King Canada KC-3010 Troubleshooting guide

Service Manual / Manuel de Service
10” Sliding Tile Saw with Laser Guide
Scie à Céramique Radiale 10” avec Guide à Laser
KC-3010
Revised/Revisé 08/2008 Table & Stand Diagram /
Diagramme de la Table et du Support

Service Manual / Manuel de Service
10” Sliding Tile Saw with Laser Guide
Scie à Céramique Radiale 10” avec Guide à Laser
KC-3010
Revised/Revisé 08/2008 Motor Diagram / Diagramme du Moteur

Service Manual / Manuel de Service
10” Sliding Tile Saw with Laser Guide
Scie à Céramique Radiale 10” avec Guide à Laser
KC-3010
Revised/Revisé 08/2008 Laser Assembly & Tubing Diagram /
Diagramme de L’Ens. du Laser et du Boyeau

Parts Pricing List / Liste de Prix des Pièces KC-3010
Diag.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
35
36
37
38
39
40
41
42
43
44
45
46
47
48
Order # Com.
7730100010
7730100020
7730100030
7730100040
7730100050
7730100060
7730100070
7730100080
7730100090
7730100100
7730100110
7730100120
7730100130
7730100140
7730100150
7730100160
7730100170
7730100180
7730100190
7730100200
7730100210
7730100220
7730100230
7730100240
7730100250
7730100260
7730100270
7730100280
7730100290
7730100300
7730100310
7730100320
7730100330
7730100350
7730100360
7730100370
7730100380
7730100390
7730100400
7730100410
7730100420
7730100430
7730100440
7730100450
7730100460
7730100470
7730100480
English Description
HEX. NUT
LOCK WASHER
WATER TANK
WASHER
HEX. BOLT
RUBBER PLUG
ALUMINUM GUIDE
PLASTIC INSERT
PRESSING PLATE
PAN HD SCREW
MACHINE FRAME
HEX. NUT
HEX. BOLT
HEX. BOLT
LOCK WASHER
WASHER
ADJUSTING PLATE
CARRYING HANDLE
STAND LEG (WITH WHEEL BRACKET)
NYLON HEX. NUT
STAND LEG
HEX. BOLT
HEX. BOLT
PIVOT WHEEL
WASHER
HEX. NUT
PLASTIC INSERT
HEX. BOLT
SET SCREW
HEX. BOLT
LOCK KNOB
WASHER
SLEEVE
STEEL COLUMN
SHAFT
CARRIAGE BOLT
ALUMINUM BASE
MOTOR ADJUSTING BAR
WASHER
HEX. BOLT
MOTOR PULLEY
SET SCREW
KEY
MOTOR
HEX. NUT
LOCK WASHER
WASHER
Description Française
ECROU HEXAGONAL
RONDELLE A RESSORT
RESERVOIR
RONDELLE
BOULON HEXAGONAL
BOUCHON EN CAOUTCHOUC
GUIDE EN ALUMINIUM
INSERTION EN PLASTIQUE
PLAQUE
VIS A TETE BOMBEE
CHASSIS
ECROU HEXAGAONAL
BOULON HEXAGAONAL
BOULON HEXAGAONAL
RONDELLE A RESSORT
RONDELLE
PLAQUE D'AJUSTEMENT
POIGNEE
JAMBE DU SUPPORT (A/SUP./ ROUL.)
ECROU HEXAGONAL AVEC NYLON
JAMBE DU SUPPORT
BOULON HEXAGONAL
BOULON HEXAGONAL
ROUE PIVOTANTE
RONDELLE
ECROU HEXAGONAL
INSERTION EN PLASTIQUE
BOULON HEXAGONAL
VIS SANS TETE
BOULON HEXAGONAL
BOUTON DE VERROUILLAGE
RONDELLE
MANCHON
COLONNE EN ACIER
TIGE
BOULON DE CARROSSERIE
BASE EN ALUMINIUM
BARRE D'AJUSTEMENT DU MOTEUR
RONDELLE
BOULON HEXAGONAL
POULIE DU MOTEUR
VIS SANS TETE
CLE DE RETENUE
MOTEUR
ECROU HEXAGONAL
RONDELLE A RESSORT
RONDELLE
Price/Prix
$1.67
$1.55
$80.49
$1.61
$1.67
$5.69
$20.53
$2.24
$4.08
$1.67
$97.69
$1.61
$1.55
$1.90
$1.55
$1.67
$3.97
$5.69
$68.94
$1.67
$63.19
$2.24
$2.13
$14.89
$1.55
$1.67
$2.47
$2.59
$2.01
$2.13
$9.14
$1.67
$5.69
$74.69
$20.64
$2.01
$103.44
$6.84
$1.67
$2.70
$17.19
$2.01
$2.13
$212.75
$1.61
$1.67
$1.55
Pricing subject to change without prior notice. / Prix sujet à changement sans préavis.
Qty./Qté.
2
8
1
2
2
1
1
2
2
6
1
6
2
2
7
4
2
2
1
2
1
2
8
2
18
8
1
2
1
1
1
1
1
1
1
4
1
1
1
1
1
2
2
1
4
18
20

Parts Pricing List / Liste de Prix des Pièces KC-3010
Diag.
51
52
53
54
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
Order # Com.
7730100510
7730100520
7730100530
7730100540
7730100560
7730100570
7730100580
7730100590
7730100600
7730100610
7730100620
7730100630
7730100640
KSC-10DB
7730100660
7730100670
7730100680
7730100690
7730100700
7730100710
7730100720
7730100730
7730100740
7730100750
7730100760
7730100770
7730100780
7730100790
7730100800
7730100810
7730100820
7730100830
7730100840
7730100850
7730100860
7730100870
7730100880
7730100890
7730100900
7730100910
7730100920
7730100930
7730100940
7730100950
7730100960
7730100970
7730100980
English Description
RUBBER BACKSPLASH
WASHER
KNOB
PAN HD SCREW
SMALL SHAFT
SLEEVE
WASHER
HEX. BOLT
BLADE GUARD
COUNTERSUNK SCREW
RUBBER PAD
BALL BEARING
INNER FLANGE
10" BLADE
OUTER FLANGE
HEX. NUT
SPINDLE LOCK SHAFT
PAN HD SCREW
SPINDLE LOCK HOLDER
RETAINING RING "E"
SPRING
RUBBER WASHER
BELT
PULLEY COVER
PAN HD SCREW
POSITION PLATE
PAN HD SCREW
SPINDLE PULLEY
SPINDLE
SPINDLE SLEEVE
SLIDING GUIDE
ALUMINUM COVER
90 DEGREE RIP GUIDE
45 DEGREE BEVEL GUIDE
LOCK KNOB
HEX. BOLT
ROLLING TUBE
HEX. BOLT
STEEL PLATE
FRONT TABLE
HEX. BOLT
HEX. BOLT
EXTENSION TABLE
HEX. NUT
HEX. BOLT
LOCK WASHER
WASHER
Description Française
BAVETTE ANTI-ECLABOSSURE
RONDELLE
BOUTON
VIS A TETE RONDE
PETITE TIGE
MANCHON
RONDELLE
BOULON HEXAGONAL
PROTEGE-LAME
VIS A TETE FRAISEE
TAMPON EN CAOUTCHOUC
ROULEMENT A BILLES
RONDELLE INTERIEURE
LAME 10"
RONDELLE EXTERIEURE
ECROU HEXAGONAL
TIGE DU VERROU DE L'ARBRE
VIS ATETE BOMBEE
PORTE-VERROU DE L'ARBRE
ANNEAU DE RETENU "E"
RESSORT
RONDELLE EN CAOUTCHOUC
COURROIE
COUVERCLE DES POULIES
VIS A TETE BOMBEE
PLAQUE DE POSITIONNEMENT
VIS A TETE BOMBEE
POULIE DE L'ARBRE
ARBRE
MANCHON DE L'ARBRE
GUIDE COULISSANT
COUVERCLE EN ALUMINUM
GUIDE A REFENDRE 90 DEGRES
GUIDE EN BISEAU 45 DEGRES
BOUTON DE VERROUILLAGE
BOULON HEXAGONAL
TUBE DE ROULEMENT
BOULON HEXAGONAL
PLAQUE EN ACIER
TABLE AVANT
BOULON HEXAGONAL
BOULON HEXAGONAL
EXTENSION DE TABLE
ECROU HEXAGONAL
BOULON HEXAGONAL
RONDELLE A RESSORT
RONDELLE
Price/Prix
$5.58
$1.67
$7.99
$1.55
$6.84
$6.73
$1.67
$1.90
$51.69
$1.84
$25.24
$12.59
$9.14
-
$5.69
$2.24
$3.74
$1.55
$5.23
$1.55
$4.31
$2.47
$11.44
$34.44
$1.61
$25.24
$1.55
$11.44
$18.34
$20.64
$51.69
$74.69
$17.19
$63.19
$4.54
$2.07
$3.39
$1.67
$5.23
$63.19
$1.78
$1.67
$17.19
$1.61
$1.78
$1.67
$1.55
Pricing subject to change without prior notice. / Prix sujet à changement sans préavis.
Qty./Qté.
1
1
1
1
1
1
1
1
1
3
1
2
1
1
1
1
1
2
1
1
1
1
1
1
2
1
4
1
1
1
1
1
1
1
4
1
1
2
1
1
2
4
1
2
2
2
2

Parts Pricing List / Liste de Prix des Pièces KC-3010
Diag.
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
117-2
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
Order # Com.
7730100990
7730101000
7730101010
7730101020
7730101030
7730101040
7730101050
7730101060
7730101070
7730101080
7730101090
7730101100
7730101110
7730101120
7730101130
7730101140
7730101150
7730101160
7730101170
7730101172
7730101180
7730101190
7730101200
7730101210
7730101220
7730101230
7730101240
7730101250
7730101260
7730101270
7730101280
7730101290
7730101300
7730101310
7730101320
7730101330
7730101340
7730101350
7730101360
773010MBIL
English Description
MAIN TABLE
TUBE
SPECIAL RETAINING RING
STEEL INSERT
NYLON INSERT
SLIDING TUBE
PUMP ASSEMBLY
RUBBER PAD
45 DEGREE RIP GUIDE
RUBBER WASHER
THICK WASHER
WASHER
WASHER
LOCK WASHER
LOCK WASHER
WASHER
WASHER
WASHER
TAPPING SCREW (POINTED)
WASHER
LASER GUIDE ASSEMBLY
TOGGLE SWITCH W/WATERPR. CAP
RESET BUTTON W/WATERPROOF CAP
POWER CORD CLIP
SWITCH BOX
SWITCH PLATE
POWER CORD
LASER BRACKET
PAN HD SCREW
SPRING WASHER
WASHER
WATER NOSE
PLASTIC NUT
PLASTIC TWO-WAY ADAPTOR
O-RING
THIN HEX. NUT
WATER HOSE
PLASTIC ONE-WAY ADAPTOR
LONG WATER HOSE
BILINGUAL MANUAL KC-3010
Description Française
TABLE PRINCIPALE
TUBE
ANNEAU DE RETENU SPECIAL
INSERTION EN ACIER
INSERTION EN NYLON
TUBE COULISSANT
POMPE A EAU ASSEMBLEE
TAMPON EN CAOUTCHOUC
GUIDE A REFENDRE 45 DEGRES
RONDELLE EN CAOUTCHOUC
RONDELLE EPAISSE
RONDELLE
RONDELLE
RONDELLE A RESSORT
RONDELLE A RESSORT
RONDELLE
RONDELLE
RONDELLE
VIS AUTOTARADEUSE (POINTUE)
RONDELLE
GUIDE AU LASER ASSEMBLE
INTERRUPTEUR AVEC CAPUCHON
DISJONCTEUR DE SECURITE A/CAP.
ATTACHE CORDON
BOITIER DE L'INTERRUPTEUR
PLAQUE DE L'INTERRUPTEUR
CORDON D'ALIMENTATION
SUPPORT DU LASER
VIS A TETE BOMBEE
RONDELLE A RESSORT
RONDELLE
BUSE D'EAU
ECROU EN PLASTIQUE
RACCORD EN PLASTIQUE A 2 VOIES
JOINT TORIQUE
ECROU HEXAGONAL MINCE
BOYAU A EAU
RACCORD EN PLASTIQUE A UNE VOIE
BOYAU A EAU LONG
MANUEL BILINGUE KC-3010
Price/Prix
$155.25
$4.54
$3.39
$4.89
$4.54
$37.89
$103.21
$28.69
$17.08
$2.82
$2.13
$1.50
$1.55
$1.55
$1.55
$1.67
$1.50
$1.67
$1.67
$1.55
$40.19
$17.19
$20.64
$2.01
$17.19
$17.19
$22.94
$11.44
$1.55
$1.55
$1.55
$5.69
$3.39
$4.54
$2.01
$2.24
$3.74
$4.31
$7.99
$15.00
Pricing subject to change without prior notice. / Prix sujet à changement sans préavis.
Qty./Qté.
1
2
2
2
2
1
1
1
1
2
2
4
6
6
7
1
4
2
2
2
1
1
1
1
1
1
1
1
4
4
4
2
3
1
2
2
1
1
1
1
