Keysight Technologies P5000A Series User manual

Quick Start Guide
P5000A Series USB-
Vector Network Analyzer
System Requirements
Description
Requirements
Operating system
Windows 7 SP1 or Windows 10 (64 bit)
a
Processor speed
Intel i5 6
th
Generation or newer/ Intel Xeon E3 v3 or newer
Available memory
4 GB minimum
Available disk space
2 GB available drive space minimum
Display resolution
1024 x 768 minimum
USB
USB 3.0 port directly connected to Intel chipset
a. Must install IO Libraries Suite 2018 Update 1 or greater.
Installation Procedure
1. Install the Keysight IO Libraries Suite, using either Keysight IO Libraries Suite CD included with your
shipment, or the downloadable file at www.keysight.com/find/iosuite. Follow the installer prompts.
2. Download the network analyzer software from http://www.keysight.com/support/P5000A webpage, click
the Drivers, Firmware & Software tab.
3. Execute and Install the network analyzer software according to the installer prompts.
Please use ESD Precautions when handling and operating

(P5000A Series USB-VNA) Quick Start Guide
Additional
information:
Topic
URL
Product information
http://www.keysight.com/products/P5000A
Manuals
http://www.keysight.com/manuals/P5000A
Technical support
http://www.keysight.com/support/P5000A
Multiple modules setup
FAQ in http://www.keysight.com/support/P5000A
Connector Care
http://na.support.keysight.com/pna/connectorcare/Connector_Care.htm
Contacting Keysight
http://www.keysight.com/find/assist
4. Connect the included USB 3.0 Type C
cable to the P50xxA and the other end of
the cable directly to a USB 3.0 port on a
PC (USB 2.0 is not supported).
5. Ensure that Step 3 is completed before
pressing firmly to plug in the AC adapter to
the back of the instrument and then plug it
into the AC power. Press the power button
to
power up
the instrument.
6. On the PC, click the Network Analyzer icon
to execute the VNA application.
The P50xxA VNA has the right side of the instrument dedicated
to air intake and the left side dedicated to air exhaust.
This information is subject to
change without
notice.
© Keysight Technologies 2018
Edition 1, Oct 2018
