KETCHAM ELLIPSE Series User manual

When using an electrical product, basic precautions should
always be folllowed, including the following:
IMPORTANT SAFETY INSTRUCTIONS
PLEASE SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE
LED MIRROR
INSTALLATION GUIDE ELLIPSE SERIES, ELLIPSE+ SERIES
!
!
!
!
WARNING
WARNING
WARNING
WARNING
To reduce the risk of burns, fire, electric shock, injury or death,
use this product only for its intended use as described in these
instructions. Do not use attachments not recommended by the
manufacturer. Never drop or insert any object into any opening.
Do not use outdoors.
Installation should be done by a licensed professional.
Failure to follow proper installation will void warranty.
Risk of electric shock. Connect this product to a properly
grounded circuit only. See grounding instructions below.
An electrical option mirror must be wired to a 20 Amp GFI
(Ground Fault Interrupter) protected circuit when used in
bathrooms and all other locations required by the
National Electric Code.
Grounding Instructions:
This product must be connected to a grounded metal,
permanent wiring system, or an equipment-grounding
conductor must be run with the circuit conductors and
connected to the equipment-grounding terminal or lead
on the product.

A- Mirror’s Width |B- Mirror’s Height
C- Distance from Mirror Frame to Electrical Box
X- Distance Between Vertical Mounting Holes |Y- Distance Between Horizontal Mounting Holes
A<W>
<H>
B
Y
X
<Depth>
20”x 30” 24”x 36”
A20” 24”
B30” 36”
C15 ” 18 ”
X9 7/16” 11 ”
Y13 3/8” 20 1/16”
SIZE GUIDE:
C
13/4”

X
Y
Ground
B
A
Wiring from light fitting
Natural wire White(N)
Green/yellow
Live Wire
Ground(green/yellow)
Black(L)
1
DETAIL 1
1. GAP 0.2”
WALL

FINAL ASSEMBLY
Use and Maintenance:
CLEANING A STANDARD MIRROR SURFACE:
When mirror is illuminated, the defogger feature is activated.
Touch the dimmer switch to turn the light on or off. Press and hold the dimmer switch to dim or
brighten the lights. The dimmer switch stores the current light level intensity when switched off
and on.
-Mirror and mirror body are constructed of mirrored glass and aluminum. Use a damp cloth
to clean your mirror. Do not use any abrasive material as it may damage the surface and
finish of the mirror.
-A mild detergent may be used to clean the surfaces of the mirror.
-When cleaning, spray the cloth, not the mirror or surrounding surfaces.
How to use Defogger Feature and Dimmer Switch:
** if applicable
