2 TYKUP-01-A-BA-e-2110_RS232
GB
KERN Interface Adapter with Cable
Version 1.0 2021-09
Installation Instructions
for RS232 and Signal lamp
Contents
1General hints .............................................................................................. 2
1.1 Installation.............................................................................................................. 2
1.1.1 Allocation of connections KUP adapter:................................................................................. 3
1.1.2 Setting communication parameters: ...................................................................................... 3
1 General hints
Cable length: 1.5 m
•Via the interfaces weighing data may be exchanged with connected
peripheral devices.
•Issue may be made to a printer, PC or control displays. Control
commands and data input may also occur at reverse order via the
connected devices.
•Only KERN KUP adapters may be connected to the 15-pol-sub-D-
plug of the device!
1.1 Installation
•Switch off the balance
•Plug in the KUP adapter (RS232) at the 15-pol-sub-D-plug of the device
•Switch on device
oThe KUP adapter is automatically recognised by the appliance
