KIND KD-C1000NW Instruction manual
Please read this manual carefully before using the machine and keep it for future reference.

WWW.KINDLIVECAST.COM
Beijing kind network technology co.ltd.
1
CATALOGUE
一、Product overview...........................................................................................................2
Matters needing attention：.....................................................................................3
二、Connection specification............................................................................................5
三、Camera debugging instructions .............................................................................. 7
Menu introduction........................................................................................................7
（一）、EXPOSURE.................................................................................................. 8
（二）FOUCS......................................................................................................... 10
（三）WB.................................................................................................................11
（四）SYSTEM....................................................................................................... 12
（五）IMAGE..........................................................................................................13
四、Remote control debugging instructions............................................................14
五、Packing list.....................................................................................................................16
六、After-sales service .......................................................................................................17

WWW.KINDLIVECAST.COM
Beijing kind network technology co.ltd.
2
一、Product overview
1、1/2.5 inch Exmor R CMOS imager with broadcast-quality 4K images.
2、20x optical zoom, SRZ 4K 30x, HD 40x.
3、servo motor high speed head, translation/pitching speed 0.1°~300°/ s.
4、8.93 million pixels, 3840×2160 1920*1080 resolution.
5、HDMI video output.
6、360°TALLY lamp.
7、Application: 4K image shooting, studio, media broadcast, multi-camera
shooting.
8、size: 160mm155mm×230mm; Weight: about 3.0kg.

WWW.KINDLIVECAST.COM
Beijing kind network technology co.ltd.
3
Matters needing attention：
Before use, please read this manual carefully, and please take the retention of
instruction.
Please do comply with the products identified on the warning signs and
instructions.
Before cleaning the machine, please pull the plug, do not use alcohol, thinner,
pesticides or other volatile solvent, because doing so would make the shell
deformation or damage to the surface.
Using extension, please confirm the total quantity/total Ann used multiple,
shall not exceed the total load by extension multiples.
Do not any liquid splashes on this product. Avoid short circuit.
Please not do STH without authorization for dismantling maintenance.
If you have the following situations occurs. Please unplug this product and
contact a qualified technician.
①The power cord or plug is damaged or peeled.
②There is liquid seeping into the product.
③If this product has been rained on or splashed with water.
When transported to equipment installed in the original packaging box, or a
similar package, the equipment can be reduced by strong vibration.

WWW.KINDLIVECAST.COM
Beijing kind network technology co.ltd.
4
Product and service disclaimer
The information provided in this manual is intended as a guide only. All along,
KIND strives to provide correct, complete and appropriate information. However,
KIND cannot exclude that some information in this manual may be incorrect or
incomplete and that this manual may contain typos, omissions or incorrect
information. KIND recommends that you double-check the accuracy of the
information in this document, and KIND is not liable for any omissions or errors. Or
any subsequent loss or damage resulting from the information provided in this
Description, further information about the contents of this description or the
products may be obtained by contacting local offices or KIND Headquarters.
For your safety, please do not let the equipment receive rain or damp. In case
of failure, please do not remove the casing. For after-sales matters, contact the
manufacturer to ask professional engineers for maintenance.
When recording or transferring important data, be sure to pre-check the
device connection or perform a test first to ensure proper operation and avoid
data loss.
According to copyright law, recorded video or audio may not be used for any
purpose other than personal enjoyment without the permission of the copyright
holder. Note that for live performances, performances and exhibitions, even your
own entertainment may be restricted.

WWW.KINDLIVECAST.COM
Beijing kind network technology co.ltd.
5
二、Connection specification
1、ADDR: Control camera address (0 is 1,1 is 2, and so on).
2、485 control.
3、HDMI output.
4、12VPower interface.

WWW.KINDLIVECAST.COM
Beijing kind network technology co.ltd.
6
Connection step：
⑴Connect the bottom of the camera ① to the top of the lifting device ①, as shown
in the following figure.

WWW.KINDLIVECAST.COM
Beijing kind network technology co.ltd.
7
⑵Secure the camera with screws, as shown below.
⑶The HDMI port on the rear of the camera connects to the HDMI port on the
wireless transmission box.
⑷ The 12V power interface is connected to the wireless transmission box
interface (the picture below shows the wireless transmission box).
Wireless transmission box
三、Camera debugging instructions
Menu introduction
This section describes the Settings menu of the camera

WWW.KINDLIVECAST.COM
Beijing kind network technology co.ltd.
8
1. Click the "OK" key of the driver or the "MENU" key of the remote control of the
camera to enter the setting graphic menu, as shown in the figure below
RETURN
-->
EXPOSURE
-->
FOUCS
AUTO
WB
-->
SYSTEM
-->
COLOR
-->
-->
（一）、EXPOSURE
1. Automatic mode
RETURN
-->
EXPOSURE
AUTO
GAIN
001
SHUTTER
018
IRIS
019
BRIGHT
019
EXPCOMP
0FF
LEVEL
007
BLC
0FF
2. Luminance priority mode
RETURN
-->
EXPOSURE
BRIGHT
GAIN
001

WWW.KINDLIVECAST.COM
Beijing kind network technology co.ltd.
9
SHUTTER
018
IRIS
019
BRIGHT
019
EXPCOMP
0FF
LEVEL
007
BLC
0FF
3. Gain priority
RETURN
-->
EXPOSURE
GAIN
GAIN
001
SHUTTER
018
IRIS
019
BRIGHT
019
EXPCOMP
0FF
LEVEL
007
BLC
0FF
4. SHUTTER
RETURN
-->
EXPOSURE
SHUTTER
GAIN
001
SHUTTER
018
IRIS
019

WWW.KINDLIVECAST.COM
Beijing kind network technology co.ltd.
10
BRIGHT
019
EXPCOMP
0FF
LEVEL
007
BLC
0FF
5. MANUAL
RETURN
-->
EXPOSURE
MANUAL
GAIN
001
SHUTTER
018
IRIS
019
BRIGHT
019
EXPCOMP
0FF
LEVEL
007
BLC
0FF
（二）FOUCS
RETURN
-->
EXPOSURE
AUTO
FOUCS
-->
WB
-->
SYSTEM
-->
COLOR
-->
-->

WWW.KINDLIVECAST.COM
Beijing kind network technology co.ltd.
11
(1) Auto focus
RETURN
-->
EXPOSURE
AUTO
FOUCS
AUTO
WB
-->
SYSTEM
-->
COLOR
-->
-->
（2）Manual foucs
RETURN
-->
EXPOSURE
AUTO
FOUCS
MANUAL
WB
-->
SYSTEM
-->
COLOR
-->
-->
（三）WB
RETURN
-->
WB
AUTO
RGAIN
211
BGAIN
156
1. Outdoor mode
RETURN
-->
WB
OUTDOOR
RGAIN
211

WWW.KINDLIVECAST.COM
Beijing kind network technology co.ltd.
12
BGAIN
156
2. Indoor mode
RETURN
-->
WB
INDOOR
RGAIN
211
BGAIN
156
3. One key white balance
RETURN
-->
WB
ONE PUSH
RGAIN
211
BGAIN
156
4. Automatic white balance
RETURN
-->
WB
ATW
RGAIN
211
BGAIN
156
（四）SYSTEM
RETURN
-->
EXPOSURE
AUTO
FOUCS
-->
WB
-->
SYSTEM
-->
COLOR
-->

WWW.KINDLIVECAST.COM
Beijing kind network technology co.ltd.
13
-->
RETURN
-->
WB
OUTDOOR
F-RATE
1080I50
RESET
OFF
Press the left arrow key to select a different resolution, and click PRSET to reset the
system.
RETURN
-->
EXPOSURE
AUTO
FOUCS
-->
WB
-->
SYSTEM
-->
COLOR
-->
-->
Press the left arrow key to appear the following picture
RETURN
-->
GAIN
004
HUE
007
You can adjust the GAIN and HUE parameters to adjust the color.
（五）IMAGE
RETURN
-->
EXPOSURE
AUTO
FOUCS
-->
WB
-->
SYSTEM
-->
COLOR
-->

WWW.KINDLIVECAST.COM
Beijing kind network technology co.ltd.
14
-->
Press the left arrow key to appear the following picture
RETURN
-->
E-PLIP
OFF
LR REV
OFF
RREEZE
OFF
B＆W
OFF
STAB
OFF
COL BAR
OFF
SRZ MOD
OFF
The preceding function options are in the OFF state by default.
四、Remote control debugging instructions

WWW.KINDLIVECAST.COM
Beijing kind network technology co.ltd.
15
①HOME button: Press once to bring the lens to the starting point.
②CAMERA: Switches the address of the control camera, which must correspond
to the dip switch of the camera. After the switch, you can set the camera.
③Auto focus button: You can directly use this key to control the one-button
focus of the camera.
④Manual focus mode: Press this key to switch the camera's focus mode to
manual focus mode.
⑤4K signal switch key: Use this key to switch to 4K30 signal with one click (after
setting, you need to restart the camera to make it take effect).
⑥1080 i50 Signal Switch key: Use this key to switch to 1080 i50 signal with one
key (After setting, you need to restart the camera for the setting to take effect).
⑦Single white balance: This button is pressed once to achieve a white balance.
⑧Single focus: This button is pressed once to achieve one focus.
⑨Single Stop: This button is pressed once to achieve one stop exposure.
⑩Adjust camera focus: + for pull in - for pull out.
⑪Focus button: After the automatic focus is changed to manual focus，
⑫Adjust aperture：Change the shutter speed
⑬Menu key: You can open all the function options of the camera. All the
contents of the camera instructions can be manipulated from the options.
⑭Up, down, left and Right keys: After entering the menu interface, you can
select the contents of the menu by pressing the up, down, left and right keys.
⑮Ok key: Press this key to confirm after selecting the option.
⑯CALL key: Select the confirm key for the preset point.
⑰SET key: Confirm key for setting camera preset points.

WWW.KINDLIVECAST.COM
Beijing kind network technology co.ltd.
16
⑱CLEAR key: Confirm key to clear preset points.
⑲Preset point selection key: 9 groups of preset points can be selected.
Steps to set preset points
⑴Position the camera.
⑵Select one of the keys 1-9.
⑶Press the SET key to complete the setting.
Invoke the preset point step：
⑴Select the prefab bit key that was set earlier.
⑵Press the CALL key and the camera lens will return to the preset position.
Clear preset point step：
⑴Select the preset key you want to delete.
⑵Click the CLEAR key to complete the clearing
After the camera is started, the lens is not in the starting position (the camera
will be in the center position after the camera is started). Firstly, press the 0 key,
and then press the CLEAR key to power off and restart the camera. After the
camera is started, the lens will return to the middle position.
五、Packing list
LIVECAM STATION, packing suitcase, instruction manual (electronic file), warranty
card, certificate of qualification

WWW.KINDLIVECAST.COM
Beijing kind network technology co.ltd.
17
六、After-sales service
1. The warranty period is 12 months from the date of sale. During the limited
warranty period, you will enjoy free warranty service for product faults, which
will be repaired by users or sent to the company (faults caused by improper
use, human failure or irresistible causes do not belong to the warranty scope)..
2. In the limited warranty period of more than 12 months, the fault of the
product will be paid lifetime maintenance service.
3. From the date when users send products to the company, 24 hours response
service, switchboard telephone：[phone].
4. Before sending the product back to our company, please contact the relevant
technical personnel of our company in advance and then send the product
back to our company. Otherwise, the maintenance is not timely, so as not to
affect your use.
BEIJING KIND NETWORK TECHNOLOGY CO.LTD
Address: 16C, Unit 1, Building C, Yingdu PLAZA, No. 48, Zhichun Road, Haidian
District, Beijing.
Official website:WWW.KINDLIVECAST.COM
Zip Code: 100086
Phone: [phone]
