KinCony KC868-H2 User manual

Page 1
KC868-H2 Device User Manual (V0612)
Ⅰ. Soft are Do nloading #####################.##Page 1
Ⅱ. Remote Controlling Operation ###################...Page1
1. Mobile APP controlling manual ###############...#####..## Page 1
2. Computer Program controlling manual (WAN mode)#####...######## Page 5
Ⅲ. Local Controlling Operation (LAN mode) #########....#####Page6
1. Configuration Setting ##################.##..##..####. Page 6
2. Computer Program Setting ################.###..#####.. Page 7
※Important: The “Remote Controlling” and the “Local Controlling” are alternative;
You must choose one of them for using.
Ⅰ. Soft are Do nloading
1. Use mobile phone to scan the belo QR code to do nload the APP
2. KC868-H2 soft are (Phone APP QR code, PC Program, Vircom Net ork Tool) do nloading link:
www.kincony.com/download/Disk_KC868-H2.rar
Please download the file to have the software firstly as below it is default you already have and know them.
Ⅱ. Remote Controlling Operation
1. Mobile APP controlling manual
1.1 Po er on the device and connect the internet cable
1.2 Register
Downloading and installing the APP
Register your account (11 digitals) and password
(Pls make a note for your password in case forgotten).

Page 2
1.3 Adding device
1.3.1: Login in
Choose 【 Mine 】 - 【 My Room 】
Add Floor and Room
(Be necessary! Make sure this step)
1.3.2: Floor and Room can be re-named;
Click 【 OK 】
1.3.3: Choose 【 Mine 】 - 【 Host Manager 】
1.3.4: Click 【 add 】
Scan the QR code on the device
Input a name for the device.
Click 【 Add 】 .
1.3.5: Click 【 Mine 】 - 【 My Device 】
- 【 Unclassified 】
Hold pressing the ICON
Choose one room for the device
Input a name
1.3.6: Click to enter control page
1.3.7: Hold pressing the name of the relay
Input new name
1.3.8: Click 【 OK 】
1.3.1
1.3.
2
1.3.
3
1.3.
4
1.3.
5
1.3.
7
1.3.
6

Page 3
1.4 When there is the camera, open it at the home page.
Then it can be sho ed hen entering into the control page.
1.5 Scene linkage operation
1.5.1 Create Scene Mode
Login in APP Click 【 Scene 】 — 【 + 】 or 【 Add 】 --Input Mode name ， choose Mode icon ，
Time setting Optional(Function of timing) at 【 Mode setting 】 input the actions you want to control click 【 Save 】 ;
See below pic1.5-1 ， pic1.5-2 ， pic1.5-. ， pic1.5-4 。
Pic1.5-1 Pic1.5-2 Pic1.5-3 Pic1.5-4
Add Scene Add Scene 2 Time setting (Optional) Mode setting (Action
controlled)

Page 4
“Mode name” can be named; e.g.: Back Home ， Leaving Home ， Meeting ；
“Mode icon” can be changed ；
“Time setting” is for timing (optional) ， Pic1.5-3 ， Repeated time: Monday Tuesday Wednesday and 7:10 am.
Meaning the scene mode is opened at 7:10 am each Monday Tuesday and Wednesday.
“Mode setting” is for adding the actions required to control
1. Press ‘Click to add action’ choose KC868H8
2. Press [Enter the ctrl pg] you can set the actions see Pic4-7
a. Open light1
b. Press the name it will save the action
3. Press Execute you can set Delay time
4. Press ‘Save’
See Pic1.5-5 Pic1.5-6 ， Pic1.5-7 。
Pic1.5-5 Pic1.5-6 Pic1.5-7
Set light1 opened successfully
1. Open light1
2. Press the name to
save the action

Page 5
2. Computer Program controlling manual (WAN mode)
2.1 Po er on the device and connect the internet cable
2.2 Double click “ActiveX Installer.exe” to install it.
(No need to install for future)
2.3 Double click “Net_Relay_Control.exe” to open it.
2.4 Setup the configuration as belo steps
2.4.1: Choose 【 Mode 】 - 【 WAN 】
2.4.2: Click 【 Control Name 】 - 【 Device Config 】
2.4.3: Input Name and Serial Number(S/N)
(Serial Number is the 24 digitals on the QR code
Labeling on the device)
2.4.4: If more devices Input name and S/N accordingly.
Total four devices can be controlled.
2.4.5: Click 【 Save 】
2.4.6: Re-start the program (very important)
2.4.7: Choose Controller
2.4.8: Close the program and open it again.
2.4.9: Choose 【 Mode 】 - 【 WAN 】
2.4.10: Control the device
2.4.1
2.4.2
2.4.7
2.4.3

Page 6
Ⅲ. Local Controlling Operation (LAN mode)
1. Configuration Setting
1.1 Po er on the device and connect the internet cable
1.2 Make sure your computer and the device are belonging to the same local internet
1.3 Open the “Vircom Net ork Tool”
1.4 Set the configuration of the device.
1.4.1 : Click 【 Device 】
1.4.2: Click 【 Auto Search 】
1.4.3: Click 【 Edit Device 】
1.4.4: Enter into page
【 Device Settings 】
1.4.1
1.4.2
1.4.3
1.4.4
1.4.4

Page 7
1.4.5: Choose “TCP Server” for the 【 Work Mode 】， instead of “UDP”
1.4.6: Keep the others unchanging;
Remember the IP Address and Port
1.4.7: Click 【 Modify Setting 】
1.4.8: Re-power the device and do the following part 2.
2. Computer Program Setting
2.1 Double click “ActiveX Installer.exe” to install it for first time using.
(No need to install in future)
2.2 Open “Net_Relay_Control.exe”.
2.3 Set the configuration as belo steps
2.3.1: Choose 【 System 】 - 【 Parameter Config 】
2.3.1
1.4.5

Page 8
2.3.2: Input the IP number and Port number. If not remembered check back from the Vircom tool
2.3.3: Click 【 Save 】
Re-start the program (Very important)
2.3.4: Click 【 Local Control 】 - 【 LAN Connect 】
【 Connect OK! 】 showed at the bottom
2.3.5: Click 【 Local Control 】 - 【 Initialization 】
【 Initialization completion 】 showed
at the bottom
2.3.6: Control the device locally
2.3.4
2.3.4
2.3.5
2.3.5
2.3.2
