IC1 SEG6060 28
30
IC1 SEG49 49
29
IC1 SEG50
68 67 66 65 64 63
IC1 SEG1
IC1 SEG2
IC1 SEG3
IC1 SEG4
IC1 SEG5
2
1
5 3 4
62 61 60 59 58
IC1 SEG6
IC1 SEG7
IC1 SEG8 IC1 SEG9
IC1 SEG10
IC1 SEG11
8 9 6 7
10
11
330
R16
390
R17
0.01
C13
R20
330
R19
330
R18
330
330
R21
330
R22
KI1
KI2
KI5
KI4
KI3
10K
R24
10K
R23
83
84
KS1
KS2
KS3
KS4
KS5
98
99
100
R10
VDD
NC
21
REMO
DGND
NC
LOCK SW
543
6
2.2K
DIMMER
L DATA L
L DATA S
879 12 11 10
RESET
L CE
L CLK
15 14 13
ILLUM G
ILL+B
S. GND
470
CP1
98
97
99
100
R8
22K
R26
1K
0.01
C16 1K
R28
330
R25
C14 C15
0.01 0.01
97
KS1
KS2
KS3
KS4
KS5
50
KI1
KI5
KI3
KI2
KI4
IC1
IC3
(X13-972X-XX)
A
47K
10K
10K
10K
10K
10K
47K
10K
2.2K
10K
Q8
Q2
Q1 Q5
DISC
SRC
VOL+
1
VOL-
2
ATT 4
3
AM
AUD
5
FM
6
CLK
EJECT
TI AUTO
S5
S4
D5S2
S21
S1
S14
S3
S15
S8
S16
S7
S6
S17
S10
S9
S13
D6
S12
S11
OPEN
S23
IC1 : LC75808W
IC3 : RS-171 Q1,2 : DTA114EK or
Q3,4 : 2SD2114K
Q5,7 :
Q6 : DTB123YK
Q8 : 2SC2412K or
D1 : MA3091-M
D2-4 : B30-1571-05
D5,6 : B30-1562-05
LCD1
Q4
Q3
S20
CN1
S22
D2
D3 D4
Q6
Q7
1/2
-J1
D1
S18
S19
2SD601A
UN2111
LOCK
KRC107S LCD1 B38-1034-05:
LCD DRIVER
AVR
REMOTE
DIMMER RESET
RED
GRN
X13
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

KDC-715S/8015/8016
21
EXPLODED VIEW (MECHANISM)
Parts with the exploded numbers larger than 700 are not supplied.
AB
1
2
3
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

KDC-715S/8015/8016
22
EXPLODED VIEW (UNIT)
Parts with the exploded numbers larger than 700 are not supplied.
CD
1
2
3
P
P
P
A x2
A
B x2
S
B x2
C x2
F
H
F
F
A
A
L
A x2
A x2
G
A
A
A
L
C
G
F
F
S
S
S
F
F
S
S
S
W
Wx2
S
X25-84XX-XX
Mx3
S
S
N
N
Q
Q
Q
Y
Ex2
Ex2
Y
X13-9720-10
R
R
R
R
Xx2
Tx2
M2x2 (BLK)
M2x2 (BLK)
M2x3 (BLK)
M2x2 (BLK)
M2x2 (BLK)
FLAT WASHER
FLAT WASHER
FLAT WASHER
FLAT WASHER
M2x3 (BLK)
M2x3 (BLK)
M3x5
Ø2x4
Ø2x8 (BLK)
Ø3x5
M3x10
M2.6x6
Ø3x12
Ø2x2.5
N09-4184-05
N09-4185-05
N09-4218-05
N09-4340-05
N09-4381-05
N19-2022-04
N19-2058-04
N19-2062-04
N19-2103-04
N35-2003-45
N38-2030-45
N67-3005-46
N80-2004-46
N80-2008-45
N83-3005-46
N35-3010-46
N86-2606-46
N83-3012-46
N38-2025-46
A
B
C
D
E
F
G
H
L
M
N
P
Q
R
S
T
W
X
Y
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
201
248 247
247
211
247
248
711
993
994
997
997
995 260 221
210 709 247
FPC1
731
785
DN1
251
212
287
258
280
263 263
786
773
244
271
PM1
FPC2
239
203
209
235
234
233
232
262
262
310
304
807
806
802 FPC1
756
246
259
240
206
231
239
243
204
271
708
762
236
207
PS1
208
240
202
F1
745
771
WH1
255x4
255x4
267
992
810
205
259 230
752
213
811
803
801
752
751
714
223
PA1
214
805
J 1
304
282
283
284
281
286
285
ME1
FPC3
LCD1
A 1
IC4
265
272 261
DC1
224
225
RM1
222 266
291
292
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

KDC-715S/8015/8016
23
PARTS LIST
∗New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
Ref. No. Parts No. Description
A
d
d
N
e
w
Dest
inati
on
201 1C A02-1489-03 PLASTIC CABINET ASSY
202 1C A10-4671-02 CHASSIS ASSY
203 1D A10-4315-04 CHASSIS CALKING ASSY
204 1C A10-4317-04 CHASSIS CALKING ASSY
205 1D A10-4319-04 CHASSIS CALKING ASSY
206 1D A10-4321-04 CHASSIS CALKING ASSY
207 1D A10-4674-02 CHASSIS ASSY
208 1D A10-4676-02 CHASSIS ASSY
209 2D A10-4534-23 CHASSIS ASSY
210 3C A22-2296-43 SUB PANEL ASSY
211 3D A10-4666-03 CHASSIS ASSY
212 2D A46-1652-01 REAR COVER
213 1D A52-0742-12 TOP PLATE
214 3C A21-4010-03 DRESSING PANEL
PA1 2A ∗A64-1871-02 PANEL ASSY K4
PA1 2A ∗A64-1872-02 PANEL ASSY K5
PA1 2A ∗A64-1874-02 PANEL ASSY M2
RM1 1C A70-0883-05 REMOTE CONTROLLER ASSY K4M2
221 3D B07-2139-03 ESCUTCHEON ASSY
222 1C B07-2183-02 ESCUTCHEON
223 2C ∗B10-3111-01 FRONT GLASS K4
223 2C ∗B10-3112-01 FRONT GLASS K5
223 2C ∗B10-3114-01 FRONT GLASS M2
- B46-0100-50 WARRANTY CARD
- B46-0606-04 ID CARD K4K5
- B46-0612-14 ID CARD M2
- B58-1278-04 CAUTION CARD
- B58-1321-14 CAUTION CARD
- B58-1344-04 CAUTION CARD K5
-∗B64-1600-00 INSTRUCTION MANUAL E,T M2
- B64-1603-00 INSTRUCTION MANUAL E K4K5
- B64-1604-00 INSTRUCTION MANUAL F,S K4K5
224 1C D10-4301-14 LEVER
225 1C D10-4302-14 LEVER
230 1D D10-4448-03 ARM ASSY
231 1D D10-4449-04 ARM ASSY
232 2D D13-1302-64 GEAR ASSY
233 2D D13-1306-24 GEAR
234 2D D13-1403-03 GEAR
235 2D D13-1404-04 GEAR
236 2D D13-1453-14 GEAR ASSY
239 1D D13-1312-34 GEAR
240 1D D13-1313-04 GEAR
243 1D D13-1456-13 GEAR ASSY
244 1D D13-1455-13 GEAR ASSY
246 1D D14-0678-04 ROLLER ASSY
247 3D D14-0723-04 ROLLER
248 3D D14-0716-14 ROLLER
251 2D E30-4797-05 CORD WITH PINPLUG
DC1 1C E30-4780-05 DC CORD
DN1 2D E30-4802-05 CORD WITH DIN CONNECTOR
KDC-715S/8015/8016
K4:KDC-8015 K5:KDC-715S M2:KDC-8016
Ref. No. Parts No. Description
Dest
inati
on
255 2D F29-0049-05 INSULATING COVER
F1 2D F52-0006-05 FUSE(MINI BLADE TYPE)
258 2D G01-2984-04 EXTENSION SPRING
259 1D G01-2818-24 EXTENSION SPRING
260 3C G01-2920-14 TORSION COIL SPRING
261 1C G01-2924-04 TORSION COIL SPRING
262 1D G11-1850-04 CUSHION
263 2D G16-1147-04 SHEET
- H10-4700-02 POLYSTYRENE FOAMED FIXTURE
- H21-1123-04 PROTECTION SHEET
- H25-0329-04 PROTECTION BAG (280X450X0.03)
- H25-0337-04 PROTECTION BAG (180X300X0.03)
- H25-1108-04 PROTECTION BAG (100X300X0.03)
-∗H54-1656-03 ITEM CARTON CASE K4
-∗H54-1657-03 ITEM CARTON CASE K5
-∗H54-1659-03 ITEM CARTON CASE M2
265 1C J19-4875-04 BRACKET
266 1C J19-4876-04 BRACKET
267 1C J21-9491-03 MOUNTING HARDWARE ASSY
271 1D J31-1035-24 COLLAR
272 1C J54-0606-04 STAY
FPC2 1D J84-0062-23 FLEXIBLE PRINTED WIRING BOARD
FPC3 3C J84-0066-13 FLEXIBLE PRINTED WIRING BOARD
280 2C K24-3540-03 KNOB OPEN
281 2C K24-3541-04 KNOB SRC
282 2C K25-1095-03 KNOB VOL
283 2C K25-1096-03 KNOB 1-3
284 2C K25-1097-03 KNOB 4-6
285 2C K25-1098-03 KNOB FM/AM
286 2C K25-1099-03 KNOB CLK
287 2D K29-7010-04 KNOB ASSY LOCK
291 1C N99-1652-05 SCREW SET
292 1C N99-1683-05 SCREW SET
A 1D N09-4184-05 MACHINE SCREW (M2X2 2º≠∏¤∏¤“ )
B 1D N09-4185-05 MACHINE SCREW (M2X2 ª◊1º≠∏)
C 1D N09-4218-05 MACHINE SCREW (M2X 3)
D 1D N09-4340-05 MACHINE SCREW (2º≠∏¤∏¤M2X2.)
E 1D N09-4381-05 MACHINE SCREW (M2X2,ª◊)
F 2D N19-2022-04 FLAT WASHER
G 2D N19-2058-04 FLAT WASHER
H 1D N19-2062-04 FLAT WASHE
J 1D N19-2085-04 FLAT WASHER
K 1D N19-2095-04 FLAT WASHER
L 1D N19-2103-04 FLAT WASHER
M 3C N35-2003-45 BINDING HEAD MACHINE SCREW
N 3C N38-2030-45 PAN HEAD MACHIN SCREW
P 3C N67-3005-46 PAN HEAD SEMS SCREW
Q 2C N80-2004-46 PAN HEAD TAPTITE SCREW
R 2C N80-2008-45 PAN HEAD TAPTITE SCREW
S 1D N83-3005-46 PAN HEAD TAPTITE SCREW
PS1 1D S68-0829-05 PUSH SWITCH
A
d
d
N
e
w
indicates safety critical components.
!
!
!
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

KDC-715S/8015/8016
24 indicates safety critical components.
!
∗New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
Ref. No. Parts No. Description
A
d
d
N
e
w
Dest
inati
on
PM1 1D T42-0752-34 MOTOR ASSY
ME1 3C X92-3700-00 MECHANISM ASSY
D2 -4 B30-1571-05 LED(WHITE)
D5 ,6 B30-1562-05 LED
LCD1 2C B38-1034-05 LIQUID CRYSTAL
C1 CK73FB1H681K CHIP C 680PF K
C2 -6 CK73FB1C104K CHIP C 0.10UF K
C7 CK73EB1C225K CHIP C 2.2UF K
C13 -16 CK73FB1H103K CHIP C 0.010UF K
304 2C E29-1596-04 CONDUCTIVE RUBBER
CN1 E59-0833-05 RECTANGULAR PLUG
CP1 R90-1016-05 MULTI-COMP 470 X4
R1 RK73FB2A433J CHIP R 43K J 1/10W
R2 -5 RK73FB2A222J CHIP R 2.2K J 1/10W
R6 RK73FB2A102J CHIP R 1.0K J 1/10W
R8 RK73FB2A223J CHIP R 22K J 1/10W
R9 RK73FB2A101J CHIP R 100 J 1/10W
R10 RK73FB2A222J CHIP R 2.2K J 1/10W
R16 RK73EB2B331J CHIP R 330 J 1/8W
R17 RK73EB2B391J CHIP R 390 J 1/8W
R18 -22 RK73EB2B331J CHIP R 330 J 1/8W
R23 ,24 RK73FB2A103J CHIP R 10K J 1/10W
R25 RK73EB2B331J CHIP R 330 J 1/8W
R26 RK73EB2B102J CHIP R 1.0K J 1/8W
R27 RK73FB2A751J CHIP R 750 J 1/10W
R28 RK73EB2B102J CHIP R 1.0K J 1/8W
R29 RK73FB2A102J CHIP R 1.0K J 1/10W
S1 -13 S70-0856-05 TACT SWITCH
S14 -17 S70-0860-05 TACT SWITCH
S18 -20 S70-0851-05 TACT SWITCH
S21 S70-0857-05 TACT SWITCH
S22 S68-0822-05 PUSH SWITCH
S23 S70-0864-05 TACT SWITCH
D1 MA3091-M ZENER DIODE
IC1 LC75808W MOS-IC
IC3 RS-171 ANALOGUE IC
Q1 ,2 DTA114EK DIGITAL TRANSISTOR
Q1 ,2 UN2111 DIGITAL TRANSISTOR
Q3 ,4 2SD2114K TRANSISTOR
Q5 DTC114YK DIGITAL TRANSISTOR
Q5 KRC107S TRANSISTOR
Q5 UN2214 DIGITAL TRANSISTOR
Q6 DTB123YK DIGITAL TRANSISTOR
Q7 DTC114YK DIGITAL TRANSISTOR
Q7 KRC107S TRANSISTOR
Q7 UN2214 DIGITAL TRANSISTOR
Q8 2SC2412K TRANSISTOR
Q8 2SD601A TRANSISTOR
310 2C B03-3057-02 DRESSING PLATE
Ref. No. Parts No. Description
Dest
inati
on
J1 E58-0895-05 RECTANGULAR RECEPTACLE
FPC1 3D J84-0106-02 FLEXIBLE PRINTED WIRING BOARD
Y 2C N38-2025-46 PAN HEAD MACHIN SCREW
C1 C90-5242-05 ELECTRO 3300UF 16WV
C2 CK73FB1H103K CHIP C 0.010UF K
C3 C90-2926-05 ELECTRO 220UF 16WV
C4 CK73FB1H103K CHIP C 0.010UF K
C5 C90-2594-05 ELECTRO 10UF 10WV
C6 CE04CW0J101M ELECTRO 100UF 6.3WV
C7 CK73EB1C105K CHIP C 1.0UF K
C8 CE04CW1A221M ELECTRO 220UF 10WV
C10 CE04CW1A101M ELECTRO 100UF 10WV
C13 CK73FB1H223K CHIP C 0.022UF K
C14 C90-2608-05 ELECTRO 1.0UF 50WV
C15 C90-2595-05 ELECTRO 4.7UF 16WV K4
C16 ,17 CK73EB1C225K CHIP C 2.2UF K K4
C18 C90-2962-05 ELECTRO 100UF 16WV K4
C19 ,20 CK73EB1C225K CHIP C 2.2UF K K4
C21 CE04CW1C220M ELECTRO 22UF 16WV K4
C22 CK73GB1E223K CHIP C 0.022UF K K4
C23 CK73FB1H103K CHIP C 0.010UF K K4
C24 C90-2595-05 ELECTRO 4.7UF 16WV K4
C25 ,26 CK73FB1E473K CHIP C 0.047UF K
C27 C90-2598-05 ELECTRO 3.3UF 25WV
C28 CK73FB1E683K CHIP C 0.068UF K
C29 C90-2602-05 ELECTRO 0.10UF 50WV
C30 CK73FB1H102K CHIP C 1000PF K
C31 ,32 CK73FB1H103K CHIP C 0.010UF K
C33 CE04CW0J470M ELECTRO 47UF 6.3WV
C34 CK73FB1H103K CHIP C 0.010UF K
C35 CC73FCH1H240J CHIP C 24PF J
C36 CC73FCH1H270J CHIP C 27PF J
C37 CK73EB1C105K CHIP C 1.0UF K
C38 CK73FB1H472K CHIP C 4700PF K
C50 CK73FB1C104K CHIP C 0.10UF K
C51 CK73FB1H103K CHIP C 0.010UF K
C54 CC73FCH1H121J CHIP C 120PFJ
C55 CK73FB1C823K CHIP C 0.082UF K
C56 CK73FB1C104K CHIP C 0.10UF K
C57 CK73EB1C474K CHIP C 0.47UF K
C58 CK73GB1E183K CHIP C 0.018UF K
C59 CK73FB1H103K CHIP C 0.010UF K
C60 CE04CW1A101M ELECTRO 100UF 10WV
C61 C90-2610-05 ELECTRO 2.2UF 50WV
C63 C93-1054-05 CHIP C 0.012UF K
C65 ,66 C90-2610-05 ELECTRO 2.2UF 50WV
C81 ,82 CE04CW1C220M ELECTRO 22UF 16WV K4
C81 ,82 C90-2597-05 ELECTRO 10UF 16WV K5M2
C85 ,86 CE04CW1C220M ELECTRO 22UF 16WV K4
C85 ,86 C90-2597-05 ELECTRO 10UF 16WV K5M2
C89 -92 C90-2597-05 ELECTRO 10UF 16WV
C95 -98 C90-5296-05 ELECTRO 0.22UF 50WV
KDC-715S/8015/8016
A
d
d
N
e
w
K4:KDC-8015 K5:KDC-715S M2:KDC-8016
ELECTRIC UNIT (X25-8470-XX)
SWITCH UNIT (X13-9720-10)
PARTS LIST
SUB CIRCUIT UNIT (X13-978X-XX)
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

KDC-715S/8015/8016
PARTS LIST
indicates safety critical components.
!
∗New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
Ref. No. Parts No. Description
A
d
d
N
e
w
Dest
inati
on
C99 C90-2935-05 ELECTRO 1.0UF 50WV
C100 C90-2608-05 ELECTRO 1.0UF 50WV
C101 CE04CW1A101M ELECTRO 100UF 10WV
C102 C90-2608-05 ELECTRO 1.0UF 50WV
C111 CE04CW0J470M ELECTRO 47UF 6.3WV
C112,113 C90-2606-05 ELECTRO 0.47UF 50WV
C115,116 CK73FB1C224K CHIP C 0.22UF K
C123-126 CC73FSL1H102J CHIP C 1000PF J
C144 CK73FB1H103K CHIP C 0.010UF K
C146 CK73FB1H103K CHIP C 0.010UF K
C147 CE04CW1A101M ELECTRO 100UF 10WV
C148 CK73FB1E273K CHIP C 0.027UF K
C151 CK73FB1H103K CHIP C 0.010UF K
C153 CK73FB1H103K CHIP C 0.010UF K
C159 CK73FB1H103K CHIP C 0.010UF K
C160 CK73EB1C225K CHIP C 2.2UF K K4
C162,163 CK73FB1H103K CHIP C 0.010UF K
CN1 E40-3241-05 PIN ASSY
CN2 E40-3299-05 PIN ASSY
CN3 E40-3252-05 PIN ASSY
CN4 E40-3261-05 PIN ASSY
CN5 E40-9550-05 FLAT CABLE CONNECTOR
CN6 E40-9557-05 FLAT CABLE CONNECTOR
CN7 E40-5029-05 FLAT CABLE CONNECTOR
J1 E58-0836-05 RECTANGULAR RECEPTACLE
WH1 2D E30-4440-05 CORD WITH PLUG
WH1 2D E30-4804-05 CORD WITH PLUG
L1 L40-4795-34 SMALL FIXED INDUCTOR
L2 L40-2205-34 SMALL FIXED INDUCTOR(22UH) K4
L4 -7 L40-4795-34 SMALL FIXED INDUCTOR
L8 L33-1039-05 LINE FILTER COIL
L9 L39-1004-05 TRAP COIL
L10 L40-4795-34 SMALL FIXED INDUCTOR
L11 L92-0075-05 CHIP FERRITE
X1 L78-0683-05 RESONATOR
X2 L77-2738-05 CRYSTAL RESONATOR
S 3D N83-3005-46 PAN HEAD TAPTITE SCREW
T 3D N35-3010-46 BINDING HEAD MACHINE SCREW
W 3D N86-2606-46 BINDING HEAD TAPTITE SCREW
X 3D N83-3012-46 PAN HEAD TAPTITE SCREW
CP2 R90-0724-05 MULTI-COMP 1K X4
CP3 R90-1022-05 MULTI-COMP 470 X2
CP4 -7 R90-0725-05 MULTI-COMP 1K X2
CP9 R90-0725-05 MULTI-COMP 1K X2
R1 RK73FB2A223J CHIP R 22K J 1/10W
R2 RK73FB2A101J CHIP R 100 J 1/10W
R3 RK73FB2A223J CHIP R 22K J 1/10W
R4 RK73FB2A222J CHIP R 2.2K J 1/10W
R5 RK73EB2B221J CHIP R 220 J 1/8W
R6 RK73FB2A153J CHIP R 15K J 1/10W
R7 R92-3032-05 CHIP R 4.3K D 1/10W
R8 ,9 R92-3052-05 METAL GLAZE RESISTOR
R11 RK73FB2A152J CHIP R 1.5K J 1/10W
R12 RK73FB2A751J CHIP R 750 J 1/10W
Ref. No. Parts No. Description
Dest
inati
on
R13 RK73FB2A471J CHIP R 470 J 1/10W
R14 RK73GB1J104J CHIP R 100K J 1/16W
R16 RK73EB2B103J CHIP R 10K J 1/8W
R20 RK73EB2B104J CHIP R 100K J 1/8W
R21 RK73FB2A102J CHIP R 1.0K J 1/10W K4
R22 RK73FB2A104J CHIP R 100K J 1/10W K4
R23 RK73FB2A750J CHIP R 75 J 1/10W K4
R24 RK73FB2A272J CHIP R 2.7K J 1/10W K4
R25 RK73FB2A470J CHIP R 47 J 1/10W K4
R27 RK73GB1J752J CHIP R 7.5K J 1/16W K4
R28 RK73GB1J563J CHIP R 56K J 1/16W K4
R29 RK73GB1J913J CHIP R 91K J 1/16W K4
R30 RK73FB2A470J CHIP R 47 J 1/10W K4
R31 RK73FB2A103J CHIP R 10K J 1/10W K4
R32 RK73GB1J913J CHIP R 91K J 1/16W K4
R33 RK73FB2A913J CHIP R 91K J 1/10W K4
R34 RK73FB2A472J CHIP R 4.7K J 1/10W
R35 R92-0366-05 CHIP R 560 J 1W
R36 RK73FB2A223J CHIP R 22K J 1/10W
R37 RK73FB2A472J CHIP R 4.7K J 1/10W
R38 R92-0365-05 CHIP R 1.0K J 1/2W
R39 RK73FB2A223J CHIP R 22K J 1/10W
R40 R92-0365-05 CHIP R 1.0K J 1/2W
R41 RK73EB2B472J CHIP R 4.7K J 1/8W
R42 RK73EB2B222J CHIP R 2.2K J 1/8W
R43 -45 RK73EB2B470J CHIP R 47 J 1/8W
R46 RK73EB2B222J CHIP R 2.2K J 1/8W
R47 ,48 RK73EB2B472J CHIP R 4.7K J 1/8W
R50 ,51 RK73FB2A123J CHIP R 12K J 1/10W
R52 RK73FB2A562J CHIP R 5.6K J 1/10W
R53 RK73GB1J223J CHIP R 22K J 1/16W
R54 RD14DB2H332J SMALL-RD 3.3K J 1/2W
R56 ,57 RK73EB2B104J CHIP R 100K J 1/8W
R58 RK73FB2A183J CHIP R 18K J 1/10W
R59 RK73GB1J104J CHIP R 100K J 1/16W
R60 RK73FB2A104J CHIP R 100K J 1/10W K4M2
R61 ,62 RK73FB2A104J CHIP R 100K J 1/10W K5
R62 RK73FB2A104J CHIP R 100K J 1/10W M2
R63 RK73FB2A104J CHIP R 100K J 1/10W K4
R65 RK73FB2A104J CHIP R 100K J 1/10W
R66 RK73FB2A222J CHIP R 2.2K J 1/10W
R67 RK73GB1J472J CHIP R 4.7K J 1/16W
R68 RK73FB2A225J CHIP R 2.2M J 1/10W
R69 RK73FB2A222J CHIP R 2.2K J 1/10W
R70 RK73FB2A102J CHIP R 1.0K J 1/10W
R71 RK73GB1J472J CHIP R 4.7K J 1/16W
R72 ,73 RK73FB2A562J CHIP R 5.6K J 1/10W
R74 RK73FB2A223J CHIP R 22K J 1/10W
R76 RK73GB1J470J CHIP R 47 J 1/16W
R77 RK73FB2A104J CHIP R 100K J 1/10W
R78 RK73FB2A470J CHIP R 47 J 1/10W
R79 ,80 RK73FB2A222J CHIP R 2.2K J 1/10W
R82 RK73FB2A104J CHIP R 100K J 1/10W
R83 RK73GB1J104J CHIP R 100K J 1/16W
R84 RK73FB2A102J CHIP R 1.0K J 1/10W
ELECTRIC UNIT (X25-8470-XX)
A
d
d
N
e
w
K4:KDC-8015 K5:KDC-715S M2:KDC-8016
!
25
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

KDC-715S/8015/8016
26 indicates safety critical components.
!
∗New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
Ref. No. Parts No. Description
A
d
d
N
e
w
Dest
inati
on
R89 RK73FB2A104J CHIP R 100K J 1/10W
R92 RK73GB1J102J CHIP R 1.0K J 1/16W
R94 RK73GB1J223J CHIP R 22K J 1/16W
R95 ,96 RK73GB1J472J CHIP R 4.7K J 1/16W
R99 RK73GB1J102J CHIP R 1.0K J 1/16W
R100 RK73FB2A102J CHIP R 1.0K J 1/10W
R101 RK73GB1J104J CHIP R 100K J 1/16W
R102,103 RK73FB2A470J CHIP R 47 J 1/10W
R104 RK73FB2A104J CHIP R 100K J 1/10W
R105-107 RK73FB2A222J CHIP R 2.2K J 1/10W
R108 RK73GB1J222J CHIP R 2.2K J 1/16W
R110 RK73FB2A104J CHIP R 100K J 1/10W
R111 RK73GB1J104J CHIP R 100K J 1/16W
R114 RK73GB1J164J CHIP R 160K J 1/16W
R116 RK73GB1J102J CHIP R 1.0K J 1/16W
R117 RK73FB2A102J CHIP R 1.0K J 1/10W
R118 RK73GB1J102J CHIP R 1.0K J 1/16W
R119 RK73EB2B102J CHIP R 1.0K J 1/8W
R130 RK73FB2A473J CHIP R 47K J 1/10W
R131 RK73FB2A472J CHIP R 4.7K J 1/10W
R132-136 RK73EB2B471J CHIP R 470 J 1/8W
R137-139 RK73FB2A222J CHIP R 2.2K J 1/10W
R140 RK73EB2B472J CHIP R 4.7K J 1/8W
R141,142 RK73GB1J104J CHIP R 100K J 1/16W
R143,144 RK73FB2A104J CHIP R 100K J 1/10W
R145 RK73FB2A472J CHIP R 4.7K J 1/10W
R147 RK73FB2A472J CHIP R 4.7K J 1/10W
R153,154 RK73EB2B361J CHIP R 360 J 1/8W
R155,156 RK73FB2A472J CHIP R 4.7K J 1/10W
R157,158 RK73FB2A222J CHIP R 2.2K J 1/10W K4
R157,158 RK73FB2A223J CHIP R 22K J 1/10W K5M2
R159,160 RK73EB2B361J CHIP R 360 J 1/8W
R161,162 RK73FB2A472J CHIP R 4.7K J 1/10W
R163,164 RK73FB2A222J CHIP R 2.2K J 1/10W K4
R163,164 RK73FB2A223J CHIP R 22K J 1/10W K5M2
R167,168 RK73FB2A103J CHIP R 10K J 1/10W K4
R169,170 RK73FB2A223J CHIP R 22K J 1/10W K4
R171,172 RK73FB2A820J CHIP R 82 J 1/10W
R174 RK73EB2B102J CHIP R 1.0K J 1/8W
R175,176 RK73FB2A103J CHIP R 10K J 1/10W K4
R177,178 RK73FB2A223J CHIP R 22K J 1/10W K4
R179,180 RK73FB2A820J CHIP R 82 J 1/10W
R181-184 RK73FB2A472J CHIP R 4.7K J 1/10W
R185 RK73GB1J184J CHIP R 180K J 1/16W
R186 RK73FB2A431J CHIP R 430 J 1/10W
R187 RK73FB2A751J CHIP R 750 J 1/10W
R188 RK73FB2A243J CHIP R 24K J 1/10W
R189 RK73FB2A102J CHIP R 1.0K J 1/10W
R190 RK73FB2A101J CHIP R 100 J 1/10W
R191 RK73FB2A223J CHIP R 22K J 1/10W
R192 RK73GB1J333J CHIP R 33K J 1/16W
R193,194 RK73EB2B100J CHIP R 10 J 1/8W
R195 RK73EB2B4R7J CHIP R 4.7 J 1/8W
R196 RK73EB2B104J CHIP R 100K J 1/8W
R197 RK73FB2A105J CHIP R 1.0M J 1/10W
Ref. No. Parts No. Description
Dest
inati
on
R199 RK73GB1J104J CHIP R 100K J 1/16W
R200 RK73EB2B222J CHIP R 2.2K J 1/8W
R232 RK73FB2A272J CHIP R 2.7K J 1/10W
R233 RK73FB2A223J CHIP R 22K J 1/10W
R234 RK73EB2B102J CHIP R 1.0K J 1/8W
R235 RK73FB2A223J CHIP R 22K J 1/10W
R236 RK73EB2B102J CHIP R 1.0K J 1/8W
R241 RK73FB2A101J CHIP R 100 J 1/10W
R242 RK73GB1J101J CHIP R 100 J 1/16W
R243,244 RK73FB2A102J CHIP R 1.0K J 1/10W
R247 RK73GB1J102J CHIP R 1.0K J 1/16W
R248 RK73FB2A104J CHIP R 100K J 1/10W
W1 -6 R92-2052-05 CHIPR 0 J 1/10W
W8 -17 R92-2052-05 CHIP R 0 J 1/10W K5M2
W16 ,17 R92-2052-05 CHIP R 0 J 1/10W K4
W20 ,21 R92-2052-05 CHIP R 0 J 1/10W
W28 R92-2052-05 CHIP R 0 J 1/10W
PH1 T95-0231-05 OPTO ISOLATOR
D1 RM10ZLF DIODE
D2 AM01Z DIODE
D2 ERA15-01 DIODE
D3 MA4056(N)-M ZENER DIODE
D4 MA4082(N)-L ZENER DIODE
D5 MA4110-L ZENER DIODE
D7 MA4110(N)-M ZENER DIODE K4
D8 MA4056(N)-M ZENER DIODE K4
D11 ,12 AM01Z DIODE
D11 ,12 ERA15-01 DIODE
D13 DAP202K DIODE
D13 KDS181 DIODE
D13 MA152WA DIODE
D16 MA3062WA ZENER DIODE
D18 MA3062WA ZENER DIODE
D19 MA4056(N)-M ZENER DIODE
D20 MA4062(N)-M ZENER DIODE
D21 DAN202K DIODE
D21 KDS184 DIODE
D21 MA152WK DIODE
D23 ,24 RD6.8M(B2) ZENER DIODE
D27 DAP202K DIODE
D27 KDS181 DIODE
D27 MA152WA DIODE
D28 ,29 RD6.8MW ZENER DIODE
D33 SA-C2012-101TB SURGE ABSORBER
D34 DAN202K DIODE
D34 KDS184 DIODE
D34 MA152WK DIODE
D35 -43 1SR154-400 DIODE
D47 ,48 DAP202K DIODE
D47 ,48 KDS181 DIODE
D47 ,48 MA152WA DIODE
D53 -59 DA204K DIODE
D53 -59 KDS226 DIODE
ELECTRIC UNIT (X25-8470-XX)
A
d
d
N
e
w
K4:KDC-8015 K5:KDC-715S M2:KDC-8016
PARTS LIST
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
