APS-M1010/APS-ONE-100 Platform for IxLoad
Release 9.45
Installation Guide

Notices
Copyright Notice
© Keysight Technologies 2023
No part of this document may be repro-
duced in any form or by any means (includ-
ing electronic storage and retrieval or
translation into a foreign language) without
prior agreement and written consent from
Keysight Technologies, Inc. as governed by
United States and international copyright
laws.
Warranty
The material contained in this document is
provided “as is,” and is subject to being
changed, without notice, in future editions.
Further, to the maximum extent permitted
by applicable law, Keysight disclaims all war-
ranties, either express or implied, with
regard to this manual and any information
contained herein, including but not limited
to the implied warranties of merchantability
and fitness for a particular purpose.
Keysight shall not be liable for errors or for
incidental or consequential damages in con-
nection with the furnishing, use, or per-
formance of this document or of any
information contained herein. Should
Keysight and the user have a separate writ-
ten agreement with warranty terms cov-
ering the material in this document that
conflict with these terms, the warranty
terms in the separate agreement shall con-
trol.
Technology Licenses
The hardware and/or software described in
this document are furnished under a license
and may be used or copied only in accord-
ance with the terms of such license.
U.S. Government Rights
The Software is "commercial computer soft-
ware," as defined by Federal Acquisition
Regulation ("FAR") 2.101. Pursuant to FAR
12.212 and 27.405-3 and Department of
Defense FAR Supplement ("DFARS")
227.7202, the U.S. government acquires
commercial computer software under the
same terms by which the software is cus-
tomarily provided to the public. Accordingly,
Keysight provides the Software to U.S. gov-
ernment customers under its standard com-
mercial license, which is embodied in its End
User License Agreement (EULA), a copy of
which can be found at http://www.key-
sight.com/find/sweula. The license set forth
in the EULA represents the exclusive author-
ity by which the U.S. government may use,
modify, distribute, or disclose the Software.
The EULA and the license set forth therein,
does not require or permit, among other
things, that Keysight: (1) Furnish technical
information related to commercial com-
puter software or commercial computer
software documentation that is not cus-
tomarily provided to the public; or (2) Relin-
quish to, or otherwise provide, the
government rights in excess of these rights
customarily provided to the public to use,
modify, reproduce, release, perform, dis-
play, or disclose commercial computer soft-
ware or commercial computer software
documentation. No additional government
requirements beyond those set forth in the
EULA shall apply, except to the extent that
those terms, rights, or licenses are explicitly
required from all providers of commercial
computer software pursuant to the FAR and
the DFARS and are set forth specifically in
writing elsewhere in the EULA. Keysight
shall be under no obligation to update,
revise or otherwise modify the Software.
With respect to any technical data as
defined by FAR 2.101, pursuant to FAR
12.211 and 27.404.2 and DFARS 227.7102,
the U.S. government acquires no greater
than Limited Rights as defined in FAR
27.401 or DFAR 227.7103-5 (c), as applic-
able in any technical data. 52.227-14 (June
1987) or DFAR 252.227-7015 (b)(2) (Novem-
ber 1995), as applicable in any technical
data.
Safety Information
Do not proceed beyond a hazard notice
until the indicated conditions are fully
understood and met.
ACAUTION notice denotes a hazardous
situation that, if not avoided, could res-
ult in minor or moderate injury.
AWARNING notice denotes a haz-
ardous situation that, if not avoided,
could result in death or serious injury.
– 2 –

Contacting Us
Keysight headquarters
1400 Fountaingrove Parkway
Santa Rosa, CA 95403-1738
www.ixiacom.com/contact/info
Support
Global Support [phone] [email protected]
Regional and local support contacts:
APAC Support [phone] [email protected]
Australia [phone] [email protected]
EMEA Support [phone] [email protected]
Greater ChinaRegion [phone] [email protected]
Hong Kong [phone] [email protected]
India Office [phone] [email protected]
Japan Head Office [phone] [email protected]
Korea Office [phone] [email protected]
Singapore Office [phone] [email protected]
Taiwan (local toll-free number) 00801856991 [email protected]
– 3 –
APS-M1010/APS-ONE-100 Platform for IxLoad

Table of Contents
Contacting Us 3
Chapter 1 Product overview 6
Chapter 2 Functionality overview 7
Rack mounting 9
Aggregation modes 13
Chapter 3 Port aggregation 15
Mode 1 - Aggregated mode (default mode) 15
Mode 2 – Non-Aggregated mode 16
How to configure the Aggregation mode 17
Chapter 4 Related documentation 18
Chapter 5 Unpacking and inspection 19
Chapter 6 Front panel indicators 20
Chapter 7 Management Node and Compute Node ports and connectivity 22
Chapter 8 Connect power to the Management Node and Compute Nodes 24
Chapter 9 Connect DUTs for testing 25
Chapter 10 Install software packages 26
Chapter 11 Add IxLoad-ATI licenses 28
Chapter 12 Accessing the IxLoad user interface 29
IP Configuration using the KCOS CLI 30
Chapter 13 Assigning ports to an IxLoad test 32
Appendix A Regulatory Compliance information 34
Regulatory specifications 35
Regulatory marks 36
Appendix B Troubleshooting 38
Basic debugging and troubleshooting 38
Check Compute Node connectivity 39
– 4 –
APS-M1010/APS-ONE-100 Platform for IxLoad

Appendix C KCOS Compute Node reboot (card hot swap) 40
Index 41
– 5 –

CHAPTER 1
Product overview
Welcome to the Keysight APS-M1010/APS-ONE-100 Platform documentation for IxLoad.
The APS-M1010/APS-ONE-100 Platform provides next-generation ultra-high-performance Layer 4 -
Layer 7 application and security testing, TLS support and 100G Interfaces. Industry-proven IxLoad
is the user interface application.
The platform consists of one management node (MN) or controller, that can manage up to ten
compute nodes (CN) and the Keysight Cluster Operating System (KCOS).
Both components of the APS-M1010/APS-ONE-100 Platform are required.
Standalone APS-ONE-100 functionality is NOT supported for IxLoad
lThe management node is used to manage the entire cluster of compute nodes and expose
administrative and test configuration functionalities to the user.
lThe compute nodes are used for generating custom traffic. They have QSFP28 interfaces for
connecting devices under test (DUTs). Compute nodes must have a functional management
node to operate.
lKeysight Cluster Operating System (KCOS) is the base operating system. It provides a
command line interface (CLI) and a command shell to enable user control of the various
services. It is a purpose-built platform that provides essential services, including host
management, user access control, software upgrades and cluster orchestration.
– 6 –
APS-M1010/APS-ONE-100 Platform for IxLoad

CHAPTER 2
Functionality overview
This chapter provides a functional overview of the APS-M1010/APS-ONE-100 Platform for IxLoad.
The entire system runs on the Keysight Cluster Operating System (KCOS). To perform any system-
level operation, you will need to use KCOS CLI commands (see the APS-100/400GE Series Plaform,
KCOS Command Line Interface (CLI), For IxLoad Release 9.45, CLI Reference Guide).
The following diagram provides a high-level system overview.
Management Node: The first block in the diagram represents the APS-M1010 Management Node
(MN). The MN is used to manage all of the compute nodes and provide administrative and test
configuration options to the user.
Chapter 2 Functionality overview
– 7 –

Compute Nodes: The second and third blocks in the diagram represent Compute Nodes. The
Compute Nodes are used for generating custom traffic. They have interfaces for connecting devices
under test (DUTs).
The "TestPorts" shown in the preceding diagram are displayed as Ports in the
IxLoad GUI.
Compute Nodes must have a functional Management Node to operate.
The bandwidth of each physical NIC shown in the diagram (consisting of 2 x
100G interfaces) is limited to 100G.
Chapter 2 Functionality overview
– 8 –

Rack mounting
The following guidelines are provided to optimize the device performance.
lMake sure cabling is away from sources of electrical noise. Radios, power lines, and fluorescent
lighting fixtures can interfere with the device performance.
lMake sure the cabling is positioned away from equipment that can damage the cables.
lOperating environment is within the ranges listed in the data sheet and installation guide.
lMake sure airflow around the APS-M1010/APS-ONE-100 and respective vents is unrestricted.
To rack mount the APS-M1010/APS-ONE-100 chassis:
1. Pull the inner rail out of the slide rail until it clicks.
2. Detach the inner rail completely from the slide rail by pulling the white tab forward.
3. After the inner rail is dislodged, adjust the middle rail back to its original position by pushing the
tab on the middle rail.
4. Install the inner rail onto the system barebone. Lock the keyholes and secure the screws on
sides of the system.
Chapter 2 Functionality overview
– 9 –

5. Continue installing the outer rail bracket to the mounting frame. Attach the outer rail
assembling to the frame and press the bracket to form a rack on both ends. Repeat to fully
mount the bracket assembly on the other side.
Chapter 2 Functionality overview
– 10 –

6. Pull out the middle channel until the ball bearing retainer is locked forward.
Verify ball bearing retainer is locked forward.
Chapter 2 Functionality overview
– 11 –

7. Slide the release tab and push barebone into rack. Make sure the barebone is completely
installed onto the rack.
8. Repeat this procedure until all components are rack mounted.
Chapter 2 Functionality overview
– 12 –

Aggregation modes
IxLoad on the M1010/APS-ONE-100 Platform supports two modes:
lMode 1 -Aggregated Mode (default mode)
lMode 2 -Non-Aggregated Mode
Switching between aggregation modes is not recommended at this time. This
functionality will be supported in a future release.
Mode 1 - Aggregated mode (default mode)
Aggregated mode is the default mode.
In the Aggregated mode, two Test Ports are mapped to a single physical port as shown in the
preceding diagram. All traffic will be sent and received through these physical ports (Port-1 and Port-
3 in the diagram) which are active links.
lTestPort-1 and TestPort-2 are mapped to physical Port-1
lTestPort-3 and TestPort-4 are mapped to physical Port-3
These specific port mappings are required but this limitation will be removed in a
future release.
In this mode, the user needs to assign TestPort-1 and TestPort-2 together in a NetTraffic
configuration. Similarly, TestPort-3 & TestPort-4 need to be assigned together in a NetTraffic
configuration.
There are twoTestPorts in a NetTraffic configuration. This will require at least
two IP addresses in an IP-Range.
Mode 2 – Non-Aggregated mode
In this mode:
lEach TestPort needs to be mapped to an individual physical Port.
lTestPorts can be assigned to different NetTraffic configurations
Chapter 2 Functionality overview
– 13 –

The preceding diagram is an example of one of the supported TestPort-to-
physical-port configurations. TestPort-1 could be mapped to Port-2, TestPort-2
could be mapped to Port-4, etc.
Chapter 2 Functionality overview
– 14 –

CHAPTER 3
Port aggregation
IxLoad on the M1010/APS-ONE-100 Platform supports an Aggregated Mode (default mode) and a
Non-Aggregated mode.
lAggregated Mode (default mode)
lNon-Aggregated Mode
lHow to configure the Aggregation mode
Mode 1 - Aggregated mode (default mode)
Aggregated mode is the default mode.
In the Aggregated mode, two Test Ports are mapped to a single physical port as shown in the
preceding diagram. All traffic will be sent and received through these physical ports (Port-1 and
Port-3 in the diagram) which are active links.
lTestPort-1 and TestPort-2 are mapped to physical Port-1
lTestPort-3 and TestPort-4 are mapped to physical Port-3
These specific port mappings are required but this limitation will be removed in
a future release.
In this mode, the user needs to assign TestPort-1 and TestPort-2 together in a NetTraffic. Similarly,
TestPort-3 & TestPort-4 need to be assigned together in a NetTraffic.
There are two TestPorts in a NetTraffic configuration. This will require at least
two IP addresses in an IP-Range.
– 15 –
APS-M1010/APS-ONE-100 Platform for IxLoad

Mode 2 – Non-Aggregated mode
In this mode:
lEach TestPort needs to be mapped to an individual physical Port
lTestPorts can be assigned to different NetTraffics
The preceding diagram is an example of one of the supported TestPort-to-
physical-port configurations. TestPort-1 could be mapped to Port-2, TestPort-2
could be mapped to Port-4, etc.
Chapter 3 Port aggregation
– 16 –

How to configure the Aggregation mode
In the IxLoad UI, you use use a card's context menu to select the aggregation mode as shown in the
following image.
In Aggregated mode, you cannot select an individual TestPort. When TestPort 1
is selected, TestPort-2 will automatically be selected. The secondary port will
appear to be grayed out in Aggregated mode.
Chapter 3 Port aggregation
– 17 –

CHAPTER 4
Related documentation
The latest documentation for each release can be found on the Ixia Support website.
Documentation Description
APS-M1010/APS-ONE-100 Release Notes Provides information about new features,
resolved customer issues, known defects and
workarounds (if available).
APS-100/400GE Series Plaform, KCOS
Command Line Interface (CLI), For IxLoad
Release 9.45, CLI Reference Guide
This guide describes the commands that make
up the command-line interface (CLI) for the
APS-M1010/APS-CN100.
IxLoad User Guide Provides information on how to use IxLoad to
set up, run and customize tests.
– 18 –
APS-M1010/APS-ONE-100 Platform for IxLoad

CHAPTER 5
Unpacking and inspection
Carefully unpack the APS-M1010/APS-ONE-100 Platform components. Each node that is described
below is shipped in its own box.
One Management Node
l1U APS-M1010 Management Node
l2 power cords region specific
l1 Tool-less Rackmount Rail Kit
l1 Micro USB to USB A cable
Up to 10 x APS-ONE Compute Nodes
Each box contains:
l1U APS-ONE-100 Compute Node
l2 power cords region specific
l1 Tool-less Rackmount Rail Kit
l1 Micro USB to USB A cable
l1 Ethernet cable
– 19 –
APS-M1010/APS-ONE-100 Platform for IxLoad

CHAPTER 6
Front panel indicators
Item Description
Power button
Power status LED indicator
Drive activity LED indicator
LAN LED indicator
System alert LED indicator
System reset LED indicator
Reset button
Luggage tag Shown on the preceding chassis image
2 x USB 3.0 Type a port Shown on the preceding chassis image
– 20 –
APS-M1010/APS-ONE-100 Platform for IxLoad
