Keston C90 User manual

Users Instructions For C90
and C110 Models
The Gas Safety (Installation And Use) Regulations: 1996 (as amended) impose certain statutory
obligations on gas users. Further information regarding these regulations can be obtained from your
Gas Supplier.
All gas appliances must be installed by competent persons by law in accordance with these
regulations. Membership of CORGI is indication of such a competent person with regard to gas
installation.
It is in your interests, and that of safety, to ensure that the appliance is installed correctly and that the
law is complied with. Failure to do so could lead to a hazardous &/or potentially dangerous situation.
Introduction
These instructions should be carefully read to ensure safe and economical
use of your boiler.
The Keston C90 and C110 are high efficiency central heating condensing
boilers designed to provide central heating and indirect sanitary hot water
supply. They are designed for use with fully pumped systems only. The C90
and C110 models are supplied for natural gas use only.
Servicing
To ensure continual safe and efficient operation of the boiler it is
recommended that the appliance be checked and serviced as necessary at
regular intervals. Generally once per year will be sufficient. It is the law that
any servicing must be carried out by a competent person.
NB: There are no user serviceable parts inside the boiler cabinet. The
cabinet should only be removed by a qualified competent person.
Clearances
If fixtures are to positioned close to the boiler the following minimum
clearances must be observed: Top : 350 mm, Bottom : 150 mm, Left : 25 mm,
WD356/0/2003
page i

Right : 25 mm & Front : 305 mm. Extended clearance is required to the front
to allow for access for servicing.
Cleaning
Normal casing cleaning only requires dusting with a dry cloth. To remove
more stubborn marks wipe with a damp cloth and finish with a dry cloth.
Boiler Setup
1) Check that the gas supply from the gas meter is turned ON
2) Switch on the electric supply to the boiler and controls and set the heating
controls to call for heat.
To Light The Boiler
The C90 and C110 boilers incorporate dual thermostats to allow two different zones
to be connected to operate at two different temperatures. Generally the central
heating zone is connected to zone 1 and the DHW calorifier to zone 2. You should
ask your installer to advise whether your boiler serves one or two zones.
To set thermostat temperatures you must turn the relevant knob to the required
position. As you turn the knob both the displays, one for each module, will change to
either “c nn” or “d nn”, depending on the knob being turned. As the knob is turned the
required temperature (the last two digits of the displays) change. Set the knob to the
position which gives the required temperature. When the knob is released the
display, after a few seconds, will return to normal.
If the boiler detects whether zone requires heat the following sequence will occur:
1) The fan and pump will start inside the module and the displays will indicate “1
nn” to show the boiler modules have started the first stage of the ignition
sequence.
2) After 5 seconds the displays will change to “2 nn” to indicate the spark ignition
of the sequence has started.
WD356/0/2003
page ii

3) After 3 seconds the displays will change to “3 nn” for zone 1 and “4 nn” for
zone 2, to show the module is now alight. NG Zone 2 will be served by the left
hand module only. A demand from zone 2 will only therefore be displayed on
the upper display. If both zones call at the same time then Zone 1 will be
served by the right hand module only until such time as the left hand module
is released by zone 2.
4) The boiler will adjust the output to best match the demands of the system.
The last two digits of the display will continuously show the relevant module
temperature. The module control will allow the temperature to overshoot the
setting by up to 5 degrees before shutting down. The standard display codes
are as follows:
0 nn Module in standby as no heat request from either zone
1 nn Module commencing ignition sequence
2 nn Module generating spark ignition
3 nn Module burning for zone 1
4 nn Module burning for zone 2
5 nn Temporary mode whilst module adjusts its internal settings
6 nn Burner off because required temperature has been reached
7 nn Module at end of heat request from zone 1
8 nn Module at end of heat request from zone 2
A nn Temporary mode whilst module adjusts its internal settings
9 nn Module off due to unexpected problem. The module will attempt
to re-fire from this mode. In this mode the display will alternately
flash “9 nn” and “b xx” where the “xx” has the following meaning:
b 18 Module ran too hot, > 95
O
C flow temperature
b 19 Module ran too hot, > 95
O
C return temperature
b 24 Module circulating in reverse. Check external pump
b 25 Module rising in temperature too quickly. Check for
system blockages
b 26 Low water pressure. Top up system pressure and check
for leaks.
b 28 No signal from fan, possible stuck fan motor.
b 29 Fan running when not required.
b 30 Circulation too slow. Check system for blockages
b 65 Waiting for fan to start. Possibly stuck.
All of the above displays, up to “A nn” indicate normal module operation. Display “9
nn” indicates a delay in module operation but will not stop module operation.
Precautions
Care must be taken at all times to ensure that no blockage or obstruction is present
in the condensate drainage line. In addition the air intake and flue exhaust terminals
of the appliance must be free of obstruction at all times.
WD356/0/2003
page iii

Frost Protection
The C90 and C110 have an integral frost protection thermostat. However, care
should also be taken to ensure that any exposed pipework is adequately insulated to
prevent freezing.
Error Codes
In the event of a fault causing a module shutdown the display will show an error
message “E nn”.
Low water pressureE 44 Return thermistor open circuit - check/replace connections/thermistorE 37 Flow thermistor open circuit - check/replace connections/thermistorE 36 Return thermistor short circuit - check/replace connections/thermistorE 32 Flow thermistor short circuit - check/replace connections/thermistorE 31 Difference between flow and return temperatures too high. Check circulation.E 30 Flow temperature increased too quickly. Check water circulation.E 25 Maximum return temperature exceeded. Check circulation.E 19 Flow overheat - check water circulationE 18 Thermal fuse blown or flue overheat thermostat activated.E 12 Internal electronics error - rest or replace control boxE 11 Power has been reset whilst module was in lockoutE 04 Gas valve faulty or not connectedE 03
No ignition after restart. Check gas supply, gas valve operation, ignitor electrode spark
generation.
E 02 Flame detected when not expected. Check module earth and probe condition.E 00 Description of faultDisplay
Gas Leak or Fault
If you suspect a gas leak turn off the appliance immediately, turn off the gas
tap to the appliance and contact your local gas region without delay.
If you suspect a fault with the appliance it must not be used until the fault has
been corrected by a competent person.
In the unlikely event of a breakdown consult your Installer or Service Engineer and
advise the fault display and description of fault.
The boiler should be installed and serviced only by CORGI registered operatives. All CORGI
registered Installers carry a CORGI ID card, and have a registration number. You can check your
installer by calling CORGI direct on 01256 372300.
WD356/0/2003
page iv
