COPYRIGHT © 2012 ALL RIGHTS RESERVED BY KING CANADA TOOLS INC.
3/8” VARIABLE SPEED
RIGHT A GLE DRILL
I STRUCTIO MA UAL
MODEL: 8310AD

WARRA TY I FORMATIO
2-YEAR
LIMITED WARRANTY
FOR THIS RIGHT ANGLE DRILL
KI G CA ADA TOOLS
OFFERS A 2-YEAR LIMITED WARRANTY
FOR NON-COMMERCIAL USE.
PROOF OF PURCHASE
Please keep your dated proof of purchase for warranty and servicing purposes.
LIMITED TOOL WARRANTY
King Canada makes every effort to ensure that this product meets high quality and
durability standards. King Canada warrants to the original retail consumer a 2-year
limited warranty as of the date the product was purchased at retail and that each
product is free from defects in materials. Warranty does not apply to defects due
directly or indirectly to misuse, abuse, normal wear and tear, negligence or
accidents, repairs done by an unauthorized service center, alterations and lack of
maintenance. King Canada shall in no event be liable for death, injuries to persons
or property or for incidental, special or consequential damages arising from the use
of our products.
To take advantage of this limited warranty, return the product at your expense
together with your dated proof of purshase to an authorized King Canada service
center. Contact your retailer or visit our web site at www.kingcanada.com for an
updated listing of our authorized service centers. In cooperation with our
authorized serviced center, King Canada will either repair or replace the product if
any part or parts covered under this warranty which examination proves to be
defective in workmanship or material during the warranty period.
NOTE TO USER
This instruction manual is ment to serve as a guide only. Specifications and
references are subject to change without prior notice.
KI G CA ADA I C. DORVAL, QUÉBEC, CA ADA H9P 2Y4
www.kingcanada.com

1. K OW YOUR TOOL
Read and understand the instruction manual and labels affixed to the tool. Learn its
application and limitations as well as its specific potential hazards.
2. Don’t use power tools in damp or wet locations or expose them to rain. Keep work area
well lit and provide adequate surrounding work space.
3. USE RIGHT TOOL.
Don’t force the tool or the attachment to do a job for which it was not designed.
4. WEAR PROPER APPAREL.
Do not wear loose clothing, gloves, neckties or jewelry (rings, watch) because they
could get caught in moving parts. Non-slip footwear is recommended. Wear protective
hair covering to contain long hair. Roll up long sleeves above the elbows.
5. MAI TAI TOOL WITH CARE.
Keep tool clean for best and safest performance. Follow instructions for operation and
changing accessories.
6. DISCO ECT TOOLS.
Before servicing, when changing accessories or attachments.
7. AVOID ACCIDE TAL STARTI G.
Make sure the switch is in the ‘’OFF’’ position before plugging in.
8. USE RECOMME DED ACCESSORIES.
Consult the manual for recommended accessories. Follow the instructions that
accompany the accessories. The use of improper accessories may cause hazards.
9. CHECK FOR DAMAGED PARTS.
Before further use of the tool, a guard or other parts that are damaged should be
carefully checked to ensure they will operate properly and perform their intended
function. Check for alignment of moving parts, breakage of parts, mounting, and any
other conditions that may affect its operation. A guard or other parts which are
damaged should be properly repaired or replaced.
Specific Safety Instructions
1. If possible, use clamps or any other practical way to secure and support the workpiece to
a stable platform. Holding the work by hand or against your body is unstable and may
lead to loss of control.
2. Do not use the tool if switch does not turn it on or off. Any tool that cannot be controlled
with the switch is dangerous and must be repaired.
3. Do not allow the power cord to contact the rotating accessory as the cord may become
quickly tangled. If this happens, turn the tool off immediately, unplug from the power
source and untangle the power cord.
4. Remove chuck key from chuck before turning the power tool on. Personal injury will result if
the power tool is turned on with the chuck key installed in the chuck.
5. Hold the tool by its insulated gripping surfaces when performing an operation where cutting
tools may contact hidden “live” wiring or its own cord. Contact with a “live” wire will
make exposed metal parts of the tool “live” and shock the operator.
6. Do not abuse the power cord. Do not use it to carry, pull or unplug the tool from the power
source. Keep power cord away from heat, oil, moving parts and sharp edges. A
damaged power cord will increase the risk of electric shock.
GE ERAL & SPECIFIC
SAFETY I STRUCTIO S

ELECTRICAL I FORMATIO
WAR I G: The warnings, cautions, and instructions discussed in this instruction manual
cannot cover all possible conditions and situations that may occur. It must be understood
by the operator that common sense and caution are factors which cannot be built into
this product, but must be supplied by the operator.
Note: Performance of this tool may vary depending on variations in local line voltage.
Extension cord usage may also affect tool performance.
VOLTAGE WAR I G
Before connecting the tool to a power source (receptacle, outlet, etc.) be sure the
voltage supplied is the same as that specified on the nameplate of the tool. If one says
120V and the other says 115V then there will be no complications. Never try to plug a
120V tool into a 240V outlet, or the other way around. A voltage greater than that speci-
fied on the tool can result in SERIOUS I JURY to the user, as well as damage to the tool. If
in doubt, DO OT PLUG I THE TOOL.
DOUBLE I SULATIO
Double insulated tools are equipped with a polarized two-prong plug (one blade is wider
than the other). This plug will fit in a polarized outlet only one way. If the plug does not fit
fully into the outlet, reverse the plug. If it still does not fit, contact a qualified electrician
to install a polarized outlet. Do not alter or change the plug in any way. Double insulation
eliminates the need for three wire grounded power supply and grounded power cords.
EXTE SIO CORDS
Improper use of extension cords may cause inefficient operation of your tool which can
result in overheating. Be sure your extension cord is rated to allow sufficient current flow
to the motor. If you are using the tool outdoors, use an extension cord rated for outdoor
use (signified by “WA” on the jacket).
The extension cord must have a minimum wire size depending on the amperage of the
tool and the length of the extension cord. This size is determined by its AWG (American
Wire Gauge) rating. The smaller the gauge, the greater the cable’s capacity. The amount
of cords used does not matter: Total length determines the minimum AWG rating. Every
cord must meet the AWG rating. Use the chart below to determine what AWG rating is
required for your situation. Cord length is rated in feet.
LENGTH OF
CONDUCTOR
0-25 FEET
26-50 FEET
51-100 FEET
WIRE SIZE REQUIRED
(AMERICAN WIRE GAUGE)
120V LINES
NO.16
NO.16
NO.14

GETTI G TO K OW YOUR TOOL
1. 3/8” keyed chuck
2. Forard/Reverse switch
3. Variable speed trigger
4. Trigger lock-on button
5. Chuck key
6. Carbon brush cap (1 of 2)
7. Power cord (polarized plug)
8. Power-on indicator LED
SPECIFICATIO S
Model ..................................................................................................................8310ADN
Chuck size....................................................................................................3/8” (Ø10mm)
Amperage ....................................................................................................................3.5A
No load speed (RPM)..............................................................................0-1,600 (variable)
Voltage ........................................................................................................................120V
Cycle/Phase ................................................................................................60Hz, 1 phase
Insulation class........................................................................................................Double

OPERATIO
FIXI G & CHA GI G DRILL BIT
1) Turn the Right Angle Drill off first.
2) Clean the shivers and any other foreign objects
away from the bit (A) Fig.1 and chuck (B),
otherwise the bit might not be tightened
securely and thus will induce severe personal
injuries.
3) Insert the bit into the chuck, make sure that the
bit is in as far as it will go.
4) Place the chuck key (C) in one of the 3 holes,
then tighten all three jaws of the chuck by
rotating the chuck key clockwise.
WAR I G! More than 1/3 of the general length of the drill bit must protrude out of the chuck jaws.
5) When dismantling the drill bit, loosen the three jaws with the chuck key, then remove
the drill bit.
OTE: Always remove chuck key before restarting drill.
TRIGGER & LOCK-O BUTTO
WAR I G: Before pluging into power source, make sure the trigger switch can be pressed
down smoothly and will return to its “OFF” position when the trigger is released. This
power tool is equipped with a “Trigger Lock-On” button which is convenient when
continuous operation for extended periods of time is required.
1) Press down trigger switch (A) Fig.2 to start tool,
release to stop. This tool can operate at
different speeds, the speed can be adjusted by
the pressure applied to the trigger switch.
2) For continuous operation, press down the
trigger switch (A) Fig.2 and push the “Trigger
Lock-on” button (B) located on the side of the
handle, then release the trigger.
3) The tool will continue running until the release
of the “Lock-on” button. To stop the tool, press
then release the trigger switch.
4) When “Lock-on” feature is engaged during use
and the tool becomes disconnected from the power supply, disengage the “Lock-on”
feature immediately by pressing then releasing the trigger switch.
REVERSIBLE ROTATI G DIRECTIO (FORWARD/REVERSE)
The rotating direction of the drill is controlled by Fwd/Rev. switch (C) Fig.2 located above
the trigger.
•With the drill held in normal operating position, the Fwd/Rev. switch should be pushed to
the right side of the trigger for forward drilling operation.
• Direction of rotation is in reverse when the Fwd/Rev. switch is pushed to the left side of the
trigger.
OTE: The drill will not operate unless the Fwd/Rev. switch is pushed fully to the left or right.
Figure 1
Figure 2

OPERATIO
Operational Guidelines
The working materials should be within: “wood, metal, plastic, resin board, concrete”.
• When drilling hard, smooth surfaces, use a center punch to mark the desired hole
location. This will prevent the drill from slipping off center as the hole is started.
• The working material should be secured in a device or with clamps to keep it from
moving as the drill bit rotates.
Drilling Wood or Plastic
It is recommended to start the drill slowly and gradually increase the speed as you drill
into wood or plastics. Use low speeds for plastics with a low melting point. If backup
material is not used, ease up on the pressure just before the bit breaks through the wood
to avoid splintering. Finish the hole from the opposite side after the point breaks through.
If it binds, reverse the drilling operation to help remove the bit from the work.
Drilling Metal
It is recommended to use high speed steel (HSS) carbide tipped drill bits on metal. Use
low speed for very hard metals and high speed for softer metals. Make a center punch in
the metal to be drilled for easier starting. Use just enough pressure to keep the bit cutting.
Lubricate the tip of the bit occasionally with light oil for easier metal drilling. If it binds,
reverse the drilling operation to help remove the bit from the work.
Drilling Masonry
Use carbide-tipped masonry bits for cinder blocks, mortar, common brick, soft stone and
other materials. The amount of pressure to be used is dependent upon the type of
material being drilled. Less pressure is needed for soft materials and more pressure for
harder materials.
Stalling
If the drill bit has a tendency to bind or stall during an operation, maintain a firm grip and
reduce the tool pressure slightly to allow the drill bit to regain speed. If the tool does stall,
release the trigger immediately. Change the rotational direction of the drill bit using the
Fwd/Rev switch and remove the bit from the workpiece and start again.

MAI TE A CE
IMPORTA T: To assure product SAFETY and RELIABILITY, repairs, maintenance and
adjustments should be performed by an authorized service center or other qualified
service technician, always using identical replacement parts.
1) Air vents of the tool should be cleaned regularly to avoid overheating of the motor which
is caused by the blocking of the air vents.
2) DON’T clean this tool with water, as no liquid is allowed in the tool body. Clean the tool
with a dry clean cloth only. Compressed air at low pressure is also suitable.
3) DON’T allow petroleum based products to come into contact with the plastic parts of
the tool, as they contain chemicals that can damage or destroy the plastic parts.
CARBO BRUSHES
Remove and check the carbon brushes regularly
(normally after 50 hours of use). The carbon
brushes are installed inside the motor housing.
Using a screwdriver, remove the carbon brush
caps (A) Fig.3 on both sides of the motor housing.
Remove the carbon brush (B) from the motor
housing and inspect it. Repeat this step for the
second carbon brush. Carbon brushes need to be
replaced once they wear down to the small limit
mark as shown in Fig.4. Keep the carbon brushes
clean and free to slip in the holders.
If they have worn down to the limit mark,
purchase a set of identical replacement carbon
brushes (both carbon brushes should be replaced at the same time). Install new carbon
brushes and reinstall the carbon brush caps.
If you are unsure about these instructions, we recommend that you get a qualified service
technician to replace the carbon brushes. Contact a King Canada service centre.
MAI TE A CE
Figure 4
Carbon brush limit mark
Figure 3
