Keysight Technologies P50 B Series User manual

Quick Start Guide
P50xxB/P937xB/P938xB Series
Keysight Streamline Series VNA,
Thunderbolt 3
System Requirements
Description
Requirements
Operating system
Windows 10 (64 bit only)
a
Available memory
16 GB recommend, 4 GB minimum
Available disk space
2 GB available drive space minimum
Display resolution
1024 x 768 minimum
Recommended CPU
Intel Core i7 10th Generation or later
Connected with VNA
ThunderboltTM 3
a. Must install IO Libraries Suite 2021 update or greater.
Installation Procedure
Please use ESD Precautions when handling and operating
1. Download and install the Keysight IO Libraries Suite
from https://www.keysight.com/find/iosuite. Follow
the installer prompts.
2. Download and install the network analyzer software
from https://www.keysight.com/find/pxiusbvna-
firmware. Follow the installer prompts.
3. Shutdown a PC once the installation is done.
4. Connect the included Thunderbolt3 cable to either of
port on the Network Analyzer rear panel and the other
end of the cable directly to a Thunderbolt3 (USB-C)
port on the PC.
For P502xB-402 or P5025/6/7/8B-400,
connect the control cable and tighten it with
the nuts as shown in the image above.

P50xxB/P937xB/P938xB Quick Start Guide
Additional information:
Topic
URL
Product information http://www.keysight.com/products/P5000B
http://www.keysight.com/products/P9370B
Manuals
http://www.keysight.com/manuals/P5000B
Technical support
http://www.keysight.com/support/P5000B
Multiple modules setup
Help: Quick Start > Multiport and Multisite Configuration
Connector Care
http://na.support.keysight.com/pna/connectorcare/Connector_Care.htm
Contacting Keysight
http://www.keysight.com/find/assist
5. Plug in the AC adapter to the back of the
instrument and then plug it into the AC power.
6. Press the power button to
power up
the
instrument first. Confirm if the Power LED is green.
7. Then, power on the PC, click the
Network Analyzer
icon on the PC destktop to execute the VNA
application.
8. Select the required model, then click RUN.
Confirm if the instrument status is green.See the
Help: Quick Start > SFP Launcher for more
information.
Note:
When the unit is not detected, reboot
PC. If it does not resolve, apply the latest
windows update and update the computer
BIOS and the thunderbolt driver and firmware.
The P50xxB/P937xB/P938xB VNAs have the right side of the
instrument dedicated to air intake and the left side dedicated to
This information is subject to
change without notice.
© Keysight Technologies 2021
Edition 2, September 2021
www.keysight.com
