Kenwood KMM-203 User manual

Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
B5A-1342-10 (MN)© 2016 JVC KENWOOD Corporation
KMM-203
KMM-103
DIGITAL MEDIA RECEIVER
INSTRUCTION MANUAL
JS_KWD_KMM_203_MN_C_4.indd 1JS_KWD_KMM_203_MN_C_4.indd 1 21-Sep-16 11:57:22 AM21-Sep-16 11:57:22 AM

Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
2
CONTENTS BEFORE USE
IMPORTANT
•
To ensure proper use, please read through this manual before using this product. It is especially important that you read and observe
Warning and Caution in this manual.
•
Please keep the manual in a safe and accessible place for future reference.
WARNING
•
Do not operate any function that takes your attention away from safe driving.
•
Do not ingest the battery, Chemical Burn Hazard
The remote control supplied with this product contains a coin/button cell battery.
If the coin/button cell battery is swallowed, it can cause severe internal burns in just 2 hours and can lead to death.
Keep new and used batteries away from children.
If the battery compartment does not close securely, stop using the product and keep it away from children.
If you think batteries might have been swallowed or placed inside any part of the body, seek immediate medical attention.
Caution
Volume setting:
•
Adjust the volume so that you can hear sounds outside the car to prevent accidents.
•
Lower the volume before playing digital sources to avoid damaging the speakers by the sudden increase of the output level.
General:
•
Avoid using the external device if it might hinder safe driving.
•
Make sure all important data has been backed up. We shall bear no responsibility for any loss of recorded data.
•
Never put or leave any metallic objects (such as coins or metal tools) inside the unit, to prevent a short circuit.
•
Depending on the types of cars, the antenna will automatically extend when you turn on the unit with the antenna control wire connected
( 17) . Turn off the unit or change the source to STANDBY when parking at a low ceiling area.
Remote control (RC-406):
•
Do not leave the remote control in hot places such as on the dashboard.
•
The Lithium battery is in danger of explosion if replaced incorrectly. Replace it only with the same or equivalent type.
•
The battery pack or batteries shall not be exposed to excessive heat such as sunshine, fire or the like.
How to read this manual
•
Operations are explained mainly using buttons on the faceplate of .
•
English indications are used for the purpose of explanation. You can select the display language from the [FUNCTION] menu. ( 5)
•
[XX] indicates the selected items.
•
( XX) indicates references are available on the stated page.
BEFORE USE 2
BASICS 3
GETTING STARTED 4
1 Select the display language
and cancel the demonstration
2 Set the clock and date
3 Set the initial settings
RADIO 5
USB/iPod/ANDROID 7
AUX 9
Pandora®
(for ) 10
AUDIO SETTINGS 11
DISPLAY SETTINGS 12
TROUBLESHOOTING 13
REFERENCES 14
Maintenance
More information
INSTALLATION/
CONNECTION 15
SPECIFICATIONS 18
iHeartRadio®
(for ) 19
ENGLISH
JS_KWD_KMM_203_MN_EN_4.indd 2JS_KWD_KMM_203_MN_EN_4.indd 2 21-Sep-16 11:49:16 AM21-Sep-16 11:49:16 AM

Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
3
BASICS
To On the faceplate On the remote control
Turn on the power Press .
• Press and hold to turn off the power.
Press and hold SRC to turn off the power.
( Pressing SRC does not turn on the power. )
Adjust the volume Turn the volume knob. Press or .
• Press and hold to continuously increase
the volume to 15.
Press ATT during playback to attenuate the sound.
• Press again to cancel.
Select a source Press repeatedly. Press SRC repeatedly.
Change the display information Press DISP repeatedly.
( 15) ( Not available )
Faceplate
How to resetAttach Detach
Remote control (RC-406)
ENGLISH
Display window
Pull out the
insulation sheet
when using for
the first time.
Your preset adjustments will be
erased except stored radio stations.
How to replace the battery
Remote sensor (Do not
expose to bright sunlight.)
Volume knob
Detach button *
Not used
JS_KWD_KMM_203_MN_EN_4.indd 3JS_KWD_KMM_203_MN_EN_4.indd 3 21-Sep-16 11:49:18 AM21-Sep-16 11:49:18 AM

4
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
GETTING STARTED
Select the display language and cancel the demonstration
When you turn on the power (or after you reset the unit), the display
shows: “SEL LANGUAGE” “PRESS” “VOLUME KNOB”
1 Turn the volume knob to select [ENG] (English) or [TUR] (Turkish),
then press the knob.
[ENG] is selected for the initial setup.
Then, the display shows: “CANCEL DEMO” “PRESS”
“VOLUME KNOB”.
2 Press the volume knob.
[YES] is selected for the initial setup.
3 Press the volume knob again.
“DEMO OFF” appears.
Set the clock and date
1 Press the volume knob to enter
[FUNCTION] .
2 Turn the volume knob to select [CLOCK] , then press the knob.
To adjust the clock
3 Turn the volume knob to select [CLOCK ADJUST] , then press the knob.
4 Turn the volume knob to make the settings, then press the knob.
Hour Minute
5 Turn the volume knob to select [CLOCK FORMAT] , then press the knob.
6 Turn the volume knob to select [12H] or [24H] , then press the knob.
1
2
To set the date
7 Turn the volume knob to select [DATE FORMAT] , then press the knob.
8 Turn the volume knob to select [DD/MM/YY] or [MM/DD/YY] , then press
the knob.
9 Turn the volume knob to select [DATE SET] , then press the knob.
10 Turn the volume knob to make the settings, then press the knob.
Day Month Year or Month Day Year
11 Press and hold to exit.
To return to the previous setting item, press .
Set the initial settings
1 Press repeatedly to enter STANDBY.
2 Press the volume knob to enter [FUNCTION] .
• Pressing AUD enters [AUDIO CONTROL] directly.
3 Turn the volume knob to select an item (see the following table),
then press the knob.
4 Repeat step 3until the desired item is selected or activated.
5 Press and hold to exit.
To return to the previous setting item, press .
Default:
XX
AUDIO CONTROL
SWITCH PREOUT REAR
/ SUB-W : Selects whether rear speakers or a subwoofer are
connected to the line out terminals on the rear (through an external
amplifier).
( 17)
SP SELECT OFF
/ 5/4 / 6 × 9/6 / OEM : Selects according to the speaker size (5inches
or 4inches, 6×9inches or 6inches) or OEM speakers for optimum
performance.
3
ENGLISH
JS_KWD_KMM_203_MN_EN_4.indd 4JS_KWD_KMM_203_MN_EN_4.indd 4 21-Sep-16 11:49:19 AM21-Sep-16 11:49:19 AM

ENGLISH 5
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
GETTING STARTED
TUNER SETTING
PRESET TYPE NORMAL
:Memorizes one station for each preset button in each band
(
RADIO ).; MIX :Memorizes one station for each preset button,
regardless of the selected band.
SYSTEM
KEY BEEP ON
:Activates the keypress tone.; OFF :Deactivates.
TDF ALARM ON :Activates the alarm if you forget to detach the faceplate when ACC is
set to OFF.;
OFF :Deactivates.
SOURCE SELECT
PANDORA SRC
(For )
ON :Enables PANDORA in source selection.; OFF :Disables. ( 10)
BUILT-IN AUX ON
:Enables AUX in source selection.; OFF :Disables. ( 9)
F/W UPDATE
UPDATE SYSTEM
F/W UP xxxx YES
:Starts upgrading the firmware.; NO :Cancels (upgrading is not
activated).
For details on how to update the firmware, visit
<www.kenwood.com/cs/ce/>.
CLOCK
CLOCK DISPLAY ON
:The clock time is shown on the display even when the unit is turned
off.;
OFF :Cancels.
ENGLISH Select the display language for [FUNCTION] menu and music
information if applicable.
By default,
[ENGLISH] is selected.
TURKCE
Supported band: FM1/FM2/FM3/AM/SW1/SW2
Search for a station
1 Press repeatedly to select TUNER.
2 Press repeatedly (or press / on the remote
control) to select the band.
3 Press S/T(or press S/ on the remote control) to
search for a station.
• To change the searching method for S/T: Press
repeatedly.
AUTO1 : Automatically search for a station.
AUTO2 : Search for a preset station.
MANUAL : Manually search for a station.
• To store a station: Press and hold one of the number buttons (1to6).
• To select a stored station: Press one of the number buttons (1to6)
(or press one of the number buttons (1to6) on the remote control).
Direct Access Tuning (using the remote control)
1 Press DIRECT to enter Direct Access Tuning.
2 Press the number buttons to enter a frequency.
3 Press to search for a station.
• To cancel, press or DIRECT.
• If no operation is done for 10seconds after step2, Direct Access Tuning
is automatically canceled.
RADIO
JS_KWD_KMM_203_MN_EN_4.indd 5JS_KWD_KMM_203_MN_EN_4.indd 5 21-Sep-16 11:49:21 AM21-Sep-16 11:49:21 AM
