CD RECEIVER
KDC-MP4028
KDC-MP428
KDC-MP6029
SERVICE MANUAL
PANEL ASSY
KDC-MP4028 (A64-3481-02) PANEL ASSY
KDC-MP428 (A64-3483-02)
SPARE TDF PANEL
MAIN UNIT NAME TDF PARTS No. TDF NAME
KDC-MP4028 Y33-2150-60 TDF-MP54DB
KDC-MP428 Y33-2150-63 TDF-MP54D
KDC-MP6029 Y33-2150-61 TDF-MP6029
PANEL ASSY
KDC-MP6029 (A64-3482-02)
MOUNTING HARDWARE ASSY
(J22-0011-03)
LEVER
(D10-4589-04) x2 SCREW SET
(N99-1763-05)
DC CORD
(E30-6414-05)
REMOTE CONTROLLER ASSY (RC-517)
(A70-2069-05)
BATTERY
(Not supplied)
SCREW SET
(N99-1757-05)
* ESCUTCHEON
(B07-xxxx-xx)
PLASTIC CABINET ASSY
(A02-2743-03)
MOUNTING HARDWARE (R)
(J22-0259-04)
MOUNTING HARDWARE (L)
(J22-0258-04)
FFFF
MENUMENU
VOLVOL
AUDAUD
SETSETUPUP
SCRL
AME
AUTO
ATT
SCAN RDM REP M.RDMF.SEL
SWSW
DISPDISP
C.S.
KDC- MP4028
SWSW
FFFF
MENUMENU
VOLVOL
AUDAUD
SETSETUPUP
SCRL
AME
AUTO
SCAN RDM REP M.RDMF.SEL
DISPDISP
KDC- MP6029
ATT
PREOUT
FFFF
MENUMENU
VOLVOL
AUDAUD
SETSETUPUP
SCRL
AME
AUTO
ATT
SCAN RDM REP M.RDMF.SEL
SWSW
DISPDISP
C.S.
KDC- MP428
* Depends on the model. Refer to the parts list.
This product uses Lead Free solder.

KDC-MP4028/MP428/MP6029
2
BLOCK DIAGRAM
FRONT-END
LX-BUS
E-VOL
IC2
CD MECHA
BU5V D5V
PREF
PRE+B
A8V
SYSTEM u-COM
BU
PW-IC SP-OUT
LOGIC
Q402-405 PRE-OUT
PHONE
ACC-DET
Q112
DIMMER
Q108
SURGE-
Q109,110
BU5V
IC12
PCON-SW
Q1,2
Q103,106
BU-DET
Q111
4V
Q15,16
IC5
SW14V
Q4,9
SW5V
Q3,11
ANT-CON
Q101,102
Q7,8
TUNER
Q302,303
A8V
IC3
DC-CN
TUN8V
A8V
PRE+B
SERVO+B
D5
BU5
SW5
8V
PRE+B
CD5V
DET
MUTE
BU
DC-CN etc
SW
EJECT BU5
PAN5V
FLIP
DET
RESET
IC7
ILL+B
CN
FLIP DET
RESET ENCODER
ROTARY
REMOTE SW5V
VFD DRIVER
ILLUMI
KEY MATRIX KEY
VFD
IC1
SW5 Q4
IC1
PAN5
IC4
IC2
J1
PREF 1/2VCC
For 4VPRE
IC11
+B
ILLUMI
ILL+B ILL+B
SW
Q305,306
AM+B AM+B
Q300,301
S1
Q10,11
ED1
D5V(FL+B)
J3
MUTE
IC6
J2
TUN8V
AM+B
SW5
W1
A1
SERVO+B
A8V
S4
BU5
BU5
EJECT & DSI
ILLUMI
Q304Q13
BU5
BU5
BU5
J1
DME1
MARINE DISP
OPEL DISP
BU5
SW5
CD
SERVO
BU5
BU5
BU5
713
2
10
1REAR L/R
FRONT L/R
FRONT/REAR
SW5
PON CD
ANT CON
P CON
BU DET ACC
ILLUMI
PHONE
P-ANT
P-CON
B.U.
MUTE DC-DET
PHONE
ACC DET
DIMMER
1
1
2
RST
PHONE
DIMMER/ACC DET
P CON/PON
BU DET/ANT CON
PON CD/PON ILL
9
5
9
P ON
P ON
P ON
P ON
PON ILL
AM+B
SELECT
COLOR
BU DET
Q111
Q114
1
1
3
MUTE
38
12
3
LAND ONLY
(X34- )
(X16- )
EF
ACB
TR COIL
FO COIL
APC
IC7
16.934MHz
CLOCK
IC3
LPF
IC2
SW
A3.3V REG
IC1
LOADING &
MICRO
PROCESSOR
IC4
CLOCK
16.00MHz
RF AMP
SERVO
MP3 DECODER
WMA DECODER
1Mbit SRAM
PROCESSOR
D3.3V REG
IC6
MOTOR
DRIVER
MOTOR
SPINDLE BU3.3V REG
IC5
S2
S4
S1
S3
AAC DECODER
+
+
+
+
+
(0-01)ONLY
SLED
MOTOR
PICKUP
CD PLAYER UNIT (X32-5740) BOARD
MOTHER
VREF
D.GND
BU5V
8EJE-SW
12EJE-SW
LOS-SW
LOE/LIM-SW
D.GND
D5.0V
MOTOR
LO/EJ
S.GND
D.GND
D.GND
P-ON1
S.GND
DATA
MUTE R
MUTE L
MSTOP
MRST
CLK
A.GND
A8V
R-ch
L-ch
D.GND
S.GND
D.GND
D.GND
D.OUT
P-ON2
S7.5V
DMUTE

KDC-MP4028/MP428/MP6029
3
●ELECTRIC UNIT (X34-338x-xx)
Ref. No. Application / Function Operation / Condition / Compatibility
IC1 SYSTEM µ-COM Controls FM/AM tuner, the changer, CD mechanism, panel, volume and tone.
IC2 E-VOL Controls the source, volume, tone.
IC3 A8V REF POWER SUPPLY Outputs 1.27V.
IC4 POWER IC Amplifies the front L/R and the rear L/R.
IC5 ILL+B POWER SUPPLY Outputs 1.225V.
IC6 MUTE LOGIC Controls logic for muting.
IC7 RESET IC “L” when detection voltage goes below 3.6V.
IC11 4V PREOUT POWER SUPPLY Outputs reference voltage for 4V preout.
IC12 SW REGULATOR Power supply for FL+B and CD mecha D5V.
IC902 SVR/3.3V SUPPLY Outputs SVR voltage and 3.3V.
Q1,2 B.U.5V AVR While BU is applied, BU5V AVR is output.
Q3,11 SW5V When Q11’s base goes “H”, SW5V is output.
Q4,9 SW14V When Q9’s base goes “H”, SW14V is output.
Q5,6 AUDIO 8V AVR When Q6’s 2nd pin goes “H”, A8V AVR outputs 8.0V.
Q7,8 SERVO+B AVR When Q8’s base goes “H”, AVR 7.5V is output.
Q12 IC12 SW When Q12’s base goes “L”, IC12 turns on.
Q13 PANEL 5V When Q13’s base goes “L”, PANEL 5V is output.
Q14 4V PRE+B If Q15’s emitter shorts GND, Q14’s emitter level goes GND, after that Q14’s B-E level goes
(SHORT PROTECTION) over 0.6V, Q14 turns on, and Q15 turns off.
Q15,16 4V PRE+B When Q15’s base goes “H”, 12V is output.
Q101,102 P-ANT SW When Q102’s base goes “H”, P-ANT SW 14V is output.
Q103,106 P-CON SW When Q106’s base goes “H”, AVR 14V is output.
Q104,105 P-CON PROTECTION When P-CON output voltage fallen is detected, protection functions.
Protects Q103 malfunction when P-CON SW turns on.
Q108 SMALL LAMP DET SW When Q108’s base goes “H”, Q108 turns on.
Q109,110 SERGE DET When Q109’s base goes “H”, IC4 state is changed into standby.
Q111 B.U.DET When Q111’s base goes “H”, Q111 turns on.
Q112 ACC DET When Q112’s base goes “H”, Q112 turns on.
Q113 MUTE DRIVER When the base goes “L”, preout mute driver turns on.
Q114 MUTE DRIVER When reset functions, Q114 turns on.
Q115,116 PREOUT MUTE DRIVER When the base goes “L”, preout mute driver turns on.
Q299 TUNER 8V SW When Q299’s 2nd pin goes “H”, tuner 8V is output.
Q300,301 AM+B When Q301’s base goes “H”, AM+B is output.
Q302,303 TUNER 8V When Q303’s base goes “H”, tuner 8V is output.
Q304 DSI DRIVER DSI lights when the base is “H”.DSI turns off when the base is “L”.
DSI turns on and off when panel is taken off.
Q305,306 SW ILL+B When Q306’s base goes “H”, SW ILL+B 11V is output.
Q400~405 PREOUT MUTE SW When the base goes “H”, preout is muted.
Q905~907 SVR+B SVR voltage is supplied from the outside.
COMPONENTS DESCRIPTION

KDC-MP4028/MP428/MP6029
4
●SWITCH UNIT (X16-291x-xx)
Ref. No. Application / Function Operation / Condition / Compatibility
IC1 VFD DRIVER
IC2 REMOTE CONTROL
Q4 SW 5V The power supply of IC2 turns on when Q4’s base goes “L”.
Q10 RED LED SW RED LED turns on when Q10’s base goes “H”.
Q11 GREEN LED SW GREEN LED turns on when Q11’s base goes “H”.
●CD PLAYER UNIT (X32-5740-00)
Ref. No. Application / Function Operation / Condition / Compatibility
IC1 A3.3V regulator Power supply for audio 3.3V
IC2 Ope amp for low-pass filter
IC3 4ch BTL driver Driving spindle motor and loading/ejection operation
IC4 µ-com
IC5 Bu 3.3V regulator Power supply for backup 3.3V
IC6 D3.3V regulator Digital 3.3V power supply
IC7 Audio DAC built-in servo DSP MP3, WMA, and AAC compatible
IC8 Memory IC Used only for 0-02 destination
IC11 Buffer IC Level shift
Q1 A3.3V discharge circuit
Q4 Electric AMP Adjusts current to be sent to laser
Q5,6 SW 5V
Q7,8 SW 8V
D1 For electric AMP
COMPONENTS DESCRIPTION

KDC-MP4028/MP428/MP6029
5
MICROCOMPUTER’STERMINAL DESCRIPTION
●SYSTEM µ-COM : IC1 on X34- (ELECTRIC UNIT)
Pin No. Pin Name I/O Application Processing Operation
1 REMO I Remote control signal Detects puls width
2LX MUTE I Mute request from slave unit H : MUTE ON, L : MUTE OFF
3AUD SDA I/O E-VOL data
4AUD SEL O E-VOL control
5AUD SCL O E-VOL clock output
6BYTE - GND
7CNVSS -
8XCIN I Oscillator terminal 32.768kHz
9XCOUT - Oscillator terminal
10 RESET I Reset detection
11 XOUT - Oscillator terminal
12 VSS -
13 XIN I Oscillator terminal 12.0MHz
14 VCC1 -
15 NMI I
16 CN DET I Panel communication detection H : Panel off, L : Panel on
17 NC -
18 LX REQ S I Communication request from slave unit
19 PON AM I/O AM power supply control AM is received : H, AM is not received : Hi-z
20 LX REQ M O Communication request to slave unit
21 TUN IFC OUT I Front-end IFC output H : Station exists, L :Station does not exsist
22 RDS AFS L I/O Function for models of European Market
23 RDS AFS M I/O Function for models of European Market
24,25 NC -
26 PWIC BEEP O Beep
27 TUN SCL I/O Front-end I2C clock MAX 400kHz
28 TUN SDA I/O Front-end I2C data
29 VFD SYS DATA O VFD data
30 VFD PAN DATA I VFD data
31 VFD CL O VFD clock 125kHz
32 VFD INH O VFD data blanking H :VFD turns on, L :VFD turns off
33 SDA I/O CD mecha I2C data
34 SCL I/O CD mecha I2C clock
35 PON PANEL I/O Panel 5V control ON : L
Momentary power down, panel off, 11 munits after ACC OFF :Hi-Z
36 DSI I/O DSI / Eject LED control OFF : Hi-z, Panel off : Puls drives, Illumination on and power on : H
37,38 NC -
39 EPM I To VSS via a resister
40 PANEL DET I Panel detection L : Panel off, H : Panel on

KDC-MP4028/MP428/MP6029
6
MICROCOMPUTER’STERMINAL DESCRIPTION
Pin No. Pin Name I/O Application Processing Operation
41 NC -
42 ROMCOR DET I To VSS via a resister
43 NC -
44 VFD CE O VFD control request
45 ROTARY CW I VOL key Detects puls width
46 ROTARY CCW I VOL key Detects puls width
47 CD DISC12 SW I12cm disc detection
48 CD LOS SW I CD loading detection
49 CD MUTE R I Rch CD source mute request L : Rch mute request, H : Other condition
50 CD MUTE L I Lch CD source mute request L : Lch mute request, H : Other condition
51 CD MRST O CD mecha µ-com reset L : Reset, H : Other condition
52 CD MSTOP O CD mecha µ-com stop H : Mecha µ-com functions, L : Mecha µ-com stops
53 CD DISC8 SW I 8cm disc detection
54 CD LOE LIM SW I CD detection (Chucking switch) H : Loadind ends, L : No disc
55 CD LOEJ I/O CD motor control Refer to“CD MECHA CONTROL OPERATION” on the TRUTH TABLE
56 CD MOTOR O CD motor control Refer to“CD MECHA CONTROL OPERATION” on the TRUTH TABLE
57 PON ILLUMI I/O Key illumination power supply ON : H, OFF : Hi-Z
58 PON PANEL CD O Panel 5V and CD/WMA power supply control
POWER ON : L, POWER OFF : H
Becomes “L” earlier than mecha stops when reset functions.
59 PON O Power supply control POWER ON : H, POWER OFF : L
60 VCC2 -
61 NC -
62 VSS -
63~65 TYPE 1~3 I Destination switch
66,67 TUN TYPE1,2 I Destination setting
68 OEM DISP DATA I/O External display data External display
69 OEM DISP CLK I/O External display clock External display
70 OEM DISP CE I/O External display chip enable External display
71 EJECT I Eject key L : Eject
72 P CON O External amp control POWER ON : H, POWER OFF and STBY :L
73 KEY REQ I Communication request from VFD driver
74 ANT CON O Power antenna control TUNER ON : H
75 ILLUMI DET I Dimmer illumination detection L : ON, H : OFF
76 BU DET I Momentary power down detection BU exists :L, Momentary power down or no BU :H
77 ACC DET I ACC detection ACC exists :L, ACC does not exist : H
78 (PWIC SVR) O SVR discharge circuit Becomes “H”in 5 seconds during POWER OFF momentary
power down, after that it becomes “L”.
79 PWIC MUTE O Power IC mute Standby source or momentary power down : H, Tel mute : L
80 PWIC STBY O Power IC standby control POWER ON : H, POWER OFF : L
81 LX CON O Start-up request to slave unit H : Slave unit ON, L :Slave unit OFF

KDC-MP4028/MP428/MP6029
7
MICROCOMPUTER’STERMINAL DESCRIPTION
Pin No. Pin Name I/O Application Processing Operation
82 MUTE PRE R O Rch preout mute Becomes “H”when “CD MUTE R”is “L” or momentary power
down happens.
83 MUTE PRE L O Lch preout mute Becomes “H”when “CD MUTE L” is “L” or momentary power
down happens.
84 MUTE 0 I/O E-VOL front mute L : MUTE ON, Hi-Z : MUTE OFF
85 MUTE 1 I/O E-VOL rear mute L : MUTE ON, Hi-Z : MUTE OFF
86 MUTE 2 I/O Mute except E-VOL front/rear L : MUTE ON, Hi-Z : MUTE OFF
87 LINE MUTE I Line mute detection TEL MUTE : Below 1V, NAVI MUTE : Below 1V or over 2.5V
88 NC -
89 PWIC DC DET I DC offset detection
90 LX RST O Hard reset to slave unit H : Reset, L : Other condition
91 MUTE C I/O E-VOL mute L : MUTE ON, Hi-Z : MUTE OFF
92 NC -
93 RDS NOISE I FM noise detection
94 AVSS -
95 TUN SMETER I S-meter input
96 VREF -
97 AVCC -
98 LX DATA S I Data from slave unit
99 LX DATA M I/O Data from slave unit
100 LX CLK I/O LX-BUS clock
TRUTHTABLE
CD MECHA CONTROL OPERATION
CD MECHA OPERATION CD MOTOR CD LOEJ
Stop L L
Load H L
Eject H H
Brake H Hi-z
●MECHANISM µ-COM : IC4 on X32- (CD PLAYER UNIT)
Pin No. Pin Name I/O Application Processing Operation Remarks
Description
1NCONot used. Low-fixed
2E2P_SCL I/O Rom correction E2P I2C clock
3~5 NC O Not used. Low-fixed
6VDD - 5V electric potential
7GND - GND electric potential

KDC-MP4028/MP428/MP6029
8* DXM-6580W : X92-5080-00, DXM-6590W : X92-5190-00
MICROCOMPUTER’STERMINAL DESCRIPTION
Pin No. Pin Name I/O Application Processing Operation Remarks
Description
8,9 NC O Not used. Low-fixed
10,11 PON1,PON2 O Power ON/OFF control H : ON, L : OFF
12 LOE/LIM_SW I Down-limit SW detection L : Lim detection
13 DAC_MUTE O DAC MUTE control H : MUTE ON, L : MUTE OFF Used only with DXM-6590W.
With DXM-6580W, open and L-fixed.
14 DAC_RST O DAC RESET H : NORMAL, L : RESET Used only with DXM-6590W.
With DXM-6580W, open and L-fixed.
15 EMPH O External DAC Emphasis control H : Emphasis ON, Used only with DXM-6590W.
L : Emphasis OFF With DXM-6580W, open and L-fixed.
16,17 NC O Not used. Low-fixed
18 IC/Vpp - Write voltage (FLASH) L : Normal operation,
H : In writing.
19 MUTE_L O Lch audio MUTE control L : MUTE ON, H : MUTE OFF
20 MUTE_R O Rch audio MUTE control L : MUTE ON, H : MUTE OFF
21 TYPE I DAC switching terminal
H : DSP built-in DAC used,
H : DXM-6580W, L : DXM-6590W
L : DSP built-in DAC Not used.
22 TEST_O 1 O TEST MODE O 1 (Not used.)
23 TEST_O 2 O TEST MODE O 2 (Not used.)
24 TEST_O 3 O TEST MODE O 3 (Not used.)
25 TEST_O 4 O TEST MODE O 4 (Not used.)
26 NC O Not used. Low-fixed
27 WAIT I Wait control signal detection
28~30 NC O Not used. Low-fixed
31 RESET I Reset detection H : NORMAL, L : RESET
32 XT1 I Not used.
33 XT2 - Not used.
34 REGC -
35 X2 -
36 X1 I
37 Vss - GND electric potential
38 VDD - 5V electric potential
39 NC O NC Output stopped in standby 3.3V driven
40 WRL I Multiplex WRITE signal 3.3V driven
41,42 NC O Not used. Low-fixed 3.3V driven
43 RD O Multiplex RD signal 3.3V driven
44 ASTB O Multiplex ASTB signal 3.3V driven
45 NC O Not used. Low-fixed 3.3V driven
46 NC O Not used. Low-fixed 3.3V driven
47~54 AD0~AD7 I/O Multiplex address/data 3.3V driven

KDC-MP4028/MP428/MP6029
9
Pin No. Pin Name I/O Application Processing Operation Remarks
Description
55 BVdd - Bus interface power supply
56 BVss - Bus interface GND
57~61 AB8~AB12 I/O Multiplex data/address 3.3V driven
62~65 NC O Not used. Low-fixed 3.3V driven
66 CS O Chip select control H : OFF, L : ON 3.3V driven
67 DSP RESET O DSP reset control H : NORMAL, L : RESET 3.3V driven
68~70 NC O Not used. Low-fixed 3.3V driven
71 Avdd -
72 Avss -
73 Avref I A/D port reference voltage input
74 NC I Not used. Low-fixed
75 RAMSEL I With DRAM/No DRAM switching H :With DRAM, L : No DRAM
for different models
76 RZM I 0bit MUTE detection H : ≥1.7V, L : <1.7V
77 LZM I 0bit MUTE detection H : ≥1.7V, L : <1.7V
78 AAC I AAC compatibility switching H : AAC non-compatible, AAC non-compatible mode has priority
L : AAC compatible for both hardware and software.
79 ASEL I Audio output polarity switching H : Reverse output,
L : Non-reverse output
80 E2P_WR I E2PROM write switching H : E2PROM WRITE,
L : NORMAL
81 TEST_I 0 I TEST MODE I 0 (Not used.)
82 TEST_I 1 I TEST MODE I 1 (Not used.)
83 TEST_I 2 I TEST MODE I 2 (Not used.)
84 TEST_I 3 I TEST MODE I 3 (Not used.)
85 NC I Not used. Low-fixed
86 NC O Not used. Low-fixed
87 MSTOP I Standby restart interruption H : STOP release, L : STOP
88 INTSV I Interruption from servo IC H : Interruption
89~92 NC O Not used. Low-fixed
93 D-MUTE O Driver MUTE H : OFF, L : ON
94 SYS_SDA I/O System µ-com I2C data Flash write port (SI0)
95 NC O Not used. Low-fixed Flash write port (SO0)
96 SYS_SCL I/O System µ-com I2C clock Flash write port (SCK0)
97~99 NC O Not used. Low-fixed
100 E2P_SDA I/O ROM correction E2P I2C data
MICROCOMPUTER’STERMINAL DESCRIPTION

KDC-MP4028/MP428/MP6029
10
TEST MODE
●How to enter the test mode
While simultaneously pressing “1” and “3”keys, press “RE-
SET” button.
●How to release the test mode
Press “RESET”button.(The release cannot be achieved in
the conditions of POWER OFF and ACC OFF.)
●Initial conditions of the test mode
• The source is “STANDBY”.
• The displays all lit up.
• The volume is at –10dB (The display shows “30”).
• LOUD is “OFF”.
• CRSC is “OFF”.
• SYSTEM Q is “NATURAL”.
• BEEP is sounded at all time with the key depressed for less
than 1 second.
• AUX is “ON”.
• SWPRE is “SW”.
● Special displays when all indicator lights are lighted
When keys are pressed while all indicators for the STANDBY
sources are lighted, the following displays will appear.
“1” Version display
key (Display) Example : 416K -1.02
(416K : Development name, -1.02 : Version)
“2” Serial number display (8 digits)
key (Display) : x x x x x x x x
“3” • When pressed for less than 1 second
key : POWER ON time display
(Display) : PON x x x x x MAX 65,535 (hours)
* The display is cleared by pressing the key for more than
2 seconds.
“4” • When pressed for less than 1 second
key : CD operation time display
(Display) : CDT x x x x x MAX 65,535 (hours)
* The display is cleared by pressing the key for more than
2 seconds.
“5” • When pressed for less than 1 second
key : CD EJECT number display
(Display) : EJC x x x x x MAX 65,535 (times)
* The display is cleared by pressing the key for more than
2 seconds.
“6” • When pressed for less than 1 second
key : Panel open/close number display
(Display) : PC x x x x x x MAX 65,535 (times)
* The display is cleared by pressing the key for more than
2 seconds.
“”•When pressed for less than 1 second
key : CD mechanism error log display
(Display) : I2C_OK_ _ → ERR_1-xx → ERR_2-xx →
ERR_3-xx → All lights light up
I2C_NG_ _ → ERR_1-xx → ERR_2-xx →
ERR_3-xx → All lights light up
(“ERR_1-xx” is the most recent error.)
Communication OK : I2C_OK_ _
Communication error : I2C_NG_ _
Communication error not detected
: ERR_n – – – (n : 1~3)
Communication error detected
: ERR_n-xx (n : 1~3 xx : Error code)
* The display is cleared by pressing the key for more than
2 seconds.

KDC-MP4028/MP428/MP6029
11
SPECIAL MODE
●Security
• How to enter the forced POWER ON mode
While “– – – –” is being displayed, while simultaneously
pressing “Q” key and “4” key, press “RESET” button, With
this, it is possible to turn the power on for 30 minutes only.
•How to clear the programmable security code
(KDC-MP4028/MP428 only)
1. While “– – – –”is being displayed, press“ ” for 3 seconds
or more while pressing the“AUTO” key.This makes the “– –
– –” display disappear.
2. Input “KCAR”, using the remote controller.
Press “5” key of the remote controller twice (Input for “K”)
and press “ ” key.
Press “2” key of the remote controller 3 times (Input for “C”)
and press “ ” key.
Press “2” key of the remote controller once (Input for “A”)
and press “ ” key.
Press “7” key of the remote controller twice (Input for “R”)
and press “ ” key.
3. The security is cleared and the unit enters STANDBY source
mode.
4. If wrong codes are input, “– – – –” will be displayed again.
•How to register the security code on the “Car
Audio Passport”sheet after replacing FRONT-END
UNIT (A1) (KDC-MP6029 only)
1. Enter the test mode.(Refer to“How to enter the test mode”.)
2. In the test mode, press “MENU” key to enter the MENU
mode.
When “SECURITY” is displayed, press “ ” key (for less
than 1 second) to enter the security registration mode.
3. Input the security code, using “FM” / “AM” / “ ” / “ ”
keys.
“FM” key :number up / “AM” key : number down
“” key : cursor to right / “ ” key : cursor to left
4. After inputting the code, press “ ” key for 3 seconds or
more which causes “RE-ENTER” to be displayed.This is
for “confirming” the code. Use the method in above No.“3”
to re-enter the code.
5. Then, press “ ” key for 3 seconds or more, which will dis-
play “APPROVED”.This completes the security code regis-
tration.
6. Release the test mode. (Refer to “How to release the test
mode”.)
* All clear cannot be used to clear the security code.
●Clearing CD mechanism error log information
1. While pressing “Q” key and “ATT”key simultaneously, press
“RESET” button to initialize the log information.
2. When the initialization is finished, the following displays will
be made.
Normal completion : CD_O_ _ _
Abnormal completion : CD_X_ _ _
3. Release Method: Press “RESET” button.(The last screen
will not be maintained.)
●Clearing DC offset error detection information
1. While pressing “3” and “6” keys simultaneously, press “RE-
SET” button to enter the error display mode.
2. In the display, when “STANDBY” is sourced, the current er-
ror condition is displayed.
When detected : DC_ERR_ _
When not detected : DC_OK_ _ _
3. When “TI”key is pressed for less than 1 second during er-
ror display, the detection information is cleared.
4. Release Method : Press “RESET” button.(The last screen
will not be maintained.)
●FM/AM channel space switching
When in the conditions of ACC ON and POWER OFF, while
depressing “1” key and “5” key simultaneously, press “SRC”
key.

KDC-MP4028/MP428/MP6029
12
ABCDE
1
2
3
4
5
6
7
R953
C7
R7
C958
C311
R260
W931
R323
R325
TH1
W15
C410
R426
R928
R936
W932
R20
R427
R429
C203
C204
R327
C435 C436
C501
C507
C513
C955
C960
R8
R24
R129
R131 R
R404
R405
R408
R409
R412
R413
R503
R519
13 11 12 8 4 3 2
9106 751
R934
X2
W997
R431
C
1
C408
C409
CP201
L
R
R21
R23
R25
R26
R28
R29
R109
R130
R201
R208
R211
R216
R218
R219
R220
R322
R324 R402
R403
R406
R407
R410
R411
R414
R415
R416
R417
R418
R419
R420
R421
R428
R440
R441
R501
R505
R506
R507
R925
R929 R933
R930
W3
X1
R312
R262
R802
C802
R801
123 224
115 214
CNVSS
VT
IFC
PL-SDA
PL-SCL
S-METER
AFS
BE
C428
C312
C405
C953
C412
C512
C954
C313
C419
C421
C15
C420
C417
C8
W123
C411
C999
C306
C310
C322
C308
C401
C959
C16
C402
C403
C431
W130
C961
W118
W129
L301
C415
C416
C418
C422
C503
C504
C505
C506
C529
W128
W127
W126
W125
W120 W119
W124
W122 W121
EB
1
4
8
5
17
148
45
31
48
49 33
116
64
32
17
1
4
8
5
B
E
E
C
C
EB
EB
EBEB
EB
EB
EB
EB
EB
EB
EB
EB
EB
E
B
BE
1
241
3
271226
BE
D904
D105
Q105
Q905
Q906
Q303
Q13
D9
Q299
D304
D309
Q113
D407
D303
D8
D1
0
D511
D512
D905
Q400
Q401
Q402
Q403
Q404
Q405
Q907
D401
D402
D403
D411
D501
D502
Q14
Q15
Q3
0
Q114
Q302
Q16
J2
J4
D505
D506
J3
W1
P1
D302
A1
CN1
CN4
S4
IC2
IC902
IC10
IC11
IC6
IC4
ELECTRIC UNIT X34-338x-xx (J76-0039-12)
PC BOARD (COMPONENT SIDEVIEW)

KDC-MP4028/MP428/MP6029
13
JIHGF
1
2
3
4
5
6
7
C7
R7
C102
R115
R243
R245
R247
R260
TH1
R3
R113
R114
R124
R125
C4
C104
C105
C106
C107
C108
C109
3
4
C208
W998
C501
C507
C10
R8
R107
R108
R112
R116
R118
R123
R128
R259
R503
R10
C103
CP201
CP202
CP203
R205
CP206
CP207
CP208 CP209
L202
R1 R2
R4
R6
R9
R101
R102
R103
R105
R109
R110
R117
R119
R120
R121
R122
R201
R204
R208
R211
R213
R219
R220
R233
R239
R240
R241
R253
R257
R258
R507
R238
CP204
R311
R312
R263
R17
R18
1
2
SS
SDA SCL
W101
C201
C5
L2
C8
W900
C1
C11
C101
L1
W115
W116
W117
C12
C9
W103
C18
C6
W108
C3
C14
W105
W118
R126
W107
C20
L3
W106
W102
W112
W111
W104
W109
W114
W113
R16
OGI
1
4
100
176
25 5026 51
75
E
B
E
C
C
EB
EB
EB
EB
EB
EB
EB
BE
EB
EB
EB
EB
EB
EB
EB EB
EB
EB
916
81
BE
1
5
42
BE
51
D105
D108
Q4
Q104
Q105
Q905
Q3
Q8
Q11
Q2
D3
D4
D103
D107
D
905
Q6
Q102
Q106
Q108
Q109
Q110
Q111
Q112
D109
D110
D111
D501
Q305
Q306
Q9
Q5
D1
Q7
Q1
D101
J1
S3
IC1
IC3
IC5
IC12
X34-338x-xx
Ref. No. Address
IC1 5F
IC2 5D
IC3 4F
IC4 2E
IC5 3H
IC6 4E
IC11 4D
IC12 6G
IC902 3E
Q1 2H
Q2 3H
Q3 4G
Q4 3H
Q5 4G
Q6 4F
Q7 4H
Q8 3H
Q9 3G
Q11 4G
Q13 6D
Q14 4D
Q15 4D
Q16 4E
Q102 2F
Q104 3F
Q105 3F
Q106 3F
Q108 3F
Q109 3G
Q110 3G
Q111 3G
Q112 3G
Q113 5E
Q114 5E
Q299 6B
Q302 5C
Q303 5B
Q305 7F
Q306 7F
Q400 3C
Q401 3B
Q402 3C
Q403 3C
Q404 3C
Q405 3C
Q905 3E
Q906 3E
Q907 4E
Refer to the schematic diagram for the values
of resistors and capacitors.

KDC-MP4028/MP428/MP6029
14
KLMNO
1
2
3
4
5
6
7
C957
R932
R937
R432
R920
C2
R5
R22
R947
R945
R
R
R951
C202
C206
C207
C209
L201
R210
R212
R224
R227
R228
R234
R235
R313
R11
C110
R316
R317
R318
R319
R336
R314
R315 C205
C320
C404
R12
R104
B
EB
E
R202
R203
R207
R215
R229
R230
R236
R237
R244
R246
R249
R250
R254
R927
R935
C19
C302
C303
C301
SCL
SDA
R952
R27
R106
R127
R261
R337
R520
REMO
DATA
CLK
CE
R521
R522
R523
R921
R922
R924
R926
R950
R942
R944
R941
R943
R14
R15
R13
R31
43
21
BE
D2
Q103
D201
D503
D504 D507
D508
D509
D510
D903
D10
Q12
D102
D104
Q101
IC7
ELECTRIC UNIT X34-338x-xx (J76-0039-12)
PC BOARD (FOIL SIDEVIEW)

KDC-MP4028/MP428/MP6029
15
TSRQP
1
2
3
4
5
6
7
L303
R321
R432
R947
R945 R948
R946
R951
R949
C305C309
L304
C304
L302
C307
R332
R339
C321
C404
C429
R30
R422
R425
W14
C406
C407
C413
C414 C426
C427
C510
C511
2
R301
R302
R303
R304
R305
R306
R307
R308
R309
R310
R320
R326
R338
R401
R423
R424
R433
R434
R508
R509
R510
R511
R512
R513
R514
R515
R516
R517
R518
R950
R942
R944
R941
R943
C423
C424
BE
BE
BE
BE
BE
Q300
Q115
Q116
D301
D310
D405
D406
D408
D409
D410
D513
D514
D515
Q301
Q304
D305
D306
D307
D308
D500
X34-338x-xx
Ref. No. Address
IC7 5N
Q12 6M
Q101 3N
Q103 3N
Q115 4P
Q116 4Q
Q300 4Q
Q301 4Q
Q304 7Q
Refer to the schematic diagram for the values
of resistors and capacitors.

KDC-MP4028/MP428/MP6029
16
UVWXY
1
2
3
4
5
6
7
X32-5740-00
Ref. No. Address
IC2 4V
IC11 4V
C30
C39
C50C57
C79
C91
C52
C32
C1 C2
C56
C34
C58
C31
C63
CP2
R41
R44
R42
R43
R57
R48
C25
C55
C64
C65
C66
C67
CP27
C24
C6
C5
CP13
X1
X2
C3 C4
C7
C8
R5 R6
R30
R56
R31
R3 R4
R8
R7
R11
R12
R1
R2
R9
R10
CP5
CP4
CP12
CP1 W20
W21
R150
R151
C101
1
1
2021
40
4
58
45
13
S1
S2
S3
S4
IC8
IC2
IC11
CD PLAYER UNIT X32-5740-00 (J76-0065-12)
PC BOARD (COMPONENT SIDEVIEW)
Refer to the schematic diagram for the values of resistors and capacitors.

KDC-MP4028/MP428/MP6029
17
ADACABAAZ
1
2
3
4
5
6
7
X32-5740-00
Ref. No. Address
IC1 3AC
IC3 5AA
IC4 4AC
IC5 4AB
IC6 3Z
IC7 3AB
Ref. No. Address
Q1 3AC
Q4 2AA
Q5 5AC
Q6 5AC
Q7 4AC
Q8 4AC
CN2
Q7
Q5
CN1
D1
Q6
Q8
Q4
Q1
IC4
IC9
IC5
IC6
IC7
IC3
IC1
CD PLAYER UNIT X32-5740-00 (J76-0065-12)
C35
C46
C61
C71
C60
C40
C80 C75
C38
C62
C53
C54
C41
C78
R49
R52
R40
R50
R51
R55
R78
R88
R25
C43
C85
C10
C90
R72
R74
R79
R89
R90
R92
C21
C22
R23
R22
R20
C9
C12
C42
W1
C51
C68
C11
C72
C83
C69
C70
C73
C82
C81 C74
CP6
CP7
R91
R16
R14
R15
C77
C76
C20
C23
R71
R29
R70
R80
R81
R21
R28
R27 R26
R24
R75
CP28
CP11 CP8
CP10 CP9
R112
R113
R100
R101
R103
R104
R102
C100
R93
1
16
1
1
1
5
8
4
1
1
5
4
1
5
24
1516
30
5
13
2551
75 76 100
2650
4
31
36
73108
109
144 37
72
EB
EB
EB
EB
EB
EB
F
EVREF
DOUT
IOP-
LOS-SW
DGND
LOE/LIM
SLD+
BU5V
Lch
MDSD
TD
TE
8EJE-SW
SPD-
SPD+
SD
TD FD
MD
ARF
RF
FD
EFM
T+
T-
F-
F+
DGND
LD
Rch
CLK
DATA
A8V D3.3V
SGND
AGND
S7.5V
D5V
MUTE-R
MUTE-L
MSTOP
MRESET
ASY
ATEST
GND
IOP+
REFOUTSV
RESET
ADIN
FE
TEC
SHOCK
FZC
TZC
RZM LZM
DOUT
LOCK
MIRR
HOLD
SRDATA
BCK
LRCK
DMUTE
X2
BU3.3V
WAIT
XT1
PON1
PON2
BU5V
SDA CP14
SCL
SI
SCK0
SI0
SO0
SO
AAC
DGND
MRESET
DGND
MOTOR
LO/EJ
12EJE-SW
ASEL
E2P
INTQ
SLD-
TO1
TO2
TO3TO4
LOE/LIM
VPP
MSTOP
TI3
TI1
TI2
TI0
AGND
VR
PD
B
A
K24
A3.3V
C
TYPE
RAM
X1
PC BOARD (FOIL SIDE VIEW)
Refer to the schematic diagram for the values of resistors and capacitors.

KDC-MP4028/MP428/MP6029
18
AE AF AG AH AI
1
2
3
4
5
6
7
C13
C14
C15
DISP
RESET
FM
AM
6542
1
SRC
68 24
231
Q
VOL
ATT
AUD
3
C16
C17
VCC
VO G
D25
D26
D1
D2
D3
D4
D5
D6
D7
D8
D9
D10
D11
D12
D13
D14
D15
D16
D17
D18
D19
D20
D21
D22
D23
D24
P1
S1 S2
S10
S27
ED1
IC2
SWITCH UNIT
X16-291x-xx (J76-0040-32)
CP12
CP13 C19
C20
C8
C10
C11
CP10
CP11
R1
R2
R3
R4
R5
R6
R7
R8
R9
R10
R11
R12
R13
R14
R20
R51
R52
R53
R54
R55
R56 R57
R58
R59
R70
R15
R73
R74
R75
E
B
EB
EB
80
1
20
21
40
41
60 61
KI5
KS1
KS2 KI1
KI2
SW5V
KS4
ILL D GND
PAN5V
INH
ILL+B
CW
RST
CLK
DI
CE
FL+B
KI3
CNDET
CCW
GND
ESD
DO
REMO
KI4
KS3
115
214
D110
Q4
Q10
Q11 D104
D103
D105
D101
D108
D107
D106
D109
J1
IC1
SWITCH UNIT
X16-291x-xx (J76-0040-32)
X16-291x-xx
Ref. No. Address
IC1 4AH
Q4 4AH
Q10 3AH
Q11 3AH
X16-291x-xx
Ref. No. Address
IC2 2AF
PC BOARD
(COMPONENT SIDE VIEW) (FOIL SIDEVIEW)
Refer to the schematic diagram for the values
of resistors and capacitors.

KDC-MP4028/MP428/MP6029
19
ABCDE
1
2
3
4
5
6
7
P1
D405
D301
D406
D511
Q16
D409
∗D410
D408
D411
D500
S3
Q300
S4
Q302
Q303 Q299
Q13
Q14
Q15
Q304
Q301
Q405
Q404
Q115Q116
D403
D307
D309 D308
CN1 J4
SUB WOOFER AUX
∗A1
W1
J2
R
REAR
R
L
L
FRONT
J3
CD MECHA
4V PRE+B
∗CN4
Q402
Q403
Q401
Q400
D512
D513
D514
D515
D402
D401
D303
TUNER8V
D302
DSI
D306 D305 D304 D310
∗A
∗D9
FILP
DET EJECT SW
∗C
∗B
FRONT-END
TUNER
2/2 X16-
J1
E-VOL
PREOUT MUTE DRIVER
AM+B
PREOUT
SW
TUNER
8V SW
DSI
DRIVER
4V PRE+B
(SHORT PR
O
PANEL
5V
TP48
TP85
TP56
TP99
TP49
TP98
TP39 TP32 TP47
TP89
TP60
TP92
TP40 TP34 TP31 TP64 TP41 TP58
TP83
TP46 TP62
TP88
TP43 TP37 TP52 TP57 TP36
TP97
TP59
TP82
TP102
TP87
TP86
TP44 TP63 TP29 TP61 TP50 TP33
TP101 TP93
TP51
TP38 TP42
TP84
TP100
TP96
TP94
TP55
TP110 TP119 TP120
TP27
TP109
L301
TP1
2
TP130
48 47 46 45 44 43 42 41 40 39 38 37 36 35 34 33
32
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
1
2
3
4
5 6
7
8 9
10
11
12
13
14
15 16
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
PREF
PGND
LDOUT1L
LDOUT1R
LDOUT2L
LDOUT2R
GND
VCC
ACIN0L
ACIN0R
ACIN1L
ACIN1R
ACIN2L
ACIN2R
ACIN3L
ACIN3R
ACOUTR
ACOUTL
MUTE2
MUTE1
MUTE0
REF3V3
VOLINR
VOLINL
REF5V5
SAIN
SAOUT
SARES
SACLK
SCL
SDA
SEL
CDCHL CDCHCOM CDCHR AUXL AUXCOM AUXR MUXAL MUXAR MUXBL MUXBR MUXCL MUXCR WININ WINTC0 WINTC1 DCERR
LDOUT0R
LDOUT0L
VP
PAOUT1R
PAOUT1L
PAOUT0R
PAOUT0L
MUTEC
MUTEB
MUTEA
TUNERL
TUNERR
CDL
CDR
MDL
MDR
24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 987654321
D OUT
12EJE SW
LOS SW
MS CLK
MS DATA
AUDIO 8V
L ch
A GND
R ch
MUTE R
MUTE L
M RST
M STOP
8EJE SW
LOE/LIM SW
BU 5V
D GND D GND
D5.0V D5.0V
LO/EJ
MOSW
SERVO +B
SERVO GND
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
ESD
FLIP DET
RTRY CCW
REMO
VFD SYS
VFD CL
VFD CE
DATA
VFD INH
RST
ILL+B
FL+B
RTRY CW
PAN5V
ILL D GND
4
5
OUT
VCC
3
2
1
IN-
VEE
IN+
1
C409
1
C408
1K
R441
1K
R440
C436
1500P
0.01
C410
∗W15
47u16
C401
10u16
C431 10
R431
10u16
C412
47u16
C16 2.2
R29
2.2
R28
1K
R26 1
K
R
2
22u16
C15
22u16
C422
360
R410
360
R411 22u16 C421
R508 4.7K
R509 100
R510 4.7K
R512 100 R513 100 R514 100 R515 100
10
R516
0.47
C510
4.7
R518
0.47
C511 10
R517
47u6.3
C512
10u16
C322
10u16
C306 1K
R320
10u16
C308
W931
R322 470
R324 470
4.7K
R323
4.7K
R325
2.2K
R326
0.01
C309
47u35
C310
100u16
C312
C311 0.01
10u16
C313
680
R327
240
R332
8.2
R801
47K
R20
10K
R21
R337
1K
R339C321
0.01 470K
1K
R302
1K
R309
100
R308
100
R307
1K
100
470 0.01
R318 100K
470 0.01
R313 4.7K
∗R314 100K
0.01470
R316 100K
R311
C407 3.3
C404
R401
C406 3.3
100
100
100P
C423
100P
C424
C414 0.47
10
R932
C402 1u50
1u50
C403
4.7u50
C405
47u16
C411
R415 180
R414 180
∗R417 180
∗R416 180
∗R420 180
∗R421 180
∗R418 180
∗R419 180
R425 1K
1000P
C802
5.6
R802
IFGND
15
8
L
IF+B 2
1
R4
3
STDGND
6
RDSMUTE 5
MPX
DGND2 7
PLLGND
AMIFOUT
QUALITY 9
SMETER 11
10
13
12
14
22
17
16
18
20
19
21
24
23
26
25
VDD5V
DGND1
SCL
SDA
IFC
COM+B
VT
RFGND
FMANT
AMANT
AM+B
OSCGND
TP66
TP113
TP67
TP68
TP114TP69
TP70 TP115
TP71 TP116
TP72
TP73 TP117
TP74
TP75
TP118TP76
TP77
TP78
TP79
2
1
3
TP65
TP128
4.7uH
L302
L303
4.7uH
L304
4.7uH
22
93
95
21
27
28
19
10
12
11
B.U.
GND
A GND
CON
REQ M
Rch
Lch
37
84
62
519
CHCLK
DATA M
RST
DATA S
REQ S
13
∗R315 ∗C301
R319 C303
R317 C302
51
48
47 33
34
50
49
54
53
52
56 55
1K
R428
3.3K
R30
220
R27
R24 51K
0.01
C304
0.01
C307
22K
R321
0.01
C305
2
1
3
10
R424
4.7
R422
10
R423
0.47
C426
0.47
C427
47u6.3
+
C428
0.01
C429
∗W14
22K
R413
22K
R412
22K
R408
R406
360 C420 22u16
22K
R409
R407
360 22u16
C419
R404
22K
360
R402
360
R405
22K
R403
22u16
C418
22u16
C417
TP90 TP91
0.01
C513
1K
R519
CH-R
CH-G
CH-L
MUTE
R511 100 TP95
99 98
100
18
90
81
2
20
PR-RR
PR-RL
PR-FR
PR-FL
PRN-FL
PRN-FR
PR-RR
PR-RL
PRN-FR
PRN-FL
PR-FR
PR-FL
RL
FL
FR
RR
0.47
C413
R433
R434
C415
2.2u50
2.2u50
C416
CH-G
CH-R
CH-L
AU-L
AU-G
AU-R
AU-L
AU-G
AU-R
10K
1
89
M-L
S-L
S-R
M-R
C435
1500P
S-L
S-R
M-L
M-R
4
3
5
86
85
84
36
71
R338
470K0.01
40
1K
C320 R336
16
46 29
44
31
32
30 35
45
R304
R303
R301
100
R306
100
R305
100
9.1 1W
R31
R310
100
1
4
BU
BU5V
BU5V
BU5V
8V
BU5V
CD5V
SERVO+B
SW5V
ILL+B
BU5V
CD5V
91
8V
2.2
R432
BU5V,B
3.3V
VFD PAN
DATA
Q300,301
Q400-405
Q
Q14
Q15,16
Q13
+ +
+
+
++
++
+
+
+
+
+
+
+
+
+
+
+
++
+
IC2
IC11
ELECTRIC UNIT (X34-338x-xx)
A
22K
22K
4.7K
4.7K
4.7K
4.7K
4.7K
4.7K
22K
22K
22K
22K
47K
10K
22K
22K22K
22K
4.0V 4.0V 4.0V
0V
5V
0V
5V
5V
0V
4.0V
3.5V
8.0V
0V
5.6V
8.0V 5.6V
5.6V 5.6V
0V
4.0V
3.5V
3.3V
5.5V
4.0V
4.0V
4.0V
4.0V
4.0V
4.0V
12.0V
4.0V
4.0V
4.0V
4.0V
3.5V
4.0V
4.0V
X34-338x-xx (1/3)

KDC-MP4028/MP428/MP6029
20
FGHIJ
X34-338x-xx (2/3)
Q103
D501
Q101
D502
D110
Q305
Q104
Q110
4
Q15
Q109
Q112
Q102
Q106
Q105
Q108
Q306
0
3
D103
D104
D101
D102
D105
D107
D108
D109
Q111
D111
D407 D8
D509 D510 D503
D504
D506 D505 D508
D507
0
2
0
1
3
10
SW
ILL+B
D201
SYSTEM u-COM
POEWR
IC
POEWR
SUPPLY
4V
PREOUT
4V PRE+B
(SHORT PROTECTION)
RESET IC
ACC DET
SMALL
DET SW
LAMP
B.U.
DET SERGE
DET
P-ANT
SW
P-CON
SW
P-CON
PROTECTION
A
NEL
V
1/2W
TP123
TP126
TP108
CP209
100
TP121
TP107
TP28
TP124
TH1
470
TP103
X1
32.768kHz
TP127
CP207
1K
CP206
2.2K
CP201
100
CP203
470
X2 12.00MHz
CP204
1K
TP125
100 99 98 97 96 95 94 93 92 91 90 89 88 87 86 85 84 83 82 81 80 79 78 77 76
75
74
73
72
71
70
69
68
67
66
65
64
63
62
61
60
59
58
57
56
55
54
53
52
51
26
27
28 29 30
31
32
33
34
35 36
37
38 39 40
41
42
43
44
45 46
47
48 49 50
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
LX CLK
LX DATA M
LX DATA S
AVCC
VREF
TUN SMETER
AVSS
RDS NOISE
NC
MUTE C
LX RST
DC DET
NC
LINE MUTE
MUTE2
MUTE1
MUTE0
MUTE PRE L
MUTE PRE R
LX CON
PWIC STBY
PWIC MUTE
(PWIC SVR)
ACC DET
BU DET
ILLUMI DET
ANT CON
KEY REQ
P CON
EJECT
OEM DISP CE
OEM DISP CLK
OEM DISP DATA
TUN TYPE2
TUN TYPE1
TYPE3
TYPE2
TYPE1
VSS
NC
VCC2
PON
PON PANEL CD
PON ILLUMI
CD MOTOR
CD LOEJ
CD LOE LIM SW
CD DISC8 SW
CD MSTOP
CD MRST
PWIC BEEP TUN SCL TUN SDA VFD SYS DATA VFD PAN DATA VFD CL VFD INH SDA SCL PON PAN DSI NC NC EPM PANEL DET NC ROMCOR DET NC VFD CE ROTARY CW ROTARY CCW CD DISC12 SW CD LOS SW CD MUTE R CD MUTE L
REMO
LX MUTE
AUD SDA
AUD SEL
AUD SCL
BYTE
CNVSS
XCIN
XCOUT
RESET
XOUT
VSS
XIN
VCC1
NMI
CN DET
NC
LX REQ S
PON AM
LX REQ M
TUN IFC OUT
RDS AFS L
RDS AFS M
NC
NC
3
2
1
N
-
E
E
N
+
R202
2.2K
R203 100K
R262 47K
R207 10K
R208 10K
R215 100K
22P
C204
22P
C203
0.01
C206
100K
600
R263 R259
1000P
R254 47K
33K
R253 2.2K
2.2K
R258
1K
R204
0.01
C209
2.2K
R257
0.01
C202
47u6.3
C201
R250 47K
R249 47K
∗R246 47K
∗R244 47K
0.01
R241 2.2K
R240 100
R239 2.2K
∗R238 2.2K
∗R243 47K
∗R245 47K
47K
R210 47K
R211 1K
R216 1K
R218 1K
R219 1K
R220 22K
R205 10K
R233 100
R224
R227 4.7K R228 4.7K
R229 47K R230 47K
R234 3.9K R235 3.9K
R236 47K R237 47K
1K
R110
22K
R109
100K
R114
1
C106
W998
22K
R112 47K
R113
0.022
C105
1W
470
R105
4.7K
R104
33K
R127
1/2W
3.3K
R126
10K
R119
470K
R120
100
R121
0.01
C108
10K
R122
100K
R124
10K
R128
22K
R125
10u16
C412
1K
R26 1K R25 1K R23
1W
22
R22
22u16
C15
100u16
C14
∗R520
∗R521 470
∗R522 470
∗R523 470
R947 10K R945 10K
10
R951 100u10
C999
3K
R503
1
C507
4.7u16
C529
22K
R505
R506 22K
R507 220
39K
R116 68K
R115
100K
R118
2.2K
R311
47K
R312
0
9
32
1u50
5
0
4
03
u
50
4
05
47u16
C411
1000P
C802
2
OFFDET
2
OUT1+ OUT1- OUT2+ OUT2-
8 6
4
10
TAB1 1
9 7 5 3
STBY
PWGND1
PWGND2
VCC1
OUT3+ IN1
12
18
SGND IN3
14
16
OUT3-
20
SVR 11
IN4
IN2
PWGND3
ACGND 17
15 13 19
OUT4+
22
OUT4- HSD
24
26
VCC2 21
PWGND4
MUTE
TAB2 27
25 23
R247 47K
22K
R106
R107 4.7K
3.3u50
C101
+
1K
R108
1
C102
0.1
C103
C104
0.01
20K
R117
10K
R123
1000P
C107
0.01
C109
1K
R428
4.7K
R427
2.2K
R426
47K
R429
220
R24 51K
W3
FR-
FR+
FL-
FL+
R501 1K
C503
4.7u16 470
R941
C504
4.7u16
470
R942
4.7u16
C506
470
R944
C505
4.7u16 R943
470
FL
RL
RL+
RL-
RR+
RR-
1
C501
10K
R946
10K
R948
FR
RR
10K
R949
4.3K
R950
+
430
R952
51
R953
M-L
M-R
86
85
84
R201
1K
2.2M
1K
CP208
C207
55
53
54
56
52
51
75
72
74
26
87
80
79
77
76
81
83
82
84
85 86
C208
89 93 95 90
98 99
100
91
47K
100K
4.7uH
L201
CP202 100
30
27
28
29
31
32
33
34
35 36
50
40
44
45 46
47
48 49
R212
3
5
4
21
22
19
18
20
L202
R260
2
ILL+B
91
72
87
75
77
76
BU5V,BU,8V
BU
3.3V
3.3V
13
BU5V
BU
80
79
26
BU5V
SW5
16
3
4VSS
NC
OUT
VDD 2
1
0.1
TP122
C205
74
TP104
TP106
TP105
TP129
71
47K
R261
Q305,306
Q
14
1/2W
Q104,105
Q103,106
3
+
+
+
+ +
IC1
IC4
IC7
47K
10K
10K
10K
47K
10K
47K
47K
47K
47K
0V
5V
5V
0V
0V
5V
0V
5V
0V
0V
0V
5V
0V
5.0V
5.0V 0V 5V
0V
5V
5V
0V
0V
5V
0V or 3.5V
0V or 3.5V
0V
5V
0V
5V
5V
0V
0V
5V
0V
5V
0V
5V
0V
0V
0V
5V 0V
5V
5V
0V
0V
5V
5V
0V
0V
5V 5.0V
0V or 5.0V
5.0V
0V
5V
0V
5V
0V
0V
5V 5V
0V
5V
0V
0V
5V
5V
0V
0V or 1.6V or 5.0V
0V
3.5V
0V
5V
5.0V
0V
0V-5.0V
5V
0V
0V
5V
0V
0V
5V
14.4V
0V
0V
14.4V
0V-4.4V
0V
6.8V
5.6V
0V
5V
0V
6.8V
6.8V
6.8V
6.8V
6.8V 6.8V
6.8V
6.8V
6.8V
6.8V
0V
5V
0V
5V
0V
5V
0V
5V
0V
0V
5V
0V
5V
or 5.0V
0V
0V
5V
5.0V
5V
0V
5V
0V
0V
