Kenwood KDC-BT630U User manual

Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
B5A-2598-00 (MN)© 2018 JVC KENWOOD Corporation
KDC-BT630U
KDC-BT530U
CD-RECEIVER
INSTRUCTION MANUAL
JS_KWD_KDC_BT630U_MN_C.indd 1JS_KWD_KDC_BT630U_MN_C.indd 1 7/11/2018 9:23:14 AM7/11/2018 9:23:14 AM

Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
2ENGLISH
BEFORE USE
IMPORTANT
• To ensure proper use, please read through this manual before using this product. It is especially important that you read and observe Warnings
and Cautions in this manual.
• Please keep the manual in a safe and accessible place for future reference.
WARNING
• Do not operate any function that takes your attention away from safe driving.
• Do not ingest the battery, Chemical Burn Hazard.
The remote control supplied with this product contains a coin/button cell battery.
If the coin/button cell battery is swallowed, it can cause severe internal burns in just 2 hours and can lead to death.
Keep new and used batteries away from children.
If the battery compartment does not close securely, stop using the product and keep it away from children.
If you think batteries might have been swallowed or placed inside any part of the body, seek immediate medical attention.
Caution
Volume setting:
• Adjust the volume so that you can hear sounds outside the car to prevent accidents.
• Lower the volume before playing digital sources to avoid damaging the speakers by the sudden increase of the output level.
General:
• Avoid using the external device if it might hinder safe driving.
• Make sure all important data has been backed up. We shall bear no responsibility for any loss of recorded data.
• Never put or leave any metallic objects (such as coins or metal tools) inside the unit to prevent a short circuit.
• If a disc error occurs due to condensation on the laser lens, eject the disc and wait for the moisture to evaporate.
• USB rating is indicated on the main unit. To view, detach the faceplate. (Page 3)
• Depending on the types of cars, the antenna will automatically extend when you turn on the unit with the antenna control wire connected
(page 32). Turn off the unit or change the source to STANDBY when parking at a low ceiling area.
Remote control (RC-406):
• Do not leave the remote control in hot places such as on the dashboard.
• The Lithium battery is in danger of explosion if replaced incorrectly. Replace it only with the same or equivalent type.
• The battery pack or batteries shall not be exposed to excessive heat such as sunshine, fire or the like.
CONTENTS
BEFORE USE 2
BASICS 3
GETTING STARTED 4
1 Select the display language
and cancel the demonstration
2 Set the clock and date
3 Set the initial settings
RADIO 6
AUX 7
CD/USB/iPod/ANDROID 8
Spotify 10
BLUETOOTH® 12
AUDIO SETTINGS 19
DISPLAY SETTINGS 24
REFERENCES 25
Maintenance
More information
TROUBLESHOOTING 28
INSTALLATION/
CONNECTION 30
SPECIFICATIONS 33
How to read this manual
• Operations are explained mainly using buttons on the faceplate of .
• English indications are used for the purpose of explanation. You can select the display language from the [FUNCTION] menu. (Page 5)
• [XX] indicates the selected items.
• (Page XX) indicates references are available on the stated page.
JS_KWD_KDC_BT630U_MN_EN_3rd draft.indd 2JS_KWD_KDC_BT630U_MN_EN_3rd draft.indd 2 7/11/2018 8:57:28 AM7/11/2018 8:57:28 AM

Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
3
ENGLISH
BASICS
To On the faceplate On the remote control
Turn on the power Press BSRC.
• Press and hold to turn off the power.
Press and hold SRC to turn off the power.
( Pressing SRC does not turn on the power. )
Adjust the volume Turn the volume knob. Press VOL or VOL .
• Press and hold VOL to continuously increase the volume to 15.
Press ATT during playback to attenuate the sound.
• Press again to cancel.
Select a source Press BSRC repeatedly. Press SRC repeatedly.
Change the display information Press DISP repeatedly. (Page 27) ( Not available )
Remote control (RC-406) (supplied for )
Attach How to resetDetach
Faceplate
How to replace the battery
Remote sensor (Do not expose to bright
sunlight.)
Pull out the insulation sheet when
using for the first time.
Reset the unit
within 5 seconds
after detaching the
faceplate.
Volume
knob
Loading
slot
Detach button
Display window
:
Lights up when
Bluetooth
connection is
established.
(Page 12)
: Can be remotely controlled with an optionally
purchased remote control.
JS_KWD_KDC_BT630U_MN_EN_3rd draft.indd 3JS_KWD_KDC_BT630U_MN_EN_3rd draft.indd 3 7/11/2018 8:57:29 AM7/11/2018 8:57:29 AM

4ENGLISH
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
GETTING STARTED
Select the display language and cancel the demonstration
When you turn on the power for the first time (or [FACTORY RESET] is set to
[YES] , see page 5), the display shows: “SEL LANGUAGE” “PRESS”
“VOLUME KNOB”
1 Turn the volume knob to select [ENG] (English) or [TUR] (Turkish), then
press the knob.
[ENG] is selected for the initial setup.
Then, the display shows: “CANCEL DEMO” “PRESS” “VOLUME KNOB”.
2 Press the volume knob again.
[YES] is selected for the initial setup.
3 Press the volume knob again.
“DEMO OFF” appears.
Then, the display shows the selected crossover type: “2-WAY X ’ OVER” or
“3-WAY X ’ OVER”
• To change the crossover type, see “Change the crossover type” on
page 5.
Set the clock and date
1 Press the volume knob to enter
[FUNCTION] .
2 Turn the volume knob to select [CLOCK] , then press the knob.
To adjust the clock
3 Turn the volume knob to select [CLOCKADJUST] , then press the knob.
1
2
4 Turn the volume knob to make the settings, then press the knob.
Hour Minute
5 Turn the volume knob to select [CLOCK FORMAT] , then press the knob.
6 Turn the volume knob to select [12H] or [24H] , then press the knob.
To set the date
7 Turn the volume knob to select [DATEFORMAT] , then press the knob.
8 Turn the volume knob to select [DD/MM/YY] or [MM/DD/YY] , then press
the knob.
9 Turn the volume knob to select [DATESET] , then press the knob.
10 Turn the volume knob to make the settings, then press the knob.
Day Month Year or Month Day Year
11 Press and hold to exit.
To return to the previous setting item, press .
Set the initial settings
1 Press BSRC repeatedly to enter STANDBY.
2 Press the volume knob to enter [FUNCTION] .
3 Turn the volume knob to select an item (see the following table), then
press the knob.
4 Repeat step 3 until the desired item is selected or activated.
5 Press and hold to exit.
To return to the previous setting item, press .
Default: [XX]
[AUDIO CONTROL]
[SWITCH PREOUT] (For : Applicable only if [X’OVER] is set to [2WAY].)
(Page 5)
[REAR]/[SUB-W]: Selects whether rear speakers or a subwoofer are
connected to the line out terminals on the rear (through an external
amplifier). (Page 33)
3
JS_KWD_KDC_BT630U_MN_EN_3rd draft.indd 4JS_KWD_KDC_BT630U_MN_EN_3rd draft.indd 4 7/11/2018 8:57:29 AM7/11/2018 8:57:29 AM

ENGLISH 5
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
GETTING STARTED
[FACTORY RESET] [YES]: Resets the settings to default (except the stored station). ;
[NO]: Cancels.
[CLOCK]
[CLOCK DISPLAY] [ON]: The clock time is shown on the display even when the unit
is turned off. ; [OFF]: Cancels.
[ENGLISH] Select the display language for [FUNCTION] menu and music
information if applicable.
By default, [ENGLISH] is selected.
[TURKCE]
Change the crossover type
1Press BSRC repeatedly to enter STANDBY.
2Press and hold number buttons 4 and 5 to enter crossover
select.
The current crossover type appears.
3Turn the volume knob to select “2WAY” or “3WAY”, then press
the knob.
4Turn the volume knob to select “YES” or “NO”, then press the
knob.
The selected crossover type appears.
• To cancel, press and hold .
• To adjust the selected crossover settings, see page 21.
Caution:
Select a crossover type according to how the speakers are connected.
(Page 32, 33)
If you select a wrong type:
• The speakers may damage.
• The output sound level may be extremely high or low.
[DISPLAY]
[EASY MENU] (For )
When entering [FUNCTION]...
[ON]: [ZONE 1] illumination changes to white color. ;
[OFF]: [ZONE 1] illumination remains as [COLOR SELECT] color. (Page 24)
• [ZONE 2] illumination changes to light blue color when you enter [FUNCTION],
irregardless of the [EASY MENU] setting.
• Refer to the illustration on page 24 for zone identification.
[TUNER SETTING]
[PRESET TYPE] [NORMAL]: Memorizes one station for each preset button in each band (FM1/
FM2/FM3/AM/SW1/SW2). ; [MIX]: Memorizes one station for each preset button,
regardless of the selected band.
[SYSTEM]
[KEY BEEP] (Applicable only if [X’OVER] is set to [2WAY].)
[ON]: Activates the keypress tone. ; [OFF]: Deactivates.
[TDF ALARM] (Applicable only if [X’OVER] is set to [2WAY].)
[ON]:
Activates the alarm if you forget to detach the faceplate when ACC is set to OFF. ;
[OFF]: Deactivates.
[SOURCE SELECT]
[SPOTIFY SRC] [ON]: Enables SPOTIFY/SPOTIFY BT in source selection. ; [OFF]: Disables.
(Page 10)
[BUILT-IN AUX] [ON]: Enables AUX in source selection. ; [OFF]: Disables. (Page 7)
[CD READ] [1]: Automatically distinguishes between audio file disc and music CD. ; [2]: Forces
to play as a music CD. No sound can be heard if an audio file disc is played.
[F/W UPDATE]
[UPDATE SYSTEM]
[F/W UP xxxx] [YES]: Starts upgrading the firmware. ; [NO]: Cancels (upgrading is not activated).
For details on how to update the firmware, visit <www.kenwood.com/cs/ce/>.
