MICROCOMPUTER’STERMINAL DESCRIPTION
Pin No.
Pin Name Module I/O Application
Truth Value
Processing Operation Description
Table
37 PM_MOT1
P-MECHA
OPanel motor control 1 wRefer to truth value table.
38 PM_MOT2
P-MECHA
OPanel motor control 2 wRefer to truth value table.
39 EPM I FLASH EPM input terminal
40 PM_OPEN
P-MECHA
IPanel full open detect eRefer to truth value table.
41 PM_CLOSE
P-MECHA
IPanel mechanism close detect eRefer to truth value table.
42 PAN_RST to PANEL O Panel µcom reset output
Normal : H, Reset, Momentary power down, Panel
is detached and 11 minutes after ACC_OFF : L
43 PM_DET
P-MECHA
IPanel mechanism detect H : Function check
44 SC_CON to PANEL O Between panel Communication control POWER OFF, ACC OFF : L
(FLASH CE)
45 CD_DISC12_SW CD I CD detect terminal (12cm)
46 CD_LOS_SW CD I CD loading detect terminal
47 CD_MUTE_R CD I CD MUTE (Rch) request terminal L :Rch mute request
48 CD_MUTE_L CD I CD MUTE (Lch) request terminal L : Lch mute request
49 CD_MRST CD O CD mechanism µcom RST terminal H : Normal, L : Reset
50 CD_MSTOP CD O CD mechanism µcom stop terminal H : Mechanism µcom operation,
L : Mechanism µcom stop
51 CD_DISC8_SW CD I CD detect terminal (8cm)
52
CD_LOE_LIM_SW
CD I CD detect terminal (chucking SW) H : Loading complete, L : No disk
53 CD_LOEJ CD I/O CD motor control terminal iRefer to truth value table.
54 CD_MOTOR CD O CD motor control terminal iRefer to truth value table.
55 TUN_TYPE1 TUNER I Destination setting 1 tRefer to truth value table.
56 TUN_TYPE0 TUNER I Destination setting 0 tRefer to truth value table.
57 PON_ILL
Power supply
I/O Key ILL power supply control ON : H, OFF : Hi-Z
58 PON_CD CD O CD WMA power supply control terminal CD : L, Other than CD : H, When RESET,
quicker than M-STOP L, Normal CD : NC
59 PON
Power supply
I/O Power supply control Power ON : H, Power OFF : Hi-Z
60 VCC2 -
61 COR_DET TYPE I E2PROM write request H :Write
62 VSS -
63~65
TYPE_0~TYPE_2
TYPE I Destination switching yRefer to truth value table.
NC O Not used Output : L
66
DIMMER_ON : H, OFF : L,When DIMMER_ON
LW_SW2 EXTRA O FL+B current control terminal at LW
from the beginning, ON before MUTE is turned
OFF after PON stabilizes.E-Type only.
NC O Not used Output : L
LW mode 153kHz~249kHz : H, 250kHz~281kHz : L
67 LW_SW EXTRA O FL+B current control terminal at LW
MW and other sources : L, During seek, condition
before seek, and after seek_stop, change is made.
E-Type only.
68 OPEL_DATA EXTRA I/O External display DATA External display
69 OPEL_CLK EXTRA I/O External display CLK External display
