CD RECEIVER
KDC-MP4032
SERVICE MANUAL
VOL
AUD
SET UP
SCAN RDM REP
Q MENU
M.RDMF.SEL
KDC-MP4032
FF
AM
FM
SCRL
AUTO
AME
s
/ C.S.
DISP
SW
Panel assy
(A64-3753-01)
SPARE TDF PANEL
MAIN UNIT NAME TDF PARTS No. TDF NAME
KDC-MP4032 Y33-2400-60 TDF-MP64DB
Mounting hardware assy
(J22-0011-03)
Lever
(D10-4589-04) x2
DC cord
(E30-6428-05) Screw set
(N99-1757-05)
Escutcheon
(B07-3125-01)
Carrying case
(W01-1661-05) Remote controller assy (RC-517)
(A70-2069-15)
Battery
(Not supplied)
Mounting hardware (R)
(J22-0259-04)
Mounting hardware (L)
(J22-0258-04)
Screw set
(N99-1780-05)
This product uses Lead Free solder.

KDC-MP4032
2
BLOCK DIAGRAM
FRONT-END
LX-BUS
E-VOL
IC2
CD
BU5V D5V
PREF
PRE+B
A8V
SYSTEM u-COM
BU
POWER SP-OUT
LOGIC
Q402-405 PRE-OUT
PHONE
ACC-DET
Q112
DIMMER
Q108
SURGE-
Q109,110
BU5V
IC12
PCON-SW
Q1,2
Q103,106
BU-DET
Q111
4V
Q15,16
IC5
SW14V
Q4,9
SW5V
Q103,106
ANT-CON
Q101,102
Q7,8
TUNER
Q302,303
A8V
IC3
DC-CN
TUN8V
A8V
PRE+B
SERVO+B
D5
BU5
SW5
8V
PRE+B
CD5V
DET
MUTE
BU
DC-CN etc
SW
EJECT BU5
PAN5V
FLIP-DOWN
DET
RESET
IC7
ILLUMI+B
CN
RESET ENCODER
ROTARY
REMOTE SW5V ILLUMI
KEY
MATRIX
KEY
VFD
IC1
SW5 Q4
Q12-14
PAN5
IC4
IC2
J1
PREF 1/2VCC
For 4VPRE
IC11
+B
ILLUMI
ILLUMI+B ILLUMI
SW
Q305,306
AM+B AM+B
Q300,301
S1
Q10,15
ED1
D5V
J3
MUTE
IC6
J2
TUN8V
AM+B
SW5
W1
A1
SERVO+B
A8V
S4
BU5
BU5
EJECT & DSI
ILLUMI
Q304Q13
BU5
BU5
BU5
J1
DME1
MARINE DISP
OPEL DISP
BU5
SW5
CD
SERVO
BU5
BU5
BU5
AUX
CN4
IC
+B
to GND
DET
to GND
FLIP-DOWN
SW
GRID
S3
J1
713
2
10
1REAR L/R
FRONT L/R
FRONT/REAR/NF
SW5
P.ON CD
ANT CON
P CON
BU DET ACC
ILLUMI
PHONE
P-ANT
P-CON
B.U.
MUTE DC-DET
PHONE
ACC DET
DIMMER
1
1
2
RST
PHONE
DIMMER / ACC DET
P CON / PON
BU DET / ANT CON
PON CD / PON ILLUMI
9
5
9
P.ON
P.ON
P.ON
P.ON
P.ON ILLUMI
AM+B
SELECT
COLOR
BU DET
Q111
Q114
1
1
3
MUTE
38
12
3
ONLY LAND
NF L/R
ELECTRIC UNIT (X34- )
SWITCH UNIT (X16- )
CD PLAYER UNIT (X32-586x-xx)
(X34- )
BOARD
MOTHER
EF
ACB
TR COIL
FO COIL
DPU1
APC
IC7
16.934MHz
CLOCK
IC3
LPF
IC2
SW
A3.3V REG
IC1
LOADING &
MECHA
u-COM
IC4
CLOCK
16.00MHz
RF AMP
SERVO
MP3 DECODER
WMA DECODER
1Mbit SRAM
PROCESSOR
D3.3V REG
IC6
MOTOR
DRIVER
MOTOR
SPINDLE
BU3.3V REG
IC5
S2
S4
S1
S3
AAC DECODER
SLED
MOTOR
DM2
DM1
Q4
X2
X1
Q7,8
0-01 ONLY
IC10
4Mbit
DRAM
+
+
+
+
+
1.6V REG
VREF
D.GND
BU5V
8EJE-SW
12EJE-SW
LOS-SW
LOE/LIM-SW
D.GND
D5.0V
MOTOR
LO/EJ
S.GND
D.GND
D.GND
S.GND
DATA
MUTE R
MUTE L
MSTOP
MRST
CLK
A.GND
A8V
R-ch
L-ch
D.GND
S.GND
D.GND
D.GND
D.OUT
S7.5V
DMUTE
D.GND
P-ON1
P-ON2

KDC-MP4032
3
COMPONENTS DESCRIPTION
●ELECTRIC UNIT (X34-4180-10)
Ref. No. Application / Function Operation / Condition
IC1 System µ-COM Controls FM/AM tuner, the changer, CD mechanism, panel, volume and tone.
IC2 E-VOL Controls the source, volume, tone.
IC3 A8V Ref Power Supply Outputs 1.27V.
IC4 Power IC Amplifies the front L/R and the rear L/R to 50W or 47W maximum.
IC5 ILL+B Power Supply Outputs 11.25V.
IC6 Muting logic IC Controls logic for muting.
IC7 Reset IC “L” when detection voltage goes below 3.6V or less.
IC11 4V preout Power Supply Outputs reference voltage for 4V preout.
IC12 SW Regulator Power supply for CD mechanism andVFD.
IC902 SVR & 3.3V Supply Outputs SVR voltage and 3.3V.
Q1,2 B.U.5V AVR While BU is applied, BU5V AVR outputs +5V.
Q3,11 SW5V When Q11’s base goes Hi, SW5V outputs +5V.
Q4,9 SW14V When Q9’s base goes Hi, SW14V outputs 14V.
Q5,6 AUDIO8V AVR When Q6’s 2nd pin goes Hi, A8V AVR outputs 8.0V.
Q7,8 SERVO+B AVR When Q8’s base goes Hi, S+B AVR outputs 7.5V.
Q12 SW for IC12 When Q12’s base goes Lo, IC12 is turned on.
Q13 PANEL5V When Q13’s base goes Lo, PANEL5V outputs 5V.
Q14 4V PRE+B If Q15’s emitter is short-circuited to GND, Q14’s emitter goes to GND, then between Q14’s
Short-circuited Protection base and emitter have more than 0.6V, and Q14 is turned on and Q15 is turned off.
Q15,16 4V PRE+B When Q15’s base goes Hi, 4V PRE+B outputs 12V.
Q101,102 P-ANT SW When Q102’s base goes Hi, P-ANT SW outputs 14V.
Q103,106 P-CON SW When Q106’s base goes Hi, AVR outputs 14V.
Q104,105 P-CON Protection Sets output protection when P-CON output is grounded.
Protects Q103’s malfunction when P-CON SW is turned on.
Q108 Small Lamp Det SW When Q108’s base goes Hi, Q108 is turned on.
Q109,110 Serge Det. When Q109’s base goes Hi, IC4 is changed into STANDBY source.
Q111 BU Det When Q111’s base goes Hi, Q111 is turned on.
Q112 ACC Det When Q112’s base goes Hi, Q112 is turned on.
Q113 Mute-Driver When a base goes Lo, preout mute driver is turned on.
Q114 Mute-Driver Q114 is turned on by RST.
Q115,116 Preout mute driver When a base goes Lo, mute driver is turned on.
Q299 Tuner8V SW When Q299’s 2nd pin goes Hi, Tuner8V outputs 8V.
Q300,301 AM+B When Q301’s base goes Hi, AM+B is output.
Q302,303 Tuner8V When Q303’s base goes Hi, Tuner8V outputs 8V.
Q304 DSI Driver DSI lights when the base is “H”. DSI turns off when the base is “L”.
DSI turns on and off when panel is taken off.
Q305,306 SW ILLUMI+B When Q306’s base goes Hi, SW ILLUMI+B outputs 11V.
Q400~405 Preout mute SW When a base goes Hi, Preout is muted.
Q905~907 SVR+B Supplies SVR voltage from the outside.

KDC-MP4032
4
●SWITCH UNIT (X16-3490-10)
Ref. No. Application / Function Operation / Condition
IC2 Remote Control IC
Q4,5 SW5V The base of Q4 goes “L” when the base of Q5 is “H” and the power supply of IC2 is turned on.
Q12 GRID1 SW When the base of Q12 is “L”, the current is supplied to G1.
Q13 GRID2 SW When the base of Q13 is “L”, the current is supplied to G2.
Q14 GRID3 SW When the base of Q14 is “L”, the current is supplied to G3.
Q20 Key Scan Start SW Key scan starts when the base of Q20 goes “H”.
●CD PLAYER UNIT (X32-5860-00)
Ref. No. Application / Function Operation / Condition
IC1 A3.3V regulator Power supply for audio 3.3V
IC2 Ope amp for low-pass filter
IC3 4ch BTL driver Driving spindle motor and loading/ejection operation
IC4 Mechanism µ-com
IC5 BU 3.3V regulator Power supply for backup 3.3V
IC6 D3.3V regulator Digital 3.3V power supply
IC7 Audio DAC built-in servo DSP MP3, WMA, and AAC compatible
IC11 Buffer IC Level shift
Q1 A3.3V discharge circuit
Q4 Current amp Adjusts current to be sent to laser
Q5,6 SW 5V
Q7,8 SW 8V
D1 For current amp
COMPONENTS DESCRIPTION

KDC-MP4032
5
MICROCOMPUTER’STERMINAL DESCRIPTION
●SYSTEM µ-com: IC1 on X34- (ELECTRIC UNIT)
Pin No. Pin Name I/O Application
Truth Value
Processing / Operation / Description
Table
1 REMO I Remote control signal input Detects pulse width
2LX MUTE I Mute request from slave unit H: MUTE ON, L: MUTE OFF
3AUD SDA O E-VOL data output
4AUD SEL O E-VOL control
5AUD SCL O E-VOL clock output
6BYTE -
7CNVSS -
8XCIN I
9XCOUT I
10 RESET -
11 XOUT -
12 VSS -
13 XIN - 12.0MHz
14 VCC1 -
15 NMI I Not used
16 CN DET I Panel communication detection H: PANEL detached, L: PANEL attached
17 NC - Not used Outputs L fixed
18 LX REQ S I Communication request from slave unit
19 PON AM I/O AM power supply control H:When AM, Hi-z:When not AM
20 LX REQ M O Communication request to the slave unit
21 TUN IFC OUT IFront-end IFC out input H: Station found, L:Station not found
22~25 NC - Not used Outputs L fixed
26 PWIC BEEP O Beep output
27 TUN SCL I/O Front-end I2C clock input/output MAX 400kHz
28 TUN SDA I/O Front-end I2C data input/output
29 VFD DATA I/O VFD data input/output Data input/output
30 VFD INT I VFD INT input INT input
31 VFD CLK O VFD clock output Normal: 125kHz, Low consumption mode: 62.5kHz
H: Clear reset, L: RESET
32 VFD RST O VFD driver reset L: Momentary power down, panel detached, or 11 minutes
after ACC OFF
33 SDA ROMCOR SDA I/O E2PROM I2C data input/output for
ROM correction
34 SCL ROMCOR SCL I/O E2PROM I2C clock output for
ROM correction
35 PON PANEL I/O Panel 5V control L:ON, Hi-z: Momentary power down, panel detached,
or 11 minutes after ACC OFF
36 DSI I/O DSI/EJECT LED control Hi-z: OFF, Pulse drive:When PANEL detached,
H: ILLUMI ON or PANEL OPEN (when Power ON)
37,38 NC - Not used Outputs L fixed
39 EPM I FLASH EPM input

KDC-MP4032
6
Pin No. Pin Name I/O Application
Truth Value
Processing / Operation / Description
Table
40 PANEL DET I Panel detection L: PANEL detached, H: PANEL attached
41 NC - Not used Outputs L fixed
42 ROMCOR DET I E2PROM writing-in request H:Writing-in
43 NC O Not used Outputs L fixed
44 VFD CS O VFD chip select control
45 ROTARY CW IVOL key input Detects pulse width
46 ROTARY CCW IVOL key input Detects pulse width
47 CD DISC12 SW I12cm disc detection
48 CD LOS SW I CD loading detection
49 CD MUTE R I Rch CD mute request H: Normal, L: Rch MUTE request
(valid only when in CD mode)
50 CD MUTE L I Lch CD mute request H: Normal, L: Lch MUTE request
(valid only when in CD mode)
51 CD MRST O CD mechanism µ-com RESET H: Normal, L: Reset
52 CD MSTOP O CD mechanism µ-com stop H: Mechanism µ-com in operation,
L: Mechanism µ-com stopped
53 CD DISC8 SW I8cm disc detection (not used)
54 CD LOE LIM SW ICD detection (chucking SW) H: Loading completed, L: Disc not found
55 CD LOEJ I/O CD motor control qRefer to the truth value table
56 CD MOTOR O CD motor control qRefer to the truth value table
57 PON ILLUMI I/O Key illumi power supply control ON: H, OFF: Hi-z
58 PON CD O Power supply control for CD/WMA L: POWER ON, H: POWER OFF,
H:When resetting before M-STOP
59 PON O Power supply control POWER ON: H, POWER OFF: L
60 VCC2 -
61 NC - Not used Outputs L fixed
62 VSS -
63 TYPE 1 I Destination switching wRefer to the truth value table
64 TYPE 2 I Destination switching wRefer to the truth value table
65 TYPE 3 I Destination switching wRefer to the truth value table
66 TUN TYPE1 I Destination setting 1 eRefer to the truth value table
67 TUN TYPE2 I Destination setting 2 eRefer to the truth value table
68 OEM DISP DATA I/O External display data External display
69 OEM DISP CLK I/O External display clock External display
70 OEM DISP CE I/O External display control request External display
71 EJECT I Eject key input L: EJECT
72 P CON O External amplifier control POWER ON: H, POWER OFF:L, STANDBY Source: L
73 VFD KEY REQ I Communication request from VFD driver Connects to INT
74 ANT CON O Power antenna control TUNER ON: H
75 ILLUMI DET I Dimmer illumi detection L: ON, H: OFF
76 BU DET I Momentary power down detection L: BU found, H:BU not found or momentary power down
77 ACC DET I ACC power supply detection L: ACC ON, H: ACC OFF
MICROCOMPUTER’STERMINAL DESCRIPTION

KDC-MP4032
7
Pin No. Pin Name I/O Application
Truth Value
Processing / Operation / Description
Table
78 (PWIC SVR) O SVR discharging circuit H: For 5 seconds after POWER OFF momentary power
down, L:Thereafter
79 PWIC MUTE O Power IC mute L:While in STANDBY source or momentary power down,
L:While TEL MUTE
80 PWIC STBY O Power IC standby control POWER ON: H, POWER OFF: L
81 LX CON O Start-up request to slave unit H: Slave unit ON, L: Slave unit OFF
H:When CD MUTE R is R (while playing CD),
82 MUTE PRE R ORch pre-out mute H:When momentary power down,
Fixed to L only when 2 zone or NAVI interruption
H:When CD MUTE L is L (while playing CD),
83 MUTE PRE L OLch pre-out mute H:When momentary power down,
Fixed to L only when 2 zone or NAVI interruption
84 MUTE 0 I/O E-VOL front mute L: MUTE ON, Hi-z: MUTE OFF
85 MUTE 1 I/O E-VOL rear mute L: MUTE ON, Hi-z: MUTE OFF
86 MUTE 2 I/O E-VOL other mute L: MUTE ON, Hi-z: MUTE OFF
87 LINE MUTE I Line mute detection TEL MUTE: 1V or lower, NAVI MUTE: 2.5V or higher
88 NC - Not used Outputs L fixed
89 PWIC DC DET IDC offset error detection
90 LX RST O Forced-reset to slave unit H: Reset, L: Normal
91,92 NC - Not used Outputs L fixed
93 RDS NOISE I FM noise detection
94 AVSS -
95 TUN SMETER ISmeter input
96 VREF - Connects to P.ON
97 AVCC - Connects to VCC
98 LX DATA S I Data from slave unit
99 LX DATA M I/O Data to slave unit
100 LX CLK I/O LX-BUS clock
TruthValueTable
q: CD mechanism control operation
CD MOTOR CD LOEJ
Stop L L
Load H L
Eject H H
Brake H Hi-z
w: Destination
TYPE 3 TYPE 2 TYPE 1 MODEL
(Pin 65) (Pin 64) (Pin 63)
000KDC-MP4032
100KDC-MP6533
e:Tuner type
MODEL TUN TYPE1 TUN TYPE2
(Pin 66) (Pin 67)
KENWOOD brand model L L
OEM model 1 L H
OEM model 2 H L
OEM model 3 H H
MICROCOMPUTER’STERMINAL DESCRIPTION

KDC-MP4032
8
●MECHANISM µ-com: IC4 on X32- (CD PLAYER UNIT)
Pin No. Pin Name I/O Application Processing Operation Remarks
Description
1NC-Not used. Low-fixed
2E2P SCL I/O Rom correction E2P I2C clock
3~5 NC - Not used. Low-fixed
6VDD - 5V electric potential
7GND - GND electric potential
8,9 NC - Not used. Low-fixed
10,11 PON1,PON2 O Power ON/OFF control H : ON, L : OFF
12 LOE/LIM SW I Down-limit SW detection L : Lim detection
Used with DXM-6680W (X32-586).
13 DAC MUTE O DAC MUTE control H : MUTE ON, L : MUTE OFF With DXM-6580W (X32-574), open
and L-fixed.
Used with DXM-6680W (X32-586).
14 DAC RST O DAC RESET H : NORMAL, L : RESET With DXM-6580W (X32-574), open
and L-fixed.
H : Emphasis ON, Used with DXM-6680W (X32-586).
15 EMPH O External DAC Emphasis control L : Emphasis OFF With DXM-6580W (X32-574), open
and L-fixed.
16,17 NC - Not used. Low-fixed
18 IC/Vpp - Write voltage (FLASH) L : Normal operation,
H : In writing.
19 MUTE L O Lch audio MUTE control L : MUTE ON, H : MUTE OFF
20 MUTE R O Rch audio MUTE control L : MUTE ON, H : MUTE OFF
21 TYPE I DAC switching
H : DSP built-in DAC used, H : DXM-6580W (X32-574),
L : DSP built-in DAC Not used. L : DXM-6680W (X32-586)
22 TEST O 1 O TEST MODE O 1 (Not used.)
23 TEST O 2 O TEST MODE O 2 (Not used.)
24 TEST O 3 O TEST MODE O 3 (Not used.)
25 TEST O 4 O TEST MODE O 4 (Not used.)
26 NC - Not used. Low-fixed
27 WAIT I Wait control signal detection
28~30 NC - Not used. Low-fixed
31 RESET I Reset detection H : NORMAL, L : RESET
32 XT1 I Not used.
33 XT2 - Not used.
34 REGC -
35 X2 -
36 X1 I
37 Vss - GND electric potential
38 VDD - 5V electric potential
39 NC - NC Output stopped in standby 3.3V driven
40 WRL I Multiplex WRITE signal 3.3V driven
MICROCOMPUTER’STERMINAL DESCRIPTION

KDC-MP4032
9
Pin No. Pin Name I/O Application Processing Operation Remarks
Description
41,42 NC - Not used. Low-fixed 3.3V driven
43 RD O Multiplex RD signal 3.3V driven
44 ASTB O Multiplex ASTB signal 3.3V driven
45 NC - Not used. Low-fixed 3.3V driven
46 NC - Not used. Low-fixed 3.3V driven
47~54 AD0~AD7 I/O Multiplex address/data 3.3V driven
55 BVdd - BUS interface power supply
56 BVss - BUS interface GND
57~61 AB8~AB12 I/O Multiplex data/address 3.3V driven
62~65 NC - Not used. Low-fixed 3.3V driven
66 CS O Chip select control H : OFF, L : ON 3.3V driven
67 DSP RESET O DSP reset control H : NORMAL, L : RESET 3.3V driven
68~70 NC - Not used. Low-fixed 3.3V driven
71 Avdd -
72 Avss -
73 Avref I A/D port reference voltage input
74 NC - Not used. Low-fixed
75 RAMSEL I With DRAM/No DRAM switching H :With DRAM, L : No DRAM
for different models
76 RZM I 0bit MUTE detection H : ≥1.7V, L : <1.7V
77 LZM I 0bit MUTE detection H : ≥1.7V, L : <1.7V
78 AAC I AAC compatibility switching H : AAC non-compatible, AAC non-compatible mode has priority
L : AAC compatible for both hardware and software.
79 ASEL I Audio output polarity switching H : Reverse output,
L : Non-reverse output
80 E2P WR I E2PROM write switching H : E2PROM WRITE,
L : NORMAL
81 TEST I 0 I TEST MODE I 0 (Not used.)
82 TEST I 1 I TEST MODE I 1 (Not used.)
83 TEST I 2 I TEST MODE I 2 (Not used.)
84 TEST I 3 I TEST MODE I 3 (Not used.)
85,86 NC - Not used. Low-fixed
87 MSTOP I Standby restart interruption H : STOP release, L : STOP
88 INTSV I Interruption from servo IC H : Interruption
89~92 NC - Not used. Low-fixed
93 D-MUTE O Driver MUTE H : OFF, L : ON
94 SYS SDA I/O System µ-com I2C data Flash write port (SI0)
95 NC - Not used. Low-fixed Flash write port (SO0)
96 SYS SCL I/O System µ-com I2C clock Flash write port (SCK0)
97~99 NC - Not used. Low-fixed
100 E2P SDA I/O ROM correction E2P I2C data
MICROCOMPUTER’STERMINAL DESCRIPTION

KDC-MP4032
10
TEST MODE
●How to enter the test mode
Press and hold the [1] and [3] keys and reset.
(While “– – – –”is being displayed, power can be ON for 30
minutes.)
●How to clear the test mode
Reset, momentary power down, Acc OFF, Power OFF, de-
tach the panel.
●Test mode default condition
• Source is STANDBY.
• Display lights are all turned on.
• The volume is at -10dB (The display is 30).
• LOUD is OFF.
• CRSC is off regardless of the availability of switching func-
tion.
• SYSTEM Q is NATURAL (=FLAT).
• BEEP should always function when the key is pressed.
●Special display in tuner mode
Error is found in front-end, etc. if indications below are dis-
played while in tuner mode.
“TNE2P_NG” : Front-end E2PROM values are still default
(not determined).
“TNCON_NG” : Cannot communicate with the front-end.
●K3I forced switching
Every time when [6] key is pressed in tuner FM mode,
switched in the following order: AUTO →Forced WIDE →
Forced MIDDLE →Forced NARROW →AUTO. Default
status is AUTO, and displayed as shown below.
AUTO: FM1_98.1A
Forced WIDE: FM1_98.1W
Forced MIDDLE: FM1_98.1M
Forced NARROW: FM1_98.1N
●CD receiver test mode specification
• Display mode default setting shall be P-TIME.
• Jumps to the following tracks by pressing the [ ] key.
No. 9 →No. 15 →No. 10 →No. 11 →No. 12 →No. 13 →
No. 22 →No. 14 →No. 9 (recursive)
Note that when playing an MP3 / WMA / AAC disc with 8
files or less, the disc is played from the 1st track in the
normal order.
• Pressing the [ ] key goes back by 1 track from the track
being played.
• When playing an MP3 / WMA / AAC disc, display the file
format before starting to play each file. (“MP3”, “WMA”,
“AAC”)
• While in CD source, press the [1] key to jump to No. 28.
• While in CD source, press the [2] key to jump to No. 14.
• While in CD source, press the [3] key to display the CD
mechanism model name and the version. Press the [3] key
again to go back to the normal screen.(Time code display)
6680:0123
Model name Version
• When CD is the source, press the [6] key to jump to No.15.
At this time, the volume value is set to 27 (4V PRE).
●AUDIO adjust mode
• Press the [AUD] key and enter the audio adjustment mode.
• Press the remote control [∗] key and [AUD] key to go into
the audio adjustment mode.
• Both AUDIO FUNCTION MODE and SETUP MODE ad-
justment items are included.
•By pressing [AUD] key and then [FM] key, switch the item
to be adjusted in the following order. (Only in forward rota-
tion)
The default item shall be Fader, and then the item is for-
warded in the following order: Balance →Bass Level →
Middle Level →Treble Level →HPF Front →HPF Rear →
LPF Sub Woofer (thereafter arbitrary).
• Continuous forwarding by remote control is prohibited.
• Fader is adjusted by the VOL knob and [ ] / [ ] keys in
3 steps: R15 ↔0 ↔F15. (Default value: 0)
• Balance is adjusted by theVOL knob and [ ] / [ ] keys
in 3 steps: L15 ↔0 ↔R15. (Default value: 0)
• Bass/Middle/Treble Level are adjusted by theVOL knob and
[] / [ ] keys in 3 steps: -8 ↔0 ↔+8.(Default value: 0)
• HPF Front / Rear is adjusted by the VOL knob and [ ] /
[] keys in 2 steps: Through ↔180Hz. (Default value:
Through)
• LPF Sub Woofer is adjusted by the VOL knob and [ ] /
[] keys in 2 steps: 60Hz ↔Through. (Default value:
Through)
• Sub Woofer Phase is adjusted by the VOL knob and [ ] /
[] keys in 2 steps: Reverse ↔Normal. (Default value:
Normal)
•Volume Offset is adjusted by theVOL knob and [ ] / [ ]
keys in 2 steps: -8 ↔0. (Default value: 0)
• Loudness ON/OFF is adjusted by theVOL knob and [ ] /
[] keys in 2 steps: OFF ↔ON.(Default value: OFF)

KDC-MP4032
11
●MENU
• Press the [Q] key to enter the MENU.
• Press the remote control [DNPP/SBF] key or the [DIRECT]
key to enter the MENU.
• Continuous forwarding by remote control is prohibited.
●Backup current measurement
If reset while in Acc OFF (Back Up ON) condition, MUTE
terminal goes off 2 seconds later, rather than 15 seconds.
(During this time, the CD mechanism does not function.)
●Initializing AUDIO-related setting value
Press the [ ] key in the STANDBY source and reset the
AUDIO setting value to the test mode default value.
●Other
• When Power ON, do not display “CODE_OFF” and
“CODE_ON”.
• When started in Test Mode, duration of prohibiting LINE
MUTE shall be changed from 10 seconds to 1 second.
• When in test mode, do not write security code by security
jig.
• While in Test Mode, serial number is not written with a se-
rial-number-writing jig.
• When in Test Mode, when DC offset error detection is run,
the detection information is not written into the E2PROM.
• DEMO mode shall not be operated while in Test Mode, CD
Mechanism Error Log Data Clearing Mode, or DC Offset
Error Detection Data Clearing Mode.
Also, do not display DEMO ON/OFF option items in the
MENU in STANDBY source in the above modes.
●Special displays while all lights are on
When all lights are on with STANDBY source, if the follow-
ing keys are pressed, the following messages are displayed.
[1] key Version is displayed (forwarding)
(Display) TYPE : x_ _ _
(“x” is displayed in hexadecimals)
→518K – 1.02 (“development ID” – “version”)
→all lights on →
∗TYPE indicates µ-com destination, and shows real-time
condition of the destination terminal.
[2] key Serial No. is displayed (8 digits)
(Display) xxxxxxxx
[3] key Key pressed: Power ON time is displayed.
While Power ON time is displayed, press and hold for 2
seconds or longer to clear the Power ON time.
(Display)
PON_0Hxx (00~50 is displayed for “xx”.When less
than 1 hour, display by increment of 10
minutes.)
xxxxx (00001~10922 is displayed for “xxxxx”)
MAX 10922 (hours)
[4] key Key pressed: CD operation time is displayed.
Press the key for more than 2 seconds while the CD
operation time is displayed to clear CD operation time.
(Display)
CDT_0Hxx (00~50 is displayed for “xx”.When less
than 1 hour, display by increment of 10
minutes.)
xxxxx (00001~10922 is displayed for “xxxxx”)
MAX 10922 (hours)
[5] key Key pressed: Number of CD EJECT time is displayed.
While the CD EJECT times is displayed, press and hold
for 2 seconds or longer to clear the number of CD EJECT
times.
(Display) EJCxxxxx MAX 65535 (times)
[6] key Key pressed: Number of times PANEL is opened/closed
is displayed.
Press the key for more than 2 seconds while the PANEL
open/close count is displayed to clear the PANEL open/
close count.
(Display) PC_xxxxx MAX 65535 (times)
TEST MODE

KDC-MP4032
12
[FM] ROM correction version is displayed
key (Display) ROM_R123
ROM_ERR_ (When E2PROM is not installed)
ROM_R – – – (When not written in)
ROM_R ∗ ∗ ∗ (When data not matching)
[]AUDIO data initialization
key (Display) AUD_INIT
[]Key pressed: Forced Power OFF data displayed.
key While the forced power OFF data is displayed, press and
hold for 2 seconds or longer to clear the data.
(Display) POFF_ – – – (No Forced Power OFF)
SEC (Forced Power OFF because of
missing Security Code)
PNL (Forced Power OFF because of
system µ-com and panel communication error)
[]Key pressed: CD information display mode ON/OFF
key While in CD information display mode, press and hold for
2 seconds or longer to clear all CD information.
∗Please refer to the next table.
CD information display mode
I2C communication condition display
(Display) I2C_OK_ _
NG
[AM] CD mechanism error log display
key(switched by [ ] / [ ] keys)
↑(Display) MCERR1: x x ↔MCERR2: x x ↔
MCERR3: x x ↔MCERR1: x x ↔
(“– –” or the error code is displayed for “xx”)
CD loading error log display (switched by [ ] / [ ] keys)
(Display) LDERR1: x x ↔LDERR2: x x ↔
LDERR1: x x ↔
(Number of times is displayed for “xx”)
MAX 99 (times)
CD ejection error log display (switched by [ ] / [ ] keys)
(Display) EJERR1: x x ↔EJERR2: x x ↔
EJERR3: x x ↔EJERR4: x x ↔
EJERR1: x x ↔
(Number of times is displayed for “xx”)
MAX 99 (times)
CD time code error count data display (missing counts)
(switched by [ ] / [ ] keys)
(Display) CNT_LOSE ↔CDDA_ _: xx ↔CDROM_: xx ↔
CNT_LOSE ↔
(Number of times is displayed for “xx”)
MAX 99 (times)
↓ CD time code error count data display (count not updated)
[FM] (switched by [ ] / [ ] keys)
key (Display) CNT_STAY ↔CDDA_ _: xx ↔CDROM_: xx ↔
CNT_STAY ↔
(Number of times is displayed for “xx”)
MAX 99 (times)
●Security
1) How to enter the forced POWER ON mode
While “– – – –” is being displayed, while simultaneously
pressing [Q] key and [4] key, press [RESET] button, With
this, it is possible to turn the power on for 30 minutes only.
2) How to clear the programmable security code
1. While “– – – –” is being displayed, press [ ] key for 3
seconds or longer while pressing the [AUTO] key. This
makes the “– – – –” display disappear.
2. Input “KCAR”, using the remote controller.
Press [5] key of the remote controller twice (Input for “K”)
and press [ ] key.
Press [2] key of the remote controller 3 times (Input for “C”)
and press [ ] key.
Press [2] key of the remote controller once (Input for “A”)
and press [ ] key.
Press [7] key of the remote controller twice (Input for “R”)
and press [ ] key.
3. The security is cleared and the unit enters STANDBY
source.
4. If wrong codes are input, “– – – –” will be displayed again.
TEST MODE

KDC-MP4032
13
●Clearing CD mechanism information and service
information (Clearing E2PROM data)
1. While pressing the [Q] key and [ATT] key, reset-start to start
CD mechanism and service information initialization.
(While “– – – –“ is being displayed, power can be ON for 30
minutes.)
[CD mechanism information]
• Displays I2C communication condition
• Displays CD mechanism error log
• Displays CD loading error data.
• Displays CD ejection error data
• Displays CD time code error count data (missing count)
• Displays CD time code error count data (count not updated)
[Service information]
• Displays power ON time is displayed
• Displays CD operation time
• Displays number of CD EJECT times
• Displays number of times panel was opened/closed
• Displays forced Power OFF data
2. After the initialization process is completed, the following is
displayed.
When successfully completed :“CD_O_ _ _”
When finished but unsuccessful:“CD_X_ _ _”
3. This mode is cancelled by resetting. (The last screen will
not be retained.)
TEST MODE
●Clearing DC offset error detection data
(E2PROM data clearing)
If DC voltage difference (DC offset error) is detected be-
tween audio power amplifier (power IC) ±outputs,
“DC_ERR_” is displayed on the display.When this occurs,
the audio is forced-mute and the display displays only
“DC_ERR_”.
Once this product detected a DC offset error, even if it is
restarted (or reset), its display displays “DC_ERR_”.
However, if the error is detected while inTest Mode, it is not
saved in E2PROM.
1. Press and hold [3] and [6] keys and reset-start to go into
the DC offset error display mode.
(While “– – – –“ is being displayed, power can be ON for 30
minutes.)
2. While in STANDBY source, the current DC offset error con-
dition is displayed.
When detected : “DC_ERR_ _”
When not detected: “DC_OK_ _ _”
3. While error condition is being displayed, press [AUTO] key
to clear the detection data. (Clear E2PROM)
4. DC offset error display mode is cancelled by resetting.(The
last screen will not be retained.)
●FM/AM channel space switching
While power is OFF, press and hold [1] and [5] keys, and
press [SRC] key to power ON.

KDC-MP4032
14
ABCDE
1
2
3
4
5
6
7
PC BOARD (COMPONENT SIDEVIEW)
R953
C7
R7
C102
C958
C311
R260
W931
R323
R325
TH1
W15
C410
R426
R928
R936
W932
R20
R114
R
R427
R429
C104
C105
C106
C108
C203
C204
C208
R327
C435 C436
C501
C507
C513
C955
C960
R8
R24
R108
R112
R129
R131 R259
R404
R405
R408
R409
R412
R413
R503
R519
13 11 12 8 4 3 2
9106 751
R934
X2
W997
R431
C103
C408
C409
CP201
CP202
CP203
R205
CP206
L202
R6
R21
R23
R25
R26
R28
R29
R101
R102
R103
R105
R109
R110
R130
R201
R204
R208
R211
R216
R218
R219
R220
R233
R257
R258
R322
R324 R402
R403
R406
R407
R410
R411
R414
R415
R416
R417
R418
R419
R420
R421
R428
R440
R441
R501
R505
R506
R507
R925
R929 R933
R930
W3
X1
CP204
R311
R312
R262
R263
R802
C802
R801
123 224
115 214
CNVSS
VT
IFC
PL-SDA
PL-SCL
S-METER
SDA SCL
AFS
BE
C428
C312
C405
C953
C412
C512
C954
C313
C419
C421
C15
C420
C417
C8
W123
C411
C101
C999
C306
C310
C322
C308
C401
C959
C14
C16
C402
C403
C431
W130
C961
W118
W129
L301
C415
C416
C418
C422
C503
C504
C505
C506
C529
W128
W127
W109
W126
W125
W120 W119
W124
W122 W121
EB
1
4
8
5
OGI
17
148
45
31
48
49 33
116
64
32
17 100
176
25 5026 5
1
7
1
4
8
5
B
E
E
C
C
E
B
E
C
C
EB
EB
EB
EB
EBEB
EB
EB
EB
EB
EB
EB
EB
EB
EB EB
EB
BE
EB
EB
BE
EB
1
241
3
271
9
8
226
BE
D904
D105
Q104
Q105
Q905
Q906
Q303
Q13
D9
Q299
D304
D309
Q113
D407
D303
D8
D107
D511
D512
D905
Q6
Q102
Q106
Q108
Q400
Q401
Q402
Q403
Q404
Q405
Q907
D111
D401
D402
D403
D411
D501
D502
Q14
Q15
Q305
Q114
Q306
Q302
Q16
J2
J4
D505
D506
J3
W1
P1
D302
A1
CN1
CN4
S4
IC2
IC902
IC1
IC10
IC11
IC3
IC6
IC4
ELECTRIC UNIT
X34-4180-10 (J76-0039-22)

KDC-MP4032
15
JIHGF
1
2
3
4
5
6
7
W10
FM
AM
AUTO
SRC
RST
653
2
1
Q
VOL
VCC
VO
G
AUD
ATT
4
141
D4
D1
D2
D3
D7
D8
D9
D13
D14
D15
D5
D6
D10
D11
D12
D16
D17
D18
D25
D26
D21
D23
D19
D20
D22
D116
ED1
S1
S2
S10
S27
IC2
SWITCH UNIT
X16-3490-10 (J76-0165-02)
R115
R243
R245
R247
R3
R113
R114
R124
R125
C4
C105
C106
C107
C109
W998
C10
R107
R116
R118
R123
R128
R10
R205
CP206
CP207
CP208 CP209
R1 R2
R4
R9
R105
R117
R119
R120
R121
R122
R213
R233
R239
R240
R241
R253
R238
CP204
R17
R18
W101
C201
C5
L2
W900
C1
C11
C101
L1
W115
W116
W117
C12
C9
W103
C18
C6
W108
C3
W105
R126
W107
C20
L3
W106
W102
W112
W111
W104
W109
W114
W113
R16
76
50 51
75
EB
EB
EB
EB
EB
EB
EB
EB
EB EB
EB
16
1
BE
1
5
42
BE
51
D108
Q4
Q3
Q8
Q11
Q2
D3
D4
D103
0
6
Q108
Q109
Q110
Q111
Q112
D109
D110
Q9
Q5
D1
Q7
Q1
D101
J1
S3
IC5
IC12
Refer to the schematic diagram for the values of resistors and capacitors.
X34-4180-10
Ref.No. Address
IC1 5E
IC2 5C
IC3 4E
IC4 2D
IC5 3G
IC6 4E
IC11 4D
IC12 6G
IC902 3D
Q1 2G
Q2 3G
Q3 4F
Q4 3G
Q5 3F
Q6 4E
Q7 4G
Q8 3G
Q9 3G
Q11 4G
Q13 6D
Q14 4D
Q15 4D
Q16 4D
Q102 2E
Q104 3E
Q105 3E
Q106 3E
Q108 3F
Q109 3F
Q110 3F
Q111 3F
Q112 3F
Q113 5D
Q114 5D
Q299 6A
Q302 5B
Q303 5A
Q305 7E
Q306 6E
Q400 3B
Q401 3B
Q402 3B
Q403 3B
Q404 3C
Q405 3C
Q905 3E
Q906 3E
Q907 4D
X16-3490-10
Ref.No. Address
IC2 6I

KDC-MP4032
16
KLMNO
1
2
3
4
5
6
7
PC BOARD (FOIL SIDEVIEW)
C957
R932
R937
R432
R920
C2
R5
R22
R947
R945 R948
R946
R951
R949
C202
C206
C207
C209
L201
R210
R212
R224
R227
R228
R234
R235
R313
R11
C110
R316
R317
R318
R319
R336
R314
R315 C205
C320
C404
R12
R30
R104
B
EB
E
R202
R203
R207
R215
R229
R230
R236
R237
R244
R246
R248
R249
R250
R254
R927
R935
C19
C302
C303
C406
C407
C510
C511
C301
SCL
SDA
R952
R27
R106
R127
R261
R305
R306
R308
R309
R310
R337
R401
R433
R434
R508
R509
R510
R511
R512
R513 R516
R517
R518
R520
REMO
DATA
CLK
CE
R521
R522
R523
R921
R922
R924
R926
R950
R942
R944
R941
R943
R14
R15
R13
C423
C424
R31
43
21
BE
B
E
D2
Q103
D201
Q115
D503
D504 D507
D508
D509
D510
D513
D515
D903
D10
Q12
D102
D104
Q101
D500
D404
IC7
ELECTRIC UNIT
X34-4180-10 (J76-0039-22)

KDC-MP4032
17
TSRQP
1
2
3
4
5
6
7
L303
R321
C305C309
L304
C304
L302
C307
R332
R339
C321
C429
R422
R425
W14
C413
C414 C426
C427
C511
R301
R302
R303
R304
R305
R306
R307
R308
R320
R326
R338
R423
R424
R434
R510
R512
R513
R514
R515
R516
R517
R518
C423
C424
BE
BE
BE
BE
BE
Q300
Q115
Q116
D301
D310
D405
D406
D408
D409
D410
D514
D515
Q301
Q304
D305
D306
D307
D308
D404
EBEB
EB
BEBEBE
EB
BE
C8
R59
R60
R20
R21
C10
C19 C20
C28
C29
C31
C32
CP14
R55
R56
R58 R63
R80
R106
R110
W6
W7
W8
C14
C16
C13 C15
CP10
CP11
CP12
CP13
R1
R2
R3
R4
R5
R6
R7
R8
R9
R10
R11
R13
R14
R15
R23
R26
R112
R29
CP15
R51
R52
R53
R54
R66 R67
R73
R74
R75
R81
R107
R108
R109
R111
W4W5
KS1 KI6
KI1-2
KI4
KI5
KI3
KS2
KS3
PAN5V
D-GND
RTRY CW
FL+B
ILL+B
2
RST
14
CN DET
ESD
RTRY CCW
FL+B
KS4
115
EB
BE
D102
D104
D110
D113
D114
Q5
Q10
Q15
Q18
Q19
D115
Q4
Q12
Q13
Q14
Q20
D111 D112
J1
SWITCH UNIT
X16-3490-10 (J76-0165-02)
Refer to the schematic diagram for the values of resistors and capacitors.
X34-4180-10
Ref.No. Address
IC7 5N
Q12 5L
Q101 3M
Q103 3M
Q115 3P
Q116 4P
Q300 4P
Q301 4P
Q304 6P
X16-3490-10
Ref.No. Address
Q4 6T
Q5 6T
Q12 3T
Q13 3T
Q14 3T
Q20 3T

KDC-MP4032
18
UVWXY
1
2
3
4
5
6
7
PC BOARD (COMPONENT SIDEVIEW)
CP4
R44
CP2
CP5
R4 C2 R6 C4 R8 C6 C8
W20
C7
C101
R48 C5
R7 C3 R5 C1 R3
W21
R2
R10 R12
R11
R1 R9
R150
R42
C32
R41
R57
C31
R43
CP1
C30
X1
X2
C55
C57
CP12
C25
C39
C34
CP13
R56
C24
R31 R30
C56
C52
C79
C50
C66
C64
C65
C67
R151
C58
CP27
C63
13
45
41
85
S4 S1 S2
S3
IC11
IC2
CD PLAYER UNIT
X32-5860-00 (J76-0212-02)
Refer to the schematic diagram for the values of resistors and capacitors.
X32-5860-00
Ref.No. Address
IC2 4V
IC11 4V

KDC-MP4032
19
ADACABAAZ
1
2
3
4
5
6
7
PC BOARD (FOIL SIDE VIEW)
R93
R21
R22
R20
C20
R27
R28
C23
C51
R24
R23
C21
R26
C22
R25
R29
C42
R152
C85
C62
C43
R89
R88
C83
R90
C81
R70
C82
C74
R81
C76
C73
W1
R80
C77
R79
C71
C80 C70
C75
C69
C72
C78
C11
CP8
C41
R55
R50
R51
R52
CP7
CP10
CP11
C40
R104
C100
CP9
R40
C35
CP14
C46
R16
C38
C9
R103 R101
C10
R102
R15 R100
CP6
R112
R14
C12 R113
C54 C53
C61
R72
R71
C60
R75
R74
R92 R91
R78
C68
CP28
LOE/LIM
SLD+
SLD-
SD
TD
SPD-
MD
FD
MRESET
LOE/LIM
DGND
RAM
AAC
BU3.3V
MSTOP
E2P
ASEL
TI0
TI1
TI2
TI3 INTQ
SO0
SO
SI0
SCK0
SCL
SDA
8EJE-SW
PON1
BU5V
DGND
SI
DGND
D3.3V
DGND
AGND
Rch
MRESET
MSTOP
MUTE-L A8V
DATA
CLK
F-
T+
T-
F+
DOUT
S7.5V
SGND
D5V
MOTOR
LO/EJ
SPD+
Lch
MUTE-R
DMUTE
BU5V
RESET
ARF
REFOUTSV
ADIN
LD
B
C
PD
A
A3.3V
VR
AGND
TE
E
IOP-
Vref
TEC FE
SD
ASY
IOP+ RF
MD
ATEST
F
GND
FD TD
EFM
SRDATA
X1
X2
XT1 WAIT
TYPE
TO3
TO2
TO1
Vpp
PON2
TO4
MIRR
DOUT
FZC TZC
RZM LZM
SHOCK LOS-SW
BCK
LOCK
HOLD
LRCK
12EJE-SW
1
16
109 108 73
361
144
72
37
26 25 50
1
1
4
8
5
51
7576 100
31
54
124
15
16 15
130
45
31
EB
EB
EB
E
EB
B
EB
CN1
CN2
D1 Q4
Q7
Q5
Q6
Q8
Q1
IC3
IC6
IC4
IC9
IC5
IC1
IC7
CD PLAYER UNIT
X32-5860-00 (J76-0212-02)
Refer to the schematic diagram for the values of resistors and capacitors.
X32-5860-00
Ref. No. Address
IC1 3AC
IC3 5AA
IC4 5AC
IC5 5AB
IC6 3Z
Ref.No. Address
IC7 3AB
IC9 5AC
Q1 4AC
Q4 3AA
Q5 5AC
Ref.No. Address
Q6 5AC
Q7 4AC
Q8 4AC

KDC-MP4032
20
ABCDE
1
2
3
4
5
6
7
P1
D511
Q16
D411
S3
Q300
S4
Q302
Q303 Q299
Q13
Q
Q304
Q301
Q405
Q404
Q115Q116
D
4
CN1 J4
SUB WOOFER AUX
A1
W1
J2
R
REAR
R
L
L
FRONT
J3
4V PRE+B
CN4
Q402
Q403
Q401
Q400
D512
D513
D514
D515
D
4
D
4
D303
TUNER8V
D302
DSI
D9
FILP
DET EJECT SW
FRONT-END
TUNER
2/2 X16-
J1
E-VOL
PREOUT MUTE DRIVER
AM+B
PREOUT
MUTE SW
TUNER
8V SW
DSI
DRIVER
P
5
D404
LX BUS
to CD PLAYER UNIT (X32- )
TP48
TP85
TP56
TP99
TP49
TP98
TP39 TP32 TP47
TP89
TP60
TP92
TP40 TP34 TP31 TP64 TP41 TP58
TP83
TP46 TP62
TP88
TP43 TP37 TP52 TP57 TP36
TP97
TP59
TP82
TP102
TP87
TP86
TP44 TP63 TP29 TP61 TP50 TP33
TP101 TP93
TP51
TP38 TP42
TP84
TP100
TP96
TP94
TP55
TP110 TP119 TP120
TP27
TP109
L301
TP130
48 47 46 45 44 43 42 41 40 39 38 37 36 35 34 33
32
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
1
2
3
4
5
6
7
8 9
10
11
12
13
14
15
16
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
PREF
PGND
LDOUT1L
LDOUT1R
LDOUT2L
LDOUT2R
GND
VCC
ACIN0L
ACIN0R
ACIN1L
ACIN1R
ACIN2L
ACIN2R
ACIN3L
ACIN3R
ACOUTR
ACOUTL
MUTE2
MUTE1
MUTE0
REF3V3
VOLINR
VOLINL
REF5V5
SAIN
SAOUT
SARES
SACLK
SCL
SDA
SEL
CDCHL CDCHCOM CDCHR AUXL AUXCOM AUXR MUXAL MUXAR MUXBL MUXBR MUXCL MUXCR WININ WINTC0 WINTC1 DCERR
LDOUT0R
LDOUT0L
VP
PAOUT1R
PAOUT1L
PAOUT0R
PAOUT0L
MUTEC
MUTEB
MUTEA
TUNERL
TUNERR
CDL
CDR
MDL
MDR
24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 987654321
D OUT
12EJE SW
LOS SW
MS CLK
MS DATA
AUDIO 8V
L ch
A GND
R ch
MUTE R
MUTE L
M RST
M STOP
8EJE SW
LOE/LIM SW
BU 5V
D GND D GND
D5.0V D5.0V
LO/EJ
MOSW
SERVO +B
SERVO GND
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
ESD
FLIP DET
RTRY CCW
REMO
VFD SYS
VFD CL
VFD CE
DATA
VFD INH
RST
ILL+B
FL+B
RTRY CW
PAN5V
ILL D GND
4
5
OUT
VCC
V
0.01
C410
47u16
C401
10u35
C431 10
R431 47u16
C16 2.2
R29
2.2
R28
22u16
C422
360
R410
360
R411 22u16 C421
R508 4.7K
R509 100
R510 4.7K
R512 100 R513 100 R514 100 R515 100
10
R516
0.47
C510
4.7
R518
0.47
C511 10
R517
47u6.3
C512
10u35
C322
10u35
C306 1K
R320
10u35
C308
W931
R322 470
R324 470
4.7K
R323
4.7K
R325
2.2K
R326
0.01
C309
47u35
C310
100u25
C312
C311 0.01
10u35
C313
680
R327
240
R332
8.2
R801
47K
R20
10K
R21
R337
1K
R339C321
0.01 470K
1K
R302
1K
R309
100
R308
100
R307
1K
100
470 0.01
R318 100K
470 0.01
R313 4.7K
R316 100K
C407 3.3
C404
R401
C406 3.3
100
100
100P
C423
100P
C424
C414 0.47
R
1u5
0
1u5
0
C40
4
C
R415 180
R414 180
R417 180
R416 180
R418
180
5
R
8
IFGND
15
8
L
IF+B 2
1
R4
3
STDGND
6
RDSMUTE 5
MPX
DGND2 7
PLLGND
AMIFOUT
QUALITY 9
SMETER 11
10
13
12
14
22
17
16
18
20
19
21
24
23
26
25
VDD5V
DGND1
SCL
SDA
IFC
COM+B
VT
RFGND
FMANT
AMANT
AM+B
OSCGND
TP66
TP113
TP67
TP68
TP114TP69
TP70 TP115
TP71 TP116
TP72
TP73 TP117
TP74
TP75
TP118TP76
TP77
TP78
TP79
2
1
3
TP65
TP128
4.7uH
L302
L303
4.7uH
L304
4.7uH
93
95
21
27
28
19
10
12
11
B.U.
GND
A GND
CON
REQ M
Rch
Lch
37
8
4
6
2
5
19
CHCLK
DATA M
RST
DATA S
REQ S
13
R319 C303
R317 C302
51
48
47
SDA
SCL
50
49
54
52
56
55
3.3K
R30
R27
0.01
C304
0.01
C307
22K
R321
0.01
C305
2
1
3
W14
22K
R413
22K
R412
22K
R408
R406
360 C420 22u16
22K
R409
R407
360 22u16
C419
R404
22K
360
R402
360
R405
22K
R403
22u16
C418
22u16
C417
TP90 TP91
0.01
C513
1K
R519
CH-R
CH-G
CH-L
MUTE
R511 100 TP95
99 98
100
18
90
81
2
20
PR-RR
PR-RL
PR-FR
PR-FL
PRN-FL
PRN-FR
PR-RR
PR-RL
PRN-FR
PRN-FL
PR-FR
PR-FL
RL
FL
FR
RR
0.47
C413
R433
R434
CH-G
CH-R
CH-L
10K
1
89
M-L
M-R
4
3
5
36
71
R338
470K0.01
40
1K
C320 R336
16
46
29
44
31
32
30
35
45
R304
R303
R301
100
R306
100
R305
100
9.1 1W
R31
R310
100
1
4
BU
BU5V
BU5V
BU5V
8V
BU5V
CD5V
SERVO+B
SW5V
ILL+B
BU5V
CD5V 8V
2.2
R432
VFD PAN
DATA
Q300,301
Q400-405
Q15,16
Q
R419
180
2.2u50
+
C415
2.2u50
+
C416
C40
2
GND
GND
ANT.
+ +
+
+
+
++
++
+
+
+
+
+
+
+
+
+
+
+
IC2
IC11
ELECTRIC UNIT (X34-4180-xx)
A
22K
22K
4.7K
4.7K
4.7K
4.7K
4.7K
4.7K
22K
22K
22K
22K
47K
10K
22K
22K22K
22K
4.0V 4.0V 4.0V
0V
5V
0V
5V
4.0V
3.5V
0V
5.6V
8.0V 5.6V
5.6V
4.0V
3.5V
3.3V
5.5V
4.0V
4.0V
4.0V
4.0V
4.0V
4.0V
12.0V
4.0V
4.0V
4.0V
4.0V
8.0V
X34-4180-10 (1/3)
