Kenwood K17SJA09 User manual

Microwave Oven
K17SJA09
DSG Retail Limited is responsible for after sales services.
If you have a query about the product please contact our product support line
0844 561 6263 (Currys) and 08700 118 117 (Pixmania).
auto
reheat
defrost
clock/
pre-set
stop
start
auto menu
pizza
fish
vegetables
meat
pasta
chicken
porridge
soup
microwave potatoes
Kenwood K17SJA09_IB_GB_090907.in1 1 07/09/09 5:26:41 PM

GB-2
table of contents
table of contents 2 - 3
know your Kenwood microwave 4
safety information 4 - 8
using aluminium foil in your microwave 9
unpacking and getting ready 10
introducing microwave cooking 11 - 16
cooking with a microwave 11 - 12
microwave heating categories 13
microwave cooking 19
two-stage cooking 20
delay start cooking (program set in advance) 21
auto cooking 22 - 23
auto menu 22 - 23
quick start cooking 24
potatoes cooking 25
auto reheat 26
defrosting 27 - 28
defrost by weight 27
defrost by time 38
querying the cooking function 29
to find out the cooking power 29
to find out the time 29
to find out the pre-set time 29
cleaning your microwave 30 - 31
troubleshooting 32 - 33
questions and answers 32 - 33
specication 34
Kenwood K17SJA09_IB_GB_090907.in2 2 07/09/09 5:26:41 PM

GB-3
before use operating instructions care, maintenance and
troubleshooting
steam 14
condensation 14
product overview 14 - 15
control panel overview 15
checking your microwave 16
clock setting 17
setting the child lock 18
Kenwood K17SJA09_IB_GB_090907.in3 3 07/09/09 5:26:41 PM

GB-4
know your Kenwood microwave
before using your Kenwood microwave
● Read these instructions carefully and retain for future
reference.
● Remove all packaging labels. Please dispose of them properly.
before calling for service
● Review the section on Troubleshooting. This will help you to
solve some general problems by yourself and reduce the need
to ask for the help of professional technicians.
safety information
general safety
● Switch off and unplug before fitting or removing tools/
attachments, after use and before cleaning.
● Keep your fingers away from moving parts and fitted
attachments.
● Never use a damaged machine.
● Never operate the machine when it is empty.
● Keep cord out of the reach of children.
● Keep power unit, cord or plug away from water.
● Never exceed the maximum capacities.
● When using an attachment, read the accompanying safety
instructions.
● Take care when lifting this appliance as it is heavy.
● This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance
by a person responsible for their safety.
● Children should be supervised to ensure that they do not play
with the appliance.
● Only use the appliance for its intended domestic use.
The company responsible for this product, DSG Retail Limited,
will not accept any liability if the appliance is subjected to
improper use, or failure to comply with these instructions.
Kenwood K17SJA09_IB_GB_090907.in4 4 07/09/09 5:26:42 PM

before use
GB-5
safety information
please read carefully and keep for future
reference
maintenance of your microwave
WARNING : It is hazardous for anyone other than a
qualified technician to carry out any service or repair operation
which involves the removal of a cover that gives protection
against exposure to microwave energy.
WARNING : If the door or door seals are damaged, the
oven must not be operated until it has been
repaired by a qualified technician.
● If smoke is observed, switch off, unplug the appliance and
keep the door closed in order to contain any flames.
● If the supply cord is damaged, it must be replaced by a service
agent or a qualified technician.
● If you have a pacemaker, please contact your doctor before
using a microwave oven.
microwave use
● This microwave is not intended for commercial use.
● It should never be used for drying clothes or other non-food
purposes.
● The microwave should not be left unattended when in use.
● The temperature of accessible surfaces may be high when the
appliance is operating.
● To prevent high moisture content gathering inside the oven
cavity, open the door immediately after the cooking function
has stopped to allow steam to escape.
● Only use utensils that are suitable for microwave use.
● Care should be taken so metal objects are not used in the
microwave.
These include :
¨ Metal cooking utensils
¨ Metal plates or trays
¨ Wire twist ties
¨ Crockery with metal trims
¨ Meat thermometers
● Care should be taken when using paper, plastic, wooden or
other combustible materials in the oven as they can catch
fire.
● Oil & fat for deep frying should not be heated in the
microwave.
● Only use cling film designed for microwave use & take extra
care when removing the film to avoid steam burns.
Kenwood K17SJA09_IB_GB_090907.in5 5 07/09/09 5:26:42 PM

GB-6
safety information
cooking use
As the power of different microwave ovens can vary
considerably, care must be taken when first using this appliance
as it may cook faster than expected.
● Do not leave the appliance unattended during use.
WARNING : Only allow children to use the oven without
supervision when adequate instructions have
been given so that the child is able to use
the oven in a safe way and understands the
hazards of improper use; DO NOT assume
that because a child has mastered one
cooking skill he/she can cook everything
without close supervision. The microwave
MUST NOT be treated nor used like a toy.
● Take care when cooking food with a high sugar or fat content,
such as Christmas pudding or fruitcake. The sugar or fat can
overheat and in some cases catch fire.
fire!
In the event of fire:
● Keep the oven door closed.
● Turn off the power.
● Unplug the appliance from the mains power.
first aid
Treat scalding by:
● Quickly placing the scald under cold running water for at least
10 minutes.
● Cover with a clean dry dressing. Do not use creams, oils or
lotions.
cleaning your microwave
The oven should be cleaned regularly and food deposits
removed. Failure to maintain the oven in a clean condition can
affect the life of the appliance and possibly result in a hazardous
situation. (See cleaning your microwave )
Kenwood K17SJA09_IB_GB_090907.in6 6 07/09/09 5:26:42 PM

before use
GB-7
safety information
do not use these in your microwave
● Never use equipment made of metal, except foil in your
microwave oven. The microwave energy cannot pass through
the metal so it bounces off and sparks against the inside of the
oven.
● Stop the microwave straight away if any equipment does cause
sparks.
● Remember that some crockery has a metal trim around the
edge. Even this trim can cause sparks.
Containers / Certain foods
WARNING : Pressure will build up in sealed containers and
cause them to explode. Therefore, do not use
the following in your microwave:
¨ Sealed containers
¨ Capped bottles
¨ Vacuum containers
¨ Sealed jars
¨ Hard-boiled eggs
¨ Eggs in their shells
¨ Nuts
● Always pierce the skin of fruit and vegetables, such as
potatoes.
● Never use scratched, cracked or damaged glass in a
microwave. Damaged glass can explode.
delayed boiling
Liquids heated in a microwave can boil up when removing them
from the microwave.
Take the following precautions :
● Always stir liquids, before and after cooking.
● Allow them to stand.
● Use containers that are wider at the top than the bottom.
preparing food for babies
Extra care must be taken when preparing food or drink for babies
and small children.
● Always test the food or liquid temperature before giving it to a
baby.
● When using a baby bottle, ensure the teat is removed before
heating.
● When warming milk, ensure the bottle is shaken.
caution!
During cooking, the outer surface will become hot, do not touch
outer casing of appliance. Care should be taken not to store any
items on top of your microwave oven.
Kenwood K17SJA09_IB_GB_090907.in7 7 07/09/09 5:26:42 PM

GB-8
earthing instructions
● WARNING: THIS APPLIANCE MUST BE
EARTHED.
● This appliance is equipped with a cord having an
equipment-earthing conductor and an earthing plug.
● The plug must be plugged into an appropriate outlet that is
installed and earthed in accordance with all local standard and
requirements.
warning!
● Improper connection of the equipment-earthing conductor can
result in a risk of electric shock.
● The wires in the cord are coloured as follows:
Green and Yellow = Earth,
Blue = Neutral,
Brown = Live.
● Check with a qualified electrician or service representative if
you are in doubt whether the appliance is properly earthed.
● Never modify the plug provided with the appliance.
● If the plug does not fit properly to the outlet, have a
qualified electrician to install a proper outlet.
safety information
Kenwood K17SJA09_IB_GB_090907.in8 8 07/09/09 5:26:42 PM

before use
GB-9
using aluminium foil in your microwave
It is safe to use aluminium foil in your microwave oven as long as
you follow these safety guidelines.
As with all metal, microwave energy cannot pass through foil, but
provided that you keep the foil away from the side of the oven it
will not cause sparks and there will not be any damage to
your oven.
Using foil is a good way of shielding parts of food that you do not
want to cook as quickly as others – perhaps where the food is
narrower and would otherwise overcook.
Place the foil over the area you want to shield, taking care that
the foil will not touch the sides of the oven when the turntable
rotates. Only use one piece of foil at a time so that you do not
get sparks between the separate pieces.
Follow these guidelines when using foil in your microwave:
● Remove foil lids from containers before using in the
microwave. Some lids are made of card with a foil covering
– these should be removed too. Use a microwave-safe
transparent lid if possible.
● Stir food during cooking if the container has a lid or film cover.
● Always use the glass turntable.
● Use shallow containers with a large surface area. Do not use
containers that are more than 1.25in (3.5cm) deep.
● Use oven gloves when handling hot foil containers.
● Do not completely cover food with foil. The microwave energy
cannot pass through the foil so the food will not cook.
● Do not let aluminium foil touch the inside of the oven.
● Do not use more than one piece of foil in the oven at the same
time.
Kenwood K17SJA09_IB_GB_090907.in9 9 07/09/09 5:26:43 PM

GB-10
unpacking and getting ready
This microwave oven is designed for home use. It
should not be used for commercial catering.
1. After unpacking your oven, check that it has
not been damaged whilst in the box. Make
sure there are no dents on the oven, and the
door closes properly. A dented or damaged
oven could allow microwave energy to escape.
Make sure that you have taken all the
packaging out from the inside of the oven.
Please dispose of the plastic wrappings or
bags safely and keep them out of the reach of
babies and young children.
2. Choose a flat work surface for your microwave
away from heat sources such as radiators or
fires and away from cold areas.
You should allow a 10cm space all around the
oven and 30cm above it so that warm air can
escape from the vents during cooking – This
microwave is not designed to be built in.
3. Plug your oven into a standard household
electrical socket (230-240 volt, 13 amp rated).
Avoid using a socket that also has an adaptor
and other equipment plugged in. Do not use a
multi-adaptor.
4. Put the turntable ring inside the oven and
place the glass turntable on top of the ring.
The turntable is shaped to sit securely on the
spindle. You must always use the turntable
and ring whenever you use the microwave.
1
30cm
10cm10cm
2
1
2
auto
reheat
defrost
clock/
pre-set
stop
start
auto menu
pizza
fish
vegetables
meat
pasta
chicken
porridge
soup
microwave potatoes
porridge
potatoes
Kenwood K17SJA09_IB_GB_090907.in10 10 07/09/09 5:26:43 PM

before use
GB-11
introducing microwave cooking
Always remember the basic safeguards you would follow when
using any cooking equipment or handling hot food.
See below for basic guidelines on microwave cooking.
If you are unfamiliar with using a microwave, refer to the back of
this instruction booklet for more information.
cooking with a microwave
● Cooking with a microwave is much faster than
conventional cooking and, whilst you should make
sure that the food is fully cooked, you should also be careful
not to overcook it.
● Microwave energy can heat unevenly so stirring to distribute
heat is very important. Always stir from the outside, inwards.
● If you are cooking a number of individual foods at the same
time, such as baked potatoes or small cakes, arrange them
evenly on the turntable so that they cook evenly. Never stack
food in your microwave.
● Turn larger foods such as meat roasts and poultry during
cooking so that the top and bottom cook evenly. It is also
recommended to turn pieces of meat or poultry, especially if
they contain the bone.
● Meat and poultry which is cooked for 15 minutes or more will
brown lightly in it’s own fat. Anything cooked for a shorter time
can be brushed with a browning sauce to give an appetising
colour.
● Strips of aluminium foil can be used to cover the thinner pieces
of food to stop them overcooking before the thicker parts of
the food have had a chance to cook. Use the foil sparingly and
wrap around the food or container carefully to stop it touching
the inside of the oven which could cause sparks.
NOTE: You should always have your microwave checked by a
qualified technician if it has been dropped or damaged to
ensure it is safe to use.
Kenwood K17SJA09_IB_GB_090907.in11 11 07/09/09 5:26:43 PM

GB-12
● Microwave ovens cook food using microwave
energy that is similar to naturally occurring radio
waves. Normally, these “waves” would fade
as they dispersed into the atmosphere but in a
microwave oven they are concentrated onto the
food causing it to heat up.
● Microwave energy cannot pass through metal
– so it cannot escape from the inside of your
microwave oven – but it can pass through
materials like glass, porcelain, plastic and paper.
These materials are used in the manufacture of
microwave safe cooking equipment.
● Microwave safe cooking equipment will still get
hot as the food it contains heats up.
The microwave energy focuses on the moisture
in the food causing lots of tiny vibrations. The
vibrations get so great that the moisture, and the
food heats up. (Fig 1)
checking your cooking utensils
Most heat-resistant, non-metallic cooking utensils
are safe to use in your microwave. If you are not
sure if you can use a utensil in your microwave,
follow this simple test:
1. Put the utensil into the oven next to a cup of
water – use a cup that you know is microwave-
safe. Close the door.
2. Turn the microwave oven on for 30 seconds
only.
3. At the end of the time, carefully check to see if
the water has warmed up.
If the water has not warmed up but the utensil
has, the utensil is not microwave-safe and
should not be used in the oven.
1
Kenwood K17SJA09_IB_GB_090907.in12 12 07/09/09 5:26:44 PM

before use
GB-13
microwave heating categories
Your oven has been tested and labelled to meet the government’s voluntary agreement
on the reheating of pre-cooked food.
The heating characteristics and output power levels of microwave ovens are usually
calculated using a relatively large portion of food (a 1000 gram load, IEC 705) but many
packs of pre-cooked food are sold in smaller packs, often about 350 grams.
The government, in partnership with food companies and microwave manufacturers,
have set up a system of heating categories to help you choose the reheating time for
pre-cooked food.
800W is the output power of the oven.
E is the heating category for your oven.
Check the cooking times for category Eon
the food’s packaging to see how long it should
be cooked for. Please see below example for
reference.
To Microwave:
Remove outer packaging.
Pierce film lid SEVERAL TIMES.
Place on a microwaveable plate.
Turn the heat on to full power.
Stir or Turn halfway through heating.
Heating
Category
Wattage
(IEC 705)
B D 650W 750W
Full power
(in minutes) 2 2 2 2
Stir / Turn Stir / Turn Stir / Turn
Full power
(in minutes) 2 1.5 2 1.5
Standing time
(in minutes) 1 1 1 1
To Microwave from frozen:
Remove outer packaging.
Pierce film lid SEVERAL TIMES.
Place on a microwaveable plate.
Turn the heat on to full power.
Stir or Turn halfway through heating.
Heating
Category
Wattage
(IEC 705)
B D 650W 750W
Full power
(in minutes) 3 2.5 3 2.5
Stir / Turn Stir / Turn Stir / Turn
Full power
(in minutes) 4 3.5 4 3.5
Standing time
(in minute) 1 1 1 1
800W
E
Kenwood K17SJA09_IB_GB_090907.in13 13 07/09/09 5:26:44 PM

GB-14
auto
reheat
defrost
clock/
pre-set
stop
start
auto menu
pizza
fish
vegetables
meat
pasta
chicken
porridge
soup
microwave potatoes
steam
When you microwave food, steam is created as
water in the food heats up and evaporates.
The steam formed during microwave cooking
is entirely safe. It has to escape from the
microwave to prevent pressure from building up
inside the oven. It does this through the vents
on the back of the oven and from around the
door.
condensation
As the steam cools, you may find the
condensation gathers in small pools inside your
microwave and on the work surface beneath the
door and vents.
Always dry the oven after cooking foods with a
high moisture content.
Your microwave is designed to let steam escape
from the vents and around the door without
microwave energy escaping. (Fig 1)
There is no danger of microwave energy
escaping with the steam.
product overview
1
control panel
door button
porridge
potatoes
Kenwood K17SJA09_IB_GB_090907.in14 14 07/09/09 5:26:44 PM

before use
GB-15
auto
reheat
defrost
clock/
pre-set
stop
start
auto menu
pizza
fish
vegetables
meat
pasta
chicken
porridge
soup
microwave potatoes
Accessories
part numbers 252100500496 and 252200200011 part number 261800303068
Glass Turnable x 1
Turnable Ring x 1
Instruction Manual x 1
LED display
Shows the clock , cooking
time and setting.
control panel overview
auto reheat button
Use this button to quickly set
cooking time and reheat your
food.
defrost button
Use this button to defrost the
food by weight or by time.
stop button
Use this button to stop
cooking and clear cooking
settings.
clock/pre-set button
Use this button to set the
clock and to preset cooking
time.
time/weight/auto
menu dial
Use this dial to set time and
food weight and to choose
the auto menu programs.
start button
Use this button to do quick
start cooking of 30 seconds,
increase cooking time by 30
seconds (by each press), or
conrm cooking settings.
potato button
Use this button to select
the cooking program for
potatoes.
microwave button
Use this button to select the
microwave function.
Kenwood K17SJA09_IB_GB_090907.in15 15 07/09/09 5:26:46 PM

GB-16
auto
reheat
defrost
clock/
pre-set
stop
start
auto menu
pizza
fish
vegetables
meat
pasta
chicken
porridge
soup
microwave potatoes
checking your microwave
Check your microwave after unpacking.
NOTE: For your safety, the microwave stops if
the oven door is opened during cooking.
1. Pull the handle to open the door.
Put the turntable ring inside the oven and
place the glass turntable on top of the ring.
The turntable is shaped to sit securely on the
spindle. (Fig 1)
You must always use the glass turntable
and turntable ring whenever you use the
microwave.
Place a cup of water on the glass turntable.
Make sure the cup is microwave-safe and it
should not have any decorative metal trim.
2. Close the oven door.
3. Press the stop button to clear any
settings that have already been made. (Fig 2)
4. Press the microwave button once and then
press start button. Turn the time/weight/
auto menu dial to adjust the time of the
microwave cooking cycle, which allows you
to check the operation of the microwave
oven.
5. Press the stop button to clear any
settings once the checking is complete.
1
2
4
3 , 5
4
4
porridge
potatoes
Kenwood K17SJA09_IB_GB_090907.in16 16 07/09/09 5:26:47 PM

before use
GB-17
clock setting
When the microwave oven is connected to the mains power, the oven will display
0:00, and the microwave will sound once. Please ensure that you have set the clock
prior to use.
Please follow the steps below to set the clock.
1. Press the clock/pre-set and the hour
figures will flash.
2. Turn the time/weight/auto menu
dial to adjust the hour figures. The
input time has to be within 0-23.
3. Press the clock/pre-set and the
minute figures will flash.
4. Turn the time/weight/auto menu
dial to adjust the minute figures, the
input time has to be within 0-59.
5. Press the clock/pre-set again to
complete the clock setting.
:will start flashing and the time will
illuminate.
auto
reheat
defrost
clock/
pre-set
stop
start
auto menu
pizza
fish
vegetables
meat
pasta
chicken
porridge
soup
microwave potatoes
2
4
1
3
5
Kenwood K17SJA09_IB_GB_090907.in17 17 07/09/09 5:26:47 PM

GB-18
auto
reheat
defrost
clock/
pre-set
stop
start
auto menu
pizza
fish
vegetables
meat
pasta
chicken
porridge
soup
microwave potatoes
setting the child lock
This feature prevents the electronic operation of the oven by locking the operation of
the control panel until you have cancelled it.
Please follow the steps below to set the child lock.
1. Press the stop button for 3 seconds.
A long tone will sound and the LED dis-
play will show to indicate the
microwave has set the child lock.
2. To release the child lock, press the
stop button again for 3 seconds and
a long tone will sound to indicate the
microwave has released the child lock.
1 , 2
1
Kenwood K17SJA09_IB_GB_090907.in18 18 07/09/09 5:26:47 PM

operating instructions
GB-19
microwave cooking
For simple Microwave Cooking, follow the steps below.
For instance: If you want to use 80% microwave power to cook for 20 minutes.
1. Press the microwave button once
and the LED display will show P100.
Press the button again to change the
microwave power level to P80.
NOTE: Alternatively, after you press the
microwave button once, you
can turn the time/weight/auto
menu dial to change the power
level to P80 as well.
2. Press the start button to confirm
the microwave power level.
3. Turn the time/weight/auto menu
dial to adjust the cooking time until the
LED display shows 20:00.
4. Press the start button to confirm
and start cooking.
5. Press the stop button to stop
cooking and cancel the setting.
Microwave Button Control
Order LED Display M i c r o w a v e
Power
1 P100 100%
2 P80 80%
3 P50 50%
4 P30 30%
5 P10 10%
auto
reheat
defrost
clock/
pre-set
stop
start
auto menu
pizza
fish
vegetables
meat
pasta
chicken
porridge
soup
microwave potatoes
1
2 , 4
3
5
1 , 3
Kenwood K17SJA09_IB_GB_090907.in19 19 07/09/09 5:26:48 PM

GB-20
two-stage cooking
For Two-Stage Cooking, please follow the steps below.
For instance: If you want to defrost your food for 5 minutes and then to cook it with
80% microwave power for 7 minutes.
NOTE: You can set 2 stages for Two-
Stage Cooking at maximum. If
defrosting is among one of the
stages, then it needs to be set as
the first stage.
1. Press the defrost button twice to
initiate the multi-stage cooking with
defrost as the first stage. The LED
display will show dEF2.
2. Turn the time/weight/auto menu
dial to adjust the defrosting time until
the LED display shows 5:00.
3. Press the microwave button once and
the LED display will show P100.
Press the button again to change the
microwave power level to P80.
NOTE: Alternatively, after you press the
microwave button once, you
can turn the time/weight/auto
menu dial to change the power
level to P80 as well.
4. Press the start button to confirm
the microwave power level.
5. Turn the time/weight/auto menu
dial to adjust the cooking time until the
LED display shows 7:00.
6. Press the start button to confirm and
start cooking. The microwave oven will
sound once to indicate it has started the
defrosting count down. The microwave
oven will sound again as it starts the
microwave cooking (the second stage).
Once completed, the microwave oven
will sound five times.
7. Press the stop button to stop the cooking and cancel the setting.
auto
reheat
defrost
clock/
pre-set
stop
start
auto menu
pizza
fish
vegetables
meat
pasta
chicken
porridge
soup
microwave potatoes
1
1 , 2
3 , 5
2 , 5
4 , 6
7
3
Kenwood K17SJA09_IB_GB_090907.in20 20 07/09/09 5:26:48 PM
