Kenwood KRC-366 User manual

CASSETTE RECEIVER
KRC-366/466/566
SERVICE MANUAL
Mechanism extension cord :W05-0477-00 (7P), W05-0609-00 (10P)
LOUD SCAN REP M.RDMB.S/RDM ADJ AUTO AMECLK
KRC-XXXX
SRC
OFF
45Wx4
AUD
DISC
Mounting hardware assy
(J21-9716-03)
Plastic cabinet assy
(A02-1486-13)
Screw set
(N99-1610-15)
Lever
(D10-4589-04) x2
Screw set
(N99-1719-05)
Panel assy
(A64-2939-02) : KRC-366
(A64-2940-02) : KRC-566
(A64-2943-02) : KRC-466
CRSC
DC cord
(E30-4784-05)or
(E30-6131-05)
Escutcheon
(B07-3001-02) : KRC-366
(B07-3022-02) : KRC-466/566
Remote controller assy
(A70-2024-05)
Depends on model. Refer to the parts list.
© 2002-10 PRINTED IN JAPAN
B51-7987-00 (N)484
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

KRC-366/466/566
2
BLOCK DIAGRAM
SW5V
B.U.14V
BU5V
BU14V
FM ANT
AM ANT
FM+B
AM+B
PLL+B
PLL-DATA
VT
IFC OUT
PLL-CLK
VDD 5V
IF2+B
IF1 GND
S-METER
IF1+B
SD
AUDIO OUT
PLL-DATA
SD
S-METER
SUB+
SUB-
EN2
ACC-DET
EN1
SCL
MUTE
SDA
EN3
SW5
PC-DET
PA-DET
PANEL
HOLD
L-CLK
L-CE
L-DATA S
L-DATA L
MUSIC
∗
DOLBY
∗
MTL
EQ-MUTE
MS-CONT
MUSIC
∗
DOLBY
∗
MTL
EQ-MUTE
MS-CONT
DSI
FWD/REV
PACK IN
M-STBY
CH CON
DATA H
DATA C
REQ H
REQ C
CH CLK
Rch
COM
Lch
MP IN
AM
MPX
OUT RR
SW5V
OUT LR
OUT RF
LEVEL
SCL
SDA
OUT LF
SVR
MUTE
EN1
EN2
EN3
P.ANT
P,CON
ILLUM
B.U.5V
AM+B
AUDIO
FM+BFM+B
AM+B
AUDIO 8V
BU5V
Rch
Lch
PACK
T-END
M-STBY
T-MODE
FWD
REV
BU5V
AUDIO 8V
BU14V
CHRST
SMUTE
FM+B
AM+B
AUDIO
8V
AUDIO
8V
MOTOR
BU14V
SW5V
8
4
1040
IN
PLAY HEAD
BU5V
PLL-CLK
T-MODE
T-END
BU5V
REMO
SW5V
BU-DET
P-STBY
SVR
P-MUTE
CHMUTE
STBY
CD L/R
CD L/R
TAPE L/R
1200mV
400mV
170mV
340mV
TAPE
CD-CH
AM
FM
: 1719mV
: 3424mV
: 550mV
: 1727mV
TAPE
CD-CH
AM
FM
:1780mV
:3546mV
:570mV
:1789mV
AUDIO 8V
TAPE L/R
(X16)
(X14)
MM
TUNER
TAPE MECHA
SW5
SYSTEM u-COM
KEY
PAN 5V
MUTE
B.U. DET
SURGE-DET
PA-DETPC-DET
B.U.
ACC
P-CONT
ANT-CON
MUTE
DC CONNECTOR
PRE
POWER IC
EQ AMP
E-VOL
CD/MD
CHANGER
FRONT Lch
FRONT Rch
REAR Lch
REAR Rch
REGULATOR
LCD DRIVER
LCD
MAIN
SUB
F-Lch
F-Rch
R-Lch
R-Rch
PRE OUT
J5/J6
J4
SP OUT
MOTOR
5V
D301
IC6
IC5
IC1
IC1
IC2
IC7
TH1
IC10
IC2
AVR
DSI
REMO
RST SW
PAN IN SW
ACC DET
J2
VOLTAGE
DRIVER
AMP
SVR
PC-DET
PA-DET
MUTE
THERMO
PROTECTION
MAIN M
DRIVER
SUB MOTOR
ANT.
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

KRC-366/466/566
3
COMPONENTS DESCRIPTION
● SYNTHESIZER UNIT (X14-6880-2x)
Ref. No. Function Operation
IC1 System µ-com Controls FM/AM tuner, the change, cassette mechanism, volume and tone.
IC2 E-volume Controls the source, volume, tone and FM multiplex detector.
IC4 Power amplifier Amplifies the front L/R and the rear L/R to 45W maximum.
IC5 Equalizer amplifier Equalizes the tape sound.
IC6 Sub motor driver Controls the sub motor.
IC7 Power supply B.U.: 5V, AUD : 8V, FM+B : 8V, AM+B : 8V.
IC10 Mute control logic Controls muting.
Q10 Backup detection Output becomes “L”when the backup voltage becomes more than 9V.
Output becomes “H” when the backup voltage becomes less than 9V (momentary power down).
Q11 Surge detection Output becomes “L”when the backup voltage becomes more than 18V (Momentary power
down). Output becomes “H” when backup voltage becomes less than 18V.
Q41 Pre mute driver When input becomes “L” output becomes “H” (Preout mute).
Q50 5V SW Outputs 5V to the SW 5V power supply when input becomes “L”.
SW 5V power supply line is cut off when the input becomes “H”.
Q51 Power antenna detection Output becomes “H” when P-ANT output is short-circuited (P-ANT off).
Output becomes “L”when FM/AM signal does not exist.
Q52 P. CON detection Output becomes “H” when P. CON output is short-circuited (P. CON off).
Q190 Panel SW Outputs 5V to the panel VDD line when panel is attached.
PanelVDD line is cut off when panel is taken out.
Q191 DSI driver DSI lights when input becomes “L”. DSI turns off when input becomes “H”.
DSI turns on and off when panel is taken off.
Q221~224 Pre mute Works when input becomes “H”. Being cancelled when input becomes “L”.
Q251 SVR “L” when input becomes“H”.
Q501 Sub motor AVR Outputs 7.3V when AUD 8V exists. Output does not exist when AUD 8V does not exist.
Q551 Main motor SW Outputs 14V when input becomes “L” (Main motor drives).
Q552 Main motor SW Output becomes “H” when input becomes “L”.
● SWITCH UNIT (X16-1520-2x)
Ref. No. Function Operation
IC1 LCD driver Scans LCD display control key.
IC2 Remote sensor Sensors remote controller signal.
Q1 Key scan SW Scans key after receiving imitative key input signal.
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

KRC-366/466/566
4
MICROCOMPUTER’STERMINAL DESCRIPTION
● Microcomputer : LC72366-9996 (X14 : IC1)
Pin No. Pin Name I/O Function
1 X IN I Clock 4.5MHz.
2 GND - GND.
3 L-DATA L I LCD driver data.
4 L-DATA S O LCD driver data.
5 L-CLK O LCD driver clock.
6 L-CE O LCD driver chip enable.
7 PANEL I Panel detection.
8 PLL-DATA I/O Tuner data.
9 PLL-CLK O Tuner clock.
10 SD I Tuner band muting.
11 CH-DATA C I 5-line CD-CH communication data.
12 CH-DATA H O 5-line CD-CH communication data.
13 CH-CLK I/O 5-line CD-CH communication clock.
14 CH-REQ C I 5 -line CD-CH communication request.
15 MOTOR O Cassette mechanism main motor.
16~20 - - -
21 CH-CON O 5-line CD-CH communication control.
22 CH-REQ H O 5-line CD-CH communication request.
23 MUTE O Muting.
24 IC2-SCL O IC2 clock.
25,26 - - -
27 IC2 TYPE 0 I Model discrimination.
28 - - -
29 TYPE 1 I Destination discrimination.
30 TYPE 0 I Destination discrimination.
31 VDD - Power supply.
32 IC2-SDA I/O IC2 data.
33 SW 5V O SW 5V control.
34 P-MUTE O Power IC muting.
35 P-STBY O Power IC standby.
36 SVR O Power IC discharge control.
37 EN1 O Power supply IC control.
38 EN3-1 O Power supply IC control.
39 EN3-0 O Power supply IC control.
40 EN2-1 O Power supply IC control.
Pin No. Pin Name I/O Function
41 EN2-0 O Power supply IC control.
42 - - -
43 MS-CONT O Tape signal sensitivity switch.
44 BEEP O Beep.
45 BU-DET I Backup detection.
46 P.CON-DET I Power control short-circuited detection.
47 P.ANT-DET I Power antenna short-circuited detection.
48 MUSIC I Tape signal detection.
49 METAL O Normal/Metal tape switch.
50 DOLBY O Dolby switch.
51 EQ-MUTE O Tape equalizer muting.
52 FWD/REV I Cassette mechanism running direction.
53,54 - - -
55 PACK-IN I Cassette mechanism pack-in.
56 REMOTE I Remote signal shape.
57 - - -
58 DSI O Disable system indicator.
59 SUB+ O Cassette mechanism sub motor.
60 SUB- O Cassette mechanism sub motor.
61,62 - - -
63 IC2 TYPE 1 I Model switching.
64 T-MODE I Cassette mechanism mode pulse.
65 ACC-DET I ACC detection.
66 S-METER I Tuner signal meter.
67 HOLD I Clock stop mode.
68 VDD - VDD.
69 M-STBY I Cassette mechanism standby.
70 T-END I Cassette mechanism end.
71,72 - - -
73 VDD - VDD.
74~76 GND - GND.
77,78 - - -
79 GND - GND.
80 X OUT O Clock 4.5MHz.
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

KRC-366/466/566
5
ADJUSTMENT
BALANCE/FADER/BASS/TREBLE : CENTER
T. ADV/METAL/DOLBY NR/AUTO :OFF
No. Item Input Output Receiver Alignment Align For Fig.
Settings Settings Settings Points
FM Section
While holding preset “1” key,
press and hold preset “6” key
98.1MHz TEST MODE : ON for a few seconds.
1SD 0 dev –FM
Preset “1” key, and “ADJ OK” is good.
35dBµ98.1MHz preset “6” key “ADJ NG” is not good.
(ANT input) (7 seg model :
“1111” is good.
“0000” is not good.)
AM Section
While holding preset “1” key,
press and hold preset “6” key
990kHz TEST MODE : ON for a few seconds.
(1) SD 0% mod –AM
Preset “1” key, and “ADJ OK” is good.
35dBµ990kHz preset “6” key “ADJ NG” is not good.
(ANT input) (7 seg model :
“1111” is good.
“0000” is not good.)
Cassette Deck Section
TCC-153 Head azimuth screw Adjust so that output level in
1 AZIMUTH 10kHz SP OUT TAPE PLAY (FWD/REV) playing “FWD” and “REV” (a)
becomes maximum each.
DOLBY Connect an VR1 (L ch)
2 (PLAYBACK TCC-130 AC voltmeter TAPE PLAY VR2 (R ch) 300mV
LEVEL) to CN5 (X14-) (X14-)
TEST MODE : ON While holding the “FM” key and preset “6” key, reset the unit.
TEST MODE : OFF Reset the unit.
(a) AZIMUTH
FWD REV
PANEL FRONT
