Keydiy KD900 User manual
JUST FOR LOCKSMITH
KD900
www.keydiy.com
KD900 Operation Manual
1 FREQUENCY TEST
2 GENERATE REMOTE
3 SMART MATCH
4 ALARM/GARAGE
5 OTHER FUNCTIONS
6 SETTINGS
6 Functions
AL BARAKA KEY TRADING
ABK-1008 MANUAL
www.abkeys.com
Page 1
1
CONTENTS
Part 1 KEYDIY Remotes
Part 2 KD900 CAR APPLICATION LIST
-----------PC Data Cable
Machine----------------
------25 Commonly Used Keyblandes
2 Commonly Used Remotes----------------------- -----------Spare Remote Data Cable
------------Remote Data Cable
-
-
Part 3 KD900 Device Operation
Part 4 KD900 Software Operation
Page 2-3
Page 4-17
Page 18-70
Page 71-117
AL BARAKA KEY TRADING
ABK-1008 MANUAL
www.abkeys.com
Page 2
2 3
Part 1
KEYDIY REMOTES TYPES
B Series
F Series For Two Remotes In One
B01 B02 B03 B04 B05 B06
F01
All B serie remotes with same data inside but different shape, all can be made to the
remotes of our support list.
All KEYDIY remotes can make remotes with 300-500MHZ frequency, thus as 310MHZ,
313MHZ, 314MHZ, 315MHZ, 433MHZ and so on.
AL BARAKA KEY TRADING
ABK-1008 MANUAL
www.abkeys.com
Page 3
4 5
BRAND MODEL YEAR Ref ORIGINAL FREQUENCY TRANSPONDER Ref KD
AUDI A3 (2 bout) 1997-00 4D0837231R 433 Mhz Megamos Grypto ID48 4D0837231R
KD900 REMOTE APPLICATION LIST(Europe area)
AUDI A3 (3 bout) 2002-05 4D0837231A 433 Mhz Megamos Grypto ID48 4D0837231A
AUDI A3 (3 bout) 2002-05 4D0837231N 433 Mhz Megamos Grypto ID48 4D0837231N
AUDI A4 (2 bout) 1995-01 4D0837231R 433 Mhz Megamos Grypto ID48 4D0837231R
AUDI A4 (3 bout) 1999-01 4D0837231A 433 Mhz Megamos Grypto ID48 4D0837231A
AUDI A4 (3 bout) 1999-01 4D0837231N 433 Mhz Megamos Grypto ID48 4D0837231N
AUDI A4 (3 bout+PANIC) 1997-03 4D0837231E 315 Mhz Megamos Grypto ID48 4D0837231E
AUDI A4 (3 bout) 1997-04 4D0837231M 315 Mhz Megamos Grypto ID48 4D0837231M
AUDI A6 (2 bout) 1997-01 4D0837231R 433 Mhz Megamos Grypto ID48 4D0837231R
AUDI A6 (3 bout) 1997-05 4D0837231A 433 Mhz Megamos Grypto ID48 4D0837231A
AUDI A6 (3 bout) 1997-05 4D0837231N 433 Mhz Megamos Grypto ID48 4D0837231N
AUDI A6 (3 bout) 1997-04 4D0837231M 315 Mhz Megamos Grypto ID48 4D0837231M
AUDI A6 (3 bout+PANIC) 1997-03 4D0837231E 315 Mhz Megamos Grypto ID48 4D0837231E
AUDI A6 (3 bout) 2002-05 4D0837231K 433 Mhz Megamos Grypto ID48 4D0837231K
AUDI A6 Allroad (3 bout) 2002-05 4D0837231K 433 Mhz Megamos Grypto ID48 4D0837231K
AUDI A6 Quatro (3 bout) 2000-05 4D0837231K 433 Mhz Megamos Grypto ID48 4D0837231K
AUDI A6 (3 bout+PANIC) 4D0837231P 315 Mhz Megamos Grypto ID48 4D0837231P
AUDI A8 (3 bout) 1994-03 4D0837231A 433 Mhz Megamos Grypto ID48 4D0837231A
AUDI A8 (3 bout) 1994-03 4D0837231N 433 Mhz Megamos Grypto ID48 4D0837231N
AUDI A8 (3 bout) 1997-04 4D0837231M 315Mhz Megamos Grypto ID48 4D0837231M
AUDI A8 (3 bout+PANIC) 1997-04 4D0837231E 315 Mhz Megamos Grypto ID48 4D0837231E
AUDI Cabrio 2 bout 1992-00 4D0837231R 433 Mhz Megamos Grypto ID48 4D0837231R
AUDI Roadster (3bout) 2000-05 4D0837231K 433 Mhz Megamos Grypto ID48 4D0837231K
AUDI RS4 (2 bout) 2001-02 4D0837231R 433 Mhz Megamos Grypto ID48 4D0837231R
AUDI RS4 (3 bout) 2001-02 4D0837231A 433 Mhz Megamos Grypto ID48 4D0837231A
AUDI RS4 (3 bout) 2001-02 4D0837231N 433 Mhz Megamos Grypto ID48 4D0837231N
AUDI RS6 (3 bout) 2003-05 4D0837231K 433 Mhz Megamos Grypto ID48 4D0837231K
AUDI S4 (3 bout+PANIC) 1997-03 4D0837231E 315 Mhz Megamos Grypto ID48 4D0837231E
AUDI TT (3 bout) 1999-02 4D0837231A 433 Mhz Megamos Grypto ID48 4D0837231A
AUDI TT (3 bout) 1999-02 4D0837231N 433 Mhz Megamos Grypto ID48 4D0837231N
AUDI TT (3 bout) 2003-06 4D0837231K 433 Mhz Megamos Grypto ID48 4D0837231K
AUDI TT (3 bout) 1997-04 4D0837231K 315 Mhz Megamos Grypto ID48 4D0837231K
AUDI TT (3 bout+PANIC) 1997-05 4D0837231E 315 Mhz Megamos Grypto ID48 4D0837231E
